Miele TepanYaki CS 1327 User manual

Operating and installation instructions
Stainless steel TepanYaki
CS 1327
To avoid the risk of accidents or
damage to the appliance it is
essential to read these
instructions before it is installed
and used for the first time. M.-Nr. 09 054 670
en-GB

Guide to the appliance .............................................3
Warning and Safety instructions .....................................4
Caring for the environment.........................................11
Before using for the first time.......................................12
Operation .......................................................13
Switching on and off ...............................................13
Residual heat indicator .............................................13
Settings .........................................................14
Tips ............................................................15
Cleaning and care ................................................16
Problem solving guide ............................................18
Optional accessories..............................................19
Safety instructions for installation...................................20
Appliance and building-in dimensions ...............................24
Preparing the worktop.............................................25
Installation of several appliances....................................26
Fixing the spring clamps and spacer bars ............................28
Installing the appliance(s)..........................................30
General installation tips ...........................................31
Electrical connection..............................................32
After sales service, data plate, guarantee .............................34
Contents
2

aRear cooking zone
bFront cooking zone
cSymbols to indicate which cooking
zone the controls are for
dIndicators
eControl for rear cooking zone
fControl for front cooking zone
Indicators
gIn-operation indicator
hTemperature indicator light
iResidual heat indicator
Guide to the appliance
3

This appliance complies with all current safety requirements.
Inappropriate use can, however, lead to personal injury and
damage to property.
To avoid the risk of accidents and damage to the appliance,
please read these instructions carefully before installation and
before using it for the first time. They contain important notes on
installation, safety, use and maintenance. Miele cannot be held
liable for damage caused by non-compliance with these Warning
and Safety instructions.
Keep these instructions in a safe place and ensure that new users
are familiar with the content. Pass them on to any future owner.
Warning and Safety instructions
4

Correct application
~This Tepan Yaki is not designed for commercial use. It is intended
for use in domestic households and similar working and residential
environments.
~The appliance is not intended for outdoor use.
~It is intended for domestic use only to cook food and keep it
warm. Any other use is not supported by the manufacturer and
could be dangerous.
~The appliance can only be used by people with reduced
physical, sensory or mental capabilities, or lack of experience and
knowledge, if they are supervised whilst using it, or have been
shown how to use it in a safe way and understand the hazards
involved.
Warning and Safety instructions
5

Safety with children
~Children under 8 years of age must be kept away from the
appliance unless they are constantly supervised.
~Children 8 years and older may only use the appliance if they
have been shown how to use it in a safe way and understand the
hazards involved.
~Children must not be allowed to clean the appliance
unsupervised.
~This appliance is not a toy! To prevent the risk of injury, do not
allow children to play with the appliance or its controls.
~The appliance gets hot when in use and remains hot for a while
after being switched off. Keep children well away from the appliance
until it has cooled down and there is no danger of burning.
~Danger of suffocation. Packaging, e.g. cling film, polystyrene and
plastic wrappings, must be kept out of the reach of babies and
children. Whilst playing, children could become entangled in
packaging, ( e.g. plastic wrapping) or pull it over their head and
suffocate.
~Danger of burning.
Do not store anything which might arouse a child's interest in
storage areas above or behind the appliance. Otherwise they could
be tempted into climbing onto the appliance
Warning and Safety instructions
6

Technical safety
~Installation, maintenance and repairs may only be carried out by
a Miele-authorised person. Installation, maintenance and repairs by
unqualified persons could be dangerous.
~A damaged appliance can be dangerous. Check the appliance
for visible signs of damage. Do not use a damaged appliance.
~The electrical safety of this appliance can only be guaranteed if
correctly earthed. It is most important that this basic safety
requirement is observed and regularly tested, and where there is
any doubt, the household wiring system should be inspected by a
qualified electrician.
~To avoid the risk of damage to the appliance, make sure that the
connection data (frequency and voltage) on the data plate
corresponds to the household supply, before connecting the
appliance to the mains supply.
Consult a qualified electrician if in any doubt.
~Do not connect the appliance to the mains electricity supply by a
multi-socket adapter or an extension lead. These are a fire hazard
and do not guarantee the required safety of the appliance.
~For safety reasons, this appliance may only be used after it has
been built in.
~This appliance must not be used in a non-stationary location (e.g.
on a ship).
Warning and Safety instructions
7

~Do not open the casing of the appliance.
Tampering with electrical connections or components and
mechanical parts is highly dangerous to the user and can cause
operational faults.
~While the appliance is under guarantee, repairs should only be
undertaken by a service technician authorised by Miele. Otherwise
the guarantee is invalidated.
~The manufacturer can only guarantee the safety of the appliance
when original Miele replacement parts are used. Faulty components
must only be replaced by genuine Miele original spare parts.
~The appliance is not intended for use with an external timer
switch or a remote control system.
~If the plug is removed from the connection cable or if the
appliance is supplied without a plug, the appliance must be
connected to the electrical supply by a suitably qualified electrician.
If the connection cable is faulty, it must be replaced with a special
connection cable. See "Electrical connection".
~The appliance must be disconnected from the mains electricity
supply during installation, maintenance and repair work. Ensure that
power is not supplied to the appliance until after it has been
installed or until any maintenance or repair work has been carried
out.
~Do not use the appliance if it is faulty. Switch it off immediately
and disconnect it from the mains electricity supply.
~In areas which may be subject to infestation by cockroaches or
other vermin, pay particular attention to keeping the appliance and
its surroundings clean at all times. Any damage caused by
cockroaches or other vermin will not be covered by the guarantee.
Warning and Safety instructions
8

Correct use
~Oil and fat are potential fire hazards as they can ignite if
overheated. Do not leave the appliance unattended when cooking
with oil or fat.
If oil or fat does catch fire, do not attempt to put out the flames with
water. Disconnect the appliance from the mains and use a suitable
fire blanket, saucepan lid, damp towel or similar to smother the
flames.
~Flames could set the grease filters of a cooker hood on fire. Do
not flambé under a cooker hood.
~Spray canisters, aerosols and other inflammable substances can
ignite when heated. Therefore do not store such items or
substances in a drawer under the appliance. Cutlery inserts must be
heat-resistant.
~Do not heat up unopened tins of food on the appliance, as
pressure will build up in the tin, causing it to explode.
~Do not cover the appliance, e.g. with a hob cover, a cloth or
protective foil. The material could catch fire, shatter or melt if the
appliance is switched on by mistake or if residual heat is still
present.
~When using an electrical appliance, e.g. a hand-held food
blender, near the appliance, ensure that the cable of the electrical
appliance cannot come into contact with the hot appliance. The
insulation on the cable could become damaged.
~If the appliance is installed behind a kitchen furniture door, it may
only be used with the furniture door open. Do not close the door
whilst the appliance is in use or whilst there is any residual heat
present.
Warning and Safety instructions
9

~The appliance gets hot when in use and remains hot for a while
after being switched off. There is a danger of burning until the
residual heat indicator goes out.
~You could burn yourself on the hot appliance. Protect your hands
with heat-resistant pot holders or gloves when handling hot pots and
pans. Do not let them get wet or damp, as this causes heat to
transfer through the material more quickly with the risk of scalding or
burning yourself.
~Where several appliances are installed side by side
Hot objects can damage the seal of the cover strip between the
appliances. Do not place hot pans near or on the cover strip.
~When the appliance is switched on either deliberately or by
mistake, or when there is residual heat present, there is the risk of
any metal items left on the appliance heating up, with the danger of
burning.
Depending on the material, other items left on the appliance could
also melt or catch fire.
Do not use the appliance as a resting place.
Switch the cooking zones off after use.
~Due to the high temperatures radiated, objects left near the
appliance when it is in use could catch fire. Do not use the
appliance to heat up the room.
~The appliance becomes very hot. Do not use plastic utensils.
Even heat-resistant plastic utensils are unsuitable.
Cleaning and care
~Danger of injury.
Do not use a steam cleaning appliance to clean this appliance. The
steam could reach electrical components and cause a short circuit.
Warning and Safety instructions
10

Disposal of the packing
material
The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.
Recycling the packaging reduces the
use of raw materials in the
manufacturing process and also
reduces the amount of waste in landfill
sites.
Ensure that any plastic wrappings,
bags, etc. are disposed of safely and
kept out of the reach of babies and
young children. Danger of suffocation.
Disposal of your old appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance.
Please do not therefore dispose of it
with your household waste.
Please dispose of it at your local
community waste collection/recycling
centre or contact your dealer for
advice. Ensure that it presents no
danger to children while being stored
for disposal.
Caring for the environment
11

Please stick the extra data plate for the
appliance supplied with this
documentation in the space provided in
the "service, data plate, guarantee"
section of this booklet.
Cleaning for the first time
^Remove any protective foil and sticky
labels.
^Clean with a solution of washing up
liquid in warm water, and dry with a
soft cloth.
Metal components have a protective
coating which may give off a slight
smell when heated up for the first
time.
The smell and any vapours will
dissipate after a short time, and do
not indicate a faulty connection or
appliance.
Before using for the first time
12

The Tepan plate is divided into two
separate cooking zones which can be
switched on and regulated
independently of one another. The
entire area can be used when cooking
large quantities of food. When cooking
smaller quantities, the front zone can
be used for cooking whilst the rear
zone can be used to keep food warm
using a lower power setting.
Switching on and off
To switch the Tepan plate on, turn the
control clockwise. To switch off, turn
the control anti-clockwise.
Only turn the control clockwise as
far as "12" and anti-clockwise back
to "0" again to switch it off. Do not
attempt to turn it all the way round
from the "12" position to "0" or vice
versa. This will damage the control.
After switching on, the in-operation
indicator Nand the temperature
indicator %light up. The temperature
indicator light will switch on and off
intermittently in conjunction with the
heating element.
Residual heat indicator
After switching off, the residual heat
indicator lights up.
The residual heat indicator remains on
until the Tepan plate is cool enough to
touch.
Do not touch or place any heat
sensitive objects on the Tepan plate
while the residual heat indicator is
still on.
Danger of burning and fire hazard.
Operation
13

Settings
Cooking process Settings
Keeping cooked food warm 1 - 2
Steaming fruit, e.g. apple slices, peach halves,
sliced bananas, etc.
2-4
Gentle stir frying of chopped/sliced vegetables, e.g.
leeks, mushrooms, green/red peppers, onion etc.
5-7
Gentle frying of breaded or battered fish 7 - 9
Rapid frying in succession of meat, fish
fried eggs, pancakes, hash browns etc.
9-11
Frying potato pancakes, prawns, corn-on-the-cob 11 - 12
These settings are only a guide. The actual cooking time will depend on the type
of food, its texture and thickness as well as personal taste.
Operation
14

Tips
Wipe the surface of the Tepan plate
before each use with a damp cloth
to remove any dust particles or other
soiling which may have settled on it
since it was last used.
–Pre-heat the Tepan plate thoroughly
for 8 -10 minutes at the power level
that you are going to be using for
cooking. Pre-heat at power level 12 if
you are going to be cooking at
settings 9-12.
– It is important to get the Tepan
sufficiently hot before use,
particularly when browning and
sealing meat. If it is not hot enough,
the meat will lose too much juice and
become tough.
– For frying only use the minimum
amount of oil or fat. With marinated
food, no fat or oil is needed. Wait
until the temperature indicator light
has gone out before adding cooking
fat.
–Only use fats and oils which can be
heated to high temperatures.
–Marinating often improves the flavour
of food to be cooked.
–Pat wet food dry with kitchen paper
before cooking to prevent it spitting.
–To prevent meat drying out, do not
season with salt until after it has
been cooked.
Operation
15

Miele offer a range of branded cleaning
products. See "Optional accessories".
,Do not use a steam cleaner to
clean this appliance.
The steam could reach electrical
components and cause a short
circuit.
The appliance should be cleaned after
each use. Let it cool down to room
temperature.
To avoid water marks and limescale
deposits, use a soft cloth to dry
surfaces that have been cleaned with
water.
To avoid damaging the surface of
your appliance, do not use:
–cleaning agents containing soda,
alkalines, ammonia, acids or
chlorides,
–cleaning agents containing
descaling agents,
–stain or rust removers,
–abrasive cleaning agents, e.g.
powder cleaners and cream
cleaners,
–solvent-based cleaning agents,
– dishwasher cleaner,
– grill and oven cleaners,
– glass cleaning agents,
– hard, abrasive brushes or sponges,
e.g. pot scourers, brushes or
sponges which have been previously
used with abrasive cleaning agents,
– sharp pointed objects
(these can damage the seal between
the frame and the worktop),
–melamine eraser blocks.
Cleaning and care
16

Follow the manufacturer's instructions
when using a stainless steel cleaning
agent.
Frying surface
Use a spatula to remove any large
particles immediately.
Allow the appliance to cool down until it
can be touched by hand, and then use
a solution of hot water and washing-up
liquid to soften the soiling. Clean the
surface with the pad of a non-scouring
sponge and a few drops Miele Ceramic
and stainless steel hob cleaning agent
(see "Optional accessories"). Finally
wipe with a damp cloth and dry
thoroughly.
Ensure that every trace of cleaning
agent has been removed from the
surface by wiping carefully with a
damp cloth. Any remaining traces
could affect food the next time you
use the appliance.
Important - Conditioning agents for
stainless steel must not be used on
the frying surface.
Stainless steel frame / control panel
Clean the frame and the control panel
with a few drops of Miele Ceramic and
stainless steel hob cleaning agent (see
"Optional accessories") and a soft,
damp cloth.
Printing (settings around the control
knob)
Do not use the ceramic and
stainless steel hob cleaning agent
on the printing as it would rub it off.
These areas should be only cleaned
with an E-Cloth or with a solution of
warm water and a little washing-up
liquid applied with a soft sponge.
Control knobs
Clean the control knobs with a solution
of warm water and a little washing-up
liquid applied with a soft sponge.
Stubborn soiling should be soaked first.
Finally dry all parts with a clean cloth.
Cleaning and care
17

Installation work and repairs to
electrical appliances must only be
carried out by a suitably qualified
and competent person in strict
accordance with current local and
national safety regulations. Repairs
and other work by unqualified
persons could be dangerous. The
manufacturer cannot be held liable
for unauthorised work.
What to do if...
... after switching on, the appliance
does not heat up
Check whether the mains fuse has
tripped. If it has, contact a qualified
electrician or Miele.
Problem solving guide
18

Miele offer a comprehensive range of useful accessories as
well as cleaning and conditioning products for your Miele
appliances.
These can be ordered online at:
or from Miele (see back cover for contact details).
Ceramic and stainless steel hob cleaner 250 ml
Removes heavy soiling, limescale deposits and light
discolouration
E-Cloth (microfibre cloth)
Removes fingerprints and light soiling.
Optional accessories
19

To avoid the risk of damaging the
TepanYaki fit the wall units and
extractor hood before installing it.
~The veneer or laminate coatings of
worktops (or adjacent kitchen units)
must be treated with 100 °C
heat-resistant adhesive which will not
dissolve or distort.
Any backmoulds must be of
heat-resistant material.
~The TepanYaki must not be installed
directly next to a salamander (CS
1421). It is essential to maintain a
distance of at least 150 mm between
these two appliances.
~Connection should be made via a
suitable isolator or a double pole fused
spur connection unit which complies
with current national and local safety
regulations, and the on/off switch
should be easily accessible after the
appliance has been built in. See
"Electrical connection" for more details.
~The appliance must not be built in
over a fridge, fridge-freezer, freezer,
dishwasher, washing machine or
tumble dryer.
~After installation, ensure that the
connection cable cannot come into
contact with the underside of the
appliance. Make sure that there is no
mechanical obstruction, such as a
drawer, which could damage it.
~Observe carefully the safety
distances given on the following pages.
All dimensions in this instruction booklet
are given in mm.
Safety instructions for installation
20
