Miele WT 2679 i WPM User manual

Operating instructions
Washer-dryer
WT 2679 i WPM
To avoid the risk of accidents
or damage to the machine
it is essential to read
these instructions before it is
installed and used for the first time.
G
M.-Nr. 06 630 570

Disposal of the packing material
The transport and protective packing
has been selected from materials which
are environmentally friendly for disposal
and can normally be recycled.
Ensure that any plastic wrappings,
bags etc. are disposed safely and kept
out of the reach of babies and young
children. Danger of suffocation!
Rather than just throwing these
materials away, please ensure they are
offered for recycling.
Disposal of your old appliance
Electrical and electronic appliances
often contain materials which, if
handled or disposed of incorrectly,
could be potentially hazardous to
human health and to the environment.
They are, however, essential for the
correct functioning of your appliance or
machine. Please do not therefore
dispose of it with your household waste.
Please dispose of it at your local
community waste collection / recycling
centre and ensure that it presents no
danger to children while being stored
for disposal.
It should be unplugged or disconnected
from the mains electricity supply by a
competent person. The plug must be
rendered useless and the cable cut off
directly behind it to prevent misuse.
See the "Warning and Safety" section of
this booklet for further details.
Caring for the environment
2

Caring for the environment . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 2
Warning and Safety instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 6
Guide to the machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Control panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 10
Display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Use. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
Before using for the first time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 12
Calibrating the load size sensor to zero . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Washing and drying environmentally . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
WASHING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Brief instructions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Separate washing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
Extra options . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Pre-wash. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Soak . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Short . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Water plus. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Buzzer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Adding or removing laundry after a programme has started . . . . . . . . . . . . . . . . 21
Spinning. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Rinse and interim spin . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
To omit the final spin (Rinse hold). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
To omit rinse and interim spin and the final spin . . . . . . . . . . . . . . . . . . . . . . . 22
Programme chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
Programme sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 27
Garment care label symbols . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Detergent . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
Water softeners. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Washing with several components . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Fabric conditioners or liquid starch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Automatic dispensing of fabric conditioner or liquid starch to laundry at
the end of a programme. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Adding fabric conditioner separately . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Adding starch separately . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Colour run and dye removers / dyes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
DRYING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Separate drying . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Contents
3

Extra option . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Low temperature. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Thermospin. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
Adding or removing laundry after a programme has started . . . . . . . . . . . . . . . . 35
Programme chart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
WASHING AND DRYING . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 40
Washing and drying in a continuous sequence . . . . . . . . . . . . . . . . . . . . . . . . . . 40
After each washing or drying programme. . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Rinse out fluff programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
Changing the programme sequence . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Cancelling a programme . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Interrupting a programme. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Altering a programme. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 43
Electronic programme locking . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 44
Delay start. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
Cleaning and care . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Cleaning the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
Cleaning the filter in the water inlet . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 48
Problem solving guide. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
What to do, if . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
The programme does not start. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 49
Fault messages in the display . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50
Problems with the load size indicator . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 51
General problems . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 52
An unsatisfactory wash result . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 53
An unsatisfactory drying result . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 54
The drum door cannot be opened by pressing the button. . . . . . . . . . . . . . 55
Opening the drum door in the event of a blocked drain outlet and/or
power failure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Drain the machine. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Opening the drum door . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 56
Cleaning the drain filter. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
After sales service . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Future updates (PC) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Appliance guarantee . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Optional accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 59
Contents
4

Installation and connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Front view. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 60
Rear view . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 61
Installation surface. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Installing the washer-dryer. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Removing the transit fittings . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
Levelling the machine . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 64
Building under a continous worktop / in a kitchen run . . . . . . . . . . . . . . . . . . . . . 65
Matching the fascia panel to the height of adjacent drawer fronts . . . . . . . . . . . . 66
Fitting the front panel . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 67
Fitting a door front panel made by another manufacturer. . . . . . . . . . . . . . . . . . . 68
Fitting a plinth facing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 69
The Miele water protection system . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 70
Connection to the water supply . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 71
Connection to the drainage system. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 72
Electrical connection U.K. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Consumption data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Note for test institutes: . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 74
Technical data . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 75
Settings menu J. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Language J. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
Time of day Y. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Water plus T. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Gentle action U. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Suds cooling R. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Door release Ü. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 79
Distribution controller g. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Alter time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 80
Lock X. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Temperature S. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Buzzer O. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Keypad tones P. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Display contrast . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Display brightness . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 82
Standby Q. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Memory V. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Set extended cool-down . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 83
Contents
5

To avoid the risk of accidents and
damage to the machine please read
these instructions carefully before
using it for the first time. They
contain important information on its
safety, installation, use and
maintenance.
Keep these operating instructions in
a safe place and ensure that new
users are familiar with the content.
Pass them on to any future owner of
the machine.
Correct usage
This washer-dryer must only be
used:
– to wash items which are specified by
the manufacturer to be washable on
the care label.
– to dry textiles which have been
washed in a water solution, marked on
the manufacturer's care label as being
suitable for tumble drying. "Dry
cleaning kits" for freshening up
garments in a tumble dryer are
increasingly available on the market. If
using, do so at your own risk, and
follow the instructions provided on the
packaging.
Any other applications may be dange-
rous. The manufacturer cannot be held
liable for damage caused by improper
or incorrect use of the appliance.
Technical safety
Before setting up the machine,
check it for any externally visible
damage. Do not install or use a
damaged machine.
Before connecting the machine,
ensure that the connection data on
the data plate (voltage and connected
load) matches the mains electricity
supply. If in any doubt, consult a
qualified electrician.
The electrical safety of this
machine can only be guaranteed
when continuity is complete between
the machine and an effective earthing
system which complies with local and
national safety regulations.
It is most important that this basic
safety requirement is present and
regularly tested and where there is any
doubt the household wiring system
should be inspected by a qualified
electrician.
The manufacturer cannot be held liable
for the consequences of an inadequate
earthing system (e.g. electric shock).
Do not connect the appliance to
the mains electricity supply by an
extension lead. Extension leads do not
guarantee the required safety of the
appliance (e.g. danger of overheating).
Warning and Safety instructions
6

The machine is built in accordance
with current safety requirements.
Unauthorised repairs could result in
unforeseen dangers for the user, for
which the manufacturer cannot accept
liability. Repairs should only be
undertaken by a Miele approved
technician.
Ensure current is not supplied to the
machine until after maintenance or
repair work has been carried out.
The machine is only completely
isolated from the electricity supply
when:
– it is switched off at the wall socket
and the plug is withdrawn, or
– it is switched off at the mains, or
– the mains fuse is withdrawn, or
– the screw-out fuse is removed in
countries where this is applicable
The Miele "Water protection
system" protects from water
damage provided the machine is
correctly plumbed in and connected to
the electricity supply.
If a fault has been identified, the
machine must be examined by a
competent person before further use,
and repaired if necessary.
–Faulty components must only be
exchanged for Miele original spare
parts. Only when these parts are
fitted can the safety standards of the
machine be guaranteed.
–If the connection cable is faulty it
must only be replaced by a Miele
approved service technician to
protect the user from danger.
In countries where there are areas
which may be subject to infestation
by cockroaches or other vermin, pay
particular attention to keeping the
appliance and its surroundings in a
clean condition at all times. Any
damage which may be caused by
cockroaches or other vermin will not be
covered by the appliance guarantee.
Use
This equipment may only be used
in mobile installations such as
ships, caravans, aircraft etc. if a risk
assessment of the installation has been
carried out by a suitably qualified
engineer.
Do not install your machine in
rooms where temperatures below
freezing may occur. Frozen hoses may
burst under pressure.The reliability of
the electronic control unit may be
impaired at temperatures below
freezing point.
Warning and Safety instructions
7

Before using the machine for the
first time, check that the transit
fittings at the rear of the machine have
been removed (see section on
"Installation"). During spinning, a transit
fitting which is still in place may result in
damage to both the machine and
adjacent furniture or appliances.
Turn off the stopcock if the
machine is to be left for any length
of time (e.g. holiday), especially if there
is no floor drain (gully) in the immediate
vicinity.
Flooding danger. If hooking the
drain hose into a wash basin,
check that the water can drain off
quickly enough to prevent the sink from
overflowing. Make sure the drain hose
is secure, so that the force of the water
flowing out of the hose does not
dislodge it.
Take care to ensure that foreign
objects (e.g. nails, pins, coins,
paper clips) do not find their way into
the machine with the laundry. These
may damage components of the
machine (e.g. suds container, drum),
which in turn can result in damage to
the laundry.
If the correct amount of detergent
is dispensed, the machine should
not need to be descaled. If, however,
you do wish to descale the machine
only use proprietary non-corrosive
descaling agents and strictly observe
the instructions on the packaging. If in
doubt contact the Miele Customer Ser-
vice Dept. or your Miele Dealer.
Textiles which have been
pre-treated in solvent based
cleaning agents must be thoroughly
rinsed in clean water before being
washed in the machine.
Never use solvent based cleaning
agents in this machine, as this may
result in damage to component parts
and create toxic fumes. Such
detergents also pose a fire and
explosion hazard.
Only use dyes specified by the
manufacturer as being suitable for
use in a domestic washing machine.
Always observe the manufacturer's
instructions carefully.
Colour run and dye removers
contain sulphur compounds which
can cause damage such as corrosion.
Do not use these products in this
machine.
Always make sure the drum is
stationary before reaching in to
remove laundry. Reaching into a
moving drum is extremely dangerous.
Warning and Safety instructions
8

To prevent the risk of fire the
following textiles must not be dried
in this machine:
–fabrics which contain a large
proportion of rubber, foam rubber or
rubber like materials.
–items which contain padding or
fillings (e.g. pillows, jackets).
–items which have been treated with
inflammable cleaning agents.
–items which have been splashed with
hair lacquer, hair spray, nail varnish
remover or similar substances.
– items which have been soiled with
oils or residues containing grease
(kitchen oils, cosmetics etc.).
– items soiled with wax or other
chemicals (e.g. mops and floor
cloths).
– items which have not been
thoroughly cleaned and which are
still soiled with grease or oil, e.g.
workwear. Such clothing may require
a heavy duty detergent to get them
clean. If necessary, consult the
detergent manufacturer for advice.
Make sure that any dispensing
balls etc. are removed from laundry
before the drying programme. These
dispensers can melt during the drying
programme and cause damage to the
machine and the laundry. Do not use
liquid dispenser balls or similar if you
are planning to wash and then dry in
one continuous sequence.
Take care, the metal cap is hot
after drying. Open the door wide
after the drying cycle. Do not touch the
metal cap located on the inside of the
door glass. It will still be hot and could
cause a burn.
Accessories
Accessory parts may only be fitted
when expressly approved by Miele.
If other parts are used, guarantee,
performance and product liability
claims will be invalidated.
Safety with children
This machine is not a toy! To avoid
the risk of injury do not allow
children to play on or near it or to play
with its controls. Supervise its use by
the elderly or infirm, and supervise
children whilst you are operating the
machine.
Disposal of your old machine
Before discarding an old machine,
switch it off at the wall socket and
unplug it. Render the plug useless. Cut
off the cable directly behind the
machine to prevent misuse. This should
be done by a competent person.
The manufacturer cannot be held
liable for damage caused by
non-compliance with these Warning
and Safety instructions.
Warning and Safety instructions
9

Control panel
aStart/Stop button
For starting the programme selected
and cancelling a programme once it
has started.
bDisplay with – , OK, + and
Load/Detergent buttons
See the following page for more
details.
cmbutton
For selecting delay start and
setting the time of day.
dPC / Optical interface
This is used by service technicians
to run diagnostic checks on your
machine and can also be used to
update programming data in the
future.
eExtra option buttons
with indicator lights
Various extra options can be added
to the programmes.
fProgramme selector
For selecting washing and drying
programmes. The programme
selector can be turned clockwise or
anti-clockwise.
gWashing/Drying button
for selecting:
– Washing
– Drying
– Washing and Drying.
hI-On/0-Off button
For switching the washer-dryer on
and off.
iDoor button
Opens the machine door.
Guide to the machine
10

Display
When a programme is selected the
display can be used to select and
change programme parameters.
- / + buttons
For altering the parameters highlighted
in the display:
-decreases the parameter or moves
the highlighting upwards
+increases the parameter or moves
the highlighting downwards.
OK button
For confirming the parameter selected
and choosing the next parameter.
Load/Detergent button
For calling up the load size and the
detergent amount.
With the programme selector at the
Further programmes position, you can
select the following programmes via the
display:
Dark garments , Shirts , Denim ,
Sportswear , Outerwear , Proofing ,
Curtains , Separate rinse and Starch .
Delay start and the soak time are
selected via the display.
The display shows the duration of the
programmes and the current time of
day.
The
Settings Jmenu is also operated
via the display.
Use
This washer-dryer can be used:
–to wash separately
max. load 5 kg (depending on
programme);
–to dry separately
max. load 2.5 kg (depending on
programme);
or
–to wash and dry in a continuous
sequence
max. load 2.5 kg (depending on
programme).
Guide to the machine
11

Before using the machine for the first
time ensure that it is correctly
installed and connected. See
"Installation and connection". Also
check that the drain filter is securely
tightened to prevent the risk of water
leaks during use.
The washer-dryer has a sensor which
measures the amount of laundry in the
drum. This determines the amount of
detergent required. To allow the load
size indicator to function correctly, you
must first run a wash programme
without any laundry and without
detergent.
^Open the stopcock.
^Press the
I-On/0-Off button in.
If the washer-dryer is being switched on
for the first time, the welcome screen
will appear.
M
Willkommen
The welcome screen will not appear
again once a programme lasting
longer than 1 hour has been
completed.
After a few seconds the display will
change to show the screen for
selecting your language.
Setting the language
Cèeština
Fdansk
deutsch H
^Use the –and +buttons to select the
language you want and confirm your
selection by pressing the OK button.
Setting the time of day
The display for setting the time will
appear.
12:00
Set the time
^Set the hour with the –and +buttons
and confirm your setting by pressing
the OK button. Now set the minutes.
After you have confirmed the minute
setting, the display will change to
show the reminder to remove the
transport struts.
Before using for the first time
12

Reminder to remove transport struts
To avoid the risk of damage, the
transport struts must be removed
before the washer-dryer is used for
the first time. See "Installation and
connection" for instructions on how
to do this.
iRemove transport
struts
OK
^After removing the transport struts (if
this has not already been done by
your fitter) press the OK button.
Running your first programme
Your washer-dryer is now ready for the
first programme to be run.
15:00
Select programme
^Turn the programme selector to the
Cottons position.
^Press the
Start/Stop button.
^When the programme has finished,
turn the programme selector to
Stop
and switch off the washer-dryer.
The load sensor must then be
calibrated to zero as you would with
bathroom scales.
Calibrating the load size sensor to
zero
^Switch the machine on.
^Open the drum door.
^Turn the programme selector to the
Cottons position.
^Press and hold the
Load/Detergent
button pressed in until the following
message appears in the display:
iZero setting
OK
^Turn the programme selector to
Stop
and switch off the washer-dryer.
The machine is now ready for use.
Before using for the first time
13

Energy and water consumption
–Water consumption and energy
usage are determined by the size of
the load.
To make the most out of your
machine, load the maximum dry load
for the programme you are using.
–Use the
Automatic and Express
programmes for small loads.
–When smaller amounts of laundry are
washed using the
Cottons
programmes, the automatic load
recognition system will reduce the
amount of water, time and energy
used. This may mean that the
programme duration is adjusted
during the course of the wash
programme.
– Using the
Cottons 60°C programme
instead of the
Cottons 95°C
programme will give energy savings
of between 35% and 45%. This is
sufficient for most levels of soiling.
For stubborn or old stains, use the
Soak extra option.
Detergent
–Do not exceed the amounts of
detergent recommended by the
manufacturer on the packaging.
–Reduce the amount of detergent for
smaller loads. Use the
Load/Detergent button.
Choosing the correct extra option
(Pre-wash, Soak, Short)
Select:
A wash programme together with the
Short extra option for light to normal
soiling where there are no obvious
marks.
A wash programme without any extra
options for normal to heavy soiling.
A wash programme together with the
Soak option for heavily soiled
laundry.
– Use the extra option
Soak instead of
Pre-wash . If Soak is followed immedi-
ately by a main wash, the same suds
are used.
When drying straight afterwards
–Select a high spin speed for the
wash programme, as well as for the
Thermospin, if tumble drying this
laundry afterwards. This saves time
and energy.
Washing and drying environmentally
14

Brief instructions
The headings numbered A,B,C, . . .
show the operating sequence and can
be used as brief instructions.
Separate washing
ASort the laundry
^Empty all pockets.
,Foreign objects (e.g. nails,
coins, paper clips, etc.) can cause
damage to garments and
components in the machine.
^Badly soiled areas, stains etc. should
be cleaned as soon as possible,
preferably whilst still fresh. Spillages
should be carefully dabbed off using
a soft colourfast cloth. Do not rub!
Badly soiled areas can be pre-treated
with liquid detergent, stain removers
etc. first, following the manufacturer's
instructions. With particularly stubborn
stains ask your dry cleaner for advice.
,Do not use solvent-based
cleaning agents in this machine.
^Sort the laundry by colour and by
care label. Most garments have a
textile care label in the collar or side
seam.
Dark textiles often contain excess dye
and should be washed separately
several times before being included in
a mixed load. Always wash whites and
coloureds separately.
–Curtains: Remove lead weights first
or place in a laundry bag.
–Underwiring and collar stiffeners:
Any loose wiring in bras, shirt collar
stiffeners, etc. should be removed or
sewn in.
– Knitted garments, trousers and
jeans, T-shirts and sweat shirts: Turn
inside out, if recommended by the
manufacturer.
– Close any zips, fasten hooks and
eyes etc before washing.
– Fasten duvet covers and pillow
cases to prevent small items from
being trapped inside them.
Do not wash any items in this machine
which are specified by the
manufacturer as non-machine
washable on the care label. (h
symbol)
WASHING
15

BSwitch the machine on
The interior drum lighting will come on.
CSelect a programme
^Select the programme you want.
The programme selected will appear in
the display.
Minimum iron
Further programmes:
When you turn the programme selector
to
Further programmes , a list of these
programmes will appear in the display.
EDark garments
Denim
Shirts H
^Use the -or +button to highlight the
programme you wish to select and
confirm your selection by pressing
the OK button.
Wait until the display switches to show
the menu for the programme selected.
40°C 900 rpm
Duration: 1:00 h
or
Denim
40°C 900 rpm
Duration: 1:00 h
^Press the
Washing/Drying button
repeatedly until only the Washing
indicator light is lit up.
The Drying indicator light must not
be lit up as well as this would mean
that the washing programme would
be followed immediately by the
drying programme.
^You can alter the highlighted
temperature with the -or +buttons.
Press the OK button to confirm the
temperature you want and move on
to the spin speed.
30°C 900 rpm
Duration 0:57 h
^You can then alter the highlighted
spin speed with the -or +buttons.
WASHING
16

^You can select any extras options
with the extra option buttons.
^Each press of the top right hand
button selects the extra option in the
following order:
Pre-wash or Soak or
no option is selected.
Not all the extra options are suitable for
use with every wash programme.
You can only select extra options which
are compatible with the basic
programme being used.
The Low temperature extra only
applies to drying.
^Select Delay start, if required.
DLoad the drum
^Press the
Door button to open the
drum door.
The load size indicator display will
appear.
Load <25%
B
The display shows the amount of
laundry loaded in the drum as a % (in
25% steps) of the maximum load
permissible for the programme
selected.
^Unfold the laundry and load loosely
in the drum. Mixing both large and
small items gives better wash results
and also helps distribute the load
evenly during spinning.
The most efficient use of energy and
water is achieved when a full load is
washed. However, do not overload as
this causes creases and reduces
cleaning efficiency.
Make sure that no garments are
caught between the drum door and
seal.
^Shut the door with a gentle swing.
WASHING
17

EAdd detergent
The load size indicator display will be
replaced with the detergent percentage
display.
Detergent 75%
A
40% Add slightly less than half the
amount recommended . . .
50% Add half the amount
recommended . . .
60% Add slightly more than half the
amount recommended . . .
75% Add three quarters of the
amount recommended . . .
100% Add the full amount
You also need to take the level of
soiling and water hardness into
account.
too little detergent results in:
–Laundry not getting properly clean
and with time it may become grey
and hard to the touch.
–Greasy particles clinging to the
laundry.
–Limescale deposits on the heater
elements.
too much detergent results in:
–Excessive foam which causes a low
level of agitation and poor wash,
rinse and spin results.
–High water consumption (an
additional rinse cycle will
automatically switch in).
–A burden to the environment.
^Pull out the detergent drawer and
add detergent to the compartments
as follows:
i= Detergent for the pre-wash
(1/4of the total amount
recommended). This
compartment is also used for
starch formulations when
starching separately.
j= Detergent for the main wash
including Soak
§= Fabric conditioner or liquid
starch
^Close the detergent drawer.
See "Detergent" for further information.
WASHING
18

FStart the programme
^Press the flashing
Start/Stop button.
The estimated programme duration will
count down in the display in one minute
steps. During the first 10 minutes the
machine measures how much water is
being absorbed by the laundry. The
programme duration may be longer or
shorter depending on this absorbency
rate.
The programme sequence is also
shown in the display. The washer-dryer
shows you when each section of the
programme is reached.
The drum lighting switches off once the
programme has started.
GRemove the laundry when the
programme has finished
In the anti-crease phase after the
programme has finished, the following
will appear alternately in the display:
Anti-crease
and
iProgramme finished.
Remove laundry, then
switch the machine off.
^Turn the programme selector to the
Stop position. Press the Door button
to open the drum door.
^Remove the laundry.
Only remove laundry from the
machine once the drum has
stopped turning. Reaching into a
moving drum is extremely
dangerous and could result in injury.
Check that all items have been
removed from the drum. Items left in
the drum could discolour other items
in the next wash or become
discoloured themselves.
Important! Always remove the
laundry before switching the machine
off. This is important to ensure that
the load size indicator works
correctly.
^Switch the machine off with the
I-On/0-Off button.
See "After each washing or drying
programme" for further information.
After washing a full load
If you have washed a full load of
laundry and you wish to dry the
laundry in the washer-dryer
afterwards you will have to remove
half the load. Carry out the drying
procedure in two batches.
WASHING
19

Extra options
You can use the Extra option buttons to
augment the basic wash programmes.
Pre-wash
For laundry with large amounts of dirt
(e.g. dust, sand).
Soak
For heavily soiled and stained items
with protein stains (e.g. blood, fats
and oils, cocoa).
A length of time of between 30 minutes
and 6 hours can be chosen, in 30
minute periods for the "Soak" process.
To select the soak time
^After selecting a programme, press
the
Pre-wash/Soak button repeatedly
until the
Soak indicator light comes
on.
15:06
Finish: 17:04
Soak: 0.30 h
Use the –and +buttons to enter the
soak time. The display will also show
the corresponding finishing time for the
washing programme. Press the OK
button to confirm the soak time you
want.
To delete the soak time
^Set the soak time to 0.00 h and
confirm this with the OK button.
Short
For light to nomal soiling with no
visible staining.
The duration of the main wash is
reduced.
Water plus
The machine is set at the factory so
that the water level in the main wash
and rinses will be increased if the
Water plus extra option is selected.
However, you can select other settings
for
Water plus . These are described in
"
Settings menu J".
Buzzer
An audible tone sounds repeatedly at
the end of a programme or when
Rinse hold is reached.
The buzzer will sound repeatedly until
the machine is switched off.
Once switched on, the buzzer is active
in all programmes until it is switched off
again.
You can switch the buzzer off by
pressing the buzzer button. You can
also change the volume of the buzzer.
These are described in "Settings J".
The buzzer will always sound when
there is a fault, even if the buzzer has
been switched off.
WASHING
20
