Miele WTF 130 WPM User manual

Operating instructions
Washer-dryer
To avoid the risk of accidents or damage to the machine, it is essential
to read these instructions before it is installed and used for the first time.
en-GB M.-Nr. 10 506 500

Contents
2
Caring for the environment .................................................................................. 6
Warning and Safety instructions ......................................................................... 7
Operating the washer-dryer ............................................................................... 15
Control panel......................................................................................................... 15
Display with sensor controls ................................................................................. 16
Examples on how to operate the machine............................................................ 17
Applications........................................................................................................... 17
Before using for the first time ............................................................................ 18
Environmentally friendly washing and drying................................................... 21
WASHING ............................................................................................................. 22
1. Prepare the laundry ........................................................................................... 22
2. Select a programme .......................................................................................... 23
3. Load the drum................................................................................................... 24
4. Select programme settings ............................................................................... 25
5. Add detergent.................................................................................................... 27
6. Start the programme ......................................................................................... 30
7. At the end of a programme ............................................................................... 30
Spin speeds........................................................................................................... 31
Programme chart................................................................................................... 33
Programme sequence ........................................................................................... 39
Special features in the programme sequence.................................................. 40
Cottons and Minimum iron............................................................................... 41
Options.................................................................................................................. 42
ProgrammeManager......................................................................................... 42
Stains................................................................................................................ 43
Further options ................................................................................................. 43
Options - overview ........................................................................................... 44
Detergent............................................................................................................... 45
Water softeners ................................................................................................45
Miele recommended detergents ...................................................................... 46
Recommended detergents in accordance with Directive (EU) No. 1015/2010...47
Dispensing fabric conditioner and liquid starch at the end of the
programme ....................................................................................................... 48
Adding fabric conditioner or liquid starch separately....................................... 49
Colour run and dye removers/dyes..................................................................49

Contents
3
DRYING ................................................................................................................ 50
1. Prepare the laundry ........................................................................................... 50
2. Select a programme .......................................................................................... 51
3. Load the drum................................................................................................... 52
4. Select programme settings ............................................................................... 53
5. Start the programme ......................................................................................... 54
6. At the end of a programme ............................................................................... 54
Programme chart................................................................................................... 55
Options.................................................................................................................. 61
ProgrammeManager......................................................................................... 61
Steam smoothing ............................................................................................. 61
Thermospin ........................................................................................................... 61
Overview of options and the thermospin .............................................................. 62
WASHING AND DRYING ..................................................................................... 63
1. Prepare the laundry ........................................................................................... 63
2. Select a programme .......................................................................................... 63
3. Load the drum................................................................................................... 63
4. Select programme settings ............................................................................... 64
5. Add detergent.................................................................................................... 64
6. Programme start/finish ...................................................................................... 64
After each washing or drying programme ............................................................. 65
"Rinse out fluff" programme.................................................................................. 65
Changing the programme sequence ................................................................ 66
Cancelling a programme ....................................................................................... 66
Interrupting a programme...................................................................................... 66
To change the programme .................................................................................... 66
Safety lock............................................................................................................. 67
Adding or removing laundry .................................................................................. 68
Delay start ............................................................................................................ 69
Garment care label symbols............................................................................... 70
Cleaning and care ............................................................................................... 71
External casing and fascia panel........................................................................... 71
Cleaning the detergent dispenser drawer ............................................................. 71
Cleaning the drum................................................................................................. 72
Cleaning the water inlet filter................................................................................. 73

Contents
4
What to do if....................................................................................................... 74
A programme does not start ................................................................................. 74
The following fault messages appear in the display and the programme stops... 75
A message appears in the display at the end of the programme ......................... 76
General problems with the washer-dryer .............................................................. 78
An unsatisfactory wash result ............................................................................... 80
Unsatisfactory drying results................................................................................. 81
The door will not open........................................................................................... 82
Opening the door in the event of a blocked drain outlet and/or power cut .......... 83
After sales service............................................................................................... 85
Repairs .................................................................................................................. 85
Guarantee: U.K. ..................................................................................................... 85
Guarantee: Other countries ................................................................................... 85
Optional accessories............................................................................................. 85
Installation and connection ................................................................................ 86
Front view .............................................................................................................. 86
Rear view............................................................................................................... 87
Installation surface ................................................................................................ 88
Installing the washer-dryer .................................................................................... 88
Remove the transit bars ........................................................................................ 88
Re-fitting the transit bars....................................................................................... 90
Installing under a continuous worktop .................................................................. 90
Aligning the washer-dryer ..................................................................................... 91
The water protection system ................................................................................ 92
Connection to the water supply ............................................................................ 93
Water drainage ...................................................................................................... 94
Electrical connection U.K. ..................................................................................... 95
Miele@home......................................................................................................... 96
Connecting the washer-dryer to your WiFi network.............................................. 98
Technical data...................................................................................................... 99
Consumption data............................................................................................. 100
Note for test institutes ......................................................................................... 101
Settings .............................................................................................................. 102
Language ......................................................................................................... 103
Degree of soiling.................................................................................................. 103
Buzzer volume..................................................................................................... 103
Keypad tone ........................................................................................................ 103
Code.................................................................................................................... 103

Contents
5
Temperature unit.................................................................................................. 104
Display brightness............................................................................................... 104
Dark display......................................................................................................... 104
Machine switch-off.............................................................................................. 104
Display maximum load ........................................................................................ 104
Display programme name ................................................................................... 104
Memory ............................................................................................................... 105
Pre-wash Cottons................................................................................................ 105
Soak duration ...................................................................................................... 105
Gentle action ....................................................................................................... 105
Temperature reduction ........................................................................................ 106
Water plus ........................................................................................................... 106
Water plus level ................................................................................................... 106
Maximum rinse level............................................................................................ 106
Suds cooling........................................................................................................ 107
Low water pressure ............................................................................................. 107
Distribution controller .......................................................................................... 107
Drying levels ........................................................................................................ 107
Miele@home ........................................................................................................ 108
Remote control.................................................................................................... 108
SmartGrid ............................................................................................................ 109
Optional accessories ........................................................................................ 110
Detergent............................................................................................................. 110
Specialist detergents........................................................................................... 110
Fabric care........................................................................................................... 111
Additives.............................................................................................................. 111

Caring for the environment
6
Disposal of the packing mater-
ial
The packaging is designed to protect
the appliance from damage during
transportation. The packaging materials
used are selected from materials which
are environmentally friendly for disposal
and should be recycled.
Recycling the packaging reduces the
use of raw materials in the manufactur-
ing process and also reduces the
amount of waste in landfill sites.
Disposing of your old appli-
ance
Electrical and electronic appliances of-
ten contain valuable materials. They
also contain specific materials, com-
pounds and components, which were
essential for their correct function and
safety. These could be hazardous to hu-
man health and to the environment if
disposed of with your domestic waste
or if handled incorrectly. Please do not,
therefore, dispose of your old appliance
with your household waste.
Please dispose of it at your local com-
munity waste collection / recycling
centre for electrical and electronic ap-
pliances, or contact your dealer or
Miele for advice. You are also respons-
ible (by law, depending on country) for
deleting any personal data that may be
stored on the appliance being disposed
of. Please ensure that your old appli-
ance poses no risk to children while be-
ing stored prior to disposal.

Warning and Safety instructions
7
 It is essential to read these instructions.
This washer-dryer complies with current safety requirements. In-
appropriate use can, however, lead to personal injury and damage
to property.
To protect yourself and to avoid the risk of damage to the washer-
dryer, please read these instructions carefully before using it for
the first time. They contain important information on its safety, use
and maintenance.
Keep these instructions in a safe place and pass them on to any
future owner.
Correct application
 This washer-dryer is intended for use in domestic households and
similar working and residential environments.
 This washer-dryer is intended for use in domestic households for
the following applications only:
– washing textiles which have a care label stating that they are
washable.
– drying textiles which have been washed in water and have a care
label stating that they are suitable for tumble drying.
Any other usage is not permitted. Miele cannot be held liable for
damage resulting from improper use or incorrect operation of the
machine.
 This washer-dryer is not intended for outdoor use.

Warning and Safety instructions
8
 This washer-dryer can only be used by people with reduced phys-
ical, sensory or mental capabilities, or lack of experience or know-
ledge, if they are supervised whilst using it or have been shown how
to use it in a safe way and understand and recognise the con-
sequences of incorrect operation.
Safety with children
 Children under eight years of age must be kept away from the
washer-dryer unless they are constantly supervised.
 Children eight years and older may only use the washer-dryer un-
supervised if they have been shown how to use it safely and recog-
nise and understand the consequences of incorrect operation.
 Children must not be allowed to clean or maintain the washer-
dryer unsupervised.
 Please supervise children in the vicinity of the washer-dryer and
do not let them play with it.
Technical safety
 Before setting up the washing-dryer, check it for any externally
visible damage.
Do not install or use a damaged washer-dryer.
 Before connecting the washer-dryer, ensure that the connection
data on the data plate (fuse rating, voltage and frequency) match the
mains electricity supply. If in any doubt, consult a qualified electri-
cian.

Warning and Safety instructions
9
 The electrical safety of this washer-dryer can only be guaranteed
when correctly earthed.
It is essential that this standard safety requirement is met. If in any
doubt, please have the household wiring system tested by a quali-
fied electrician.
Miele cannot be held liable for the consequences of an inadequate
earthing system (e.g. electric shock).
 Do not connect the machine to the mains electricity supply by an
extension lead, multi-socket adapter or similar. These can overheat
and are a fire hazard.
 Unauthorised repairs could result in unforeseen dangers for the
user, for which the manufacturer cannot accept liability. Repairs
should only be undertaken by a Miele authorised service technician,
otherwise any subsequent damage will not be covered by the guar-
antee.
 Please observe the instructions in "Installation and connection"
and the "Technical data".
 This washer-dryer is supplied with a special lamp to cope with
particular conditions (e.g. temperature, moisture, chemical resist-
ance, abrasion resistance and vibration). This special lamp must only
be used for the purpose it is intended for. It is not suitable for room
lighting. Replacement lamps may only be fitted by a Miele authorised
person or by Miele Service.
 The electrical socket must be easily accessible after installation so
that the washer-dryer can be disconnected from the electricity sup-
ply if necessary.

Warning and Safety instructions
10
 The washer-dryer must be isolated from the electricity supply
when cleaning and maintaining the machine and in the event of a
fault.
 The Miele "Water protection system" protects from water damage
provided the following conditions are met:
– The machine is correctly plumbed in and connected to the electri-
city supply.
– If a fault or damage has been identified, the washer-dryer must be
examined by a competent person before further use, and repaired
if necessary.
 The water flow pressure must be at least 100kPa and should not
exceed 1000kPa.
 Faulty components must only be replaced by genuine Miele ori-
ginal spare parts. Only when these parts are fitted can Miele guaran-
tee the safety standards of the machine.
 If the electrical connection cable is faulty it must only be replaced
by a Miele authorised service technician to protect the user from
danger.
 This washer-dryer must not be used in a non-stationary location
(e.g. on a ship).
 Do not make any alterations to the washer-dryer, unless author-
ised to do so by Miele.
 Reliable and safe operation of this washer-dryer can only be as-
sured if it has been connected to the mains electricity supply.

Warning and Safety instructions
11
Correct use
 Do not install the washer-dryer in a room where there is a risk of
frost. Frozen hoses may burst or split. The reliability of the electronic
control unit may be impaired at temperatures below freezing point.
 Before using the machine for the first time, check that the transit
bars at the rear of the washer-dryer have been removed (see "Install-
ation and connection - Removing the transit bars"). During spinning,
a transit bar which is still in place may result in damage to both the
washer-dryer and adjacent furniture or appliances.
 Turn off the stopcock if the washer-dryer is to be left for any
length of time (e.g. holiday), especially if there is no floor drain (gully)
in the immediate vicinity.
 Flooding danger. If hooking the drain hose into a wash basin,
check that the water can drain off quickly enough to prevent the sink
from overflowing. Make sure the drain hose is secure, so that the
force of the water flowing out of the hose does not dislodge it.
 Take care to ensure that foreign objects (e.g. nails, pins, coins, pa-
per clips) do not find their way into the machine with the laundry.
These may damage components of the machine (e.g. suds con-
tainer, drum), which in turn can result in damage to the laundry.
 Do not leave any detergent dispensing aids, e.g. plastic dispenser
balls, in the laundry when tumble drying. These dispensers can melt
during the drying programme and cause damage to the washer-
dryer and the laundry.
 Caution, the metal cap located on the inside of the door glass is
very hot after drying. Open the drum door fully after drying. Do not
touch the metal cap. Danger of burning!

Warning and Safety instructions
12
 Fabric conditioner and similar products must be used according
to the instructions on the manufacturer's packaging.
 If the correct amount of detergent is dispensed, the washer-dryer
should not need to be descaled. If, however, there is large build-up
of limescale and you need to descale it, you must use a special non-
corrosive descaling agent. A suitable descaling agent is available to
order from Miele (see "Optional accessories"). Instructions on the
packaging must be strictly observed.
 To prevent the risk of fire, the following textiles must not be dried:
– Items which have not been washed.
– Items, such as workwear, which have not been thoroughly
washed and which are still soiled with grease, oil or other depos-
its (such as cooking oil, cosmetics, lotions etc). If items have not
been thoroughly washed there is a danger that these might ignite
when heated, even after they have been removed from the
washer-dryer at the end of the programme.
– Items (e.g. mops and floor cloths) which have been treated with
inflammable cleaning agents or which contain residues of acet-
one, alcohol, benzene, petrol, stain remover, turpentine, wax and
wax remover or other chemicals.
– Items which have been splashed with hair lacquer, hair spray, nail
varnish remover or similar substances.
When washing heavily soiled items ensure that you use sufficient
detergent and select a high temperature. If in doubt, wash the
items several times.

Warning and Safety instructions
13
 To prevent the risk of fire, the following textiles must not be
tumble dried:
– Items which have been cleaned using chemicals (e.g. professional
dry-cleaning agents).
– Items which contain a large proportion of rubber, foam rubber or
rubber-like materials. For example, products made from latex
foam rubber, shower caps, waterproof textiles, rubberised articles
and items of clothing and pillows with foam rubber filling.
– Damaged items which contain padding or fillings (e.g. pillows,
jackets). When damaged, the filling can get out with the risk of it
igniting.
 Only use dyes specified by the manufacturer as being suitable for
use in a domestic washing machine. These must only be used in do-
mestic quantities. Always observe the manufacturer's instructions
carefully.
 Colour run and dye removers contain sulphur compounds which
can cause corrosion. Do not use these products in this washer-dryer.
 In many programmes, the heating phase is followed by a cooling
down phase to ensure that the items are not too hot to handle when
you remove them (this also avoids the danger of the laundry self-ig-
niting). The programme is not finished until the cooling down phase
has been completed. As soon as the programme has finished, re-
move all laundry from the drum.
 Warning: do not switch the washer-dryer off before the drying pro-
gramme has finished. If this is done, the laundry must be removed
immediately and hung up or spread out to cool it down.
 Textiles which have been pre-treated in solvent based cleaning
agents must be thoroughly rinsed in clean water before being
washed in the machine.

Warning and Safety instructions
14
 Do not use solvent based cleaning agents, e.g. those containing
benzine, in this washer-dryer, as this may result in damage to com-
ponent parts and create toxic fumes. Such agents also pose a fire
and explosion hazard.
 If detergent comes into contact with the eyes, rinse them thor-
oughly with lukewarm water immediately. If swallowed, seek medical
assistance immediately and retain the packaging or label for refer-
ence. Those with skin problems or sensitive skin should avoid their
skin coming into contact with detergent.
 The maximum load for this washer-dryer is 7.0 kg (dry weight) for
washing and 4.0 kg (dry weight) for tumble drying. See the "Pro-
gramme chart" for the maximum recommended loads for individual
programmes.
 Take care when opening the drum door after using the steam
function. Danger of burning due to escaping steam and the high
temperature of the surface of the drum as well as the porthole glass.
Stand back away from the machine and wait until the steam has dis-
sipated.
Accessories
 Accessory parts may only be fitted when expressly approved by
Miele. If other parts are used, guarantee, performance and product
liability claims will be invalidated.
 If you order a plinth for this washer-dryer (available from Miele as
an optional accessory), make sure it is the correct one.
Miele cannot be held liable for damage caused by non-compliance
with these Warning and Safety instructions.

Operating the washer-dryer
15
Control panel
aDisplay with sensor controls
See the next page for more informa-
tion.
bStart/Stop button
For starting the programme selected
and cancelling a programme once it
has started.
cTemperature button
For selecting the temperature.
dSpin speed button
For selecting the spin speed.
eDrying level button
For selecting the drying level.
fCapDosing button
For selecting CapDosing
gOptions buttons
Various options can be added to the
programmes.
hProgramme selector
For selecting washing and drying
programmes.
iOptical interface
For service technicians.
j button
For switching the washer-dryer on
and off. To save energy the washer-
dryer will switch off automatically 15
minutes after the end of the pro-
gramme/anti-crease phase or after
being switched on if no other selec-
tion is made.

Operating the washer-dryer
16
Display with sensor controls
k sensor
Scrolls down the list to the next op-
tion or decreases a value.
lOK sensor
Confirms the programme selected, a
value set or opens a sub-menu.
m sensor
Scrolls up the list to the next option
or increases a value.
nWashing sensor
For selecting the washing function
oDrying sensor
For selecting the drying function
pDelay start sensor
For selecting delay start
Standard display
The standard display for a wash pro-
gramme shows the following values
from left to right:
2:59 60°C 1600
– the programme duration
– the selected wash temperature
– the selected spin speed
The standard display for a drying pro-
gramme shows the following values
from left to right:
1:30 1600Normal
– the programme duration
– the drying level selected (only briefly)
– the spin speed selected for the
thermo-spin (if applicable for the pro-
gramme being used)
The standard display of a continuous
programme for washing followed by
drying shows the following:
– the programme duration
– the drying level selected (only briefly)
– the selected wash temperature
– the selected spin speed
Tip: The illuminated  and  arrow
sensors can be used to see the drying
level selected.

Operating the washer-dryer
17
Examples on how to operate
the machine
Scrolling through a list
The  arrows in the display indicate that
choices are available:
Language  
Touching the  sensor scrolls down the
list to the next option and touching the
 sensor scrolls up the list to the next
option. The OK sensor is used to activ-
ate the option which is currently in the
display.
Identifying options selected
Cap   
An option which has been activated will
have a tick  next to it.
Setting numerical values
Start in h00:00
The numerical value is highlighted in
white. Touching the  sensor de-
creases the value and touching the 
sensor increases it. The OK sensor is
used to activate the value shown in the
display.
Exiting a sub-menu
Select Back  to exit a sub-menu.
Applications
You can use this washer-dryer to:
–wash separately
Maximum load (depending on pro-
gramme) 7.0 kg;
–dry separately
Maximum load (depending on pro-
gramme) 4.0 kg;
or
–wash and dry in a continuous se-
quence
Maximum load (depending on pro-
gramme) 4.0 kg.

Before using for the first time
18
Remove the drain hose elbow
from the drum
An elbow piece for the drain hose is
stored in the drum.
Reach under the door grip and pull
the door open.
Remove the elbow piece.
Shut the door with a gentle swing.
Remove the protective foil and
stickers
Remove
– the protective foil from the door.
– any stickers from the front and the
lid.
Please do not remove any labels
(e.g. the data plate), visible when you
open the door.

Before using for the first time
19
Before using the washer-dryer
for the first time ensure that it is cor-
rectly installed and connected. See
"Installation and connection". Also
check that the drain filter is securely
tightened to prevent the risk of water
leaks during use.
This washer-dryer has undergone a
complete functional test at the factory
and there will be some residual water
in the drum from this process.
Switch the washer-dryer on
Press the  button.
The welcome screen will light up.
Select the language
You will be asked to select the language
you want for the display. It is possible
to change the language at any time via
"Settings".
deutsch 
Touch the  or  sensor until the
language you want appears in the
display.
Confirm your selection of the lan-
guage by touching the OK sensor.
Miele@home
The display indicates that this washer-
dryer can be connected to the
Miele@home system via a communica-
tion module (only available in selected
countries).
Confirm the message in the dispaly
with OK.
Remove the transit bars
A reminder to remove the transit bars
will appear in the display.
Failure to remove the transit bars
can result in damage to the washer-
dryer and to adjacent cabinetry or
appliances.
Remove the transit bars as described
in "Installation and connection".
After removing the transit bars (if this
has not already been done by your
fitter) confirm by pressing the OK but-
ton.

Before using for the first time
20
Start the calibration pro-
gramme
The following message will in the dis-
play:
Open  and run Cottons 90°C without
laundry.
Touch the sensor repeatedly until
you have read all the rows of text.
The OK sensor will light up.
Confirm the message with the
OKsensor.
It is important to calibrate the machine
to ensure optimum water and energy
usage, as well as optimum washing
and drying results.
To do this the Cottons 90°C pro-
gramme must be run without laundry
and without detergent.
No other programmes can be started
until calibration has been carried out.
Open the stopcock.
Turn the programme selector to Cot-
tons.
Do not change any other programme
settings.
1:55 90°C 1600
Press the Start/Stop button.
The calibration programme will start.
At the end of the programme the follow-
ing message will appear in the display:
Set-up complete
Reach under the door grip and pull
the door open.
Tip: Leave the door slightly open to al-
low the drum to dry.
Switch the washer-dryer off with the
 button.
