SECTION 1 – SAFETY PRECAUTIONS –
READ BEFORE USING
Protect yourself and others from injury—read, follow, and save these important safety
precautions and operating instructions.
1-1. Symbol Usage
DANGER! – Indicates a hazardous situation which, if not avoided, will result in death
or serious injury. The possible hazards are shown in the adjoining symbols or ex-
plained in the text.
Indicates a hazardous situation which, if not avoided, could result in death or seri-
ous injury. The possible hazards are shown in the adjoining symbols or explained in
the text.
NOTICE – Indicates statements not related to personal injury.
F
Indicates special instructions.
This group of symbols means Warning! Watch Out! ELECTRIC SHOCK, MOVING PARTS, and
HOT PARTS hazards. Consult symbols and related instructions below for necessary actions to
avoid these hazards.
1-2. Arc Welding Hazards
The symbols shown below are used throughout this manual to call attention to and
identify possible hazards. When you see the symbol, watch out, and follow the related
instructions to avoid the hazard. The safety information given below is only a sum-
mary of the more complete safety information found in the Principal Safety Standards
listed in Section 1-5. Read and follow all Safety Standards.
Only qualified persons should install, operate, maintain, and repair this equipment. A
qualified person is defined as one who, by possession of a recognized degree, certifi-
cate, or professional standing, or who by extensive knowledge, training and experi-
ence, has successfully demonstrated the ability to solve or resolve problems relating
to the subject matter, the work, or the project and has received safety training to rec-
ognize and avoid the hazards involved.
During operation, keep everybody, especially children, away.
ARC RAYS can burn eyes and skin.
Arc rays from the welding process produce intense visible and invisible (ultra-
violet and infrared) rays that can burn eyes and skin. Sparks fly off from the
weld.
lWear a welding helmet fitted with a proper shade of filter to protect your face
and eyes when welding or watching (see ANSI Z49.1 and Z87.1 listed in Principal Safety
Standards). Refer to Lens Shade Selection table in Section 1-4.
lWear approved safety glasses with side shields under your helmet.
lUse protective screens or barriers to protect others from flash, glare, and sparks; warn others
not to watch the arc.
lWear body protection made from durable, flame-resistant material (leather, heavy cotton,
wool). Body protection includes oil-free clothing such as leather gloves, heavy shirt, cuffless
trousers, high shoes, and a cap.

OM-269681 Page 2
lBefore welding, adjust the auto-darkening lens sensitivity setting to meet the application.
lStop welding immediately if the auto-darkening lens does not darken when the arc is struck.
NOISE can damage hearing.
Noise from some processes or equipment can damage hearing.
lWear approved ear protection if noise level is high.
WELDING HELMETS do not provide unlimited eye, ear,
and face protection.
Arc rays from the welding process produce intense visible and invisible (ultra-
violet and infrared) rays that can burn eyes and skin. Sparks fly off from the
weld.
lUse helmet for welding/cutting applications only. Do not use helmet for laser welding/cutting.
lUse impact resistant safety spectacles or goggles and ear protection at all times when using
this welding helmet.
lDo not use this helmet while working with or around explosives or corrosive liquids.
lThis helmet is not rated for overhead welding. Do not weld in the direct overhead position
while using this helmet unless additional precautions are taken to protect yourself from arc
rays, spatter, and other hazards.
lInspect the auto-lens frequently. Immediately replace any scratched, cracked, or pitted cover
lenses or auto-lenses.
lLens and retention components must be installed as instructed in this manual to ensure com-
pliance with ANSI Z87.1 protection standards.
lThis helmet provides protection from projectiles associated with grinding, chipping, and re-
lated activities; it is not a hard hat and does not provide protection from falling objects.
READ INSTRUCTIONS.
lRead and follow all labels and the Owner’s Manual carefully before installing,
operating, or servicing unit. Read the safety information at the beginning of the
manual and in each section.
lUse only genuine replacement parts from the manufacturer.
lPerform installation, maintenance, and service according to the Owner’s Manuals, industry
standards, and national, state, and local codes.
FUMES AND GASES can be hazardous.
Welding produces fumes and gases. Breathing these fumes and gases can be
hazardous to your health.
lKeep your head out of the fumes. Do not breathe the fumes.
lVentilate the work area and/or use local forced ventilation at the arc to remove welding fumes
and gases. The recommended way to determine adequate ventilation is to sample for the
composition and quantity of fumes and gases to which personnel are exposed.
lIf ventilation is poor, wear an approved air-supplied respirator.
lRead and understand the Safety Data Sheets (SDSs) and the manufacturer’s instructions for
adhesives, coatings, cleaners, consumables, coolants, degreasers, fluxes, and metals.
lWork in a confined space only if it is well ventilated, or while wearing an air-supplied respirator.
Always have a trained watchperson nearby. Welding fumes and gases can displace air and
lower the oxygen level causing injury or death. Be sure the breathing air is safe.

OM-269681 Page 3
lDo not weld in locations near degreasing, cleaning, or spraying operations. The heat and rays
of the arc can react with vapors to form highly toxic and irritating gases.
lDo not weld on coated metals, such as galvanized, lead, or cadmium plated steel, unless the
coating is removed from the weld area, the area is well ventilated, and while wearing an air-
supplied respirator. The coatings and any metals containing these elements can give off toxic
fumes if welded.
1-3. California Proposition 65 Warnings
WARNING – Cancer and Reproductive Harm — www.P65Warnings.ca.gov.
1-4. Lens Shade Selection Table
Process Electrode Size
in. (mm)
Arc Current in
Amperes
Minimum Pro-
tective Shade
No.
Suggested
Shade No.
(Comfort)*
Shielded Metal
Arc
Welding
(SMAW)
Less than 3/32 (2.4) Less than 60 7 - -
3/32-5/32 (2.4-4.0) 60–160 8 10
5/32-1/4 (4.0-6.4) 160–250 10 12
More than 1/4 (6.4) 250–550 11 14
Gas Metal Arc
Welding
(GMAW)
Flux Cored Arc
Welding (FCAW)
Less than 60 7 - -
60–160 10 11
160–250 10 12
250–500 10 14
Gas Tungsten
Arc
Welding (TIG)
Less than 50 8 10
50–150 8 12
150–500 10 14
Air Carbon Arc
Cutting (CAC-A)
Light Less than 500 10 12
Heavy 500–1000 11 14
Plasma Arc Cut-
ting (PAC)
Less than 20 4 4
20–40 5 5
40–60 6 6
60–80 8 8
80–300 8 9
300–400 9 12
400–800 10 14
Plasma Arc
Welding (PAW)
Less than 20 6 6–8
20–100 8 10
100–400 10 12
400–800 11 14
Reference: ANSI Z49.1:2012
*Start with a shade that is too dark to see the weld zone. Then, go to a lighter shade which gives
a sufficient view of the weld zone without going below the minimum.

OM-269681 Page 4
1-5. Principal Safety Standards
Safety in Welding, Cutting, and Allied Processes, American Welding Society standard ANSI
Standard Z49.1. Website: http://www.aws.org.
Safe Practice For Occupational And Educational Eye And Face Protection, ANSI Standard Z87.1,
from American National Standards Institute. Website: www.ansi.org.
Safety in Welding, Cutting, and Allied Processes, CSA Standard W117.2 from Canadian Stand-
ards Association. Website: www.csagroup.org.
Industrial Head Protection, ANSI/ISEA Standard Z89.1 from American National Standards Insti-
tute. Website: www.ansi.org.
Helmet 2020–06

OM-269681 Page 5
SECTION 2 – DEFINITIONS
2-1. Additional Safety Symbol Definitions
Warning! Watch Out! There are possible haz-
ards as shown by the symbols.
Accidental ingestion prevention. Keep battery
away from children. Battery is harmful if
swallowed.
2-2. Miscellaneous Symbols And Definitions
Positive
Negative
Power On/
Off
Information
Navigational
Arrows

OM-269681 Page 6
SECTION 3 – SPECIFICATIONS
F
Please register your product at www.MillerWelds.com/Support/Registration
Specification Digital Infinity Helmet
Viewing Field 4.4 x 3.1 in (112 x 78 mm)
Reaction Time 0.0000500 sec (1/20,000)
Available Shades
All Shades Provide
Continuous UV And
IR Protection.
Weld Mode Darkened State: No. 8 - No. 13 Light State: No. 3
Cut Mode Darkened State: No. 5 - No. 8 Light State: No. 3
Grind Mode Light State: No. 3
X-Mode Darkened State: No. 8 - No. 13 Light State: No. 3
Sensitivity Control Adjustable For Varying Ambient Light And Welding Arc
Delay Control Slows Lens Dark-To-Light State Between 0.1 And 1.0 Seconds
Automatic Power Off Shuts Lens Off 45 Minutes After Last Arc Is Struck
Low Battery Light Red Led Illuminates To Indicate 2-3 Days Remaining Battery Life
Power Supply Panasonic CR2450 Lithium Batteries (Miller Part No. 217043)
Sensors Independent/Redundant (Four)
Operating
Temperature 14°F to 131°F / -10°C to +55°C
☞When Stored In Extremely Cold Temperatures, Warm Helmet To
Ambient Temperature Before Welding.
Storage Temperature -4°F to 158°F / -20°C to +70°C
☞When Stored In Extremely Cold Temperatures, Warm Helmet To
Ambient Temperature Before Welding.
Total Weight 23 oz (650 g)
Standards Meets ANSI Z87.1+ And CSA Z94.3 Standards
Warranty Three Years From Date Of Purchase (Section 12)

OM-269681 Page 7
SECTION 4 – OPERATING INSTRUCTIONS
4-1. Helmet Controls
OM-269681 Page 1
The auto-darkening lens
turns on (darkens) automati-
cally when welding begins
and turns off when welding
stops.
1 Auto On/Off Button
(See Section NO TAG)
Mode Control Button
(Section NO TAG)
2 Grind Mode/Low
Battery Light (Section
NO TAG)
3 Lens/Info Adjustment
Buttons (See Sections
NO TAG Through
NO TAG)
Use adjustment buttons
to change shade, delay,
and sensitivity settings
when lens is in Mode
function. Use adjust-
ment buttons to change
arc time, clock, timer,
alarm, language, and
help settings when lens
is in Info function.
4 Info Control Button
(See Section NO TAG)
The lens assembly
saves the shade, sensi-
tivity, and delay settings.
1
3
4
2
The auto-darkening lens turns on (darkens)
automatically when welding begins and
turns off when welding stops.
1 Auto On/Off (Mode) Button (Section 4-2)
2 Grind Mode / Low Battery Light (Section
4-2)
3 Lens/Info Adjustment Buttons (See Sec-
tions 4-4 Through 4-5)
F
Use adjustment buttons to change
shade, delay, and sensitivity settings
when lens is in Mode function. Use ad-
justment buttons to change arc time,
clock, timer, alarm, language, and help
settings when lens is in Info function.
4 Info Control Button (See Section 4-8)
F
The lens assembly saves the shade,
sensitivity, and delay settings.

OM-269681 Page 8
4-2. Auto On/Off (Mode) Button And Grind/Low Battery Light
OM-269681 Page 1
The auto-darkening lens
turns on (darkens) auto-
matically when welding
begins and turns off
when welding stops.
1 Auto On/Off Button
Press Auto On/Off button to
check if the lens is working
properly and to begin Mode
and Info adjustments.
Whenthe Auto On/Off button
is pressed, the LCD control
panelwill turn On.
Press and hold the Auto On/
Off button to turn the LCD
controlpanel Off. Lens is on
and will function properly.
After four minutes of in-
activity, the LCD control
panel will turn off auto-
matically to conserve
power. Press any button
to wake up the LCD con-
trol panel.
2 Grind/Low Battery Light
The Grind/Low Battery light
blinks when the lens is in the
Grind mode. Light stays on
when 2 3 days of battery life
remain.
If battery power is low, re-
place with CR2450 lithium
batteries(2 required Miller
Part No. 217043). See Sec-
tion NO TAG.
12
F
The auto-darkening lens turns on
(darkens) automatically when welding
begins and turns off when welding
stops.
1 Auto On/Off (Mode) Button
Press Auto On/Off (Mode) button to check if
the lens is working properly and to begin
Mode and Info adjustments.
When the Auto On/Off (Mode) button is
pressed, the LCD control panel will turn On.
Press and hold the Auto On/Off button to
turn the LCD control panel Off. Lens is on
and will function properly.
F
After four minutes of inactivity, the LCD
control panel will turn off automatically
to conserve power. Press any button
to wake up the LCD control panel.
2 Grind/Low Battery Light
The Grind/Low Battery light blinks when the
lens is in the Grind mode. Light stays on
when 2–3 days of battery life remain.
If battery power is low, replace with Pana-
sonic CR2450 lithium batteries (2 required,
Miller Part No. 217043). See Section 7-1.
