User Manual
Elix® 20, 35, 70 and 100

Note
This User’s Manual refers to an item called a ‘TAG’ Sensor. This version of your system may not include this ‘TAG’ Sensor. Please
kindly disregard all references to this item while reviewing this User’s Manual.
Notice
The information in this document is subject to change without notice and should not be construed as a commitment by
Millipore SAS. Millipore SAS assumes no responsibility for any errors that might appear in this document. This manual is believed
to be complete and accurate at the time of publication. In no event shall Millipore SAS be liable for incidental or consequential
damages in connection with or arising from the use of this manual.
We manufacture and sell water purification systems designed to produce pure or ultrapure water with specific characteristics
(µS/cm, T, TOC, CFU/ml, Eu/ml) when it leaves the water purification system provided that the systems are fed with water quality
within specifications, and properly maintained as required by the supplier.
We do not warrant these systems for any specific applications. It is up to the end user to determine if the quality of the water
produced by our systems matches his expectations, fits with norms/legal requirements and to bear responsibility resulting from
the usage of the water.
Copyright
2012 Millipore SAS. Printed in France. All rights reserved. This book or parts thereof may not be reproduced in any form
without the written permission of the publishers. The photos are non-contractual.
PF08836 - V3.0 – 12/2012
Manufacturer: MILLIPORE SAS, 67120 MOLSHEIM, FRANCE.
Trademarks
Elix, Progard, Q-Gard are a registered trademark of Merck KGaA, Darmstadt, Germany.
RiOs, RoClean, Merck Millipore and the M logo are trademarks of Merck KGaA, Darmstadt, Germany.
All other trademarks are trademarks of their respective owners.

Product warranty and limitation of liability
The applicable warranty and limitation of liability for the products listed in this publication may be found at
http://www.millipore.com/ec/cp3/terms within the "Terms and Conditions of Sale" applicable to your purchase transaction.
Recycling
Directive 2002/96 EC: For European users only
The symbol “crossed bin” on a product or its packaging indicates that the product should not be treated like
household waste when discarded. Instead the product should be disposed of at a location that handles
discarded electric or electronic equipment.
Proper disposal of equipment containing electric or electronic components will help to reduce pollution effects
to the environment or to human health. Proper recycling of these products helps in environmental
preservation and helps to protect natural resources. For more information about recycling of products
containing electric or electronic components, please contact your local recycling representative or
organization.
Use appropriate means for lifting and carrying.
Pay special attention to how you handle the system in order not to damage your back.
Lift by straightening your legs. Let your leg muscles, not your back muscles, do the work.

Table of Contents
CHAPTER 1INTRODUCTION ................................................................................................................................. 1
1-1 USING THIS MANUAL ..................................................................................................................................................................................................1
Matching this manual with your water purification system ...........................................................................................................................1
Installation Information..............................................................................................................................................................................................1
How to use the Keypad and the LCD ......................................................................................................................................................................2
Commonly used abbreviations in this manual .....................................................................................................................................................4
1-2 CONVERSION FACTORS ................................................................................................................................................................................................5
1-3 SAFETY INFORMATION .................................................................................................................................................................................................6
Safety Statement..........................................................................................................................................................................................................6
Safety Symbols ..............................................................................................................................................................................................................6
1-4 CONTACT MILLIPORE ...................................................................................................................................................................................................6
By Internet......................................................................................................................................................................................................................6
Manufacturing Site ......................................................................................................................................................................................................6
CHAPTER 2PRODUCT INFORMATION .................................................................................................................... 7
2-1 ELIX PRODUCT WATER SPECIFICATIONS ......................................................................................................................................................................7
Product Water Flow Rates..........................................................................................................................................................................................7
Product Water Quality.................................................................................................................................................................................................7
2-2 SYSTEM RECOVERY......................................................................................................................................................................................................8
What is RO Recovery? .................................................................................................................................................................................................8
Elix System Recovery ...................................................................................................................................................................................................8
2-3 SCHEMATIC OF MAIN COMPONENTS...........................................................................................................................................................................9
Schematic of an Elix System .....................................................................................................................................................................................9
Guide to Schematic......................................................................................................................................................................................................9
RO Cartridge configuration for Elix Systems .....................................................................................................................................................10
2-4 DESCRIPTION OF INPUT AND OUTPUT CONNECTIONS ............................................................................................................................................... 11
Ports...............................................................................................................................................................................................................................11
TANK LEVEL and RS 232 ..........................................................................................................................................................................................11
Grommets.....................................................................................................................................................................................................................12
2-5 DESCRIPTION OF MAIN COMPONENTS .....................................................................................................................................................................13
Inlet Solenoid Valve ..................................................................................................................................................................................................13
Flowmeter ....................................................................................................................................................................................................................13
Progard® TL System Pretreatment Pack ..............................................................................................................................................................13
PrePak L1 Pre-System Pretreatment Pak ............................................................................................................................................................14
Purge Valve..................................................................................................................................................................................................................14
Feedwater Pressure Switch .....................................................................................................................................................................................14
Feedwater and Permeate Conductivity Cells .....................................................................................................................................................14
RO Pump (Motor + Pumphead)..............................................................................................................................................................................15
RO Cartridge(s) ...........................................................................................................................................................................................................15
Flow Controller ...........................................................................................................................................................................................................15
RO Permeate Divert Solenoid Valve......................................................................................................................................................................15
Pressure Sensor...........................................................................................................................................................................................................15

Table of Contents
Back Pressure Regulator...........................................................................................................................................................................................15
RO Reject Control Device.........................................................................................................................................................................................15
RO Reject Solenoid Valve.........................................................................................................................................................................................15
Elix Module ..................................................................................................................................................................................................................15
Product Water Resistivity Sensor ..........................................................................................................................................................................16
UV Lamp........................................................................................................................................................................................................................16
2-6 DESCRIPTION OF OPTIONAL COMPONENTS ...............................................................................................................................................................17
QGard TL1 Polishing Pak (Optional)......................................................................................................................................................................17
Loop Resistivity Sensor (Optional).........................................................................................................................................................................17
A10 TOC Monitor (Optional) ...................................................................................................................................................................................18
2-7 TECHNICAL SPECIFICATIONS......................................................................................................................................................................................19
Dimensions...................................................................................................................................................................................................................19
Weight...........................................................................................................................................................................................................................20
Operating Pressures ...................................................................................................................................................................................................20
Environmental .............................................................................................................................................................................................................20
Electrical .......................................................................................................................................................................................................................21
Materials of construction for wetted components ..........................................................................................................................................21
Noise Level ...................................................................................................................................................................................................................21
Measurement Ranges for Conductivity, Temperature, Pressure and Flow ................................................................................................21
CHAPTER 3USING THE ELIX SYSTEM.................................................................................................................23
3-1 HOW THE ELIX NORMALLY DELIVERS PRODUCT WATER............................................................................................................................................23
SDS and Loops.............................................................................................................................................................................................................23
Automatic Method.....................................................................................................................................................................................................23
Manual Method ..........................................................................................................................................................................................................23
Alarm Message Displayed ........................................................................................................................................................................................24
3-2 ELIX WITH A POLISHER,LOOP RESISTIVITY SENSOR OR A10 ADDED ........................................................................................................................25
3-3 HOW TO VIEW THE ELIX SYSTEM PERFORMANCE......................................................................................................................................................26
3-4 HOW TO VIEW SERIAL NUMBERS AND MAINTENANCE INFORMATION FROM THE LCD............................................................................................29
3-5 WHAT ARE THE DIFFERENT OPERATING MODES? .......................................................................................................................................................31
CHAPTER 4MAINTENANCE...............................................................................................................................33
4-1 SCHEDULED MAINTENANCE TABLE ...........................................................................................................................................................................33
4-2 HOW TO REPLACE THE PROGARD TL .........................................................................................................................................................................34
When to replace the Progard TL ............................................................................................................................................................................34
Removing the used Progard TL ...............................................................................................................................................................................34
Installing the new Progard TL.................................................................................................................................................................................35
4-3 HOW TO REPLACE THE UV LAMP INSIDE THE ELIX SYSTEM ......................................................................................................................................36
4-4 HOW TO CHECK AND ADJUST THE PUMP PRESSURE ..................................................................................................................................................36
4-5 HOW TO SANITISE THE RO CARTRIDGE(S) ................................................................................................................................................................37
What is needed to sanitise the RO Cartridge(s) ................................................................................................................................................37
Automatic Way of Sanitisation..............................................................................................................................................................................37
Manual Way of Sanitisation ...................................................................................................................................................................................37

Table of Contents
How to manually sanitise the RO Cartridge(s)..................................................................................................................................................38
4-6 HOW TO CLEAN THE RO CARTRIDGE(S)....................................................................................................................................................................40
What is needed to clean the RO Cartridge(s) ....................................................................................................................................................40
Which cleaner to use, RoClean A or RoClean B?.............................................................................................................................................. 40
How often should the RO Cartridge(s) be cleaned?.........................................................................................................................................40
How to manually clean the RO Cartridge(s) ......................................................................................................................................................41
4-7 HOW TO REPLACE THE QGARD TL1 POLISHER PACK ...............................................................................................................................................43
When to replace the QGard TL Pack.....................................................................................................................................................................43
Removing the used QGard TL Pack .......................................................................................................................................................................43
Installing the new QGard TL Pack.........................................................................................................................................................................44
4-8 HOW TO CLEAN THE A10 TOC MONITOR ...............................................................................................................................................................45
How long does the A10 Cleaning take? .............................................................................................................................................................. 45
Why would I need to do an A10 Cleaning?........................................................................................................................................................45
How do I do an A10 Cleaning? ..............................................................................................................................................................................45
How to see the remaining time of the A10 CLEANING. .................................................................................................................................47
How to cancel an A10 CLEANING.........................................................................................................................................................................47
4-9 HOW TO REPLACE THE A10 UV LAMP .....................................................................................................................................................................48
4-10 HOW TO CALIBRATE THE A10 TOC MONITOR.........................................................................................................................................................48
CHAPTER 5TROUBLESHOOTING .........................................................................................................................49
5-1 MAINTENANCE,ALARM,ALARM STOP AND CUSTOM MESSAGES ........................................................................................................................... 49
Types of messages .....................................................................................................................................................................................................49
How messages are displayed and other information ......................................................................................................................................49
5-2 AN ALARM MESSAGE OR MAINTENANCE MESSAGE IS DISPLAYED..........................................................................................................................50
CHAPTER 6ORDERING INFORMATION ................................................................................................................57
6-1 CATALOGUE NUMBERS FOR CONSUMABLES ............................................................................................................................................................57
6-2 CATALOGUE NUMBERS FOR ACCESSORIES ...............................................................................................................................................................57
6-3 CATALOGUE NUMBERS FOR ALL ELIX SYSTEMS........................................................................................................................................................ 58
CHAPTER 7APPENDIXES...................................................................................................................................59
APPENDIX 1HOW TO CHANGE THE MAIN POWER FUSE....................................................................................................................................................59
APPENDIX 2PRE INSTALLATION -WHAT’S INSIDE THE SHIPPING BOX .............................................................................................................................60
APPENDIX 3POST INSTALLATION CHECKLIST......................................................................................................................................................................61
APPENDIX 4FEEDWATER REQUIREMENTS..........................................................................................................................................................................63

Introduction
Elix® 20, 35, 70 and 100 1
Chapter 1 INTRODUCTION
1-1 USING THIS MANUAL
MATCHING THIS MANUAL WITH YOUR WATER PURIFICATION SYSTEM
This manual is intended for use with a Millipore SAS Elix 20, Elix 35, Elix 70 or Elix 100 Water Purification System.
This User Manual is a guide for use during the normal operation and maintenance of an Elix 20, Elix 35, Elix 70 or Elix 100 Water
Purification System. It is highly recommended to completely read this manual and to fully comprehend its contents before
attempting normal operation or maintenance of the Water Purification System.
You can easily identify your type of Water Purification System if you do not see the Catalogue Number. The type of Elix System
is indicated above the Keypad on the front of the Elix System Cabinet.
If this manual is not the correct one for your Water Purification System, then please contact Millipore SAS.
INSTALLATION INFORMATION
IMPORTANT! INSTALLATION INSTRUCTIONS ARE NOT INCLUDED. INSTALLATION
OF THIS PRODUCT IS MEANT TO BE PERFORMED BY A QUALIFIED MILLIPORE SAS
SERVICE REPRESENTATIVE.
The Pre-Installation and Installation Documentation for the Elix Systems mentioned
above are not found in this Manual. Contact Millipore SAS if you would like to
have this information.
Appendix 2 contains a Pre Installation Checklist and Appendix 3 contains a Post Installation Checklist. These can be used to
confirm that you received the necessary items for installation and also that the Elix System was installed according to
specifications.
ATTENTION
ATTENTION

Introduction
Elix® 20, 35, 70 and 100 2
HOW TO USE THE KEYPAD AND THE LCD
The Keypad and LCD are shown below. Press the Keypad Button lining up with the desired action. For example, if you wanted to
go from STANDBY Mode to SETUP Mode, you would press the Keypad as shown below.
In this manual, pressing a Keypad Button would be shown like this.
There are several symbols that are displayed on the Keypad. These symbols are explained below.
SYMBOL WHAT IT MEANS
PRESS AND RELEASE SYMBOL. Pressing the Keypad Button next to this symbol brings you
immediately to the next LCD Screen.
PRESS AND HOLD SYMBOL. Pressing the Keypad Button next to this symbol for 2-3 seconds brings
you to the next LCD Screen.
Pressing the Keypad Button next to this symbol brings you to the next LCD Screen within the same
software branch.
Pressing the Keypad Button next to this symbol exits the currently viewed software branch. It
brings you back to the Root Menu.
⇌
Pressing the Keypad Button next to this symbol toggles between various parameters being
displayed.
+ Pressing the Keypad Button next to this symbol increases the value of the currently displayed
parameter.
- Pressing the Keypad Button next to this symbol decreases the value of the currently displayed
parameter.
►
►
►
►
►
►
►
►
►
►
S
T
A
N
D
B
Y
S
E
T
U
P
►
M
A
I
N
T
E
N
A
N
C
E
►
P
R
O
D
U
C
T
I
O
N
►
=

Introduction
Elix® 20, 35, 70 and 100 3
Some examples of various Keypad Button actions are shown below.
Pressing the Keypad Button
next to STANDBY for a few
seconds changes the LCD.
Pressing the Keypad
Button next to DATA
immediately changes
the LCD.
Pressing this Keypad Button (→) will scroll the
LCD to the next LCD Screen containing DATA
information. In this example, DATA is the
Software Branch linked together with LCD
Screens and the Keypad Arrow shown above.
Pressing this Keypad Button
(X) will scroll the LCD to
the ROOT Menu.
P R O D U C T I O N ▄ 4 0 %
R E J . : 9 7 . 3 %
D A T A

S T A N D B Y

R O M E M B . P E R F O R M .
F E E D : 5 3 6 µ S T C
P E R M E A T E : 8 . 9 µ S T C
R E J . : 9 7 . 3 %
→

P R O D U C T I O N ▄ 4 0 %
R E J . : 9 7 . 3 %
D A T A

S T A N D B Y

D A T A P R I N T
C U R R E N T V A L U E S
3 0 D H I S T O R Y
X

P R O D U C T I O N ▄ 4 0 %
R E J . : 9 7 . 3 %
D A T A

S T A N D B Y


Introduction
Elix® 20, 35, 70 and 100 4
COMMONLY USED ABBREVIATIONS IN THIS MANUAL
Abbreviation Full Text + Comments
µS/cm microSiemens per centimeter
BSP, MBSP, FBSP British Standard Thread, Male BSP, Female BSP
CFU/ml Colony Forming Units per millilitre
FI Fouling Index
GAZ A type of thread (a metric thread)
i.e. For Example
kPa kiloPascals
L Litre
LCD Liquid Crystal Display
LED Light Emitting Diode
LPH Litre Per Hour
LPM Litre Per Minute
LSI Langelier Saturation Index
mm millimeter
MW Molecular Weight
nm nanometer
NPT National Pipe Thread
NPTF National Pipe Thread Female
NPTM National Pipe Thread Male
OD Outer Diameter
RO Reverse Osmosis
TOC Total Organic Carbon

Introduction
Elix® 20, 35, 70 and 100 5
1-2 CONVERSION FACTORS
To convert from to multiply by example
Litres US Gallon 0.258 1 L = 0.264 US Gal.
Litres Imperial Gallon 0.215 1 L = 0.220 Imp. Gal.
mm inches 0.03937 1 inch = 25.4 mm = 2.54 cm
mm feet 0.0037 1 foot = 304.8 mm = 30.48 cm
kg lb 2.2 1 kg = 2.2 lb
bar psi 14.7 1 bar = 1 b= 14.7 psi
bar kPa 100 1 bar = 100 kPa
°C °F (1.8 *°C) + 32 25 °C = 77 °F
LPM US Gal. per minute 0.264 500 ml/min. = 0.500 LPM = 0.132 USG/min.

Introduction
Elix® 20, 35, 70 and 100 6
1-3 SAFETY INFORMATION
SAFETY STATEMENT
Your Elix System should be operated according to the instructions in this manual. In particular, the hydraulic and electrical
specifications should be followed and met. It is important to use this equipment as specified in this manual; using this
equipment in a different manner may impair the safety precautions of the Elix System.
Do not open the system cabinet at any time. Electrical and mechanical components inside
the Elix System could pose a hazard. A qualified Millipore SAS Service Representative should
perform any work that needs to be done while the Elix System cabinet is opened.
SAFETY SYMBOLS
This
ATTENTION symbol is used to refer to instructions in this manual that need to
be done carefully.
These symbols are used to indicate that proper safety equipment has to be used.
Protective glasses and gloves must be worn
.
This
UV RADIATION sticker is used to refer to a position on the water system
Cabinet or inside of it where exposure to UV light is possible.
This
DANGER sticker is used to refer to a position on the water system Cabinet or
inside of it that could b
e hazardous.
This
ELECTRICAL GROUND
sticker is used to refer to a position on the water system
Cabinet or inside where an electrical ground connection is made.
This
ELECTRICAL DANGER
sticker is used to refer to a position on the water system
Cabinet
or inside where an electrical danger could exist.
1-4 CONTACT MILLIPORE SAS
For any questions or requests, please use the contact information provided below.
BY INTERNET
The Internet Site can be used to find addresses, telephone/fax numbers and other information.
Internet Site Address:
www.millipore.com
www.millipore.com/techservice
www.millipore.com/lab_water
MANUFACTURING SITE
Millipore SAS
67120 Molsheim
France
HAZARD

Product Information
Elix® 20, 35, 70 and 100 7
Chapter 2 PRODUCT INFORMATION
2-1 ELIX PRODUCT WATER SPECIFICATIONS
PRODUCT WATER FLOW RATES
ELIX 20, ELIX 35, ELIX 70 AND ELIX 100 FLOWRATES
ELIX SYSTEM
PRODUCT WATER FLOW RATE
Nominal Flow 7 – 30 °C
(See bottom 2 rows of this table)
Elix 20 20 LPH
Elix 35 35 LPH
Elix 70 70 LPH
Elix 100 100 LPH
Water temperature < 25 °C and 10 bar operating pressure.
(up to 12 bar with cold feedwater).
Water temperature ≥25 °C and 7 bar operating pressure.
PRODUCT WATER QUALITY
Resistivity > 5 MΩ.cm (@25 °C) typically 10-15 MΩ.cm (when CO2 is < 30 ppm in the Feedwater)
Conductivity < 0.2 µS/cm (@25 °C) typically 0.067-0.10 µS/cm (when CO2 is < 30 ppm in the Feedwater)
TOC < 30 ppb
Micro-Organisms < 10 CFU/ml
Silica Rejection > 99.9%

Product Information
Elix® 20, 35, 70 and 100 8
2-2 SYSTEM RECOVERY
WHAT IS RO RECOVERY?
An RO Cartridge has 1 feedwater inlet and 2 water streams exiting it. One exiting water stream is called the RO Permeate. The
other is called the RO Reject.
The RO % Recovery is a comparison of the RO Permeate flow rate to the RO Feedwater flow rate. It can be thought of as how
much water you ‘recover’ from the RO as a useful product.
It is calculated as:
% Recovery = [(Permeate flow rate / Feedwater flow rate] * 100%
Membrane % Recovery is defined as the recovery of a single RO Cartridge.
System % Recovery is defined as the amount of water produced relative to the amount going into the entire Elix System.
In most cases, the Membrane and System Recovery values will not be the same number.
ELIX SYSTEM RECOVERY
An Elix System can be operated with a System Recovery between 30% to 70%. This value will depend upon several factors
including the chemical makeup of the Feedwater.
System Recovery is defined above. See “What is RO Recovery?”
The Elix System Recovery is factory pre-set. If desired, the Elix System Recovery can be modified. Contact Millipore SAS for
assistance.
A System Recovery set too low will waste water. A low recovery occurs when a lot of RO Reject Water is sent to drain relative to
the RO Permeate flow rate (i.e. RO Recovery = 5%).
A System Recovery set too high can possibly cause the RO Cartridges to become clogged. A high recovery occurs when too little
RO Reject Water is sent to drain relative to the RO Permeate flow rate (i.e. RO Recovery = 80%).

Product Information
Elix® 20, 35, 70 and 100 9
2-3 SCHEMATIC OF MAIN COMPONENTS
SCHEMATIC OF AN ELIX SYSTEM
The water flow through an Elix Water Purification System is shown here in a flow diagram. A description of each item is in the
next section.
GUIDE TO SCHEMATIC
Identification of lettered items in the flow schematic above
Item Description Item Description
A Inlet Solenoid Valve L RO Permeate Divert Solenoid Valve
B Flowmeter M Elix Module
C Purge Valve N QGard TL 1 Polishing Pack (Optional)
D Progard™ TL System Pretreatment Pack O Product Water Resistivity Sensor
E Feedwater Pressure Switch P UV Lamp
F Feedwater Conductivity Cell Q Loop Resistivity Sensor (Optional)
G RO Pump (Motor + Pumphead) R A10 TOC Monitor (Optional)
H RO Cartridge S Back Pressure Regulator
I Flow Controller T Pressure Sensor
J Permeate Conductivity Cell U RO Reject Control Device
K Permeate Check Valve V RO Reject Solenoid Valve
A
C
E
F
G
H
I
J
K
M
L
O
N
D
B
P
S
R
Q
T
U
V

Product Information
Elix® 20, 35, 70 and 100 10
RO CARTRIDGE CONFIGURATION FOR ELIX SYSTEMS
The RO Cartridge configuration for each type of Elix Water Purification System is shown below.
Elix 20 / Elix 35
Elix 50
Elix 100

Product Information
Elix® 20, 35, 70 and 100 11
2-4 DESCRIPTION OF INPUT AND OUTPUT CONNECTIONS
This section describes the use of the various ports and other connection places on the front left side of the Elix System Cabinet.
PORTS
PORT DRAIN 1
The DRAIN 1 Port is used to secure the 1/2 inch OD RO Reject Tubing. This port allows RO Reject Water to exit the Elix System.
PORT FEED 2
The FEED 2 Port is used to secure the 1/2 inch OD Feedwater Tubing. This port allows Feedwater to enter the Elix System.
PORT CONC. 3
This port is used to secure the 8 mm OD Elix Module Waste Water Tubing. This port allows Elix Module Waste Water to exit the
Elix System.
PORT PRODUCT 4
The PRODUCT 4 Port is used to secure 8 mm OD Product Water Tubing. This port allows Product Water to exit the Elix System.
PORT 5
Port 5 is used when a peripheral device is connected to the Elix System. This port could be used to allow water to enter the Elix
System to the device inside.
PORT 6
Port 6 is used when a peripheral device is connected to the Elix System. This port could be used to allow water to enter the Elix
System to the device inside.
PORT 7
Port 7 is used when a peripheral device is connected to the Elix System. This port could be used to allow water to enter the Elix
System to the device inside.
TANK LEVEL AND RS 232
TANK LEVEL
A Male Stereo Jack from an Analogue Level Sensor can be plugged into the Elix System here. The Supply Voltage coming from
this connection to the Level Sensor is normally 5 VDC but can be set to 24 VDC.
RS 232
This connection allows a 9-pin Male RS 232 Cable to be plugged into the Elix System. The Transmit and Receive voltages out of
or into this connection are 5 VDC when active.

Product Information
Elix® 20, 35, 70 and 100 12
GROMMETS
The grommets are not labelled with text on the front left side of the Elix System Cabinet. The grommet is a rubber device that
covers most of a hole drilled in the side of the cabinet.
GROMMET 1
The bottom grommet is designated as Grommet 1. The Electrical Cable going from the Elix System to the externally located Inlet
Solenoid Valve goes through this grommet. The voltage in this electrical cable is either 100, 120 or 230 VAC depending upon the
voltage supplied to the Elix System.
GROMMETS 2THROUGH 7
These grommets are used to allow an electrical cable to go into or out of the Elix System. The electrical cable(s) are used to
control or to power peripheral devices. The voltage in any one of these electrical cables is dependent upon the device being used
and the way that the device is interfaced with the Elix System PC Board.
