Milwaukee M18 PC6 User manual

M18 PC6
Original instructions

2 3
6x
6x
4 6
5
9
8
PACKOUT
Text section with Technical Data, important Safety
and Working Hints and description of Symbols
10

4 5
1
2
4
3
5
RED
RED
GREEN
RED/GREEN
100 %
40°C
5°C
40°C
5°C
RED
GREEN

6 7
1
3
2
1
2
Devices connected to the USB port are supplied with power. Any
device that uses more than 2,1 A of DC electrical current will trip a
self-resetting function and disable the output.

8 9
78-100 %
55-77 %
33-54 %
10-32 %
< 10 %
1
2
1
2
3
click
PACKOUT
1

10 11
M18 PC6
18 V
100-240 V
2,5 A
18 V
/ 6 A
5 V
/ max. 2,1 A
50 mA
4,99 kg
+ 5°C ... + 40°C
TECHNICAL DATA
Type
Battery Voltage
Input Volts
Input Current
Output Charger
Output USB max.
Stand-by operation
Weight according EPTA-Procedure 01/2014
Recommended ambient charging temperature
WARNING! Read all safety warnings and all instructions.
Failure to follow the warnings and instructions may result in electric
shock, fire and/or serious injury.
Save all warnings and instructions for future reference.
SAFETY INSTRUCTIONS
Do not dispose of used batteries in the household refuse or by
burning them. Milwaukee Distributors offer to retrieve old batteries to
protect our environment.
The following batteries can be charged with this charger:
Battery Cat.
No.
Cell Type DC Volts Capacity Cell No.
M18B Li-Ion 18 V ≤1.5 Ah 5
M18B2 Li-Ion 18 V ≤2.0 Ah 5
M18BX Li-Ion 18 V ≤3.0 Ah 2 x 5
M18B4 Li-Ion 18 V ≤4.0 Ah 2 x 5
M18B5 Li-Ion 18 V ≤5.0 Ah 2 x 5
M18B6 Li-Ion 18 V ≤6.0 Ah 2 x 5
M18B9 Li-Ion 18 V ≤9.0 Ah 3 x 5
M18HB3 Li-Ion 18 V ≤3.0 Ah 5
M18HB4 Li-Ion 18 V ≤4.0 Ah 5
M18HB5.5 Li-Ion 18 V ≤5.5 Ah 2 x 5
M18HB8 Li-Ion 18 V ≤8.0 Ah 2 x 5
M18HB12 Li-Ion 18 V ≤12.0 Ah 3 x 5
Do not try to charge non-rechargeable batteries
with this charger.
Do not store the battery together with metal objects (short circuit
risk).
No metal parts must be allowed to enter the battery section of the
charger (short circuit risk).
Never break open batteries and chargers and store only in dry
rooms. Keep dry at all times.
Do not touch the tool with conducting objects.
Never charge a damaged battery pack. Replace by a new one.
Before use check machine, cable, and plug for any damages or
material fatigue. Repairs should only be carried out by authorised
Service Agents.
Always place the charger on a level, well ventilated surface (e.g. not
on a car seat).
Do not place anything, such as a jacket, over the charger and
battery.
This appliance is not intended to
be used or cleaned by persons with
reduced physical, sensory or mental
capabilities, or lack of experience or
knowledge, unless they have been
given instructions concerning the
safe use of the appliance by a person
legally responsible for their safety. They
should be supervised whilst using the
appliance. Children shall not use, clean
or play with this appliance, which when
not in use should be secured out of
their reach.
Warning! To reduce the risk of fire, personal injury, and product
damage due to a short circuit, never immerse your tool, battery pack
or charger in fluid or allow a fluid to flow inside them. Corrosive or
conductive fluids, such as seawater, certain industrial chemicals,
and bleach or bleach containing products, etc., can cause a short
circuit.
SPECIFIED CONDITIONS OF USE
This charger charges 18V Milwaukee Li-Ion battery packs.
Do not use this product in any other way as stated for normal use.
CHARGING TIME
Battery Cat. No. Volts Capacity Charging Time
approx.
M18B 18 V ≤1.5 Ah 21 min
M18B2 18 V ≤2.0 Ah 27 min
M18BX 18 V ≤3.0 Ah 35 min
M18B4 18 V ≤4.0 Ah 48 min
M18B5 18 V ≤5.0 Ah 63 min
M18B6 18 V ≤6.0 Ah 73 min
M18B9 18 V ≤9.0 Ah 101 min
M18HB3 18 V ≤3.0 Ah ≤35 min
M18HB4 18 V ≤4.0 Ah ≤35 min
M18HB5.5 18 V ≤5.5 Ah ≤60 min
M18HB8 18 V ≤8.0 Ah 85 min
M18HB12 18 V ≤12.0 Ah 128 min
MAINS CONNECTION
Connect only to single-phase AC current and only to the system
voltage indicated on the rating plate. It is also possible to connect
to sockets without an earthing contact as the design conforms to
safety class II.
NOTES FOR LI-ION BATTERIES
Use of Li-Ion batteries
Batteries which have not been used for some time should be
recharged before use.
Temperatures in excess of 50°C (122°F) reduce the performance
of the battery. Avoid extended exposure to heat or sunshine (risk of
overheating).
The contacts of chargers and battery packs must be kept clean.
For an optimum life-time, the batteries have to be fully charged, after
used.
To obtain the longest possible battery life remove the battery pack
from the charger once it is fully charged.
For battery storage longer than 30 days:
Store the battery where the temperature is below 27°C and away
from moisture
Store the battery in a 30% - 50% charged condition
Every six months of storage, charge the battery as normal.
Battery protection for Li-Ion batteries
In extremely high torque, binding, stalling and short circuit situations
that cause high current draw, the tool will vibrate for about 5
seconds, the fuel gauge will flash,and then the tool will turn OFF. To
reset, release the trigger.
Under extreme circumstances, the internal temperature of the
battery could become to high. If this happens, the fuel gauge will
flash and the battery pack cool and then continue work.
Transport of Li-Ion batteries
Lithium-ion batteries are subject to the Dangerous Goods Legislation
requirements.
Transportation of those batteries has to be done in accordance with
local, national and international provisions and regulations.
• The user can transport the batteries by road without further
requirements.
• Commercial transport of Lithium-Ion batteries by third parties is
subject to Dangerous Goods regulations. Transport preparation
and transport are exclusively to be carried out by appropriately
trained persons and the process has to be accompanied by
corresponding experts.
When transporting batteries:
• Ensure that battery contact terminals are protected and insulated
to prevent short circuit.
• Ensure that battery pack is secured against movement within
packaging.
• Do not transport batteries that are cracked or leak.
Check with forwarding company for further advice
CHARACTERISTICS
After inserting the battery into the reception of the charger the
battery will automatically be charged (red lamp is illuminated
continuously)
When a hot or cold battery pack is inserted into the charger (flashing
red lamp), charging will begin automatically once the battery
reaches the correct charging temperature (5°C...40°C). The max.
charging current is flowing when the temperature of the battery is
between 5°C and 40°C.
The battery’s charging time is between 1 min and 21 min (at 1,5 Ah
battery), depending on the state of discharge.
Once the battery is fully charged, the LED on the charger changes
from red to green and the LEDs on the battery go out.
It is not necessary to remove the battery after charging. The battery
can be stored permanently in the charger without the danger of
being overcharged.
If both LEDs flash alternately then the rechargeable battery is either
not fully pushed in or there is a fault with the battery or charger. Take
the charger and battery out of use immediately for safety reasons
and have them inspected by a Milwaukee customer service centre.
Two 18V battery packs can be inserted into the charger at the same
time, one on each side of the charger. It will then charge any other
attached batteries in sequence in a clockwise rotation.
CHARGER LIGHT INDICATORS
Continuous red Charging
Slow flashing green Approaching full charge
Continuous green Charging is complete
Fast flashing red
Battery or charger is too hot/
cold - charging will begin/
resume when battery or charger
reaches correct charging
temperature
Slow flashing red
Battery charge is pending -
Charging will begin when the
first pack is fully charged
Flashing red/green Damaged or faulty battery pack
or charger
USB POWER OUTLET
This outlet can be used to charge a cell phone, power an MP3
player or any other devices that uses less than 2,1 A of DC electrical
current.
MAINTENANCE
If the supply cord of this appliance is damaged, it must only be
replaced by a repair shop appointed by the manufacturer, because
special purpose tools are required
Use only Milwaukee accessories and Milwaukee spare parts. Should
components need to be replaced which have not been described,
please contact one of our Milwaukee service agents (see our list of
guarantee/service addresses).
If needed, an exploded view of the tool can be ordered. Please
state the machine type printed as well as the six-digit No. on
the label and order the drawing at your local service agents or
directly at: Techtronic Industries GmbH, Max-Eyth-Straße 10,
71364 Winnenden, Germany.
ENGLISH ENGLISH
6-Bay Packout Charger

1312
SYMBOLS
Please read the instructions carefully before starting
the machine.
Safety class III
This tool is only suitable for indoor use. Never expose
tool to rain.
Class II tool
T5,0A
Time-lag fuse 5,0 A
Do not dispose of waste batteries, waste electrical and
electronic equipment as unsorted municipal waste.
Waste batteries and waste electrical and electronic
equipment must be collected separately.
Waste batteries, waste accumulators and light sources
have to be removed from equipment.
Check with your local authority or retailer for recycling
advice and collection point.
According to local regulations retailers may have an
obligation to take back waste batteries and Waste
electrical and electronic equipment free of charge.
Your contribution to reuse and recycling of waste
batteries and waste electrical and electronic
equipment helps to reduce the demand of raw
materials.
Waste batteries, in particular containing lithium and
waste Electrical and electronic equipment contain
valuable, recyclable materials, which can adversely
impact the environment and the human health, if not
disposed of in an environmentally compatible manner.
Delete personal data from waste equipment, if any.
European Conformity Mark
UK Conformity Mark
Ukraine Conformity Mark
EurAsian Conformity Mark
ENGLISH

14 15

(05.22)
4100 4706 95
