Milwaukee M18 POALC User manual

OPERATOR'S MANUAL
Cat. No.
M18 POALC
M18™ PACKOUT™ AREA LIGHT/CHARGER
WARNING
To reduce the risk of injury, user must read and understand operator's manual.

2
WARNING
•Toreduce therisk ofinjury,close supervision isnec-
essary when an appliance is used near children.
•Store idle light out of reach of children. Warm
lights can become hazardous in the hands of children.
•Do not expose to rain. Store indoors.
•Power cord plugs must match the outlet. Never
modify the plug in any way. Do not use any
adapter plugs with earthed (grounded) power
tools.
reduce risk of electric shock.
•
•
Do not unplug by pulling on the cord. To unplug,
grasp the plug, not the cord.
Unplug the cord from outlet when not in use and
before servicing or cleaning.
•Avoid body contact with earthed or grounded
surfaces, such as pipes, radiators, ranges and
refrigerators. There is an increased risk of electric
shock if your body is earthed or grounded.
•To reduce the risk of electric shock, do not put light
in water orother liquid. Do notplace or store appliance
where it can fall or be pulled into a tub or sink.
•Do not abuse the cord. Never use the cord for
carrying, pulling or unplugging the product.
Keep cord away from heat, oil, sharp edges or
moving parts. Damaged or entangled cords increase
the risk of electric shock.
•Arrange cords carefully to avoid hazardous
environments. Tripping or snagging on cords can
cause injury and product damage. Do not allow
cords to run through puddles or across wet ground.
•
•Do not use on a ladder or unstable support.
Loose Stable footing on a solid surface enables
better control of the light in unexpected situations.
•Do not stare at the operating light source.
•Always use a suitable extension cord to reduce
the risk of electric shock.
•When operating a light outdoors, use an extension
cord suitable for outdoor use. Use of a cord suitable
for outdoor use reduces the risk of electric shock.
•
•
•
•
manufacturer. A charger that is suitable for one type
with another battery pack.
packs. Use of any other battery packs may create
•
When battery pack is not in use, keep it away
from other metal objects, like paper clips, coins,
keys, nails, screws or other small metal objects,
that can make a connection from one terminal
to another. Shorting the battery terminals together
Do not short circuit.A short-circuited battery
damage. A battery pack will short circuit if a metal
object makes a connection between the positive and
negative contacts on the battery pack. Do not place
a battery pack near anything that may cause a short
circuit, such as coins, keys or nails in your pocket.
•
•
•
•
•
•
•Avoid dangerous environments.Do not charge bat-
tery pack in rain, snow, damp or wet locations. Do not
use battery pack or charger in the presence of explo-
materials) because sparks may be generated when in-
•Charge in a well ventilated area.Do not allow
pack. Vented gases may explode.
IMPORTANT SAFETY
INSTRUCTIONS
Read all safety warnings and all
instructions. Failure to follow the
warnings and instructions may result in electric
shock, fire and/or serious injury. Save all warnings
and instructions for future reference.
This appliance is not intended to be used or
cleaned by persons with reduced physical,
sensory or mental capabilities, or lack of
experience or knowledge, unless they have been
given instructions concerning the safe use of the
appliance by a person legally responsible for their
safety. They should be supervised whilst using the
appliance.
Children shall not use, clean or play with this
appliance, which when not in use should be
secured out of their reach.
WORK AREA SAFETY
•
ELECTRICAL SAFETY
If operating a light in a damp location is
unavoidable, use a residual current device
(RCD) protected supply. Use of a RCD reduces
the risk of electric shock.
PERSONAL SAFETY
Do not overreach. Keep proper footing and
balance at all times. This enables better control
of the unit in unexpected situations.
To reduce the risk of fire or burns, keep hands
and combustible materials away from lens.
Lens may become hot after extended use.
BATTERY TOOL USE AND
CARE
Do not allow fluids to flow into battery pack.
Corrosive or conductive fluids, such as seawater,
certain industrial chemicals, and bleach or
products containing bleach.
Under abusive conditions, liquid may be
ejected from the battery; avoid contact. If
contact accidentally occurs, flush with water. If
liquid contacts eyes, additionally seek medical
help. Liquid ejected from the battery may cause
irritation or burns.
Do not use a battery pack or tool that is
damaged or modified. Damaged or modified
batteries may exhibit unpredictable behaviour
resulting in fire, explosion or risk of injury.
Do not expose a battery pack or tool to fire or
excessive temperature. Exposure to fire or
temperature above 130°C (265°F) may cause
explosion.
Follow all charging instructions and do not
charge the battery pack or tool outside the
temperature range specified in the
instructions. Charging improperly or at
temperatures outside the specified range may
damage the battery and increase the risk of fire.
CHARGER USE AND CARE
To reduce the risk of injury,
charge MILWAUKEE®Lithium-Ion
CAUTION
packs only in their MILWAUKEE®Lithium-Ion
charger. Other types of batteries may burst
causing personal injury and damage. Do not wire a
battery pack to a power supply plug or car cigarette
lighter. Batteries will be permanently disabled or
damaged.
Charge only MILWAUKEE®M18™ Lithium-Ion
packs. Other types of batteries may burst causing
personal injury or damage.
•

3
•
•
•Maintain charger cord. When unplugging char-
ger, pull plug rather than cord to reduce the risk of
damage to the electrical plug and cord. Never carry
charger by its cord. Keep cord from heat, oil and
sharp edges. Make sure cord will not be stepped on,
tripped over or subjected to damage or stress. Do
not use charger with damaged cord or plug. Have a
damaged charger replaced immediately.
•Use only recommended attachments. Use of an
attachment not recommended or sold by the battery
charger or battery pack manufacturer may result in a
•Unplug charger when not in use. Remove battery
packs from unplugged chargers.
•
•
Cat. No............................................... M18 POALC
•
DC Input Volts..................................................... 18V
DC Output Volts.................................................. 18V
AC Input Volts............................................ 220-240V
Output Volts USB.................................................. 5V
Output Amps USB ............................................. 2.1A
Operating Temperature
Battery and Charger ............................0°C to 65°C
(32°F to 150°F)
Battery and Tool................................-20°C to 40°C
(-4°F to 104°F)
M18TM Li-Ion Battery Packs...................... 18V DC
1. MODE button
2. Power button
3. Brightness button
4. Charger indicators
5. Battery bay
6. Handle
7. USB Outlet
8. Power plug
9. USB power button
1
23
4
5
6
8
97
To reduce the risk of electric shock, always
unplug charger before cleaning or maintenance.
Do not allow water to flow into AC/DC plug. Use a
residual current device (RCD) to reduce shock
hazards.
SERVICE
Store your battery and charger in a cool, dry
place. Do not store battery pack where
temperatures may exceed 50°C (120°F) such as in
direct sunlight, a vehicle or metal building during
the summer.
•Have your light serviced by a qualified repair
person using only identical replacement parts.
This will ensure that the safety of the light is
maintained.
Never service damaged battery packs. Service
of battery packs should only be performed by the
manufacturer or authorised service providers.
SPECIFIC SAFETY RULES FOR
LIGHTS
ADDITIONAL BATTERY SAFETY RULES
WARNING
WARNING
To reduce the risk of fire, personal
injury, and product damage due to
a short circuit, never immerse your tool, battery
pack or charger in fluid or allow a fluid to flow inside
them. Corrosive or conductive fluids, such as
seawater , certain industrial chemicals, and bleach
or bleach-containing products, etc., can cause a
short circuit.
Do not charge non-rechargeable
batteries.
WARNING
The lens may get hot during use.
To reduce the risk of burns, do not
touch hot lens.
Always use common sense and be cautious
when using the product. It is not possible to
anticipate every situation that could result in a
dangerous outcome. Do not use this product if you
do not understand these operating instructions or
you feel the work is beyond your capability; contact
MILWAUKEE®Tool or a trained professional for
additional information or training.
Maintain labels and nameplates. These carry
important information. If unreadable or missing,
contact a MILWAUKEE®service facility for a
replacement.
SAVE THESE INSTRUCTIONS
SPECIFICATIONS
FUNCTIONAL DESCRIPTION
The light source contained in the product shall only
be replaced by the manufacturer, its service agent
or a similar qualified person.
•
If the external flexible cable or cord of the product
is damaged, it shall be exclusively replaced by the
manufacturer.
•
DC Output Power
............................................. 45W
AC Input Power ............................................... 130W
Frequency.................................................. 50-60Hz
IP rating........................................................... IP54

4
WARNING
Removing/Inserting the Battery
To remove the battery, push in the release buttons
and pull the battery pack away from the tool.
changing or removing accessories.
WARNING
Always remove battery pack before
To insert the battery, slide the pack into the body
of the tool. Make sure it latches securely into place.
WARNING
reco
Only use
mmended
accessorie
for thi
s
s tool. Others
may be hazardous.
SYMBOLOGY
Volts
Direct Current
Alternating Current
Amps
Hertz
Do not stare at the operating light
source.
Double insulated
Do not step or stand.
AC Power
Universal serial bus (USB)
USB power button
OPERATION
CAUTION
To reduce the risk of injury
stare at the operating light source.
, do not
Using the Lights
1. Insert battery pack or connect to AC power.
2. Press the power button to turn on the light.
3. Press the brightness button to cycle through
High, Medium, and Low.
4. Press the MODE button to select full lighting, main
light, or front/back lights.
5. Press the power button to turn OFF the light.
Rotating the Lights
USB Power Outlet
This outlet can be used to charge a cell phone,
power an MP3 player or any other device that uses
less that 2.1A of DC electrical current. To turn on the
USB, press the USB power button. The USB
port will remain on for two hours before turning off
automatically.
NOTE: Any device that uses more than 2.4A of DC
electrical current will trip a self-resetting overload
and disable the output.
Do not dispose of electric tools
together with household waste
material. Electric tools and electronic
equipment that have reached the end
of their life must be collected
separately and returned to an
environmentally compatible recycling
facility.
Regulatory Compliance Mark (RCM).
This product meets applicable
regulatory requirements.
Read operator's manual
ASSEMBLY
NOTE: The light will default to the selected
brightness and selected mode setting the next time
it is turned on. On battery power, the light will flash
to indicate the battery is reaching end-of-charge.
To rotate the main light, pull the light outward and
rotate up to 210° counterclockwise or 95°
clockwise.To rotate the front and back lights, pull
the lights outward and rotate up to 30° counter-
clockwise or 300° clockwise.
T3.15A
Time lag fuse
Recharge only with the charger
specified for the battery. For
specific charging instructions, read the
operator’s manual supplied with your charger
and battery.

5
78-100%
55-77%
33-54%
10-32%
Approximate Run
Fuel Gauge
Time Remaining
Fuel Gauge Lights Diagnosis Solution
Lights 1 - 4 Solid Remaining run time Continue working
slowly
Less than 10% run
time left Prepare to charge pack
quickly End of discharge Charge pack
quickly
Current draw too
high
Release trigger and
restart, reduce pressure
Lights 1&3 / 2&4, Battery temperature
too high
Release trigger and allow
battery to cool
NOTE: If the Fuel Gauge doesn't appear to be
working, place the battery pack on the charger and
charge as needed.
Battery Pack Protection
Cold Weather Operation
BATTERY OPERATION
Use the Fuel Gauge on the battery pack to
determine the battery pack's remaining run time.
Press the Fuel Gauge button to display the lights.
The Fuel Gauge will light up for 2-3 seconds. When
less than 10% of charge is left, 1 light on the fuel
gauge will flash slowly.
Compared to NiCd battery pack types,
MILWAUKEE®Lithium-Ion battery packs deliver
fade-free power for their entire run time. The tool
will not experience a slow, gradual loss of power as
you work. To signal the end of discharge, 1 light on
the fuel gauge will flash quickly for 2-3 seconds and
the tool will not run. Charge the battery pack.
NOTE: Immediately after using the battery pack,
the Fuel Gauge may display a lower charge than it
will if checked a few minutes later. The battery cells
"recover" some of their charge after resting.
To protect itself from damage and extend its life, the
battery pack’s intelligent circuit monitors current
draw and temperature. In extremely high torque,
binding, stalling, and short circuit situations, the
battery pack will turn OFF the tool if the current
draw becomes too high. All the fuel gauge lights will
flash. Release the trigger and restart.
Under extreme circumstances, the internal
temperature of the battery could become too high. If
this happens, the fuel gauge lights will flash in an
alternating pattern and the tool will not run. Allow
the battery to cool down.
MILWAUKEE®Lithium-Ion battery packs are
designed to operate in temperatures below freezing.
When the battery pack is too cold, it may need to
warm up before normal use. Put the battery on a tool
and use the tool in a light application. It may “buzz”
for a short time until it warms up. When the buzzing
stops, use the tool normally.
WARNING
To reduce the risk of injury or ex-
Maintenance and Storage
Do not expose your battery pack or cordless tools
to water or rain, or allow them to get wet. This could
damage the tool and battery pack. Do not use oil or
solvents to clean or lubricate your battery pack. The
plastic casing will become brittle and crack, causing
a risk of injury.
Transport
Personal transport of Li-Ion battery packs is allowed
when done in accordance with these warnings and
-
beling, marking, and documentation requirements for
shipping Li-Ion batteries is dependent upon whether
the particular batteries are rated greater than or less
than 100 Wh (Watt Hours can be found on the battery
pack nameplate). Generally, Li-Ion batteries rated
100 Wh or less are “excepted” from certain Class 9
DG requirements. Always check compliance of Li-Ion
battery consignments against the current regulations
governing the chosen mode of transport. When in
doubt, contact the carrier or other trained Dangerous
(battery only) or UN 3481 (batteries contained in or
packed with equipment).
plosion, never burn or incinerate a
battery pack even if it is damaged, dead or com-
pletely discharged. When burned, toxic fumes
and materials are created.
Disposing of MILWAUKEE®Lithium-Ion
Battery Packs
Store battery packs at room temperature away from
moisture. Do not store in damp locations where
corrosion of terminals may occur. As with other
battery pack types, permanent capacity loss can
result if the pack is stored for long periods of time at
high temperatures (over 49°C). MILWAUKEE®
Lithium-Ion battery packs maintain their charge
during storage longer than other battery pack types.
After about a year of storage, charge the pack as
normal.
MILWAUKEE®Lithium-Ion battery packs are more
environmentally friendly than some other types of
power tool battery packs (e.g., nickel-cadmium).
Always dispose of your battery pack according to
federal, state and local regulations. Contact a
recycling agency in your area for recycling
locations.
Even discharged battery packs contain some
energy. Before disposing, use electrical tape to
cover the terminals to prevent the battery pack from
shorting, which could cause a fire or explosion.

6
WARNING
When to Charge the Battery Pack
Continuous red: Charging
Continuous green light: Charging is complete
Flashing red: Battery is too hot/cold
Charging will begin when battery reaches
correct charging temperature
Flashing red/green: Damaged or faulty battery
pack
•
•
•
How to Charge the Battery Pack
•When a battery pack is inserted into the charger,
the LEDs will indicate the following:
•A fully discharged battery pack with an internal
temperature in the normal range will charge
in about 30 to 185 minutes, depending on the
battery pack.
•Heavily cycled batteries may take longer to
charge completely.
•The Fuel Gauge lights on the battery pack are
displayed as the pack is being charged, indicating
how fully charged the pack is. The fuel gauge will
•After charging is complete, the continuous green
light will come on.
•The charger will keep the battery pack fully
charged if it is left on the charger. The light
charging.
•
•If the light indicator does not come on, check
that the battery pack is fully seated into the bay.
CHARGER OPERATION
Charge only MILWAUKEE®M18™
Lithium-Ion batteries in this
MILWAUKEE®Lithium-Ion charger. Other types
of batteries may cause personal injury and
damage.
To charge the battery pack, connect the light to AC
power and insert a battery pack. The light will
remain operational when the battery pack is
charging. MILWAUKEE®batteries do not develop a
"memory" when charged after only a partial
discharge. It is not necessary to run down the
battery pack before placing it on the charger.
Use the Fuel Gauge to determine when to charge
your MILWAUKEE®Lithium-Ion battery pack.
You can "Top-Off" your battery pack's charge
before starting a big job or long day of use.
The only time it is necessary to charge the
MILWAUKEE®Lithium-Ion battery pack is when
the battery pack has reached the end of its charge.
To signal the end of charge, power to the tool will
drop quickly, allowing you just enough power to
finish making a cut, drilling a hole, or driving a
fastener. Charge the battery pack as needed.
Plug the light into a 230-240V outlet. The battery
pack will not charge if the Light is not plugged in.
Align the battery pack with the bay and slide the
battery pack into the charger as far as possible.
If the light indicator flashes red and green, check
that the battery pack is fully seated into the bay.
Remove the pack and reinsert. If the problem
persists, contact a MILWAUKEE®service facility.
Remove the battery pack and reinsert. If the
light indicator still does not come on, contact a
MILWAUKEE®service facility.
Lithium-Ion Charging Status
Battery Pack
Temperature
Red Charger
Indicator Light
Charging Status
Charging a Hot or Cold Battery Pack
The Red Flashing Indicator light on the charger in-
dicates that the battery pack temperature is outside
the charging range. Once the battery pack is within
the acceptable range, normal charging will take place
and the red light will be continuous. Hot or cold bat-
teries may take longer to charge.
Too Hot
Normal Range
Too Cold
Fast Flashing
Continuous
Fast Flashing
Not charging
Normal charging
Not charging
MAINTENANCE
WARNING
WARNING
To reduce the risk of personal in-
jury and damage, never immerse
Maintaining Light
Keep your light, battery pack and charger in good
repair by adopting a regular maintenance program.
If the light does not work properly, return the light to
a MILWAUKEE®service facility for repairs.
WARNING
Use only recommended accesso-
ries. Others may be hazardous.
your tool, battery pack or charger in liquid or
Cleaning
Repairs
For repairs, return the tool, battery pack and charger
to the nearest authorised service centre.
ACCESSORIES
To reduce the risk of injury,
always unplug the charger and
remove the battery pack from the charger or
tool before performing any maintenance. Never
disassemble the tool, battery pack or charger.
Contact a MILWAUKEE®service facility for ALL
repairs.
To reduce the risk of fire, personal injury, and
product damage due to a short circuit, never
immerse your tool, battery pack or charger in
fluid or allow a fluid to flow inside them.
Corrosive or conductive fluids, such as
seawater, certain industrial chemicals, and
bleach or products containing bleach, etc., can
cause a short circuit.
For a complete listing of accessories, go online to
milwaukeetool.com.au/ milwaukeetool.co.nz or
contact a distributor.
Clean dust and debris from vents. Keep handles
clean, dry and free of oil or grease. Use only mild
soap and a damp cloth to clean, since certain
cleaning agents and solvents are harmful to plastics
and other insulated parts. Some of these include
gasoline, turpentine, lacquer thinner, paint thinner,
chlorinated cleaning solvents, ammonia and
household detergents containing ammonia. Never
use flammable or combustible solvents around
tools.

WARRANTY - AUSTRALIA and NEW ZEALAND
SERVICE - AUSTRALIA and NEW ZEALAND
21 Kelletts Road, Rowville, VIC 3178
Please refer to Australian and New Zealand warranty supplied with tool. This warranty applies only to
product sold by authorised dealers in Australia and New Zealand.
Milwaukee Electric Tool Corporation
13135 West Lisbon Road, Brookfield, Wisconsin U.S.A. 53005
Milwaukee Tool (Australia)
Melbourne, Australia
Milwaukee Tool (New Zealand)
274 Church Street, Penrose,
Auckland, 1061, New Zealand
MILWAUKEE®prides itself in producing a premium quality product that is Nothing But Heavy DutyTM.
Your satisfaction with our products is very important to us! If you encounter any problems with the
operation of this tool, please contact your authorised MILWAUKEE®dealer.
For a list of MILWAUKEE®dealers, guarantee or service agents please contact MILWAUKEE®
Customer Service or visit our website.
(Australia Toll Free Telephone Number 1300 645 928)
(New Zealand Toll Free Telephone Number 0800 645 928)
or visit milwaukeetool.com.au/milwaukeetool.co.nz.
01613600301Q-01B
DESIGNED BY MILWAUKEE ELECTRIC TOOL CORP.
PROFESSIONALLY MADE IN CHINA
PRINTED IN CHINA
All trade marks are owned by Techtronic Cordless GP unless otherwise stated.
© 2020 Milwaukee Electric Tool Corporation.
