Mini Gadgets MiniClockCamHD User manual

MINI CLOCK CAMERA HD
HIDDEN CLOCK DVR
SKU: MiniClockCamHD
THANK YOU FOR PURCHASING THE MINI CLOCK CAMERA
HD HIDDEN CLOCK DVR
Please read this manual before operating the mini clock camera HD
and keep it handy.
Our line of mini clock cams is one of our bestselling products. These
functional clocks with hidden cameras are a great option for covert
recording. This new sleek design not only has a style that will fit into
any home, it also has full HD recording. Uniquely to this model, you
can watch the recorded videos on your television using the HDMI
cable. The display cycles through time, date, and temperature.
The mini clock camera HD records 1920*1080 resolution video in full
color. This unit also has HDMI output with onscreen menu settings,
giving you an easy way to configure your device. Use the remote
control to choose between continuous video recording, motion
detection, audio only, and taking still photographs. The battery lasts
for up to 8 hours on one charge. In addition to its long battery life,
this unit can also record while plugged in to a wall adapter. Store
from 4GB up to 32GB of data on Micro SD. Connect the device
directly to your computer for file transfer.
Your purchase should include:
1 x Mini Clock Camera HD
1 x Remote Control
1 x USB Cable
1 x A/C Adapter
1 x HDMI Cable
1 x Instruction Booklet

GET FAMILIAR WITH YOUR MINI CLOCK CAMERA HD
Figure 1: Front View
Figure 2: Back View
Camera
Lens
LCD Display
Clock Function Buttons
On / Off
Switch
HDMI
Port
USB Port
MicroSD
Card Slot
Battery
Indicator
Light

OPERATING THE MINI CLOCK
CAMERA HD
IMPORTANT NOTICE: Allow the device to
charge 4 –6 hours before using.
HOW TO CHARGE THE MINI CLOCK
CAMERA HD
Using the AC Adapter
1. Plug the AC adapter with cable into
a wall outlet
2. Plug the cable into the mini clock
camera pro
The red indicator light will be
on while the device is
charging
Using the USB Cable
1. Plug the USB cable into your PC
2. Plug the USB cable into the mini
clock camera pro
The red indicator light will be
on while the device is
charging
The red indicator light will
turn off when fully charged
HOW TO SET THE TIME AND DATE
The time, date, and temperature will all be
displayed on the front LCD display.
The first time you plug in the mini clock
travel, the LCD display will count upward
0 –9.
The LCD display will rotate between time,
date, and temperature. The temperature
default is Celsius and the time default is
Military.
Five buttons that you need for setting up
the mini clock travel are located on the back
of the device (see Figure 2):
TIME
DOWN
UP
SET
MODE
Set the Year
1. Push the SET button on the back of
the device. “2010” should be
blinking on the LCD display.
2. Push the UP button on the back of
the device until the LCD display
reads the current year.
Set the Month and Day
1. Push the SET button again. There
should be a “1” blinking on the left
side of the LCD display. This is the
month.
2. Push the UP or DOWN button until
the number on the left side reads
the current month.
3. Push the SET button again. There
should be a “1” blinking on the right
side of the LCD display. This is the
day.
4. Push the UP or DOWN button until
the number on the right side reads
the current day.
Set the Time
1. Push the SET button again. The hour
should be blinking.
2. Push the UP or DOWN button until
the LCD display reads the current
hour.
3. Push the SET button again. The
minutes should be blinking.
4. Push the UP or DOWN button until
the LCD display reads the current
minute.
Switch from Military to Civilian Time
1. Push the TIME button on the back of
the device.
2. Push the UP button to switch
between military (24:00) and civilian
(12:00).
If the time is after noon, the
PM light should be on.

Switch from Celsius to Fahrenheit
1. Push the TIME button on the back of
the device.
2. Push the DOWN button to switch
between degrees Celsius and
degrees Fahrenheit.
NOTICE: If done correctly, the time, date,
and temperature will alternate on a loop.
Set the Alarm
1. Push the TIME button on the back of
the device.
2. Push the MODE button on the back
of the device. The LCD display
should read like the following:
3. Push the SET button on the back of
the device. The hour should be
blinking.
4. Push the UP or DOWN button to set
the hour for which you want the
alarm to sound.
5. Push the SET button again. The
minutes should be blinking.
6. Push the UP or DOWN button to set
the minute for which you want the
alarm to sound.
7. Push the SET button again. The LCD
display should read with a “01.”
This is the snooze.
Snooze can last from
1 –60 minutes.
8. Push the UP or DOWN button to set
the snooze time.
9. Push the SET button again. The LCD
display should read with a “1.”
This is the alarm ring.
There are 6 rings from which
to choose
Rings 1 –5 are nature sounds
Ring 6 is a repetitive buzz.
10. Push the MODE button on the back
of the device to exit the alarm.
NOTICE: You have only set the alarm with
these steps
Turn On the Alarm
1. Push the TIME button on the back of
the device.
2. Push the MODE button on the back
of the device.
3. Push the UP button on the back of
the device. The alarm light —
located directly beneath the PM
light —on the LCD display should be
lit.
4. Push the MODE button to exit the
alarm.
5. Repeat steps 1 –4 to turn the alarm
off.
6. To stop the alarm after it sounds,
press the button on top of the
device.
PREPARING THE DEVICE FOR USE
1. Be sure the small On / Off switch—
located above the battery and to the
left of the USB port —is in the ON
position.
2. Insert a MicroSD card —4GB or
higher —into the slot located to the
left of the HDMI port.
If there is no SD card in the
slot, the indicator light will
flash red/blue while the
device is plugged in.
If there is an SD card in the
slot, the indicator light will
be solid red/blue while the
device is plugged in.
3. Make sure your mini clock camera
HD has been fully charged.
4. Place the device where you want to
record.

USING THE REMOTE
Power Button
Night Vision Lamp
Photo Button / Select Up
Video Button / Select Down
Motion Detection / Menu
OK Button
HOW TO TURN ON THE CAMERA
1. Push the Power Button on the remote
The blue indicator light will come on
HOW TO RECORD VIDEO
1. Push the Video Button on the remote
The blue indicator light will flash 3 times slowly
The device is now recording
HOW TO TAKE PHOTOS
1. Push the Camera Button
The blue indicator light will blink once slowly
HOW TO USE MOTION DETECTION
1. Press the Motion Detection Button
The blue indicator light will flash quickly

OPERATING THROUGH THE HDMI CABLE
1. Connect the HDMI cable to the television
2. Connect the HDMI cable to the mini clock camera HD
3. Access the HDMI input with your television remote
4. Slide the On / Off switch into the ON position
5. Push the Power button on the camera remote
6. Push the Night Vision Lamp button on the camera remote
7. Push the Menu button on the camera remote
8. Use the Select Up and Select Down buttons to navigate
through the menu
HOW TO ADJUST THE RESOLUTION
1. Use the Select Up and Select Down buttons to select
Resolution
2. Press the OK button
3. Use the Select Up and Select Down buttons to select the
resolution with which you want to record
4. Press the OK button
HOW TO CHANGE THE TIME AND DATE STAMP
1. Use the Select Up and Select Down buttons to select
Time/Date
2. Press OK
3. Use the Select Up and Select Down buttons to change the year
4. Press OK
5. Use the Select Up and Select Down buttons to change the
month
6. Press OK
7. Use the Select Up and Select Down buttons to change the day
8. Press OK
9. Use the Select Up and Select Down buttons to change the
hour (military time)
10. Press OK
11. Use the Select Up and Select Down buttons to change the
minute
12. Press OK
13. Use the Select Up and Select Down buttons to change the
seconds
14. Press OK
15. Use the Select Up and Select Down buttons to change the date
display
16. Press OK
HOW TO CHANGE THE LANGUAGE
1. Use the Select Up and Select Down buttons to select Language
2. Use the Select Up and Select Down buttons to choose the
language you want
3. Press OK
HOW TO FORMAT THE SD CARD
1. Use the Select Up and Select Down buttons to select Format
2. Use the Select Down button to choose SD Card
3. Press OK

RETRIEVE THE FILES TO YOUR PC
1. Plug the device into your PC using the USB cable.
2. Locate “Removable Disk” inside the (My) Computer folder.
AutoPlay Removable Disk > Open folder to view files
Or…
Go to Start > Computer > Removable Disk
3. Open the Removable Disk drive.
4. Open the DCIM folder.
5. Open the folder featuring a sequence of numbers.
6. Double click the file you want to view.
VLC Player is recommended for watching videos.

TROUBLESHOOTING
THE DEVICE WON’T TURN ON
Charge the device for at least 4 hours before the first use.
Make sure the charging cable is securely inserted into the
device and into the power source.
THE DEVICE ISN’T CHARGING
Replace the battery or charging cable.
If you are charging via a wall power source, you may need to
charge via your PC. The A/C adapter might be bad.
THE DEVICE HAS CRASHED
You need to reset the device.
oTake out the battery and put it back in.
MY COMPUTER DOESN’T RECOGNIZE THE DEVICE
Unplug the device from your PC and reboot the device.
Unplug the device from your PC and reboot your PC.
Try using a different USB slot on your PC.
Replace the USB cable.
THE SOUND OR VIDEO IS UNCLEAR
The device needs charging.
THE INDICATOR LIGHT IS ON, BUT THE CAMERA WILL NOT
RECORD VIDEO OR TAKE PHOTOS
The SD card may be too small.
oInsert and SD card at least 4GB –32GB.
THE INDICATOR LIGHT IS FLASHING RED/BLUE
There is no SD card in the device.
OTHER PROBLEMS
Call our technical support at 770–694–6921
SPECIFICATIONS
Video Resolution
1920*1080
Video Format
AVI
Frames per Second
30
Vision Angle
160°
Motion Detection
Yes
Lux Rating
1LUX
Water Resistant
No
Battery Life
8 hours
Type of Memory
MicroSD Card
Memory Capacity
4GB –32GB
USB Interface
2.0 USB
Player Software
VLC recommended
Operating Systems
Windows 2000
Windows Me
Windows XP
Windows Vista
Windows 7
Mac OSX
Linux
