Minolta CF2001P User manual

CF2001P
7664-7714-01
User Manual
If used as a MicroPress printer, refer to the manual in the
Minolta MicroPress Cluster Printing System server.

Energy Star®
As an ENERGY STAR®Partner, we have determined that this machine
meets the ENERGY STAR®Guidelines for energy efficiency.
What is an ENERGY STAR®Product?
An ENERGY STAR®product has a special feature that allows it to auto-
matically switch to a “low-power mode” after a period of inactivity. An EN-
ERGY STAR®product uses energy more efficiently, saves you money on
utility bills and helps protect the environment.
Trademarks and Registered Trademarks
Fiery and the Fiery logo are registered trademarks of Electronics for Im-
aging, Inc.
Fiery X3e is a trademark of Electronics for Imaging, Inc.
T/R Systems, MicroPress and other T/R Systems’ product names are
either trademarks or registered trademarks of T/R Systems, Inc. in the
United States and other countries.
DiALTA and NMT are registered trademarks of Minolta Co., Ltd.
All other product names mentioned are trademarks or registered trade-
marks of their respective companies.

CF2001P i
Contents
1 Introduction
1.1 We Want You to Be a Satisfied Customer ..................................1-1
1.2 SAFETY INFORMATION................................................................1-1
Warning and Precaution Symbols...................................................1-2
Meaning of Symbols........................................................................1-2
WARNING.......................................................................................1-2
CAUTION........................................................................................1-4
Precautions for Routine Use...........................................................1-5
USER INSTRUCTIONS
FCC PART 15 - RADIO FREQUENCY DEVICES
(For U.S.A. Users)...........................................................................1-6
INTERFERENCE-CAUSING EQUIPMENT STANDARD
(ICES-003 ISSUE 3) (For Canada Users).......................................1-6
CE Marking (Declaration of Conformity) for Users of the European
Union (EU) ......................................................................................1-6
For users in countries subject to Class B regulations.....................1-7
For users in countries not subject to Class B regulations...............1-7
Ozone Release ...............................................................................1-7
WARNING LABEL...........................................................................1-8
LED Radiation Safety......................................................................1-8
1.3 Guide to Manuals..........................................................................1-9
Enclosed Manuals...........................................................................1-9
Explanation of Manual Conventions................................................1-9
1.4 Explanation of Basic Concepts and Symbols..........................1-11
Paper Feeding...............................................................................1-11
“Width” and “Length”.....................................................................1-12
Paper Orientation..........................................................................1-12
1.5 Features .......................................................................................1-13
2Precautions
2.1 Installation Precautions................................................................2-1
Installation site ................................................................................2-1
Power source..................................................................................2-1
Space requirements........................................................................2-2
2.2 Operation Precautions..................................................................2-3
Operating environment....................................................................2-3
Proper use.......................................................................................2-3

ii CF2001P
Transporting the printer .................................................................. 2-4
Care of printer supplies ..................................................................2-4
3 Before Making Prints
3.1 Components and Their Functions ..............................................3-1
3.2 Parts Names and Their Functions .............................................. 3-4
Outside of Printer............................................................................3-4
Inside of Printer ..............................................................................3-6
Supplies and Parts .........................................................................3-7
Duplex Unit (Optional)....................................................................3-8
10-Mailbin Sorter (Optional) ........................................................... 3-9
Finisher (Optional)........................................................................ 3-10
Paper Feed Unit (Optional)...........................................................3-11
Large-Capacity Cabinet (Optional)...............................................3-12
Printer Controller Fiery X3e.......................................................... 3-12
Printer Controller MicroPress PrintLink 2020m ............................ 3-12
3.3 Names of Control Panel Parts and Their Functions................ 3-13
Names of Control Panel Parts and Their Functions ..................... 3-13
3.4 Power Switch .............................................................................. 3-14
Turning the printer on and off....................................................... 3-14
To turn the printer on.................................................................... 3-14
To turn the printer off.................................................................... 3-14
Turning On the Printer.................................................................. 3-15
Turning Off the Printer.................................................................. 3-16
To turn off the printer.................................................................... 3-16
3.5 Total Counter.............................................................................. 3-18
To print the total counter............................................................... 3-18
4PrintPaper
4.1 Paper Specifications ....................................................................4-1
Paper Types...................................................................................4-1
Paper Sizes....................................................................................4-2
Paper Types To Be Avoided........................................................... 4-5
4.2 Print Area ...................................................................................... 4-6
4.3 Paper Storage ............................................................................... 4-6
4.4 Loading Paper............................................................................... 4-7
To load paper into Tray 1 (250-sheet multipurpose tray) ...............4-7
To set the paper size for Tray 1....................................................4-11
To load paper into Tray 2 or the 500-sheet paper feed unit......... 4-12
To load paper into the large-capacity cabinet...............................4-14
To load paper into the manual bypass tray ..................................4-16

CF2001P iii
5 Control Panel Messages
5.1 Message List..................................................................................5-1
To load paper into Tray 1
(250-sheet multipurpose paper drawer)..........................................5-4
To load paper into Tray 2 or the 500-sheet paper feed unit............5-5
To load paper into the large-capacity cabinet.................................5-7
5.2 When the Message “Xxxx toner nearly empty” Appears..........5-8
To add toner....................................................................................5-9
5.3 When the Message “No xxxx staples” Appears.......................5-12
To replace the staple cartridge......................................................5-12
5.4 Clearing a Paper Misfeed and Staple Jam................................5-16
To clear a paper misfeed in the manual bypass tray....................5-18
To clear a paper misfeed in the duplex unit..................................5-20
To clear a paper misfeed in the paper feed unit............................5-21
To clear a paper misfeed in the printer .........................................5-23
To clear a paper misfeed in finisher FN-107/FN-108....................5-26
To clear a paper misfeed in the 10-mailbin sorter.........................5-30
To clear jammed staples...............................................................5-33
5.5 When the Message “Service Code Cxxxx” Appears ...............5-36
5.6 When the Message “xxxx unit near life limit” Appears...........5-37
5.7 When the Message “Near troble XX/XX” Appears...................5-38
6 Troubleshooting
6.1 Improving Print Quality ................................................................6-1
7Appendix
7.1 Specifications................................................................................7-1
Printer CF2001P .............................................................................7-1
500-sheet Paper Feed Unit PF-118................................................7-2
Large-capacity Cabinet PF-117 ......................................................7-3
Duplex Unit AD-14 ..........................................................................7-3
10-Mailbin Sorter JS-1002 ..............................................................7-4
Finisher FN-107 ..............................................................................7-5
Finisher FN-108 ..............................................................................7-6
7.2 Care of the Printer.........................................................................7-7
Cleaning..........................................................................................7-7
Housing cover.................................................................................7-7
Control panel...................................................................................7-7
8Index

iv CF2001P

Introduction 1
CF2001P 1-1
1 Introduction
1.1 We Want You to Be a Satisfied Customer
Thank you for choosing a Minolta CF2001P.
To ensure the best performance and effective use of your printer, this
manual will provide information on the following topics:
GGetting to Know Your printer.
GInitial Steps . . .
GTroubleshooting.
Please read this manual carefully before using your printer and keep it
handy at all times. Store the manual in the holder on the rear side of the
printer.
1.2 SAFETY INFORMATION
This section contains detailed instructions on the operation and mainte-
nance of this machine. To achieve optimum utility of this device, all oper-
ators should carefully read and follow the instructions in this manual.
Please keep this manual in a handy place near the machine.
* Please note that some parts of the contents of this section may not correspond with the pur-
chased product.
Please read the next section before using this device. It contains important information relat-
ed to user safety and preventing equipment problems.
Make sure you observe all of the precautions listed in this manual.

1Introduction
1-2 CF2001P
Warning and Precaution Symbols
Meaning of Symbols
WARNING
Ignoring this warning could cause serious injury or even death.
Ignoring this caution could cause injury or damage to property.
WARNING:
CAUTION:
A triangle indicates a danger against which you should take precaution.
This symbol warns against possible electrical shock.
A diagonal line indicates a prohibited course of action.
This symbol warns against dismantling the device.
A black circle indicates an imperative course of action.
This symbol indicates you must unplug the device.
• Do not modify this product, as a fire, electrical shock, or breakdown could
result. If the product employs a laser, the laser beam source could cause
blindness.
• Do not attempt to remove the covers and panels which have been fixed to
the product. Some products have a high-voltage part or a laser beam
source inside that could cause an electrical shock or blindness.
• Only use the power cord supplied in the package. Failure to use this cord
could result in a fire or electrical shock.
• Use only the specified power sourcevoltage. Failure to do that could result
in a fire or electrical shock.
• Do not use a multiple outlet adapter to connect any other appliances or ma-
chines. Use of a power outletfor more than the marked current valuecould
result in a fire or electrical shock.
Do not unplug and plug in the power cord with a wet hand, as an electrical
shock could result.
Plug the power cord all the way into the power outlet. Failure to do this could
result in a fire or electrical shock.

Introduction 1
CF2001P 1-3
• Do not scratch, abrade, place a heavy object on, heat, twist, bend, pull on,
or damage the power cord. Use of a damaged power cord (exposed core
wire, broken wire, etc.) could result in a fire or breakdown.
Should any of these conditions be found, immediately turn OFF the power
switch, unplug the power cord from the power outlet, and then call your au-
thorized service representative.
• In principle, do not use an extension cord. Use of an extension cord could
cause a fire or electrical shock. Contact your authorized service represen-
tative if an extension cord is required.
Do not place a flower vase or other container that contains water, or metal
clips or other small metallic objects on this product. Spilled water or metallic
objects dropped inside the product could result in a fire, electrical shock, or
break-down.
Should a piece of metal, water, or any other similar foreign matter get inside
the product, immediately turn OFF the power switch, unplug the power cord
from the power outlet, and then call your authorized service representative.
• If this product becomes inordinately hot or emits smoke, or unusual odor or
noise, immediately turn OFF the power switch, unplug the power cord from
the power outlet, and then call your authorized service representative. If
you keep on using it as is, a fire or electrical shock could result.
• If this product has been dropped or its cover damaged, immediately turn
OFF the power switch, unplug the power cord from the power outlet, and
then call your authorized service representative. If you keep on using it as
is, a fire or electrical shock could result.
Do not throw the toner cartridge or toner into an open flame. The hot toner
may scatter and cause burns or other damage.
Connect the power cord to an electrical outlet that is equipped with a ground-
ing terminal.
