Mitsubishi Electric City Multi PEFY-WP20VMA-E Product guide
PEFY-WP-VMA-E
MODEL
AIR CONDITIONING SYSTEMS
PEFY-WP-VMA-E
MEES17K198 1
CONTENTS Ceiling concealed (Medium static pressure type)
I.Ceiling concealed (Medium static pressure type)
1. SPECIFICATIONS .................................................................................................................................... 2
2. EXTERNAL DIMENSIONS ....................................................................................................................... 5
3. CENTER OF GRAVITY ............................................................................................................................ 9
4. ELECTRICAL WIRING DIAGRAMS ......................................................................................................... 10
5. SOUND LEVELS ...................................................................................................................................... 11
5-1. Sound levels .................................................................................................................................... 11
5-2. NC curves ........................................................................................................................................ 12
6. FAN CHARACTERISTICS CURVES........................................................................................................ 18
7. ELECTRICAL CHARACTERISTICS......................................................................................................... 24
8. OPTIONAL PARTS................................................................................................................................... 25
8-1. Optional parts line up for the Indoor unit.......................................................................................... 25
8-2. Filter box .......................................................................................................................................... 25
0000004790.BOOK 1 ページ ２０１８年５月８日 火曜日 午後３時２７分
MEES17K198
PEFY-WP-VMA-E
2
1. SPECIFICATIONS Ceiling concealed (Medium static pressure type)
I.Ceiling concealed (Medium static pressure type)1. SPECIFICATIONS
Model PEFY-WP20VMA-E PEFY-WP25VMA-E PEFY-WP32VMA-E PEFY-WP40VMA-E
Power source 1-phase 220-230-240 V 50/
60 Hz
1-phase 220-230-240 V 50/
60 Hz
1-phase 220-230-240 V 50/
60 Hz
1-phase 220-230-240 V 50/
60 Hz
Cooling capacity *1 kW 2.2 2.8 3.6 4.5
(Nominal) *1 kcal/h 1,900 2,400 3,100 3,900
*1 BTU/h 7,500 9,600 12,300 15,400
*2 Power input kW 0.07 0.09 0.11 0.14
*2 Current input A 0.55 0.64 0.74 1.15
Heating capacity *3 kW 2.5 3.2 4.0 5.0
(Nominal) *3 kcal/h 2,200 2,800 3,400 4,300
*3 BTU/h 8,500 10,900 13,600 17,100
*2 Power input kW 0.05 0.07 0.09 0.12
*2 Current input A 0.44 0.53 0.63 1.04
External finish Galvanized steel plate Galvanized steel plate Galvanized steel plate Galvanized steel plate
External dimension HxWxD mm 250 x 700 x 732 250 x 900 x 732 250 x 900 x 732 250 x 1,100 x 732
in. 9-7/8 x 27-9/16 x 28-7/8 9-7/8 x 35-7/16 x 28-7/8 9-7/8 x 35-7/16 x 28-7/8 9-7/8 x 43-5/16 x 28-7/8
Net weight kg (lbs) 21 (47) 26 (58) 26 (58) 31 (69)
Heat exchanger Cross fin (Aluminum fin and
copper tube)
Cross fin (Aluminum fin and
copper tube)
Cross fin (Aluminum fin and
copper tube)
Cross fin (Aluminum fin and
copper tube)
Water Volume L 0.7 1.0 1.0 1.8
FAN Type x Quantity Sirocco fan x 1 Sirocco fan x 1 Sirocco fan x 1 Sirocco fan x 2
*4 External static press. Pa <35> - 50 - <70> - <100> -
<150>
<35> - 50 - <70> - <100> -
<150>
<35> - 50 - <70> - <100> -
<150>
<35> - 50 - <70> - <100> -
<150>
mmH2O<3.6> - 5.1 - <7.1> - <10.2> -
<15.3>
<3.6> - 5.1 - <7.1> - <10.2> -
<15.3>
<3.6> - 5.1 - <7.1> - <10.2> -
<15.3>
<3.6> - 5.1 - <7.1> - <10.2> -
<15.3>
Motor Type DC motor DC motor DC motor DC motor
Motor output kW 0.085 0.085 0.085 0.121
Driving mechanism Direct-driven by motor Direct-driven by motor Direct-driven by motor Direct-driven by motor
Air flow rate (Low-Mid-High) (Low-Mid-High) (Low-Mid-High) (Low-Mid-High)
m3/min 7.5 - 9.0 - 10.5 10.0 - 12.0 - 14.0 12.0 - 14.5 - 17.0 14.5 - 18.0 - 21.0
L/s 125 - 150 - 175 167 - 200 - 233 200 - 242 - 283 242 - 300 - 350
cfm 265 - 318 - 371 353 - 424 - 494 424 - 512 - 600 512 - 636 - 742
Sound pressure level (measured in anechoic room) (Low-Mid-High) (Low-Mid-High) (Low-Mid-High) (Low-Mid-High)
*2 dB <A> 23-26-29 23-27-30 25-29-32 26-29-34
Insulation material EPS, Polyethylene foam,
Urethane foam
EPS, Polyethylene foam,
Urethane foam
EPS, Polyethylene foam,
Urethane foam
EPS, Polyethylene foam,
Urethane foam
Air filter PP honeycomb fabric. PP honeycomb fabric. PP honeycomb fabric. PP honeycomb fabric.
Protection device Fuse Fuse Fuse Fuse
Refrigerant control device - - - -
Connectable outdoor unit/HBC controller
HYBRID CITY MULTI/
CMB-WP-V-GA1, CMB-WP-
V-GB1, CMB-WM-V-AA,
CMB-WM-V-AB
HYBRID CITY MULTI/
CMB-WP-V-GA1, CMB-WP-
V-GB1, CMB-WM-V-AA,
CMB-WM-V-AB
HYBRID CITY MULTI/
CMB-WP-V-GA1, CMB-WP-
V-GB1, CMB-WM-V-AA,
CMB-WM-V-AB
HYBRID CITY MULTI/
CMB-WP-V-GA1, CMB-WP-
V-GB1, CMB-WM-V-AA,
CMB-WM-V-AB
Diameter of water pipe Inlet in. Rc 3/4 screw Rc 3/4 screw Rc 3/4 screw Rc 3/4 screw
*5 *6 Outlet in. Rc 3/4 screw Rc 3/4 screw Rc 3/4 screw Rc 3/4 screw
Field drain pipe size mm (in.) O.D.32 (1-1/4) O.D.32 (1-1/4) O.D.32 (1-1/4) O.D.32 (1-1/4)
Drawing External KD94L918X01 KD94L918X01 KD94L918X01 KD94L918X01
Wiring KD94L919X01 KD94L919X01 KD94L919X01 KD94L919X01
Refrigerant cycle - - - -
Standard attachment Document Installation Manual, Instruc-
tion Book
Installation Manual, Instruc-
tion Book
Installation Manual, Instruc-
tion Book
Installation Manual, Instruc-
tion Book
Accessory
Insulation pipe for water pipe,
Washer, Drain hose, Tie
band
Insulation pipe for water pipe,
Washer, Drain hose, Tie
band
Insulation pipe for water pipe,
Washer, Drain hose, Tie
band
Insulation pipe for water pipe,
Washer, Drain hose, Tie
band
Optional parts Filter box PAC-KE91TB-E PAC-KE92TB-E PAC-KE92TB-E PAC-KE93TB-E
Remarks * Details on foundation work, duct work, insulation work, electrical wiring, power source switch, and other items shall be
referred to the Installation Manual.
* Due to continuing improvement, above specifications may be subject to change without notice.
Notes: Unit converter
1.Nominal cooling conditions
Indoor: 27°CD.B./19°CW.B. (81°CD.B./66°CW.B.), Outdoor: 35°CD.B. (95°CD.B.)
Pipe length: 7.5 m (24-9/16 ft.), Level difference: 0 m (0 ft.)
2.The values are measured at the factory setting of external static pressure.
3.Nominal heating conditions
Indoor: 20°CD.B. (68°CD.B.), Outdoor: 7°CD.B./6°CW.B. (45°CD.B./43°CW.B.)
Pipe length: 7.5 m (24-9/16 ft.), Level difference: 0 m (0 ft.)
4.The factory setting of external static pressure is shown without < >.
Refer to "Fan characteristics curves", according to the external static pressure, in DATA BOOK for the usable
range of air flow rate.
5.Be sure to install a valve on the water outlet.
6.Install a strainer (40 mesh or more) on the pipe next to the valve to remove the foreign matters.
7.Please group units that operate on 1 branch.
kcal/h =kW x 860
BTU/h =kW x 3,412
cfm =m3/min x 35.31
lbs =kg / 0.4536
*Above specification data is
subject to rounding variation.
0000004790.BOOK 2 ページ ２０１８年５月８日 火曜日 午後３時２７分
MEES17K198
PEFY-WP-VMA-E
3
1. SPECIFICATIONS Ceiling concealed (Medium static pressure type)
Model PEFY-WP50VMA-E PEFY-WP63VMA-E PEFY-WP71VMA-E PEFY-WP80VMA-E
Power source 1-phase 220-230-240 V 50/
60 Hz
1-phase 220-230-240 V 50/
60 Hz
1-phase 220-230-240 V 50/
60 Hz
1-phase 220-230-240 V 50/
60 Hz
Cooling capacity *1 kW 5.6 7.1 8.0 9.0
(Nominal) *1 kcal/h 4,800 6,100 6,900 7,700
*1 BTU/h 19,100 24,200 27,300 30,700
*2 Power input kW 0.14 0.14 0.24 0.24
*2 Current input A 1.15 1.15 1.47 1.47
Heating capacity *3 kW 6.3 8.0 9.0 10.0
(Nominal) *3 kcal/h 5,400 6,900 7,700 8,600
*3 BTU/h 21,500 27,300 30,700 34,100
*2 Power input kW 0.12 0.12 0.22 0.22
*2 Current input A 1.04 1.04 1.36 1.36
External finish Galvanized steel plate Galvanized steel plate Galvanized steel plate Galvanized steel plate
External dimension HxWxD mm 250 x 1,100 x 732 250 x 1,100 x 732 250 x 1,400 x 732 250 x 1,400 x 732
in. 9-7/8 x 43-5/16 x 28-7/8 9-7/8 x 43-5/16 x 28-7/8 9-7/8 x 55-1/8 x 28-7/8 9-7/8 x 55-1/8 x 28-7/8
Net weight kg (lbs) 31 (69) 31 (69) 40 (89) 40 (89)
Heat exchanger Cross fin (Aluminum fin and
copper tube)
Cross fin (Aluminum fin and
copper tube)
Cross fin (Aluminum fin and
copper tube)
Cross fin (Aluminum fin and
copper tube)
Water Volume L 1.8 2.0 2.6 2.6
FAN Type x Quantity Sirocco fan x 2 Sirocco fan x 2 Sirocco fan x 2 Sirocco fan x 2
*4 External static press. Pa <35> - 50 - <70> - <100> -
<150>
<35> - 50 - <70> - <100> -
<150>
<35> - 50 - <70> - <100> -
<150>
<35> - 50 - <70> - <100> -
<150>
mmH2O<3.6> - 5.1 - <7.1> - <10.2> -
<15.3>
<3.6> - 5.1 - <7.1> - <10.2> -
<15.3>
<3.6> - 5.1 - <7.1> - <10.2> -
<15.3>
<3.6> - 5.1 - <7.1> - <10.2> -
<15.3>
Motor Type DC motor DC motor DC motor DC motor
Motor output kW 0.121 0.121 0.244 0.244
Driving mechanism Direct-driven by motor Direct-driven by motor Direct-driven by motor Direct-driven by motor
Air flow rate (Low-Mid-High) (Low-Mid-High) (Low-Mid-High) (Low-Mid-High)
m3/min 14.5 - 18.0 - 21.0 14.5 - 18.0 - 21.0 23.0 - 28.0 - 33.0 23.0 - 28.0 - 33.0
L/s 242 - 300 - 350 242 - 300 - 350 383 - 467 - 550 383 - 467 - 550
cfm 512 - 636 - 742 512 - 636 - 742 812 - 989 - 1,165 812 - 989 - 1,165
Sound pressure level (measured in anechoic room) (Low-Mid-High) (Low-Mid-High) (Low-Mid-High) (Low-Mid-High)
*2 dB <A> 26-29-34 26-29-34 28-33-37 28-33-37
Insulation material EPS, Polyethylene foam,
Urethane foam
EPS, Polyethylene foam,
Urethane foam
EPS, Polyethylene foam,
Urethane foam
EPS, Polyethylene foam,
Urethane foam
Air filter PP honeycomb fabric. PP honeycomb fabric. PP honeycomb fabric. PP honeycomb fabric.
Protection device Fuse Fuse Fuse Fuse
Refrigerant control device - - - -
Connectable outdoor unit/HBC controller
HYBRID CITY MULTI/
CMB-WP-V-GA1, CMB-WP-
V-GB1, CMB-WM-V-AA,
CMB-WM-V-AB
HYBRID CITY MULTI/
CMB-WP-V-GA1, CMB-WP-
V-GB1, CMB-WM-V-AA,
CMB-WM-V-AB
HYBRID CITY MULTI/
CMB-WP-V-GA1, CMB-WP-
V-GB1, CMB-WM-V-AA,
CMB-WM-V-AB
HYBRID CITY MULTI/
CMB-WP-V-GA1, CMB-WP-
V-GB1, CMB-WM-V-AA,
CMB-WM-V-AB
Diameter of water pipe Inlet in. Rc 3/4 screw Rc 1-1/4 screw Rc 1-1/4 screw Rc 1-1/4 screw
*5 *6 Outlet in. Rc 3/4 screw Rc 1-1/4 screw Rc 1-1/4 screw Rc 1-1/4 screw
Field drain pipe size mm (in.) O.D.32 (1-1/4) O.D.32 (1-1/4) O.D.32 (1-1/4) O.D.32 (1-1/4)
Drawing External KD94L918X01 KL94G001X01 KL94G001X01 KL94G001X01
Wiring KD94L919X01 KD94L919X01 KD94L919X01 KD94L919X01
Refrigerant cycle - - - -
Standard attachment Document Installation Manual, Instruc-
tion Book
Installation Manual, Instruc-
tion Book
Installation Manual, Instruc-
tion Book
Installation Manual, Instruc-
tion Book
Accessory
Insulation pipe for water pipe,
Washer, Drain hose, Tie
band
Insulation pipe for water pipe,
Washer, Drain hose, Tie
band
Insulation pipe for water pipe,
Washer, Drain hose, Tie
band
Insulation pipe for water pipe,
Washer, Drain hose, Tie
band
Optional parts Filter box PAC-KE93TB-E PAC-KE93TB-E PAC-KE94TB-E PAC-KE94TB-E
Remarks * Details on foundation work, duct work, insulation work, electrical wiring, power source switch, and other items shall be
referred to the Installation Manual.
* Due to continuing improvement, above specifications may be subject to change without notice.
Notes : Unit converter
1.Nominal cooling conditions
Indoor: 27°CD.B./19°CW.B. (81°CD.B./66°CW.B.), Outdoor: 35°CD.B. (95°CD.B.)
Pipe length: 7.5 m (24-9/16 ft.), Level difference: 0 m (0 ft.)
2.The values are measured at the factory setting of external static pressure.
3.Nominal heating conditions
Indoor: 20°CD.B. (68°CD.B.), Outdoor: 7°CD.B./6°CW.B. (45°CD.B./43°CW.B.)
Pipe length: 7.5 m (24-9/16 ft.), Level difference: 0 m (0 ft.)
4.The factory setting of external static pressure is shown without < >.
Refer to "Fan characteristics curves", according to the external static pressure, in DATA BOOK for the usable
range of air flow rate.
5.Be sure to install a valve on the water outlet.
6.Install a strainer (40 mesh or more) on the pipe next to the valve to remove the foreign matters.
7.Please group units that operate on 1 branch.
kcal/h =kW x 860
BTU/h =kW x 3,412
cfm =m3/min x 35.31
lbs =kg / 0.4536
*Above specification data is
subject to rounding variation.
0000004790.BOOK 3 ページ ２０１８年５月８日 火曜日 午後３時２７分
MEES17K198
PEFY-WP-VMA-E
4
1. SPECIFICATIONS Ceiling concealed (Medium static pressure type)
Model PEFY-WP100VMA-E PEFY-WP125VMA-E
Power source 1-phase 220-230-240 V 50/
60 Hz
1-phase 220-230-240 V 50/
60 Hz
Cooling capacity *1 kW 11.2 14.0
(Nominal) *1 kcal/h 9,600 12,000
*1 BTU/h 38,200 47,800
*2 Power input kW 0.24 0.36
*2 Current input A 1.47 2.21
Heating capacity *3 kW 12.5 16.0
(Nominal) *3 kcal/h 10,800 13,800
*3 BTU/h 42,700 54,600
*2 Power input kW 0.22 0.34
*2 Current input A 1.36 2.10
External finish Galvanized steel plate Galvanized steel plate
External dimension HxWxD mm 250 x 1,400 x 732 250 x 1,600 x 732
in. 9-7/8 x 55-1/8 x 28-7/8 9-7/8 x 63 x 28-7/8
Net weight kg (lbs) 40 (89) 42 (93)
Heat exchanger Cross fin (Aluminum fin and
copper tube)
Cross fin (Aluminum fin and
copper tube)
Water Volume L 2.6 3.0
FAN Type x Quantity Sirocco fan x 2 Sirocco fan x 2
*4 External static press. Pa <35> - 50 - <70> - <100> -
<150>
<35> - 50 - <70> - <100> -
<150>
mmH2O<3.6> - 5.1 - <7.1> - <10.2> -
<15.3>
<3.6> - 5.1 - <7.1> - <10.2> -
<15.3>
Motor Type DC motor DC motor
Motor output kW 0.244 0.244
Driving mechanism Direct-driven by motor Direct-driven by motor
Air flow rate (Low-Mid-High) (Low-Mid-High)
m3/min 23.0 - 28.0 - 33.0 29.5 - 35.5 - 42.0
L/s 383 - 467 - 550 492 - 592 - 700
cfm 812 - 989 - 1,165 1,042 - 1,254 - 1,483
Sound pressure level (measured in anechoic room) (Low-Mid-High) (Low-Mid-High)
*2 dB <A> 28-33-37 32-36-40
Insulation material EPS, Polyethylene foam,
Urethane foam
EPS, Polyethylene foam,
Urethane foam
Air filter PP honeycomb fabric. PP honeycomb fabric.
Protection device Fuse Fuse
Refrigerant control device - -
Connectable outdoor unit/HBC controller
HYBRID CITY MULTI/
CMB-WP-V-GA1, CMB-WP-
V-GB1, CMB-WM-V-AA,
CMB-WM-V-AB
HYBRID CITY MULTI/
CMB-WP-V-GA1, CMB-WP-
V-GB1, CMB-WM-V-AA,
CMB-WM-V-AB
Diameter of water pipe Inlet in. Rc 1-1/4 screw Rc 1-1/4 screw
*5 *6 Outlet in. Rc 1-1/4 screw Rc 1-1/4 screw
Field drain pipe size mm (in.) O.D.32 (1-1/4) O.D.32 (1-1/4)
Drawing External KL94G001X01 KL94G001X01
Wiring KD94L919X01 KD94L919X01
Refrigerant cycle - -
Standard attachment Document Installation Manual, Instruc-
tion Book
Installation Manual, Instruc-
tion Book
Accessory
Insulation pipe for water pipe,
Washer, Drain hose, Tie
band
Insulation pipe for water pipe,
Washer, Drain hose, Tie
band
Optional parts Filter box PAC-KE94TB-E PAC-KE95TB-E
Remarks * Details on foundation work, duct work, insulation work, electrical wiring, power source switch, and other items shall be
referred to the Installation Manual.
* Due to continuing improvement, above specifications may be subject to change without notice.
Notes : Unit converter
1.Nominal cooling conditions
Indoor: 27°CD.B./19°CW.B. (81°CD.B./66°CW.B.), Outdoor: 35°CD.B. (95°CD.B.)
Pipe length: 7.5 m (24-9/16 ft.), Level difference: 0 m (0 ft.)
2.The values are measured at the factory setting of external static pressure.
3.Nominal heating conditions
Indoor: 20°CD.B. (68°CD.B.), Outdoor: 7°CD.B./6°CW.B. (45°CD.B./43°CW.B.)
Pipe length: 7.5 m (24-9/16 ft.), Level difference: 0 m (0 ft.)
4.The factory setting of external static pressure is shown without < >.
Refer to "Fan characteristics curves", according to the external static pressure, in DATA BOOK for the usable
range of air flow rate.
5.Be sure to install a valve on the water outlet.
6.Install a strainer (40 mesh or more) on the pipe next to the valve to remove the foreign matters.
7.Please group units that operate on 1 branch.
kcal/h =kW x 860
BTU/h =kW x 3,412
cfm =m3/min x 35.31
lbs =kg / 0.4536
*Above specification data is
subject to rounding variation.
0000004790.BOOK 4 ページ ２０１８年５月８日 火曜日 午後３時２７分
MEES17K198
PEFY-WP-VMA-E
5
2. EXTERNAL DIMENSIONS Ceiling concealed (Medium static pressure type)
2. EXTERNAL DIMENSIONS
Control box
2×2-ø2.9
Air
outlet Air
inlet
2×E-ø2.9
Water pipe(To HBC unit)
Rc3/4 screw
2
1Water pipe(From HBC unit)
Rc3/4 screw
Drain pump
Air Filter
Terminal block(Power source)
Terminal block(Transmission)
Drain pipe(O.D.ø32)
(Spontaneous draining)
Drain pipe
(O.D.ø32)
Suspension bolt hole
4-14×30 Slot
Note 1.Use M10 screw for the Suspension bolt (field supply).
2.Keep the service space for the maintenance at the bottom.
3.This chart indicates for PEFY-WP40·50VMA-E models,
which have 2 fans.PEFY-WP20·25·32VMA-E models
have 1 fan.
4.In case of the inlet duct is used,remove the air filter
(supply with the unit),then install the filter
(field supply) at suction side.
Rc3/4 screw
Water pipe
(To HBC unit)
Water pipe
(From HBC unit)
7
Model A
660800
1200
700 754
900 954 860 9
E
11
D
1060
C
1100
B
1154PEFY-WP40,50VMA-E
PEFY-WP25,32VMA-E
PEFY-WP20VMA-E
1000
1000
F
858800
G
658
1058
600
Outlet air
side view Top view Inlet air
side view
Piping
side view
Top
Bottom
91 64
87117
20
64
40
250
40
D (Duct)
21018
G21
57
10
A
B(Suspension bolt pitch)
C
23
643(Suspension bolt pitch)
178(Duct) 23
10
238
32 700
732
356
100
41
217
100
30 100×(E-1)=F
58
15
Unit: mm
PEFY-WP20, 25, 32, 40, 50VMA-E
0000004790.BOOK 5 ページ ２０１８年５月８日 火曜日 午後３時２７分
MEES17K198
PEFY-WP-VMA-E
6
2. EXTERNAL DIMENSIONS Ceiling concealed (Medium static pressure type)
PEFY-WP20, 25, 32, 40, 50VMA-E
Unit: mm
N-ø2.9
(Actual length)
<accessory>
Drain hose (I.D.ø32)
Model H RQS
PEFY-WP20VMA-E 44 50~150 800 1300
K
300
PEFY-WP25,32VMA-E 1000150~250 150054
P
700
900
1100
N
10
10
10
M
780
990
J
150
260
330PEFY-WP40,50VMA-E 1200250~350 1700
L
4
449
Maintenance access space
Maintenance access space Maintenance access space
Access door 3 Access door 4
Access door 2
(450×450)
Ceiling
Ceiling
A
B
Fig.3
Fig.4
Fig.2
Fig.1
Fig.5
(Viewed from the direction of the arrow A)
(Viewed from the direction of the arrow B) (Viewed from the direction
of the arrow B)
Intake air
Intake air
Supply air
Supply air
Access door 2(450×450)
Access door 3
Ceiling beam
Ceiling beam
Bottom of indoor unit
Bottom of
indoor unit
Bottom of
indoor unit
100~200
100~200
Access door 1
(450×450)
Access door 1
(450×450)
Electric box
Electric box
Electric box
Electric box
Electric box
[Maintenance access space]
Secure enough access space to allow for the maintenance, inspection, and replacement of the motor, fan, drain pump, heat exchanger,
and electric box in one of the following ways.
Select an installation site for the indoor unit so that its maintenance access space will not be obstructed by beams or other objects.
(1)When a space of 300mm or more is available below the unit between the unit and the ceiling. (Fig.1)
·Create access door 1 and 2 (450×450mm each) as shown in Fig.2.
(Access door 2 is not required if enough space is available below the unit for a maintenance worker to work in.)
(2)When a space of less than 300mm is available below the unit between the unit and the ceiling.
(At least 20mm of space should be left below the unit as shown in Fig.3.)
·Create access door 1 diagonally below the electric box and access door 3 below the unit as shown in Fig.4.
or
·Create access door 4 below the electric box and the unit as shown in Fig.5.
112 11112
H
JK
6H
J
J×(L-1)=M
65 0
-10
Less than 300mm
Less than 700mm
700
700
475
Min.10mm
475
Min.10mm
450
450
50
Q
50~150
450
Min.300mm
450
450
450
50
50
Min.300mm50 700
777 777
R
S
P
P
P
Min.300mm
Min.20mm
0000004790.BOOK 6 ページ ２０１８年５月８日 火曜日 午後３時２７分
MEES17K198
PEFY-WP-VMA-E
7
2. EXTERNAL DIMENSIONS Ceiling concealed (Medium static pressure type)
2
1
Control box
2×2-ø2.9
Air
outlet Air
inlet
2×E-ø2.9
Water pipe(To HBC unit)
Rc1-1/4 screw
Water pipe(From HBC unit)
Rc1-1/4 screw
Drain pump
Air Filter
Terminal block(Power source)
Terminal block(Transmission)
Drain pipe(O.D.ø32)
(Spontaneous draining)
Drain pipe
(O.D.ø32)
Suspension bolt hole
4-14×30 Slot
Note 1. Use an M10 screw for the Suspension bolt (field supply).
2. Keep the service space for the maintenance at the bottom.
3. In case of the inlet duct is used,remove the air filter
(supply with the unit),then install the filter
(field supply) at suction side.
Rc1-1/4 screw
Water pipe
(To HBC unit)
Water pipe
(From HBC unit)
Model A
1200
E
11
D
1060
C
1100
B
1154
PEFY-WP63VMA-E
1000
FG
1058
Outlet air
side view Top view Inlet air
side view
Piping
side view
Top
Bottom
1500 1413601400 1454
PEFY-WP71,80,100VMA-E
1300 1358
1700 1615601600 1654
PEFY-WP125VMA-E
1500 1558
60 69
69126
20
64
40
250
40
D (Duct)
210
18
G21
57
10
A
B(Suspension
bolt pitch)
C
23
643(Suspension bolt pitch)
178(Duct) 23
10
238
32 700
732
356
100
41
217
100
30 100×(E-1)=F
58
15
Unit: mm
PEFY-WP63, 71, 80, 100, 125VMA-E
0000004790.BOOK 7 ページ ２０１８年５月８日 火曜日 午後３時２７分
MEES17K198
PEFY-WP-VMA-E
8
2. EXTERNAL DIMENSIONS Ceiling concealed (Medium static pressure type)
Unit: mm
PEFY-WP63, 71, 80, 100, 125VMA-E
Ceiling
Ceiling
A
B
Fig.3
Fig.1
Intake air
Intake air
Supply air
Supply air
Access door 2(450×450)
Access door 3
Ceiling beam
Ceiling beam
Electric box
Electric box
Min.10mm
Min.10mm
Min.20mm
[Maintenance access space]
Secure enough access space to allow for the maintenance, inspection, and replacement of the motor, fan, drain pump, heat exchanger,
and electric box in one of the following ways.
Select an installation site for the indoor unit so that its maintenance access space will not be obstructed by beams or other objects.
(1) When a space of 300mm or more is available below the unit between the unit and the ceiling. (Fig.1)
·Create access door 1 and 2 (450×450mm each) as shown in Fig.2.
(Access door 2 is not required if enough space is available below the unit for a maintenance worker to work in.)
(2) When a space of less than 300mm is available below the unit between the unit and the ceiling.
(At least 20mm of space should be left below the unit as shown in Fig.3.)
·Create access door 1 diagonally below the electric box and access door 3 below the unit as shown in Fig.4.
or
·Create access door 4 below the electric box and the unit as shown in Fig.5.
M-ø2.9
(Actual length)
<accessory>
Drain hose (I.D.ø32)
JP
1100
N
10
M
990
L
330
K
PEFY-WP63VMA-E
Model HR
1200
Q
250~350 17004
49
1400121280320
PEFY-WP71,80,100VMA-E
1500
400~500 20005
54
1600121480370
PEFY-WP125VMA-E
1700
500~600 22005
54
Maintenance access space
Maintenance access space Maintenance access space
Access door 3 Access door 4
Access door 2
(450×450)
Fig.4
Fig.2
Fig.5
(Viewed from the direction of the arrow A)
(Viewed from the direction of the arrow B)
(Viewed from the direction
of the arrow B)
Bottom of indoor unit
Bottom of
indoor unit
Bottom of
indoor unit
100~200
100~200
Access door 1
(450×450)
Access door 1
(450×450)
Electric box
Electric box
Electric box
112 11112
H
JJ
6H
J
J×(K-1)=L
65
0
-10
Less than 300mm
Less than 700mm
700
700
475
475
450
450
50
P
50~150
450
Min.300mm
450
450
450
50
50
Min.300mm
50 700
777 777
Q
R
N
N
N
Min.300mm
0000004790.BOOK 8 ページ ２０１８年５月８日 火曜日 午後３時２７分
MEES17K198
PEFY-WP-VMA-E
9
3. CENTER OF GRAVITY Ceiling concealed (Medium static pressure type)
3. CENTER OF GRAVITY
Model name
PEFY-WP20VMA-E
PEFY-WP25VMA-E
PEFY-WP32VMA-E
W
643 [25 - 6/16]
643 [25 - 6/16]
643 [25 - 6/16]
L
754 [29 - 11/16]
954 [37 - 9/16]
954 [37 - 9/16]
X
330 [13]
340 [13 - 7/16]
340 [13 - 7/16]
Y
300 [11 -13/16]
375 [14 -13/16]
375 [14 -13/16]
Z
130 [5 -2/16]
130 [5 -2/16]
130 [5 -2/16]
PEFY-WP40VMA-E
PEFY-WP50VMA-E
643 [25 - 6/16] 1154 [45 - 7/16] 325 [12 - 13/16] 525 [20 -11/16] 130 [5 -2/16]
643 [25 - 6/16] 1154 [45 - 7/16] 325 [12 - 13/16] 525 [20 -11/16] 130 [5 -2/16]
PEFY-WP63VMA-E 643 [25 - 6/16] 1154 [45 - 7/16] 325 [12 - 13/16] 525 [20 -11/16] 130 [5 -2/16]
PEFY-WP71VMA-E 643 [25 - 6/16] 1454 [57 - 4/16] 330 [13] 675 [26 -10/16] 130 [5 -2/16]
PEFY-WP80VMA-E 643 [25 - 6/16] 1454 [57 - 4/16] 330 [13] 675 [26 -10/16] 130 [5 -2/16]
PEFY-WP100VMA-E 643 [25 - 6/16] 1454 [57 - 4/16] 330 [13] 675 [26 -10/16] 130 [5 -2/16]
PEFY-WP125VMA-E 643 [25 - 6/16] 1654 [65 - 2/16] 332 [13 - 2/16] 725 [28 -9/16] 130 [5 -2/16]
A : Center of gravity
YX
LW
A
Z
PEFY-WP20, 25, 32, 40, 50, 63, 71, 80, 100, 125VMA-E
(mm)[in]
0000004790.BOOK 9 ページ ２０１８年５月８日 火曜日 午後３時２７分
MEES17K198
PEFY-WP-VMA-E
10
4. ELECTRICAL WIRING DIAGRAMS Ceiling concealed (Medium static pressure type)
4. ELECTRICAL WIRING DIAGRAMS
INSIDE SECTION OF CONTROL BOX
Drainpump Fan motor
Thermistor (piping temp.detection/water in)
Thermistor (piping temp.detection/water out)
Switch (for mode selection)
Switch (for capacity code)
Switch (10ths digit address set)
Switch (for static pressure selection)
Switch (for static pressure selection)
Switch (BRANCH No.)
Switch (for mode selection)
Switch (for model selection)
Switch (for mode selection)
Connector (emergency operation)
Transmission terminal block
Fuse AC250V 6.3A
Arrester
Aux. relay
Aux. relay
AC reactor(Power factor improvement)
Varistor
TB15
F01
DSA
X01
X10
ACL
ZNR01,02
TH21
LED1
Thermistor (inlet air temp.detection)
LED(Power supply)
LED(Remote controller supply)
TH23
TH22
LED2
NAMESYMBOLSYMBOL
I.B.
P. B .
Indoor controller board
Power supply board
Switch (1s digit address set)
SW2(I.B.)
SW3(I.B.)
SW11(I.B.)
SW12(I.B.)
SWA(I.B.)
SW14(I.B.)
SWC(I.B.)
SW1(I.B.)
SW4(I.B.)
SW5(I.B.)
SWE(I.B.)
TB2
TB5
Transmission terminal block
Power source terminal block
SYMBOL EXPLANATION
NAME
CN27
CN41
CN51
CN52
CN90
CN2A
CN105
FS
Connector (HA terminal-A)
Connector (Centrally control)
Connector (Remote indication)
Connector (Wireless)
Connector (0-10V Analog input)
Connector (IT terminal)
Float switch
SYMBOL NAME
Connector (Damper)
CN32
Connector (Remote switch)
NOTE:Symbols used in wiring diagram above are,
:Connector
:Terminal
(Heavy dotted line):Field wiring
I.B.
P. B .
TH23 TH21
TH22
t° t° t°
FS
(Blue)
(Blue)
(Blue)
(Blue)
(Blue)
(Black)
(Green)
(Red)
CN44 (Red)
(Red)
(Red)
CN27
ON
ZNR01
CNP
CND
ZNR02
DSA
OFF
F01
SW5
SWC
SW14
SW12
SW11
SW4
SWA
ACL
SW1
SW2
SW3
CNXC1
X01 X10
CNXA1CNXB1 CNMF
CNXC2
CN2A
CN2M
CNXB2 CNXA2
CN51
CN4F CN41
CN105
CN90
CN20
SWE
CN52
CN32
CN3A
TB5
LED2
LED1
DC280-340V
Rectifier circuit
U
U
AC220-240V
50,60Hz
N
L
TB15
M2
2
TB2
M1
1
S(SHIELD)
MMS
3~
1111
1
11
22752
5
33445 6 4
3
22
2
1
3
1
3
232
3
12
11
3431
454
1
2
41
2
2
1
1~
TO MA REMOTE
CONTROLLER
TO OUTDOOR UNIT
HBC CONTROLLER
REMOTE CONTROLLER
POWER SUPPLY
PULL BOX
BREAKER (16A)
FUSE (16A)
TO NEXT INDOOR UNIT
PEFY-WP20, 25, 32, 40, 50, 63, 71, 80, 100, 125VMA-E
0000004790.BOOK 10 ページ ２０１８年５月８日 火曜日 午後３時２７分
MEES17K198
PEFY-WP-VMA-E
11
5. SOUND LEVELS Ceiling concealed (Medium static pressure type)
5. SOUND LEVELS
5-1. Sound levels
5-1-1. Sound levels (Measured condition: With 1m air inlet duct and 2m air outlet duct)
5-1-2. Sound levels (Measured condition: With 2m air inlet duct and 2m air outlet duct)
Sound level at anechoic room : Low-Mid-High
Model Sound level dB(A)
35Pa 50Pa 70Pa 100Pa 150Pa
PEFY-WP20VMA-E 28-30-34 28-30-34 29-32-36 29-33-37 31-35-40
PEFY-WP25VMA-E 28-30-34 28-30-34 29-32-36 29-33-37 32-36-40
PEFY-WP32VMA-E 28-31-35 28-32-35 29-33-37 30-34-38 32-37-41
PEFY-WP40VMA-E 30-33-37 30-34-38 31-36-39 33-37-41 36-41-44
PEFY-WP50VMA-E 30-33-37 30-34-38 31-36-39 33-37-41 36-41-44
PEFY-WP63VMA-E 30-33-37 30-34-38 31-36-39 33-37-41 36-41-44
PEFY-WP71VMA-E 31-36-40 32-37-41 33-38-42 35-39-43 37-42-45
PEFY-WP80VMA-E 31-36-40 32-37-41 33-38-42 35-39-43 37-42-45
PEFY-WP100VMA-E 31-36-40 32-37-41 33-38-42 35-39-43 37-42-45
PEFY-WP125VMA-E 36-41-45 36-41-45 38-42-46 39-43-47 40-45-48
*Measured in anechoic room.
PEFY-WP-VMA-E
2m 1m
Aux. duct
1.5m
Measurement location
Sound level at anechoic room : Low-Mid-High
Model Sound level dB(A)
35Pa 50Pa 70Pa 100Pa 150Pa
PEFY-WP20VMA-E 23-25-28 23-26-29 24-27-30 25-28-32 28-32-36
PEFY-WP25VMA-E 23-26-29 23-27-30 24-28-31 26-29-33 29-33-37
PEFY-WP32VMA-E 24-28-31 25-29-32 26-30-33 27-31-34 29-34-38
PEFY-WP40VMA-E 26-29-33 26-29-34 26-30-35 29-33-37 32-37-41
PEFY-WP50VMA-E 26-29-33 26-29-34 26-30-35 29-33-37 32-37-41
PEFY-WP63VMA-E 26-29-33 26-29-34 26-30-35 29-33-37 32-37-41
PEFY-WP71VMA-E 28-32-36 28-33-37 30-35-39 31-36-40 33-38-43
PEFY-WP80VMA-E 28-32-36 28-33-37 30-35-39 31-36-40 33-38-43
PEFY-WP100VMA-E 28-32-36 28-33-37 30-35-39 31-36-40 33-38-43
PEFY-WP125VMA-E 31-35-40 33-37-42 34-38-43 35-38-44 37-41-45
Measurement location
Aux. duct
*Measured in anechoic room.
PEFY-WP-VMA-E
2m 2m
1.5m
0000004790.BOOK 11 ページ ２０１８年５月８日 火曜日 午後３時２７分
MEES17K198
PEFY-WP-VMA-E
12
5. SOUND LEVELS Ceiling concealed (Medium static pressure type)
5-2. NC curves
5-2-1. NC curves (Sound level measured condition : With 1m air inlet duct and 2m air outlet duct)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP20VMA-E
External Static Pressure: 35Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP20VMA-E
External Static Pressure: 50Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP20VMA-E
External Static Pressure: 70Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP20VMA-E
External Static Pressure: 100Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP20VMA-E
External Static Pressure: 150Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP25VMA-E
External Static Pressure: 35Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP25VMA-E
External Static Pressure: 50Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP25VMA-E
External Static Pressure: 70Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP25VMA-E
External Static Pressure: 100Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP25VMA-E
External Static Pressure: 150Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP32VMA-E
External Static Pressure: 35Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP32VMA-E
External Static Pressure: 50Pa
Power Source: 220-240V(50/60Hz)
0000004790.BOOK 12 ページ ２０１８年５月８日 火曜日 午後３時２７分
MEES17K198
PEFY-WP-VMA-E
13
5. SOUND LEVELS Ceiling concealed (Medium static pressure type)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP32VMA-E
External Static Pressure: 70Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP32VMA-E
External Static Pressure: 100Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP32VMA-E
External Static Pressure: 150Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP40,50,63VMA-E
External Static Pressure: 35Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP40,50,63VMA-E
External Static Pressure: 50Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP40,50,63VMA-E
External Static Pressure: 70Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP40,50,63VMA-E
External Static Pressure: 100Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP40,50,63VMA-E
External Static Pressure: 150Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP71,80,100VMA-E
External Static Pressure: 35Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP71,80,100VMA-E
External Static Pressure: 50Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP71,80,100VMA-E
External Static Pressure: 70Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP71,80,100VMA-E
External Static Pressure: 100Pa
Power Source: 220-240V(50/60Hz)
0000004790.BOOK 13 ページ ２０１８年５月８日 火曜日 午後３時２７分
MEES17K198
PEFY-WP-VMA-E
14
5. SOUND LEVELS Ceiling concealed (Medium static pressure type)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP71,80,100VMA-E
External Static Pressure: 150Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP125VMA-E
External Static Pressure: 35Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP125VMA-E
External Static Pressure: 50Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP125VMA-E
External Static Pressure: 70Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP125VMA-E
External Static Pressure: 100Pa
Power Source: 220-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP125VMA-E
External Static Pressure: 150Pa
Power Source: 220-240V(50/60Hz)
0000004790.BOOK 14 ページ ２０１８年５月８日 火曜日 午後３時２７分
MEES17K198
PEFY-WP-VMA-E
15
5. SOUND LEVELS Ceiling concealed (Medium static pressure type)
5-2-2. NC curves (Sound level measured condition : With 2m air inlet duct and 2m air outlet duct)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP20VMA-E
External Static Pressure: 35Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP20VMA-E
External Static Pressure: 50Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP20VMA-E
External Static Pressure: 70Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP20VMA-E
External Static Pressure: 100Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP20VMA-E
External Static Pressure: 150Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP25VMA-E
External Static Pressure: 35Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP25VMA-E
External Static Pressure: 50Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP25VMA-E
External Static Pressure: 70Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP25VMA-E
External Static Pressure: 100Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP25VMA-E
External Static Pressure: 150Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP32VMA-E
External Static Pressure: 35Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP32VMA-E
External Static Pressure: 50Pa
Power Source: 220-230-240V(50/60Hz)
0000004790.BOOK 15 ページ ２０１８年５月８日 火曜日 午後３時２７分
MEES17K198
PEFY-WP-VMA-E
16
5. SOUND LEVELS Ceiling concealed (Medium static pressure type)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP32VMA-E
External Static Pressure: 70Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP32VMA-E
External Static Pressure: 100Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP32VMA-E
External Static Pressure: 150Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP40, 50, 63VMA-E
External Static Pressure: 35Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP40, 50, 63VMA-E
External Static Pressure: 50Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP40, 50, 63VMA-E
External Static Pressure: 70Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP40, 50, 63VMA-E
External Static Pressure: 100Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP40, 50, 63VMA-E
External Static Pressure: 150Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP71, 80, 100VMA-E
External Static Pressure: 35Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP71, 80, 100VMA-E
External Static Pressure: 50Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP71, 80, 100VMA-E
External Static Pressure: 70Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP71, 80, 100VMA-E
External Static Pressure: 100Pa
Power Source: 220-230-240V(50/60Hz)
0000004790.BOOK 16 ページ ２０１８年５月８日 火曜日 午後３時２７分
MEES17K198
PEFY-WP-VMA-E
17
5. SOUND LEVELS Ceiling concealed (Medium static pressure type)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP71, 80, 100VMA-E
External Static Pressure: 150Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP125VMA-E
External Static Pressure: 35Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP125VMA-E
External Static Pressure: 50Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP125VMA-E
External Static Pressure: 70Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP125VMA-E
External Static Pressure: 100Pa
Power Source: 220-230-240V(50/60Hz)
10.0
15.0
20.0
25.0
30.0
35.0
40.0
45.0
50.0
55.0
60.0
65.0
70.0
63 125 250 500 1k 2k 4k 8k
NC-60
NC-50
Octave band pressure level (dB) 0dB=20μPa
Approximate minimum
audible limit on
continuous noise
NC-40
NC-30
NC-20
Octave band center frequencies (Hz)
High
Middle 50/60Hz
Low 50/60Hz
50/60Hz
PEFY-WP125VMA-E
External Static Pressure: 150Pa
Power Source: 220-230-240V(50/60Hz)
0000004790.BOOK 17 ページ ２０１８年５月８日 火曜日 午後３時２７分
MEES17K198
PEFY-WP-VMA-E
18
6. FAN CHARACTERISTICS CURVES Ceiling concealed (Medium static pressure type)
6. FAN CHARACTERISTICS CURVES
PEFY-WP20VMA-E
External static pressure : 35Pa
Power source : 220-240V
Static pressure (Pa)
Airflow rate (m
3
/min)
50
40
30
20
10
0
PEFY-WP20VMA-E
External static pressure : 50Pa
Power source : 220-240V
Static pressure (Pa)
Airflow rate (m
3
/min)
70
60
50
40
30
20
10
0
PEFY-WP20VMA-E
External static pressure : 70Pa
Power source : 220-240V
Static pressure (Pa)
Airflow rate (m
3
/min)
90
80
70
60
50
40
30
20
10
0
PEFY-WP20VMA-E
External static pressure : 100Pa
Power source : 220-240V
Static pressure (Pa)
Airflow rate (m
3
/min)
110
100
90
80
70
60
50
40
30
20
10
0
PEFY-WP20VMA-E
External static pressure : 150Pa
Power source : 220-240V
Static pressure (Pa)
Airflow rate (m
3
/min)
160
150
140
130
120
110
100
90
80
70
60
50
40
30
20
10
0
5 10 15 5 10 15
5 10 15 5 10 15
5 10 15
Middle
High
Middle
High
Middle
High
Middle
High
Middle
High
Low Low
Low
Low
Low
Limit
Limit
Limit
Limit
Limit
0000004790.BOOK 18 ページ ２０１８年５月８日 火曜日 午後３時２７分
MEES17K198
PEFY-WP-VMA-E
19
6. FAN CHARACTERISTICS CURVES Ceiling concealed (Medium static pressure type)
PEFY-WP25VMA-E
External static pressure : 35Pa
Power source : 220-240V
Static pressure (Pa)
Airflow rate (m
3
/min)
60
50
40
30
20
10
0
PEFY-WP25VMA-E
External static pressure : 50Pa
Power source : 220-240V
Static pressure (Pa)
Airflow rate (m
3
/min)
70
60
50
40
30
20
10
0
PEFY-WP25VMA-E
External static pressure : 70Pa
Power source : 220-240V
Static pressure (Pa)
Airflow rate (m
3
/min)
90
80
70
60
50
40
30
20
10
0
PEFY-WP25VMA-E
External static pressure : 100Pa
Power source : 220-240V
Static pressure (Pa)
Airflow rate (m
3
/min)
120
110
100
90
80
70
60
50
40
30
20
10
0
PEFY-WP25VMA-E
External static pressure : 150Pa
Power source : 220-240V
Static pressure (Pa)
Airflow rate (m
3
/min)
170
160
150
140
130
120
110
100
90
80
70
60
50
40
30
20
10
0
7 9 11 13 15 17 19 21 7 9 11 13 15 17 19 21
7 9 11 13 15 17 19 21 7 9 11 13 15 17 19 21
7 9 11 13 15 17 19 21
Middle
High
Middle
High
Middle
High
Middle
High
Middle
High
Low Low
Low
Low
Low
Limit
Limit
Limit
Limit
Limit
0000004790.BOOK 19 ページ ２０１８年５月８日 火曜日 午後３時２７分
Other manuals for City Multi PEFY-WP20VMA-E
3
This manual suits for next models
9
Table of contents
Other Mitsubishi Electric Air Conditioner manuals
Mitsubishi Electric
Mitsubishi Electric MUZ-FS06NAH-U1 User manual
Mitsubishi Electric
Mitsubishi Electric MSZ-GA60VA User manual
Mitsubishi Electric
Mitsubishi Electric CITY MULTI PFFY-WP50VLRMM-E User manual
Mitsubishi Electric
Mitsubishi Electric Mr.Slim PEH-2.5EAKH User manual
Mitsubishi Electric
Mitsubishi Electric Mr. SLIM Mr. SLIM S KA Series User manual
Mitsubishi Electric
Mitsubishi Electric PURY-(E)P200 How to use
Mitsubishi Electric
Mitsubishi Electric P-Series User manual
Mitsubishi Electric
Mitsubishi Electric Mr.SLIM PKA-A12HA4 User manual
Mitsubishi Electric
Mitsubishi Electric MSH-CB50VB- E1 User manual
Mitsubishi Electric
Mitsubishi Electric MSZ-G09SV-E1 User manual
Mitsubishi Electric
Mitsubishi Electric ecodan EHPT17X-VM6D User manual
Mitsubishi Electric
Mitsubishi Electric MUZ-GB50VA - E1MUZ-GB50VA - E2 User manual
Mitsubishi Electric
Mitsubishi Electric City Multi PLFY-P08NCMU-E Operating manual
Mitsubishi Electric
Mitsubishi Electric PAC-AK52BC User manual
Mitsubishi Electric
Mitsubishi Electric Mr. Slim SLZ-M25 User manual
Mitsubishi Electric
Mitsubishi Electric PLA-RP.BA Series Instruction manual
Mitsubishi Electric
Mitsubishi Electric MSC-A07WV-E1 User manual
Mitsubishi Electric
Mitsubishi Electric PLH Series Operating manual
Mitsubishi Electric
Mitsubishi Electric Series PDFY Operating manual
Mitsubishi Electric
Mitsubishi Electric Mr.SLIM PUHZ-P V Series User manual
