Mitsubishi Electric City Multi PUMY-SP112VKM Operating manual

TECHNICAL & SERVICE MANUAL
OUTDOOR UNIT
HFC
utilized
R410A
April 2018
Note:
•This service manual describes
technical data of the outdoor
units only.
<Outdoor unit>
[Model Name]
PARTS CATALOG (OCB668)
PUMY-SP112VKM PUMY-SP112VKM.TH PUMY-SP112VKMR1.TH
PUMY-SP125VKM PUMY-SP125VKM.TH PUMY-SP125VKMR1.TH
PUMY-SP140VKM PUMY-SP140VKM.TH PUMY-SP140VKMR1.TH
PUMY-SP112YKM PUMY-SP112YKM.TH PUMY-SP112YKMR1.TH
PUMY-SP125YKM PUMY-SP125YKM.TH PUMY-SP125YKMR1.TH
PUMY-SP140YKM PUMY-SP140YKM.TH PUMY-SP140YKMR1.TH
Salt proof model
[Service Ref.]
CONTENTS
1. SAFETY PRECAUTION....................................2
2. OVERVIEW OF UNITS......................................5
3. SPECIFICATIONS............................................. 9
4. DATA................................................................11
5. OUTLINES AND DIMENSIONS...................... 26
6. WIRING DIAGRAM......................................... 27
7. NECESSARY CONDITIONS FOR SYSTEM CONSTRUCTION..... 29
8. TROUBLESHOOTING.................................... 47
9. ELECTRICAL WIRING...................................124
10. REFRIGERANT PIPING TASKS....................130
11. DISASSEMBLY PROCEDURE.......................137
SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
PUMY-SP112VKM-BS PUMY-SP112VKM.TH-BS PUMY-SP112VKMR1.TH-BS
PUMY-SP125VKM-BS PUMY-SP125VKM.TH-BS PUMY-SP125VKMR1.TH-BS
PUMY-SP140VKM-BS PUMY-SP140VKM.TH-BS PUMY-SP140VKMR1.TH-BS
PUMY-SP112YKM-BS PUMY-SP112YKM.TH-BS PUMY-SP112YKMR1.TH-BS
PUMY-SP125YKM-BS PUMY-SP125YKM.TH-BS PUMY-SP125YKMR1.TH-BS
PUMY-SP140YKM-BS PUMY-SP140YKM.TH-BS PUMY-SP140YKMR1.TH-BS
No. OCH668
REVISED EDITION-B
Revision:
•Added
PUMY-SP112VKMR1.TH,
PUMY-SP125VKMR1.TH,
PUMY-SP140VKMR1.TH,
PUMY-SP112YKMR1.TH,
PUMY-SP125YKMR1.TH and
PUMY-SP140YKMR1.TH
in REVISED EDITION-B.
•Someotherdescriptionshave
been also modified.
OCH668 REVISED EDITION-A
is void.

2
OCH668B
Cautions for units utilizing refrigerant R410A
1-1. CAUTIONS RELATED TO NEW REFRIGERANT
Use new refrigerant pipes.
Store the piping indoors, and keep both ends of
the piping sealed until just before brazing.
(Leave elbow joints, etc. in their packaging.)
Avoid using thin pipes.
Charge refrigerant from liquid phase of gas
cylinder.
If the refrigerant is charged from gas phase, composition
change may occur in refrigerant and the efficiency will be
lowered.
Do not use refrigerant other than R410A.
If other refrigerant (R22, etc.) is used, chlorine in refrige-
rant can cause deterioration of refrigerant oil, etc.
Use a vacuum pump with a reverse flow check
valve.
Vacuum pump oil may flow back into refrigerant cycle and
that can cause deterioration of refrigerant oil, etc.
Use the following tools specifically designed for
use with R410A refrigerant.
The following tools are necessary to use R410A refrigerant.
Handle tools with care.
If dirt, dust or moisture enters into refrigerant cycle, that can
cause deterioration of refrigerant oil or malfunction of com-
pressor.
Do not use a charging cylinder.
If a charging cylinder is used, the composition of refrigera-
nt will change and the efficiency will be lowered.
Flare tool
Electronic refrigerant
charging scale
Vacuum pump adaptor
Size adjustment gauge
Gauge manifold
Torque wrench
Gas leak detector
Charge hose
Tools for R410A
Contamination inside refrigerant piping can cause deterio-
ration of refrigerant oil, etc.
If dirt, dust or moisture enters into refrigerant cycle, that can
cause deterioration of refrigerant oil or malfunction of com-
pressor.
If large amount of mineral oil enters, that can cause deterio-
ration of refrigerant oil, etc.
Make sure that the inside and outside of refrige-
rant piping is clean and it has no contaminants
such as sulfur, oxides, dirt, shaving particles, etc,
which are hazard to refrigerant cycle.
In addition, use pipes with specified thickness.
The refrigerant oil applied to flare and flange
connections must be ester oil, ether oil or
alkylbenzene oil in a small amount.
Ventilate the room if refrigerant leaks during
operation. If refrigerant comes into contact with
a flame, poisonous gases will be released.
Use the specified refrigerant only.
Never use any refrigerant other than that specified.
Doing so may cause a burst, an explosion, or fire when the
unit is being used, serviced, or disposed of.
Correct refrigerant is specified in the manuals and on the
spec labels provided with our products.
We will not be held responsible for mechanical failure,
system malfunction, unit breakdown or accidents caused
by failure to follow the instructions.
1SAFETY PRECAUTION

3
OCH668B
Unit
Electronic weighing scale
[3] Service tools
Use the below service tools as exclusive tools for R410A refrigerant.
[1] Cautions for service
(1) Perform service after recovering the refrigerant left in unit completely.
(2) Do not release refrigerant in the air.
(3) After completing service, charge the cycle with specified amount of refrigerant.
(4) If moisture or foreign matter might have entered the refrigerant piping during service, ensure to remove them.
[2] Additional refrigerant charge
When charging directly from cylinder
 (1)CheckthatcylinderforR410Aonthemarketisasyphontype.
 (2)Chargingshouldbeperformedwiththecylinderofsyphonstoodvertically.(Refrigerantischargedfromliquidphase.)
Although"-BS"modelhasbeendesignedtoberesistanttosaltdamage,observethefollowingprecautionstomaintainthe
performanceoftheunit.
(1)Avoidinstallingtheunitinalocationwhereitwillbeexposeddirectlytoseawaterorseabreeze.
(2)Ifthecoverpanelmaybecomecoveredwithsalt,besuretoinstalltheunitinalocationwherethesaltwillbewashedaway
byrainwater.(Ifasunshadeisinstalled,rainwatermaynotcleanthepanel.)
(3)Toensurethatwaterdoesnotcollectinthebaseoftheoutdoorunit,makesurethatthebaseislevel,notatangle.Water
collecting in the base of the outdoor unit could cause rust.
(4)Iftheunitisinstalledinacoastalarea,cleantheunitwithwaterregularlytoremoveanysaltbuild-up.
(5)Iftheunitisdamagedduringinstallationormaintenance,besuretorepairit.
(6) Be sure to check the condition of the unit regularly.
(7)Besuretoinstalltheunitinalocationwithgooddrainage.
1-2. PRECAUTIONS FOR SALT PROOF TYPE "-BS" MODEL
No. Tool name Specifications
1Gauge manifold · Only for R410A
·Usetheexistingfittingspecifications. (UNF1/2)
·Usehigh-tensionsidepressureof5.3MPa·Gorover.
2Charge hose · Only for R410A
·Usepressureperformanceof5.09MPa·Gorover.
3Electronicweighingscale —
4Gas leak detector · Use the detector for R134a, R407C or R410A.
5Adaptorforreverseflowcheck ·Attachonvacuumpump.
6Refrigerant charge base —
7Refrigerant cylinder ·OnlyforR410A·Topofcylinder(Pink)
·Cylinderwithsyphon
8Refrigerantrecoveryequipment —

4
OCH668B
Cautions for refrigerant piping work
NewrefrigerantR410Aisadoptedforreplacement inverterseries.Althoughtherefrigerant piping workforR410Aissame
as for R22, exclusive tools are necessary so as not to mix with different kind of refrigerant. Furthermore as the working
pressureofR410Ais1.6timeshigherthanthatofR22,theirsizesofflaredsectionsandflarenutsaredifferent.
1Thicknessofpipes
Because the working pressure of R410A is higher compared to R22, be sure to use refrigerant piping with thickness
shownbelow.(Neverusepipesof0.7mmorbelow.)
2Dimensions of flare cutting and flare nut
The component molecules in HFC refrigerant are smaller compared to conventional refrigerants. In addition to that,
R410Aisarefrigerant,whichhashigherriskofleakagebecauseitsworkingpressureishigherthanthatofotherrefrig-
erants. Therefore, to enhance airtightness and strength, flare cutting dimension of copper pipe for R410A has been
specifiedseparatelyfromthedimensionsforotherrefrigerantsasshownbelow.ThedimensionBofflarenutforR410A
alsohas partly been changed to increase strength as shown below.Set copper pipe correctly referring to copper pipe
flaringdimensionsforR410Abelow.For1/2and5/8inchpipes,thedimensionBchanges.
Usetorquewrenchcorrespondingtoeachdimension.
3ToolsforR410A(Thefollowingtableshowswhetherconventionaltoolscanbeusedornot.)
1/4
3/8
1/2
5/8
3/4
6.35
9.52
12.70
15.88
19.05
0.8
0.8
0.8
1.0
—
0.8
0.8
0.8
1.0
1.0
Nominal
dimensions (in)
Diagram below: Piping diameter and thickness
Outside
diameter (mm)
Thickness (mm)
R410A R22
1/4
3/8
1/2
5/8
3/4
6.35
9.52
12.70
15.88
19.05
9.1
13.2
16.6
19.7
—
9.0
13.0
16.2
19.4
23.3
Nominal
dimensions (in)
Flare cutting dimensions
Outside
diameter
Dimension A ( )
+0
-0.4 (mm)
R410A R22
(mm)
1/4
3/8
1/2
5/8
3/4
6.35
9.52
12.70
15.88
19.05
17.0
22.0
26.0
29.0
—
17.0
22.0
24.0
27.0
36.0
Nominal
dimensions (in)
Flare nut dimensions
Outside
diameter
Dimension B (mm)
R410A R22
(mm)
Gauge manifold
Charge hose
Gas leak detector
Refrigerant recovery equipment
Refrigerant cylinder
Applied oil
Safety charger
Charge valve
Vacuum pump
Flare tool
Bender
Pipe cutter
Welder and nitrogen gas cylinder
Refrigerant charging scale
Vacuum gauge or thermis-
tor vacuum gauge and
vacuum valve
Charging cylinder
Air purge, refrigerant charge
and operation check
Gas leak check
Refrigerant recovery
Refrigerant charge
Apply to flared section
Prevent compressor malfunction
when charging refrigerant by
spraying liquid refrigerant
Prevent gas from blowing out
when detaching charge hose
Vacuum drying and air
purge
Flaring work of piping
Bend the pipes
Cut the pipes
Weld the pipes
Refrigerant charge
Check the degree of vacuum. (Vacuum
valve prevents back flow of oil and refri-
gerant to thermistor vacuum gauge)
Refrigerant charge
Tool exclusive for R410A
Tool exclusive for R410A
Tool for HFC refrigerant
Tool exclusive for R410A
Tool exclusive for R410A
Ester oil, ether oil and
alkylbenzene oil (minimum amount)
Tool exclusive for R410A
Tool exclusive for R410A
Tools for other refrigerants can
be used if equipped with adop-
ter for reverse flow check
Tools for other refrigerants
can be used by adjusting
flaring dimension
Tools for other refrigerants can be used
Tools for other refrigerants can be used
Tools for other refrigerants can be used
Tools for other refrigerants can be used
Tools for other refrigerants
can be used
Tool exclusive for R410A
Tools and materials Use R410A tools Can R22 tools be used?
(Usable if equipped
with adopter for rever-
se flow)
(Usable by adjusting
flaring dimension)
Can R407C tools be used?
Ester oil, ether oil:
Alkylbenzene oil: minimum amount
(Usable if equipped
with adopter for rever-
se flow)
(Usable by adjusting
flaring dimension)
: Prepare a new tool. (Use the new tool as the tool exclusive for R410A.)
: Tools for other refrigerants can be used under certain conditions.
: Tools for other refrigerants can be used.
Dimension A
Dimension B

5
OCH668B
2
2-1. UNIT CONSTRUCTION
Remote
controller
Name
Model number
Functions
M-NET remote controller
PAR-F27MEA-E, PAR-U02MEDA
• A handy remote controller for use in
conjunction
with the Melans centralized
management system.
• Addresses must be set.
• Addresses setting is not
necessary.
MA remote controller
PAR-21MAA, PAR-31/32MAA
*1WhentheindoorunitofFreshAirtypeisconnectedwiththeoutdoorunit,themaximumconnectabletotalindoorunitcapacityis110%.
*2PUMYisconnectabletoFreshAirtypeindoorunit.
Itispossibletoconnect1FreshAirtypeindoorunitto1outdoorunit.(1:1system)
 Operatingtemperaturerange(outdoortemperature)forfreshairtypeindoorunitsdifferfromotherindoorunits.
 Referto"2-4-(3).Operatingtemperaturerange".
*3
WhenconnectingtheCONNECTIONKIT(PAC-LV11M-J)andanM-seriesindoorunit,refertotheinstallationmanualfortheCONNECTIONKIT.
*4Do not connect Lossnay remote controller(s). (PZ-61DR-E, PZ-60DR-E, PZ-52SF-E, PZ-43SMF-E)
*5Authorizedconnectableindoorunitsareasfollows;
PUMY-SP112:PEFY-P25VMA3-E×2 + PEFY-P32VMA3-E×2
PUMY-SP125: PEFY-P25VMA3-E×1 + PEFY-P32VMA3-E×3
PUMY-SP140: PEFY-P32VMA3-E×2 + PEFY-P40VMA3-E×2
*6ForthePLFY-EP/VEM-E,upto2unitscanbeconnected.Otherindoorunits(ExcludingthePEFY-P/VMA3-EandPEFY-P/VMH-EF)can
beconnectedwithinthetotalratedcapacityandmaximumnumberofconnectedunits.
*7ConnectableonlyforPUMY-SP▪VKMR1.TH(-BS),PUMY-SP▪YKMR1.TH(-BS).
OVERVIEW OF UNITS
Outdoor unit
4.5HP 5HP 6HP
PUMY-SP112VKM(R1).TH(-BS)
PUMY-SP112YKM(R1).TH(-BS)
PUMY-SP125VKM(R1).TH(-BS)
PUMY-SP125YKM(R1).TH(-BS)
PUMY-SP140VKM(R1).TH(-BS)
PUMY-SP140YKM(R1).TH(-BS)
Applicable
indoor unit
Capacity Type15toType140
Number of units 1to9units 1 to 10 units 1 to 12 units
Totalsystemcapacityrange 50to130%ofoutdoorunitcap50to130%ofoutdoorunitcapacity*1acity*250to130%ofoutdoorunitcapacity*2
Branching pipe
components
Branch header
(2 branches)
Branch header
(4 branches)
Branch header
(8 branches)
CMY-Y62-G-E CMY-Y64-G-E CMY-Y68-G-E
M series remote
controller
Model
Capacity
Cassette Ceiling Ceiling
concealed
Wall
Mounted
Ceiling
Suspended
Floor standing Ceiling concealed Lossnay CONNECTION KIT
2 by 2 4-way ow 2-way ow 1-way ow Exposed Concealed Fresh air
*2
Built-in PAC-LV11M-J
PLFY-P PLFY-P
PLFY-EP*6 PLFY-P PMFY-P PEFY-P PKFY-P PCFY-P PFFY-P PFFY-P PEFY-P PDFY-P GUF*4
15 15VFM-E1 – – – – 15VMS1(L)-E 15VBM-E – – – – – –
20 20VFM-E1 20VEM-E – 20VLMD-E 20VBM-E
20VMS1(L)-E
20VMA(L)-E
20VMR-E-L/R
20VBM-E –
20VLEM-E
20VKM-E(2)
20VLRM-E
20VLRMM-E
– 20VM-E –
25 25VFM-E1 25VEM-E – 25VLMD-E 25VBM-E
25VMS1(L)-E
25VMA(L)-E
25VMR-E-L/R
25VMA3-E*5
25VBM-E –
25VLEM-E
25VKM-E(2)
25VLRM-E
25VLRMM-E
– 25VM-E –
32 32VFM-E1 32VEM-E – 32VLMD-E 32VBM-E
32VMS1(L)-E
32VMA(L)-E
32VMR-E-L/R
32VMA3-E*5
32VHM-E –
32VLEM-E
32VKM-E(2)
32VLRM-E
32VLRMM-E
– 32VM-E –
40 40VFM-E1 40VEM-E – 40VLMD-E 40VBM-E
40VMS1(L)-E
40VMA(L)-E
40VMH(S)-E
40VMA3-E*5
40VHM-E 40VKM-E
40VLEM-E
40VKM-E(2)
40VLRM-E
40VLRMM-E
– 40VM-E –
50 50VFM-E1 50VEM-E 50VEM-E 50VLMD-E –
50VMS1(L)-E
50VMA(L)-E
50VMH(S)-E
50VHM-E – 50VLEM-E
50VLRM-E
50VLRMM-E
– 50VM-E 50RD(H)4
63 – 63VEM-E 63VEM-E 63VLMD-E –
63VMS1(L)-E
63VMA(L)-E
63VMH(S)-E
63VKM-E 63VKM-E 63VLEM-E
63VLRM-E
63VLRMM-E
– 63VM-E –
71 –––––71VMA(L)-E
71VMH(S)-E – – – – – 71VM-E –
80 – 80VEM-E 80VEM-E 80VLMD-E – 80VMA(L)-E
80VMH(S)-E – – – – 80VMH-E-F 80VM-E –
100 – 100VEM-E –
100VLMD-E –100VMA(L)-E
100VMH(S)-E 100VKM-E 100VKM-E – – – 100VM-E 100RD(H)4
125 –
125VEM-E – 125VLMD-E –
125VMA(L)-E
125VMH
(S) -E
– 125VKM-E – – – 125VM-E –
140 – –
– – –
140VMA(L)-E
140VMH
(S) -E
–– – – 140VMH-E-F – –
M series indoor unit *3
MSZ-GE Series
MSZ-SF Series
MSZ-EF Series
MSZ-FH Series
MSZ-LN Series
MSZ-AP Series *7

6
OCH668B
Branch box
5-branches
(MAX. 5 units)
Number of branches
Indoor unit that
can be connected
( )
Note:
A maximum of 2 branch boxes can be connected
to 1 outdoor unit.
PUMY-SP・VKM.TH(-BS),PUMY-SP・YKM.TH(-BS)
cannot connect 52/ 32 series.
PUMY-SP・VKMR1.TH(-BS),PUMY-SP・
YKMR1.TH(-BS)
cannot connect 31/32/51/52 series.
Select a model according to the connection method.
2-branch pipe (joint): Optional parts
In case of using 1- branch box
In case of using 2- branch boxes
No need
Model name Connection method
flare
brazing
MSDD-50AR-E
MSDD-50BR-E
Option Optional accessories of indoor units and outdoor units are available.
PAC-MK5*BC
3-branches
(MAX. 3 units)
PAC-MK3*BC
2-2. UNIT CONSTRUCTION (BRANCH BOX SYSTEM)
*1ConnectableforonlyPUMY-SP▪VKMR1.TH(-BS),PUMY-SP▪YKMR1.T
Note:Thelineupofaconnectableindoorunitdependsonadistrict/areas/country.
Outdoor unit
4.5HP 5HP 6HP
PUMY-SP112VKM(R1).TH(-BS)
PUMY-SP112YKM(R1).TH(-BS)
PUMY-SP125VKM(R1).TH(-BS)
PUMY-SP125YKM(R1).TH(-BS)
PUMY-SP140VKM(R1).TH(-BS)
PUMY-SP140YKM(R1).TH(-BS)
Applicable
indoor unit
Capacity kWunit:Type15toType100
Number of units 2 to 8 units
Totalsystemcapacity
range
50to130%ofoutdoorunitcapacity
(6.3to16.2kW) o
50to130%ofoutdoorunitcapacity
(7.1to18.2kW) o
50to130%ofoutdoorunitcapacity
(8.0to20.2kW) o
Branchboxthat
can be connected
Number of units 1 to 2 units
Model
capacity
[kWtype]
WallMounted
1-way
ceiling
cassette
4-way
ceiling cassette
2by2type Standard
MSZ-FH MSZ-LN MSZ-GF MSZ-SF MSZ-EF MSZ-SF MSZ-AP*1 MLZ-KA MLZ-KP*1 SLZ-KF SLZ-M*1 PLA-RP
15
- - - - - 15VA 15VF - - - 15FA -
18
- - - - 18VE3 - - - ----
20
- - - - - 20VA 20VF - ----
22
- - - - 22VE3 - - - ----
25
25VE2 25VG - 25VE3 25VE3 - 25VG 25VA 25VE 25VA2 25FA -
35
35VE2 35VG - 35VE3 35VE3 - 35VG 35VA 35VE 35VA2 35FA 35EA
42
- - - 42VE3 42VE3 - 42VG - ----
50
50VE2 - - 50VE3 50VE3 - 50VG 50VA 50VE 50VA2 50FA 50EA
60
- - 60VE - - - - - - - - 60EA
71
- - 71VE - - - - - - - - 71EA
80
------ - - ----
100
------ - - - - - 100EA
Model
capacity
[kWtype]
Ceiling
concealed
Ceiling
suspended
Floor
standing
Lowstaticpressure Middlestaticpressure
SEZ-KD SEZ-M *1 PEAD-RP PEAD-M PCA-RP PCA-M MFZ-KJ*1
15 - - - - - - -
18 - - - - - - -
20 - - - - - - -
22 - - - - - - -
25
25VAQ(L) 25DA - - - - 25VE
35
35VAQ(L) 35DA - - 35KAQ 35KA 35VE
42 - - - - - - -
50
50VAQ(L) 50DA 50JAQ(L) 50JA(L) 50KAQ 50KA 50VE
60
60VAQ(L) 60DA 60JAQ(L) 60JA(L) 60KAQ 60KA -
71
71VAQ(L) 71DA 71JAQ(L) 71JA(L) 71KAQ 71KA -
80 - - - - - - -
100 - -
100JAQ(L) 100JA(L) 100KAQ 100KA -

7
OCH668B
PUMY-SP・VKM.TH(-BS),PUMY-SP・YKM.TH(-BS)
cannot connect 52/ 32 series.
PUMY-SP・VKMR1.TH(-BS),PUMY-SP・
YKMR1.TH(-BS)
cannot connect 31/32/51/52 series.
PAC-MK5*BC
5-branches
(MAX. 5 units)
Branch box
Number of branches
Branching pipe
components
CMY-Y62-G-E
Branch header
(2-branches)
CMY-Y64-G-E
Branch header
(4-branches)
CMY-Y68-G-E
Branch header
(8-branches)
Citymulti indoor units*2
CONNECTION KIT
PAC-LV11M-J
M series indoor unit
MA
remote
controller
M series
remote
controller
M series
S series
P series
indoor units*2
MA
remote
controller
*1When connecting 7 indoor units via branch box, connectable citymulti indoor units are 3; connecting 8 indoor units
via branch box, connectable citymulti indoor units are 2.
*2Refer to “2-1. UNIT CONSTRUCTION” or “2-2. UNIT CONSTRUCTION (BRANCH BOX SYSTEM)”, for more detail.
PAC-MK3*BC
3-branches
(MAX. 3 units)
2-3. UNIT CONSTRUCTION (MIXED SYSTEM)
Outdoor unit
4.5HP 5HP 6HP
PUMY-SP112VKM(R1).TH(-BS)
PUMY-SP112YKM(R1).TH(-BS)
PUMY-SP125VKM(R1).TH(-BS)
PUMY-SP125YKM(R1).TH(-BS)
PUMY-SP140VKM(R1).TH(-BS)
PUMY-SP140YKM(R1).TH(-BS)
Applicable
indoor unit
Capacity
City multi indoor unit
Type15toType140
Viabranchbox kWunit:Type15toType100
Number
of units
Viabranchbox City multi indoor Viabranchbox City multi indoor Viabranchbox City multi indoor
1branchbox- 5 5 5 5 5 5
2branchboxes 7 or 8*1 3 or 2 *18 3 8 3
Totalsystemcapacityrange 6.3to16.2kW 7.1to18.2kW 8.0to20.2kW

8
OCH668B
2-4. UNIT SPECIFICATIONS
(2) Method for identifying MULTI-S model
(1) Outdoor Unit
Outdoor unit <When using model 125 >
PU M Y - SP 125 Y K M - BS
Refrigerant
R410A
Indicates equivalent
to Cooling capacity
Power supply
V: Single phase
220-230-240V, 50 Hz
220 V, 60 Hz
Y: 3-phase
380-400-415V, 50 Hz
380 V, 60 Hz
Outdoor unit
model type
M-NET
control
Frequency
conversion
controller
Outdoor unit
MULTI-S
(kcal/ h)
Salt proof
type
Coolingcapacityindicatesthemaximumvalueatoperationunderthefollowingcondition.
 *Cooling Indoor :D.B.27°C/W.B.19.0°C
Outdoor : D.B. 35°C
*Heating Indoor : D.B. 20°C
  Outdoor :D.B.7°C/W.B.6°C
(3) Operating temperature range
Note: D.B.:DryBulbTemperature
 W.B.:WetBulbTemperature
Cooling Heating
W.B. 15 to 24°C
D.B. -5 to 52℃*1
D.B. 15 to 27℃
W.B. -20 to 15℃
Indoor-side intake air temperature
Outdoor-side intake air temperature
■When connecting fresh air type indoor unit
air type indoor
Capacity of Fresh
Cooling Heating
Indoor-side and Outdoor-side P80 D.B. 21 to 43:*2
W.B. 15.5 to 35:
intake air temperature P140 D.B. 21 to 43:*2
W.B. 15.5 to 35:
D.B. -10 to 20℃*3
D.B. -5 to 20℃*3
*1 Thermo-OFF (FAN-mode) automatically starts if the outdoor temp. is lower than 21:D.B..
Outdoor unit
PUMY-SP112VKM.TH(-BS)
PUMY-SP112YKM.TH(-BS)
PUMY-SP112VKMR1.TH(-BS)
PUMY-SP112YKMR1.TH(-BS)
PUMY-SP125VKM.TH(-BS)
PUMY-SP125YKM.TH(-BS)
PUMY-SP125VKMR1.TH(-BS)
PUMY-SP125YKMR1.TH(-BS)
PUMY-SP140VKM.TH(-BS)
PUMY-SP140YKM.TH(-BS)
PUMY-SP140VKMR1.TH(-BS)
PUMY-SP140YKMR1.TH(-BS)
Capacity
Cooling(kW) 12.5 14.0 15.5
Heating(kW) 14.0 16.0 16.5
Compressor(kW) 3.1 3.5 3.7
*1 10 to 52°C D.B. °C:WhenconnectingPKFY-P15/20/25VBM,PFFY-P20/25/32VKM,PFFY-P20/25/32VLE(R)M,PEFY-P25/32/40VMA3-E,
Mseries,Sseries,andPseriestypeindoorunitwithbranchbox,Mseriestypeindoorunitwithconnectionkit.
*2Thermo-OFF(FAN-mode)automaticallystartsiftheoutdoortemp.islowerthan21°C D.B.
*3Thermo-OFF(FAN-mode)automaticallystartsiftheoutdoortemp.islowerthan20°C D.B.

9
OCH668B
3SPECIFICATIONS
Model PUMY-SP112VKM(R1).TH(-BS) PUMY-SP125VKM(R1).TH(-BS) PUMY-SP140VKM(R1).TH(-BS)
Powersource 1-phase220-230-240V,50Hz;1-phase220V,60Hz
220 230 240 220 230 240 220 230 240
50/60 50 50 50/60 50 50 50/60 50 50
Coolingcapacity
(Nominal)
kW*1 12.5 14.0 15.5
kcal/h*1 10,750 12,040 13,330
BTU/h*1 42,650 47,768 52,886
Powerinput kW 3.10 3.84 4.70
Currentinput A 14.38 13.75 13.18 17.81 17.04 16.33 21.80 20.85 19.98
COP kW/kW 4.03 3.65 3.30
Temp.rangeofcooling Indoortemp. W.B. 15 to 24°C
Outdoortemp. D.B. -5 to 52°C *3,*4
Heatingcapacity
(Nominal)
kW*2 14.0 16.0 16.5
kcal/h*2 12,040 13,760 14,190
BTU/h*2 47,768 54,592 56,298
Powerinput kW 3.17 3.90 4.02
Currentinput A 14.70 14.06 13.48 18.09 17.30 16.58 18.65 17.83 17.09
COP kW/kW 4.42 4.10 4.10
Temp.rangeofheating Indoortemp. D.B. 15 to 27°C
Outdoortemp. W.B. -20 to 15°C
Indoor unit
connectable
Totalcapacity 50to130%ofoutdoorunitcapacity
Model/
Quantity
City multi 15-140/9 15-140/10 15-140/12
Branchbox 15-100/8 15-100/8 15-100/8
"Mixed
system"
Branchbox
1 unit
City multi 15-140/5 15-140/5 15-140/5
Branch
box
15-100/5 15-100/5 15-100/5
Branchbox
2 units
City multi 15-140/3 or 2 *7 15-140/3 15-140/3
Branch
box
15-100/7 or 8 *7 15-100/8 15-100/8
Soundpressurelevel
(measured in anechoic room)
dB <A> 52/54 53/56 54/56
Powerpressurelevel
(measured in anechoic room)
dB <A> 72/74 73/76 74/76
Refrigerantpiping
diameter
Liquidpipe mm (inch) 9.52(3/8)
Gaspipe mm (inch) 15.88 (5/8)
FAN *2 Type×Quantity PropellerFan×1
Airowrate m³/min 77 83 83
L/s 1283 1383 1383
cfm 2719 2931 2931
Control, Driving mechanism DC control
Motoroutput kW 0.20 × 1
Externalstaticpress. 0
Compressor Type×Quantity Twinrotaryhermeticcompressor×1
Manufacturer MitsubishiElectricCorporation
Starting method Inverter
Capacitycontrol %Cooling 26 to 100
Heating 20 to 100
Cooling 24 to 100
Heating 18 to 100
Cooling 21 to 100
Heating 17 to 100
Motoroutput kW 3.1 3.5 3.7
Case heater kW 0
Lubricant FV50S (1.4litter)
Externalnish GalvanizedSteelSheetMunsellNo.3Y7.8/1.1
ExternaldimensionH×W×D mm 981×1,050×330(+40)
inch 38-5/8 × 41-3/8 × 13 (+1-37/64)
Protection devices Highpressureprotection HighpressureSwitch
Inverter circuit (COMP./FAN) Overcurrent detection, Overheat detection(Heat sink thermistor)
Compressor Compressorthermistor,Overcurrentdetection
Fan motor Overheating,Voltageprotection
Refrigerant Type×originalcharge R410A 3.5 kg
Control Electronicexpansionvalve
Netweight kg (lb) 93(205)*8
Heatexchanger CrossFinandCoppertube
HIC circuit (HIC: Heat Inter-Changer) HIC circuit
Defrosting method Reversed refrigerant circuit
Drawing External RK01B171
Wiring BH79J995
Standard attachment Document Installation Manual
Accessory Groundedleadwire×2
Optionalparts Joint:CMY-Y62-G-E
Header: CMY-Y64/68-G-E
Remarks *1 Nominal cooling conditions *2 Nominal heating conditions Unit converter
Indoor:
Outdoor:
Pipelength:
Level difference:
27°CD.B./19°CW.B.[81°FD.B/66°FW.B.]
35°CD.B.[95°FD.B.]
7.5m[24-9/16ft]
0m[0ft]
20°CD.B.[68°FD.B.]
7°CDB/6°CW.B.[45°FD.B./43°FW.B.]
7.5m[24-9/16ft]
0m[0ft]
kcal/h=kW×860
BTU/h=kW×3,412
cfm = m³/min × 35.31
lb = kg/0.4536
Abovespecicationdatais
subject to rounding variation.
*3 10 to 52 °C(D.B) :,whenconnectingfollowingmodels:PKFY-P15/20/25VBM,PFFY-P20/25/32VLE(R)M,PFFY-P20/25/32VKM,and
Mseries,Sseries,andPseriestypeindoorunitwithbranchbox,Mseriestypeindoorunitwithconnectionkit.
*4 −15to52 °C(D.B) :,whenusinganoptionalairprotectguide[PAC-SH95AG-E].However,thisconditiondoesnotapplytotheindoorunitlisted
in *3.
*5 UptoP100whenconnectingviabranchbox.
*6 Upto11unitswhenconnectingvia2branchboxes.
*7 Whenconnecting7indoorunitsviabranchbox,connectablecitymultiindoorunitsare3;connecting8indoorunitsviabranchbox,connectablecitymultiindoorunitsare2.
*8 94(207),forPUMY-SP112/125/140VKM(R1).TH-BS.
Notes :1. Nominal conditions *1, *2 are subject to ISO 15042.
2.Duetocontinuingimprovement,abovespecicationsmaybesubjecttochangewithoutnotice.

10
OCH668B
Model PUMY-SP112YKM(R1).TH(-BS) PUMY-SP125YKM.(R1)TH(-BS) PUMY-SP140YKM(R1).TH(-BS)
Powersource
3-phase380-400-415V,50Hz;3-phase380V,60Hz
380 400 415 380 400 415 380 400 415
50/60 50 50 50/60 50 50 50/60 50 50
Coolingcapacity
(Nominal)
kW*1 12.5 14.0 15.5
kcal/h*1 10,750 12,040 13,330
BTU/h*1 42,650 47,768 52,886
Powerinput kW 3.10 3.84 4.70
Currentinput A4.96 4.71 4.54 6.14 5.83 5.62 7.52 7.14 6.88
COP kW/kW 4.03 3.65 3.30
Temp.rangeofcooling
Indoortemp. W.B. 15 to 24°C
Outdoortemp. D.B. -5 to 52°C *3,*4
Heatingcapacity
(Nominal)
kW*2 14.0 16.0 16.5
kcal/h*2 12,040 13,760 14,190
BTU/h*2 47,768 54,592 56,298
Powerinput kW 3.17 3.90 4.02
Currentinput A 5.07 4.82 4.64 6.24 5.93 5.71 6.43 6.11 5.89
COP kW/kW 4.42 4.10 4.10
Temp.rangeofheating
Indoortemp. D.B. 15 to 27°C
Outdoortemp. W.B. -20 to 15°C
Indoor unit
connectable
Totalcapacity 50to130%ofoutdoorunitcapacity
Model/
Quantity
City multi 15-140/9 15-140/10 15-140/12
Branchbox 15-100/8 15-100/8 15-100/8
Mixed
system
Branchbox
1 unit
City multi 15-140/5 15-140/5 15-140/5
Branchbox 15-100/5 15-100/5 15-100/5
Branchbox
2 units
City multi 15-140/3 or 2 *7 15-140/3 15-140/3
Branchbox 15-100/7 or 8 *7 15-100/8 15-100/8
Soundpressurelevel
(measured in anechoic room) dB <A> 52/54 53/56 54/56
Powerpressurelevel
(measured in anechoic room) dB <A> 72/74 73/76 74/76
Refrigerantpiping
diameter
Liquidpipe mm (inch) 9.52(3/8)
Gaspipe mm (inch) 15.88 (5/8)
FAN *2
Type×Quantity PropellerFan×1
Airowrate
m³/min 77 83 83
L/s 1283 1383 1383
cfm 2719 2931 2931
Control, Driving mechanism DC control
Motoroutput kW 0.20 × 1
Externalstaticpress. 0
Compressor
Type×Quantity Twinrotaryhermeticcompressor×1
Manufacturer MitsubishiElectricCorporation
Starting method Inverter
Capacity
control %Cooling 26 to 100
Heating 20 to 100 Cooling 24 to 100 Heating 18 to 100 Cooling 21 to 100 Heating 17 to 100
Motoroutput kW 3.1 3.5 3.7
Case heater kW 0
Lubricant FV50S (1.4litter)
Externalnish GalvanizedSteelSheetMunsellNo.3Y7.8/1.1
ExternaldimensionH×W×D mm 981×1,050×330(+40)
inch 38-5/8 × 41-3/8 × 13 (+1-37/64)
Protection
devices
Highpressureprotection HighpressureSwitch
Inverter circuit (COMP./FAN) Overcurrent detection, Overheat detection(Heat sink thermistor)
Compressor Compressorthermistor,Overcurrentdetection
Fan motor Overheating,Voltageprotection
Refrigerant Type×originalcharge R410A 3.5 kg
Control Electronicexpansionvalve
Netweight kg (lb) 94(207)*8
Heatexchanger CrossFinandCoppertube
HIC circuit (HIC: Heat Inter-Changer) HIC circuit
Defrosting method Reversed refrigerant circuit
Drawing External RK01B171
Wiring BH79J996
Standard
attachment
Document Installation Manual
Accessory Groundedleadwire×2
Optionalparts Joint:CMY-Y62-G-E
Header: CMY-Y64/68-G-E
Remarks Unit converter
kcal/h=kW×860
BTU/h=kW×3,412
cfm = m³/min × 35.31
lb = kg/0.4536
Abovespecicationdatais
subject to rounding variation.
*1 Nominal cooling conditions
27°CD.B./19°CW.B.[81°FD.B/66°FW.B.]
35°CD.B.[95°FD.B.]
7.5m[24-9/16ft]
0m[0ft]
*2 Nominal heating conditions
20°CD.B.[68°FD.B.]
7°CDB/6°CW.B.[45°FD.B./43°FW.B.]
7.5m[24-9/16ft]
0m[0ft]
Indoor :
Outdoor :
Pipelength:
Level difference :
*310to52°C(D.B):,whenconnectingfollowingmodels:PKFY-P15/20/25VBM,PFFY-P20/25/32VLE(R)M,PFFY-P20/25/32VKM,and
Mseries,Sseries,andPseriestypeindoorunitwithbranchbox,Mseriestypeindoorunitwithconnectionkit.
*4−15to52 °C(D.B) :,whenusinganoptionalairprotectguide[PAC-SH95AG-E].However,thisconditiondoesnotapplytotheindoorunit
listed in *3.
*5UptoP100whenconnectingviabranchbox.
*6Upto11unitswhenconnectingvia2branchboxes.
*7Whenconnecting7indoorunitsviabranchbox,connectablecitymultiindoorunitsare3;connecting8indoorunitsviabranchbox,
connectable citymulti indoor units are 2.
*895(209),forPUMY-SP112/125/140YKM(R1).TH-BS.
Notes : 1. Nominal conditions *1, *2 are subject to ISO 15042.
 2.Duetocontinuingimprovement,abovespecicationsmaybesubjecttochangewithoutnotice.

11
OCH668B
4
Capacity of indoor unit
Model 20
Model Number
for indoor unit
2.2
Model 15
1.7
Model 25
2.8
Model 32
3.6
Model 40
4.5
Model 50
5.6
Model 63
7.1
Model 71
8.0
Model 80
9.0
Model 100
11.2
Model 125
14.0
Model 140
16.0
Model Capacity
2.01.5 2.2 2.5 3.5 4.2 5.0 6.0 7.1
P•FY Series
M Series
S Series
P Series
Model 20
Model Number
for indoor unit
[kW type]
Model 15 Model 22 Model 25 Model 35 Model 42 Model 50 Model 60 Model 71
1.8
Model 18
8.0
Model 80
10.0
Model 100
Model Capacity
DATA
Indoor Temperature [°CW.B.]
Ratio of cooling capacity
15 16 17 18 19 20 21 22 23 24
0.4
0.6
0.8
1.0
1.2
<Cooling>
Design Condition
Outdoor Design Dry Bulb Temperature 44.7ºC
Total Cooling Load 9.0 kW
Room1
Indoor Design Dry Bulb Temperature 27ºC
Indoor Design Wet Bulb Temperature 20ºC
Cooling Load 4.0 kW
Room2
Indoor Design Dry Bulb Temperature 24ºC
Indoor Design Wet Bulb Temperature 18ºC
Cooling Load 4.5 kW
<Other>
Indoor/Outdoor Equivalent Piping Length 60 m
1. Cooling Calculation
(1) Temporary Selection of Indoor Units
Room1
PEFY-P40 4.5 kW (Rated)
Room2
PEFY-P50 5.6 kW (Rated)
(2) Total Indoor Units Capacity
P40 + P50 = P90
(3) Selection of Outdoor Unit
The SP112 outdoor unit is selected as total indoor units capacity is P90
PUMY-SP112 12.5 kW
(4) Total Indoor Units Capacity Correction Calculation
Room1
Indoor Design Wet Bulb Temperature Correction (20ºC)
1.03 (Refer to Figure 1)
Figure 1 Indoor unit temperature correction
To be used to correct indoor unit only
Figure 2 Outdoor unit temperature correction
To be used to correct outdoor unit only
Figure 3 Correction of refrigerant piping length
Room2
Indoor Design Wet Bulb Temperature Correction (18ºC)
0.94 (Refer to Figure 1)
CTi = Σ (Indoor Unit Rating × Indoor Design Temperature Correction)
= 4.5 × 1.03 + 5.6 × 0.94
= 9.9 kW
(5) Outdoor Unit Correction Calculation
Outdoor Design Dry Bulb Temperature Correction (44.7ºC)
0.88 (Refer to Figure 2)
Piping Length Correction (60 m) 0.88 (Refer to Figure 3)
Total Outdoor Unit Capacity (CTo)
Total Indoor Units Capacity (CTi)
CTo = Outdoor Rating × Outdoor Design Temperature Correction × Piping Length Correction
= 12.5 × 0.88 × 0.88
= 9.7 kW
(6) Determination of Maximum System Capacity
Comparison of Capacity between Total Indoor Units Capacity (CTi) and Total Outdoor Unit Capacity (CTo)
CTi = 9.9 > CTo = 9.7, thus, select CTo.
CTx = CTo = 9.7 kW
(7) Comparison with Essential Load
Against the essential load 9.0kW, the maximum system capacity is 9.7 kW: Proper outdoor units have been selected.
(8) Calculation of Maximum Indoor Unit Capacity of Each Room
CTx = CTo, thus, calculate by the calculation below
Room1
Maximum Capacity × Room1 Capacity after the Temperature Correction/(Room1,2 Total Capacity after the Temperature Correction
= 9.7 × (4.5 × 1.03)/(4.5 × 1.03 + 5.6 × 0.94)
= 4.5 kW OK: fulfills the load 4.0 kW
Room2
Maximum Capacity × Room2 Capacity after the Temperature Correction/(Room1,2 Total Capacity after the Temperature Correction)
= 9.7 × (5.6 × 0.94)/(4.5 × 1.03 + 5.6 × 0.94)
= 5.1 kW OK: fulfills the load 4.5 kW
Go on to the heating trial calculation since the selected units fulfill the cooling loads of Room 1, 2.
Note: If CTx = CTi, please refer to the <Heating> section to calculate the Maximum Indoor Unit Capacity of Each Room.
0 20 40 60 80
0.50
0.55
0.60
0.65
0.70
0.75
0.80
0.85
0.90
0.95
1.00
11.6
7.8
15.5
20.2
Capacity ratio
Piping equivalent length (m)
Total capacity of indoor unit
4-1. SELECTION OF COOLING/HEATING UNITS
Ratio of cooling capacity
Outdoor Temperature [°C D.B.]
Indoor Temperature
-15 -10 -5 0 5 10 15 20 25 30 35 40 45 50
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
19°C W.B

12
OCH668B
Capacity of indoor unit
Model 20
Model Number
for indoor unit
2.5
Model 15
1.9
Model 25
3.2
Model 32
4.0
Model 40
5.0
Model 50
6.3
Model 63
8.0
Model 71
9.0
Model 80
10.0
Model 100
12.5
Model 125
16.0
Model 140
18.0
Model Capacity
2.3 2.5 2.9 4.0 4.8 5.7 6.9 8.1
P•FY Series
M Series
S Series
P Series
Model 20
Model Number
for indoor unit
[kW type]
Model 22 Model 25 Model 35 Model 42 Model 50 Model 60 Model 71
9.3
Model 80
11.2
Model 100
2.1
Model 18
1.7
Model 15
Model Capacity
<Heating>
Design Condition
Outdoor Design Wet Bulb Temperature 2ºC
Total Heating Load 10.3 kW
Room1
Indoor Design Dry Bulb Temperature 21ºC
Heating Load 4.8 kW
Room2
Indoor Design Dry Bulb Temperature 23ºC
Heating Load 5.5 kW
<Other>
Indoor/Outdoor Equivalent Piping Length 100 m
2. Heating Calculation
(1) Temporary Selection of Indoor Units
Room1
PEFY-P40 5.0 kW (Rated)
Room2
PEFY-P50 6.3 kW (Rated)
(2) Total Indoor Units Capacity
P40 + P50 = P90
(3) Selection of Outdoor Unit
The SP112 outdoor unit is selected as total indoor units capacity is P90
PUMY-SP112 14.0 kW
(4) Total Indoor Units Capacity Correction Calculation
Room1
Indoor Design Dry Bulb Temperature Correction (21ºC)
0.96 (Refer to Figure 4)
Table 1 Table of correction factor at frost and defrost
Room2
Indoor Design Dry Bulb Temperature Correction (23ºC)
0.88 (Refer to Figure 4)
CTi = Σ (Indoor Unit Rating × Indoor Design Temperature Correction)
= 5.0 × 0.96 + 6.3 × 0.88
= 10.3 kW
(5) Outdoor Unit Correction Calculation
Outdoor Design Wet Bulb Temperature Correction (2ºC)
1.0 (Refer to Figure 5)
Piping Length Correction (100 m)
Defrost Correction
0.94 (Refer to Figure 6)
0.89 (Refer to Table 1)
Total Outdoor Unit Capacity (CTo)
Total Indoor Units Capacity (CTi)
CTo = Outdoor Unit Rating ×Outdoor Design Temperature Correction ×Piping Length
Correction ×Defrost Correction
= 14.0 × 1.0 × 0.94 × 0.89
= 11.7 kW
(6) Determination of Maximum System Capacity
Comparison of Capacity between Total Indoor Units Capacity (CTi) and Total Outdoor Unit Capacity (CTo)
CTi = 10.3 < CTo = 11.7, thus, select CTi.
CTx = CTi = 10.3 kW
(7) Comparison with Essential Load
Against the essential load 10.3kW, the maximum system capacity is 10.3 kW: Proper indoor units have been selected.
(8) Calculation of Maximum Indoor Unit Capacity of Each Room
CTx = CTo, thus, calculate by the calculation below
Room1
Indoor Unit Rating ×Indoor Design Temperature Correction
= 5.0 × 0.96
= 4.8 kW OK: fulfills the load 4.8 kW
Room2
Indoor Unit Rating ×Indoor Design Temperature Correction
= 6.3× 0.88
= 5.5 kW OK: fulfills the load 5.5 kW
Completed selecting units since the selected units fulfill the heating loads of Room 1, 2.
Figure 4 Indoor unit temperature correction
To be used to correct indoor unit only
Figure 5 Outdoor unit temperature correction
To be used to correct outdoor unit only
Figure 6 Correction of refrigerant piping length
1
0.90
0.80
0.95
0.85
0.75
0.65
0.70
200 40 60 80 100 120 140 160 180 200
Heating capacity correction factor
Piping equivalent length (m)
15 16 17 18 19 20 21 22 23 24 25 26 27
0.6
0.7
0.8
0.9
1.0
1.1
1.2
Ratio of heating capacity
Indoor Temperature [°CD.B.]
−20 −15 −10 −5 0 5 10 15
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
Ratio of heating capacity
Outdoor Temperature [°C W.B.]
20°C D.B
Note: If CTx = CTo, please refer to the <Cooling> section to calculate the Maximum Indoor Unit Capacity of Each Room.
Outdoor inlet air temp. °C 6 4 2 0 −2−4−6−8−10 −15 −20
PUMY-SP112,125,140VKM 1.0 0.98 0.89 0.88 0.89 0.90 0.95 0.95 0.95 0.95 0.95
PUMY-SP112,125,140YKM 1.0 0.98 0.89 0.88 0.89 0.90 0.95 0.95 0.95 0.95 0.95

13
OCH668B
4-2. CORRECTION BY TEMPERATURE
15 16 17 18 19 20 21 22 23 24
0.4
0.6
0.8
1.0
1.2
Ratio of cooling capacity
Indoor Temperature [°CW.B.]
15.0 16.0 18.0 19.0 20.0 22.0 24.0
0.777 0.832 0.944 1.000 1.030 1.091 1.151
Ratio of cooling capacity
Outdoor Temperature [°C D.B.]
Indoor Temperature
-15 -10 -5 0 5 10 15 20 25 30 35 40 45 50
0.2
0.3
0.4
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
1.3
19°C W.B
CITYMULTIcouldhavevariedcapacityatdifferentdesigningtemperature.Usingthenominalcoolingcapacityvalueandthe
ratiobelow,thecapacitycanbeobservedatvarioustemperature.
PUMY-SP•V(Y)KM.TH(-BS)
112 125 140
Nominal
cooling
capacity
kW 12.5 14.0 15.5
BTU/h 42,700 47,800 52,900
Input kW 3.10 3.84 4.70
Figure 7 Indoor unit temperature correction
Tobeusedtocorrectindoorunitcapacityonly
Figure 8 Outdoor unit temperature correction
Tobeusedtocorrectoutdoorunitcapacityonly
<Cooling>
PUMY-SP•VKM(-BS), PUMY-SP•YKM(-BS)
Continuetothenextpage

14
OCH668B
Ratio of power input
Outdoor Temperature [°C D.B.]
Indoor Temperature
-15 -10 -5 0 5 10 15 20 25 30 35 40 45 50 55
0.0
0.2
0.4
0.6
0.8
1.0
1.2
1.4
16°C W.B
18°C W.B
19°C W.B
20°C W.B
24°C W.B
22°C W.B
PUMY-SP112VKM.TH(-BS), PUMY-SP112YKM.TH(-BS)
PUMY-SP112VKMR1.TH(-BS), PUMY-SP112YKMR1.TH(-BS)
PUMY-SP125VKM.TH(-BS), PUMY-SP125YKM.TH(-BS)
PUMY-SP125VKMR1.TH(-BS), PUMY-SP125YKMR1.TH(-BS)
Ratio of power input
Outdoor Temperature [°C D.B.]
Indoor Temperature
-15 -10 -5 0 5 10 15 20 25 30 35 40 45 50 55
0.0
0.2
0.4
0.6
0.8
1.0
1.2
16°C W.B
18°C W.B
19°C W.B
24°C W.B
22°C W.B
20°C W.B
PUMY-SP140VKM.TH(-BS), PUMY-SP140YKM.TH(-BS)
PUMY-SP140VKMR1.TH(-BS), PUMY-SP140YKMR1.TH(-BS)
Figure 9 Outdoor unit temperature correction
Tobeusedtocorrectoutdoorunitcapacityonly

15
OCH668B
Figure11 Outdoor unit temperature correction
Tobeusedtocorrectoutdoorunitcapacityonly
<Heating>
15 16 17 18 19 20 21 22 23 24 25 26 27
0.6
0.7
0.8
0.9
1.0
1.1
1.2
Ratio of heating capacity
Indoor Temperature [°CD.B.]
Ratio of heating capacity
Outdoor Temperature [°C W.B.]
20°C D.B
-20.0 -15.0 -10.0 -5.0 0.0 5.0 10.0 15.0
0.5
0.6
0.7
0.8
0.9
1.0
1.1
1.2
Ratio of power input
Outdoor Temperature [°C W.B.]
Indoor Temperature
-20 -15 -10 -5 0 5 10 15
0.2
0.4
0.6
0.8
1.0
1.2
25°C D.B
15°C D.B
20°C D.B
27°C D.B
1.4
Figure 10 Indoor unit temperature correction
Tobeusedtocorrectindoorunitcapacityonly
PUMY-SP・V(Y)KM.TH(-BS)
112 125 140
Nominal
heating
capacity
kW 14.0 16.0 16.5
BTU/h 47,768 54,592 56,298
Input kW 3.17 3.90 4.02

16
OCH668B
Operation
PUMY-SP112VKM.TH(-BS)
PUMY-SP112VKMR1.TH(-BS)
PUMY-SP112YKM.TH(-BS)
PUMY-SP112YKMR1.TH(-BS)
PUMY-SP125VKM.TH(-BS)
PUMY-SP125VKM R1 .TH(-BS)
PUMY-SP125YKM.TH(-BS)
PUMY-SP125YKM R1 .TH(-BS)
PUMY-SP140VKM .TH (-BS)
PUMY-SP140VKM R1.TH (-BS)
PUMY-SP140YKM .TH (-BS)
PUMY-SP140YKM R1.TH (-BS)
Operating
conditions
Ambient
temperature
Indoor DB/
WB
27/19°C 20°C 27/19°C 20°C 27/19°C 20°C
Outdoor 35°C 7/6°C 35°C 7/6°C 35°C 7/6°C
Indoor unit
No. of connected units Unit 4 4 4
No. of units in operation 4 4 4
Model — 25×2+32×2 25×1 + 32×3 32×2 + 40×2
Piping
Main pipe
m
5 5 5
Branch pipe 2.5 2.5 2.5
Total pipe length 15 15 15
Fan speed — Hi Hi Hi
Amount of refrigerant kg 6.5 6.5 6.5
Outdoor unit
Electric current A 15.69 14.88 18.78 18.38 22.27 19.62
Voltage V 230 230 230 230 230 230
Compressor frequency Hz 57 74 65 84 73 88
LEV opening Indoor unit Pulse 226 396 264 335 262 358
Pressure High pressure/Low pressure MPaG 2.96/1.08 1.93/0.63 3.12/1.02 2.06/0.60 3.25/0.99 2.08/0.60
Temp. of
each section
Outdoor
unit
Discharge
°C
67.6 43.1 81.6 46.4 83.9 47.6
Heat exchanger outlet 48.5 2.0 49.9 1.3 51.2 -0.3
Accumulator inlet 14.8 -1.2 17.6 -2.0 15.4 -2.4
Compressor inlet 15.7 -1.6 19.6 -2.7 17.5 -2.8
Indoor unit LEV inlet 30.6 25.2 32.7 44.6 33.7 45.0
Heat exchanger inlet 16.6 39.2 14.5 24.4 14.3 26.5
4-3. STANDARD OPERATION DATA (REFERENCE DATA)

17
OCH668B
Current(A) Capacity(kW)
Total capacity of indoor units(kW)
Total capacity of indoor units(kW)
Total capacity of indoor units(kW)
Total capacity of indoor units(kW)
Current(A) Input(kW)
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0 20.0
2.0
4.0
6.0
8.0
10.0
12.0
14.0
16.0
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0 20.0
0.0
5.0
10.0
15.0
20.0
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0 20.0
1.0
2.0
3.0
4.0
5.0
6.0
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0 20.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
V-Type
220V
230V
240V
380V
400V
415V
Y-Type
4-4-1. PUMY-SP112VKM.TH(-BS) PUMY-SP112YKM.TH(-BS) <cooling>
PUMY-SP112VKMR1.TH(-BS) PUMY-SP112YKMR1.TH(-BS)
 Beforecalculatingthesumoftotalcapacityofindoorunits,pleaseconvertthevalueintothekWmodelcapacityfollowingtheformulaon
 "4-1-1.Methodforobtainingsystemcoolingcapacity".
4-4. STANDARD CAPACITY DIAGRAM

18
OCH668B
4-4-2. PUMY-SP112VKM.TH(-BS) PUMY-SP112YKM.TH(-BS) <heating>
PUMY-SP112VKMR1.TH(-BS) PUMY-SP112YKMR1.TH(-BS)
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0 20.0
1.0
2.0
3.0
4.0
5.0
6.0
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0 20.0
0
5.0
10.0
15.0
20.0
Y-Type
Current(A)
Total capacity of indoor units(kW)
Current(A) Input(kW)
V-Type
220V
230V
240V
380V
400V
415V
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0 20.0
2.0
4.0
6.0
8.0
10.0
12.0
14.0
16.0
Capacity(kW)
Total capacity of indoor units(kW)
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0 20.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
Total capacity of indoor units(kW)
Total capacity of indoor units(kW)

19
OCH668B
4-4-3. PUMY-SP125VKM.TH(-BS) PUMY-SP125YKM.TH(-BS) <cooling>
PUMY-SP125VKMR1.TH(-BS) PUMY-SP125YKMR1.TH(-BS)
 Beforecalculatingthesumoftotalcapacityofindoorunits,pleaseconvertthevalueintothekWmodelcapacityfollowingtheformulaon
"4-1-1.Methodforobtainingsystemcoolingcapacity".
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0 20.0
0.0
5.0
10.0
15.0
20.0
Current(A) Capacity(kW)
Total capacity of indoor units(kW)
Total capacity of indoor units(kW)
Total capacity of indoor units(kW)
Total capacity of indoor units(kW)
Current(A) Input(kW)
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0 20.0
2.0
4.0
6.0
8.0
10.0
12.0
14.0
16.0
18.0
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0 20.0
1.0
2.0
3.0
4.0
5.0
6.0
7.0
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0 20.0
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
V-Type
220V
230V
240V
380V
400V
415V
Y-Type

20
OCH668B
4-4-4. PUMY-SP125VKM.TH(-BS) PUMY-SP125YKM.TH(-BS) <heating>
PUMY-SP125VKMR1.TH(-BS) PUMY-SP125YKMR1.TH(-BS)
2 4 6 8 10 12 14 16 18 20
1
2
3
4
5
6
7
2 4 6 8 10 12 14 16 18 20
0
5
10
15
20
Y-Type
Current(A)
Total capacity of indoor units(kW)
Current(A) Input(kW)
V-Type
220V
230V
240V
380V
400V
415V
2.0 4.0 6.0 8.0 10.0 12.0 14.0 16.0 18.0 20.0
2.0
4.0
6.0
8.0
10.0
12.0
14.0
16.0
18.0
Capacity(kW)
Total capacity of indoor units(kW)
2 4 6 8 10 12 14 16 18 20
0.5
1.0
1.5
2.0
2.5
3.0
3.5
4.0
Total capacity of indoor units(kW)
Total capacity of indoor units(kW)
