SERVICE MANUAL
SPLIT-TYPE,HEAT PUMP AIR CONDITIONERS
CONTENTS
1. TECHNICAL CHANGES ····································2
2. OUTLINES AND DIMENSIONS ························ 2
3. PARTS LIST ·······················································3
Wireless type
Models
MSH-07NV22-(WH)· MUH-07NV -
MSH-09NV22-(WH)· MUH-09NV -
MSH-12NV22-(WH)· MUH-12NV -
E2E1
E2E1
E2E1
No. OB215
MSH-09NV22-E1
NOTE:This Service Manual covers only change points. (MSH-07/09/12NV- ➔MSH-07/09/12NV2-)
Please refer to the Service Manual OB207 for unchanged contents.
Please refer to the Service Manual OB207 for MUH-07/09/12NV- .
Please refer to the Service Manual OB185 REVISED EDITION A when MSH-07/09/12NV2- are
connected with MXZ-32NV- / as multi system units.
E2E1
E1
E2
E1E2

2
TECHNICAL CHANGES
MSH-07NV - ➔MSH-07NV@@-
1. Indoor unit design has changed.
MSH-09NV - ➔MSH-09NV@@-
1. Indoor unit design has changed.
MSH-12NV - ➔MSH-12NV@@-
1. Indoor unit design has changed.
E1E2
E1E2
E1E2
1
OUTLINES AND DIMENSIONS
2
MSH-07NV22- MSH-09NV22- MSH-12NV22-E1E1E1
INDOOR UNIT
314.5323
2.5 186
191
223
266.5
46
41
225
84.5
9
133.5
84.5
225
93
183
13062560
275
815
17.5
783
72
7 or more
100
90
5
160
56
Liquid line {6.35-0.5m
Gas line {9.52-0.43m
Insulation {35 O.D
{19 I.D
Wireless remote controller
Power supply cord
Lead to right 1.0m
Lead to left 0.3m
Installation plate
Indoor unit
Wall hole {65
Installation plate
Drain hose {16
Insulation {28
Air out
{
Air in
Unit: mm

3
3 PARTS LIST
1
2
3
4
5
6
E02 346 000
E02 347 000
E02 348 000
E02 339 010
E02 164 100
E02 166 234
E02 151 970
E02 166 067
FRONT PANEL(WH)
FRONT PANEL(WH)
FRONT PANEL(WH)
GRILLE(WH)
AIR FILTER
BOX(WH)
INSTALLATION PLATE
SCREW CAP(WH)
Symbol
in Wiring
Diagram
Q'ty/unit
1
1
2
1
1
2
1
1
2
1
1
2
2PCS/SET
RemarksPart No. NO. Part Name
MSH-07NV@- E1
(WH) MSH-09NV@- E1 (WH) MSH-12NV@- E1 (WH)
1
1
2
1
1
2
Optional parts
3
4
5
1
6
2
INDOOR UNIT
STRUCTURAL PARTS
MSH-07NV22- (WH)
MSH-09NV22- (WH)
MSH-12NV22- (WH)
E1
E1
E1
E02 151 620
E02 155 620
E02 151 666
E02 155 666
E02 151 667
1
2
3
INDOOR HEAT EXCHANGER
INDOOR HEAT EXCHANGER
UNION(GAS)
UNION(GAS)
UNION(LIQUID)
Symbol
in Wiring
Diagram
Q'ty/unit
1
1
1
1
1
1
{9.52
{12.7
{6.35
RemarksPart No.
NO. Part Name MSH-07/09NV@-
(WH) E1 MSH-12NV@- (WH) E1
1
2
3
INDOOR UNIT
HEAT EXCHANGER
MSH-07NV22- (WH)
MSH-09NV22- (WH)
MSH-12NV22- (WH)
E1
E1
E1
wAset of FRONT PANEL and GRILLE of NV2series is compatible with that of NV series.

E02 199 235
E02 166 040
E02 141 702
E02 151 303
E02 151 300
E02 151 505
E02 151 302
E02 151 509
E02 151 308
E02 151 307
E02 198 375
E02 199 452
E02 200 452
E02 201 452
E02 152 395
E02 127 382
E02 085 385
E02 001 504
E02 151 468
E02 199 520
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
16
17
18
NOZZLE(WH)
VANE(WH)
DRAIN HOSE
VANE MOTOR
INDOOR FAN MOTOR
RUBBER MOUNT
LINE FLOW FAN
BEARING MOUNT
ROOM TEMPERATURE THERMISTOR
INDOOR COIL THERMISTOR
TERMINAL BLOCK
ELECTRONIC CONTROL P.C.BOARD
ELECTRONIC CONTROL P.C.BOARD
ELECTRONIC CONTROL P.C.BOARD
POWER SUPPLY CORD
FUSE
VARISTOR
SLEEVE BEARING
RECEIVER
FAN GUARD
RC4V19 -
2PCS/SET
AUTO RESTART
AUTO RESTART
AUTO RESTART
3.15A
MV
MF
RT11
RT12
TB
F11
NR11
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
1
2
1
1
1
1
1
1
1
1
1
1
1
1
Symbol
in Wiring
Diagram
Q'ty/unit RemarksPart No.
NO. Part Name MSH-07NV@-
(WH) E1 MSH-09NV@- (WH) E1 MSH-12NV@- (WH) E1
Part number that are circled is not shown in the illustration.
12
13
1
4
2
5
6
7
3
16
8
910
INDOOR UNIT
ELECTRICAL PARTS
MSH-07NV22- (WH)
MSH-09NV22- (WH)
MSH-12NV22- (WH)
E1
E1
E1
11
