Mitsubishi Electric Mr. Slim PCA-M KA Series User manual

Air Conditioners
Кондиционеры
Кондиционерлер
Օդորակիչներ
Кондиціонери
PCA-M·KA Series
ОРНАТУ БОЙЫНША НҰСҚАУЛЫҚ
Қауіпсіз және дұрыс пайдалану үшін кондиционер блогын орнатпас бұрын осы нұсқаулықты және сыртқы
блокты орнату бойынша нұсқаулықты мұқият оқып шығыңыз.
ՏԵՂԱԴՐՄԱՆ ՁԵՌՆԱՐԿ
Նախքան օդորակչի բլոկը տեղադրելը շադիր կարդացեք այս և արտաքին բլոկի տեղադրման
ձեռնարկները՝ անվտանգ և ճիշտ կիրառման համար:
INSTALLATION MANUAL
For safe and correct use, read this manual and the outdoor unit installation manual thoroughly before installing
the air-conditioner unit.
РУКОВОДСТВО ПО УСТАНОВКЕ
Для обеспечения безопасной и надлежащей эксплуатации внимательно прочтите данное руководство и
руководство по установке наружного прибора перед установкой кондиционера.
ПОСІБНИК З УСТАНОВЛЕННЯ
Для правильної та безпечної експлуатації зовнішнього блока обов’язково перед його встановленням
прочитайте посібник з установлення.
ДЛЯ СПЕЦІАЛІСТА З МОНТАЖУ
Українська
Հայերեն
ДЛЯ УСТАНОВИТЕЛЯ
Қазақ
Русский
FOR INSTALLER
English
ОРНАТУШЫ ҮШІН
ՏԵՂԱԴՐՈՂԻ ՀԱՄԱՐ
BT79D079H01_01en.indd 1 2021/02/24 11:38:53
001

1
Contents
1. Safety precautions .....................................................................................1
2. Installation location ....................................................................................2
3. Installing the indoor unit ............................................................................3
4. Installing the refrigerant piping ..................................................................5
5. Drainage piping work .................................................................................6
6. Electrical work ...........................................................................................6
7. Test run ....................................................................................................12
8. Easy maintenance function .....................................................................16
1. Safety precautions
Note:
The phrase “Wired remote controller” in this installation manual refers to the PAR-41MAA. If you need any information for other remote controller, please
refer to the installation manual that is included with the optional remote controller.
► Before installing the unit, make sure you read all the “Safety Precautions”.
► The “Safety Precautions” provide very important points regarding safety. Make sure you follow them.
► Please report to your supply authority or obtain their consent before connecting this equipment to the power supply system.
Symbols used in the text
Warning:
Describes precautions that should be observed to prevent danger of injury or
death to the user.
Caution:
Describes precautions that should be observed to prevent damage to the unit.
Symbols used in the illustrations
: Indicates a part which must be grounded.
: Be sure not to do.
After installation work has been completed, explain the “Safety Precautions,” use,
and maintenance of the unit to the customer according to the information in the
Operation Manual and perform the test run to ensure normal operation. Both the
Installation Manual and Operation Manual must be given to the user for keeping.
These manuals must be passed on to subsequent users.
MEANINGS OF SYMBOLS DISPLAYED ON INDOOR UNIT AND/OR OUTDOOR UNIT
WARNING
(Risk of re)
This mark is for R32 refrigerant only. Refrigerant type is written on nameplate of outdoor unit.
In case that refrigerant type is R32, this unit uses a ammable refrigerant.
If refrigerant leaks and comes in contact with re or heating part, it will create harmful gas and there is risk of re.
Read the OPERATION MANUAL carefully before operation.
Service personnel are required to carefully read the OPERATION MANUAL and INSTALLATION MANUAL before operation.
Further information is available in the OPERATION MANUAL, INSTALLATION MANUAL, and the like.
Warning:
• Carefully read the labels afxed to the main unit.
• Ask a dealer or an authorized technician to install, relocate and repair the
unit.
• The user should never attempt to repair the unit or transfer it to another loca-
tion.
• For installation and relocation work, follow the instructions in the Installation
Manual and use tools and pipe components specically made for use with
refrigerant specied in the outdoor unit installation manual.
• The unit must be installed according to the instructions in order to mini-
mize the risk of damage from earthquakes, typhoons, or strong winds. An
incorrectly installed unit may fall down and cause damage or injuries.
• Do not alter the unit. It may cause re, electric shock, injury or water leak-
age.
• The unit must be securely installed on a structure that can sustain its
weight.
• The appliance shall be stored in a well-ventilated area where the room size
corresponds to the room area as specied for operation.
• If the air conditioner is installed in a small room or closed room, measures
must be taken to prevent the refrigerant concentration in the room from
exceeding the safety limit in the event of refrigerant leakage. Should the
refrigerant leak and cause the concentration limit to be exceeded, hazards
due to lack of oxygen in the room may result.
• Keep gas-burning appliances, electric heaters, and other re sources (igni-
tion sources) away from the location where installation, repair, and other air
conditioner work will be performed.
If refrigerant comes into contact with a ame, poisonous gases will be
released.
• Ventilate the room if refrigerant leaks during operation. If refrigerant comes
into contact with a ame, poisonous gases will be released.
• All electric work must be performed by a qualied technician according to
local regulations and the instructions given in this manual.
• Do not use intermediate connection of the electric wires.
• Use only specied cables for wiring. The wiring connections must be made
securely with no tension applied on the terminal connections. Also, never
splice the cables for wiring (unless otherwise indicated in this document).
Failure to observe these instructions may result in overheating or a re.
• When installing or relocating, or servicing the air conditioner, use only the
specied refrigerant written on outdoor unit to charge the refrigerant lines.
Do not mix it with any other refrigerant and do not allow air to remain in the
lines.
If air is mixed with the refrigerant, then it can be the cause of abnormal high
pressure in the refrigerant line, and may result in an explosion and other
hazards.
The use of any refrigerant other than that specied for the system will
cause mechanical failure or system malfunction or unit breakdown. In the
worst case, this could lead to a serious impediment to securing product
safety.
• The appliance shall be installed in accordance with national wiring regula-
tions.
• This appliance is not intended for use by persons (including children) with
reduced physical, sensory or mental capabilities, or lack of experience and
knowledge, unless they have been given supervision or instruction con-
cerning use of the appliance by a person responsible for their safety.
• Children should be supervised to ensure that they do not play with the ap-
pliance.
• The terminal block cover panel of the unit must be rmly attached.
• If the supply cord is damaged, it must be replaced by the manufacturer, its
service agent or similarly qualied persons in order to avoid a hazard.
• Use only accessories authorized by Mitsubishi Electric and ask a dealer or
an authorized technician to install them.
• After installation has been completed, check for refrigerant leaks. If refrig-
erant leaks into the room and comes into contact with the ame of a heater
or portable cooking range, poisonous gases will be released.
• Do not use means to accelerate the defrosting process or to clean, other
than those recommended by the manufacturer.
• The appliance shall be stored in a room without continuously operating
ignition sources (for example: open ames, an operating gas appliance or
an operating electric heater).
• Do not pierce or burn.
• Be aware that refrigerants may not contain an odour.
• Pipe-work shall be protected from physical damage.
• The installation of pipe-work shall be kept to a minimum.
• Compliance with national gas regulations shall be observed.
• Keep any required ventilation openings clear of obstruction.
• Do not use low temperature solder alloy in case of brazing the refrigerant
pipes.
• When performing brazing work, be sure to ventilate the room sufciently.
Make sure that there are no hazardous or ammable materials nearby.
When performing the work in a closed room, small room, or similar loca-
tion, make sure that there are no refrigerant leaks before performing the
work.
If refrigerant leaks and accumulates, it may ignite or poisonous gases may
be released.
en
BT79D079H01_01en.indd 1 2021/02/24 11:38:53
002

2
1.1. Before installation (Environment)
Caution:
• Do not use the unit in an unusual environment. If the air conditioner is installed
in areas exposed to steam, volatile oil (including machine oil), or sulfuric gas,
areas exposed to high salt content such as the seaside, the performance can
be signicantly reduced and the internal parts can be damaged.
• Do not install the unit where combustible gases may leak, be produced, ow,
or accumulate. If combustible gas accumulates around the unit, re or explo-
sion may result.
• Do not keep food, plants, caged pets, artwork, or precision instruments in the
direct airow of the indoor unit or too close to the unit, as these items can be
damaged by temperature changes or dripping water.
• When the room humidity exceeds 80% or when the drainpipe is clogged,
water may drip from the indoor unit. Do not install the indoor unit where such
dripping can cause damage.
• When installing the unit in a hospital or communications ofce, be prepared for
noise and electronic interference. Inverters, home appliances, high-frequency
medical equipment, and radio communications equipment can cause the air
conditioner to malfunction or breakdown. The air conditioner may also affect
medical equipment, disturbing medical care, and communications equipment,
harming the screen display quality.
1.2. Before installation or relocation
Caution:
• Be extremely careful when transporting the units. Two or more persons
are needed to handle the unit, as it weighs 20 kg or more. Do not grasp the
packaging bands. Wear protective gloves as you can injure your hands on
the ns or other parts.
• Be sure to safely dispose of the packaging materials. Packaging materials,
such as nails and other metal or wooden parts may cause stabs or other
injuries.
• Thermal insulation of the refrigerant pipe is necessary to prevent condensa-
tion. If the refrigerant pipe is not properly insulated, condensation will be
formed.
1.3. Before electric work
Caution:
• Be sure to install circuit breakers. If not installed, electric shock may result.
• For the power lines, use standard cables of sufcient capacity. Otherwise, a
short circuit, overheating, or re may result.
• When installing the power lines, do not apply tension to the cables.
• Be sure to ground the unit. If the unit is not properly grounded, electric shock
may result.
1.4. Before starting the test run
Caution:
• Turn on the main power switch more than 12 hours before starting operation.
Starting operation just after turning on the power switch can severely damage
the internal parts.
• Before starting operation, check that all panels, guards and other protective
parts are correctly installed. Rotating, hot, or high voltage parts can cause
injuries.
• Do not operate the air conditioner without the air lter set in place. If the air
lter is not installed, dust may accumulate and breakdown may result.
• Do not touch any switch with wet hands. Electric shock may result.
• Do not touch the refrigerant pipes with bare hands during operation.
• After stopping operation, be sure to wait at least ve minutes before turning
off the main power switch. Otherwise, water leakage or breakdown may result.
• Place thermal insulation on the pipes to prevent condensation. If the drain-
pipe is installed incorrectly, water leakage and damage to the ceiling, oor,
furniture, or other possessions may result.
• Do not clean the air conditioner unit with water. Electric shock may result.
• Tighten all are nuts to specication using a torque wrench. If tightened too
much, the are nut can break after an extended period.
• Use circuit breakers (ground fault interrupter, isolating switch (+B fuse), and
molded case circuit breaker) with the specied capacity. If the circuit breaker
capacity is larger than the specied capacity, breakdown or re may result.
1. Safety precautions
2. Installation location
(mm)
W
Fig. 2-1
2.1. Outline dimensions (Indoor unit) (Fig. 2-1)
Select a proper position allowing the following clearances for installation and main-
tenance.
(mm)
Models W
M35, 50 960
M60, 71 1280
M100, 125, 140 1600
Warning:
Mount the indoor unit on a ceiling strong enough to withstand the weight of
the unit.
2.2. Outline dimensions (Outdoor unit)
Refer to the outdoor unit installation manual.
Min.300
Max. 250
Min. 270
Min. 500
Min. 2200
en
BT79D079H01_01en.indd 2 2021/02/24 11:38:54
003

3
3. Installing the indoor unit
123
456
7 8
A
A
BC
D
F
H
G
J
E
236
B
2
75
80320
680
2
19046
6
233
246 C
D
233
246
IF
E
E
H G
H
G
86 285
138
126
19046
3.1. Check the indoor unit accessories (Fig. 3-1)
The indoor unit should be supplied with the following accessories
(contained in the inside of the intake grille).
Accessory name Q’ty
1Washer 4 pcs
2Pipe cover 1 pc Large size (For gas tubing)
3Pipe cover 1 pc Small size (For liquid tubing)
4Band 4 pcs
5Joint socket 1 pc Marked with “UNIT”
6Socket cover 1 pc
7Drain tubing cover 1 pc
8Flare nut 1 pc ø6.35 (M60 only)
3.2. Preparation for installation (Fig. 3-2)
3.2.1. Suspension bolt installing spacing
(mm)
Models AB
M35, 50 917 960
M60, 71 1237 1280
M100, 125, 140 1557 1600
3.2.2. Refrigerant and drain tubing location
(mm)
Models CD
M35, 50 184 203
M60 179 203
M71-140 180 200
A Front side outlet F Left drain tubing
B Left side outlet G Gas tubing
C Right side outlet H Liquid tubing
D Independent piece (Removable) I Rubber plug
E Right drain tubing J with Joint socket 5
In case of the rear pipe arrangement, make sure to remove the shaded portions from
the D independent piece. Then put the D independent piece back in initial position.
(The heat exchanger might be clogged because of dust)
Fig. 3-1
UNIT
Fig. 3-2
(mm)
en
BT79D079H01_01en.indd 3 2021/02/24 11:38:54
004

4
3. Installing the indoor unit
(mm)
(mm)
B
AD
E
H
G
2
J
L
KM
C
1F
(mm)
a g
e
g
e
f
b
10 –20
dc
e
g
A
a
b
B
D
E
A
C
B
125
175
190
70
80 ø65 ø100
7~12
B
C
A
D
E
F
A
G
C
3.3. Installing the indoor unit (Fig. 3-5)
Use a proper suspending method depending on the presence or absence of ceiling
materials as follows.
A In the presence of ceiling materials c Ceiling
B In the absence of ceiling materials d Suspending bolt
a Suspending bracket e Washer 1
b Unit f Washer (Local procurement)
g Double nuts
1) Directly suspending the unit
Installing procedures
1. Install the washer 1 (supplied with the unit) and the nuts (to be locally procured).
2. Set (hook) the unit through the suspending bolts.
3. Tighten the nuts.
Check the unit installing condition.
• Check that the unit is horizontal between the right and left sides.
• Check that the front and the rear of suspending brackets are horizontal.
(To keep drainage,the unit is inclined to the suspending brackets. The unit slopes
continuously downward from the front to the rear is the right installation position.)
2) Installing the suspending bracket rst onto the ceiling (Fig. 3-6)
Installing procedures
1. Remove the suspending brackets and U-shaped washers from the unit.
2. Adjust the suspending bracket holding bolts on the unit.
3. Attach the suspending brackets to the suspending bolts.
4. Check that the suspending brackets are horizontal (front and rear/ right and left).
5. Set (hook) the unit to the suspending brackets.
6. Tighten xed bolts of the suspending brackets.
w Be sure to install the U-shaped washers.
A Suspending bracket holding bolt
B Unit
C U-shaped washer
D Suspending bolt
E Washer 1
F Double nuts
3.2.3. Selection of suspension bolts and tubing positions (Fig. 3-3)
Using the pattern paper provided for installation, select proper positions for suspen-
sion bolts and tubing and prepare relative holes.
A Pattern paper
B Suspension bolt hole
C Indoor unit width
Secure the suspension bolts or use angle stock braces or square timbers for bolt
installation.
D Use inserts of 100 kg to 150 kg each.
E Use suspension bolts of W3/8 or M10 in size.
3.2.4. Indoor unit preparation (Fig. 3-4)
1. Install the suspending bolts. (Procure the W3/8 or M10 bolts locally.)
Predetermine the length from the ceiling (1 within 100 mm).
A Ceiling surface B Suspending bolt C Suspending bracket
2. Remove the intake grille.
Slide the intake grille holding knobs (at 2 or 3 locations) backward to open the
intake grille.
3. Remove the side panel.
Remove the side panel holding screws (one in each side, right and left) then slide
the side panel forward for removal.
D Intake grille J Slide the side panel forward.
E Intake grille holding knob K Side panel
F Slide L Remove the side panel holding screws.
G Hinge M Remove the protective vinyl of vane.
H Pushing the hinge, pull out the intake grille.
2 Forcing open the intake grille or opening it to an angle of more than 120° may
damage the hinges.
Fig. 3-4
Fig. 3-5
Fig. 3-3
Fig. 3-6
(mm)
GM35, 50 882-887
M60, 71 1202-1207
M100-140 1522-1527
en
BT79D079H01_01en.indd 4 2021/02/24 11:38:55
005

5
4. Installing the refrigerant piping
G
C
D
E
F
C
B
A
DE
E
F
B
A B
C
D
A
45 2
4.3. Indoor unit (Fig. 4-3)
Installing procedures
1. Slide the supplied pipe cover 2 over the gas tubing until it is pressed against the
sheet metal inside the unit.
2. Slide the provided pipe cover 3 over the liquid tubing until it is pressed against
the sheet metal inside the unit.
3. Tighten the pipe covers 2 and 3 at the both ends (20 mm) with the supplied
bands 4.
A Gas tubing E Pipe cover 3
B Liquid tubing F Press the pipe cover against the sheet metal.
C Band 4 G Refrigerant tubing heat insulating material
D Pipe cover 2
4.4. For twin/triple combination
Refer to the outdoor unit installation manual.
4.1. Precautions
For devices that use R32/R410A refrigerant
• Use ester oil, ether oil or alkylbenzene oil (small amount) as the refrigeration
oil applied to the ared sections.
• Use C1220 copper phosphorus for copper and copper alloy seamless pipes,
to connect the refrigerant pipes. Use refrigerant pipes with the thicknesses
specied in the table below. Make sure the insides of the pipes are clean
and do not contain any harmful contaminants such as sulfuric compounds,
oxidants, debris, or dust.
Warning:
When installing or relocating, or servicing the air conditioner, use only the
specied refrigerant written on outdoor unit to charge the refrigerant lines. Do
not mix it with any other refrigerant and do not allow air to remain in the lines.
If air is mixed with the refrigerant, then it can be the cause of abnormal high
pressure in the refrigerant line, and may result in an explosion and other hazards.
The use of any refrigerant other than that specied for the system will cause
mechanical failure or system malfunction or unit breakdown. In the worst case,
this could lead to a serious impediment to securing product safety.
M35, 50 M60-140
Liquid pipe ø6.35 thickness 0.8 mm ø9.52 thickness 0.8 mm
Gas pipe ø12.7 thickness 0.8 mm ø15.88 thickness 1.0 mm
• Do not use pipes thinner than those specied above.
4.2. Connecting pipes (Fig. 4-1)
• When commercially available copper pipes are used, wrap liquid and gas pipes
with commercially available insulation materials (heat-resistant to 100 °C or more,
thickness of 12 mm or more).
• The indoor parts of the drain pipe should be wrapped with polyethylene foam insula-
tion materials (specic gravity of 0.03, thickness of 9 mm or more).
• Apply thin layer of refrigerant oil to pipe and joint seating surface before tightening
are nut.
• Use 2 wrenches to tighten piping connections.
• Use refrigerant piping insulation provided to insulate indoor unit connections. Insulate
carefully.
• After connecting the refrigerant piping to the indoor unit, be sure to test the pipe
connections for gas leakage with nitrogen gas. (Check that there is no refrigerant
leakage from the refrigerant piping to the indoor unit.)
• Use ared nut installed to this indoor unit.
• In case of reconnecting the refrigerant pipes after detaching, make the ared part
of pipe re-fabricated.
B Flare nut tightening torque
Copper pipe O.D.
(mm)
Flare nut O.D.
(mm)
Tightening torque
(N·m)
ø6.35 17 14-18
ø6.35 22 34-42
ø9.52 22 34-42
ø12.7 26 49-61
ø12.7 29 68-82
ø15.88 29 68-82
C Apply refrigerating machine oil over the entire are seat surface.
Do not apply refrigerating machine oil to the screw portions.
(This will make the are nuts more apt to loosen.)
D Use correct are nuts meeting the pipe size of the outdoor unit.
Available pipe size
M35, 50 M60 M71-140
Liquid side ø6.35 Ο ø6.35 —
—ø9.52 Ο ø9.52 Ο
Gas side ø12.7 Ο ø15.88 Ο ø15.88 Ο
Ο : Factory are nut attachment to the heat exchanger.
A Flare cutting dimensions
Copper pipe O.D.
(mm)
Flare dimensions
øA dimensions (mm)
ø6.35 8.7 - 9.1
ø9.52 12.8 - 13.2
ø12.7 16.2 - 16.6
ø15.88 19.3 - 19.7
Copper pipe O.D.
(mm)
B (mm)
Flare tool for R32/R410A
Clutch type
ø6.35 (1/4″) 0 - 0.5
ø9.52 (3/8″) 0 - 0.5
ø12.7 (1/2″) 0 - 0.5
ø15.88 (5/8″) 0 - 0.5
Fig. 4-3
Fig. 4-1
Fig. 4-2
90° ± 0.5°
R0.4 - R0.8
E Die
F Copper pipe
en
BT79D079H01_01en.indd 5 2021/02/24 11:38:55
006

6
5. Drainage piping work
6. Electrical work
BC
A
AC
F
D
B
E
C
D
B
E
AB
CD
EF
D
H
I
G
i
• For left side tubing, be sure to insert the rubber plug into the right drain port. (Fig. 5-1)
• Use VP-20 (O.D. ø26 (1”) PVC TUBE) for drain piping and provide 1/100 or more
downward slope.
• After completion of work, check that correct drain is available from the out ow port
of the drain tubing.
A Drain pan
B Plug
C Insert the driver etc.in the plug deeply.
Installing procedures (Fig. 5-2)
1. Attach the joint socket 5 supplied with the unit to the drain port on the unit with a
vinyl chloride adhesive.
2. Fasten the socket cover 6 supplied with the unit to the joint socket 5.
3. Attach the  eld drain tubing (VP-20) to the joint socket 5 with a vinyl chloride
adhesive.
4. Wrap the drain tubing cover 7 supplied with the unit. (Seam taping)
A Drain pan
B Drain tubing
C Socket cover 6
D Joint socket 5
E Drain tubing cover 7
F Insertion length 37 mm
5. Check for correct drainage. (Fig. 5-3)
* Fill the drain pan with water of about 1 L from the air outlet.
6.1. Electric wiring (Fig. 6-1)
Wiring procedures
1. Remove the tapping screw C then remove the beam.
2. Remove the (2) tapping screws B then remove the electric part cover A.
3. Connect the electric wires securely to the corresponding terminals.
4. Reinstall the removed parts.
5. Tie the electric wires with the local wiring clamp located in the right side of the
junction box.
A Cover H Grounding cable connector
B Set screws (2 pcs) I Terminal block for remote controller
C Set screws (Beam) i Secure with the wiring clamp.
D Wiring clamp
E Control board
F Wire service entrance
G Terminal block for indoor and outdoor units connection: S1, S2 and S3, have
polarity
Fig. 5-1
Fig. 5-2
Fig. 5-3
Fig. 6-1
en
BT79D079H01_01en.indd 6 2021/02/24 11:38:55
007

7
6.1.1. Indoor unit power supplied from outdoor unit
The following connection patterns are available.
The outdoor unit power supply patterns vary on models.1 System
S1
S2
L
N
1
2
S1
S2
S3
S3
ABC
D
E
F
G
S1
S2
L
N
1
2
S1
S2
S3
1
2
S1
S2
S3
S3
1
2
S1
S2
S3
1
2
S1
S2
S3
D
E
F
GGGG
ABC
HH H
* Afx label A that is included with the manuals near each wiring diagram for the indoor and outdoor units.
A Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor unit/outdoor unit connecting cables
F Remote controller
G Indoor unit
* Afx label A that is included with the manuals near each wiring diagram for the indoor and outdoor units.
Indoor unit model PCA
Wiring
Wire No. × size
(mm²)
Indoor unit-Outdoor unit *1 3 × 1.5 (polar)
Indoor unit-Outdoor unit earth *1 1 × Min.1.5
Indoor unit earth 1 × Min.1.5
Remote controller-Indoor unit *2 2 × 0.3 (Non-polar)
Circuit rating
Indoor unit (Heater) L-N *3 -
Indoor unit-Outdoor unit S1-S2 *3 230 V AC
Indoor unit-Outdoor unit S2-S3 *3 *4 24 V DC / 28 V DC
Remote controller-Indoor unit *3 12 V DC
*1. <For 50-140 outdoor unit application>
Max. 45 m
If 2.5 mm2 used, Max. 50 m
If 2.5 mm2 used and S3 separated, Max. 80 m
<For 200/250 outdoor unit application>
Max. 18 m
If 2.5 mm2 used, Max. 30 m
If 4 mm2 used and S3 separated, Max. 50 m
If 6 mm2 used and S3 separated, Max. 80 m
*2. Max. 500 m
(When using 2 remote controllers, the maximum wiring length for the remote controller cables is 200 m. If 2 remote controllers are connected, set one to “Main” and the other to
“Sub”. For setting procedures, refer to “Initial settings” in the installation manual for the remote controller.)
*3. The gures are NOT always against the ground.
S3 terminal has 24 V DC / 28 V DC against S2 terminal. However between S3 and S1, these terminals are not electrically insulated by the transformer or other device.
*4. It depends on the outdoor unit.
Notes: 1. Wiring size must comply with the applicable local and national code.
2.
Power supply cords and indoor unit/outdoor unit connecting cords shall not be lighter than polychloroprene sheathed exible cord.
(Design 60245 IEC 57)
3. Install an earth longer than other cables.
4. Indoor and outdoor connecting wires have polarities. Make sure to match the terminal number (S1, S2, S3) for correct wirings.
5. Wiring for remote controller cable shall be apart (50 mm or more) from power source wiring so that it is not inuenced by electric noise
from power source wiring.
Simultaneous twin/triple/quadruple system
1:1 System
6.1.2. Separate indoor unit/outdoor unit power supplies (For PUZ/PUHZ application only)
The following connection patterns are available.
The outdoor unit power supply patterns vary on models.
1:1 System
6. Electrical work
A Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor unit/outdoor unit connecting cables
F Remote controller
G Indoor unit
H Indoor unit earth
S1
S2
L
N
1
2
L
N
S1
S2
S3
S3
D
E
F
G
H
ABC BC
J
* The indoor power supply terminal kit is required. A Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor unit/outdoor unit connecting cables
F Remote controller
G Indoor unit
H Option
J Indoor unit power supply
* Afx label B that is included with the manuals near each wiring diagram for the indoor and outdoor units.
en
BT79D079H01_01en.indd 7 2021/02/24 11:38:56
008

8
6. Electrical work
Simultaneous twin/triple/quadruple system
S1
S2
L
N
1
2
L
N
S1
S2
S3
1
2
L
N
S1
S2
S3
1
2
L
N
S1
S2
S3
1
2
L
N
S1
S2
S3
S3
D
E
F
H
GGGG
KKK
HHH
ABC BC
J
ON
OFF 1 2 (SW8)
3
S1
S2
S3
L
N
BLUE BLUE
YELLOW YELLOW
CN01
CN01
BLACK
CN01
BLACK
S1
S2
S3
L
N
YELLOW
BLUE
BLUE
YELLOW
CN01
* Afx label B that is included with the manuals near each wiring diagram for the indoor and outdoor units.
If the indoor and outdoor units have separate power supplies, refer to the table below.
If the indoor power supply terminal kit is used, change the indoor unit electrical box
wiring refering to the gure in the right and the DIP switch settings of the outdoor
unit control board.
Indoor unit specications
Indoor power supply terminal kit (option) Required
Indoor unit electrical box connector connec-
tion change
Required
Label afxed near each wiring diagram for the
indoor and outdoor units
Required
Outdoor unit DIP switch settings (when us-
ing separate indoor unit/outdoor unit power
supplies only)
* There are 3 types of labels (labels A, B and C). Afx the appropriate labels to the
units according to the wiring method.
Indoor unit model PCA
*1. A breaker with at least 3.0 mm contact separation in each pole shall be pro-
vided. Use earth leakage breaker (NV).
The breaker shall be provided to ensure disconnection of all active phase
conductors of the supply.
*2. Max. 120 m
*3. Max. 500 m
(When using 2 remote controllers, the maximum wiring length for the remote
controller cables is 200 m. If 2 remote controllers are connected, set one to
“Main” and the other to “Sub”. For setting procedures, refer to “Initial settings”
in the installation manual for the remote controller.)
*4. The gures are NOT always against the ground.
*5. It depends on the outdoor unit.
Indoor unit power supply ~/N (single), 50 Hz, 230 V
Indoor unit input capacity
Main switch (Breaker) *1 16 A
Wiring
Wire No. ×
size (mm²)
Indoor unit power supply & earth 3 × Min. 1.5
Indoor unit-Outdoor unit *2 2 × Min. 0.3
Indoor unit-Outdoor unit earth –
Remote controller-Indoor unit *3 2 × 0.3 (Non-polar)
Circuit
rating
Indoor unit L-N *4 230 V AC
Indoor unit-Outdoor unit S1-S2 *4 –
Indoor unit-Outdoor unit S2-S3 *4 *5 24 V DC / 28 V DC
Remote controller-Indoor unit *4 12 V DC
Notes: 1. Wiring size must comply with the applicable local and national code.
2.
Power supply cords and indoor unit/outdoor unit connecting cords shall not be lighter than polychloroprene sheathed exible cord. (Design 60245 IEC 57)
3. Install an earth longer than other cables.
4. Wiring for remote controller cable shall be apart (50 mm or more) from power source wiring so that it is not inuenced by electric noise from power
source wiring.
A Outdoor unit power supply
B Earth leakage breaker
C Wiring circuit breaker or isolating switch
D Outdoor unit
E Indoor unit/outdoor unit connecting cables
F Remote controller
G Indoor unit
H Option
J Indoor unit power supply
K Indoor unit earth
Never splice the power cable or the indoor-outdoor connection cable, otherwise it may result in a smoke, a re or communication failure.
Warning:
* The indoor power supply terminal kits are required.
Set the SW8-3 to ON.
Option
Option
Indoor unit power supplied from outdoor unit
(initial setting)
Separate indoor unit/outdoor unit power supplies
Connectors (connections of initial setting
are for indoor unit power supplied from
outdoor unit)
If the indoor and
outdoor units have
separate power
supplies, change the
connections of the
connectors as shown
in the following
gure.
Connectors
Indoor unit
control board
Indoor unit
control board
en
BT79D079H01_01en.indd 8 2021/02/24 11:38:56
009

9
6. Electrical work
en
6.2. Function setting
6.2.1. Function setting on the unit (Selecting the unit functions)
1 (Fig. 6-2)
• Select “Service” from the Main menu, and press the [SELECT] button.
• Select “Settings” from the Service menu, and press the [SELECT] button.
2 (Fig. 6-3)
• Select “Function setting” with the [SELECT] button.
3 (Fig. 6-4)
• Set the indoor unit refrigerant addresses and unit numbers with the [F1]
through [F4] buttons, and then press the [SELECT] button to conrm the cur-
rent setting.
<Checking the Indoor unit No.>
When the [SELECT] button is pressed, the target indoor unit will start fan
operation. If the unit is common or when running all units, all indoor units for the
selected refrigerant address will start fan operation.
4 (Fig. 6-5)
• When data collection from the indoor units is completed, the current settings
appears. Screen appearance varies depending on the “Unit No.” setting.
• Toggle through the pages with the [F3] or [F4] button.
• Select the mode number with the [F1] or [F2] button, and then press the [SE-
LECT] button.
5 (Fig. 6-6)
• Select the setting number with the [F1] or [F2] button.
Setting range for modes 1 through 28: 1 through 3
Setting range for modes 31 through 66: 1 through 15
6 (Fig. 6-7)
• When the settings are completed, press the [SELECT] button to send the set-
ting data from the remote controller to the indoor units.
• When the transmission is successfully completed, the screen will return to the
Function setting screen.
Settings menu
Cursor
Service menu:
Function setting
Rotation setting
F1 F2 F3 F4
F1 F2 F3 F4
Service menu
Cursor
Main menu:
Test run
Input maintenance info.
Settings
Check
Others
Function setting
Cursor Address
Monitor:
Ref. address
Unit No.
Grp./1/2/3/4/All
F1 F2 F3 F4
Fig. 6-3Fig. 6-2
Fig. 6-4
F1 F2 F3 F4
Function setting
Cursor Page
Ref. address
Mode 1
Mode 2
Mode 3
Mode 4
Grp.
Save:
1/8
F1 F2 F3 F4
Function setting
Request:
Ref. address
Mode 1
Mode 2
Mode 3
Mode 4
Grp.
1/8
Value
Fig. 6-5
Fig. 6-6
F1 F2 F3 F4
Function setting
Ref. address
Sending data
Grp.
Fig. 6-7
Note:
• Make the above settings on Mr. Slim units as necessary.
• Function table summarizes the setting options for each mode number.
• Be sure to write down the settings for all functions if any of the initial set-
tings has been changed after the completion of installation work.
BT79D079H01_01en.indd 9 2021/02/24 11:38:56
010

10
6. Electrical work
Function table
Select unit number “Grp.”
Mode Settings Mode no. Setting no. Initial setting setting
Power failure automatic recovery Not available 01 1
Available *1 2Ο *2
Indoor temperature detecting Indoor unit operating average
02
1Ο
Set by indoor unit’s remote controller 2
Remote controller’s internal sensor 3
LOSSNAY connectivity Not Supported
03
1Ο
Supported (indoor unit is not equipped with outdoor-air intake)
2
Supported (indoor unit is equipped with outdoor-air intake) 3
Power voltage 240 V 04 1
220 V, 230 V 2Ο
Auto operation mode Single set point (Available 14 °C cooling setting *3) 06 1
Dual set point (Not available 14 °C cooling setting *3) 2Ο
Smart Defrost *3 Available 20 1Ο
Not Available 2
Select unit numbers 1 to 4 or “All”
Mode Settings Mode no. Setting no. Initial setting setting
Filter sign 100 Hr
07
1
2500 Hr 2Ο
No lter sign indicator 3
Fan speed Silent
08
1
Standard 2Ο
High ceiling 3
Installed options (high efciency lter) Not supported 10 1Ο
Supported 2
Up/down vane setting No vanes
11
1
Equipped with vanes (vanes angle setup 1)2Ο
Equipped with vanes (vanes angle setup 2)3
Fan speed during the cooling thermostat is OFF Setting fan speed
27
1
Stop 2
Extra low 3Ο
*1 When the power supply returns, the air conditioner will start 3 minutes later.
*2 Power failure automatic recovery initial setting depends on the connecting outdoor unit.
*3 It is available when the indoor unit is connected to any of the particular outdoor units.
en
BT79D079H01_01en.indd 10 2021/02/24 11:38:56
011

11
6. Electrical work
en
6.2.2. Rotation setting
You can set these functions by wired remote controller. (Maintenance monitor)
Rotation setting
Select :
Rotation
TempDifTrigger
− Content +
Backup only
+4°C
Cur.
F1 F2 F3 F4
Reset
4 Set the rotation function.
• Select "Rotation" with the [F1] button.
• Select the switching period or "Backup only" with the [F2] or [F3] button.
■ "Rotation" setup options
None, 1 day, 3 days, 5 days, 7 days, 14 days, 28 days, Backup only
5 Set the support function.
• Select "TempDifTrigger" with the [F1] button.
• Select the difference between the suction temperature and the set temperature with the [F2] or [F3]
button.
1 Select “Service” from the Main menu, and press the [SELECT] button.
2 Select “Settings” with the [F1] or [F2] button, and press the [SELECT] button.
3 Select “Rotation setting” with the [F1] or [F2] button, and press the [SELECT] button.
F1 F2 F3 F4
Settings menu
Cursor
Service menu:
Function setting
Rotation setting
Rotation setting
Select :
Rotation
TempDifTrigger
− Content +
Backup only
+4°C
Cur.
F1 F2 F3 F4
Reset
Notes:
• When 1 to 28 days are selected from the setup options, the backup function is also enabled.
• When "Backup only" is selected, the rotation function will be disabled. The systems with refrigerant ad-
dresses of 00 or 01 (00 system/ 01 system) will be operated as a main system while the 02 system is
the standby mode as backup.
6 Press the [SELECT] button to update the setting.
■ "TempDifTrigger" setup options
None, +4ºC, +6ºC, +8ºC
Notes:
• The support function is available only in the COOL mode. (Not available in the HEAT, DRY and AUTO
mode.)
• The support function is enabled when any option other than "None" is selected from the "Rotation"
setup options.
Reset method
• Press the [F4] button in step 4 or 5 to reset the operation time of the rotation function. Once it is reset, operation will start from the systems with
refrigerant addresses of 00 or 01.
Note: When the system with refrigerant addresse of 02 is in the backup operation, the 00 or 01 systems will be operated again.
BT79D079H01_01en.indd 11 2021/02/24 11:38:57
012

12
7. Test run
7.2. Test run
7.2.1. Using wired remote controller.
■ Make sure to read operation manual before test run. (Especially items to secure safety)
Step 1 Turn on the power.
● Remote controller: The system will go into startup mode, and the remote controller power lamp (green) and “Please Wait” will blink. While the lamp and message are
blinking, the remote controller cannot be operated. Wait until “Please Wait” is not displayed before operating the remote controller. After the power is turned on, “Please
Wait” will be displayed for approximately 2 minutes.
● Indoor controller board: LED 1 will be lit up, LED 2 will be lit up (if the address is 0) or off (if the address is not 0), and LED 3 will blink.
● Outdoor controller board: LED 1 (green) and LED 2 (red) will be lit up. (After the startup mode of the system nishes, LED 2 will be turned off.) If the outdoor controller
board uses a digital display, [- ] and [ -] will be displayed alternately every second.
If the operations do not function correctly after the procedures in step 2 and thereafter are performed, the following causes should be considered and eliminated if they
are found.
(The symptoms below occur during the test run mode. “Startup” in the table means the LED display written above.)
Symptoms in test run mode
Cause
Remote Controller Display OUTDOOR BOARD LED Display
< > indicates digital display.
Remote controller displays “Please Wait”, and
cannot be operated.
After “startup” is displayed, only green lights up.
<00>
• After power is turned on, “Please Wait” is displayed for 2 minutes
during system startup. (Normal)
After power is turned on, “Please Wait” is
displayed for 3 minutes, then error code is
displayed.
After “startup” is displayed, green (once) and red
(once) blink alternately. <F1>
• Incorrect connection of outdoor terminal block (~/N: L, N and S1,
S2, S3) (3N~: L1, L2, L3, N and S1, S2, S3)
After “startup” is displayed, green (once) and red
(twice) blink alternately. <F3, F5, F9> • Outdoor unit’s protection devise connector is open.
No display appears even when remote control-
ler operation switch is turned on. (Operation
lamp does not light up.)
After “startup” is displayed, green (twice) and red
(once) blink alternately. <EA. Eb>
• Incorrect wiring between the indoor and outdoor unit (Polarity is
wrong for S1, S2, S3.)
• Remote controller transmission wire short.
After “startup” is displayed, only green lights up.
<00>
• There is no outdoor unit of address 0. (Address is other than 0.)
• Remote controller transmission wire open.
Display appears but soon disappears even
when remote controller is operated.
After “startup” is displayed, only green lights up.
<00>
• After canceling function selection, operation is not possible for about
30 seconds. (Normal)
Step 2 Switch the remote controller to “Test run”.
1
Select “Test run” from the Service menu, and press the [SELECT] button. (Fig. 7-1)
2 Select “Test run” from the Test run menu, and press the [SELECT] button. (Fig. 7-2)
3 The test run operation starts, and the Test run operation screen is displayed.
unemec i v r eS
rosruC
: u n emn i aM
Test run
Input maintenance info.
Function setting
Check
Self check
F1 F2 F3 F4
Fig. 7-1
Test run menu
Cursor
Service menu:
Test run
Drain pump test run
F1 F2 F3 F4
Fig. 7-2
Cool Auto
Switch disp.
Mode Fan
RemainTest run
F1 F2 F3 F4
Pipe
Fig. 7-3
Remain
Vane
F1 F2 F3 F4
Fig. 7-4
Step 3 Perform the test run and check the airow temperature and auto vane.
1 Press the [F1] button to change the operation mode. (Fig. 7-3)
Cooling mode: Check that cool air blows from the unit.
Heating mode: Check that warm air blows from the unit.
2 Press the [SELECT] button to display the Vane operation screen, and then press
the [F1] and [F2] buttons to check the auto vane. (Fig. 7-4)
Press the [RETURN] button to return to the Test run operation screen.
Step 4 Conrm the operation of the outdoor unit fan.
The speed of the outdoor unit fan is controlled in order to control the performance of the unit. Depending on the ambient air, the fan will rotate at a slow speed and will keep
rotating at that speed unless the performance is insufcient. Therefore, the outdoor wind may cause the fan to stop rotating or to rotate in the opposite direction, but this is
not a problem.
► Do not carry out this test on the control wiring (low voltage circuit) terminals.
Warning:
Do not use the air conditioner if the insulation resistance is less than 1 M .
7.1. Before test run
► After completing installation and the wiring and piping of the indoor and
outdoor units, check for refrigerant leakage, looseness in the power supply
or control wiring, wrong polarity, and no disconnection of one phase in the
supply.
► Use a 500-volt megohmmeter to check that the resistance between the power
supply terminals and ground is at least 1 M .
en
BT79D079H01_01en.indd 12 2021/02/24 11:38:57
013

13
7. Test run
Step 5 Stop the test run.
1 Press the [ON/OFF] button to stop the test run. (The Test run menu will appear.)
Note: If an error is displayed on the remote controller, see the table below.
LCD Description of malfunction LCD Description of malfunction LCD Description of malfunction
P1 Intake sensor error P9 Pipe sensor error (dual-wall pipe)
E0 ~ E5
Communication error between the
remote controller and the indoor
unit
P2 Pipe sensor error (liquid pipe) PA Leakage error (refrigerant system)
P4 Drain oat switch connector
disconnected (CN4F)
Pb Indoor unit fan motor error
PL Refrigerant circuit abnormal
P5 Drain overow protection operation FB Indoor controller board error
E6 ~ EF Communication error between the
indoor unit and the outdoor unit
P6 Freezing/overheating protection
operation
U*, F*
(* indicates an
alphanumeric
character
excluding FB.)
Outdoor unit malfunction
Refer to the wiring diagram for the
outdoor unit.
P8 Pipe temperature error
See the table below for the details of the LED display (LED 1, 2, and 3) on the indoor controller board.
LED 1 (microcomputer power supply) Indicates whether control power is supplied. Make sure that this LED is always lit.
LED 2 (remote controller power supply) Indicates whether power is supplied to the wired remote controller. The LED is lit only for the indoor unit that is connected
to the outdoor unit that has an address of 0.
LED 3 (indoor/outdoor unit communication) Indicates whether the indoor and outdoor units are communicating. Make sure that this LED is always blinking.
7.2.2. Using wireless remote controller (Fig. 7-5)
1. Press the button 1 to stop the air conditioner.
• If the weekly timer is enabled ( is on), press the button 3 to disable
it ( is off).
2. Press the button 2 for 5 seconds.
• comes on and the unit enters the service mode.
3. Press the button 2.
• B comes on and the unit enters the test run mode.
4. Press the following buttons to start the test run.
: Switch the operation mode between cooling and heating and start the test run.
: Switch the fan speed and start the test run.
: Switch the airow direction and start the test run.
: Switch the louver and start the test run.
: Start the test run.
5. Stop the test run.
• Press the button 1 to stop the test run.
• After 2 hours, the stop signal is transmitted.
7.2.3. Using SW4 in outdoor unit
Refer to the outdoor unit installation manual.
7.3. Self-check
7.3.1. Wired remote controller
■ Refer to the installation manual that comes with each remote controller for details.
7.3.2. Wireless remote controller (Fig. 7-6)
1. Press the button 1 to stop the air conditioner.
• If the weekly timer is enabled ( is on), press the button 3 to disable
it ( is off).
2. Press the button 2 for 5 seconds.
• A comes on and the unit enters the self-check mode.
3. Press the button 5 to select the refrigerant address (M-NET address) B of the
indoor unit for which you want to perform the self-check.
4. Press the button 4.
• If an error is detected, the check code is indicated by the number of beeps from
the indoor unit and the number of blinks of the OPERATION INDICATOR lamp.
5. Press the button 1.
• A and the refrigerant address (M-NET address) B go off and the self-check
is completed.
Fig. 7-5
Fig. 7-6
1
A
B
2
3
5
B
1
A
4
2
3
en
BT79D079H01_01en.indd 13 2021/02/24 11:38:59
014

14
7. Test run
• Refer to the following tables for details on the check codes. (Wireless remote controller)
[Output pattern A]
[Output pattern A] Errors detected by indoor unit
Wireless remote controller Wired remote
controller
Symptom Remark
Beeper sounds/OPERATION
INDICATOR lamp blinks
(Number of times)
Check code
1P1 Intake sensor error
2P2 Pipe (TH2) sensor error
P9 Pipe (TH5) sensor error
3E6, E7 Indoor/outdoor unit communication error
4P4 Float switch connector open
5P5 Drain pump error
PA Forced compressor stop (due to water leakage abnormality)
6P6 Freezing/Overheating protection operation
7EE Communication error between indoor and outdoor units
8P8 Pipe temperature error
9E4 Remote controller signal receiving error
10 — —
11 Pb Indoor unit fan motor error
12 Fb Indoor unit control system error (memory error, etc.)
14 PL Refrigerant circuit abnormal
No sound E0, E3 Remote controller transmission error
No sound E1, E2 Remote controller control board error
No sound – – – – No corresponding
OPERATION
INDICATOR
lamp blinking
pattern
Beep Beep Beep Beep Beep Beep Beep
Off
Approx. 2.5 sec.
On
Approx. 3 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec.
Off
Approx. 2.5 sec.
On
Approx. 3 sec.
On
0.5 sec.
On
0.5 sec.
· · · Repeated
Number of blinks/beeps in pattern indicates the check
code in the following table (i.e., n=5 for “U2”)
Number of blinks/beeps in pattern
indicates the check code in the
following table
nth 1st 2nd 3rd 1st 2nd
Self-check
starts
(Start signal
received)
Beeper sounds
[Output pattern B]
OPERATION
INDICATOR
lamp blinking
pattern
Beep Beep Beep Beep Beep Beep Beep
Off
Approx. 2.5 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec.
On
0.5 sec.
Off
Approx. 2.5 sec.
On
0.5 sec.
On
0.5 sec.
· · · Repeated
Number of blinks/beeps in pattern indicates the check
code in the following table (i.e., n=5 for “P5”)
Number of blinks/beeps in pattern indicates
the check code in the following table
nth
1st 2nd 3rd 1st 2nd
Self-check
starts
(Start signal
received)
Beeper sounds
en
BT79D079H01_01en.indd 14 2021/02/24 11:39:00
015

15
7. Test run
[Output pattern B] Errors detected by unit other than indoor unit (outdoor unit, etc.)
Wireless remote controller Wired remote
controller
Symptom Remark
Beeper sounds/OPERATION
INDICATOR lamp blinks
(Number of times)
Check code
1E9 Indoor/outdoor unit communication error (Transmitting error) (Outdoor unit)
For details, check the LED
display of the outdoor controller
board.
2UP Compressor overcurrent interruption
3U3, U4 Open/short of outdoor unit thermistors
4UF Compressor overcurrent interruption (When compressor locked)
5U2 Abnormal high discharging temperature/49C worked/insufcient refrigerant
6U1, Ud Abnormal high pressure (63H worked)/Overheating protection operation
7U5 Abnormal temperature of heat sink
8U8 Outdoor unit fan protection stop
9U6 Compressor overcurrent interruption/Abnormal of power module
10 U7 Abnormality of super heat due to low discharge temperature
11 U9, UH Abnormality such as overvoltage or voltage shortage and abnormal
synchronous signal to main circuit/Current sensor error
12 — —
13 — —
14 Others Other errors (Refer to the technical manual for the outdoor unit.)
*1. If the beeper does not sound again after the initial 2 beeps to conrm the self-check start signal was received and the OPERATION INDICATOR lamp does
not come on, there are no error records.
*2. If the beeper sounds 3 times continuously “beep, beep, beep (0.4 + 0.4 + 0.4 sec.)” after the initial 2 beeps to conrm the self-check start signal was received,
the specied refrigerant address is incorrect.
• On wireless remote controller
The continuous buzzer sounds from receiving section of indoor unit.
Blink of operation lamp
• On wired remote controller
Check code displayed in the LCD.
• If the unit cannot be operated properly after test run, refer to the following table to nd the cause.
Symptom Cause
Wired remote controller LED 1, 2 (PCB in outdoor unit)
Please Wait For about 2 minutes
after power-on
After LED 1, 2 are lit, LED 2 is turned off,
then only LED 1 is lit. (Correct operation)
•For about 2 minutes after power-on, operation of the remote
controller is not possible due to system start-up. (Correct
operation)
Please Wait →Error code
Subsequent to about
2 minutes after
power-on
Only LED 1 is lit. → LED 1, 2 blink.
•Connector for the outdoor unit’s protection device is not con-
nected.
Reverse or open phase wiring for the outdoor unit’s power
terminal block (~/N: L, N) (3N~: L1, L2, L3, N)
Display messages do not appear
even when operation switch is
turned ON
(operation lamp does not light up).
Only LED 1 is lit. → LED 1 blinks twice,
LED 2 blinks once.
•Incorrect wiring between indoor and outdoor units (incorrect
polarity of S1, S2, S3)
•Remote controller wire short
On the wireless remote controller with condition above, following phenomena take place.
• No signals from the remote controller are accepted.
• Operation lamp is blinking.
• The buzzer makes a short ping sound.
Note:
Operation is not possible for about 30 seconds after cancellation of function selection. (Correct operation)
For description of each LED (LED 1, 2, 3) provided on the indoor controller, refer to the following table.
LED 1 (power for microcomputer) Indicates whether control power is supplied. Make sure that this LED is always lit.
LED 2 (power for remote controller) Indicates whether power is supplied to the remote controller. This LED lights only in the case of
the indoor unit which is connected to the outdoor unit refrigerant address “0”.
LED 3 (communication between indoor and outdoor units) Indicates state of communication between the indoor and outdoor units. Make sure that this LED
is always blinking.
en
BT79D079H01_01en.indd 15 2021/02/24 11:39:00
016

16
8. Easy maintenance function
en
Maintenance data, such as the indoor/outdoor unit’s heat exchanger temperature and compressor operation current can be displayed with “smooth maintenance”.
* This cannot be executed during test operation.
* Depending on the combination with the outdoor unit, this may not be supported by some models.
• Select “Service” from the Main menu, and press the [SELECT] button.
• Select “Check” with the [F1] or [F2] button, and press the [SELECT] button.
• Select “Smooth maintenance” with the [F1] or [F2] button, and press the [SELECT]
button.
Select each item.
• Select the item to be changed with the [F1] or [F2] button.
• Select the required setting with the [F3] or [F4] button.
“Ref. address” setting ………. “0” - “15”
“Stable mode” setting……….. “Cool” / “Heat” / “Normal”
• Press the [SELECT] button, xed operation will start.
* Stable mode will take approx. 20 minutes.
The operation data will appear.
The Compressor-Accumulated operating (COMP. run) time is 10-hour unit, and
the Compressor-Number of operation times (COMP. On/Off) is a 100-time unit
(fractions discarded)
Navigating through the screens
• To go back to the Service menu................[MENU] button
• To return to the previous screen .......... [RETURN] button
F1 F2 F3 F4
Check menu
Cursor
Service menu:
Error history
Diagnosis
Smooth maintenance
Request code
Smooth maintenance
Begin:
Smooth maintenance
Exit:
Ref.address
Stable mode
Cursor
Ref.address
Stable mode
Stabilization→Collecting
Cool / Heat/Normal
Address
Cool / Heat/Normal
Smooth maintenance
Return:
Smooth maintenance
Return:
Smooth maintenance
Return:
Page
Page
Page
COMP. current
COMP. run time
COMP. On / Off
COMP. frequency
A
Hz
Hr
times
Hr
Ref. address
Cool
Ref.address
Cool
Ref.address
Cool
Sub cool
OU TH4 temp.
OU TH6 temp.
OU TH7 temp.
IU air temp.
IU HEX temp.
IU filter time
1
2
3
BT79D079H01_01en.indd 16 2021/02/24 11:39:00
017

1
►Передустановкойданногоприбора,пожалуйстаобязательнопрочитайтевсе“Мерыпредосторожности”.
►
Вразделе“Мерыпредосторожности”изложеныоченьважныесведения,касающиесятехникибезопасности.Обязательноследуйтеэтиминструкциям.
►Передподключениемоборудованияксистемепитанияинформируйтеобэтомвашуэнергоснабжающуюорганизациюилиполучитееесогласие.
Символика,используемаявтексте
Предупреждение:
Описываетмерыпредосторожности,которыеследуетвыполнять,чтобы
избежатьтравмыилигибелипользователя.
Осторожно:
Описываетмерыпредосторожности,которыеследуетвыполнять,чтобы
неповредитьприбор.
Символы,указанныенаиллюстрациях
: Указывает, что эта часть должна быть заземлена.
: Строго воспрещается.
После окончания установочных работ проинструктируйте пользователя относительно
правил эксплуатации и обслуживания аппарата, а также ознакомьте с разделом “Меры
предосторожности” в соответствии с информацией, приведенной в Руководстве по
использованию аппарата, и выполните тестовый прогон аппарата для того, чтобы убе-
диться, что он работает нормально. Обязательно передайте пользователю на хранение
экземпляры Руководства по установке и Руководства по эксплуатации. Эти Руковод-
ства должны быть переданы и последующим пользователям данного прибора.
Значениясимволов,отображаемыхнавнутреннеми/илинаружномблоке
ПРЕДУПРЕЖДЕНИЕ
(опасность возгорания)
Данный символ применяется только для хладагента R32. Тип хладагента указывается на бирке наружного прибора.
Если тип хладагента — R32, то в данном устройстве используется огнеопасный хладагент.
В случае утечки хладагента и его контакта с огнем или источником тепла образуется вредный газ и возникнет опасность возгорания.
Внимательно прочтите РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ перед началом эксплуатации.
Обслуживающий персонал обязан внимательно прочитать РУКОВОДСТВО ПО ЭКСПЛУАТАЦИИ и РУКОВОДСТВО ПО УСТАНОВКЕ перед на-
чалом работ.
Дополнительную информацию можно найти в РУКОВОДСТВЕ ПО ЭКСПЛУАТАЦИИ, РУКОВОДСТВЕ ПО УСТАНОВКЕ и аналогичных документах.
Предупреждение:
• Внимательнопрочтитетекстнаэтикеткахглавногоприбора.
• Дляустановки,перемещенияиремонтаустройстваобратитесь к
дилеруилиуполномоченномутехническомуспециалисту.
• Запрещаетсясамостоятельныйремонтилиперемещениеприбора.
•
Дляустановкииперемещенияследуйтеинструкциям,приведенным
в Руководствепоустановке,ииспользуйтеинструментыитрубные
компоненты,специальнопредназначенныедляиспользования с
хладагентом,указанныевруководствепоустановкенаружногоприбора.
• Прибордолженбытьустановленсогласноинструкциям,чтобысвести
к минимумурискповрежденияотземлетрясений,тайфуновили
сильных порывов ветра. Неправильно установленный прибор может
упастьипричинитьповреждениеилинанеститравму.
• Не изменяйтеустройство.Это можетпривестиквозникновению
пожара,поражениюэлектротоком,травмамиподтеканиюводы.
•
Прибордолженбытьустановленнаконструкции,способнойвыдержатьеговес.
• Устройствонеобходимосодержатьвхорошопроветриваемомпомещении,
размерыкоторогосоответствуютразмерампомещения,указаннымдля
эксплуатации.
• Есликондиционерустановленвнебольшомилизакрытомпомещении,
необходимопринятьмерыдляпредотвращенияконцентрациихладагента
в помещениисвышебезопасныхпределоввслучаеутечкихладагента. В
случаеутечкихладагента ипревышениидопустимойего концентрациииз-
занехваткикислородавпомещенииможетпроизойтинесчастныйслучай.
• Недопускайтеразмещениягазоиспользующихустройств,электрообогревателей
идругихочаговвозгорания(источниковвозгорания)возлеместосуществления
установки,ремонтаидругихработскондиционером.
 Приконтактехладагентасогнемобразуетсятоксичныйгаз.
•
Есливовремяработыприборапроизошлаутечкахладагента,проветрите
помещение.Приконтактехладагентаспламенемобразуютсяядовитыегазы.
• Всеэлектроработыдолжнывыполнятьсяквалифицированным
техническимспециалистомвсоответствиисместнымиправилами и
инструкциями,приведеннымивданномРуководстве.
• Неиспользуйтепромежуточноесоединениеэлектрическихпроводов.
•
Используйтедляпроводки указанныекабели.Убедитесь,чтокабели
надежносоединены,аоконечныесоединенияненатянуты.Никогда
несоединяйтекабеливнахлест(если иноенеуказановприлагаемой
документации).Несоблюдениеэтихинструкцийможетпривести к
перегревуиливозгоранию.
• Приустановке,перемещенииилиобслуживаниикондиционерадлязаправки
трубопроводовхладагентаиспользуйтетолькототхладагент,который
указаннанаружномустройстве.Несмешивайтеего нискакимдругим
хладагентоминедопускайтеналичиявоздухавтрубопроводах.
Наличиевоздухавтрубопроводахможетвызыватьскачкидавления,в
результатекоторыхможетпроизойтивзрывилидругиеповреждения.

Использованиелюбогохладагента,отличного от указанногодляэтой
системы,вызоветмеханическоеповреждение,сбоивработесистемы,или
выходустройства из строя.Внаихудшемслучае,это можетпослужить
серьезнойпреградойкобеспечениюбезопаснойработыэтогоизделия.
• Установкунеобходимовыполнятьвсоответствиисдействующими
правиламиэлектробезопасности.
•
Данныйприборнепредназначендля использованиялюдьми(включая
детей)сограниченнымифизическими,сенсорнымиилипсихическими
возможностями.Принедостаткеопытаизнанийразрешаетсяпользоваться
даннымприборомтолькоподнаблюдениемлица,ответственногоза
безопасность,илипослеинструктажапоиспользованиюприбора.
• Следуетследитьзадетьми,чтобыонинеигралисустройством.
•
Крышкаклеммнойкоробкидолжнабытьнадежноприсоединена к
прибору.
• Поврежденныйкабельизкомплектапоставкидолженбытьзамененв
целяхбезопасностипроизводителем,сервиснымагентомилилицами,
обладающиминеобходимойквалификацией.
• Используйтетолькотедополнительныепринадлежности,накоторые
имеетсяразрешениеотMitsubishiElectric;дляихустановкиобратитесь
кдилеруилиуполномоченномутехническомуспециалисту.
•
Поокончанииустановкиубедитесьвотсутствииутечкихладагента.Еслихладагент
проникнетвпомещениеипроизойдетконтактегоспламенемобогревателяили
переносногопищевогонагревателя,образуютсяядовитыхгазов.
• Не используйтесредствадляускоренияразмораживанияиочистки,
еслионинерекомендованыпроизводителем.
•
Устройстводолжнохранитьсявпомещениибезнепрерывноработающих
источниковвоспламенения(например,открытогопламени,работающего
газовогоприбораилиэлектрическогообогревателя).
• Неделайтеотверстийпутемсверленияилипрожигания.
• Имейтеввиду,чтохладагентымогутнеиметьзапаха.
• Недопускайтефизическогоповреждениятрубопроводов.
• Установкатрубопроводовдолжнабытьсведенакминимуму.
• Соблюдайтенациональныенормативы,касающиесягаза.
•
Недопускайтезасоренияпредусмотренныхвентиляционныхотверстий.
• Неиспользуйтелегкоплавкийприпойдляпайки трубопроводов
хладагента.
• Вовремяпайкиобязательнопроветривайтепомещение.
Убедитесь,чтовокруготсутствуютопасныеиливоспламеняющиеся
материалы.
 Приработевзакрытом,небольшомилидругоманалогичномпомещении
передвыполнениемработубедитесьвотсутствииутечкихладагента.
 Приутечкеинакоплениихладагентаонможетзагореться,илиможет
выделятьсятоксичныйгаз.
ru
Примечание:
Фраза“Проводнойпультдистанционногоуправления”вданномруководствепоустановкеотноситсякPAR-41MAA.Есливамнеобходимаинфор-
мацияодругомпультедистанционногоуправления,см.прилагаемыекпультуинструкциипоустановке.
1. Мерыпредосторожности
1. Меры предосторожности.........................................................................1
2. Место установки ......................................................................................2
3. Установка внутреннего прибора .............................................................3
4. Прокладка труб хладагента ....................................................................5
5. Дренажные трубы ....................................................................................6
6. Электрические работы ............................................................................6
7. Выполнение испытания.........................................................................12
8. Функция простого техобслуживания ....................................................16
Содержание
BT79D079H01_02ru.indd 1 3/18/2021 11:45:17 AM
018

2
ru
1. Мерыпредосторожности
1.2. Передустановкойилиперемещением
Осторожно:
• Будьтечрезвычайноосторожныпритранспортировкеприборов.При-
бордолжныпереноситьдваилиболеечеловека,посколькуонвесит
неменее20кг.Неподнимайтеприборзаупаковочныеленты.Исполь-
зуйтезащитныеперчатки,посколькуможноповредитьрукиребристы-
мидеталямиилидругимичастямиприбора.
• Утилизируйтеупаковочныематериалынадлежащимобразом.Упако-
вочныематериалы,такие,какгвоздиидругиеметаллическиеилиде-
ревянныечасти,могутпоранитьилипричинитьдругиетравмы.
• Дляпредотвращенияконденсациинеобходимообеспечитьтеплоизо-
ляциютрубыхладагента.Еслитрубахладагентанеизолированадолж-
нымобразом,приработеприборабудетобразовыватьсяконденсат.
1.1. Передустановкой(Окружающаясреда)
Осторожно:
• Неиспользуйтеприборвнестандартнойокружающейсреде.Установкаконди-
ционеравместах,подверженныхвоздействиюпара,летучихмасел(включая
машинноемасло)илисернистыхиспарений,местахсповышеннойконцентра-
циейсоли(таких,какберегморя),можетпривестикзначительномуснижению
эффективностиработыприбораилиповреждениюеговнутреннихчастей.
• Не устанавливайтеприборвместах,гдевозможнаутечка,возникно-
вение,притокилинакоплениегорючихгазов.Еслигорючийгазбудет
накапливатьсявокругприбора,этоможет привестиквозникновению
пожараиливзрыву.
• Недержитепищевыепродукты,растения,домашнихживотныхвклет-
ках,произведенияискусстваиточныеинструментыв прямомпотоке
воздухаотвнутреннегоприбораилислишкомблизкокнему,посколь-
куэтипредметымогутбытьповрежденыперепадамитемпературы
иликапающейводой.
• Приуровневлажностивпомещениивыше80%илизакупоркедренаж-
нойтрубыизвнутреннегоприбораможеткапать вода.Неустанав-
ливайтевнутреннийприборв местах, где такиекаплимогутвызвать
какое-либоповреждение.
• Примонтажеприборавбольницеилицентресвязипримитевовнима-
ниешумовоеиэлектронноевоздействие.Работатакихустройств,как
инверторы,бытовыеприборы,высокочастотноемедицинскоеобо-
рудованиеиоборудованиерадиосвязиможетвызватьсбоивработе
кондиционераилиегополомку. Кондиционертакжеможетповлиять
наработумедицинскогооборудованияимедицинскоеобслуживание,
работукоммуникационногооборудования, вызываяискажениеизо-
бражениянадисплее.
• Обернитетрубы теплоизоляционнымматериаломдляпредотвраще-
нияконденсации.Еслидренажнаятрубаустановленанеправильно,
этоможетвызватьпротечкуводы и испортить потолок, пол, мебель
илидругоеимущество.
• Немойтекондиционерводой.Этоможетпривестикпоражениюэлек-
трическимтоком.
• Затягивайтевсехомутынамуфтахвсоответствиисоспецифика-
циями,используяключсрегулируемымусилием.Слишкомсильно
затянутыйхомутмуфтыпопрошествиинекотороговремениможет
сломаться.
1.3. Передэлектрическимиработами
Осторожно:
• Обязательноустановитеавтоматическиевыключатели.Впротивном
случаевозможнопоражениеэлектрическимтоком.
• Используйтедляэлектропроводкистандартныекабели,рассчитанные
насоответствующуюмощность.Впротивномслучаеможетпроизойти
короткоезамыкание,перегревилипожар.
•
Примонтажекабелейпитаниянеприкладывайтерастягивающихусилий.
• Обязательно заземлите прибор. Отсутствие надлежащего заземления
можетпривестикпоражениюэлектрическимтоком.
•
Используйтеавтоматическиевыключатели (прерывательутечкитока на
землю,разъединитель(плавкийпредохранитель+B)ипредохранитель
корпуса)суказанным предельнымтоком.Если предельныйтокавтома-
тическоговыключателябольше,чемнеобходимо,можетпроизойтипо-
ломкаилипожар.
1.4. Передтестовымпрогоном
Осторожно:
• Включайтеглавныйвыключательпитаниянепозднее,чемза12часов
до началаэксплуатации.Запуск прибора сразупослевключения вы-
ключателяпитанияможетсерьезноповредитьвнутренниечасти.
• Передначаломэксплуатациипроверьте,чтовсепульты,щиткиидру-
гиезащитныечастиправильноустановлены.Вращающиеся,нагретые
илинаходящиесяподнапряжениемчастимогутнанеститравмы.
• Невключайтекондиционербезустановленноговоздушногофильтра.
Есливоздушныйфильтрнеустановлен,вприбореможетнакопиться
пыль,чтоможетпривестикегополомке.
• Неприкасайтесьниккакимвыключателямвлажнымируками.Этомо-
жетпривестикпоражениюэлектрическимтоком.
•
Неприкасайтеськтрубамсхладагентомголымирукамивовремяработыприбора.
• Послеостановкиприбораобязательноподождитепокрайнеймере
пятьминутпередвыключениемглавноговыключателяпитания. В
противномслучаевозможнапротечкаводыилиполомкаприбора.
(мм)
2. Местоустановки
Fig.2-1
2.1.
Контурныегабариты(Внутреннийприбор)(Fig.2-1)
Выберите надлежащее место, с учетом наличия следующего свободного про-
странства для установки и проведения техобслуживания.
(мм)
Модели W
M35, 50 960
M60, 71 1280
M100, 125, 140 1600
Предупреждение:
Подвешивайте внутренний прибор на потолок, способный выдержать вес прибора.
2.2.Контурныегабариты(Наружныйприбор)
Смотрите руководство по установке наружного прибора.
W
Мин. 300
Макс. 250
Мин. 270
Мин. 500
Мин. 2200
BT79D079H01_02ru.indd 2 3/18/2021 11:45:17 AM
019

3
ru
3. Установкавнутреннегоприбора
123
456
7 8
A
A
BC
D
F
H
G
J
E
236
B
2
75
80320
680
2
19046
6
233
246 C
D
233
246
IF
E
E
H G
H
G
86 285
138
126
19046
Fig.3-2
(мм)
3.1. Проверьтеналичиедополнительных
принадлежностейквнутреннемуприбору(Fig.3-1)
В комплект поставки внутреннего прибора должны входить следующие
дополнительные принадлежности (находящиеся внутри впускной решетки).
Наименование принадлежности Кол-во
1Прокладка 4 шт.
2Изоляция для труб
1 шт. Большой размер (для газового трубопровода)
3Изоляция для труб
1 шт. Небольшой размер (для жидкостного трубопровода)
4Лента 4 шт.
5Соединительная муфта 1 шт. С отметкой “UNIT”
6Изоляция для муфты 1 шт.
7Изоляция для дренажного
трубопровода 1 шт.
8Гайка раструбного стыка 1 шт. ø6,35 (Только M60)
3.2.Подготовкакустановке(Fig.3-2)
3.2.1.Расстояниемеждунавеснымиболтами
(мм)
Модели A B
M35, 50 917 960
M60, 71 1237 1280
M100, 125, 140 1557 1600
3.2.2.Местоположениетрубопроводадляхладагентаидренажа
(мм)
Модели C D
M35, 50 184 203
M60 179 203
M71-140 180 200
A
Переднее боковое выходное отверстие
FЛевый дренажный трубопровод
BЛевое боковое выходное отверстие GГазовый трубопровод
CПравое боковое выходное отверстие HЖидкостный трубопровод
DНезависимая деталь (Съемная) IРезиновая пробка
EПравый дренажный трубопровод Jс соединительной муфтой 5
В случае расположения трубы с задней стороны обязательно удалите за-
штрихованные участки с D независимой детали. Затем верните D независи-
мую деталь в исходное положение.
(Возможно, теплообменник засорен пылью)
Fig.3-1
UNIT
BT79D079H01_02ru.indd 3 3/18/2021 11:45:17 AM
020
