Mitsubishi Electric Mr.SLIM PEAD-A12AA7 User manual

Air-Conditioners
PEAD-A12,18,24,30,36,42AA7
OPERATION MANUAL
For safe and correct use, please read this operation manual thoroughly before operating the air-conditioner unit. English
FOR USER
MANUEL D’UTILISATION
Pour une utilisation correcte sans risques, veuillez lire le manuel d’utilisation en entier avant de vous servir du
climatiseur.
Français
POUR L’UTILISATEUR

2
Contents
1. Safety Precautions .................................................................2
2. Parts Names...........................................................................2
3. Operation................................................................................6
4. Timer.......................................................................................8
5. Emergency Operation for IR Wireless Remote Controller......8
6. Care and Cleaning..................................................................8
7. Trouble Shooting ....................................................................9
8. Specications .......................................................................10
►Beforeinstallingtheunit,makesureyoureadallthe“Safety
Precautions”.
► The“SafetyPrecautions”provideveryimportantpointsregard-
ingsafety.Makesureyoufollowthem.
►Pleasereporttoortakeconsentbythesupplyauthoritybefore
connectiontothesystem.
1.SafetyPrecautions
2.PartsNames
■ IndoorUnit
PEAD-A·AA7
Fan steps 3 steps
Vane –
Louver –
Filter Normal
Filter cleaning indication –
Symbolsusedinthetext
Warning:
Describesprecautionsthatshouldbeobservedtopreventdanger
ofinjuryordeathtotheuser.
Caution:
Describesprecautionsthatshouldbeobservedtopreventdamage
totheunit.
Symbolsusedintheillustrations
: Indicates a part which must be grounded.
Warning:
• Theseappliancesarenotaccessibletothegeneralpublic.
• Theunitmustnotbeinstalledbytheuser.Askthedealeroran
authorizedcompanytoinstalltheunit.Iftheunitisinstalledim-
properly,waterleakage,electricshockorremayresult.
• Donotstandon,orplaceanyitemsontheunit.
• Donotsplashwaterovertheunitanddonottouchtheunitwith
wethands.Anelectricshockmayresult.
• Donotspraycombustiblegasclosetotheunit.Firemayresult.
• Donotplaceagasheateroranyotheropen-ameappliancewhere
itwillbeexposedtotheairdischargedfromtheunit.Incomplete
combustionmayresult.
• Donotremovethefrontpanelorthefanguardfromtheoutdoor
unitwhenitisrunning.
• Whenyounoticeexceptionallyabnormalnoiseorvibration,stop
operation,turnoffthepowerswitch,andcontactyourdealer.
• Neverinsertngers,sticksetc.intotheintakesoroutlets.
• Ifyoudetectoddsmells,stopusingtheunit,turnoffthepower
switchandconsultyourdealer.Otherwise,abreakdown,electric
shockorremayresult.
• ThisairconditionerisNOTintendedforusebychildrenorinrm
personswithoutsupervision.
• Youngchildrenmustbesupervisedtoensurethattheydonotplay
withtheairconditioner.
• Iftherefrigerationgasblowsoutorleaks,stoptheoperationoftheair
conditioner,thoroughlyventilatetheroom,andcontactyourdealer.
• Thisapplianceisintendedtobeusedbyexpertortrainedusersin
shops,inlightindustryandonfarms,orforcommercialusebylay
persons.
• Thisappliancecanbeusedbychildrenagedfrom8yearsandabove
andpersonswithreducedphysical,sensoryormentalcapabilities
orlackofexperienceandknowledgeiftheyhavebeengivensuper-
visionorinstructionconcerninguseoftheapplianceinasafeway
andunderstandthehazardsinvolved.Childrenshallnotplaywith
theappliance.Cleaningandusermaintenanceshallnotbemade
bychildrenwithoutsupervision.
• Thisapplianceisnotintendedforusebypersons(includingchil-
dren)withreduced physical, sensory ormentalcapabilities,or
lackofexperienceandknowledge,unlesstheyhavebeengiven
supervisionorinstructionconcerninguseoftheappliancebya
personresponsiblefortheirsafety.
• Childrenshouldbesupervisedtoensurethattheydonotplaywith
theappliances.
• Wheninstallingorrelocating,orservicingtheairconditioner,use
onlythespeciedrefrigerant(R410A)tochargetherefrigerant
lines.Donotmixitwithanyotherrefrigerantanddonotallowair
toremaininthelines.
Ifairismixedwiththerefrigerant,thenitcanbethecauseof
abnormalhighpressureintherefrigerantline,andmayresultin
anexplosionandotherhazards.
Theuseofanyrefrigerantotherthanthatspeciedforthe
systemwillcausemechanicalfailureorsystemmalfunctionor
unitbreakdown.Intheworstcase,thiscouldleadtoaserious
impedimenttosecuringproductsafety.
Caution:
• Donotuseanysharpobjecttopushthebuttons,asthismaydam-
agetheremotecontroller.
• Neverblockorcovertheindoororoutdoorunit’sintakesoroutlets.
Disposingoftheunit
When you need to dispose of the unit, consult your dealer.
■ PEAD-A·AA7
Ceiling Concealed

3
2.PartsNames
■Remotecontroller(Optionalparts)
Radio frequency interface Wired remote controller IR wireless remote controller
RF thermostat
■WiredRemoteController
Function buttons
④ ③ ② ①
⑤
⑥
⑦ ⑧ ⑨ ⑩
Thefunctionsofthefunctionbuttonschangedependingonthescreen.
Refertothebuttonfunctionguidethatappearsatthebottomofthe
LCDforthefunctionstheyserveonagivenscreen.
Whenthesystemiscentrallycontrolled,thebuttonfunctionguide
thatcorrespondstothelockedbuttonwillnotappear.
83
F
83
F
Fri
Room
Set temp.
Mode Temp. Fan
Cool Auto
Main
Main display:
Cursor Page
Main menu
Vane·Louver·Vent. (Lossnay)
High power
Timer
Weekly timer
OU silent mode
Maindisplay Mainmenu
Functionguide
▌①[ON/OFF]button
Press to turn ON/OFF the indoor unit.
▌②[SELECT]button
Press to save the setting.
▌③[RETURN]button
Press to return to the previous screen.
▌④[MENU]button
Press to bring up the Main menu.
▌⑤BacklitLCD
Operation settings will appear.
When the backlight is off, pressing any button turns the backlight on
and it will stay lit for a certain period of time depending on the screen.
When the backlight is off, pressing any button turns the backlight on
and does not perform its function. (except for the [ON/OFF] button)
▌⑥ON/OFFlamp
This lamp lights up in green while the unit is in operation. It blinks while
the remote controller is starting up or when there is an error.
▌⑦Functionbutton[F1]
Main display: Press to change the operation mode.
Main menu: Press to move the cursor down.
▌⑧Functionbutton[F2]
Main display: Press to decrease temperature.
Main menu: Press to move the cursor up.
▌⑨Functionbutton[F3]
Main display: Press to increase temperature.
Main menu: Press to go to the previous page.
▌⑩Functionbutton[F4]
Main display: Press to change the fan speed.
Main menu: Press to go to the next page.
Controllerinterface
⑦ ⑧ ⑨ ⑩ ⑦ ⑧ ⑨ ⑩

4
The main display can be displayed in two different modes: “Full” and “Basic”. The factory setting is “Full”. To switch to the “Basic” mode, change the
setting on the Main display setting. (Refer to operation manual included with remote controller.)
▌①Operationmode
Indoor unit operation mode appears here.
▌②Presettemperature
Preset temperature appears here.
▌③Clock(SeetheInstallationManual.)
Current time appears here.
▌④Fanspeed
Fan speed setting appears here.
▌⑤Buttonfunctionguide
Functions of the corresponding buttons appear here.
▌⑥
Appears when the ON/OFF operation is centrally controlled.
▌⑦
Appears when the operation mode is centrally controlled.
▌⑧
Appears when the preset temperature is centrally controlled.
▌⑨
Appears when the lter reset function is centrally controlled.
▌⑩
Indicates when lter needs maintenance.
▌⑪Roomtemperature(SeetheInstallationManual.)
Current room temperature appears here.
▌⑫
Appears when the buttons are locked.
<Full mode>
* All icons are displayed for explanation.
Fri
Mode Temp. Fan
Room
Cool Set temp.
83
F
83
F
<Basic mode>
83
F
Fri
Cool
Mode Temp. Fan
Set temp.
④
③
②
①
⑤
⑥
⑦⑧
⑨⑩
⑪
③
⑳
④
㉑
⑰
㉒
⑫ ⑬ ⑭ ⑮ ⑯ ⑱ ⑲ ②
①
⑤
▌⑬
Appears when the On/Off timer, Night setback, or Auto-off timer func-
tion is enabled.
appears when the timer is disabled by the centralized control
system.
▌⑭
Appears when the Weekly timer is enabled.
▌⑮
Appears while the units are operated in the energy-save mode. (Will
not appear on some models of indoor units)
▌⑯
Appears while the outdoor units are operated in the silent mode.
▌⑰
Appears when the built-in thermistor on the remote controller is acti-
vated to monitor the room temperature (⑪).
appears when the thermistor on the indoor unit is activated to
monitor the room temperature.
▌⑱
Appears when the units are operated in the energy-save mode with 3D
i-see Sensor.
▌⑲
Indicates the vane setting.
(This indication is not available for this model.)
▌⑳
Indicates the louver setting.
(This indication is not available for this model.)
▌㉑
Indicates the ventilation setting.
▌㉒
Appears when the preset temperature range is restricted.
Most settings (except ON/OFF, mode, fan speed, temperature) can be made from the Menu screen.
(Refer to operation manual included with remote controller.)
Display
2.PartsNames

5
■WirelessRemote-Controller
1
2
3
Note(Onlyforwirelessremotecontroller):
■ When using the wireless remote controller, point it towards the receiver on the indoor unit.
■ If the remote controller is operated within approximately 2 minutes after power is supplied to the
indoor unit, the indoor unit may beep twice as the unit is performing the initial automatic check.
■ The indoor unit beeps to conrm that the signal transmitted from the remote controller has been
received. Signals can be received up to approximately 7 meters, 275-19/32 inch in a direct line
from the indoor unit in an area 45° to the left and right of the unit. However, illumination such as
uorescent lights and strong light can affect the ability of the indoor unit to receive signals.
■ If the operation lamp near the receiver on the indoor unit is blinking, the unit needs to be inspected.
Consult your dealer for service.
■ Handle the remote controller carefully! Do not drop the remote controller or subject it to strong
shocks. In addition, do not get the remote controller wet or leave it in a location with high humidity.
■ To avoid misplacing the remote controller, install the holder included with the remote controller on
a wall and be sure to always place the remote controller in the holder after use.
Batteryinstallation/replacement
1. Remove the top cover, insert 2 AAA batteries,
and then install the top cover.
2. Press the Reset button.
■Outdoorunit
Two AAA batteries
Insert the negative (–)
end of each battery rst.
Install the batteries in the
correct directions
(+, –) !
Press the Reset button
with an object that has a
narrow end.
Top cover
*For explanation purposes, all of the items that
appear in the display are shown.
*All items are displayed when the Reset but-
ton is pressed.
Transmission indicator
Timer indicator
Remote controller display
ON/OFF button
Set Temperature buttons
Fan Speed button (Changes fan speed)
Airow button (Changes up/down airow direction)
Mode button (Changes operation mode)
Check button
Test Run button
Transmission area
Operation areas
Timer Off button
Timer On button
Hour button
Minute button
Set Time button (Sets the time)
Louver button (Changes left/right airow direction)
Reset button
Power
Earth
Service Panel
Indoor-Outdoor
Connection wire
Ref. Pipes
2.PartsNames

6
3.Operation
■Abouttheoperationmethod,refertotheoperationmanualthatcomeswitheachremotecontroller.
3.1.TurningON/OFF
[ON] [OFF]
Press the [ON/OFF] button.
The ON/OFF lamp will light up in green,
and the operation will start.
Press the [ON/OFF] button again.
The ON/OFF lamp will come off, and
the operation will stop.
■Operationstatusmemory
Remote controller setting
Operation mode Operation mode before the power was turned off
Preset temperature Preset temperature before the power was turned off
Fan speed Fan speed before the power was turned off
■Settablepresettemperaturerange
Operation mode Preset temperature range
Cool/Dry 67 - 87 ºF/19 - 30 ºC
Heat 63 - 83 ºF/17 - 28 ºC
Auto 67 - 83 ºF/19 - 28 ºC
Fan/Ventilation Not settable
Note:
EvenifyoupresstheON/OFFbuttonimmediatelyaftershuttingdowntheoperationisprogress,theairconditionerwillnotstartforabout3
minutes.Thisistopreventtheinternalcomponentsfrombeingdamaged.
3.2.ModeSelection Press the [F1] button to go through the op-
eration modes in the order of “Cool”, “Dry”,
“Fan”, “Auto”, and “Heat”. Select the desired
operation mode.
Cool Dry Fan
Auto Heat
• Operation modes that are not available to
the connected outdoor unit models will not
appear on the display.
Whattheblinkingmodeiconmeans
The mode icon will blink when other indoor units in the same refrigerant
system (connected to the same outdoor unit) are already operated in a
different mode. In this case, the rest of the unit in the same group can
only be operated in the same mode.
Automaticoperation
■According to a set temperature, cooling operation starts if the room tem-
perature is too hot and heating operation starts if the room temperature
is too cold.
■During automatic operation, if the room temperature changes and re-
mains 2.0 °C, 4 °F or more above the set temperature for 15 minutes,
the air conditioner switches to cool mode. In the same way, if the room
temperature remains 2.0 °C, 4 °F or more below the set temperature for
15 minutes, the air conditioner switches to heat mode.
F1 F2 F3 F4
83
F
83
F
Cool
Room
AutoSet temp.
Mode Temp. Fan
Fri
3.3.Temperaturesetting
<Cool,Dry,Heat,andAuto>
Cool
Room
AutoSet temp.
Mode Temp. Fan
Fri
84
F
84
F
Example display
(Centigrade in 0.5-degree increments)
F1 F2 F3 F4
83
F
83
F
Cool
Room
AutoSet temp.
Mode Temp. Fan
Fri
Press the [F2] button to decrease the preset temperature, and press the
[F3] button to increase.
• Refer to the table on page 6 for the settable temperature range for dif-
ferent operation modes.
• Preset temperature range cannot be set for Fan/Ventilation operation.
• Preset temperature will be displayed either in Centigrade in 0.5- or 1-de-
gree increments, or in Fahrenheit, depending on the indoor unit model
and the display mode setting on the remote controller.
Cool mode 15 minutes (switches from
heating to cooling)
Set temperature +2.0 °C, +4 °F
Set temperature
Set temperature -2.0 °C, -4 °F
15 minutes (switches from
cooling to heating)

7
3.4.Fanspeedsetting
F1 F2 F3 F4
Cool
Room
Set temp.
Mode Temp. Fan
Fri
83
F
83
F
Press the [F4] button to go through the fan speeds in the following order.
Auto
• The available fan speeds depend on the models of connected indoor units.
Notes:
●Thenumberofavailablefanspeedsdependsonthetypeofunit
connected.
●Inthefollowingcases,theactualfanspeedgeneratedbytheunit
willdifferfromthespeedshownontheremotecontrollerdisplay.
1.Whilethedisplayisin“STANDBY”or“DEFROST”states.
2.Whenthetemperatureoftheheatexchangerislowintheheat-
ingmode.
(e.g.immediatelyafterheatingoperationstarts)
3.InHEATmode,whenroomtemperatureishigherthanthetem-
peraturesetting.
4.WhentheunitisinDRYmode.
3.5.NavigatingthroughtheMainmenu
<AccessingtheMainmenu>
F1 F2 F3 F4
Main
Main display:
Cursor Page
Main menu
Vane·Louver·Vent. (Lossnay)
High power
Timer
Weekly timer
OU silent mode
<Itemselection>
F1 F2 F3 F4
Main
Main display:
Cursor Page
Main menu
Vane·Louver·Vent. (Lossnay)
High power
Timer
Weekly timer
OU silent mode
Cursor
Press the [MENU] button.
The Main menu will appear.
Press [F1] to move the cursor down.
Press [F2] to move the cursor up.
<Navigatingthroughthepages>
F1 F2 F3 F4
Main
Main display:
Cursor Page
Main menu
Vane·Louver·Vent. (Lossnay)
High power
Timer
Weekly timer
OU silent mode
page
<Savingthesettings>
F1 F2 F3 F4
OU silent mode
Mon Tue Wed Thu Fri Sat Sun
Start Stop Silent
-
Setting display:
day
<ExitingtheMainmenuscreen>
F1 F2 F3 F4
83
F
83
F
Cool
Room
Set temp.
Mode Temp. Fan
Fri
If no buttons are touched for 10 minutes, the screen will automatically
return to the Main display. Any settings that have not been saved will
be lost.
<Displayofunsupportedfunctions>
F1 F2 F3 F4
Title
Not available
Unsupported function
Return:
3.6. Ventilation
►ForLOSSNAYcombination
● The following 2 patterns of operation are available.
• Run the ventilator together with the indoor unit.
• Run the ventilator independently.
Note:
●Withsomemodelcongurations,thefanontheindoorunitmaycomeon
evenwhenyousettheventilatortorunindependently.
Note(forIRwirelessremotecontrollerandRFthermostat):
●Runningtheventilatorindependentlyisnotavailable.
●Noindicationontheremotecontroller.
Press [F3] to go to the previous page.
Press [F4] to go to the next page.
Select the desired item, and press
the [SELECT] button.
The screen to set the selected item
will appear.
Press the [RETURN] button to exit
the Main menu and return to the
Main display.
The message at left will appear
if the user selects a function not
supported by the corresponding
indoor unit model.
3.Operation

8
►Cleaningthelters
• Clean the lters using a vacuum cleaner. If you do not have a vacuum
cleaner, tap the lters against a solid object to knock off dirt and dust.
• If the lters are especially dirty, wash them in lukewarm water. Take care
to rinse off any detergent thoroughly and allow the lters to dry completely
before putting them back into the unit.
Caution:
• Donotdrytheltersindirectsunlightorbyusingaheatsource,
suchasanelectricheater:thismaywarpthem.
• Donotwashtheltersinhotwater(above122°F[50°C]),asthis
maywarpthem.
• Makesurethattheairltersarealwaysinstalled.Operatingtheunit
withoutairlterscancausemalfunction.
Caution:
• Beforeyoustartcleaning,stopoperationandturnOFFthepower
supply.
• Indoorunitsareequippedwithlterstoremovethedustofsucked-
inair.Cleantheltersusingthemethodsshowninthefollowing
sketches.
6.CareandCleaning
►Filterremoval
Caution:
• Inremovingthelter,precautionsmustbetakentoprotectyour
eyesfromdust.Also,ifyouhavetoclimbuponastooltodothe
job,becarefulnottofall.
• Whenthelterisremoved,donottouchthemetallicpartsinside
theindoorunit,otherwiseinjurymayresult.
■PEAD-A·AA7
• Whileliftingthelterknob,pullit.
AAir intake BAir outlet CFilter DKnob
5.EmergencyOperationforIRWirelessRemoteController
ON/OFF
HEAT COOL
2
1
1ON/OFFlamp (lit when unit is operating; unlit when unit is not operating)
2Emergencyoperation
In cases where the remote control unit does not operate properly, use
either the COOL or HEAT button on the wireless remote control
signal receiver to toggle the unit on or off. On cooler only units, pushing
the HEAT button toggles the fan on and off.
Pressing the COOL or HEAT button selects the following settings.
Operation mode COOL HEAT
Preset temperature 24 °C/75 °F 24 °C/75 °F
Fan speed High High
B
A
DD
C
4.Timer
■Timer functions are different by each remote controller.
■Refer to the operation manual that comes with each remote controller for the details included an operation method.

9
7.TroubleShooting
Having trouble? Here is the solution. (Unit is operating normally.)
Air conditioner does not heat or cool well. ■ Clean the lter. (Airow is reduced when the lter is dirty or clogged.)
■ Check the temperature adjustment and adjust the set temperature.
■Make sure that there is plenty of space around the outdoor unit. Is the
indoor unit air intake or outlet blocked?
■Has a door or window been left open?
When heating operation starts, warm air does not blow from the indoor
unit soon.
■ Warm air does not blow until the indoor unit has sufciently warmed up.
During heating mode, the air conditioner stops before the set room tem-
perature is reached.
■When the outdoor temperature is low and the humidity is high, frost
may form on the outdoor unit. If this occurs, the outdoor unit performs a
defrosting operation. Normal operation should begin after approximately
10 minutes.
When the airow direction is changed, the vanes always move up and
down past the set position before nally stopping at the position.
■ When the airow direction is changed, the vanes move to the set posi-
tion after detecting the base position.
A owing water sound or occasional hissing sound is heard. ■ These sounds can be heard when refrigerant is owing in the air con-
ditioner or when the refrigerant ow is changing.
A cracking or creaking sound is heard. ■These sounds can be heard when parts rub against each due to expan-
sion and contraction from temperature changes.
The room has an unpleasant odor. ■The indoor unit draws in air that contains gases produced from the walls,
carpeting, and furniture as well as odors trapped in clothing, and then
blows this air back into the room.
A white mist or vapor is emitted from the indoor unit. ■If the indoor temperature and the humidity are high, this condition may
occur when operation starts.
■ During defrosting mode, cool airow may blow down and appear like a
mist.
Water or vapor is emitted from the outdoor unit. ■During cooling mode, water may form and drip from the cool pipes and
joints.
■During heating mode, water may form and drip from the heat exchanger.
■During defrosting mode, water on the heat exchanger evaporates and
water vapor may be emitted.
The operation indicator does not appear in the wired remote controller
display. (*1) ■Turn on the power switch. “ ” will appear in the wired remote controller
display.
“ ” appears in the wired remote controller display. (*1) ■During central control, “ ” appears in the wired remote controller
display and air conditioner operation cannot be started or stopped using
the wired remote controller.
When restarting the air conditioner soon after stopping it, it does not
operate even though the ON/OFF button is pressed.
■Wait approximately three minutes.
(Operation has stopped to protect the air conditioner.)
Air conditioner operates without the ON/OFF button being pressed. (*1) ■Is the on timer set?
Press the ON/OFF button to stop operation.
■Is the air conditioner connected to a central wired remote controller?
Consult the concerned people who control the air conditioner.
■Does “ ” appear in the wired remote controller display?
Consult the concerned people who control the air conditioner.
■Has the auto recovery feature from power failures been set?
Press the ON/OFF button to stop operation.
Air conditioner stops without the ON/OFF button being pressed. (*1) ■Is the off timer set?
Press the ON/OFF button to restart operation.
■Is the air conditioner connected to a central wired remote controller?
Consult the concerned people who control the air conditioner.
■Does “ ” appear in the wired remote controller display?
Consult the concerned people who control the air conditioner.
Wired remote controller timer operation cannot be set. (*1) ■Are timer settings invalid?
If the timer can be set, , or appears in the wired remote controller
display.
“PLEASE WAIT” appears in the wired remote controller display. (*1) ■The initial settings are being performed. Wait approximately 3 minutes.
An error code appears in the remote controller display. ■The protection devices have operated to protect the air conditioner.
■Do not attempt to repair this equipment by yourself.
Turn off the power switch immediately and consult your dealer. Be sure
to provide the dealer with the model name and information that appeared
in the remote controller display.
Draining water or motor rotation sound is heard. ■When cooling operation stops, the drain pump operates and then stops.
Wait approximately 3 minutes.
The fan speed changes in spite of not changing the setting. ■Not to blow out cold air at the beginning of heating operation, the air
conditioner automatically adjusts the fan speed gradually from lower to
the set speed. It also adjust its fan speed to protect the fan motor when
return air temperature or fan speed excessively rises.
*1: Only for wired remote controller

10
PEAD-A·AA7 series
Item Model A12AA7 A18AA7 A24AA7 A30AA7 A36AA7 A42AA7
Power source 208, 230V 60Hz
Cooling capacity*1/
Heating capacity*1
Btu/h 12,000/14,000 18,000/19,000 24,000/26,000 30,000/32,000 35,000/37,000 42,000/45,000
kW 3.5/4.1 5.3/5.6 7.0/7.6 8.8/9.4 10.3/10.8 12.3/13.2
Dimen-
sions
Height mm [in] 250 [9-7/8]
Width mm [in] 900 [35-7/16] 1100 [43-5/16] 1400 [55-1/8]
Depth mm [in] 732 [28-7/8]
Net weight kg [lb] 26 [58] 28 [62] 31 [69] 39 [86] 41 [91]
Fan
Airow rate
(Low-Mid-High) CFM 353-424-494 424-512-600 512-635-741 618-742-883 847-1024-1201 1042-1254-1483
External static
pressure*2
in. WG 0.14-0.20-0.28-0.40-0.60
[Pa] [35/50/70/100/150]
Sound level
(Low-Mid-High)*2*3 dB (A) 28-30-34 30-33-37 30-33-37 30-34-39 33-38-42 36-40-44
Filter Standard lter
7.TroubleShooting
Having trouble? Here is the solution. (Unit is operating normally.)
Noise is louder than specications. ■The indoor operation sound level is affected by the acoustics of the
particular room as shown in the following table and will be higher than
the noise specication, which was measured in an echo-free room.
High sound-
absorbing rooms Normal rooms Low sound-
absorbing rooms
Location
examples
Broadcasting
studio, music
room, etc.
Reception
room, hotel
lobby, etc.
Ofce, hotel
room
Noise levels 3 to 7 dB 6 to 10 dB 9 to 13 dB
Nothing appears in the IR wireless remote controller display, the display
is faint, or signals are not received by the indoor unit unless the IR remote
controller is close. (*2)
■The batteries are low.
Replace the batteries and press the Reset button.
■If nothing appears even after the batteries are replaced, make sure that
the batteries are installed in the correct directions (+, –).
The operation lamp near the receiver for the IR wireless remote controller
on the indoor unit is blinking. (*2)
■The self diagnosis function has operated to protect the air conditioner.
■Do not attempt to repair this equipment by yourself.
Turn off the power switch immediately and consult your dealer. Be sure
to provide the dealer with the model name.
8.Specications
Notes: 1. Ratingconditions(cooling) Indoor : 80°F[26.7°C]D.B.,67°F[19.4°C]W.B. Outdoor : 95°F[35°C]D.B.
 2. Ratingconditions(heating) Indoor : 70°F[21.1°C]D.B. Outdoor : 47°F[8.3°C]D.B.,43°F[6.1°C]W.B.
 3. Thecapacityisindicatedthevaluewhenoneindoorunitisconnectedtotheoutdoorunit.
 4. Specicationssubjecttochangewithoutnotice.
 5. Theexternalstaticpressureissetto0.20in.WG(50Pa)atfactoryshipment.
Guaranteedoperatingrange
Indoor
Cooling
Upper limit 95 °F [35 °C] D.B.
71 °F [21.7 °C] W.B.
Lower limit 67 °F [19.4 °C] D.B.
57 °F [13.9 °C] W.B.
Heating
Upper limit 80 °F [26.7 °C] D.B.
–
Lower limit 70 °F [21.1 °C] D.B.
–
Notes:1. Unitsshouldbeinstalledbylicensedelectriccontractoraccordinglytolocalcoderequirement.
2. Foroutdoorunitstobeconnected,refertotheInstallationManualthatcomeswiththeunits.
*2: Only for IR wireless remote controller
