SERVICE MANUAL
No.OCH526
SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
R410A
September 2012
Note:
• This manual describes only
service data of the outdoor
units.
• RoHS compliant products
have <G> mark on the spec
name plate.
PARTS CATALOG (OCB526)
Outdoor unit
[Model names]
PUHZ-SHW80VHA
PUHZ-SHW112VHA
PUHZ-SHW112YHA
PUHZ-SHW140YHA
[Service Ref.]
PUHZ-SHW80VHA
PUHZ-SHW112VHA
PUHZ-SHW112YHA
PUHZ-SHW140YHA
CONTENTS
1. REFERENCE MANUAL································2
2. SAFETY PRECAUTION ·······························3
3. SPECIFICATIONS ········································7
4. DATA·····························································9
5. OUTLINES AND DIMENSIONS·················· 11
6. WIRING DIAGRAM·····································12
7. WIRING SPECIFICATIONS························14
8. REFRIGERANT SYSTEM DIAGRAM········15
9. TROUBLESHOOTING································17
10. FUNCTION SETTING·································73
11. MONITORING THE OPERATION DATA BY THE REMOTE CONTROLLER ····80
12. EASY MAINTENANCE FUNCTION···········90
13. DISASSEMBLY PROCEDURE···················95
www.zubadan.ro

2
1REFERENCE MANUAL
INDOOR UNIT SERVICE MANUAL
1-1. FOR AIR TO WATER SYSTEM
Model name Service ref. Service manual No.
EHST20C-VM6HB
EHST20C-YM9HB
EHST20C-VM6B
EHST20C-YM9B
EHST20C-VM6EB
EHST20C-YM9EB
EHST20C-VM6SB
EHPT20X-VM2HB
EHPT20X-VM6HB
EHPT20X-YM9HB
EHPT20X-VM6B
EHPT20X-YM9B
EHST20C-VM6HB.UK
EHST20C-YM9HB.UK
EHST20C-VM6B.UK
EHST20C-YM9B.UK
EHST20C-VM6EB.UK
EHST20C-YM9EB.UK
EHST20C-VM6SB.UK
EHPT20X-VM2HB.UK
EHPT20X-VM6HB.UK
EHPT20X-YM9HB.UK
EHPT20X-VM6B.UK
EHPT20X-YM9B.UK
OCH531
EHSC-VM6B
EHSC-YM9B
EHSC-VM6EB
EHSC-YM9EB
EHPX-VM2B
EHPX-VM6B
EHPX-YM9B
ERSC-VM2B
EHSC-VM6B.UK
EHSC-YM9B.UK
EHSC-VM6EB.UK
EHSC-YM9EB.UK
EHPX-VM2B.UK
EHPX-VM6B.UK
EHPX-YM9B.UK
ERSC-VM2B.UK
OCH532
1-2. FOR AIR TO AIR SYSTEM
Model name Service Ref. Service
Manual No.
PLA-RP71/125BA2 PLA-RP71/125BA2.UK OCH412
OCB412
PLA-RP100BA3 PLA-RP100BA3 OCH459
OCB459
PLA-ZRP35/50/60/71/100/125BA PLA-ZRP35/50/60/71/100/125BA OCH529
OCB529
PKA-RP100KAL PKA-RP100KAL.TH OCH452
OCB452
PKA-RP60/100FAL PKA-RP50FAL2 PKA-RP60/100FAL PKA-RP50FAL2 OC331
PKA-RP50HAL PKA-RP50HAL OCH453
OCB453
PEAD-RP50/60/71/100/125/JA(L) PEAD-RP50/60/71/100/125/JA(L)(R1).UK HWE08130 BWE09220
BWE09240
PEAD-RP50/60/71/100/125/JA(L)Q PEAD-RP50/60/71/100/125/JA(L)Q.UK BWE10160
OCH526

3
2SAFETY PRECAUTION
2-2. CAUTIONS RELATED TO NEW REFRIGERANT
Cautions for units utilizing refrigerant R410A
Use new refrigerant pipes.
Make sure that the inside and outside of refrige-
rant piping is clean and it has no contaminants
such as sulfur, oxides, dirt, shaving particles, etc,
which are hazard to refrigerant cycle.
In addition, use pipes with specified thickness.
Store the piping to be used indoors during instal-
lation, and keep both ends of the piping sealed
until just before brazing. (Leave elbow joints, etc.
in their packaging.)
The refrigerant oil applied to flare and flange
connections must be ester oil, ether oil or
alkylbezene oil in a small amount.
In case of using the existing pipes for R22, be careful with
the followings.
· Be sure to perform replacement operation before test run.
· Change flare nut to the one provided with this product.
Use a newly flared pipe.
· Avoid using thin pipes.
Charge refrigerant from liquid phase of gas
cylinder.
If the refrigerant is charged from gas phase, composition change
may occur in refrigerant and the efficiency will be lowered.
Use a vacuum pump with a reverse flow check
valve.
Vacuum pump oil may flow back into refrigerant cycle and
that can cause deterioration of refrigerant oil etc.
Use the following tools specifically designed for
use with R410A refrigerant.
The following tools are necessary to use R410A refrigerant.
Handle tools with care.
If dirt, dust or moisture enters into refrigerant cycle, that can
cause deterioration of refrigerant oil or malfunction of com-
pressor.
Do not use a charging cylinder.
If a charging cylinder is used, the composition of refrigera-
nt will change and the efficiency will be lowered.
Flare tool
Electronic refrigerant
charging scale
Vacuum pump adaptor
Size adjustment gauge
Gauge manifold
Torque wrench
Gas leak detector
Charge hose
Tools for R410A
Contamination inside refrigerant piping can cause deterio-
ration of refrigerant oil etc.
If dirt, dust or moisture enters into refrigerant cycle, that can
cause deterioration of refrigerant oil or malfunction of compressor.
If large amount of mineral oil enters, that can cause deterio-
ration of refrigerant oil etc.
Ventilate the room if refrigerant leaks during
operation. If refrigerant comes into contact with
a flame, poisonous gases will be released.
Use the specified refrigerant only.
Never use any refrigerant other than that specified.
Doing so may cause a burst, an explosion, or fire when the
unit is being used, serviced, or disposed of.
Correct refrigerant is specified in the manuals and on the
spec labels provided with our products.
We will not be held responsible for mechanical failure,
system malfunction, unit breakdown or accidents caused
by failure to follow the instructions.
Do not use refrigerant other than R410A.
If other refrigerant (R22 etc.) is used, chlorine in refrige-
rant can cause deterioration of refrigerant oil etc.
2-1. ALWAYS OBSERVE FOR SAFETY
Before obtaining access to terminal, all supply circuits must be disconnected.
Preparation before the repair service.
• Prepare the proper tools.
• Prepare the proper protectors.
• Provide adequate ventilation.
• After stopping the operation of the air conditioner, turn off the power-supply breaker.
• Discharge the condenser before the work involving the electric parts.
Precautions during the repair service.
• Do not perform the work involving the electric parts with wet hands.
• Do not pour water into the electric parts.
• Do not touch the refrigerant.
• Do not touch the hot or cold areas in the refrigerating cycle.
• When the repair or the inspection of the circuit needs to be done without turning off the power,
exercise great caution not to touch the live parts.
OCH526

4
Gravimeter
Unit
[3] Service tools
Use the below service tools as exclusive tools for R410A refrigerant.
[4] Refrigerant leakage detection function
This air conditioner can detect refrigerant leakage which may happen during a long period of use. In order to enable the
leakage detection, settings are required to let the unit memorize the initial conditions (initial learning).
Refer to 14-3. INITIAL SETTINGS FOR REFRIGERANT LEAKAGE DETECTION FUNCTION.
[1] Cautions for service
(1) Perform service after recovering the refrigerant left in unit completely.
(2) Do not release refrigerant in the air.
(3) After completing service, charge the cycle with specified amount of refrigerant.
(4) When performing service, install a filter drier simultaneously.
Be sure to use a filter drier for new refrigerant.
[2] Additional refrigerant charge
When charging directly from cylinder
· Check that cylinder for R410A on the market is syphon type.
· Charging should be performed with the cylinder of syphon stood vertically. (Refrigerant is charged from liquid phase.)
No. Tool name Specifications
1Gauge manifold · Only for R410A
· Use the existing fitting specifications. (UNF1/2)
· Use high-tension side pressure of 5.3 MPa·G or over.
2Charge hose · Only for R410A
· Use pressure performance of 5.09 MPa·G or over.
3Electronic scale —
4Gas leak detector · Use the detector for R134a, R407C or R410A.
5Adaptor for reverse flow check · Attach on vacuum pump.
6Refrigerant charge base —
7Refrigerant cylinder · Only for R410A · Top of cylinder (Pink)
· Cylinder with syphon
8Refrigerant recovery equipment —
OCH526

5
2-3. PRECAUTIONS WHEN REUSING EXISTING R22 REFRIGERANT PIPES
(1) Flowchart
Connecting a new air conditioner
Flaring work should be done so that flare meets the dimension for R410A.
Use flare nut provided with indoor and outdoor unit.
When using gas piping of :19.05mm for SHW112, 140.
Make sure that DIP SW8-1 on outdoor unit controller board is set to ON.
This is to keep the pressure on pipes within permissible range.
●Use different diameter joint or adjust the piping size by brazing.
When using pipes larger than specified size for SHW80.
Make sure that DIP SW8-1 on outdoor unit controller board is set to ON.

This is to prevent oil flow ratio from lowering due to the decrease in flowing refrigerant.
●Use different diameter joint or adjust the piping size by brazing.
When existing pipes are specified size.
The pipes can be reused.
●Use different diameter joint or adjust the piping size by brazing.
SHW·HA
Measure the existing pipe thickness and check for damage.
Check if existing air conditioner can operate.
Existing air conditioner can
operate.
Disconnect existing air con-
ditioner from piping.
Existing pipes can be reused.
Perform cooling operation
for about 30 minutes and
then do a pump down work.
Use a refrigerant recovery
equipment to recover the
refrigerant.
Existing air conditioner
cannot operate.
The existing pipe thickness meets speci-
fications and the pipes are not damaged.
The existing pipe thickness does not meet
specifications or the pipes are damaged.
Connect a new air conditioner.
●The air conditioner automatically performs cooling operation through replace filter for about 2 hours.
Existing pipes cannot be
reused. Use new pipes.
+In case existing pipes were used
for gas or oil heat pump system,
be sure to clean the pipes.
OCH526

6
(2) Cautions for refrigerant piping work
New refrigerant R410A is adopted for replacement inverter series. Although the refrigerant piping work for R410A is same
as for R22, exclusive tools are necessary so as not to mix with different kind of refrigerant. Furthermore as the working
pressure of R410A is 1.6 times higher than that of R22, their sizes of flared sections and flare nuts are different.
1Thickness of pipes
Because the working pressure of R410A is higher compared to R22, be sure to use refrigerant piping with thickness
shown below. (Never use pipes of 0.7 mm or below.)
2Dimensions of flare cutting and flare nut
The component molecules in HFC refrigerant are smaller compared to conventional refrigerants. In addition to that,
R410A is a refrigerant, which has higher risk of leakage because its working pressure is higher than that of other refrig-
erants. Therefore, to enhance airtightness and intensity, flare cutting dimension of copper pipe for R410A has been
specified separately from the dimensions for other refrigerants as shown below. The dimension B of flare nut for R410A
also has partly been changed to increase intensity as shown below. Set copper pipe correctly referring to copper pipe
flaring dimensions for R410A below. For 1/2 and 5/8 inch, the dimension B changes.
Use torque wrench corresponding to each dimension.
3Tools for R410A (The following table shows whether conventional tools can be used or not.)
1/4
3/8
1/2
5/8
3/4
6.35
9.52
12.70
15.88
19.05
0.8
0.8
0.8
1.0
—
0.8
0.8
0.8
1.0
1.0
Nominal
dimensions(inch)
Diagram below: Piping diameter and thickness
Outside
diameter (mm)
Thickness (mm)
R410A R22
1/4
3/8
1/2
5/8
3/4
6.35
9.52
12.70
15.88
19.05
9.1
13.2
16.6
19.7
—
9.0
13.0
16.2
19.4
23.3
Nominal
dimensions(inch)
Flare cutting dimensions
Outside
diameter Dimension A ( )
+0
-0.4
(mm)
R410A R22 1/4
3/8
1/2
5/8
3/4
6.35
9.52
12.70
15.88
19.05
17.0
22.0
26.0
29.0
-
17.0
22.0
24.0
27.0
36.0
Nominal
dimensions(inch)
Flare nut dimensions Outside
diameter Dimension B (mm)
R410A
+
+36.0mm for
indoor unit
of RP100,
125 and 140
R22
Gauge manifold
Charge hose
Gas leak detector
Refrigerant recovery equipment
Refrigerant cylinder
Applied oil
Safety charger
Charge valve
Vacuum pump
Flare tool
Bender
Pipe cutter
Welder and nitrogen gas cylinder
Refrigerant charging scale
Vacuum gauge or thermis-
tor vacuum gauge and
vacuum valve
Charging cylinder
Air purge, refrigerant charge
and operation check
Gas leak check
Refrigerant recovery
Refrigerant charge
Apply to flared section
Prevent compressor malfunction
when charging refrigerant by
spraying liquid refrigerant
Prevent gas from blowing out
when detaching charge hose
Vacuum drying and air
purge
Flaring work of piping
Bend the pipes
Cut the pipes
Weld the pipes
Charge refrigerant
Check the degree of vacuum. (Vacuum
valve prevents back flow of oil and refri-
gerant to thermistor vacuum gauge)
Refrigerant charge
Tool exclusive for R410A
Tool exclusive for R410A
Tool for HFC refrigerant
Tool exclusive for R410A
Tool exclusive for R410A
Ester oil, ether oil and alky-
lbenzene oil (minimum amount)
Tool exclusive for R410A
Tool exclusive for R410A
Tools for other refrigerants can
be used if equipped with adop-
ter for reverse flow check
Tools for other refrigerants
can be used by adjusting
flaring dimension
Tools for other refrigerants can be used
Tools for other refrigerants can be used
Tools for other refrigerants can be used
Tools for other refrigerants can be used
Tools for other refrigerants
can be used
Tool exclusive for R410A
Tools and materials Use R410A tools Can R22 tools be used?
(Usable if equipped
with adopter for rever-
se flow)
(Usable by adjusting
flaring dimension)
Can R407C tools be used?
Ester oil, ether oil:
Alkylbenzene oil: minimum amount
(Usable if equipped
with adopter for rever-
se flow)
(Usable by adjusting
flaring dimension)
: Prepare a new tool. (Use the new tool as the tool exclusive for R410A.)
: Tools for other refrigerants can be used under certain conditions.
: Tools for other refrigerants can be used.
Dimension A
Dimension B
OCH526

7
<Reference data> Plate heat exchanger (MWA2-38PA)
SHW80 SHW112 SHW140
Nominal water flow L/min 22.9 32.1 40.1
Heating
(A7/W35) Capacity kW 8.0 11.2 14.0
COP 4.65 4.46 4.22
Power input kW 1.72 2.51 3.32
Heating
(A7/W45) Capacity kW 8.0 11.2 14.0
COP 3.42 3.51 3.28
Power input kW 2.34 3.19 4.27
Heating
(A2/W35) Capacity kW 8.0 11.2 14.0
COP 3.55 3.34 2.96
Power input kW 2.25 3.35 4.73
Heating
(A2/W45) Capacity kW 8.0 11.2 14.0
COP 2.90 2.78 2.45
Power input kW 2.76 4.03 5.71
Nominal water flow L/min 20.4 32.1 35.8
Cooling
(A35/W7) Capacity kW 7.1 10.0 12.5
EER 3.31 2.83 2.17
Power input kW 2.14 3.53 5.76
Cooling
(A35/W18) Capacity kW 7.1 10.0 12.5
EER 4.11 4.74 4.26
Power input kW 1.72 2.11 2.93
Rating conditions
Nominal operating condition
Heating (A2/W35)
Outside air temperature (Dry-bulb) + 2 °C
Outside air temperature (Wet-bulb) + 1 °C
Water temperature (inlet/outlet) + 30 °C/+ 35 °C
Heating (A7/W35)
Outside air temperature (Dry-bulb) + 7 °C
Outside air temperature (Wet-bulb) + 6 °C
Water temperature (inlet/outlet) + 30 °C/+ 35 °C
Heating (A7/W45)
Outside air temperature (Dry-bulb) + 7 °C
Outside air temperature (Wet-bulb) + 6 °C
Water temperature (inlet/outlet) + 40 °C/+ 45 °C
Heating (A7/W55)
Outside air temperature (Dry-bulb) + 7 °C
Outside air temperature (Wet-bulb) + 6 °C
Water temperature (inlet/outlet) + 50 °C/+ 55 °C
Heating (A-7/W35)
Outside air temperature (Dry-bulb) - 7 °C
Outside air temperature (Wet-bulb) —
Water temperature (inlet/outlet) — °C/+ 35 °C
Heating (A-7/W45)
Outside air temperature (Dry-bulb) - 7 °C
Outside air temperature (Wet-bulb) —
Water temperature (inlet/outlet) — °C/+ 45 °C
Heating (A-7/W55)
Outside air temperature (Dry-bulb) - 7 °C
Outside air temperature (Wet-bulb) —
Water temperature (inlet/outlet) — °C/+ 55 °C
Heating (A-15/W35)
Outside air temperature (Dry-bulb) - 15 °C
Outside air temperature (Wet-bulb) —
Water temperature (inlet/outlet) — °C/+ 35 °C
Heating (A-15/W45)
Outside air temperature (Dry-bulb) - 15 °C
Outside air temperature (Wet-bulb) —
Water temperature (inlet/outlet) — °C/+ 45 °C
Heating (A-15/W55)
Outside air temperature (Dry-bulb) - 15 °C
Outside air temperature (Wet-bulb) —
Water temperature (inlet/outlet) — °C/+ 55 °C
Cooling (A35/W7)
Outside air temperature (Dry-bulb) + 35 °C
Outside air temperature (Wet-bulb) + 24 °C
Water temperature (inlet/outlet) + 12 °C/+ 7 °C
Cooling (A35/W18)
Outside air temperature (Dry-bulb) + 35 °C
Outside air temperature (Wet-bulb) + 24 °C
Water temperature (inlet/outlet) + 23 °C/+ 18 °C
Note: "COP" and "Power input" in the above table are values that does NOT contains the "pump input (based on EN 14511)".
3SPECIFICATIONS
OCH526

8
A
kW
W
kW
*
/min(CFM )
dB
dB
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
L
mm(in.)
mm(in.)
Power supply (phase, cycle, voltage)
Max. current
External finish
Refrigerant control
Compressor
Model
Motor output
Starter type
Protection devices
Crankcase heater
Heat exchanger
Fan Fan(drive) %No.
Fan motor output
Airflow
Defrost method
Noise level
Dimensions
Weight
Refrigerant
Charge
Oil (Model)
Pipe size O.D.
Connection method
Between the indoor &
outdoor unit
Cooling
Heating
W
D
H
Liquid
Gas
Indoor side
Outdoor side
Height difference
Piping length
Service Ref.
PUHZ-SHW80VHA
PUHZ-SHW112VHA
28
Munsell 3Y 7.8/1.1
Linear Expansion Valve
Hermetic
ANB33FJMMT
Inverter
—
Plate fin coil
Propeller fan %2
0.074+0.074
100(3,530)
Reverse cycle
950(37-3/8)
330+30(13+1-3/16)
1,350(53-1/8)
120(265)
R410A
5.5(12.1)
1.40(FV50S)
9.52(3/8)
15.88(5/8)
Flared
Flared
Max. 30m
Max. 75m
HP switch, LP switch
Discharge thermo, Comp. surface thermo
Single 50Hz, 230V
OUTDOOR UNIT
REFRIGERANT PIPING
2.5
51
52
A
kW
W
kW
*
/min(CFM )
dB
dB
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
kg(lbs)
L
mm(in.)
mm(in.)
Power supply (phase, cycle, voltage)
Max. current
External finish
Refrigerant control
Compressor
Model
Motor output
Starter type
Protection devices
Crankcase heater
Heat exchanger
Fan Fan(drive) %No.
Fan motor output
Airflow
Defrost method
Noise level
Dimensions
Weight
Refrigerant
Charge
Oil (Model)
Pipe size O.D.
Connection method
Between the indoor &
outdoor unit
Cooling
Heating
W
D
H
Liquid
Gas
Indoor side
Outdoor side
Height difference
Piping length
Service Ref.
PUHZ-SHW112YHA
PUHZ-SHW140YHA
14
Munsell 3Y 7.8/1.1
Linear Expansion Valve
Hermetic
ANB33FJLMT
2.5
Inverter
—
Plate fin coil
Propeller fan %2
0.074+0.074
100(3,530)
Reverse cycle
950(37-3/8)
330+30(13+1-3/16)
1,350(53-1/8)
134(295)
R410A
5.5(12.1)
1.40(FV50S)
9.52(3/8)
15.88(5/8)
Flared
Flared
Max. 30m
Max. 75m
3phase, 50Hz, 400V
OUTDOOR UNIT
REFRIGERANT PIPING
51
52
HP switch, LP switch
Discharge thermo, Comp. surface thermo
OCH526

9
4DATA
4-1. REFILLING REFRIGERANT CHARGE (R410A : kg)
4-2. COMPRESSOR TECHNICAL DATA
Piping length (one way)
10m 20m 30m 40m 50m Factory
charged
5.1
5.1
5.1
5.3
5.3
5.3
5.5
5.5
5.5
6.1
6.1
6.1
6.7
6.7
6.7
60m
7.3
7.3
7.3
75m
7.9
7.9
7.9
5.5
5.5
5.5
Service Ref.
PUHZ-SHW80VHA
PUHZ-SHW112VHA
PUHZ-SHW112YHA
PUHZ-SHW140YHA
U-V
U-W
W-V
Service Ref.
Compressor model
Winding
Resistance
()
ANB33FJLMT
(at 20)
0.302
0.302
0.302
ANB33FJMMT
0.188
0.188
0.188
PUHZ-SHW80VHA
PUHZ-SHW112VHA PUHZ-SHW112YHA PUHZ-SHW140YHA
Additional charge is required for pipes
longer than 10m.
4-3. NOISE CRITERION CURVES
PUHZ-SHW80VHA
PUHZ-SHW112VHA
PUHZ-SHW112YHA
PUHZ-SHW140YHA
1.5m
1m
MICROPHONE
UNIT
GROUND
NC-60
NC-50
NC-40
NC-30
NC-20
NC-70
90
80
70
60
50
40
30
20
10
OCTAVE BAND SOUND PRESSURE LEVEL, dB (0 dB = 0.0002 μbar)
63 125 250 500 1000 2000 4000 8000
APPROXIMATE
THRESHOLD OF
HEARING FOR
CONTINUOUS
NOISE
BAND CENTER FREQUENCIES, Hz
COOLING
MODE
HEATING
51
SPL(dB)
52
LINE
OCH526

10
4-4. STANDARD OPERATION DATA
TotalElectrical circuitRefrigerant circuitIndoor side
Outdoor
side
Representative matching
SHF
W
Mode
Capacity
kW
Input
PEAD-RP71JA
PEAD-RP71JA
Cooling
7,100
3.30
Heating
8,000
2.21
8.09
2.46
0.92
68
42
14
7.5
27
19
15
35
24
0.85
8.94
2.71
0.76
74
43
5
7.5
20
15
38
7
6
—
1 , 50
230
1 , 50
230
Phase , Hz
Voltage
Current
Outdoor unit
Phase , Hz
Voltage
Current
Discharge pressure
Suction pressure
Discharge temperature
Condensing temperature
Suction temperature
Ref. pipe length
Intake air temperature
Discharge air temperature
Intake air temperature
V
A
V
A
MPa
MPa



m





Indoor unit
D.B.
W.B.
D.B.
D.B.
W.B.
PEAD-RP100JA PEAD-RP125JA
PEAD-RP100JA PEAD-RP125JA
Cooling
10,000
3.26
Heating
11,200
3.10
Cooling
12,500
3.89
Heating
14,000
3.88
11.10/3.69
2.61
0.97
68
44
13
7.5
27
19
16
35
24
0.89
11.28/3.74
2.22
0.72
65
37
4
7.5
20
15
35
7
6
—
4.92
2.79
0.89
72
47
8
7.5
27
19
15
35
24
0.85
4.91
2.70
0.70
76
44
1
7.5
20
15
39
7
6
—
1 , 50
230
1/3 , 50
230/400
1 , 50
230
3 , 50
400
PUHZ-SHW112VHA
PUHZ-SHW112YHA PUHZ-SHW140YHA
PUHZ-SHW80VHA
1.28 1.17 1.68 1.57 2.40 2.29
The unit of pressure has been changed to MPa based on international SI system.
The conversion factor is : 1(MPa)=10.2(kgf/cm2)
OCH526
