Mitsubishi Electric MSZ-GF60VE - E1 User manual

SERVICE MANUAL No. OBH634
REVISED EDITION-B
PARTS CATALOG (OBB634)
NOTE:
RoHS compliant products have <G> mark on the spec name plate.
Models
MSZ-GF60VE -E1 , ER1
MSZ-GF60VE2 -E1 , ER1
MSZ-GF71VE -E1 , ER1
MSZ-GF71VE2 -E1 , ER1
Outdoor unit service manual
MUZ-GF·VE Series (OBH635)
MXZ-D·VA Series (OBH626)
MXZ-6C122VA (OBH584)
INDOOR UNIT
Revision B:
• MSZ-GF60VE2- E1 , ER1 and MSZ-
GF71VE2- E1 , ER1 have been added.
Please void OBH634 REVISED EDITION-A.
CONTENTS
1. TECHNICAL CHANGES ··································· 3
2. PART NAMES AND FUNCTIONS····················· 4
3. SPECIFICATION················································ 5
4. NOISE CRITERIA CURVES······························ 6
5. OUTLINES AND DIMENSIONS ························ 7
6. WIRING DIAGRAM············································ 8
7. REFRIGERANT SYSTEM DIAGRAM··············· 9
8. SERVICE FUNCTIONS ··································· 10
9. MICROPROCESSOR CONTROL ··················· 12
10. TROUBLESHOOTING····································· 19
11. DISASSEMBLY INSTRUCTIONS···················· 33

2
Use the specified refrigerant only
Never use any refrigerant other than that specified.
Doing so may cause a burst, an explosion, or fire when the unit is being used, serviced, or disposed of.
Correct refrigerant is specified in the manuals and on the spec labels provided with our products.
We will not be held responsible for mechanical failure, system malfunction, unit breakdown or accidents caused by
failure to follow the instructions.
<Preparation before the repair service>
Prepare the proper tools.
Prepare the proper protectors.
Provide adequate ventilation.
After stopping the operation of the air conditioner, turn off the power-supply breaker and remove the power plug.
Discharge the capacitor before the work involving the electric parts.
<Precautions during the repair service>
Do not perform the work involving the electric parts with wet hands.
Do not pour water into the electric parts.
Do not touch the refrigerant.
Do not touch the hot or cold areas in the refrigeration cycle.
When the repair or the inspection of the circuit needs to be done without turning off the power, exercise great caution not to
touch the live parts.
Revision A:
• MSZ-GF60VE- ER1 and MSZ-GF71VE- ER1 have been added.
Revision B:
• MSZ-GF60VE2- E1 , ER1 and MSZ-GF71VE2- E1 , ER1 have been added.
OBH634B

3
TECHNICAL CHANGES
1
These models are compatible with the outdoor units with low standby power control.
Connecting these models to the MUZ-GF·VE-series outdoor units enables the low standby power control. Refer to the techni-
cal guide (OBT17) about the low standby power control.
These models may be connected to the MUZ-GF·VE series after once connected to the MXZ series and operated, for exam-
ple because of relocation. In that case, the MUZ-GF·VE series outdoor units will not operate without taking a step. Follow the
procedure "Deleting the memorized abnormal condition" described in 10-2.1.
MSZ-GF60VE -E1 , ER1
MSZ-GF71VE -E1 , ER1
1. New model
MSZ-GF60VE -E1 MSZ-GF60VE2 -E1
MSZ-GF71VE -E1 MSZ-GF71VE2 -E1
1. Air filter has been changed.
2. Optional air cleaning filter has been changed.
3. Remote controller has been changed.
MSZ-GF60VE - ER1 MSZ-GF60VE2 - ER1
MSZ-GF71VE - ER1 MSZ-GF71VE2 - ER1
1. Air filter has been changed.
2. Optional air cleaning filter has been changed.
3. Remote controller has been changed.
OBH634B

4
ACCESSORIES
PART NAMES AND FUNCTIONS
2
MSZ-GF60VE MSZ-GF60VE2 MSZ-GF71VE MSZ-GF71VE2
Model
MSZ-GF60VE
MSZ-GF60VE2
MSZ-GF71VE
MSZ-GF71VE2
Installation plate 1
Installation plate fixing screw 4 × 25 mm 7
Remote controller holder 1
Fixing screw for 3.5 × 16 mm (Black) 2
Battery (AAA) for remote controller 2
Wireless remote controller 1
Felt tape (For left or left-rear piping) 1
Operation indicator lamp
Remote control receiving section
Emergency operation switch (E. O. SW)
Horizontal vane Vertical vane
Air outlet
Fan
Air filter
[Nano platinum filter (GF60/71VE) /
Air purifying filter (GF60/71VE2)]
Air inlet
Heat exchanger
Front panel
Air cleaning filter
[Electrostatic anti-allergy enzyme filter,
option (GF60/71VE) / Silver-ionized air
purifier filter, option (GF60/71VE2)]
Display section
Fan guard Remote controller
OBH634B

5
Indoor model MSZ-GF60VE
MSZ-GF60VE2 MSZ-GF71VE MSZ-GF71VE2
Power supply Single phase 230 V, 50 Hz
Electrical data
Power input
1Cooling W48 58
Heating 62 58
Running
current 1Cooling A0.43 0.51
Heating 0.53 0.51
Fan motor
Model RC0J56-AF
Current 1Cooling A0.43 0.51
Heating 0.53 0.51
Dimensions W × H × D mm 1100 × 325 × 238
Weight kg 16
Special remarks
Air direction 5
Airflow
Cooling
Super High 1,242 1,164
+ LONG + POWERFUL
Super High
m3/h
1,098 1,068
High 936 924
Med. 804 798
Low 678 690
Silent 588 582
Heating
Super High 1,242 1,164
+ LONG + POWERFUL
Super High
m3/h
1,098 1,068
High
936 (882 2)
924
Med. 804 798
Low 678 690
Silent 588 612
Sound level
Cooling
Super High 52 53
+ LONG + POWERFUL
Super High
dB(A)
49
High 45
Med. 41
Low 37
Silent 29 30
Heating
Super High 52
+ LONG + POWERFUL
Super High
dB(A)
49
High 45
Med. 41
Low 37
Silent 29 30
Fan speed
Cooling
Super High 1,280 1,300
+ LONG + POWERFUL
Super High
rpm
1,090 1,140
High 960 1,010
Med. 850 900
Low 740 800
Silent 660 700
Heating
Super High 1,280 1,300
+ LONG + POWERFUL
Super High
rpm
1,090 1,140
High
960 (910 2)
1,010
Med. 850 900
Low 740 800
Silent 660 730
Fan speed regulator 5
Remote controller model SG12D(VE)/ SG15E (VE2)
NOTE: Test conditions are based on ISO 5151.
Cooling: Indoor Dry-bulb temperature 27°C Wet-bulb temperature 19°C
Outdoor Dry-bulb temperature 35°C
Heating: Indoor Dry-bulb temperature 20°C
Outdoor Dry-bulb temperature 7°C Wet-bulb temperature 6°C
1 Measured under rated operating frequency.
2 For multi system.
SPECIFICATION
3
OBH634B

6
NOISE CRITERIA CURVES
4
MSZ-GF60VE MSZ-GF60VE2 MSZ-GF71VE MSZ-GF71VE2
Test conditions
Cooling: Dry-bulb temperature 27°C
Wet-bulb temperature 19°C
Heating: Dry-bulb temperature 20°C
INDOOR UNIT WALL
MICROPHONE
0.8m
1m
90
80
70
60
50
40
30
20
10 63 125 250 500 1000 2000 4000 8000
NC-60
NC-50
NC-40
NC-30
NC-20
NC-70
OCTAVE BAND SOUND PRESSURE LEVEL, dB re 0.0002 MICRO BAR
BAND CENTER FREQUENCIES, Hz
COOLING
FUNCTION SPL(dB(A)) LINE
Super High
FAN SPEED
HEATING
49
49
NC-10
90
80
70
60
50
40
30
20
10 63 125 250 500 1000 2000 4000 8000
NC-60
NC-50
NC-40
NC-30
NC-20
NC-70
OCTAVE BAND SOUND PRESSURE LEVEL, dB re 0.0002 MICRO BAR
BAND CENTER FREQUENCIES, Hz
COOLING
FUNCTION SPL(dB(A)) LINE
Super High
FAN SPEED
HEATING
49
49
NC-10
Specifications and rated conditions of main electric parts
Fuse (F11) T3.15AL250V
Horizontal vane motor (MV1) 12 VDC
Vertical vane motor (MV2) 12 VDC
Varistor (NR11) S10K300E3K1 (ERZV10D471)
Terminal block (TB) 3P
Relay (X1)
OBH634B

7
Unit: mm
OUTLINES AND DIMENSIONS
5
1090 5
1100
45 238.5
258.5
3
280
225 225
129
239.5
281
44
49.5 500.5 439.5
199.5199.5 110.5
65
63 76 843 181
65
65 30
63
60
193
18
65
67
63
325
3
100
125
160
110
(
70° )
238
5
210
21.5
184
12
Piping
Insulation Ø50 O.D
Liquid line Ø9.52 - 0.5m (Flared connection Ø9.52)
Gas line A1 - 0.45m (Flared connection Ø15.88)
Drain hose Insulation Ø28 Connected part Ø16 O.D
Piping
Insulation Ø50 O.D
Liquid line Ø9.52 - 0.5m (Flared connection Ø6.35)
Gas line
Ø12 - 0.45m (Flared connection Ø15.88)
Drain hose Insulation Ø28 Connected part Ø16 O.D
Air out
Piping
Drain hose
11×26 Oblong hole 11×20 Oblong hole
Installation plate
Indoor unit
Wall hole
Ø 75
Air in Installation plate
MSZ-GF60VE MSZ-GF60VE2
MSZ-GF71VE MSZ-GF71VE2
MSZ-GF60VE MSZ-GF60VE2 MSZ-GF71VE MSZ-GF71VE2
OBH634B

8
WIRING DIAGRAM
6
MSZ-GF60VE - E1 MSZ-GF71VE - E1
MSZ-GF60VE - ER1 MSZ-GF71VE - ER1
MSZ-GF60VE2 - E1 MSZ-GF60VE2 - ER1 MSZ-GF71VE2 - E1 MSZ-GF71VE2 - ER1
OBH634B

9
REFRIGERANT SYSTEM DIAGRAM
7
Unit: mm
Indoor
heat
exchanger
Flared connection
Room temperature
thermistor
RT11
Flared connection
Refrigerant pipe ø15.88
(with heat insulator)
Refrigerant pipe ø6.35 (MSZ-GF60VE)
(MSZ-GF60VE2)
ø9.52 (MSZ-GF71VE)
(MSZ-GF71VE2)
(with heat insulator)
Indoor coil
thermistor
RT12 (main)
Indoor coil
thermistor
RT13 (sub)
Refrigerant flow in cooling
Refrigerant flow in heating
MSZ-GF60VE MSZ-GF60VE2 MSZ-GF71VE MSZ-GF71VE2
OBH634B

10
8-1. TIMER SHORT MODE
For service, the following set time can be shortened by bridging JPG and JPS on the electronic control P.C. board.
(Refer to 10-7.1.)
• The set time for the ON/OFF timer can be reduced to 1 second for each minute.
• After the breaker is turned on, the time for starting the compressor, which normally takes 3 minutes, can be reduced to 1
minute. Restarting the compressor, which takes 3 minutes, cannot be reduced.
8-2. REMOTE CONTROLLER P.C. BOARD MODIFICATION FOR INDIVIDUAL OPERATION
A maximum of 4 indoor units with wireless remote controllers can be used in a room.
In this case, to operate each indoor unit individually by each remote controller, the remote controller P.C. boards must be
modified according to the number of the indoor unit.
How to modify the remote controller P.C. board
Remove batteries before modification.
The board has a print as shown below:
The remote controller P.C. board has the print “J1” and “J2”. Solder “J1” and “J2” according to the number of indoor unit as
shown in Table 1.
After modification, press the RESET button.
Table 1
1 unit operation 2 units operation 3 units operation 4 units operation
No. 1 unit No modification Same as at left Same as at left Same as at left
No. 2 unit — Solder J1 Same as at left Same as at left
No. 3 unit — — Solder J2 Same as at left
No. 4 unit — — — Solder both J1 and J2
How to set the remote controller exclusively for particular indoor unit
After you turn the breaker ON, the first remote controller that sends the signal to the indoor unit will be regarded as the remote
controller for the indoor unit.
The indoor unit will only accept the signal from the remote controller that has been assigned to the indoor unit once they are set.
The setting will be cancelled if the breaker is turned OFF, or the power supply is shut down.
Please conduct the above setting once again after the power has restored.
SERVICE FUNCTIONS
8
J1 J2 NOTE: For modification, take out the batteries
and press the OPERATE/STOP (ON/
OFF) (GF60/71VE) / STOP/OPERATE
(OFF/ON) (GF60/71VE2) button 2 or 3
times at first.
After modification, put back the batteries
then press the RESET button.
MSZ-GF60VE MSZ-GF60VE2 MSZ-GF71VE MSZ-GF71VE2
OBH634B
