PARTS CATALOG (OBB702)

SERVICE MANUAL

OUTDOOR UNIT

Models

MXZ-2C20NA2 -U1 , U4 MXZ-2C20NAHZ

MXZ-2C20NA3 -U1 MXZ-2C20NAHZ2 -U1

MXZ-2C20NA4 -U1 MXZ-2C20NAHZ3 -U1

MXZ-3C24NA MXZ-2C20NAHZ4 -U1

MXZ-3C24NA2 -U1 MXZ-3C24NAHZ

MXZ-3C24NA3 -U1 MXZ-3C24NAHZ2 -U1

MXZ-3C24NA4 -U1 MXZ-3C24NAHZ3 -U1

MXZ-3C30NA MXZ-3C24NAHZ4 -U1

MXZ-3C30NA2 -U1 MXZ-3C30NAHZ

MXZ-3C30NA3 -U1 MXZ-3C30NAHZ2 -U1

MXZ-3C30NA4 -U1 MXZ-3C30NAHZ3 -U1

MXZ-4C36NA MXZ-3C30NAHZ4 -U1

MXZ-4C36NA2 -U1

MXZ-4C36NA3 -U1

MXZ-4C36NA4 -U1

MXZ-5C42NA

MXZ-5C42NA2 -U1

MXZ-5C42NA3 -U1

MXZ-5C42NA4 -U1

No. OBH702

REVISED EDITION-N

Indoor unit service manual

MSZ-FE·NA Series (OBH542)

MSZ-FH·NA Series (OBH683)

MSZ-GE·NA Series (OBH548)

MSZ-GL·NA Series (OBH732)

MSZ-EF·NA Series (OBH736)

MSZ-FS·NA Series (OBH872)

MFZ-KA·NA Series (OBH568)

MFZ-KJ·NA Series (OBH752)

SLZ-KA·NA Series (OCH487)

SLZ-KF·NA.TH Series (OCH669)

PLA-A·BA Series (OCH420)

PLA-A·EA Series (OCH640)

SEZ-KD·NA Series

PEAD-A·AA Series

PCA-A·KA Series (OCH455)

MVZ-A·AA Series

SVZ-KP·NA Series (MD-1404-K019)

CONTENTS

• INDOOR / OUTDOOR UNIT

COMPATIBILITY TABLE ······················4

1. TECHNICAL CHANGES ······························8

2. SAFETY PRECAUTION·······························9

3. PART NAMES AND FUNCTIONS················13

4. SPECIFICATION ······································14

5. NOISE CRITERIA CURVES························30

6. OUTLINES AND DIMENSIONS···················33

7. WIRING DIAGRAM···································39

8. REFRIGERANT SYSTEM DIAGRAM ···········62

9. DATA······················································75

10. ACTUATOR CONTROL ··························· 106

11. SERVICE FUNCTIONS ···························· 107

12. TROUBLESHOOTING······························110

13. DISASSEMBLY INSTRUCTIONS··············· 141

HFC

utilized

R410A

Revision N:

• 4. SPECIFICATION and 8. REFRIGERANT

SYSTEM DIAGRAM have been corrected.

OBH702 REVISED EDITION-M is void.

MXZ-3C24NA MXZ-3C30NA MXZ-4C36NA

MXZ-3C24NA2 MXZ-3C30NA2 MXZ-4C36NA2

MXZ-3C24NA3 MXZ-3C30NA3 MXZ-4C36NA3

MXZ-3C24NA4 MXZ-3C30NA4 MXZ-4C36NA4

Use the specied refrigerant only

Never use any refrigerant other than that specified.

Doing so may cause a burst, an explosion, or fire when the unit is being used, serviced, or disposed of.

Correct refrigerant is specified in the manuals and on the spec labels provided with our products.

We will not be held responsible for mechanical failure, system malfunction, unit breakdown or accidents caused by failure to

follow the instructions.

Prepare the proper tools.

Prepare the proper protectors.

Provide adequate ventilation.

After stopping the operation of the air conditioner, turn off the power-supply breaker and pull the power plug.

Discharge the capacitor before the work involving the electric parts.

Do not perform the work involving the electric parts with wet hands.

Do not pour water into the electric parts.

Do not touch the refrigerant.

Do not touch the hot or cold areas in the refrigeration cycle.

When the repair or the inspection of the circuit needs to be done without turning off the power, exercise great caution not to

touch the live parts.

WARNING

• When the refrigeration circuit has a leak, do not execute pump down with the compressor.

• When pumping down the refrigerant, stop the compressor before disconnecting the refrigerant pipes.

The compressor may burst if air etc. get into it.

• When opening or closing the valve below freezing temperatures, refrigerant may spurt out from the gap

between the valve stem and the valve body, resulting in injuries.

OBH702N

Revision A:

• MXZ-3C24NA, MXZ-3C30NA and MXZ-4C36NA have been added.

Revision B:

• MXZ-3C24/3C30/4C36/5C42NA2 and MXZ-2C20/3C24/3C30NAHZ2- U1 have been added.

Revision C:

• 4. SPECIFICATION has been changed.

• Some descriptions have been modied.

Revision D:

• Connectable indoor unit lineups have been modied.

• WIRING DIAGRAM (7.) and TEST POINT DIAGRAM AND VOLTAGE (12-7.) have been changed.

Revision E:

• Capacity and input curve have been corrected.

Revision F:

• MXZ-2C20NA2- U1 has been added.

Revision G:

• 5. NOISE CRITERIA CURVES has been changed.

Revision H:

• MSZ-FS·NA series have been added to INDOOR / OUTDOOR UNIT COMPATIBILITY TABLE.

• 2. SAFETY PRECAUTION has been added.

• 9-2. CAPACITY AND THE INPUT CURVES has been modied.

• 12. TROUBLESHOOTING has been modied.

Revision K:

• MXZ-2C20/3C24/3C30/4C36/5C42NA3- U1 and MXZ-2C20/3C24/3C30NAHZ3- U1 have been added.

Revision J:

• MXZ-2C20NA2- U4 has been added.

Revision L:

• Models of refrigeration oil for MXZ-3C24/3C30/4C36/5C42NA3- U1 and MXZ-2C20/3C24/3C30NAHZ3- U1 at

4. SPECIFICATION have been added.

Revision M:

• MXZ-2C20/3C24/3C30/4C36/5C42NA4- U1 and MXZ-2C20/3C24/3C30NAHZ4- U1 have been added.

Revision N:

• 4. SPECIFICATION and 8. REFRIGERANT SYSTEM DIAGRAM have been corrected.

Specications of MXZ-2C20NA4/MXZ-3C24NA4/MXZ-3C30NA4 - U1 have been corrected.

Refrigerant system diagrams of MXZ-3C24/3C30/4C36NA and MXZ-3C24/3C30/4C36NA2/NA3- U1 have been corrected.

OBH702N

INDOOR / OUTDOOR UNIT COMPATIBILITY TABLE

<MXZ-2C20NAHZ2-U1>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●

MSZ-FH**NA2

MSZ-FS**NA ●●●●●●●●

MSZ-GE**NA ●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●

MSZ-EF**NA-U1 ●●●●●●

Floor standing MFZ-KA**NA ●●●●

MFZ-KJ**NA-U1 ●●●●●●

4-way cassette

SLZ-KA**NA.TH ●●●●

SLZ-KF**NA.TH ●●●●

PLA-A**BA6

PLA-A**EA7

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●

PEAD-A**AA5 ●●●●

Ceiling suspended PCA-A**KA6.TH

Multi-position MVZ-A**AA4 ●●

SVZ-KP**NA ●●

<MXZ-2C20NAHZ3-U1, MXZ-2C20NAHZ4-U1>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●

MSZ-FH**NA2

MSZ-FS**NA ●●●●●●●●

MSZ-GE**NA ●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●

MSZ-GS**NA-U1 ●●●●●●●●

MSZ-EF**NA-U1 ●●●●●●

Floor standing MFZ-KA**NA ●●●●

MFZ-KJ**NA-U1 ●●●●●●

4-way cassette

SLZ-KA**NA.TH ●●●●

SLZ-KF**NA.TH ●●●●

PLA-A**BA6

PLA-A**EA7

1-way cassette MLZ-KP**NA-U1 ●●●●

MLZ-KP**NA2-U1 ●●●●

MLZ-KY**NA-U1 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●

PEAD-A**AA7 ●●●●

Ceiling suspended PCA-A**KA7.TH

Multi-position MVZ-A**AA4 ●●

SVZ-KP**NA ●●

<MXZ-3C24NA>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●

MSZ-FH**NA2

MSZ-FS**NA

MSZ-GE**NA ●●●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●●●

MSZ-EF**NA-U1

Floor standing MFZ-KA**NA ●●●●●●

MFZ-KJ**NA-U1

4-way cassette

SLZ-KA**NA.TH ●●●●●●

SLZ-KF**NA.TH

PLA-A**BA6 ●●

PLA-A**EA7 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●●●

PEAD-A**AA5

Ceiling suspended PCA-A**KA6.TH

Multi-position MVZ-A**AA4 ●●●●

SVZ-KP**NA

<MXZ-2C20NA2-U1/U4>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●

MSZ-FH**NA2

MSZ-FS**NA ●●●●●●●●

MSZ-GE**NA ●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●

MSZ-EF**NA-U1 ●●●●●●

Floor standing MFZ-KA**NA ●●●●

MFZ-KJ**NA-U1 ●●●●●●

4-way cassette

SLZ-KA**NA.TH ●●●●

SLZ-KF**NA.TH ●●●●

PLA-A**BA6

PLA-A**EA7

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●

PEAD-A**AA5 ●●●●

Ceiling suspended PCA-A**KA6.TH

Multi-position MVZ-A**AA4 ●●

SVZ-KP**NA ●●

<MXZ-2C20NA3-U1, MXZ-2C20NA4-U1>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●

MSZ-FH**NA2

MSZ-FS**NA ●●●●●●●●

MSZ-GE**NA ●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●

MSZ-GS**NA-U1 ●●●●●●●●

MSZ-EF**NA-U1 ●●●●●●

Floor standing MFZ-KA**NA ●●●●

MFZ-KJ**NA-U1 ●●●●●●

4-way cassette

SLZ-KA**NA.TH ●●●●

SLZ-KF**NA.TH ●●●●

PLA-A**BA6

PLA-A**EA7

1-way cassette MLZ-KP**NA-U1 ●●●●

MLZ-KP**NA2-U1 ●●●●

MLZ-KY**NA-U1 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●

PEAD-A**AA7 ●●●●

Ceiling suspended PCA-A**KA7.TH

Multi-position MVZ-A**AA4 ●●

SVZ-KP**NA ●●

<MXZ-2C20NAHZ>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●

MSZ-FH**NA2

MSZ-FS**NA

MSZ-GE**NA ●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●

MSZ-EF**NA-U1

Floor standing MFZ-KA**NA ●●●●

MFZ-KJ**NA-U1

4-way cassette

SLZ-KA**NA.TH ●●●●

SLZ-KF**NA.TH

PLA-A**BA6

PLA-A**EA7

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●

PEAD-A**AA5

Ceiling suspended PCA-A**KA6.TH

Multi-position MVZ-A**AA4 ●●

SVZ-KP**NA

OBH702N

<MXZ-3C24NA2-U1>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●●●

MSZ-FH**NA2

MSZ-FS**NA ●●●●●●●●●●

MSZ-GE**NA ●●●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●●●

MSZ-EF**NA-U1 ●●●●●●●●

Floor standing MFZ-KA**NA ●●●●●●

MFZ-KJ**NA-U1 ●●●●●●●●

4-way cassette

SLZ-KA**NA.TH ●●●●●●

SLZ-KF**NA.TH ●●●●●●

PLA-A**BA6 ●●

PLA-A**EA7 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●●●

PEAD-A**AA5 ●●●●●●●●

Ceiling suspended PCA-A**KA6.TH

Multi-position MVZ-A**AA4 ●●●●

SVZ-KP**NA ●●●●

<MXZ-3C24NA3-U1, MXZ-3C24NA4-U1>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●●●

MSZ-FH**NA2 ●●

MSZ-FS**NA ●●●●●●●●●●

MSZ-GE**NA ●●●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●●●

MSZ-GS**NA-U1 ●●●●●●●●●●

MSZ-EF**NA-U1 ●●●●●●●●

Floor standing MFZ-KA**NA ●●●●●●

MFZ-KJ**NA-U1 ●●●●●●●●

4-way cassette

SLZ-KA**NA.TH ●●●●●●

SLZ-KF**NA.TH ●●●●●●

PLA-A**BA6 ●●

PLA-A**EA7 ●●

1-way cassette MLZ-KP**NA-U1 ●●●●●●

MLZ-KP**NA2-U1 ●●●●●●

MLZ-KY**NA-U1 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●●●

PEAD-A**AA7 ●●●●●●●●

Ceiling suspended PCA-A**KA7.TH

Multi-position MVZ-A**AA4 ●●●●

SVZ-KP**NA ●●●●

PAA-A** ●●

<MXZ-3C24NAHZ>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●

MSZ-FH**NA2

MSZ-FS**NA

MSZ-GE**NA ●●●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●

MSZ-EF**NA-U1

Floor standing MFZ-KA**NA ●●●●●●

MFZ-KJ**NA-U1

4-way cassette

SLZ-KA**NA.TH ●●●●●●

SLZ-KF**NA.TH

PLA-A**BA6 ●●

PLA-A**EA7 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●●●

PEAD-A**AA5

Ceiling suspended PCA-A**KA6.TH

Multi-position MVZ-A**AA4 ●●●●

SVZ-KP**NA

<MXZ-3C24NAHZ2-U1>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●●●

MSZ-FH**NA2

MSZ-FS**NA ●●●●●●●●●●

MSZ-GE**NA ●●●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●●●

MSZ-EF**NA-U1 ●●●●●●●●

Floor standing MFZ-KA**NA ●●●●●●

MFZ-KJ**NA-U1 ●●●●●●●●

4-way cassette

SLZ-KA**NA.TH ●●●●●●

SLZ-KF**NA.TH ●●●●●●

PLA-A**BA6 ●●

PLA-A**EA7 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●●●

PEAD-A**AA5 ●●●●●●●●

Ceiling suspended PCA-A**KA6.TH

Multi-position MVZ-A**AA4 ●●●●

SVZ-KP**NA ●●●●

<MXZ-3C24NAHZ3-U1, MXZ-3C24NAHZ4-U1>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●●●

MSZ-FH**NA2 ●●

MSZ-FS**NA ●●●●●●●●●●

MSZ-GE**NA ●●●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●●●

MSZ-GS**NA-U1 ●●●●●●●●●●

MSZ-EF**NA-U1 ●●●●●●●●

Floor standing MFZ-KA**NA ●●●●●●

MFZ-KJ**NA-U1 ●●●●●●●●

4-way cassette

SLZ-KA**NA.TH ●●●●●●

SLZ-KF**NA.TH ●●●●●●

PLA-A**BA6 ●●

PLA-A**EA7 ●●

1-way cassette MLZ-KP**NA-U1 ●●●●●●

MLZ-KP**NA2-U1 ●●●●●●

MLZ-KY**NA-U1 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●●●

PEAD-A**AA7 ●●●●●●●●

Ceiling suspended PCA-A**KA7.TH

Multi-position MVZ-A**AA4 ●●●●

SVZ-KP**NA ●●●●

PAA-A** ●●

<MXZ-3C30NA>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●

MSZ-FH**NA2

MSZ-FS**NA

MSZ-GE**NA ●●●●●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●●●●●

MSZ-EF**NA-U1

Floor standing MFZ-KA**NA ●●●●●●

MFZ-KJ**NA-U1

4-way cassette

SLZ-KA**NA.TH ●●●●●●

SLZ-KF**NA.TH

PLA-A**BA6 ●●●●

PLA-A**EA7 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●●●

PEAD-A**AA5 ●●

Ceiling suspended PCA-A**KA6.TH ●●

Multi-position MVZ-A**AA4 ●●●●●●

SVZ-KP**NA

OBH702N

<MXZ-3C30NAHZ2-U1>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●●●

MSZ-FH**NA2

MSZ-FS**NA ●●●●●●●●●●

MSZ-GE**NA ●●●●●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●●●●●

MSZ-EF**NA-U1 ●●●●●●●●

Floor standing MFZ-KA**NA ●●●●●●

MFZ-KJ**NA-U1 ●●●●●●●●

4-way cassette

SLZ-KA**NA.TH ●●●●●●

SLZ-KF**NA.TH ●●●●●●

PLA-A**BA6 ●●●●

PLA-A**EA7 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●●●

PEAD-A**AA5 ●●●●●●●●●●

Ceiling suspended PCA-A**KA6.TH ●●

Multi-position MVZ-A**AA4 ●●●●●●

SVZ-KP**NA ●●●●●●

<MXZ-3C30NAHZ3-U1, MXZ-3C30NAHZ4-U1>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●●●

MSZ-FH**NA2 ●●

MSZ-FS**NA ●●●●●●●●●●

MSZ-GE**NA ●●●●●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●●●●●

MSZ-GS**NA-U1 ●●●●●●●●●●●●

MSZ-EF**NA-U1 ●●●●●●●●

Floor standing MFZ-KA**NA ●●●●●●

MFZ-KJ**NA-U1 ●●●●●●●●

4-way cassette

SLZ-KA**NA.TH ●●●●●●

SLZ-KF**NA.TH ●●●●●●

PLA-A**BA6 ●●●●

PLA-A**EA7 ●●

1-way cassette MLZ-KP**NA-U1 ●●●●●●

MLZ-KP**NA2-U1 ●●●●●●

MLZ-KY**NA-U1 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●●●

PEAD-A**AA7 ●●●●●●●●●●

Ceiling suspended PCA-A**KA7.TH ●●

Multi-position MVZ-A**AA4 ●●●●●●

SVZ-KP**NA ●●●●●●

PAA-A** ●●●●

<MXZ-4C36NA>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●

MSZ-FH**NA2

MSZ-FS**NA

MSZ-GE**NA ●●●●●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●●●●●

MSZ-EF**NA-U1

Floor standing MFZ-KA**NA ●●●●●●

MFZ-KJ**NA-U1

4-way cassette

SLZ-KA**NA.TH ●●●●●●

SLZ-KF**NA.TH

PLA-A**BA6 ●●●●

PLA-A**EA7 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●●●

PEAD-A**AA5 ●●

Ceiling suspended PCA-A**KA6.TH ●●

Multi-position MVZ-A**AA4 ●●●●●●

SVZ-KP**NA

<MXZ-3C30NA2-U1>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●●●

MSZ-FH**NA2

MSZ-FS**NA ●●●●●●●●●●

MSZ-GE**NA ●●●●●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●●●●●

MSZ-EF**NA-U1 ●●●●●●●●

Floor standing MFZ-KA**NA ●●●●●●

MFZ-KJ**NA-U1 ●●●●●●●●

4-way cassette

SLZ-KA**NA.TH ●●●●●●

SLZ-KF**NA.TH ●●●●●●

PLA-A**BA6 ●●●●

PLA-A**EA7 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●●●

PEAD-A**AA5 ●●●●●●●●●●

Ceiling suspended PCA-A**KA6.TH ●●

Multi-position MVZ-A**AA4 ●●●●●●

SVZ-KP**NA ●●●●●●

<MXZ-3C30NA3-U1, MXZ-3C30NA4-U1>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●●●

MSZ-FH**NA2 ●●

MSZ-FS**NA ●●●●●●●●●●

MSZ-GE**NA ●●●●●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●●●●●

MSZ-GS**NA-U1 ●●●●●●●●●●●●

MSZ-EF**NA-U1 ●●●●●●●●

Floor standing MFZ-KA**NA ●●●●●●

MFZ-KJ**NA-U1 ●●●●●●●●

4-way cassette

SLZ-KA**NA.TH ●●●●●●

SLZ-KF**NA.TH ●●●●●●

PLA-A**BA6 ●●●●

PLA-A**EA7 ●●

1-way cassette MLZ-KP**NA-U1 ●●●●●●

MLZ-KP**NA2-U1 ●●●●●●

MLZ-KY**NA-U1 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●●●

PEAD-A**AA7 ●●●●●●●●●●

Ceiling suspended PCA-A**KA7.TH ●●

Multi-position MVZ-A**AA4 ●●●●●●

SVZ-KP**NA ●●●●●●

PAA-A** ●●●●

<MXZ-3C30NAHZ>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●

MSZ-FH**NA2

MSZ-FS**NA

MSZ-GE**NA ●●●●●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●●●

MSZ-EF**NA-U1

Floor standing MFZ-KA**NA ●●●●●●

MFZ-KJ**NA-U1

4-way cassette

SLZ-KA**NA.TH ●●●●●●

SLZ-KF**NA.TH

PLA-A**BA6 ●●●●

PLA-A**EA7 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●●●

PEAD-A**AA5 ●●

Ceiling suspended PCA-A**KA6.TH ●●

Multi-position MVZ-A**AA4 ●●●●●●

SVZ-KP**NA

OBH702N

<MXZ-5C42NA2-U1>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●●●

MSZ-FH**NA2 ●●

MSZ-FS**NA ●●●●●●●●●●

MSZ-GE**NA ●●●●●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●●●●●

MSZ-EF**NA-U1 ●●●●●●●●

Floor standing MFZ-KA**NA ●●●●●●

MFZ-KJ**NA-U1 ●●●●●●●●

4-way cassette

SLZ-KA**NA.TH ●●●●●●

SLZ-KF**NA.TH ●●●●●●

PLA-A**BA6 ●●●●

PLA-A**EA7 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●●●

PEAD-A**AA5 ●●●●●●●●●●

Ceiling suspended PCA-A**KA6.TH ●●

Multi-position MVZ-A**AA4 ●●●●●●

SVZ-KP**NA ●●●●●●

<MXZ-5C42NA3-U1, MXZ-5C42NA4-U1>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●●●

MSZ-FH**NA2 ●●

MSZ-FS**NA ●●●●●●●●●●

MSZ-GE**NA ●●●●●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●●●●●

MSZ-GS**NA-U1 ●●●●●●●●●●●●

MSZ-EF**NA-U1 ●●●●●●●●

Floor standing MFZ-KA**NA ●●●●●●

MFZ-KJ**NA-U1 ●●●●●●●●

4-way cassette

SLZ-KA**NA.TH ●●●●●●

SLZ-KF**NA.TH ●●●●●●

PLA-A**BA6 ●●●●

PLA-A**EA7 ●●

1-way cassette MLZ-KP**NA-U1 ●●●●●●

MLZ-KP**NA2-U1 ●●●●●●

MLZ-KY**NA-U1 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●●●

PEAD-A**AA7 ●●●●●●●●●●

Ceiling suspended PCA-A**KA7.TH ●●

Multi-position MVZ-A**AA4 ●●●●●●

SVZ-KP**NA ●●●●●●

PAA-A** ●●●●

<MXZ-4C36NA2-U1>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●●●

MSZ-FH**NA2

MSZ-FS**NA ●●●●●●●●●●

MSZ-GE**NA ●●●●●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●●●●●

MSZ-EF**NA-U1 ●●●●●●●●

Floor standing MFZ-KA**NA ●●●●●●

MFZ-KJ**NA-U1 ●●●●●●●●

4-way cassette

SLZ-KA**NA.TH ●●●●●●

SLZ-KF**NA.TH ●●●●●●

PLA-A**BA6 ●●●●

PLA-A**EA7 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●●●

PEAD-A**AA5 ●●●●●●●●●●

Ceiling suspended PCA-A**KA6.TH ●●

Multi-position MVZ-A**AA4 ●●●●●●

SVZ-KP**NA ●●●●●●

<MXZ-4C36NA3-U1, MXZ-4C36NA4-U1>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●●●

MSZ-FH**NA2 ●●

MSZ-FS**NA ●●●●●●●●●●

MSZ-GE**NA ●●●●●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●●●●●

MSZ-GS**NA-U1 ●●●●●●●●●●●●

MSZ-EF**NA-U1 ●●●●●●●●

Floor standing MFZ-KA**NA ●●●●●●

MFZ-KJ**NA-U1 ●●●●●●●●

4-way cassette

SLZ-KA**NA.TH ●●●●●●

SLZ-KF**NA.TH ●●●●●●

PLA-A**BA6 ●●●●

PLA-A**EA7 ●●

1-way cassette MLZ-KP**NA-U1 ●●●●●●

MLZ-KP**NA2-U1 ●●●●●●

MLZ-KY**NA-U1 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●●●

PEAD-A**AA7 ●●●●●●●●●●

Ceiling suspended PCA-A**KA7.TH ●●

Multi-position MVZ-A**AA4 ●●●●●●

SVZ-KP**NA ●●●●●●

PAA-A** ●●●●

<MXZ-5C42NA>

Connectable indoor unit lineups (Heat pump inverter type)

Model type Model name Capacity class [kBTU/h]

06 09 12 15 18 24 30 36

Wall mounted

MSZ-FE**NA ●●●●

MSZ-FH**NA ●●●●●●●●

MSZ-FH**NA2

MSZ-FS**NA

MSZ-GE**NA ●●●●●●●●●●●●

MSZ-GL**NA-U1 ●●●●●●●●●●

MSZ-EF**NA-U1

Floor standing MFZ-KA**NA ●●●●●●

MFZ-KJ**NA-U1

4-way cassette

SLZ-KA**NA.TH ●●●●●●

SLZ-KF**NA.TH

PLA-A**BA6 ●●●●

PLA-A**EA7 ●●

Ceiling concealed SEZ-KD**NA4.TH ●●●●●●●●

PEAD-A**AA5 ●●

Ceiling suspended PCA-A**KA6.TH ●●

Multi-position MVZ-A**AA4 ●●●●●●

SVZ-KP**NA

OBH702N

1 TECHNICAL CHANGES

MXZ-5C42NA

MXZ-2C20NAHZ

MXZ-3C24NAHZ

MXZ-3C30NAHZ

1. New model

MXZ-3C24NA

MXZ-3C30NA

MXZ-4C36NA

1. New model

MXZ-3C24NA MXZ-3C24NA2- U1

MXZ-3C30NA MXZ-3C30NA2- U1

MXZ-4C36NA MXZ-4C36NA2- U1

MXZ-5C42NA MXZ-5C42NA2- U1

MXZ-2C20NAHZ MXZ-2C20NAHZ2- U1

MXZ-3C24NAHZ MXZ-3C24NAHZ2- U1

MXZ-3C30NAHZ MXZ-3C30NAHZ2- U1

1. Outdoor control P.C. board has been changed.

MXZ-2C20NA2- U1

1. New model

MXZ-2C20NA2- U1 MXZ-2C20NA2- U4

1. Outdoor fan motor has been changed.

2. Outdoor control P.C. board has been changed.

MXZ-2C20NA2- U4 MXZ-2C20NA3- U1

MXZ-3C24NA2- U1 MXZ-3C24NA3- U1

MXZ-3C30NA2- U1 MXZ-3C30NA3- U1

MXZ-4C36NA2- U1 MXZ-4C36NA3- U1

MXZ-5C42NA2- U1 MXZ-5C42NA3- U1

MXZ-2C20NAHZ2- U1 MXZ-2C20NAHZ3- U1

MXZ-3C24NAHZ2- U1 MXZ-3C24NAHZ3- U1

MXZ-3C30NAHZ2- U1 MXZ-3C30NAHZ3- U1

1. Outdoor fan motor has been changed.

2. Outdoor control P.C. board has been changed.

MXZ-2C20NA3- U1 MXZ-2C20NA4- U1

MXZ-3C24NA3- U1 MXZ-3C24NA4- U1

MXZ-3C30NA3- U1 MXZ-3C30NA4- U1

MXZ-4C36NA3- U1 MXZ-4C36NA4- U1

MXZ-5C42NA3- U1 MXZ-5C42NA4- U1

MXZ-2C20NAHZ3- U1 MXZ-2C20NAHZ4- U1

MXZ-3C24NAHZ3- U1 MXZ-3C24NAHZ4- U1

MXZ-3C30NAHZ3- U1 MXZ-3C30NAHZ4- U1

1. Outdoor control P.C. board has been changed.

2. Compressor protector has been added.

OBH702N

SAFETY PRECAUTION2

Use the following tools specically designed for

use with R410A refrigerant.

The following tools are necessary to use R410A refrigerant.

Tools for R410A

Gauge manifold Flare tool

Charge hose Size adjustment gauge

Gas leak detector Vacuum pump adaptor

Torque wrench Electronic refrigerant

charging scale

Handle tools with care.

If dirt, dust or moisture enters into refrigerant cycle, that can

cause deterioration of refrigerant oil or malfunction of

compressor.

Use the specied refrigerant only.

Never use any refrigerant other than that specied.

Doing so may cause a burst, an explosion, or re when

the unit is being used, serviced, or disposed of.

Correct refrigerant is specied in the manuals and on the

spec labels provided with our products.

We will not be held responsible for mechanical failure,

system malfunction, unit breakdown or accidents caused

by failure to follow the instructions.

Do not use a charging cylinder.

If a charging cylinder is used, the composition of refriger-

ant will change and the e󰀩ciency will be lowered.

Ventilate the room if refrigerant leaks during

operation. If refrigerant comes into contact with

a ame, poisonous gases will be released.

Cautions for units utilizing refrigerant R410A

2-2. CAUTIONS RELATED TO R410A REFRIGERANT

Make sure that the inside and outside of refriger-

ant piping is clean and it has no contaminants

such as sulfur, oxides, dirt, shaving particles, etc.,

which are hazard to refrigerant cycle.

In addition, use pipes with specied thickness.

Contamination inside refrigerant piping can cause deterio-

ration of refrigerant oil, etc.

Store the piping indoors, and keep both ends of

the piping sealed until just before brazing.

(Leave elbow joints, etc. in their packaging.)

If dirt, dust or moisture enters into refrigerant cycle, that can cause

deterioration of refrigerant oil or malfunction of compressor.

The refrigerant oil applied to are and ange

connections must be ester oil, ether oil or

alkylbenzene oil in a small amount.

If large amount of mineral oil enters, that can cause deteri-

oration of refrigerant oil, etc.

Charge refrigerant from liquid phase of gas

cylinder.

If the refrigerant is charged from gas phase, composition

change may occur in refrigerant and the e󰀩ciency will be

lowered.

Do not use refrigerant other than R410A.

If other refrigerant (R22, etc.) is used, chlorine in refrigerant

can cause deterioration of refrigerant oil, etc.

Use a vacuum pump with a reverse ow check

valve.

Vacuum pump oil may ow back into refrigerant cycle and

that can cause deterioration of refrigerant oil, etc.

2-1. ALWAYS OBSERVE FOR SAFETY

Before obtaining access to terminal, all supply circuit must be disconnected.

Preparation before the repair service

• Prepare the proper tools.

• Prepare the proper protectors.

• Provide adequate ventilation.

• After stopping the operation of the air conditioner, turn o󰀨

the power-supply breaker.

• Discharge the condenser before the work involving the

electric parts.

Precautions during the repair service

• Do not perform the work involving the electric parts with

wet hands.

• Do not pour water into electric parts.

• Do not touch the refrigerant.

• Do not touch the hot or cold areas in the refrigerating

cycle.

• When the repair or the inspection of the circuit needs

to be done without turning o󰀨 the power, exercise great

caution not to touch the live parts.

• When opening or closing the valve below freezing

temperatures, refrigerant may spurt out from the gap

between the valve stem and the valve body, resulting in

injuries.

OBH702N

Unit

Electronic weighing scale

[3] Service tools

(1) Use the below service tools as exclusive tools for R410A refrigerant.

[2] Additional refrigerant charge

When charging directly from cylinder

(1) Check that cylinder for R410A on the market is a siphon type.

(2) Charging should be performed with the cylinder of siphon stood vertically. (Refrigerant is charged from liquid phase.)

[1] Cautions for service

(1) Perform service after recovering the refrigerant left in unit completely.

(2) Do not release refrigerant in the air.

(3) After completing service, charge the cycle with specied amount of refrigerant.

(4) If moisture or foreign matter might have entered the refrigerant piping during service, ensure to remove them.

No. Tool name Specications

1 Gauge manifold ·Only for R410A

·Use the existing tting specications. (UNF1/2)

·Use high-tension side pressure of 768.7 PSIG [5.3 MPaG] or over.

2 Charge hose ·Only for R410A

·Use pressure performance of 738.2 PSIG [5.09MPaG] or over.

3 Electronic weighing scale —

4 Gas leak detector ·Use the detector for R134a, R407C or R410A.

5Adaptor for reverse ow check ·Attach on vacuum pump.

6 Refrigerant charge base —

7 Refrigerant cylinder ·Only for R410A

·Top of cylinder (Pink)

·Cylinder with siphon

8 Refrigerant recovery equipment —

OBH702N

2-3. Cautions for refrigerant piping work

Refrigerant R410Ais adopted for replacement inverter series. Although the refrigerant piping work for R410Ais the same as for

R22, exclusive tools are necessary so as not to mix with different kind of refrigerant. Furthermore as the working pressure of

R410A is 1.6 times higher than that of R22, their sizes of flared sections and flare nuts are different.

Thickness of pipes

Since the working pressure of R410Ais higher compared to R22, be sure to use refrigerant piping with thickness shown below.

(Never use pipes of 7/256 in [0.7 mm] or below.)

Diagram below: Piping diameter and thickness

Nominal

dimensions (inch) Outside

diameter (mm) Thickness: in [mm]

R410A R22

1/4 6.35 1/32 [0.8] 1/32 [0.8]

3/8 9.52 1/32 [0.8] 1/32 [0.8]

1/2 12.70 1/32 [0.8] 1/32 [0.8]

5/8 15.88 5/128 [1.0] 5/128 [1.0]

3/4 19.05 — 5/128 [1.0]

Dimensions of flare cutting and flare nut

The component molecules in HFC refrigerant are smaller compared to conventional refrigerants. In addition to that, R410A is

a refrigerant, which has higher risk of leakage because its working pressure is higher than that of other refrigerants. Therefore,

to enhance airtightness and strength, flare cutting dimension of copper pipe for R410A has been specified separately from the

dimensions for other refrigerants as shown below. The dimension B of flare nut for R410A also has partly been changed to

increase strength as shown below. Set copper pipe correctly referring to copper pipe flaring dimensions for R410A below. For

1/2 and 5/8 inch pipes, the dimension B changes.

Use torque wrench corresponding to each dimension.

Dimension A

Dimension B

Flare cutting dimensions Unit: in [mm]

Nominal

dimensions (in)

Outside

diameter (mm) Dimension A (+0

-0.4)

R410A R22

1/4 6.35 11/32-23/64 [9.1] 9.0

3/8 9.52 1/2-33/64 [13.2] 13.0

1/2 12.70 41/64-21/32 [16.6] 16.2

5/8 15.88 49/64-25/32 [19.7] 19.4

3/4 19.05 — 23.3

Flare nut dimensions Unit: in [mm]

Nominal

dimensions (in)

Outside

diameter (mm) Dimension B

R410A R22

1/4 6.35 43/64 [17.0] 17.0

3/8 9.52 7/8 [22.0] 22.0

1/2 12.70 1-3/64 [26.0] 24.0

5/8 15.88 1-9/64 [29.0] 27.0

3/4 19.05 — 36.0

OBH702N

Tools for R410A (The following table shows whether conventional tools can be used or not.)

Tools and materials Use R410A tools Can R22 tools be used?

Can R407C tools be used?

Gauge manifold

Air purge, refrigerant charge

and operation check

Tool exclusive for R410A

Charge hose Tool exclusive for R410A

Gas leak detector Gas leak check Tool for HFC refrigerant

Refrigerant recovery equipment

Refrigerant recovery Tool exclusive for R410A

Refrigerant cylinder Refrigerant charge Tool exclusive for R410A

Applied oil Apply to ared section

Ester oil, ether oil and

alkylbenzene oil

(minimum amount)

Ester oil, ether oil:

Alkylbenzene oil:

minimum amount

Safety charger

Prevent compressor malfunction

when charging refrigerant by

spraying liquid refrigerant

Tool exclusive for R410A

Charge valve

Prevent gas from blowing out

when detaching charge hose

Tool exclusive for R410A

Vacuum pump Vacuum drying and air

purge

Tools for other refrigerants can be

used if equipped with adopter for

reverse ow check

(Usable if equipped with

adopter for reverse ow)

(Usable if equipped with

adopter for reverse ow)

Flare tool Flaring work of piping

Tools for other refrigerants can be

used by adjusting aring dimension

(Usable by adjusting

aring dimension)

(Usable by adjusting

aring dimension)

Bender Bend the pipes

Tools for other refrigerants can be used

Pipe cutter Cut the pipes

Tools for other refrigerants can be used

Welder and nitrogen gas cylinder

Weld the pipes

Tools for other refrigerants can be used

Refrigerant charging scale

Refrigerant charge

Tools for other refrigerants can be used

Vacuum gauge or

thermistor vacuum

gauge and vacuum valve

Check the degree of vacuum.

(Vacuum valve prevents back

ow of oil and refrigerant to

thermistor vacuum gauge)

Tools for other refrigerants

can be used

Charging cylinder Refrigerant charge Tool exclusive for R410A ─

: Prepare a new tool. (Use the new tool as the tool exclusive for R410A.)

: Tools for other refrigerants can be used under certain conditions.

: Tools for other refrigerants can be used.

OBH702N

3 PART NAMES AND FUNCTIONS

MXZ-5C42NA MXZ-5C42NA2 MXZ-5C42NA3 MXZ-5C42NA4

MXZ-2C20NAHZ MXZ-2C20NAHZ2 MXZ-2C20NAHZ3 MXZ-2C20NAHZ4

MXZ-3C24NAHZ MXZ-3C24NAHZ2 MXZ-3C24NAHZ3 MXZ-3C24NAHZ4

MXZ-3C30NAHZ MXZ-3C30NAHZ2 MXZ-3C30NAHZ3 MXZ-3C30NAHZ4

MXZ-3C24NA MXZ-3C24NA2 MXZ-3C24NA3 MXZ-3C24NA4

MXZ-3C30NA MXZ-3C30NA2 MXZ-3C30NA3 MXZ-3C30NA4

MXZ-4C36NA MXZ-4C36NA2 MXZ-4C36NA3 MXZ-4C36NA4

MXZ-2C20NA2 MXZ-2C20NA3 MXZ-2C20NA4

Drain outlet

Air inlet

(Back and side)

Air outlet

Air inlet

Air outlet

Drain outlet

(Back and side)

Air outlet

Drain outlet

Air inlet

(Back and side)

OBH702N

4 SPECIFICATION

Item Outdoor model MXZ-2C20NA2 MXZ-2C20NA3

Indoor type Non-Duct (09+09) Duct (09+12)

Capacity Cooling *1 Btu/h 18,000 20,000

Heating 47 *1 Btu/h 22,000 22,000

Heating 17 *2 Btu/h 15,500 14,500

Power

consumption

Cooling *1 W 1,417 2,000

Heating 47 *1 W 1,641 1,771

Heating 17 *2 W 1,750 1,810

EER Cooling 12.7 10.0

SEER Cooling 20.0 16.0

HSPF IV(V) Heating 10.0 9.3

COP Heating 3.93 3.64

External nish Munsell 3.0Y 7.8/1.1

Power supply V, phase, Hz 208/230, 1, 60

Max. fuse size (time delay) A 20

Min. circuit ampacity A 17.2

Fan motor F.L.A 1.77

Compressor

Model SNB140FQUH2T

Winding resistance

(at 68 ºF) ΩU-V1.99 V-W 1.99 W-U 1.99

R.L.A 10.7

L.R.A 15.5

Refrigerant control LEV

Sound level dB(A) 50/54

Defrost method Reverse cycle

Dimensions W in. 33-1/16

D in. 13

H in. 27-15/16

Weight lb. 126

Remote controller Wireless type

Control voltage (by built-in transformer) 12 - 24 V DC

Refrigerant piping Not supplied (optional parts)

Valve size Liquid in. 1/4

Gas in. 3/8

Connection method

Indoor Flared

Outdoor Flared

Refrigerant charge (R410A) lb. 5 lb. 15 oz.

Refrigeration oil (Model)  oz. (L) 20.3 (0.6) (NEO22)

NOTE: Test conditions are based on ARI 210/240. Unit: °F

Mode Test Indoor air condition Outdoor air condition

Dry bulb Wet bulb Dry bulb Wet bulb

Cooling *1: "A" Cooling steady state at rated compressor speed 80 67 95 (75)

"B-2" Cooling steady state at rated compressor speed 80 67 82 (65)

"B-1" Cooling steady state at minimum compressor speed 80 67 82 (65)

Low ambient cooling steady state at minimum compressor speed 80 67 67 (53.5)

Intermediate cooling steady state at intermediate compressor speed 80 67 87 (69)

Heating *1: Standard rating-heating at rated compressor speed 70 60 47 43

*2: Low temperature heating at maximum compressor speed 70 60 17 15

Maximum temperature heating at minimum compressor speed 70 60 62 56.5

High temperature heating at minimum compressor speed 70 60 47 43

Frost accumulation at rated compressor speed 70 60 35 33

Frost accumulation at intermediate compressor speed 70 60 35 33

OBH702N

Item Outdoor model MXZ-2C20NA4

Indoor type Non-Duct (09+09) Duct (09+12)

Capacity Cooling *1 Btu/h 18,000 20,000

Heating 47 *1 Btu/h 22,000 22,000

Heating 17 *2 Btu/h 15,500 14,500

Power

consumption

Cooling *1 W 1,417 2,000

Heating 47 *1 W 1,641 1,771

Heating 17 *2 W 1,750 1,810

EER2 Cooling 12.7 10.0

SEER2 Cooling 20.0 16.0

HSPF2 Heating 12.0 9.1

COP2 Heating 3.92 3.64
