Mitsubishi Electric NTXUKS06A112AA User manual

No. OBHT922
REVISED EDITION-A
INDOOR UNIT
SERVICE MANUAL
PARTS CATALOG (OBBT922)
CONTENTS
1. TECHNICAL CHANGES ··································· 2
2. PART NAMES AND FUNCTIONS····················· 3
3. SPECIFICATION················································ 4
4. OUTLINES AND DIMENSIONS ························ 6
5. WIRING DIAGRAM············································ 7
6. REFRIGERANT SYSTEM DIAGRAM ··············· 8
7. SERVICE FUNCTIONS ····································· 9
8. MICROPROCESSOR CONTROL ··················· 12
9. TROUBLESHOOTING····································· 21
10. DISASSEMBLY INSTRUCTIONS···················· 35
Model
NTXUKS06A112AA
Outdoor unit service manual
NTXMMX•A•BA, NTXMPH•A•BA Series
(OBHT702)
OBHT922 is void.
Revision A:
• Specications of NTXUKS06A112AA have
been corrected.

2
1TECHNICAL CHANGES
NTXUKS06A112AA
1. New model
Use the specied refrigerant only
Never use any refrigerant other than that specified.
Doing so may cause a burst, an explosion, or fire when the unit is being used, serviced, or disposed of.
Correct refrigerant is specified in the manuals and on the spec labels provided with our products.
We will not be held responsible for mechanical failure, system malfunction, unit breakdown or accidents caused by failure to
follow the instructions.
<Preparation before the repair service>
Prepare the proper tools.
Prepare the proper protectors.
Provide adequate ventilation.
After stopping the operation of the air conditioner, turn off the power-supply breaker and pull the power plug.
Discharge the capacitor before the work involving the electric parts.
<Precautions during the repair service>
Do not perform the work involving the electric parts with wet hands.
Do not pour water into the electric parts.
Do not touch the refrigerant.
Do not touch the hot or cold areas in the refrigeration cycle.
When the repair or the inspection of the circuit needs to be done without turning off the power, exercise great caution not to
touch the live parts.
WARNING
• When the refrigeration circuit has a leak, do not execute pump down with the compressor.
• When pumping down the refrigerant, stop the compressor before disconnecting the refrigerant pipes.
The compressor may burst if air etc. get into it.
• When opening or closing the valve below freezing temperatures, refrigerant may spurt out from the gap
between the valve stem and the valve body, resulting in injuries.
Revision A:
• Specications of NTXUKS06A112AA have been corrected.
OBHT922A

3
PART NAMES AND FUNCTIONS2
ACCESSORIES
INDOOR UNIT
NTXUKS06A112AA
MODELS NTXUKS06A112AA
(1) Alkaline battery (AAA) for remote controller 2
(2) Drain hose (with insulation) 1
(3) Special washer (with cushion, 4pcs) 8
(4) Installation template 1
(5) Fixing screw for (4) M5 х 30 mm 4
(6) Band 1
(7) Fixing screw for (6) 4 х 16 mm 2
(8) Remote controller 1
(9) Remote controller holder 1
(
10 ) Fixing screw for (9) 3.5 x 16 mm (Black) 2
Horizontal vane
Vertical vane
Air outlet
Air filter
(Air purifying filter)
Air inlet
Intake grille
Safety strings Spec name plate
Remote control receiving section
Emergency operation switch
Operation indicator lamp
Display section
Air cleaning filter
(Anti-allergy Enzyme
Filter, option)
OBHT922A

4
3 SPECIFICATION
Indoor model NTXUKS06A112AA
Power supply V, phase, Hz 208/230, 1, 60
Max. fuse size (time delay)/ Disconnect switch A 15
Airow
High - Med. - Low - SLow
COOL Dry (Wet) CFM 198 - 184 - 166 - 152
HEAT Dry CFM 212 - 194 - 173 - 152
Sound level
High - Med. - Low - SLow
Cooling dB (A) 36 - 34 - 31 - 29
Heating dB (A) 37 - 35 - 32 - 29
Cond. drain connection O.D. in. ø1 (26 mm)
Dimensions
W
in.
33-3/16
D11-7/8
H7-11/16
Weight Ib. 25
External nish White
Control voltage (by built-in transformer) 12 - 24 V DC
NOTE: Test conditions are based on ARI 210/240.
1. Multi connection
Specifications and rated conditions of main electric parts
Model
Item NTXUKS06A112AA
Fuse (F11) T3.15AL250V
Horizontal vane motor (MV1) 12 V DC
Vertical vane motor (MV2) 12 V DC
Varistor (NR11) 470 V
DRAIN PUMP (DP) 230 V 6.4 W
DRAIN SENSOR (DS) Thermistor 25°C 5.3kΩ
OBHT922A

5
(2) OPERATION
*The operating range of the outdoor unit depends on the connected outdoor unit.
Mode Condition
Intake air temperature (°F)
Indoor Outdoor
DB WB DB WB
Cooling
Standard temperature 80 67 95 —
Maximum temperature 90 73 115 —
Minimum temperature 67 57 14 —
Maximum humidity 78% —
Heating
Standard temperature 70 60 47 43
Maximum temperature 80 67 75 65
Minimum temperature 70 60 -13 -14
3-1. OPERATING RANGE
(1) POWER SUPPLY
Rated voltage Guaranteed voltage (V)
Indoor unit
208/230 V
1 phase
60 Hz
Min. 187 208 230 Max. 253
● The air coverage is the figure up to the
position where the air speed is 1 ft./s.,
when air is blown out horizontally from
the unit properly at the High speed posi-
tion.
The coverage should be used only as a
general guideline since it varies accord-
ing to the size of the room and furniture
arranged inside the room.
3-2. OUTLET AIR SPEED AND COVERAGE
Multi connection
Model Mode Function Airow
(CFM)
Air speed
(ft./s.)
Coverage
(ft.)
NTXUKS06A112AA
HEAT Dry 212 14.6 17.6
COOL Dry 198 15.6 18.8
Wet ———
OBHT922A

6
4OUTLINES AND DIMENSIONS
Unit: inch
INDOOR UNIT
NTXUKS06A112AA
(TLP-448W/ALP-448W)
OBHT922A

7
WIRING DIAGRAM5
INDOOR UNIT
NTXUKS06A112AA
NOTES :
1.About the outdoor side electric wiring
refer to the outdoor unit electric wiring
diagram for servicing.
2.Use copper conductors only.
(For field wiring)
3.Symbols below indicate.
: Terminal
block
: Connector
: Borne : Connecteur
REMARQUES :
1.Pour le câblage électronique côté
extérieur, se reporter au schéma
d'entretien du câblage électronique
de l'appareil extérieur.
2.Utiliser des fils d'alimentation en cuivre.
3.Les symboles ont les significations
suivantes
OBHT922A

8
REFRIGERANT SYSTEM DIAGRAM6
INDOOR UNIT
Unit: inch(mm)
NTXUKS06A112AA
Indoor
heat
exchanger
Flared connection
Room temperature
thermistor
RT11
Indoor coil
thermistor
RT13 (sub)
Flared connection
Refrigerant pipe ø3/8(ø9.52)
(with heat insulator)
Refrigerant pipe ø1/4(ø6.35)
(with heat insulator)
Indoor coil
thermistor
RT12 (main)
Refrigerant flow in cooling
Refrigerant flow in heating
OBHT922A

9
7SERVICE FUNCTIONS
7-1. TIMER SHORT MODE
• For service, the following set time can be shortened by bridging the timer short mode point on the electronic control P.C.
board. (Refer to 9-7.)
• The set time for the ON/OFF timer can be reduced to 1 second for each minute.
• After the breaker is turned on, the time for starting the compressor, which normally takes 3 minutes, can be reduced to 3
seconds. Restarting the compressor, which takes 3 minutes, cannot be reduced.
Table 1
7-2. HOW TO SET REMOTE CONTROLLER EXCLUSIVELY FOR A PARTICULAR INDOOR UNIT
A maximum of 4 indoor units with wireless remote controllers can be used in a room.
To operate the indoor units individually with each remote controller, assign a number to each remote controller according
to the number of the indoor unit.
This setting can be set only when all the following conditions are met:
• The remote controller is powered OFF.
• Weekly timer is not set.
• Weekly timer is not being edited.
2. How to set the remote controller
(1) Hold down button on the remote controller for 2 seconds to enter the pairing mode.
(2) Press button again and assign a number to each remote controller.
Each press of button advances the number in the following order: 1 → 2 → 3 → 4.
(3) Press button to complete the pairing setting.
After the setting, turn ON the power supply and with the remote controller headed towards the indoor unit, press the OFF/
ON (stop/operate) button. If 1 or 2 beeps is heard from the indoor unit, the setting is completed correctly.
The remote controller that first sends a signal to an indoor unit will be regarded as the remote controller for the indoor
unit.
Once they are set, the indoor unit will only receive the signal from the assigned remote controller afterwards.
1. How to modify the electronic control P.C. board
Turn OFF the power supply before modification. To assign a number to each indoor unit , cut off “JR05” and “JR06” on the
electronic control P.C. board as shown in Table 1. (Refer to 9-7.)
Unit No. 1
Unit No. 2
Unit No. 3
Unit No. 4
JR05
No modification
Cut off JR05
No modification
Cut off JR05
JR06
No modification
No modification
Cut off JR06
Cut off JR06
C111
IC101
JR05
JR06
NTXUKS06A112AA
OBHT922A

10
NOTE:
• The operation settings are memorized when 10 seconds has passed after the indoor unit was operated with the
remote controller.
• If main power is turned OFF or a power failure occurs while AUTO START/STOP timer is active, the timer setting is
cancelled.
• If the unit has been off with the remote controller before power failure, the auto restart function does not work as the
power button of the remote controller is off.
• To prevent breaker tripping due to the rush of starting current, systematize other home appliance not to turn on at
the same time.
• When some air conditioners are connected to the same supply system, if they are operated before power failure,
the starting current of all the compressors may flow simultaneously at restart.
Therefore, the special counter-measures are required to prevent the main voltage-drop or the rush of the starting
current by adding to the system that allows the units to start one by one.
C111
JR77
IC101
How to disable “AUTO RESTART FUNCTION”
Turn off the main power for the unit.
Cut the jumper wire to JR77 on the indoor electronic control P.C. board. (Refer to 9-7.)
Operation
If the main power has been cut, the operation settings remain.
After the power is restored, the unit restarts automatically according to the memory.
(However, it takes at least 3 minutes for the compressor to start running.)
7-3. AUTO RESTART FUNCTION
When the indoor unit is controlled with the remote controller, the operation mode, the set temperature, and the fan speed
are memorized by the indoor electronic control P.C. board. “AUTO RESTART FUNCTION” automatically starts operation
in the same mode just before the shutoff of the main power.
