TECHNICAL DATA BOOK
CONTENTS
1. REFERENCE SERVICE MANUAL·············································2
2. SPECIFICATIONS ······································································3
3. OUTLINES AND DIMENSIONS ···············································24
4. WIRING DIAGRAM···································································44
5. REFRIGERANT SYSTEM DIAGRAM······································58
6. PERFORMANCE CURVES······················································63
7. CORRECTION FACTORS························································65
8. APPLICABLE EXTENSION PIPE FOR EACH MODEL··········66
9. AIR FLOW DATA······································································75
10. NOISE CRITERION CURVES··················································90
11. OPTIONAL PARTS ··································································106
<Indoor unit>
[Model names]
R410A
PLA-RP·BA/BA2/BA3
PEAD-RP·JA(L)
PEA-RP·GA
PKA-RP·HAL
PKA-RP·KAL
PCA-RP·KA
PCA-RP·HA
PSA-RP·GA
<Outdoor unit>
[Model names]
SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
PUHZ-RP35/50/60/71VHA4
PUHZ-RP100/125/140VKA
PUHZ-RP100/125/140YKA
PUHZ-RP200/250YKA
July 2009
INVERTER
kW Model
No. OCS16

2
1REFERENCE SERVICE MANUAL
For information on service, please refer to the service manual as follows.
1-1. INDOOR UNIT SERVICE MANUAL
Model name Service Ref. Service
Manual No.
PLA-RP35/50/60/71/100/125BA
PLA-RP71/125/140BA2 PLA-RP35/50/60/71/100/125BA#2.UK PLA-RP71/125/140BA2.UK OCH412 OCB412
PLA-RP100BA3 PLA-RP100BA3 OCH459
OCB459
PCA-RP50/60/71/100/125/140KA PCA-RP50/60/71/100/125/140KA OCH454
OCB454
PCA-RP71/125HA PCA-RP71/125HA#1 OC329
PKA-RP35/50HAL PKA-RP35/50HAL OCH453
OCB453
PKA-RP60/71/100KAL PKA-RP60/71/100KAL.TH OCH452
OCB452
PSA-RP71/100/125/140GA PSA-RP71/100/125/140GA#1 OC332
PEAD-RP35/50/60/71/100/125/140JA(L)
PEAD-RP35/50/60/71/100/125/140JA(L).UK
HWE08130
BWE08240
PEA-RP200/250/400/500GA
PEA-RP200/250/400/500GA.TH-AF
PEA-RP200/250GA.TH-AFMF
HWE0708A
1-2. OUTDOOR UNIT
Model name Service Ref. Service
Manual No.
PUHZ-RP35/50/60/71VHA4
PUHZ-RP100/125/140VKA
PUHZ-RP100/125/140YKA
PUHZ-RP200/250YKA
PUHZ-RP35/50/60/71VHA4
PUHZ-RP100/125/140VKA
PUHZ-RP100/125/140YKA
PUHZ-RP200/250YKA
OCH451
OCB451

3
2SPECIFICATIONS
2-1. CEILING CASSETTE TYPE
Model name Indoor unit PLA-RP35BA PLA-RP50BA
Outdoor unit PUHZ-RP35VHA4 PUHZ-RP50VHA4
Cooling Capacity Btu/h 12,300 17,100
kW 3.6(1.6-4.5) 5.0(2.3-5.6)
Total input kW 1.07 1.55
EER 3.36 3.23
Energy label class AA
SHF 0.84 0.81
Heating Capacity Btu/h 14,000 20,500
kW 4.1(1.6-5.2) 6.0(2.5-7.3)
Total input kW 1.12 1.66
COP 3.66 3.61
Energy label class A A
Booster heater kW – –
Power supply Phase :1
Cycle Hz 50
Voltage V 230
Breaker size A 16
Indoor unit Air flow CMM 11-12-13-15 12-14-16-18
(Low-Medium2-Medium1-High) CFM 390-425-460-530 425-495-565-635
External pressure Pa 0 0
Sound level dB(A) 27-28-29-31 28-29-31-32
(Low-Medium2-Medium1-High)
External finish (Panel) White Munsell 6.4Y 8.9/0.4
Dimension W : mm 840 (950)
Unit (Panel) D : mm 840 (950)
H : mm 258 (35)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 10-3/16 (1-3/8)
Weight kg 22(6)
Unit (Panel) lbs 49(13)
Field drain pipe O.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 35
CFM 1,240
Sound level at cooling dB(A) 44
Sound level at heating dB(A) 46
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 800
D : mm 300+23
H : mm 600
W : inch 31-1/2
D : inch 11-13/16 + 7/8
H : inch 23-5/8
Weight kg 42
lbs 93
Refrigerant pipe size Gas side O.D. mm 12.7
inch 1/2
Liquid side O.D. mm 6.35
inch 1/4
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27(80°F) W.B. 19(66°F) Outdoor : D.B. 35(95°F) W.B. 24(75°F)
Heating Indoor: D.B. 20(68°F) Outdoor : D.B. 7(45°F) W.B. 6(43°F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35°C, W.B. 22.5°C D.B. 46°C
Lower limit D.B. 19°C, W.B. 15°C D.B. -5°C +
Heating Upper limit D.B. 28°C D.B. 21°C, W.B. 15°C
Lower limit D.B. 17°C D.B. -11°C, W.B. -12°C
4. Above data are based on the indicated voltage.
+If optional air protect guide installed. D.B.-15
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz

4
Model name Indoor unit PLA-RP60BA PLA-RP71BA
Outdoor unit PUHZ-RP60VHA4 PUHZ-RP71VHA4
Cooling Capacity Btu/h 20,500 24,200
kW 6.0(2.7-6.7) 7.1(3.3-8.1)
Total input kW 1.60 2.09
EER 3.75 3.40
Energy label class A –
SHF 0.76 0.73
Heating Capacity Btu/h 23,900 27,300
kW 7.0(2.8-8.2) 8.0(3.5-10.2)
Total input kW 1.82 2.15
COP 3.85 3.72
Energy label class A –
Booster heater kW – –
Power supply Phase :1
Cycle Hz 50
Voltage V 230
Breaker size A 25
Indoor unit Air flow CMM 12-14-16-18 14-16-18-21
(Low-Medium2-Medium1-High) CFM 425-495-565-635 495-565-635-740
External pressure Pa 0 0
Sound level dB(A) 28-29-31-32 28-30-32-34
(Low-Medium2-Medium1-High)
External finish (Panel) White Munsell 6.4Y 8.9/0.4
Dimension W : mm 840 (950)
Unit (Panel) D : mm 840 (950)
H : mm 258 (35)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 10-3/16 (1-3/8)
Weight kg 23(6)
Unit (Panel) lbs 51(13)
Field drain pipe O.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 60
CFM 2,120
Sound level at cooling dB(A) 47
Sound level at heating dB(A) 48
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 943
W : inch 37-3/8
D : inch 13 + 1-3/16
H : inch 37-1/8
Weight kg 67
lbs 148
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference mMax.30
Length mMax.50
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27(80°F) W.B. 19(66°F) Outdoor : D.B. 35(95°F) W.B. 24(75°F)
Heating Indoor: D.B. 20(68°F) Outdoor : D.B. 7(45°F) W.B. 6(43°F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35°C, W.B. 22.5°C D.B. 46°C
Lower limit D.B. 19°C, W.B. 15°C D.B. -5°C +
Heating Upper limit D.B. 28°C D.B. 21°C, W.B. 15°C
Lower limit D.B. 17°C D.B. -20°C, W.B. -20°C
4. Above data are based on the indicated voltage.
+If optional air protect guide installed. D.B.-15
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz

5
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27(80°F) W.B. 19(66°F) Outdoor : D.B. 35(95°F) W.B. 24(75°F)
Heating Indoor: D.B. 20(68°F) Outdoor : D.B. 7(45°F) W.B. 6(43°F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35°C, W.B. 22.5°C D.B. 46°C
Lower limit D.B. 19°C, W.B. 15°C D.B. -5°C +
Heating Upper limit D.B. 28°C D.B. 21°C, W.B. 15°C
Lower limit D.B. 17°C D.B. -20°C, W.B. -20°C
4. Above data are based on the indicated voltage.
+If optional air protect guide installed. D.B.-15
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PLA-RP71BA2 PLA-RP100BA3
Outdoor unit PUHZ-RP71VHA4 PUHZ-RP100VKA
Cooling Capacity Btu/h 24,200 34,100
kW 7.1(3.3-8.1) 10.0(4.9-11.4)
Total input kW 1.90 2.39
EER 3.74 4.18
Energy label class A A
SHF 0.73 0.74
Heating Capacity Btu/h 27,300 38,200
kW 8.0(3.5-10.2) 11.2(4.5-14.0)
Total input kW 1.90 2.43
COP 4.21
PLA-RP100BA
PUHZ-RP100VKA
34,100
10.0(4.9-11.4)
2.65
3.77
–
0.74
38,200
11.2(4.5-14.0)
2.79
4.01 4.61
Energy label class A –
Booster heater kW – – A –
Power supply Phase :1
Cycle Hz 50
Voltage V 230
Breaker size A 3225
23(6)
51(13) 25(6) 55(13) 26(6) 57(13)
Indoor unit Air flow CMM 14-16-18-21
(Low-Medium2-Medium1-High)
CFM 495-565-635-740
External pressure Pa 0
Sound level dB(A) 28-30-32-34
20-23-26-30
710-810-920-1060
0
32-34-37-40
(Low-Medium2-Medium1-High)
External finish (Panel) White Munsell 6.4Y 8.9/0.4
Dimension W : mm 840 (950)
Unit (Panel) D : mm 840 (950)
H : mm 258 (35) 298 (35)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 10-3/16 (1-3/8) 11-3/4 (1-3/8)
Weight kg
Unit (Panel) lbs
Field drain pipe O.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 110
CFM 3,880
60
2,120
Sound level at cooling dB(A) 47
Sound level at heating dB(A) 48 49
51
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30
H : mm 943 1,338
1,050
W : inch 41-5/1637-3/8
D : inch 13 + 1-3/16
H : inch 37-1/8 52-11/16
Weight kg 67 116
lbs 148 256
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference mMax.30
Length m Max. 75Max. 50

6
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27(80°F) W.B. 19(66°F) Outdoor : D.B. 35(95°F) W.B. 24(75°F)
Heating Indoor: D.B. 20(68°F) Outdoor : D.B. 7(45°F) W.B. 6(43°F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35°C, W.B. 22.5°C D.B. 46
Lower limit D.B. 19°C, W.B. 15°C D.B. -5+
Heating Upper limit D.B. 28°C D.B. 21, W.B. 15
Lower limit D.B. 17°C D.B. -20, W.B. -20
4. Above data are based on the indicated voltage.
+If optional air protect guide installed. D.B.-15
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PLA-RP125BA PLA-RP125BA2 PLA-RP140BA2
Outdoor unit PUHZ-RP125VKA PUHZ-RP125VKA PUHZ-RP140VKA
Cooling Capacity Btu/h 42,700 42,700 47,800
kW 12.5(5.5-14.0) 12.5(5.5-14.0) 14.0(6.2-15.3)
Total input kW 3.83 3.67 4.36
EER 3.26 3.41 3.21
Energy label class – A A
SHF 0.71 0.71 0.71
Heating Capacity Btu/h 47,800 47,800 54,600
kW 14.0(5.0-16.0) 14.0(5.0-16.0) 16.0(5.7-18.0)
Total input kW 3.86 3.50 4.32
COP 3.63 4.00 3.70
Energy label class – A A
Booster heater kW – – –
Power supply Phase :1
Cycle Hz 50
Voltage V 230
Breaker size A 32
25(6)
55(13) 27(6) 60(13)
40
Indoor unit Air flow CMM 22-25-28-31 22-25-28-31
(Low-Medium2-Medium1-High)
CFM 780-880-990-1090 780-880-990-1090
External pressure Pa 0 0
Sound level dB(A) 34-36-39-41 34-36-39-41
24-26-29-32
850-920-1020-1130
0
36-39-42-44
(Low-Medium2-Medium1-High)
External finish (Panel) White Munsell 6.4Y 8.9/0.4
Dimension W : mm 840 (950)
Unit (Panel) D : mm 840 (950)
H : mm 298 (35)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 11-3/4 (1-3/8)
Weight kg 27(6)
Unit (Panel) lbs 60(13)
Field drain pipe O.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 120
CFM 4,230
Sound level at cooling dB(A) 50
Sound level at heating dB(A) 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 1,050
D : mm 330+30
H : mm 1,338
W : inch 41-5/16
D : inch 13 + 1-3/16
H : inch 52-11/16
Weight kg 116 119
lbs 256 262
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75

7
Model name Indoor unit PLA-RP100BA PLA-RP100BA3
Outdoor unit PUHZ-RP100YKA PUHZ-RP100YKA
Cooling Capacity Btu/h 34,100 34,100
kW 10.0(4.9-11.4) 10.0(4.9-11.4)
Total input kW 2.65 2.39
EER 3.77 4.18
Energy label class –A
SHF 0.74 0.74
Heating Capacity Btu/h 38,200 38,200
kW 11.2(4.5-14.0) 11.2(4.5-14.0)
Total input kW 2.79 2.43
COP 4.01 4.61
Energy label class –A
Booster heater kW – –
Power supply Phase :3
Cycle Hz 50
Voltage V 400
Breaker size A 16
Indoor unit Air flow CMM 20-23-26-30 20-23-26-30
(Low-Medium2-Medium1-High)
CFM 710-810-920-1,060 710-810-920-1,060
External pressure Pa 0 0
Sound level dB(A) 32-34-37-40 32-34-37-40
(Low-Medium2-Medium1-High)
External finish (Panel) White Munsell 6.4Y 8.9/0.4
Dimension W : mm 840 (950)
Unit (Panel) D : mm 840 (950)
H : mm 298 (35)
W : inch 33-1/16 (37-3/8)
D : inch 33-1/16 (37-3/8)
H : inch 11-3/4 (1-3/8)
Weight kg 25 (6)
Unit (Panel) lbs 55 (13) 26 (6) 57 (13)
Field drain pipe O.D. mm 32
inch 1-1/4
Outdoor unit Air flow CMM 110
CFM 3,880
Sound level at cooling dB(A) 49
Sound level at heating dB(A) 51
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 1,050
D : mm 330+30
H : mm 1,338
W : inch 41-5/16
D : inch 13 + 1-3/16
H : inch 52-11/16
Weight kg 124
lbs 273
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27(80°F) W.B. 19(66°F) Outdoor : D.B. 35(95°F) W.B. 24(75°F)
Heating Indoor: D.B. 20(68°F) Outdoor : D.B. 7(45°F) W.B. 6(43°F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35°C, W.B. 22.5°C D.B. 46°C
Lower limit D.B. 19°C, W.B. 15°C D.B. -5°C +
Heating Upper limit D.B. 28°C D.B. 21°C, W.B. 15°C
Lower limit D.B. 17°C D.B. -20°C, W.B. -20°C
4. Above data are based on the indicated voltage.
Indoor unit Single phase 230V 50Hz
3 phase 400V 50Hz
Outdoor unit
Indoor unit 198~264V, 50Hz
342~457V, 50Hz
Outdoor unit
3. Guaranteed voltage
If optional air protect guide installed. D.B.-15

8
Model name Indoor unit PLA-RP125BA PLA-RP125BA2 PLA-RP140BA2
Outdoor unit PUHZ-RP125YKA PUHZ-RP125YKA PUHZ-RP140YKA
Cooling Capacity Btu/h
kW
Total input kW
EER
Energy label class
SHF
Heating Capacity Btu/h
kW
Total input kW
COP
Energy label class
Booster heater kW
Power supply Phase :3
Cycle Hz 50
Voltage V 400
Breaker size A 16
Indoor unit Air flow CMM
(Low-Medium2-Medium1-High)
CFM
External pressure Pa
Sound level dB(A)
(Low-Medium2-Medium1-High)
External finish (Panel)
Dimension W : mm
Unit (Panel) D : mm
H : mm
W : inch
D : inch
H : inch
Weight kg
Unit (Panel) lbs
Field drain pipe O.D. mm
inch
Outdoor unit Air flow CMM
CFM
Sound level at cooling dB(A)
Sound level at heating dB(A)
External finish
Dimension W : mm
D : mm
H : mm
W : inch
D : inch
H : inch
Weight kg 126 132
lbs 278 291
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
42,700 42,700 47,800
12.5(5.5-14.0) 12.5(5.5-14.0) 14.0(6.2-15.3)
3.83 3.67 4.36
3.26 3.41 3.21
–AA
0.71 0.71 0.71
47,800 47,800 54,600
14.0(5.0-16.0) 14.0(5.0-16.0) 16.0(5.7-18.0)
3.86 3.50 4.32
3.63 4.00 3.70
–AA
–––
25(6)
55(13) 27(6) 60(13)
22-25-28-31 22-25-28-31
780-880-990-1090 780-880-990-1090
00
34-36-39-41 34-36-39-41
24-26-29-32
850-920-1020-1130
0
36-39-42-44
White Munsell 6.4Y 8.9/0.4
840 (950)
840 (950)
298 (35)
33-1/16 (37-3/8)
33-1/16 (37-3/8)
11-3/4 (1-3/8) 27(6)
60(13)
32
1-1/4
120
4,230
50
52
Ivory Munsell 3Y 7.8/1.1
1,050
330+30
1,338
41-5/16
13 + 1-3/16
52-11/16
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27(80°F) W.B. 19(66°F) Outdoor : D.B. 35(95°F) W.B. 24(75°F)
Heating Indoor: D.B. 20(68°F) Outdoor : D.B. 7(45°F) W.B. 6(43°F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35°C, W.B. 22.5°C D.B. 46°C
Lower limit D.B. 19°C, W.B. 15°C D.B. -5°C +
Heating Upper limit D.B. 28°C D.B. 21°C, W.B. 15°C
Lower limit D.B. 17°C D.B. -20°C, W.B. -20°C
4. Above data are based on the indicated voltage.
Indoor unit Single phase 230V 50Hz
3 phase 400V 50Hz
Outdoor unit
Indoor unit 198~264V, 50Hz
342~457V, 50Hz
Outdoor unit
3. Guaranteed voltage
If optional air protect guide installed. D.B.-15

9
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27(80°F) W.B. 19(66°F) Outdoor : D.B. 35(95°F) W.B. 24(75°F)
Heating Indoor: D.B. 20(68°F) Outdoor : D.B. 7(45°F) W.B. 6(43°F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35°C, W.B. 22.5°C D.B. 46°C
Lower limit D.B. 19°C, W.B. 15°C D.B. -5°C +
Heating Upper limit D.B. 28°C D.B. 21°C, W.B. 15°C
Lower limit D.B. 17°C D.B. -11°C, W.B. -12°C
4. Above data are based on the indicated voltage.
+If optional air protect guide installed. D.B.-15
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PEAD-RP35JA(L) PEAD-RP50JA(L)
Outdoor unit PUHZ-RP35VHA4 PUHZ-RP50VHA4
Cooling Capacity Btu/h 12,300 17,100
kW 3.6(1.6-4.5) 5.0(2.3-5.6)
Total input kW 1.02(1.00) 1.55(1.53)
EER 3.53(3.60) 3.23(3.27)
Energy label class A A
SHF 0.85 0.84
Heating Capacity Btu/h 14,000 20,500
kW 4.1(1.6-5.2) 6.0(2.5-7.3)
Total input kW 1.10 1.56
COP 3.73 3.85
Energy label class A A
Booster heater kW - -
Power supply Phase :1
Cycle Hz 50
Voltage V 230
Breaker size A 16
Indoor unit Air flow CMM 10-12-14
(Low-Middle-High) CFM 353-424-494
External pressure Pa 35/50/70/100/150
Sound level dB(A) 23-27-30
(Low-Middle-High/ 50Pa)
12-14.5-17
424-512-600
26-31-35
External finish Galvanized sheets
Dimension W : mm 900
D : mm 732
H : mm 250
W : inch 35-7/16
D : inch 28-7/8
H : inch 9-7/8
Weight kg 26(25) 28(27)
lbs
mm
inch
58(56) 62(60)
Field drain pipe O.D. 32
1-1/4
Outdoor unit Air flow CMM 35
CFM 1,240
Sound level at cooling dB(A) 44
Sound level at heating dB(A) 46
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 800
D : mm 300+23
H : mm 600
W : inch 31-1/2
D : inch 11-13/16 + 7/8
H : inch 23-5/8
Weight kg 42
lbs 93
Refrigerant pipe size Gas side O.D. mm 12.7
inch 1/2
Liquid side O.D. mm 6.35
inch 1/4
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
2-2. CEILING-CONCEALED TYPE

10
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27(80°F) W.B. 19(66°F) Outdoor : D.B. 35(95°F) W.B. 24(75°F)
Heating Indoor: D.B. 20(68°F) Outdoor : D.B. 7(45°F) W.B. 6(43°F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35°C, W.B. 22.5°C D.B. 46°C
Lower limit D.B. 19°C, W.B. 15°C D.B. -5°C +
Heating Upper limit D.B. 28°C D.B. 21°C, W.B. 15°C
Lower limit D.B. 17°C D.B. -20°C, W.B. -20°C
4. Above data are based on the indicated voltage.
+If optional air protect guide installed. D.B.-15
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PEAD-RP60JA(L) PEAD-RP71JA(L)
Outdoor unit PUHZ-RP60VHA4 PUHZ-RP71VHA4
Cooling Capacity Btu/h 20,500 24,200
kW 6.0(2.7-6.7) 7.1(3.3-8.1)
Total input kW 1.60(1.58) 2.03(2.01)
EER 3.75(3.80) 3.50(3.53)
Energy label class A A
SHF 0.83 0.83
Heating Capacity Btu/h 23,900 27,300
kW 7.0(2.8-8.2) 8.0(3.5-10.2)
Total input kW 1.75 2.00
COP 4.00 4.00
Energy label class A A
Booster heater kW - -
Power supply Phase :1
Cycle Hz 50
Voltage V 230
Breaker size A 25
Indoor unit Air flow CMM 14.5-18-21 17.5-21-25
(Low-Middle-High) CFM 512-636-742 618-742-883
External pressure Pa 35/50/70/100/150
Sound level dB(A) 25-29-33 26-30-34
(Low-Middle-High/ 50Pa)
External finish Galvanized sheets
Dimension W : mm 1,100
D : mm 732
H : mm 250
W : inch 43-5/16
D : inch 28-7/8
H : inch 9-7/8
Weight kg 33(32) 33(32)
lbs
mm
inch
73(71) 73(71)
Field drain pipe O.D. 32
1-1/4
Outdoor unit Air flow CMM 60 60
CFM 2,120 2,120
Sound level at cooling dB(A) 47 47
Sound level at heating dB(A) 48 48
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950 950
D : mm 330+30 330+30
H : mm 943 943
W : inch 37-3/8 37-3/8
D : inch 13 + 1-3/16 13 + 1-3/16
H : inch 37-1/8 37-1/8
Weight kg 67
lbs 148
Refrigerant pipe size Gas side O.D. mm 15.88 15.88
inch 5/8 5/8
Liquid side O.D. mm 9.52 9.52
inch 3/8 3/8
Refrigerant pipe length Height difference m Max. 30 Max. 30
Length m Max. 50 Max. 50

11
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27(80°F) W.B. 19(66°F) Outdoor : D.B. 35(95°F) W.B. 24(75°F)
Heating Indoor: D.B. 20(68°F) Outdoor : D.B. 7(45°F) W.B. 6(43°F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35°C, W.B. 22.5°C D.B. 46
Lower limit D.B. 19°C, W.B. 15°C D.B. -5+
Heating Upper limit D.B. 28°C D.B. 21, W.B. 15
Lower limit D.B. 17°C D.B. -20, W.B. -20
4. Above data are based on the indicated voltage.
+If optional air protect guide installed. D.B.-15
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PEAD-RP100JA(L) PEAD-RP125JA(L) PEAD-RP140JA(L)
Outdoor unit PUHZ-RP100VKA PUHZ-RP125VKA PUHZ-RP140VKA
Cooling Capacity Btu/h 34,100 42,700 47,800
kW 10.0(4.9-11.4) 12.5(5.5-14.0) 14.0(6.2-15.3)
Total input kW 2.77(2.75) 3.86(3.84) 4.36(4.34)
EER 3.61(3.64) 3.24(3.26) 3.21(3.23)
Energy label class A A A
SHF 0.82 0.84 0.83
Heating Capacity Btu/h 38,200 47,800 54,600
kW 11.2(4.5-14.0) 14.0(5.0-16.0) 16.0(5.7-18.0)
Total input kW 2.72 3.50 4.04
COP 4.12 4.00 3.96
Energy label class A A A
Booster heater kW - - -
Power supply Phase :1
Cycle Hz 50
Voltage V 230
Breaker size A 32 40
Indoor unit Air flow CMM 24-29-34 32-39-46
(Low-Middle-High) CFM 847-1,024-1,201 29.5-35.5-42 1,042-1,253-1,483 1,130-1,377-1,624
External pressure Pa 35/50/70/100/150
Sound level dB(A) 29-34-38 33-36-40 34-38-43
(Low-Middle-High/50Pa)
External finish Galvanized sheets
Dimension W : mm 1,400 1,600
D : mm 732
H : mm 250
W : inch 55-1/8 63
D : inch 28-7/8
H : inch 9-7/8
Weight kg 41(40) 47(46)
lbs 91(89) 104(102)
43(42)
95(93)
mm
inch 1-1/4
Field drain pipe O.D. 32
Outdoor unit Air flow CMM 120
CFM 4,230
110
3,880
Sound level at cooling dB(A) 49 50
Sound level at heating dB(A) 51 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 1,050
D : mm 330+30
H : mm 1,338
W : inch 41-5/16
D : inch 13 + 1-3/16
H : inch 52-11/16
Weight kg 116 116
lbs 256 256 119 262
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75

12
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27(80°F) W.B. 19(66°F) Outdoor : D.B. 35(95°F) W.B. 24(75°F)
Heating Indoor: D.B. 20(68°F) Outdoor : D.B. 7(45°F) W.B. 6(43°F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35°C, W.B. 22.5°C D.B. 46°C
Lower limit D.B. 19°C, W.B. 15°C D.B. -5°C +
Heating Upper limit D.B. 28°C D.B. 21°C, W.B. 15°C
Lower limit D.B. 17°C D.B. -20°C, W.B. -20°C
4. Above data are based on the indicated voltage.
Indoor unit Single phase 230V 50Hz
3 phase 400V 50Hz
Outdoor unit
Indoor unit 198~264V, 50Hz
342~457V, 50Hz
Outdoor unit
3. Guaranteed voltage
+If optional air protect guide installed. D.B.-15
Model name Indoor unit PEAD-RP100JA(L) PEAD-RP125JA(L) PEAD-RP140JA(L)
Outdoor unit PUHZ-RP100YKA PUHZ-RP125YKA PUHZ-RP140YKA
Cooling Capacity Btu/h
kW
Total input kW
EER
Energy label class
SHF
Heating Capacity Btu/h
kW
Total input kW
COP
Energy label class
Booster heater kW - - -
Power supply Phase :3
Cycle Hz 50
Voltage V 400
Breaker size A 16
Indoor unit
Outdoor unit
Weight kg 124 132
lbs 273 126 278 291
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
34,100 42,700 47,800
10.0(4.9-11.4) 12.5(5.5-14.0) 14.0(6.2-15.3)
2.77(2.75) 3.86(3.84) 4.36(4.34)
3.61(3.64) 3.24(3.26) 3.21(3.23)
AAA
0.82 0.84 0.83
38,200 47,800 54,600
11.2(4.5-14.0) 14.0(5.0-16.0) 16.0(5.7-18.0)
2.72 3.50 4.04
4.12 4.00 3.96
AAA
Air flow CMM 24-29-34 32-39-46
(Low-Middle-High) CFM 847-1,024-1,201 29.5-35.5-42 1,042-1,253-1,483 1,130-1,377-1,624
External pressure Pa 35/50/70/100/150
Sound level dB(A) 29-34-38 33-36-40 34-38-43
(Low-Middle-High/50Pa)
External finish Galvanized sheets
Dimension W : mm 1,400 1,600
D : mm 732
H : mm 250
W : inch 55-1/8 63
D : inch 28-7/8
H : inch 9-7/8
Weight kg 41(40) 47(46)
lbs 91(89) 104(102)
43(42)
95(93)
mm
inch 1-1/4
Field drain pipe O.D. 32
Air flow CMM 120
CFM 4,230
110
3,880
Sound level at cooling dB(A) 49 50
Sound level at heating dB(A) 51 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 1,050
D : mm 330+30
H : mm 1,338
W : inch 41-5/16
D : inch 13 + 1-3/16
H : inch 52-11/16

13
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27(80°F) W.B. 19(66°F) Outdoor : D.B. 35(95°F) W.B. 24(75°F)
Heating Indoor: D.B. 20(68°F) Outdoor : D.B. 7(45°F) W.B. 6(43°F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35°C, W.B. 22.5°C D.B. 46°C
Lower limit D.B. 19°C, W.B. 15°C D.B. -5°C +1
Heating Upper limit D.B. 28°C D.B. 21°C, W.B. 15°C
Lower limit D.B. 17°C
D.B. -20°C, W.B. -20°C
4. Above data are based on the indicated voltage.
+1. If optional air protect guide is installed : D.B.-15
Indoor unit 3 phase 400V 50Hz
3 phase 400V 50Hz
Outdoor unit
3. Guaranteed voltage
342~457V, 50Hz
Model name Indoor unit PEA-RP200GA PEA-RP250GA
Outdoor unit PUHZ-RP200YKA PUHZ-RP250YKA
Cooling Capacity Btu/h 65,000 75,000
kW 19.0(9.0-22.4) 22.0(11.2-28.0)
Total input kW 6.70 8.34
EER
Energy label class 2.84 2.64
--
SHF 0.81 0.86
Heating Capacity Btu/h 76,400 92,000
kW 22.4(9.5-25.0) 27.0(12.5-31.5)
Total input kW 6.50 8.20
COP 3.45 3.29
Energy label class - -
Booster heater kW - -
Power supply Phase :3
Cycle Hz 50
Voltage V 400
Breaker size A Indoor 15 / Outdoor 32
Indoor unit Air flow CMM 52-65 64-80
(Low-High) CFM 1835-2295 2260-2825
External pressure Pa 150
Sound level dB(A) 48-51 49-52
(Low-High)
External finish Galvanized steel
Dimension W : mm 16001400
D : mm 634
H : mm 400
W : inch 6355-1/8
D : inch 25
H : inch 15-3/4
Weight kg 70 77
lbs 155 170
Unit drain pipe R1
Outdoor unit Air flow CMM 140
CFM 4,940
Sound level at cooling dB(A) 58
Sound level at heating dB(A) 59
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 1,050
D : mm 330+30
H : mm 1,338
W : inch 41-5/16
D : inch 13 + 1-3/16
H : inch 52-11/16
Weight kg 135
lbs 297 141 311
Refrigerant pipe size Gas side O.D. mm 25.4
inch 1
Liquid side O.D. mm 12.7
inch 1/2
9.52
3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 100

14
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27(80°F) W.B. 19(66°F) Outdoor : D.B. 35(95°F) W.B. 24(75°F)
Heating Indoor: D.B. 20(68°F) Outdoor : D.B. 7(45°F) W.B. 6(43°F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35°C, W.B. 22.5°C D.B. 46°C
Lower limit D.B. 19°C, W.B. 15°C D.B. -5°C +1
Heating Upper limit D.B. 28°C D.B. 21°C, W.B. 15°C
Lower limit D.B. 17°C
D.B. -20°C, W.B. -20°C
4. Above data are based on the indicated voltage.
+1. If optional air protect guide is installed : D.B.-15
Indoor unit 3 phase 400V 50Hz
3 phase 400V 50Hz
Outdoor unit
3. Guaranteed voltage
342~457V, 50Hz
Model name Indoor unit PEA-RP400GA PEA-RP500GA
Outdoor unit PUHZ-RP200YKA%2 PUHZ-RP250YKA%2
Cooling Capacity Btu/h 130,000 150,000
kW 38.0(18.0-44.8) 44.0(22.4-56.0)
Total input kW 12.95 17.16
EER 2.93 2.56
Energy label class - -
Energy label class - -
SHF 0.75 0.77
Heating Capacity Btu/h 153,000 184,000
kW 44.8(18.0-50.0) 54.0(25.0-63.0)
Total input kW 12.55 16.88
COP 3.57 3.20
Booster heater kW - -
Power supply Phase :3
Cycle Hz 50
Voltage V 400
Breaker size A Indoor 15 / Outdoor 32 %2
Indoor unit Air flow CMM 120 160
(High) CFM 4240 5650
External pressure Pa 150
Sound level dB(A) 52 53
(High)
External finish Galvanized steel
Dimension W : mm 1,947
D : mm 764
H : mm 595
W : inch 79-11/16
D : inch 30-1/8
H : inch 23-7/16
Weight kg 130 133
lbs 286 293
Unit drain pipe R1
Outdoor unit
(Per 1 outdoor unit) Air flow CMM
CFM
Sound level at cooling dB(A)
Sound level at heating dB(A)
External finish
Dimension W : mm
D : mm
H : mm
W : inch
D : inch
H : inch
Weight kg
lbs
Refrigerant pipe size Gas side O.D. mm 25.4 %2
inch 1 %2
Liquid side O.D. mm 12.7 %2
inch 1/2 %2
9.52 %2
3/8 %2
Refrigerant pipe length Height difference m Max. 30
Length m Max. 100 (per 1 outdoor unit)
140
4,940
58
59
Ivory Munsell 3Y 7.8/1.1
1,050
330+30
1,338
41-5/16
13 + 1-3/16
52-11/16
135
297 141 311

15
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27(80°F) W.B. 19(66°F) Outdoor : D.B. 35(95°F) W.B. 24(75°F)
Heating Indoor: D.B. 20(68°F) Outdoor : D.B. 7(45°F) W.B. 6(43°F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35°C, W.B. 22.5°C D.B. 46°C
Lower limit D.B. 19°C, W.B. 15°C D.B. -5°C +
Heating Upper limit D.B. 28°C D.B. 21°C, W.B. 15°C
Lower limit D.B. 17°C D.B. -11°C, W.B. -12°C
4. Above data are based on the indicated voltage.
+If optional air protect guide installed. D.B.-15
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PKA-RP35HAL PKA-RP50HAL
Outdoor unit PUHZ-RP35VHA4 PUHZ-RP50VHA4
Cooling Capacity Btu/h 12,300 15,700
kW 3.6(1.6-4.5) 4.6(2.3-5.6)
Total input kW 0.98 1.43
EER 3.67 3.22
Energy label class A A
SHF 0.81 0.72
Heating Capacity Btu/h 14,000 17,100
kW 4.1(1.6-5.2) 5.0(2.5-7.3)
Total input kW 1.13 1.38
COP 3.63 3.62
Energy label class A A
Booster heater kW - -
Power supply Phase :1
Cycle Hz 50
Voltage V 230
Breaker size A 16
Indoor unit Air flow CMM 9-10.5-12
(Low-Middle-High) CFM 320-370-425
External pressure Pa 0
Sound level dB(A) 36-40-43
(Low-Middle-High)
External finish White Munsell 1.0Y 9.2/0.2
Dimension W : mm 898
D : mm 249
H : mm 295
W : inch 35-3/8
D : inch 9-13/16
H : inch 11-5/8
Weight kg 13
lbs 29
Field drain pipe I.D. mm 16
inch 5/8
Outdoor unit Air flow CMM 35
CFM 1,240
Sound level at cooling dB(A) 44
Sound level at heating dB(A) 46
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 800
D : mm 300+23
H : mm 600
W : inch 31-1/2
D : inch 11-13/16 + 7/8
H : inch 23-5/8
Weight kg 42
lbs 93
Refrigerant pipe size Gas side O.D. mm 12.7
inch 1/2
Liquid side O.D. mm 6.35
inch 1/4
Refrigerant pipe length Height difference m Max. 30
Length m Max. 50
2-3. WALL MOUNTED TYPE

16
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27(80°F) W.B. 19(66°F) Outdoor : D.B. 35(95°F) W.B. 24(75°F)
Heating Indoor: D.B. 20(68°F) Outdoor : D.B. 7(45°F) W.B. 6(43°F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35°C, W.B. 22.5°C D.B. 46°C
Lower limit D.B. 19°C, W.B. 15°C D.B. -5°C +
Heating Upper limit D.B. 28°C D.B. 21°C, W.B. 15°C
Lower limit D.B. 17°C D.B. -20°C, W.B. -20°C
4. Above data are based on the indicated voltage.
+If optional air protect guide installed. D.B.-15
Indoor unit Single phase 230V 50Hz
V: Single phase 230V 50Hz
Y: 3phase 400V 50Hz
Outdoorunit
3. Guaranteed voltage
198~264V, 50Hz (RP100Y: 342~457V, 50Hz)
Model name Indoor unit PKA-RP71KAL PKA-RP100KAL PKA-RP100KAL
Outdoor unit PUHZ-RP71VHA4 PUHZ-RP100VKA PUHZ-RP100YKA
Cooling Capacity Btu/h 24,200 34,100 34,100
kW 7.1(3.3-8.1) 10.0(4.9-11.4) 10.0(4.9-11.4)
Total input kW 1.96 2.90 2.90
EER 3.62 3.45 3.45
Energy label class A A A
SHF 0.78 0.73 0.73
Heating Capacity Btu/h 27,300 38,200 38,200
kW 8.0(3.5-10.2) 11.2(4.5-14.0) 11.2(4.5-14.0)
Total input kW 2.13 3.10 3.10
COP 3.76 3.61 3.61
Energy label class A A A
Booster heater kW - - -
Power supply Phase :1
Cycle Hz 50
Voltage V 230
Breaker size A 3225 16
Indoor unit Air flow CMM 18-20-22 20-23-26
(Low-Middle-High) CFM 635-705-780 705-810-920
3
50
400
External pressure Pa 0
Sound level dB(A) 39-42-45 41-45-49
(Low-Middle-High)
External finish Munsell 1.0Y 9.2/0.2
Dimension W : mm 1,170
D : mm 295
H : mm 365
W : inch 46-1/16
D : inch 11-5/8
H : inch 14-3/8
Weight kg 21
lbs 46
Field drain pipe I.D. mm 16
inch 5/8
Outdoor unit Air flow CMM 60
CFM 2,120
Sound level at cooling dB(A) 47
Sound level at heating dB(A) 48
110
3,880
49
51
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950
D : mm 330+30 1,050
H : mm 943 1,338
W : inch 37-3/8
D : inch 41-5/16 13 + 1-3/16
H : inch 37-1/8 52-11/16
Weight kg 67 116
lbs 148 256 124 273
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30 Max. 30
Length m Max. 50 Max. 75
PKA-RP60KAL
PUHZ-RP60VHA4
20,500
6.0(2.7-6.7)
1.54
3.90
A
0.86
23,900
7.0(2.8-8.2)
1.76
3.98
A
-
25

17
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27(80°F) W.B. 19(66°F) Outdoor : D.B. 35(95°F) W.B. 24(75°F)
Heating Indoor: D.B. 20(68°F) Outdoor : D.B. 7(45°F) W.B. 6(43°F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35°C, W.B. 22.5°C D.B. 46°C
Lower limit D.B. 19°C, W.B. 15°C D.B. -5°C +1
Heating Upper limit D.B. 28°C D.B. 21°C, W.B. 15°C
Lower limit D.B. 17°C
D.B. -11°C, W.B. -12°C +2
4. Above data are based on the indicated voltage.
+1. If optional air protect guide installed. D.B.-15°C
+2. For RP60/71 D.B. -20°C, W.B. -20°C
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PCA-RP60KA PCA-RP71KA
Outdoor unit PUHZ-RP60VHA4 PUHZ-RP71VHA4
Cooling Capacity Btu/h 20,500 24,200
kW 6.0(2.7-6.7) 7.1(3.3-8.1)
Total input kW 1.50 1.96
EER 4.00 3.62
Energy label class A A
SHF 0.81 0.76
Heating Capacity Btu/h 23,900 27,300
kW 7.0(2.8-8.2) 8.0(3.5-10.2)
Total input kW 1.94 2.21
COP 3.61 3.62
Energy label class A A
Booster heater kW - -
Power supply Phase :1
Cycle Hz 50
Voltage V 230
Breaker size A 16 25
Indoor unit Air flow CMM 10-11-13-15 15-16-17-19 16-17-18-20
(Low-Medium2-Medium1-High) CFM 355-390-460-530 530-565-600-670 565-600-635-705
External pressure Pa 0
Sound level dB(A) 32-34-37-40 33-35-37-40 35-37-39-41
(Low-Medium2-Medium1-High)
External finish White Munsell 6.4Y 8.9/0.4
Dimension W : mm 1,280960
D : mm 680
H : mm 230
W : inch 50-3/837-13/16
D : inch 26-3/4
H : inch 9-1/16
Weight kg 32
lbs 71
25
55
Field drain pipe O.D. mm 26
inch 1
Outdoor unit Air flow CMM 35 60
CFM 1,240 2,120
Sound level at cooling dB(A) 44 47
Sound level at heating dB(A) 46 48
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 800 950
D : mm 330+23 330+30
H : mm 600 943
W : inch 31-1/2 37-3/8
D : inch 13 + 7/8 13 + 1-3/16
H : inch 23-5/8 37-1/8
Weight kg 42 67
lbs 93 148
Refrigerant pipe size Gas side O.D. mm 12.7 15.88
inch 1/2 5/8
Liquid side O.D. mm 6.35 9.52
inch 1/4 3/8
Refrigerant pipe length Height difference m Max. 30 Max. 30
Length m Max. 50 Max. 50
PCA-RP50KA
PUHZ-RP50VHA4
17,100
5.0(2.3-5.6)
1.56
3.21
A
0.79
18,800
5.5(2.5-6.6)
1.52
3.62
A
-
2-4. CEILING SUSPENDED TYPE

18
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27(80°F) W.B. 19(66°F) Outdoor : D.B. 35(95°F) W.B. 24(75°F)
Heating Indoor: D.B. 20(68°F) Outdoor : D.B. 7(45°F) W.B. 6(43°F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35°C, W.B. 22.5°C D.B. 46
Lower limit D.B. 19°C, W.B. 15°C D.B. -5+
Heating Upper limit D.B. 28°C D.B. 21, W.B. 15
Lower limit D.B. 17°C D.B. -20, W.B. -20
4. Above data are based on the indicated voltage.
+If optional air protect guide installed. D.B.-15
Indoor unit Single phase 230V 50Hz
Single phase 230V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz
Model name Indoor unit PCA-RP100KA PCA-RP125KA PCA-RP140KA
Outdoor unit PUHZ-RP100VKA PUHZ-RP125VKA PUHZ-RP140VKA
Cooling Capacity Btu/h 34,100 42,700 47,800
kW 10.0(4.9-11.4) 12.5(5.5-14.0) 14.0(6.2-15.3)
Total input kW 2.63 3.88 4.36
EER 3.80 3.22 3.21
Energy label class A A A
SHF 0.77 0.72 0.71
Heating Capacity Btu/h 38,200 47,800 54,600
kW 11.2(4.5-14.0) 14.0(5.0-16.0) 16.0(5.7-18.0)
Total input kW 3.02 3.88 4.43
COP 3.71 3.61 3.61
Energy label class A A A
Booster heater kW - - -
Power supply Phase :1
Cycle Hz 50
Voltage V 230
Breaker size A 32 40
Indoor unit Air flow CMM 22-24-26-28 23-25-27-29
(Low-Medium2-Medium1-High) CFM 775-850-920-990 810-885-955-1,025 24-26-29-32 850-920-1,025-1,130
External pressure Pa 0
Sound level dB(A) 37-39-41-43 39-41-43-45 41-43-45-48
(Low-Medium2-Medium1-High)
External finish White Munsell 6.4Y 8.9/0.4
Dimension W : mm 1,600
D : mm 680
H : mm 230
W : inch 63
D : inch 26-3/4
H : inch 9-1/16
Weight kg 36 38 39
lbs 79 84 86
Field drain pipe O.D. mm 26
inch 1
Outdoor unit Air flow CMM
CFM
Sound level at cooling dB(A) 49 50
Sound level at heating dB(A) 51 52
110 120
3,880 4,230
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 1,050
D : mm 330+30
H : mm 1,338
W : inch 41-5/16
D : inch 13 + 1-3/16
H : inch 52-11/16
Weight kg 116 119
lbs 256 262
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75

19
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27(80°F) W.B. 19(66°F) Outdoor : D.B. 35(95°F) W.B. 24(75°F)
Heating Indoor: D.B. 20(68°F) Outdoor : D.B. 7(45°F) W.B. 6(43°F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35°C, W.B. 22.5°C D.B. 46°C
Lower limit D.B. 19°C, W.B. 15°C D.B. -5°C +
Heating Upper limit D.B. 28°C D.B. 21°C, W.B. 15°C
Lower limit D.B. 17°C D.B. -20°C, W.B. -20°C
4. Above data are based on the indicated voltage.
Indoor unit Single phase 230V 50Hz
3 phase 400V 50Hz
Outdoor unit
Indoor unit 198~264V, 50Hz
342~457V, 50Hz
Outdoor unit
3. Guaranteed voltage
+If optional air protect guide installed. D.B.-15
Model name Indoor unit PCA-RP100KA PCA-RP125KA PCA-RP140KA
Outdoor unit PUHZ-RP100YKA PUHZ-RP125YKA PUHZ-RP140YKA
Cooling Capacity Btu/h
kW
Total input kW
EER
Energy label class
SHF
Heating Capacity Btu/h
kW
Total input kW
COP
Energy label class
Booster heater kW
Power supply Phase :3
Cycle Hz 50
Voltage V 400
16
Breaker size A
Indoor unit Air flow CMM
(Low-Medium2-Medium1-High) CFM
External pressure Pa
Sound level dB(A)
(Low-Medium2-Medium1-High)
External finish
Dimension W : mm
D : mm
H : mm
W : inch
D : inch
H : inch
Weight kg
lbs
Field drain pipe O.D. mm
inch
Outdoor unit Air flow CMM
CFM
Sound level at cooling dB(A)
Sound level at heating dB(A)
External finish
Dimension W : mm
D : mm
H : mm
W : inch
D : inch
H : inch
Weight kg 124 132
lbs 273 126 278 291
Refrigerant pipe size Gas side O.D. mm 15.88
inch 5/8
Liquid side O.D. mm 9.52
inch 3/8
Refrigerant pipe length Height difference m Max. 30
Length m Max. 75
34,100 42,700 47,800
10.0(4.9-11.4) 12.5(5.5-14.0) 14.0(6.2-15.3)
2.63 3.88 4.36
3.80 3.22 3.21
AAA
0.77 0.72 0.71
38,200 47,800 54,600
11.2(4.5-14.0) 14.0(5.0-16.0) 16.0(5.7-18.0)
3.02 3.88 4.43
3.71 3.61 3.61
AAA
---
22-24-26-28 23-25-27-29
775-850-920-990 810-885-955-1,025 24-26-29-32 850-920-1,025-1,130
0
37-39-41-43 39-41-43-45 41-43-45-48
White Munsell 6.4Y 8.9/0.4
1,600
680
230
63
26-3/4
9-1/16
36 38 39
79 84 86
26
1
49 50
51 52
110 120
3,880 4,230
Ivory Munsell 3Y 7.8/1.1
1,050
330+30
1,338
41-5/16
13 + 1-3/16
52-11/16

20
Model name Indoor unit PCA-RP71HA PCA-RP125HA PCA-RP125HA
Outdoor unit PUHZ-RP71VHA4 PUHZ-RP125VKA PUHZ-RP125YKA
Cooling Capacity Btu/h 24,200 42,700 42,700
kW 7.1(3.3-8.1) 12.5(5.5-14.0) 12.5(5.5-14.0)
Total input kW 2.21 3.88 3.88
EER 3.21 3.22 3.22
Energy label class A A A
SHF 0.74 0.77 0.77
Heating Capacity Btu/h 25,900 47,100 47,100
kW 7.6(3.5-10.2) 13.8(5.0-16.0) 13.8(5.0-16.0)
Total input kW 2.23 4.05 4.05
COP 3.41 3.41 3.41
Energy label class B B B
Booster heater kW - - -
Power supply Phase :13
Cycle Hz 50 50
Voltage V 230 400
Breaker size A 25 16
Indoor unit Air flow CMM 17-19 30-38
(Low-High) CFM 600-670 1,060-1,350
External pressure Pa 0
Sound level dB(A) 34-38 44-50
(Low-High)
External finish Stainless steel
Dimension W : mm 1136 1520
D : mm 650
H : mm 280
W : inch 44-3/4 59-7/8
D : inch 25-5/8
H : inch 11
Weight kg 41 56
lbs 90 124
Field drain pipe O.D. mm 26
inch 1
Outdoor unit Air flow CMM 60 120
CFM 2,120 4,230
Sound level at cooling dB(A) 47 50
Sound level at heating dB(A) 48 52
External finish Ivory Munsell 3Y 7.8/1.1
Dimension W : mm 950 1,050
D : mm 330+30 330+30
H : mm 943 1,338
W : inch 37-3/8 41-5/16
D : inch 13 + 1-3/16 13 + 1-3/16
H : inch 37-1/8 52-11/16
Weight kg 67 116 126
lbs 148 256 278
Refrigerant pipe size Gas side O.D. mm 15.88 15.88
inch 5/8 5/8
Liquid side O.D. mm 9.52 9.52
inch 3/8 3/8
Refrigerant pipe length Height difference m Max. 30 Max. 30
Length m Max. 50 Max. 75
NOTE: 1. Rating conditions (ISO T1)
Cooling Indoor : D.B. 27(80°F) W.B. 19(66°F) Outdoor : D.B. 35(95°F) W.B. 24(75°F)
Heating Indoor: D.B. 20(68°F) Outdoor : D.B. 7(45°F) W.B. 6(43°F)
Refrigerant piping length (one way) : 5m (16ft.)
2. Guaranteed operating range
Indoor Outdoor
Cooling Upper limit D.B. 35°C, W.B. 22.5°C D.B. 46°C
Lower limit D.B. 19°C, W.B. 15°C D.B. -5°C +
Heating Upper limit D.B. 28°C D.B. 21°C, W.B. 15°C
Lower limit D.B. 17°C D.B. -20°C, W.B. -20°C
4. Above data are based on the indicated voltage.
+If optional air protect guide installed. D.B.-15
Indoor unit Single phase 230V 50Hz
V: Single phase 230V 50Hz
,
Y: 3 phase 400V 50Hz
Outdoor unit
3. Guaranteed voltage
198~264V, 50Hz (RP125Y : 342~457V, 50Hz)
