Mitsubishi Electric MAC-588IF-E User manual

Wi-Fi INTERFACE
MODEL
MAC-568IF-E
MAC-588IF-E
INSTALLATION GUIDE
Intelligent control, no matter where you are.

2
Setting Information
Indoor unit model name
Indoor unit serial number
Outdoor unit model name
Outdoor unit serial number
Wi-Fi interface MAC address (MAC)
Wi-Fi interface serial number (ID)
Wi-Fi interface PIN (PIN) <MAC-568IF-E only>
Wi-Fi interface SSID (SSID)
Wi-Fi interface KEY (KEY)
System commissioning date
Wi-Fi interface installation date
Installer Contact Details
Name
Telephone Number
Wi-Fi interface Minimum Requirements for Operation:
• Router capable of WPA2-PSK(AES) encryption. 2.4GHz needs to be enabled
on dual band Routers. The wireless network coverage must include the heat
pump installation location.
• A PC or Smartphone/Tablet that is iOS/Android compatible.
• A compatible Mitsubishi Electric indoor unit with a Wi-Fi interface.

3
Contents
About Wi-Fi Interface
This Wi-Fi interface communicates the status information and controls the
commands from the server by connecting to an indoor unit.
Safety Precautions
• Read all safety instructions before installation, setting up, or use of the Wi-Fi
interface.
• This installation manual contains important safety information. Be sure to
comply with the instructions.
• After installing the Wi-Fi interface, provide this installation manual for the user.
Instruct users to store it with their indoor unit instruction manual in a safe
location.
[Precautions for installation]
Warning
(Improper handling may have serious consequences, including serious injury or death.)
• Do not install the Wi-Fi interface by
yourself (user).
Improper installation may result in fire, electric
shock, injury due to fall of the Wi-Fi interface,
or water leaks. Consult the dealer from
whom you purchased the Wi-Fi interface or
professional installer.
• The Wi-Fi interface should be securely
installed in accordance with this
installation manual.
Improper installation may result in fire, electric
shock, or damage, or the Wi-Fi interface
falling.
• The Wi-Fi interface should be mounted in a
location that can support its weight.
If the Wi-Fi interface is installed in a location
that cannot support its weight, the Wi-Fi
interface could fall and cause damage.
• Connect and fasten the electric wires
securely so external force on the wires will
not apply on the terminals.
Improper connection and mounting may
result in breakdown, heat generation, smoke
generation, or fire.
• Mitsubishi Electric’s components or other
designated components must be used for
installation.
Improper component may result in fire,
electric shock, or damage/water leaks.
• Electric work must be performed by
authorized personnel in accordance with
the local regulations and the instructions
detailed in the installation manual.
Inadequate circuit capacity or improper
installation may result in electric shock or fire.
• Do not connect the Wi-Fi interface to earth
inside the indoor unit.
Safety Precautions
Wi-Fi interface introduction
Parts
Connecting the Wi-Fi Interface
Wi-Fi Interface: Setting Up Instructions
LED Pattern
Troubleshooting
Specifications
3
7
9
9
11
15
16
18

4
Warning
(Improper handling may have serious consequences, including serious injury or death.)
• Attach the electrical cover to the indoor
unit securely.
If the electrical cover of the indoor units is not
attached securely, it could result in a fire or an
electric shock due to dust, water, etc.
• When installing the Wi-Fi interface, use
appropriate protective equipment and
tools for safety.
Failure to do so could cause injury.
• Turn off the breaker or unplug the power
supply plug of the indoor unit when
connecting the Wi-Fi interface.
Failure to do so could cause electric shock.
• Make sure to connect the connecter of
the Wi-Fi interface to the P.C. board of the
indoor unit properly.
Incomplete connecting or mounting may
result in broken wire, heat generation, smoke
generation, or fire.
• Do not install the Wi-Fi interface nearby
the automatic control devices such as
automatic doors or fire alarms.
It can cause accidents due to malfunctions.
• Do not disassemble, modify, or repair by
yourself.
It can cause electric shock, fire, or injury.
• Do not use the Wi-Fi interface near medical
electrical equipment or people who
have a medical device such as a cardiac
pacemaker or an implantable cardioverter-
defibrillator.
It can cause an accident due to malfunctions
of the medical equipment or device.
• This equipment should be installed and
operated with a minimum distance of 20
cm between the device and the user or
bystanders.
• This device complies with all Australia and
New zealand regulrements for EMC and
electrical safety.
Caution
(Improper handling may have consequences, including injury or damage to building.)
• To prevent damage from static electricity,
touch a nearby metal body to discharge
static electricity from yourself before
touching the Wi-Fi interface.
Static electricity from the human body may
damage the Wi-Fi interface unit.
• Do not install the Wi-Fi interface in a place
which produces steam, such as bathrooms
and kitchens.
Avoid places where water is splashed or
where condensation forms on walls. Installing
in such places can cause electric shock or
breakdown.
• Do not install the Wi-Fi interface in places
with direct sunlight or where the ambient
temperature is 40°C or more or is 0°C or
less.
Direct sunlight and high or low temperature
environments may cause the Wi-Fi interface
to deform or breakdown.
• Do not use in special environments.
Use in places with oil (including machine oil),
steam, or sulfuric gas may lead to severe
decrease in functionality and damage to parts.
• Turn off power supply of connected
equipment when performing construction
or wiring work.
Failure to turn off the power supply to
the connected equipment may lead to
malfunction or breakdown of the Wi-Fi
interface or connected equipment.
• The connecting cable must not touch
piping directly.
• Do not use the Wi-Fi interface near other
wireless devices, microwaves, cordless
phones, or facsimiles.
It can cause malfunctions.
• Do not mount the Wi-Fi interface where
children can reach.
It can cause injury.

5
[Precautions for setting up, or use of the Wi-Fi interface]
Warning
(Improper handling may have serious consequences, including serious injury or death.)
Be sure not to do. Never touch with wet hand.
• Do not disassemble, modify, or repair by
yourself (user).
It can cause electric shock, fire, or injury.
• This appliance is not intended for use by
persons (including children) with reduced
physical, sensory or mental capabilities,
or lack of experience and knowledge,
unless they have been given supervision
or instruction concerning use of the
appliance by a person responsible for
their safety.
• Children should be supervised to ensure
that they do not play with the appliances.
• This appliance can be used by children
aged from 8 years and above and persons
with reduced physical, sensory or mental
capabilities or lack of experience and
knowledge if they have been given
supervision or instruction concerning
use of the appliance in a safe way and
understand the hazards involved.
• Children shall not play with the appliance.
Cleaning and user maintenance shall not
be done by children without supervision.
• Do not use the Wi-Fi interface near
electrical medical equipment or people
who have a medical device such as a
cardiac pacemaker or an implantable
cardioverter-defibrillator.
It can cause an accident due to malfunctions
of the medical equipment or device.
• Do not install the Wi-Fi interface near
automatic control devices such as
automatic doors or fire alarms.
It can cause accidents due to malfunctions.
• Do not touch the Wi-Fi interface with wet
hands.
It can cause damage to the device, electric
shock, or fire.
Never splash water on the unit.
• Do not splash water on the Wi-Fi interface or
use it in a bathroom.
It can cause damage to the device, electric
shock, or fire.
Be sure to follow all the instructions.
• Do not install the Wi-Fi interface by yourself
(user).
Improper installation may result in fire, electric
shock, or injury due to the Wi-Fi interface
falling. Consult the dealer from whom you
purchased the Wi-Fi interface or professional
installer.
Be sure to disconnect the power
supply plug from the power outlet.
• When the Wi-Fi interface is dropped, or the
holder or cable is damaged, disconnect the
power supply plug or turn the breaker OFF.
It may cause fire or electric shock. In this case,
consult your dealer.
• In case of an abnormal condition (such as
a burning smell), stop the indoor unit and
disconnect the power supply plug or turn
the breaker OFF.
A continued operation in the abnormal state
may cause a malfunction, fire, or electric
shock. In this case, consult your dealer.

6
[Precautions for installation, setting up, or use of the Wi-Fi interface]
Caution
(Improper handling may have consequences, including injury or damage to building.)
Be sure not to do.
• Do not mount the Wi-Fi interface where
children can reach.
It can cause injury.
• Do not step on unstable step stool to set
up or clean the Wi-Fi interface.
It may cause injury if you fall down.
• Do not use the Wi-Fi interface near other
wireless devices, microwaves, cordless
phones, or facsimiles.
It can cause malfunctions.
Note
• Please ensure that the Router supports the
WPA2-PSK(AES) encryption setting before
installation for this Wi-Fi interface begins.
• The end user should read and accept the
terms and conditions of the Wi-Fi service
before installation of this Wi-Fi interface
begins.
• The Router may be required to complete
connection of this Wi-Fi interface to the Wi-Fi
service.
• This Wi-Fi interface should not be installed
and connected to any Mitsubishi Electric
System which is to provide application critical
cooling or heating.
• Please write down the model information and
more on the first page "Setting Information",
when you install this Wi-Fi interface.
• Before transferring or disposing of the Wi-Fi
interface, it has to be reset to the factory
default.
• Dismantling the indoor unit
Please refer to the indoor units “service
manual” for detailed instructions for accessing
the control adaptor connector CN105 on the
indoor unit control PCB.
Mitsubishi Electric’s Wi-Fi interface is designed for communication to Mitsubishi Electric’s
Wi-Fi service. Third party Wi-Fi interfaces cannot connect to Mitsubishi Electric’s Wi-Fi
service. Mitsubishi Electric is not responsible for any (i) underperformance of a system or
any product; (ii) system or product fault; or (iii) loss or damage to any system or product;
which is caused by or arises from connection to and/or use of any third party Wi-Fi
interface or any third party Wi-Fi service with Mitsubishi Electric equipment.
For the latest information regarding Wi-Fi Control:
New Zealand based enquiries please visit: www.mitsubishi-electric.co.nz/wifi
Australian based enquiries please visit: www.mitsubishielectric.com.au/wifi

7
This Wi-Fi interface, communicates the status information and controls the
commands from the server by connecting to the indoor unit.
No Item Description
1MODE Button Selects modes.
2RESET Button
Resets the system and ALL settings.
3ERR LED (Orange) Shows the network error state.
4NET LED (Green) Shows the network state.
5
MODE LED (Orange)
Shows the Access Point Mode state.
6UNIT LED (Green) Shows the indoor unit state.
(1) MODE Button
WPS-Push mode <For a router with a WPS button>
[To enter the mode]
Hold down the MODE Button for 2 seconds.
[LED indication]
When WPS-Push is enabled on the Wi-Fi interface, the MODE LED starts flashing
orange (every second).
[To cancel the mode]
Hold down the RESET Button for 2 seconds to return to the initial state.
Access Point mode <For a router without a WPS button and to set up with a
smart phone>
[To enter the mode]
Hold down the MODE Button for 7 seconds.
[LED indication]
When Access Point mode is enabled on the Wi-Fi interface, the MODE LED
starts flashing orange (every 5 seconds).
[To cancel the mode]
Hold down the MODE Button for 7 seconds again and ensure that the MODE
LED is no longer flashing.
In any mode, the NET LED will ash when the Wi-Fi interface is connected to the
Router.
Wi-Fi interface introduction
RESET
ERR
NET
MODE
UNIT
MODE
3
4
5
6
21
MAC-568IF-E MAC-588IF-E
ERR
NET
MODE
UNIT
RESET MODE
Wi-Fi INTERFACE
MODEL
XXXXXXXX
MAC
ID
SSID
KEY
:XXXXXXXXXXXX
:XXXXXXXXXX
:XXXXXXXXXXXX
:XXXXXXXXXXXX
VOLTAGE
CURRENT
:
:
MITSUBISHI ELECTRIC CORPORATION
WiFi.ASSYDWG No.
XXXXXXXXXXX
MADE IN CHINA
XXXXXXXXXX
>PP<
3
4
5
6
21

8
(2) RESET Button
• Hold down the RESET Button for 2 seconds to reboot the system.
• Hold down the RESET Button for 14 seconds to initialise the Wi-Fi interface
to the factory default.
Note: When the Wi-Fi interface is reset to the factory default, ALL the
configuration information will be lost. Take great care in implementing this
operation.
WPS-PIN mode <MAC-568IF-E only>
[To enter the mode]
Hold down the MODE Button for 14 seconds.
[LED indication]
When WPS-PIN is enabled on the Wi-Fi interface, the MODE LED starts flashing
orange (every 0.5 seconds).
[To cancel the mode]
Hold down the RESET Button for 2 seconds to return to the initial state.

9
Before dismantling the indoor unit, turn the power off and make sure that the
power has been disconnected from the complete system.
Dismantle the indoor unit in accordance with the service manual to access the
main control PCB.
Locate the CN105 port on the main control PCB and connect the Wi-Fi interface.
When mounting the interface unit inside an indoor unit, refer to the
installation manual of the indoor unit. Do not mount the interface
unit inside the indoor unit, unless mentioned in the manual.
Connecting the Wi-Fi Interface
(For details about your heat pump, see the relevant installation manual)
Parts
Interface unit
(with connecting
cable)
Holder
Fixing screw
for
3.5×16 mm
Clip
Fixing screw
for
4×16 mm
Mounting cord
clamp
Fastener
(for bundling
the wires)

10
Insert the clip into the holder until it clicks
into place.
Slip the clip over the edge of corner box to fix
the interface unit .
Note: Mount the interface unit on the
underside of the indoor unit if it cannot be
mounted on the side of the indoor unit.
Insert the interface unit into the holder until
it clicks into place.
Note: When inserting the interface unit into
the holder, align the cable of the interface unit
with the mark for the cable on the holder .
1
3
2
4
2
Clip
Holder
Interface unit
Mark for cable
Align
Holder
Connecting cable
Interface
unit
Corner box
Clip
1
Indoor unit
Indoor unit
Corner box
Corner box
Underside of the
indoor unit Side of the
indoor unit
Example of mounting on the left side of the indoor unit
Otherwise, light leakage or degradation in
appearance may result.
Note: Interface unit can also be mounted on
the right side of the indoor unit.
To check the LED indication after setup, remove
the interface unit from the holder .
Run the connecting cable in the space on the
back of the unit as shown in the above image.
Tuck cabling away and secure it.
Note: Make sure that the connecting cable will
not get caught on or between the installation
plate and the wall, or between the indoor unit
and the installation plate. Failure to do so may
cause damage to the connecting cable resulting
in communication problems.
Make sure that the connecting cable will not
come out from the indoor unit.

ERR
NET
MODE
UNIT
RESET MODE
ERR
NET
MODE
UNIT
RESET MODE
11
The following steps explain how to connect the Wi-Fi interface to a Router.
: ON : Flashing
: OFF
KEY (LED LIGHTS):
1
3
2
4
Ensure the Wi-Fi interface is
connected correctly as per the
previous section, ‘Connecting the Wi-
Fi interface’.
UNIT LED should be flashing green
only.
Activate Access Point Mode on your
Wi-Fi interface by using a small object
to press and hold the MODE Button
for 7 seconds.
Download and install Wi-Fi Control App to your compatible Apple or
Android smartphone/tablet (search term: Mitsubishi Wi-Fi Control).
When Access Point Mode is enabled
on the Wi-Fi interface, MODE LED
starts flashing orange (every 5
seconds).
Complete the setting up in the Access
Point Mode with in 10 minutes.
Information for users
Option 1 - Access Point Mode Pairing
THERE ARE TWO OPTIONS OF CONNECTING
Wi-Fi Interface: Setting Up Instructions

12
5
7
6
For MAC-588IF-E, Scan the matrix
barcode from the label on the back
of the interface to connect to its
network. If you can't connect this Wi-Fi
interface, check the label on the back
of the interface for the SSID.
For MAC-568IF-E, Check the label on
the back of the interface for the SSID.
Open the Wi-Fi networks screen on
your smartphone/tablet and connect
to the network with the same name
as the SSID. The network password,
labelled KEY, is just under the SSID on
the interface.
You will now be connected to this Wi-
Fi interface.
Once completed, the MAC and ID will
be filled in ‘Add new unit’. Select ‘Add’
and then control your heat pump via
Wi-Fi.
Open Wi-Fi Control App and follow
the ‘How to Setup’ instructions in the
‘Setup Wi-Fi interface’ section.
If the app does not go to this section,
you are not connected to the Wi-Fi
interface’s Access Point; please start
process again.
You can either select your available
Wi-Fi Network, or manually configure a
Wi-Fi Network.

ERR
NET
MODE
UNIT
RESET MODE
13
Option 2 - WPS-Push Pairing
• Please Note: The WPS and Router reset buttons may be similar on some
Routers.
• Please exercise caution as resetting your Router will erase network
configuration.
3
5
7
4
6
8
Check Wi-Fi and WPS are enabled
on your Router. The connection
procedure varies depending on your
Router – refer to your Router’s manual
for more information.
Activate WPS on your Wi-Fi interface
by using a small object to press and
hold the MODE Button for 2 seconds.
When pairing process is completed on
the Wi-Fi interface, the NET LED lights
up solid green for 5 seconds.
Activate WPS Mode on your Router.
This will be enabled for a set period
allowing approximately 2 minutes
to complete the next step. To do so,
please refer to your Router’s manual.
When WPS-Push is enabled on the Wi-
Fi interface, MODE LED starts flashing
orange (every second).
If ERR LED lights up orange for 5
seconds at any stage, there may be a
problem; please start process again.
ERR
NET
MODE
UNIT
RESET MODE
ERR
NET
MODE
UNIT
RESET MODE

14
9 10
Open Wi-Fi Control App. Enter MAC
and ID into ‘Add new unit’ and select
‘Add’.
Once completed, control your heat
pump via Wi-Fi.

15
LED Pattern
: ON : Flashing: OFF
● Software initialising
Description ERR
(Orange)
NET
(Green)
MODE
(Orange)
UNIT
(Green)
Firmware updating
Firmware downloading
(every second) (every second)
Reset to the factory default
● Wireless setting
Description ERR
(Orange)
NET
(Green)
MODE
(Orange)
UNIT
(Green)
Access Point Mode acti-
vated
(every 5 sec) (every 5 sec)
WPS-Push Mode activated
(every second)
WPS-PIN mode activated
<MAC-568IF-E only>
(every 0.5 sec)
Pairing process via WPS
completed (5 sec)
Pairing process via WPS
failed (5 sec)
● Connection to server in progress
Description ERR
(Orange)
NET
(Green)
MODE
(Orange)
UNIT
(Green)
Communicating with server,
and starting up indoor unit
communication (*1)
Communicating with server,
and communicating with
indoor unit (*1)
(every 5 sec)
● Normal operation
Description ERR
(Orange)
NET
(Green)
MODE
(Orange)
UNIT
(Green)
Communicating with server, and
communicating with indoor unit (every 5 sec) (every 5 sec)
(*1) Details of flash pattern
• Every 0.5 sec: Searching for server.
• Every second: Registering the information of the Wi-Fi interface to server.
• Every 5 sec: Communicating with server.

16
Troubleshooting
: ON : Flashing: OFF
Description ERR
(Orange)
NET
(Green)
MODE
(Orange)
UNIT
(Green)
Connection to server established,
and connection to indoor unit
failed
Connection to Router failed,
and connection to indoor unit
established
Connection to Router failed,
and starting up indoor unit
connection
Connection to Router failed, and
connection to indoor unit failed
Connection to server failed,
and connection to indoor unit
established
(*2)
Connection to server failed, and
starting up indoor unit connection
(*2)
Connection to server failed, and
connection to indoor unit failed
(*2)
Check the following first in the cases listed in the above table.
• Make sure that the communication distance is not too far between the Wi-Fi
interface and the Router.
• Make sure 2.4GHz is enabled on dual band Routers.
• Make sure that WPS is working on the Router.
• Make sure that the Router is compatible with the Wi-Fi interface.
• If Static IP has been set - make sure it is correct as per Router network settings.
• Make sure that the Router uses WPA2-PSK(AES) encryption.
• Make sure that the number of connected devices to the Router does not
exceed the limit.

17
(*2) Details of flash pattern
• Every 0.5 sec:
IP address setting is invalid.
Make sure that DHCP is enabled, or check IP address settings of the Wi-Fi
interface.
If there are no problems on the items above, but the lamp is still flashing,
push RESET Button for more than 14 seconds to retry the pairing.
• Every second:
DNS setting is invalid.
FIX DNS setting of the Router, DNS address setting of the Wi-Fi interface,
or import the ratio wave environment.
If there are no problems on the items above, but the lamp is still flashing,
push RESET Button for more than 14 seconds to retry the pairing.
• Once every 5 sec:
Not communicating with server properly.
Push RESET Button for 2 seconds.
• Twice every 5 sec:
Not connected to server.
Check if the Router is connected to the Internet.
• Three times every 5 sec:
Not communicating with server. (Quick communication error)
Push RESET Button for 2 seconds.
The Wi-Fi Interface uses Open Source Software. To view the Open Source
software licence(s), please go to the following website whilst connected
to the Wi-Fi Interface during the Access Point mode. http://192.168.11.1/
license
[About trademarks]
• WPS is the connection via Wi-Fi Protected Setup.
• “Wi-Fi®”, “Wi-Fi Protected Setup™”, “WPA2™” are trademarks or registered
trademarks of the Wi-Fi Alliance.

18
Note: • Ensure that the Router supports the WPA2-PSK(AES) encryption setting before
starting the Wi-Fi interface setup.
• The End user should read and accept the terms and conditions of the Wi-Fi service
before using this Wi-Fi interface.
• To complete connection of this Wi-Fi interface to the Wi-Fi service, the Router may
be required.
• This Wi-Fi interface will not commence transmission of any operational data from the
system until the End user registers and accepts the terms and conditions of the Wi-Fi
service.
• This Wi-Fi interface should not be installed and connected to any Mitsubishi Electric
system which is to provide application critical cooling or heating.
• Please write down the information regarding the Wi-Fi interface setting on the last
page of this manual, when you set up this Wi-Fi interface.
• At the time of relocation or disposal, reset the Wi-Fi interface to the factory default.
Mitsubishi Electric’s Wi-Fi interface is designed for communication to
Mitsubishi Electric’s Wi-Fi service. Third party Wi-Fi interfaces cannot connect
to Mitsubishi Electric’s Wi-Fi service. Mitsubishi Electric is not responsible for
any (i) underperformance of a system or any product; (ii) system or product
fault; or (iii) loss or damage to any system or product; which is caused by or
arises from connection to and/or use of any third party Wi-Fi interface or any
third party Wi-Fi service with Mitsubishi Electric equipment.
For the latest information regarding Wi-Fi Control:
New Zealand based enquiries please visit: www.mitsubishi-electric.co.nz/wifi
