GT15 General Description
Thank you for purchasing the GOT1000 Series.
GT1595-XTBA
GT1585-STBA
GT1575-STBA
GT1565-VTBA
GT1572-VNBA
GT1555-VTBD
GT1595-XTBD
GT1585-STBD
GT1575-STBD
GT1565-VTBD
GT1572-VNBD
GT1555-QTBD
GT1585V-STBA
GT1575V-STBA
GT1575-VTBA
GT1575-VNBA
GT1562-VNBA
GT1555-QSBD
GT1585V-STBD
GT1575V-STBD
GT1575-VTBD
GT1575-VNBD
GT1562-VNBD
GT1550-QLBD
Prior to use, please read both this manual and the
detailed manual thoroughly to fully understand the
product.
MODEL GT15-U-GD-E
Model
code 1D7MP8
IB(NA)-0800546ENG-A(1410)MEE
1
2
3
4
5
6
7
8
9
0
1
2
3
4
5
6
7
8
9
0
SAFETY PRECAUTIONS
(Always read these precautions before using this equipment.)
Before using this product, please read this manual and the relevant
manuals introduced in this manual carefully and pay full attention to
safety to handle the product correctly.
The precautions given in this manual are concerned with this prod-
uct.
In this manual, the safety precautions are ranked as "WARNING"
and "CAUTION".
Note that the CAUTION level may lead to a serious accident
according to the circumstances.
Always follow the instructions of both levels because they are impor-
tant to personal safety.
Please save this manual to make it accessible when required and
always forward it to the end user.
[DESIGN PRECAUTIONS]
Indicates that incorrect handling may cause
hazardous conditions, resulting in death or
severe injury.
Indicates that incorrect handling may cause
hazardous conditions, resulting in medium or
slight personal injury or physical damage.
Some failures of the GOT, communication unit or cable may keep the outputs
on or off.
Some failures of a touch panel may cause malfunction of the input objects
such as a touch switch.
An external monitoring circuit should be provided to check for output signals
which may lead to a serious accident.
Not doing so can cause an accident due to false output or malfunction.
If a communication fault (including cable disconnection) occurs during
monitoring on the GOT, communication between the GOT and PLC CPU is
suspended and the GOT becomes inoperative.
For bus connection : The CPU becomes faulty and the GOT becomes
inoperative.
For other than bus connection : The GOT becomes inoperative.
A system where the GOT is used should be configured to perform any
significant operation to the system by using the switches of a device other
than the GOT on the assumption that a GOT communication fault will occur.
Not doing so can cause an accident due to false output or malfunction.
Do not use the GOT as the warning device that may cause a serious
accident.
An independent and redundant hardware or mechanical interlock is required
to configure the device that displays and outputs serious warning.
Failure to observe this instruction may result in an accident due to incorrect
output or malfunction.
WARNING
CAUTION
WARNING
[DESIGN PRECAUTIONS]
[DESIGN PRECAUTIONS]
[MOUNTING PRECAUTIONS]
Incorrect operation of the touch switch(s) may lead to a serious accident if the
GOT backlight is gone out.
When the GOT backlight goes out, the POWER LED flickers (green/orange)
and the display section turns black and causes the monitor screen to appear
blank, while the input of the touch switch(s) remains active.
This may confuse an operator in thinking that the GOT is in "screensaver"
mode, who then tries to release the GOT from this mode by touching the
display section, which may cause a touch switch to operate.
Note that the following occurs on the GOT when the backlight goes out.
• The POWER LED flickers (green/orange) and the monitor screen appears
blank.
The display section of the GT1595-X is an analog-resistive type touch panel.
If you touch the display section simultaneously in 2 points or more, the switch
that is located around the center of the touched point, if any, may operate.
Do not touch the display section in 2 points or more simultaneously.
Doing so may cause an accident due to incorrect output or malfunction.
When programs or parameters of the controller (such as a PLC) that is
monitored by the GOT are changed, be sure to reset the GOT or shut off the
power of the GOT at the same time.
Not doing so can cause an accident due to false output or malfunction.
Do not bundle the control and communication cables with main-circuit, power
or other wiring.
Run the above cables separately from such wiring and keep them a minimum
of 100mm apart.
Not doing so noise can cause a malfunction.
Do not press the GOT display section with a pointed material as a pen or
driver.
Doing so can result in a damage or failure of the display section.
When the GOT is connected to the Ethernet network, the available IP
address is restricted according to the system configuration.
• When multiple GOTs are connected to the Ethernet network :
Do not set the IP address (192.168.0.18) for the GOTs and the controllers in
the network.
• When a single GOT is connected to the Ethernet network :
Do not set the IP address (192.168.0.18) for the controllers except the GOT
in the network.
Doing so can cause the IP address duplication. The duplication can
negatively affect the communication of the device with the IP address
(192.168.0.18).
The operation at the IP address duplication depends on the devices and the
system.
Turn on the controllers and the network devices to be ready for
communication before they communicate with the GOT.
Failure to do so can cause a communication error on the GOT.
Be sure to shut off all phases of the external power supply used by the
system before mounting or removing the GOT main unit to/from the panel.
Not doing so can cause the unit to fail or malfunction.
Be sure to shut off all phases of the external power supply used by the
system before mounting or removing the communication unit, printer unit,
option function board or multi-color display board onto/from the GOT.
Not doing so can cause the unit to fail or malfunction.
When installing the option function board or multi-color display board, wear
an earth band etc. to avoid the static electricity.
Not doing so can cause a unit corruption.
Use the GOT in the environment that satisfies the general specifications
described in this manual.
Not doing so can cause an electric shock, fire, malfunction or product
damage or deterioration.
When mounting the GOT to the control panel, tighten the mounting screws in
the specified torque range (0.36 to 0.48 N•m) with a Phillips-head screwdriver
No.2.
Undertightening can cause the GOT to drop, short circuit or malfunction.
Overtightening can cause a drop, short circuit or malfunction due to the
damage of the screws or the GOT.
When loading the communication unit or printer unit to the GOT, fit it to the
connection interface of the GOT and tighten the mounting screws in the
specified torque range (0.36 to 0.48 N•m) with a Phillips-head screwdriver
No.2.
Under tightening can cause the GOT to drop, short circuit or malfunction.
Overtightening can cause a drop, failure or malfunction due to the damage of
the screws or unit.
When mounting the multi-color display board onto the GOT, tighten the
mounting screws within the specified torque range (0.25 to 0.35 N•m) with a
Phillips-head screwdriver No.1.
Loose tightening may cause the unit and/or GOT to malfunction due to poor
contact.
Overtightening may damage the screws, unit and/or GOT; they might
malfunction.
Push the option function board onto the corresponding connector until it
clicks, so that it will be secured firmly.
Push the multi-color display board onto the corresponding connector so that it
will be secured firmly.
When inserting a CF card into the GOT, push it into the insertion slot until the
CF card eject button will pop out.
If not properly inserted, a bad connection may cause a malfunction.
WARNING
CAUTION
WARNING
CAUTION
[MOUNTING PRECAUTIONS]
[WIRING PRECAUTIONS]
[TEST OPERATION PRECAUTIONS]
[STARTUP/MAINTENANCE PRECAUTIONS]
When inserting/removing a CF card into/from the GOT, turn the CF card
access switch off in advance.
Failure to do so may corrupt data within the CF card.ue to poor contact.
When removing a CF card from the GOT, make sure to support the CF card
by hand, as it may pop out.
Failure to do so may cause the CF card to drop from the GOT and break.
Operate and store the GOT in environments without direct sunlight, high
temperature, dust, humidity, and vibrations.
When using the GOT in the environment of oil or chemicals, use the
protective cover for oil.
Failure to do so may cause failure or malfunction due to the oil or chemical
entering into the GOT.
Be sure to shut off all phases of the external power supply used by the
system before wiring.
Failure to do so may result in an electric shock, product damage or
malfunctions.
Always ground the FG terminal, LG terminal, and Functional ground terminal
of the GOT power to the functional ground conductors dedicated to the GOT.
Not doing so may cause an electric shock or malfunction.
When tightening the terminal screws, use a Phillips-head screwdriver No.2.
Terminal screws which are not to be used must be tightened always at torque
0.5 to 0.8 N•m.
Otherwise there will be a danger of short circuit against the solderless
terminals.
Use applicable solderless terminals and tighten them with the specified
torque.
If any solderless spade terminal is used, it may be disconnected when the
terminal screw comes loose, resulting in failure.
Correctly wire the GOT power supply section after confirming the rated
voltage and terminal arrangement of the product.
Not doing so can cause a fire or failure.
Tighten the terminal screws of the GOT power supply section in the specified
torque range (0.5 to 0.8 N•m). Undertightening can cause a short circuit or
malfunction.
Overtightening can cause a short circuit or malfunction due to the damage of
the screws or the GOT.
Exercise care to avoid foreign matter such as chips and wire offcuts entering
the GOT.
Not doing so can cause a fire, failure or malfunction.
The module has an ingress prevention label on its top to prevent foreign
matter, such as wire offcuts, from entering the module during wiring.
Do not peel this label during wiring.
Before starting system operation, be sure to peel this label because of heat
dissipation.
Plug the communication cable into the connector of the connected unit and
tighten the mounting and terminal screws in the specified torque range.
Undertightening can cause a short circuit or malfunction.
Overtightening can cause a short circuit or malfunction due to the damage of
the screws or unit.
Plug the QnA/ACPU/Motion controller (A series) bus connection cable by
inserting it into the connector of the connected unit until it "clicks".
After plugging, check that it has been inserted snugly.
Not doing so can cause a malfunction due to a contact fault.
Before performing the test operations of the user creation monitor screen
(such as turning ON or OFF bit device, changing the word device current
value, changing the settings or current values of the timer or counter, and
changing the buffer memory current value), read through the manual
carefully and make yourself familiar with the operation method.
During test operation, never change the data of the devices which are used to
perform significant operation for the system.
False output or malfunction can cause an accident.
When power is on, do not touch the terminals.
Doing so can cause an electric shock or malfunction.
Correctly connect the battery connector.
Do not perform the following actions to the battery.
• Charging, disassembling, heating, short-circuiting, or soldering the battery,
or throwing it into the fire
Doing so will cause the battery to produce heat, explode, or ignite, resulting in
injury and fire.
Before starting cleaning or terminal screw retightening, always switch off the
power externally in all phases.
Not switching the power off in all phases can cause a unit failure or
malfunction.
Undertightening can cause a short circuit or malfunction.
Overtightening can cause a short circuit or malfunction due to the damage of
the screws or unit.
CAUTION
WARNING
CAUTION
WARNING
WARNING
[STARTUP/MAINTENANCE PRECAUTIONS]
[TOUCH PANEL PRECAUTIONS]
[BACKLIGHT CHANGING PRECAUTIONS]
[DISPOSAL PRECAUTIONS]
[TRANSPORTATION PRECAUTIONS]
Do not disassemble or modify the unit.
Doing so can cause a failure, malfunction, injury or fire.
Do not touch the conductive and electronic parts of the unit directly.
Doing so can cause a unit malfunction or failure.
The cables connected to the unit must be run in ducts or clamped.
Not doing so can cause the unit or cable to be damaged due to the dangling,
motion or accidental pulling of the cables or can cause a malfunction due to a
cable connection fault.
When unplugging the cable connected to the unit, do not hold and pull the
cable portion.
Doing so can cause the unit or cable to be damaged or can cause a
malfunction due to a cable connection fault.
Do not drop the module or subject it to strong shock. A module damage may
result.
Do not drop or give an impact to the battery mounted to the unit.
Doing so may damage the battery, causing the battery fluid to leak inside the
battery.
If the battery is dropped or given an impact, dispose of it without using.
Before touching the unit, always touch grounded metals, etc. to discharge
static electricity from human body, etc.
Not doing so can cause the unit to fail or malfunction.
Replace battery with GT15-BAT by Mitsubishi electric Co. only.
Use of another battery may present a risk of fire or explosion.
Dispose of used battery promptly.
Keep away from children. Do not disassemble and do not dispose of in fire.
For the analog-resistive film type touch panels, normally the adjustment is not
required. However, the difference between a touched position and the object
position may occur as the period of use elapses.
When any difference between a touched position and the object position
occurs, execute the touch panel calibration.
When any difference between a touched position and the object position
occurs, other object may be activated. This may cause an unexpected
operation due to incorrect output or malfunction.
Before changing the backlight, always switch off the GOT power externally in
all phases (when the GOT is connected to the bus, the PLC CPU power must
also be switched off externally in all phases) and remove the GOT from the
control panel.
Not switching the power off in all phases may cause an electric shock.
Not removing the unit from the control panel can cause injury due to a drop.
When replacing the backlight, use the gloves.
Otherwise, it may cause you to be injured.
Start changing the backlight more than 5 minutes after switching the GOT
power off.
Not doing so can cause a burn due to the heat of the backlight.
When disposing of the product, handle it as industrial waste.
When disposing of the battery, dispose of it separately based on the law in
each region.
(Refer to the User's Manual for the GOT you are using for details of the
battery regulations in the EU member countries.)
When transporting lithium batteries, make sure to treat them based on the
transport regulations.
(Refer to the User's Manual for the GOT you are using for details of the
regulated models.)
Make sure to transport the GOT main unit and/or relevant unit(s) in the
manner they will not be exposed to the impact exceeding the impact
resistance described in the general specifications of the User's Manual, as
they are precision devices.
Failure to do so may cause the unit to fail.
Check if the unit operates correctly after transportation.
When fumigants that contain halogen materials such as fluorine, chlorine,
bromine, and iodine are used for disinfecting and protecting wooden
packaging from insects, they cause malfunction when entering our products.
Please take necessary precautions to ensure that remaining materials from
fumigant do not enter our products, or treat packaging with methods other
than fumigation (heat method).
Additionally, disinfect and protect wood from insects before packing products.
CAUTION
CAUTION
WARNING
CAUTION
CAUTION
CAUTION
Manual
The following shows manuals relevant to this product.
For detailed manuals, refer to the PDF manuals stored in the DVD-ROM for the
drawing software used.
For relevant manuals, refer to the Help or the PDF manuals stored in the DVD-
ROM for the drawing software used.
The latest manuals are also available from MITSUBISHI ELECTRIC FA Global
Website (http://www.MitsubishiElectric.co.jp/fa/).
© 2014MITSUBISHI ELECTRIC CORPORATION
Before using the GOT
Connect the connector of the GOT to the connector of the battery.
For details on GT15 specifications, installing procedure, EMC Directive, wiring,
maintenance and inspection, or checking method for the version and the
compatible standard, refer to GT15 User's Manual.
Packing List
The GOT product package includes the following:
1. FEATURES
(1) Improved monitoring performance and connectivity to FA devices
• Using of TFT color liquid crystal display (high intensity, wide angle view and
high definition type) provides clear full-color display and displays small
characters clearly. (Displays digital images of BMP and other formats in
65536 colors.)*1
• Provides multi-language display function based on Unicode2.1 True Type
font and high-speed drawing of beautiful text.
• High speed monitoring through high speed communication at maximum of
115.2kbps.
• High speed display and high speed touch switch response.
(2) More efficient GOT operations including screen design, startup, adjustment,
management and maintenance works
• 9MB user memory is included as standard. (Memory capacity can be
expanded up to 57MB by increasing the option memory)*1
• CF card interface is included as standard.
• Font installation is available to increase the system fonts.
• Combined use of 4 types of alarms (system alarm, user alarm, alarm
history, alarm popup display) realizes more efficient alarm notification.
• Maintenance timing report function is available that measures the backlight
energization time and notifies of maintenance time.
• The USB connector is positioned on the GOT front. This enables the system
startup to be performed more efficiently using FA device startup tool, and
eliminates the necessity of indirect works (opening and closing the control
panel, cable replacement, cable rewiring) in order to improve the working
efficiency.
• The blown backlight bulb can be confirmed even during screen saving, with
the blinked POWER LED at backlight shutoff detection.
(3) Enhanced support of FA device setup tools
• Transferring and monitoring sequence programs with the personal computer
connected to the GOT can be executed when connecting to a PLC CPU
with the direct CPU connection or bus connection. (FA transparent function)
*1: The specifications differ depending on the GOT to be used.
For the specifications, refer to the GT15 User’s Manual.
Detailed Manual
Manual name Manual number
(Model code)
GT15 User's Manual
(Sold separately)
SH-080528ENG
(1D7M23)
Relevant Manuals
Model name Product Quantity
GT1595-X
GOT 1
Installation fitting 8
GT15 General Discription 1
GT15 本体概要説明書 1
GT1585V-S
GT1585-S
GT1575V-S
GT1575-S
GT1575-V
GT1575-VN
GT1572-VN
GT1565-V
GT1562-VN
GT1555-V
GT1555-Q
GT1550-Q
GOT 1
Installation fitting 4
GT15 General Discription 1
GT15 本体概要説明書 1
2. Part Names and Settings
Part Names and Settings of the GT15
*1: For the multi-color display board, refer to the GT15 User’s Manual.
*2: GT1585V-S and GT1575V-S only
*3: The GT155 has no multi-color display board.
*4: GT1595 and GT1585 only
*5:GT1595 only
*6:GT155 only
*7:The GT155 has no LG terminal.
*8:The GT1575-VN, GT1572-VN, and GT1562-VN do not support the 65536-color
display even if the multi-color display board is mounted.
3. Specifications
3.1 General Specifications
No. Name Description
1) POWER LED
Lit in green : Power is correctly supplied , Lit in orange :
Screen saving
Blinks in orange/green : Blown back light bulb , Not lit :
Power is not supplied
2) Display screen Displays the Utility and the user creation screen
3) Touch key For operating touch switches in the Utility and the user
creation screen
4) USB interface For connecting a personal computer (Connector type: Mini-
B)
5) RS-232 interface For communicating with a controller or connecting a
personal computer(Connector type: D sub 9-pin)
6) Power terminal Power input terminal, LG terminal*7, FG terminal
7) Extension interface For installing an extension unit
8) CF card interface For installing a CF card
9) CF card access Lit : CF card accessed , Not lit : CF card not accessed
10) CF card access switch
Used for accepting or stopping the access to the CF card
before removing the CF card from the GOT
ON :CF card being accessed (CF card removal prohibited)
OFF :CF card not accessed (CF card removal possible)
11) Optional function
board For installing the optional function board
12) Multi-color display
board interface*1*3*8 For installing the multi-color display board
13) Reset switch Hardware reset switch(Inoperative in the bus connection or
with the bus connection unit installed)
14) Hole for unit
installation fitting Hole for inserting the unit installation fitting
15) Battery holderVideo Houses the battery
16) Human sensor*4 Sensor that detects human movement
17) Installation switch*5 Used for OS installations at the GOT startup
18) Video/RGB interface*2 For installing the video input unit, RGB input unit, video/
RGB input unit, or RGB output unit
19) Functional ground
terminal*6 For earthing
Item Specifications
Operating
ambient
temperature
*1
Température
ambiante de
fonctionnem
ent*1
Display
section
Zone
d'affichage
0 to 50
0 à 50
Other than
the display
section
Autre que la
zone
d'affichage
0 to 55
0 à 55
Storage ambient
temperature -20 to 60
Operating ambient
humidity*6 10 to 90% RH, non-condensing
Storage ambient
humidity*6 10 to 90% RH, non-condensing
Vibration resistance*2
Compliant
with JIS B
3502 and
IEC 61131-
2
Frequency Acceleration Half-
amplitude
Sweep
count
Under
intermittent
vibration
5 to 8.4Hz - 3.5mm 10 times
each in X,
Y and Z
directions
8.4 to150Hz 9.8m/s2-
Under
continuous
vibration
5 to 8.4Hz - 1.75mm
-
8.4
to 150Hz 4.9m/s2-
13)
GOT Rear face
11) 12)
7)
15)
17)
8)
9)
10)
2),3)
1)
4)
16)
14)
5)
6)
14)
18)
19)
Example)
GT1595
*1: When mounting MELSECNET/H communication unit (GT15-J71LP23-25,
GT15-J71BR13) or CC-Link communication unit (GT15-J61BT13), the
operating ambient temperature must be reduced 5°C against the maximum
values described in general specifications.
Lors du montage du module de communication MELSECNET/H (GT15-
J71LP23-25, GT15-J71BR13) ou du module de communication CC-Link
(GT15-J61BT13), la température ambiante de fonctionnement doit être réduite
de 5°C par rapport aux valeurs maximales décrites dans les spécifications
générales.
*2: When using the MELSECNET/10 communication unit (GT15-75J71LP23-Z,
GT15-75J71BR13-Z) or CC-Link communication unit (GT15-75J61BT13-Z),
refer to the manual of the communication unit you use. (Differs with the
specification of GOT.)
*3: Do not use or store the GOT under pressure higher than the atmospheric
pressure of altitude 0m (0ft.). Failure to observe this instruction may cause a
malfunction.
When an air purge is made inside the control panel by adding pressure, there
may be a clearance between the surface sheet and the screen making it difficult
to use the touch panel, or the sheet may come off.
*4: This indicates the section of the power supply to which the equipment is
assumed to be connected between the public electrical power distribution
network and the machinery within the premises. Category II applies to
equipment for which electrical power is supplied from fixed facilities.
The surge voltage withstand level for up to the raged voltage of 300 V is 2500 V.
*5: This index indicates the degree to which conductive material is generated in the
environment where the equipment is used.
In pollution degree 2, only non-conductive pollution occurs but temporary
conductivity may be produced due to condensation.
*6: For the STN LCD model, the wet-bulb temperature must be 39°C or less.
3.2 Power Supply Specifications
The following indicates the power supply specifications for GT15.
3.2.1 For GOTs powered from the 100 to 240VAC
power supply
Item Specifications
Shock resistance Compliant with JIS B 3502 and IEC 61131-2 147 m/s2(15G),
3 times each in X, Y and Z directions
Operating atmosphere
No greasy fumes, corrosive gas, flammable gas, excessive
conductive dust, and direct sunlight (Same as storage
atmosphere)
Operating altitude*3 2000 m (6562 ft) max.
Installation location Inside control panel
Overvoltage category*4 II or less
Pollution degree*5 2 or less
Cooling method Self-cooling
Grounding Grounding with a resistance of 100Ωor less
Point
Refer to GT15 User's Manual for details of the performance specifications of each GOT.
Note
Operation at momentary failure
• If an instantaneous power failure occurs in the power supply and continues for more
than the permissible period, the GOT will be reset.
• Make sure to power on the unit more than 5 seconds after power-off.
Item
Specifications
GT1595-XTBA GT1585V-STBA,
GT1585-STBA
GT1575V-STBA,
GT1575-STBA,
GT1575-VTBA,
GT1575-VNBA,
GT1572-VNBA,
GT1565-VTBA,
GT1562-VNBA
Input power supply voltage 100 to 240VAC (+10%, -15%)
Input frequency 50/60Hz±5%
Input max. apparent power 110VA (maximum load)
Power consumption 56W or less 41W or less 39W or less
At backlight off 30W or less 28W or less
Inrush current
50A or less
(4ms)
(maximum load)
45A or less
(4ms)
(maximum load)
40A or less (4ms)
(maximum load)
Allowable momentary power
failure time 20ms or less (100VAC or more)
Noise immunity
1,500Vp-p noise voltage, 1 s noise width (when
measuring with a noise simulator under 25 to 60Hz
noise frequency)
Dielectric withstand voltage 1500VAC for 1 minute across power terminals and earth
Insulation resistance 10M or more across power terminals and earth by a
500VDC insulation resistance tester
Applicable wire size 0.75 to 2 [mm2]
Applicable solderless terminal Solderless terminal for M3 screw RAV1.25-3, V2-S3.3,
V2-N3A, FV2-N3A
Applicable tightening torque
(Terminal block terminal screw) 0.5 to 0.8 [N•m]
3.2.2 For GOTs powered from the 24VDC power
supply
3.3 External Dimensions
Item
Specifications
GT1595-
XTBD
GT1585
V-STBD,
GT1585-
STBD
GT1575V-
STBD,
GT1575-
STBD,
GT1575-
VTBD,
GT1575-
VNBD,
GT1572-
VNBD,
GT1565-
VTBD,
GT1562-
VNBD
GT1555-
V
GT1555-
QTBD
GT1555-
QSBD
GT1550-
QLBD
Input power
supply voltage 24VDC (+25%, -20%)
Power
consumption
57W or
less
(2380mA
/24VDC)
43W or
less
(1790mA
/24VDC)
41W or
less
(1710mA
/24VDC)
19W or
less
(790mA/
24VDC)
18W or
less
(750mA/
24VDC)
17W or
less
(710mA/
24VDC)
15W or
less
(620mA
/
24VDC)
At backlight
off
32W or
less
(1330mA
/24VDC)
30W or less
(1250mA/24VDC)
14W or
less
(580mA/
24VDC)
13W or less (540mA/24VDC)
Inrush current
100A or
less
(4ms)
(maximu
m load)
115A or less (1ms)
(maximum load)
67A or
less
(1ms)
(maxi-
mum
load)
60A or less (1ms) (maximum
load)
Allowable
momentary power
failure time
10 ms or less
Noise immunity 500Vp-p noise voltage, 1 s noise width (when measuring with a noise simulator
under 25 to 60Hz noise frequency)
Dielectric
withstand voltage 500VDC for 1 minute across power terminals and earth
Insulation
resistance
10M or more across power terminals and earth by a 500V DC insulation
resistance tester
Applicable wire
size 0.75 to 2 [mm2]
Applicable
solderless
terminal
Solderess terminal for M3 screw RAV1.25-3, V2-S3.3, V2-N3A, FV2-N3A
Applicable
tightening torque
(Terminal block
terminal screw)
0.5 to 0.8 [N•m]
GT1595 GT1585
GT157 GT156
GT155
Unit : mm(inch)
10
(0.39)
281(11.1)10
(0.39)
397(15.6)
320(12.6)
296 (11.7)
320(12.6)
61
(2.4)
6
(0.24)
5
(0.20)
382(15.0)
316(12.44)
263(10.35)
250(9.84)
301(11.85)
227(8.94)
242(9.53)
Unit: mm (inch)
10
(0.39) 10
(0.39)
56
(2.20)
6
(0.24)
5
(0.20)
52
(2.05)
303 (11.93)
252 (9.92)
222 (8.74)
288 (11.34)
56
(2.20)
49
(1.93)
10
(0.39)
10
(0.39)
199 (7.83)
214 (8.43)
6
(0.24)
5
(0.20)
Unit: mm (inch)
241 (9.49)
175.5 (6.91)
175.5 (6.91)
226 (8.90)
190 (7.48)
175 (6.89)
10
(0.39)
6
(0.24)
56 (2.20)
52 (2.05)
5
(0.20)
10
(0.39)
Unit : mm(inch)
110 (4.33)
110 (4.33)
167 (6.58)
135 (5.32)
120 (4.73) 10
60 (2.36)
152 (5.99)
Unit : mm(inch)
(0.39)
10
(0.39)
6
(0.24)
5
(0.20)

4. EMC AND LOW VOLTAGE DIRECTIVE
For the products sold in European countries, the conformance to the
EMC Directive, which is one of the European Directives, has been a
legal obligation since 1996. Also, conformance to the Low Voltage.
Directive, another European Directives, has been a legal obligation since
1997.
Manufacturers who recognize their products must conform to the EMC
and Low Voltage Directive are required to declare that their products
conform to these Directives and put a "CE mark" on their products.
• Authorized representative in Europe
Authorized representative in Europe is shown below.
Name :Mitsubishi Electric Europe BV
Address :Gothaer strase 8, 40880 Ratingen, Germany
4.1 Requirements to Meet EMC Directive
EMC Directives are those which require "any strong electromagnetic
force is not output to the external.:Emission (electromagnetic
interference)" and "It is not influenced by the electromagnetic wave from
the external.: Immunity (electromagnetic sensitivity)".
Items4.1.1 through4.1.3 summarize the precautions to use GOT and
configure the mechanical unit in order to match the EMC directives.
Though the data described herein are produced with our best on the
basis of the requirement items and standards of the restrictions gathered
by Mitsubishi, they do not completely guaranteed that all mechanical unit
manufactured according to the data do not always match the above
directives. The manufacturer itself which manufactures the mechanical
unit must finally judge the method and others to match the EMC
directives.
4.1.1 EMC directive
The standards of the EMC Directive are shown below.
*1: The GOT is an open type device (device installed to another device) and must
be installed in a conductive control panel.
The above test items are conducted in the condition where the GOT is installed
on the conductive control panel and combined with the Mitsubishi PLC.
Applied
standard Test standard Test details Standard value
EN61131-2
: 2007
CISPR16-2-3
Radiated noise*1
Electromagnetic
emissions from the
product are
measured.
30M-230MHz QP:
30dB V/m (30m in
measurement range)*2, *3
230M-1000MHz QP:
37dB V/m(30m in
measurement range)*2, *3
CISPR16-2-1
Conducted noise*1
Electromagnetic
emissions from the
product to the power
line is measured.
150k-500kHz QP:79dB,
Mean: 66dB*2
500k-30MHz QP:73dB,
Mean: 60dB*2
IEC61000-4-2
Electrostatic
immunity*1
Immunity test in
which static
electricity is applied
to the cabinet of the
equipment.
4kV Contact discharge
8kV Aerial discharge
IEC61000-4-3
Radiated
electromagnetic
field AM modulation
Immunity test in
which field is
irradiated to the
product.
80-1000MHz:10V/m
1.4-2GHz:3V/m
2.0-2.7GHz:1V/m
80%AM modulation@1kHz
IEC61000-4-4
Fast transient burst
noise*1
Immunity test in
which burst noise is
applied to the power
line and signal lines.
Power line:2kV
Digital I/O(24V or higher): 1kV
(Digital I/O(24V or less))> 250V
(Analog I/O, signal lines)> 250V
IEC61000-4-5
Surge immunity*1
Immunity test in
which lightening
surge is applied to
the product.
AC power type
Power line (between line and
ground): 2kV
Power line (between lines)
: 1kV
Data communication port
: 1kV
DC power type
Power line (between line and
ground) : 0.5kV
Power line (between lines)
: 0.5kV
Data communication port
: 1kV
IEC61000-4-6
Conducted RF
immunity*1
Immunity test in
which a noise
inducted on the
power and signal
lines is applied.
Power line: 10V
Data communication port: 10V
IEC61000-4-8
Power supply
frequency magnetic
field immunity
Test for checking
normal operations
under the
circumstance
exposed to the
ferromagnetic field
noise of the power
supply frequency
(50/60Hz).
30 A/m
EN61000-4-11
EN61000-4-29
Instantaneous
power failure and
voltage dips
immunity
Test for checking
normal operations
at instantaneous
power failure.
AC power type
0.5 cycle 0% (interval 1 to 10s)
250/300 cycle 0%
10/12 cycle 40%
25/30 cycle 70%
*2: QP (Quasi-Peak): Quasi-peak value, Mean: Average value
*3: The above test items are conducted in the following conditions.
30M-230MHz QP : 40dB V/m (10m in measurement range)
230M-1000MHz QP : 47dB V/m (10m in measurement range)
4.1.2 Control panel
The GOT is an open type device (device installed to another device) and
must be installed in a conductive control panel.
It not only assure the safety but also has a large effect to shut down the
noise generated from GOT, on the control panel.
(1) Control Panel
(a) The control panel must be conductive.
(b) When fixing a top or bottom plate of the control panel with bolts,
do not coat the plate and bolt surfaces so that they will come into
contact.
And connect the door and box using a thick grounding cable in
order to ensure the low impedance under high frequency.
(c) When using an inner plate to ensure electric conductivity with the
control panel, do not coat the fixing bolt area of the inner plate
and control panel to ensure conductivity in the largest area as
possible.
(d) Ground the control panel using a thick grounding cable in order to
ensure the low impedance under high frequency.
(e)The diameter of cable holes in the control panel must be 10cm
(3.94in.). In order to reduce the chance of radio waves leaking out,
ensure that the space between the control panel and its door is
small as possible.
Paste the EMI gasket directly on the painted surface to seal the
space so that the leak of electric wave can be suppressed.
Our test has been carried out on a panel having the damping
characteristics of 37dB max. and 30dB mean (measured by 3m
method with 30 to 300MHz).
(2) Connection of power and ground wires
Ground and power supply wires for the GOT must be connected
as described below.
(a) Provide a grounding point near the GOT. Short-circuit the LG and
FG terminals of the GOT (LG: line ground, FG: frame ground)
and ground them with the thickest and shortest wire possible
(The wire length must be 30cm (11.81in.) or shorter.)
The LG and FG terminals function is to pass the noise generated
in the PC system to the ground, so an impedance that is as low
as possible must be ensured. As the wires are used to relieve the
noise, the wire itself carries a large noise content and thus short
wiring means that the wire is prevented from acting as an
antenna.
Note) A long conductor will become a more efficient antenna at
high frequency.
(b) The earth wire led from the earthing point must be twisted with
the power supply wires.
By twisting with the earthing wire, noise flowing from the power
supply wires can be relieved to the earthing. However, if a filter is
installed on the power supply wires, the wires and the earthing
wire may not need to be twisted.
4.1.3 Noise filter (power supply line filter)
The noise filter (power supply line filter) is a device effective to reduce
conducted noise. Except some models, installation of a noise filter onto
the power supply lines is not necessary. However conducted noise can
be reduced if it is installed. (The noise filter is generally effective for
reducing conducted noise in the band of 10MHz or less.) Usage of the
following filters is recommended.
The precautions required when installing a noise filter are described
below.
(1) Do not install the input and output cables of the noise filter together
to prevent the output side noise will be inducted into the input side
cable where noise has been eliminated by the noise filer.
Manufacturer Series model name
KITAGAWA INDUSTRIES CO., LTD. UC series (Recommended Product)
Model name FN343-3/01 FN660-6/06 ZHC2203-11
Manufacturer SCHAFFNER SCHAFFNER TDK
Rated current 3A 6A 3A
Rated voltage 250V
• Installing the input and output cables
together will cause noise induction.
• Separate the input cable from the output
cable.
Filter
Induction
Output side
(device side)
Input side
(power supply side)
Filter
Output side
(device side)
Input side
(power supply side)
(2) Connect the noise filter's ground terminal to the control panel with
the shortest cable as possible (approx. 10cm (3.94 in.) or less).
4.2 Requirements for Compliance with the Low
Voltage Directive
The Low Voltage Directive requires each device which operates with
power supply ranging from 50VAC to 1000V and 75VDC to 1500V to
satisfy necessary safety items.
In the Sections from 4.2.1 to 4.2.5, cautions on installation and wiring of
the GOT to conform to the Low Voltage Directive requires are described.
We have put the maximum effort to develop this material based on the
requirements and standards of the Directive that we have collected.
However, compatibility of the devices which are fabricated according to
the contents of this manual to the above Directive is not guaranteed.
Each manufacturer who fabricates such device should make the final
judgement about the application method of the Low Voltage Directive
and the product compatibility.
4.2.1 Standard subject to GOT
4.2.2 Power supply
The insulation specification of the GOT was designed assuming
installation category II. Be sure to use the installation category II power
supply to the GOT.
The installation category indicates the durability level against surge
voltage generated by lightning strike.
Category I has the lowest durability; category IV has the highest
durability.
Installation category
Category II indicates a power supply whose voltage has been reduced
by two or more levels of isolating transformers from the public power
distribution.
4.2.3 Control panel
Because the GOT is open type equipment (device designed to be stored
within another device), be sure to use it only when installed in a control
panel.
(1) Shock Protection
In order to prevent those who are unfamiliar with power facility,
e.g., an operator, from getting a shock, make sure to take the
following measures on the control panel.
(a) Store the GOT within the control panel locked, and allow only
those who are familiar with power facility to unlock the panel.
(b) Build the structure in order that the power supply will be shut off
when the control panel is opened.
(2) Dustproof and waterproof features
The control panel also provides protection from dust, water and
other substances. Insufficient ingression protection may lower the
insulation withstand voltage, resulting in insulation destruction.
The insulation in the GOT is designed to cope with the pollution
level 2, so use in an environment with pollustion level 2 or better.
4.2.4 Grounding
The following are applicable ground terminals. Use them in the grounded
state.
Be sure to ground the GOT for ensuring the safety and complying with
the EMC Directive.
Standard applied to GOT : EN61131-2 Programmable controllers - Equipment
requirements and tests
EN60950-1 Safety of Information Technology Equipment
Pollution level 1: An environment where the air is dry and conductive
dust does not exist.
Pollution level 2: An environment where conductive dust does not
usually exist, but occasional temporary conductivity
occurs due to the accumulated dust.
Generally, this is the level for inside the control panel
equivalent a control room or on the floor of a typical
factory.
Pollution level 3: An environment where conductive dust exits and
conductivity may be generated due to the accumulated
dust.
An environment for a typical factory floor.
Pollution level 4: Continuous conductivity may occur due to rain, snow,
etc. An outdoor environment.
Functional grounding : Improves the noise resistance.
Category ICategory IICategory IIICategory IV
4.2.5 External wiring
(1) External devices
When a device with a hazardous voltage circuit is externally
connected to the GOT, select a model which complies with the
Low Voltage Directive's requirements for isolation between the
primary and secondary circuits.
(2) Insulation requirements
Dielectric withstand voltages are shown in the following table.
Reinforced Insulation Withstand Voltage
(Installation Category II, source : IEC664)
5. INSTALLATION
5.1 Control Panel Inside Dimensions for
Mounting GOT
Install the GOT on the control panel out of the way for the equipment
inside the control panel. Do not install the GOT and the unit in prohibited
areas for the installation.
5.2 Panel Cutting Dimensions
Make an installation hole on the control panel with the dimensions shown
below.
Make space of 10mm above and below the hole respectively for the
installation fittings.
5.3 Mounting Position
When mounting the GOT, the following clearances must be maintained
from other structures and devices.
Depending on the units and cables connected to the GOT, clearances
more than the described dimensions can be required.
Therefore, consider the connector dimensions and bending radius of the
cable as well for installation.
For the lead-in allowance for cables at the bottom of the GOT, refer to
the GT15 User’s Manual.
According to the dimensions in the following table, leave clearances
between the GOT and the other devices. The values enclosed in square
brackets apply to the case where no other equipment generating
radiated noise (such as a contactor) or heat is installed near the GOT.
However, keep the ambient temperature of the GOT to 55°C or lower.
Rated voltage of hazardous
voltage area Surge withstand voltage (1.2/50 s)
150 VAC or below 2500V
300 VAC or below 4000V
Point
Applicable cable
Some cables may need to be longer than the specified dimensions when connecting to the
GOT. Therefore, consider the connector dimensions and bending radius of the cable as
well for installation.
A
B
*Panel thickness : 2 to 4 mm (0.08 to 0.16 inch)
GOT A[mm] (inch) B[mm] (inch)
GT1595
GT157□
GT156□
383.5 (15.10)
289 (11.38)
227 (8.94)
+2 (0.08)
0 (0)
+2 (0.08)
0 (0)
+2 (0.08)
0 (0)
153(6.02)
+2 (0.08)
0 (0)
282.5 (11.12)
200 (7.87)
176 (6.93)
+2 (0.08)
0 (0)
+2 (0.08)
0 (0)
+2 (0.08)
0 (0)
121(4.76)
+2 (0.08)
0 (0)
GT1585
GT155□
302 (11.89)
+2 (0.08)
0 (0)
228 (8.98)
+2 (0.08)
0 (0)
B
DE
A
C
Panel thickness: 2 to 4mm
(0.08 to 0.16 inch)
Unit : mm(inch)
*1: This value differs depending on the cable used.
Please contact your local Mitsubishi Electric System & Service Co.,Ltd.
The value indicated in the table is a reference value.
*2: This value is for use of the coaxial cable 3C-2V (JIS C 3501).
For specifications of the cable, refer to the MODEL GT15V-75V4R1 Video/
RGB Input Unit MODEL GT15V-75V4 Video Input Unit MODEL GT15V-
75R1 RGB Input Unit User's Manual.
*3: This value differs depending on the cable used.
If the bending radius of the cable used is greater than the value specified
above, apply the value of the cable used.
Item GT1595 GT1585 GT157 GT156 GT155
A
GOT only
50(1.97) or more
[20(0.79) or more]
50(1.97) or
more
[20(0.79)
or more]
50(1.97) or
more
[21(0.83)
or more]
49(1.92) or
more
Bus connection unit
is fitted
50(1.97) or
more
[35(1.38)
or more]
50(1.97) or
more
[40(1.57)
or more]
50(1.97) or
more
Serial
communication unit
fitted
50(1.97) or
more
[39(1.54)
or more]
50(1.97) or
more
[21(0.83)
or more]
49(1.92) or
more
RS-422 Conversion
unit is fitted
50(1.97) or
more
[20(0.79)
or more]
50(1.97) or
more
[39(1.54)
or more]
53(2.09) or
more
58(2.28) or
more -
Ethernet
communication unit
is fitted
50(1.97) or more [20(0.79) or more]
MELSECNET/10
communication unit
(coaxial) is fitted
50(1.97) or more [20(0.79) or more] -
CC-Link
communication unit
(GT15-75J61BT13-
Z) fitted
50(1.97) or more
[20(0.79) or more] -
CC-Link
communication unit
(GT15-J61BT13)
fitted
50(1.97) or more [20(0.79) or more]
50(1.97) or
more
[32(1.26)
or more]
MELSECNET/10
communication unit
(optical) fitted
50(1.97) or
more
[20(0.79)
or more]
50(1.97) or
more
[26(1.02)
or more]
50(1.97) or
more
[43(1.69)
or more]
50(1.97) or
more
[48(1.89)
or more]
-
MELSECNET/H
communication unit
(coaxial) fitted
50(1.97) or more
[20(0.79) or more]
50(1.97) or
more
[30(1.18)
or more]
50(1.97) or
more
[35(1.38)
or more]
64(2.52) or
more
MELSECNET/H
communication unit
(optical) fitted
50 (1.97)
or more
[20(0.79)
or more]*1
50(1.97) or
more
[23(0.91)
or more]*1
50(1.97) or
more
[37(1.46)
or more]*1
50(1.97) or
more
[42(1.65)
or more]*1
79(3.11) or
more
CC-Link IE
Controller Network
Module 50(1.97) or more
[20(0.79) or more]
50(1.97) or
more
[23(0.91)
or more]
50(1.97) or
more
[28(1.10)
or more]
57(2.24) or
more
CC-Link IE Field
Network Module
Printer unit fitted 50(1.97) or more [20(0.79) or more]
50(1.97) or
more
[29(1.14)
or more]
Video input unit fitted - 61(2.40) or
more*2
75(2.95) or
more*2 --
RGB input unit fitted - 50(1.97) or more
[20(0.79) or more]*3 --
Video/RGB input unit
fitted -61(2.40) or
more*2*3
75(2.95) or
more*2*3 --
RGB output unit
fitted -50(1.97) or more
[20(0.79) or more]*3 --
CF card unit 50(1.97) or more [20(0.79) or more]
CF card extension
unit
50(1.97) or
more
[20(0.79)
or more]
50(1.97) or
more
[49(1.93)
or more]
63(2.48) or
more
68(2.48) or
more
97(3.82) or
more
Output/Input unit 50(1.97) or more
[20(0.79) or more]
50(1.97) or
more
[24(0.94)
or more]
50(1.97) or
more
[29(1.14)
or more]
58(2.28) or
more
Sound Interface Unit 50(1.97) or more [20(0.79) or more]
B 80(3.15) or more [20(0.79) or more]
C
(When the CF card is
not used) 50(1.97) or more [20(0.79) or more]
(When the CF card is
used) 50(1.97) or more [20(0.79) or more] 100(3.94)
or more
D 50(1.97) or more [20(0.79) or more]
E 100(3.94) or more [20(0.79) or more]
Point
Refer to GT15 User's Manual for details of the Control Panel Inside Temperature and
Mounting Angle, Installation Procedure of each GOT.
5. INSTALLATION
5.1 Dimensions intérieures du tableau de
commande pour le montage du GOT
Installez le GOT sur le tableau de commande en laissant de l'espace
pour le dispositif à l'intérieur du tableau de commande. N'installez
pas le GOT et le module dans des zones où l'installation est interdite.
5.2 Cotes de découpe du panneau
Faites un trou d'installation sur le tableau de commande avec les
dimensions indiquées ci-dessous.
Laissez un espace de 10mm au-dessus et sous le trou respectivement
pour les attaches de montage.
5.3 Position de montage
Lors du montage du GOT, laissez les espaces suivants pour les autres
structures et dispositifs.
En fonction des modules et des câbles connectés au GOT, il peut être
nécessaire de laisser des espaces plus importants que les dimensions
indiquées.
Par conséquent, prenez également en compte les dimensions du
connecteur et le rayon de courbure du câble pour l'installation.
Pour connaître l'espace à laisser pour les câbles sous le GOT, référez-
vous au manuel GT15 User’s Manual.
Laissez les espaces entre le GOT et les autres dispositifs en fonction
des dimensions contenues dans le tableau suivant. Les valeurs entre
parenthèses s'appliquent au cas où aucun dispositif générant des
émissions sonores (comme un contacteur) ou de la chaleur n'est installé
près du GOT.
Toutefois, maintenez la température ambiante du GOT à 55°C ou moins.
Unité : mm (pouce)
Point
Câble applicable
Certains câbles peuvent être plus longs que les dimensions spécifiées lors de la
connexion au GOT. Par conséquent, prenez également en compte les dimensions du
connecteur et le rayon de courbure du câble pour l'installation.
Article GT1595 GT1585 GT157 GT156 GT155
A
GOT uniquement
50 (1,97) ou plus
[20 (0,79) ou plus]
50 (1,97)
ou plus
[20 (0,79)
ou plus]
50 (1,97)
ou plus
[21 (0,83)
ou plus]
49 (1,92)
ou plus
Unité de connexion de
bus encastrée
50 (1,97)
ou plus
[35 (1,38)
ou plus]
50 (1,97)
ou plus
[40 (1,57)
ou plus]
50 (1,97)
ou plus
Module de
communication série
encastré
50 (1,97)
ou plus
[39 (1,54)
ou plus]
50 (1,97)
ou plus
[21 (0,83)
ou plus]
49 (1,92)
ou plus
Unité de conversion
RS-422 encastrée
50 (1,97)
ou plus
[20 (0,79)
ou plus]
50 (1,97)
ou plus
[39 (1,54)
ou plus]
53 (2,09)
ou plus
58 (2,28)
ou plus -
Module de
communication
Ethernet encastré
50 (1,97) ou plus [20 (0,79) ou plus]
A
B
*Épaisseur du panneau : 2 à 4mm ou moins
GOT A [mm] (pouce) B[mm] (pouce)
GT1595
GT157□
GT156□
383.5 (15.10)
289 (11.38)
227 (8.94)
+2 (0.08)
0 (0)
+2 (0.08)
0 (0)
+2 (0.08)
0 (0)
153(6.02)
+2 (0.08)
0 (0)
282.5 (11.12)
200 (7.87)
176 (6.93)
+2 (0.08)
0 (0)
+2 (0.08)
0 (0)
+2 (0.08)
0 (0)
121(4.76)
+2 (0.08)
0 (0)
GT1585
GT155□
302 (11.89)
+2 (0.08)
0 (0)
228 (8.98)
+2 (0.08)
0 (0)
B
DE
A
C
Épaisseur du panneau : 2 à 4mm
(0,08 à 0,16 pouce)
*1 : Cette valeur diffère selon le câble utilisé.000
Contactez le bureau local Mitsubishi Electric System & Service Co., Ltd.
La valeur indiquée dans le tableau est une référence.
*2 : Cette valeur est utilisée pour le câble coaxial 3C-2V (JIS C 3501).
Pour connaître les spécifications du câble, référez-vous au MODEL
GT15V-75V4R1 Video/RGB Input Unit MODEL GT15V-75V4 Video Input
Unit MODEL GT15V-75R1 RGB Input Unit User's Manual (Section 2.4.1
Spécifications des câbles (câbles coaxiaux) utilisés lors de l'affichage
d'images vidéo).
*3 : Cette valeur diffère selon le câble utilisé.
Si le rayon de courbure du câble utilisé est supérieur à la valeur spécifiée
ci-dessus, appliquez la valeur du câble utilisé.
6. MAINTENANCE AND INSPECTION
Refer to the GT15 User's Manual for maintenance and inspection for the
GOT.
A
Module de
communication
MELSECNET/10
(coaxial) encastré
50 (1,97) ou plus [20 (0,79) ou plus] -
Module de
communication CC-
Link (GT15-
75J61BT13-Z)
encastré
50 (1,97) ou plus [20 (0,79) ou plus] -
Module de
communication CC-
Link (GT15-J61BT13)
encastré
50 (1,97) ou plus [20 (0,79) ou plus]
50 (1,97)
ou plus
[32 (1,26)
ou plus]
Module de
communication
MELSECNET/10
(optique) encastré
50 (1,97)
ou plus
[20 (0,79)
ou plus]
50 (1,97)
ou plus
[26 (1,02)
ou plus]
50 (1,97)
ou plus
[43 (1,69)
ou plus]
50 (1,97)
ou plus
[48 (1,89)
ou plus]
-
Module de
communication
MELSECNET/H
(coaxial) encastré
50 (1,97) ou plus
[20 (0,79) ou plus]
50 (1,97)
ou plus
[30 (1,18)
ou plus]
50 (1,97)
ou plus
[35 (1,38)
ou plus]
64 (2,52)
ou plus
Module de
communication
MELSECNET/H
(optique) encastré
50 (1,97)
ou plus
[20 (0,79)
ou plus]*1
50 (1,97)
ou plus
[23 (0,91)
ou plus]*1
50 (1,97)
ou plus
[37 (1,46)
ou plus]*1
50 (1,97)
ou plus
[42 (1,65)
ou plus]*1
79 (3,11)
ou plus
Module réseau de
contrôleur CC-Link IE 50 (1,97) ou plus
[20 (0,79) ou plus]
50 (1,97)
ou plus
[23 (0,91)
ou plus]
50 (1,97)
ou plus
[28 (1,10)
ou plus]
57 (2,24)
ou plus
Module réseau de
champ CC-Link IE
Imprimante encastrée 50 (1,97) ou plus [20 (0,79) ou plus]
50 (1,97)
ou plus
[29 (1,14)
ou plus]
Module d'entrée vidéo
encastré -61 (2,40)
ou plus*2 75 (2,95)
ou plus*2 --
Module d'entrée RGB
encastré -50 (1,97) ou plus
[20 (0,79) ou plus]3--
Module d'entrée vidéo/
RGB encastré -
61 (2,40)
ou
plus*2*3
75 (2,95)
ou
plus*2*3 --
Module de sortie RGB
encastré -50 (1,97) ou plus
[20 (0,79) ou plus]*3 --
Module de carte CF 50 (1,97) ou plus [20 (0,79) ou plus]
Module d'extension de
carte CF
50 (1,97)
ou plus
[20 (0,79)
ou plus]
50 (1,97)
ou plus
[49 (1,93)
ou plus]
63 (2,48)
ou plus
68 (2,48)
ou plus
97 (3,82)
ou plus
Module de sortie/
entrée
50 (1,97) ou plus
[20 (0,79) ou plus]
50 (1,97)
ou plus
[24 (0,94)
ou plus]
50 (1,97)
ou plus
[29 (1,14)
ou plus]
58 (2,28)
ou plus
Module d'interface
acoustique 50 (1,97) ou plus [20 (0,79) ou plus]
B 80 (3,15) ou plus [20 (0,79) ou plus]
C
(Quand la carte CF
n'est pas utilisée) 50 (1,97) ou plus [20 (0,79) ou plus]
(Quand la carte CF est
utilisée) 50 (1,97) ou plus [20 (0,79) ou plus] 100 (3,94)
ou plus
D 50 (1,97) ou plus [20 (0,79) ou plus]
E 100 (3,94) ou plus [20 (0,79) ou plus]
Point
Référez-vous au Manuel d'utilisation du GT15 pour obtenir des détails sur la
température intérieure et l'angle de montage du tableau de commande et sur la
procédure d'installation de chaque GOT.
Article GT1595 GT1585 GT157 GT156 GT155 Warranty
Mitsubishi will not be held liable for damage caused by factors found
not to be the cause of Mitsubishi; machine damage or lost profits
caused by faults in the Mitsubishi products; damage, secondary
damage, accident compensation caused by special factors
unpredictable by Mitsubishi; damages to products other than
Mitsubishi products; and to other duties.
For safe use
• This product has been manufactured as a general-purpose part for
general industries, and has not been designed or manufactured to
be incorporated in a device or system used in purposes related to
human life.
• Before using the product for special purposes such as nuclear
power, electric power, aerospace, medicine or passenger
movement vehicles, consult with Mitsubishi.
• This product has been manufactured under strict quality control.
However, when installing the product where major accidents or
losses could occur if the product fails, install appropriate backup or
failsafe functions in the system.
Country/Region Sales office/Tel
U.S.A Mitsubishi Electric Automation Inc.
500 Corporate Woods Parkway Vernon Hills, IL 60061, U.S.A.
Tel : [phone]
Brazil MELCO-TEC Rep. Com.e Assessoria Tecnica Ltda.
Rua Correia Dias, 184, Edificio Paraiso Trade Center-8 andar
Paraiso, Sao Paulo, SP Brazil
Tel : [phone]
Germany Mitsubishi Electric Europe B.V. German Branch
Gothaer Strasse 8 D-40880 Ratingen, GERMANY
Tel : [phone]
U.K Mitsubishi Electric Europe B.V. UK Branch
Travellers Lane, Hatfield, Hertfordshire., AL10 8XB, U.K.
Tel : [phone]
Italy Mitsubishi Electric Europe B.V. Italian Branch
Centro Dir. Colleoni, Pal. Perseo-Ingr.2
Via Paracelso 12, I-20041 Agrate Brianza., Milano, Italy
Tel : [phone]
Spain Mitsubishi Electric Europe B.V. Spanish Branch
Carretera de Rubi 76-80,
E-08190 Sant Cugat del Valles, Barcelona, Spain
Tel : [phone]
France Mitsubishi Electric Europe B.V. French Branch
25, Boulevard des Bouvets, F-92741 Nanterre Cedex, France
Tel : [phone]
South Africa Circuit Breaker Industries Ltd.
Private Bag 2016, ZA-1600 Isando, South Africa
Tel : [phone]
Hong Kong Mitsubishi Electric Automation (Hong Kong) Ltd.
10th Floor, Manulife Tower, 169 Electric
Road, North Point, Hong Kong
Tel : [phone]
China Mitsubishi Electric Automation (China) Ltd.
4/F Zhi Fu Plazz, No.80 Xin Chang Road,
Shanghai 200003, China
Tel : [phone]
Taiwan Setsuyo Enterprise Co., Ltd.
6F No.105 Wu-Kung 3rd.Rd, Wu-Ku Hsiang,
Taipei Hsine, Taiwan
Tel : [phone]
Korea Mitsubishi Electric Automation Korea Co., Ltd.
1480-6, Gayang-dong, Gangseo-ku Seoul
157-200, Korea
Tel : [phone]
Singapore Mitsubishi Electric Asia Pte, Ltd.
307 Alexandra Road #05-01/02,
Mitsubishi Electric Building, Singapore 159943
Tel : [phone]
Thailand Mitsubishi Electric Automation (Thailand) Co., Ltd.
Bang-Chan Industrial Estate No.111 Moo 4, Serithai Rd,
T.Kannayao, A.Kannayao, Bangkok 10230 Thailand
Tel : [phone]
Indonesia P.T. Autoteknindo Sumber Makmur
Muara Karang Selatan, Block A/Utara
No.1 Kav. No.11 Kawasan Industri Pergudangan
Jakarta - Utara 14440, P.O.Box 5045 Jakarta, 11050 Indonesia
Tel : [phone]
India Messung Systems Pvt, Ltd.
Electronic Sadan NO:III Unit No15, M.I.D.C Bhosari,
Pune-411026, India
Tel : [phone]
Australia Mitsubishi Electric Australia Pty. Ltd.
348 Victoria Road, Rydalmere, N.S.W 2116, Australia
Tel : [phone]
HEAD OFFICE : TOKYO BUILDING, 2-7-3 MARUNOUCHI, CHIYODA-KU, TOKYO 100-8310, JAPAN
NAGOYA WORKS : 1-14, YADA-MINAMI 5-CHOME, HIGASHI-KU, NAGOYA, JAPAN
When exported from Japan, this manual does not require application to the Ministry
of Economy, Trade and Industry for service transaction permission.
Specifications subject to change without notice.
Printed in Japan, October 2014.
