Mitsubishi Electric CC-Link IE TSN User manual

CC-Link IE TSN―CC-Link IE Field Network Bridge
Module User's Manual
-NZ2GN-GFB

1
SAFETY PRECAUTIONS
(Read these precautions before using this product.)
Before using this product, please read this manual and the relevant manuals carefully and pay full attention to safety to handle
the product correctly.
The precautions given in this manual are concerned with this product only. For the safety precautions of the programmable
controller system, refer to the user's manual for the CPU module used.
In this manual, the safety precautions are classified into two levels: " WARNING" and " CAUTION".
Under some circumstances, failure to observe the precautions given under " CAUTION" may lead to serious
consequences.
Observe the precautions of both levels because they are important for personal and system safety.
Make sure that the end users read this manual and then keep the manual in a safe place for future reference.
[Design Precautions]
[Design Precautions]
WARNING
●In the case of a communication failure in the network, data of the master station are held. Check Data
link status (each station) (SW00B0 to SW00B7) and configure an interlock circuit in the program to
ensure that the entire system will operate safely.
●When a module on CC-Link IE TSN is disconnected due to a communication failure, outputs to the
stations connected to CC-Link IE Field Network are held or turned off according to the I/O
maintenance settings. In such a case, configure an interlock circuit in the program to ensure that the
entire system will operate safely. If not, an accident may occur due to an incorrect output or
malfunction.
●When a module on CC-Link IE Field Network is disconnected due to a communication failure, outputs
to the master station on CC-Link IE TSN are held or turned off according to the I/O maintenance
settings. Configure an interlock circuit in the program to ensure that the entire system will operate
safely even in such a case. If not, an accident may occur due to an incorrect output or malfunction.
●Outputs may remain on or off due to a failure of the module. Configure an external circuit for
monitoring output signals that could cause a serious accident.
●Do not use any "use prohibited" signals as a remote I/O signal since they are used by the system. Do
not write any data to the "use prohibited" areas in the remote register. If these operations are
performed, an accident may occur due to an incorrect output or malfunction.
CAUTION
●Do not install the control lines or communication cables together with the main circuit lines or power
cables. Keep a distance of 100mm or more between them. Failure to do so may result in malfunction
due to noise.
WARNING Indicates that incorrect handling may cause hazardous conditions, resulting in
death or severe injury.
CAUTION Indicates that incorrect handling may cause hazardous conditions, resulting in
minor or moderate injury or property damage.

2
[Security Precautions]
[Installation Precautions]
[Installation Precautions]
WARNING
●To maintain the security (confidentiality, integrity, and availability) of the programmable controller and
the system against unauthorized access, denial-of-service (DoS) attacks, computer viruses, and other
cyberattacks from external devices via the network, take appropriate measures such as firewalls,
virtual private networks (VPNs), and antivirus solutions.
WARNING
●Shut off the external power supply (all phases) used in the system before mounting or removing a
module. Failure to do so may result in electric shock or cause the module to fail or malfunction.
CAUTION
●Use the module in an environment that meets the general specifications in the user's manual for the
module. Failure to do so may result in electric shock, fire, malfunction, or damage to or deterioration of
the product.
●Do not directly touch any conductive parts and electronic components of the module. Doing so can
cause malfunction or failure of the module.
●Securely connect the cable connectors. Poor contact may cause malfunction.
●After the first use of the product, do not connect/remove the connector more than 50 times (IEC
61131-2/JIS B 3502 compliant). Exceeding the limit may cause malfunction.

3
[Wiring Precautions]
[Wiring Precautions]
WARNING
●Shut off the external power supply (all phases) used in the system before wiring. Failure to do so may
result in electric shock or cause the module to fail or malfunction.
CAUTION
●Individually ground the FG terminal of the programmable controller with a ground resistance of 100?
or less. Failure to do so may result in electric shock or malfunction.
●Check the rated voltage and terminal layout before wiring to the module, and connect the cables
correctly. Connecting a power supply with a different voltage rating or incorrect wiring may cause a fire
or failure.
●Prevent foreign matter such as dust or wire chips from entering the module. Such foreign matter can
cause a fire, failure, or malfunction.
●Place the cables in a duct or clamp them. If not, dangling cables may swing or inadvertently be pulled,
resulting in malfunction or damage to modules or cables. In addition, the weight of the cables may put
stress on modules in an environment of strong vibrations and shocks.
●Do not install the communication cables together with the main circuit lines or power cables. Keep a
distance of 100mm or more between them. Failure to do so may result in malfunction due to noise.
●When disconnecting the cable from the module, do not pull the cable by the cable part. For the cable
with connector, hold the connector part of the cable. For the cable connected to the terminal block,
loosen the terminal screw. Pulling the cable connected to the module may result in malfunction or
damage to the module or cable.
●When an overcurrent caused by an error of an external device or a failure of the programmable
controller flows for a long time, it may cause smoke and fire. To prevent this, configure an external
safety circuit, such as a fuse.
●Mitsubishi Electric programmable controllers must be installed in control panels. Wiring and
replacement of a module must be performed by qualified maintenance personnel with knowledge of
protection against electric shock. For wiring, refer to "INSTALLATION AND WIRING" in the user's
manual.

4
[Startup and Maintenance Precautions]
[Startup and Maintenance Precautions]
[Disposal Precautions]
WARNING
●Do not touch any terminal while power is on. Doing so will cause electric shock or malfunction.
●Shut off the external power supply (all phases) used in the system before cleaning the module or
retightening the terminal block screws or the connector screws. Failure to do so may cause the
module to fail or malfunction.
CAUTION
●Do not disassemble or modify the module. Doing so may cause failure, malfunction, injury, or a fire.
●Do not drop or apply strong shock to the module. Doing so may damage the module.
●Use any radio communication device such as a cellular phone or PHS (Personal Handy-phone
System) more than 25cm away from wiring as well as away in all directions from the programmable
controller. Failure to do so may cause malfunction.
●Shut off the external power supply (all phases) used in the system before mounting or removing a
module. Failure to do so may cause the module to fail or malfunction.
●After the first use of the product, do not connect/remove the terminal block more than 50 times (IEC
61131-2/JIS B 3502 compliant). Exceeding the limit may cause malfunction.
●After the first use of the product, do not connect/remove the connector more than 50 times (IEC
61131-2/JIS B 3502 compliant). Exceeding the limit may cause malfunction.
●Before handling the module or connection cables, touch a conducting object such as a grounded
metal to discharge the static electricity from the human body. Failure to do so may cause the module
to fail or malfunction.
●Startup and maintenance of a control panel must be performed by qualified maintenance personnel
with knowledge of protection against electric shock. Lock the control panel so that only qualified
maintenance personnel can operate it.
CAUTION
●When disposing of this product, treat it as industrial waste.

5
CONDITIONS OF USE FOR THE PRODUCT
COMPLIANCE WITH EMC AND LOW VOLTAGE
DIRECTIVES
Method of ensuring compliance
To ensure that Mitsubishi Electric programmable controllers maintain the EMC and Low Voltage Directives or other
regulations when incorporated into other machinery or equipment, certain measures may be necessary. Please refer to one of
the following manuals.
• User's manual for the CPU module or head module used
• Safety Guidelines (This manual is included with the CPU module, base unit, or head module.)
Certification marks on the side of the programmable controller indicate compliance with the relevant regulations.
Additional measures
To ensure that this product maintains EMC and Low Voltage Directives, please refer to the following.
Page 273 EMC and Low Voltage Directives
(1) MELSEC programmable controller ("the PRODUCT") shall be used in conditions;
i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or serious accident;
and
ii) where the backup and fail-safe function are systematically or automatically provided outside of the PRODUCT for the
case of any problem, fault or failure occurring in the PRODUCT.
(2) The PRODUCT has been designed and manufactured for the purpose of being used in general industries.
MITSUBISHI ELECTRIC SHALL HAVE NO RESPONSIBILITY OR LIABILITY (INCLUDING, BUT NOT LIMITED TO
ANY AND ALL RESPONSIBILITY OR LIABILITY BASED ON CONTRACT, WARRANTY, TORT, PRODUCT
LIABILITY) FOR ANY INJURY OR DEATH TO PERSONS OR LOSS OR DAMAGE TO PROPERTY CAUSED BY the
PRODUCT THAT ARE OPERATED OR USED IN APPLICATION NOT INTENDED OR EXCLUDED BY
INSTRUCTIONS, PRECAUTIONS, OR WARNING CONTAINED IN MITSUBISHI ELECTRIC USER'S, INSTRUCTION
AND/OR SAFETY MANUALS, TECHNICAL BULLETINS AND GUIDELINES FOR the PRODUCT.
("Prohibited Application")
Prohibited Applications include, but not limited to, the use of the PRODUCT in;
• Nuclear Power Plants and any other power plants operated by Power companies, and/or any other cases in which the
public could be affected if any problem or fault occurs in the PRODUCT.
• Railway companies or Public service purposes, and/or any other cases in which establishment of a special quality
assurance system is required by the Purchaser or End User.
• Aircraft or Aerospace, Medical applications, Train equipment, transport equipment such as Elevator and Escalator,
Incineration and Fuel devices, Vehicles, Manned transportation, Equipment for Recreation and Amusement, and
Safety devices, handling of Nuclear or Hazardous Materials or Chemicals, Mining and Drilling, and/or other
applications where there is a significant risk of injury to the public or property.
Notwithstanding the above restrictions, Mitsubishi Electric may in its sole discretion, authorize use of the PRODUCT in
one or more of the Prohibited Applications, provided that the usage of the PRODUCT is limited only for the specific
applications agreed to by Mitsubishi Electric and provided further that no special quality assurance or fail-safe,
redundant or other safety features which exceed the general specifications of the PRODUCTs are required. For details,
please contact the Mitsubishi Electric representative in your region.
(3) Mitsubishi Electric shall have no responsibility or liability for any problems involving programmable controller trouble and
system trouble caused by DoS attacks, unauthorized access, computer viruses, and other cyberattacks.

6
INTRODUCTION
Thank you for purchasing the CC-Link IE TSN-CC-Link IE Field Network bridge module.
This manual describes the procedures, system configuration, parameter settings, functions, and troubleshooting of the
relevant product listed below.
Before using this product, please read this manual and the relevant manuals carefully and develop familiarity with the
functions and performance of the relevant product to handle the product correctly.
When applying the program examples introduced in this manual to an actual system, ensure the applicability and confirm that
it will not cause system control problems.
Note that the menu names and operating procedures may differ depending on an operating system in use and its version.
When reading this manual, replace the names and procedures with the applicable ones as necessary.
Relevant product
NZ2GN-GFB
Unless otherwise specified, this manual provides program examples in which the remote I/O signals and
remote registers are assigned to the NZ2GN-GFB as follows.
• Remote input signal: RX0 to RX2F
• Remote output signal: RY0 to RY2F
• Remote register: RWr0 to RWr3F
• Remote register: RWw0 to RWw3F
For the assignment of remote I/O signals and remote registers, refer to the following.
Page 101 Program Examples

7
CONTENTS
CONTENTS
SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
CONDITIONS OF USE FOR THE PRODUCT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .5
INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .6
RELEVANT MANUALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
TERMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
GENERIC TERMS AND ABBREVIATIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
CHAPTER 1 PART NAMES 13
CHAPTER 2 SPECIFICATIONS 15
2.1 General Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 15
2.2 Performance Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
2.3 Ethernet Communication Specifications . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
2.4 Function List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 18
CHAPTER 3 PROCEDURES BEFORE OPERATION 20
CHAPTER 4 SYSTEM CONFIGURATION 22
4.1 Network Configuration . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
4.2 Network Topology . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23
4.3 Applicable Systems. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 24
CHAPTER 5 INSTALLATION AND WIRING 26
5.1 Setting Switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Settings for CC-Link IE TSN IP address setting switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
Settings for CC-Link IE Field Network station number setting switch . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
Function setting switch setting. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 29
5.2 Installation Environment and Installation Position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Installation environment. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 30
Installation position . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 31
Mounting direction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
5.3 Installation . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
Mounting a module on a DIN rail . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
5.4 Wiring of Terminal Block for Module Power Supply and FG. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 35
5.5 Wiring of Ethernet Cable. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
5.6 Precautions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 41
CHAPTER 6 PARAMETER SETTINGS 42
6.1 Parameter Settings for CC-Link IE TSN. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
6.2 Parameter Settings for CC-Link IE Field Network . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 45
6.3 Module Parameter Setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 47
Parameter automatic setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 57
Device station parameter processing . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 62
6.4 Parameter Settings for CC-Link IE Field Network Device Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .66
CHAPTER 7 FUNCTIONS 68
7.1 Cyclic Transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68

8
Communications using RX, RY, RWr, and RWw . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 68
I/O maintenance settings. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 73
Cyclic transmission stop and restart . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 77
7.2 Transient Transmission . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Communications using a dedicated instruction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 78
Transient transmission with other stations using remote buffer memory. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 81
Communications using the SLMP . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 85
Communications using the engineering tool . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 86
7.3 RAS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Module power supply voltage drop detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 88
Device station disconnection. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Automatic return . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 89
Master station duplication detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 90
Station number duplication detection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 91
7.4 Others. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
Communication speed setting function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 92
CC-Link IE TSN Class setting function . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 93
Reserved station setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 96
Error invalid station setting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 97
CHAPTER 8 PROGRAMMING 98
8.1 Precautions for Programming . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Cyclic transmission program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 98
Transient transmission program . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100
8.2 Program Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 101
When the NZ2GN-GFB is used as the CC-Link IE Field Network master station . . . . . . . . . . . . . . . . . . . . . . . 101
When the NZ2GN-GFB is used as the CC-Link IE Field Network local station. . . . . . . . . . . . . . . . . . . . . . . . . 109
CHAPTER 9 MAINTENANCE AND INSPECTION 117
CHAPTER 10 TROUBLESHOOTING 119
10.1 CC-Link IE TSN/CC-Link IE Field Diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
CC-Link IE TSN diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 119
CC-Link IE Field Network diagnostics . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 121
10.2 Checking the LEDs . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 137
10.3 Check with Remote Register and Remote Buffer Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 143
10.4 Unit Test . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 144
10.5 Troubleshooting by Symptom . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 145
10.6 Checking Event Codes and Error Codes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
Checking method. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 148
How to clear an error. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 150
How to clear an event history . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 151
10.7 Error Code List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 152
10.8 Event List . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 167
APPENDICES 169
Appendix 1 Remote I/O Signals . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
List of remote I/O signals. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 169
Remote I/O signal details . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 171
Appendix 2 Remote Register . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175

9
CONTENTS
Lists of remote register areas . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 175
Details of remote registers. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 177
Appendix 3 Remote Buffer Memory . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 188
List of buffer memory addresses . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 189
Details of remote buffer memory (parameter area) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 201
Details of remote buffer memory (monitor area) . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 219
Details of remote buffer memory (control area). . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 221
Details of remote buffer memory (Link special relay (SB) area of CC-Link IE Field Network) . . . . . . . . . . . . . 223
Details of remote buffer memory (Link special register (SW) area of CC-Link IE Field Network) . . . . . . . . . . . 241
Details of remote buffer memory (CC-Link IE Field Network control and monitor areas) . . . . . . . . . . . . . . . . . 260
Appendix 4 Processing Time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
Device transfer time. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
Link scan time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 266
Transmission delay time . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 267
Appendix 5 Differences in Cyclic Transmission Modes . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 272
Appendix 6 EMC and Low Voltage Directives . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 273
Measures to comply with the EMC Directive. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 273
Measures to comply with the Low Voltage Directive . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 277
Appendix 7 How to Check Production Information and Firmware Version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 278
Checking the production information. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 278
Checking the firmware version . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 279
Appendix 8 Connecting with modules of the MELSEC-Q/L series . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 280
Appendix 9 External Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 281
INDEX 282
REVISIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .284
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .285
TRADEMARKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .286
COPYRIGHTS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .286

10
RELEVANT MANUALS
e-Manual refers to the Mitsubishi Electric FA electronic book manuals that can be browsed using a dedicated
tool.
e-Manual has the following features:
• Required information can be cross-searched in multiple manuals.
• Other manuals can be accessed from the links in the manual.
• The hardware specifications of each part can be found from the product figures.
• Pages that users often browse can be bookmarked.
• Sample programs can be copied to an engineering tool.
Manual name [manual number] Description Available
form
CC-Link IE TSN―CC-Link IE Field Network Bridge Module
User's Manual
[SH-082571ENG] (this manual)
Specifications, procedures before operation, system configuration, wiring,
parameter settings, functions, communication examples, troubleshooting,
remote I/O signals, remote register, and remote buffer memory of the
NZ2GN-GFB
Print book
e-Manual
PDF
MELSEC iQ-R CC-Link IE TSN User's Manual (Startup)
[SH-082127ENG]
Specifications, procedures before operation, system configuration, wiring,
and communication examples of CC-Link IE TSN
Print book
e-Manual
PDF
MELSEC iQ-R CC-Link IE TSN User's Manual (Application)
[SH-082129ENG]
Functions, parameter settings, troubleshooting, I/O signals, and buffer
memory of CC-Link IE TSN
Print book
e-Manual
PDF
MELSEC iQ-R Ethernet/CC-Link IE User's Manual (Startup)
[SH-081256ENG]
Specifications, procedures before operation, system configuration, wiring,
and communication examples of Ethernet, CC-Link IE Controller Network,
and CC-Link IE Field Network
Print book
e-Manual
PDF
MELSEC iQ-R CC-Link IE Field Network User's Manual
(Application)
[SH-081259ENG]
Functions, parameter settings, programming, troubleshooting, I/O signals,
and buffer memory of CC-Link IE Field Network
Print book
e-Manual
PDF
GX Works3 Operating Manual
[SH-081215ENG]
System configuration, parameter settings, and online operations of GX
Works3
e-Manual
PDF
SLMP Reference Manual
[SH-080956ENG]
A protocol used to access an SLMP-compatible device from an external
device (such as a personal computer or HMI (Human Machine Interface)) or
an SLMP-compatible module (such as the Ethernet-equipped module or
modules on CC-Link IE TSN)
Print book
e-Manual
PDF

11
TERMS
Unless otherwise specified, this manual uses the following terms.
Term Description
Baton pass A data transmission method by which transmission right (token) is passed around the network.
CC-Link IE TSN Class A group of devices and switching hubs compatible with CC-Link IE TSN, ranked according to the functions and
performance by the CC-Link Partner Association.
For CC-Link IE TSN Class, refer to the CC-Link IE TSN Installation Manual (BAP-C3007ENG-001) published by the CC-
Link Partner Association.
CC-Link IE TSN Protocol version
1.0
This protocol is used to perform communications by using the time sharing method defined by IEEE 802.1AS or IEEE
1588 for time synchronization.
CC-Link IE TSN Protocol version
2.0
This protocol is used to perform communications by using the time sharing method defined by IEEE 802.1AS and time-
managed polling method for time synchronization.
Control CPU A CPU module that controls connected I/O modules and intelligent function modules. In a multiple CPU system, a
control CPU can be set for each module.
Cyclic transmission A function by which data are periodically exchanged among stations on the same network using link devices.
Dedicated instruction An instruction that simplifies programming for using functions of intelligent function modules
Device station Stations other than a master station (such as a local station, a remote station, and an intelligent device station)
Disconnection A process of stopping data link if a data link error occurs
Engineering tool A tool used for setting up programmable controllers, programming, debugging, and maintenance
Intelligent device station A station that exchanges I/O signals (bit data) and I/O data (word data) with the master station by cyclic transmission.
This station responds to a transient transmission request from another station and also issues a transient transmission
request to another station.
Link device A device (such as RX, RY, RWr, or RWw) in a module
Link scan (link scan time) Time required for all the stations on the network to transmit data. The link scan time depends on data volume and the
number of transient transmission requests.
Local station A station that performs cyclic transmission and transient transmission with the master station and other local stations
Master operating station A station that controls the entire system in the network where a master station and a submaster station are connected.
Only one master operating station can be used in a network.
Master station A station that controls the entire network. This station can perform cyclic transmission and transient transmission with all
stations.
Only one master station can be used in a network.
Multicast filter A filter function that selects whether to send cyclic data of multicast mode received by the own station to the subsequent
stations. Setting parameters for this function are not required because the master station automatically sets the
parameters according to the system configuration.
Multicast mode A communication mode used to send cyclic data to multiple stations
Relay station A station in which multiple network modules are mounted on one programmable controller to relay data link to other
stations
Remote buffer memory Buffer memory in a remote station, intelligent device station, and other stations
Remote device station A station that exchanges I/O signals (bit data) and I/O data (word data) with the master station by cyclic transmission.
This station responds to a transient transmission request from another station.
Remote I/O station A station that exchanges I/O signals (bit data) with the master station by cyclic transmission
Remote station A station that exchanges I/O signals (bit data) and I/O data (word data) with another station by cyclic transmission. This
station can perform transient transmission.
Reserved station A station reserved for future use. This station is not actually connected, but counted as a connected station.
Return A process of restarting data link when a station recovers from an error
Routing A process of selecting paths for communication with other networks. There are two types of routing: dynamic routing that
auto-selects the communication paths, and static routing where any communication paths can be set.
SLMP SeamLess Message Protocol.
This protocol is used to access an SLMP-compatible device or a programmable controller connected to an SLMP-
compatible device from an external device.
Submaster operating station A station that monitors the status of a master operating station in the network where a master station and a submaster
station are connected. Only one submaster operating station can be used in a network.
Submaster station A station that serves as a master station to control the entire network if the master station is disconnected. Only one
submaster station can be used in a network.
Transient transmission A function of communication with another station, which is used when requested by a dedicated instruction or the
engineering tool.
Unicast mode A communication mode used to send cyclic data to one station

12
GENERIC TERMS AND ABBREVIATIONS
Unless otherwise specified, this manual uses the following generic terms and abbreviations.
Generic term/abbreviation Description
CC-Link IE A generic term for the following items:
• CC-Link IE TSN
• CC-Link IE Controller Network
• CC-Link IE Field Network
CC-Link IE TSN remote module A generic term for an A/D converter module, a D/A converter module, an I/O module of CC-Link IE TSN
Data link A generic term for cyclic transmission and transient transmission
Ethernet device A generic term for the devices supporting IP communication (such as a personal computer, a vision sensor, and a bar
code reader)
REMFR A generic term for the JP.REMFR and ZP.REMFR
REMFRD An abbreviation for the JP.REMFRD
REMFRDIP An abbreviation for the GP.REMFRDIP
REMFRIP An abbreviation for the GP.REMFRIP
REMTO A generic term for the JP.REMTO and ZP.REMTO
REMTOD An abbreviation for the JP.REMTOD
REMTODIP An abbreviation for the GP.REMTODIP
REMTOIP An abbreviation for the GP.REMTOIP
REQ A generic term for the J.REQ, JP.REQ, G.REQ, and GP.REQ
RIRD A generic term for the J.RIRD, JP.RIRD, G.RIRD, and GP.RIRD
RIWT A generic term for the J.RIWT, JP.RIWT, G.RIWT, and GP.RIWT
RWr An abbreviation for a remote register of a link device. Word data (16-bit data) input from a device station to the master
station. (For some areas in a local station, data are input in the opposite direction.)
RWw An abbreviation for a remote register of a link device. Word data (16-bit data) output from the master station to a device
station (For some areas in a local station, data are output in the opposite direction.)
RX An abbreviation for remote input of a link device. Bit data input from a device station to the master station (For some
areas in a local station, data are input in the opposite direction.)
RY An abbreviation for remote output of a link device. Bit data output from the master station to a device station (For some
areas in a local station, data are output in the opposite direction.)
SB An abbreviation for a link special relay. Bit data that indicates the operating status and data link status of a module on
CC-Link IE.
SEND A generic term for the JP.SEND and GP.SEND
SLMPSND A generic term for the J.SLMPSND, JP.SLMPSND, G.SLMPSND, and GP.SLMPSND
SW An abbreviation for the link special register. Word data that indicates the operating status and data link status of a
module on CC-Link IE.

1 PART NAMES
13
1
1 PART NAMES
The following table indicates the part names of the NZ2GN-GFB.
No. Name Description
(1) PW LED Indicates the power status of the NZ2GN-GFB.
On: Power-on
Off: Power-off
RUN LED Indicates the operation status of the NZ2GN-GFB.
On: Normal operation
Flashing: Unit test mode
Off: Major error
ERR. LED Indicates the error status of the NZ2GN-GFB.
On: Major/minor error occurring, or searching for error in all CC-Link IE Field Network stations
*1
Flashing (500ms interval): Searching for data link faulty stations in CC-Link IE Field Network
Flashing (200ms interval): Major/moderate error occurring
*1
Off: Normal operation
(2) D LINK LED (CC-Link IE TSN) Indicates the CC-Link IE TSN data link status.
On: Cyclic transmission being performed
Off: Cyclic transmission stopped
Off: Disconnected
(3) D LINK LED (CC-Link IE Field) Indicates the CC-Link IE Field Network data link status.
On: Data link in progress (cyclic transmission being performed)
Flashing: Data link in progress (cyclic transmission stopped)
Off: Data link not performed (disconnected)
L ERR. LED Indicates the CC-Link IE Field Network received data and link error status.
On: Abnormal data received or loopback being performed
Off: Normal data received and loopback not performed
(4) Function setting switch This switch sets the functions of the NZ2GN-GFB. (Page 29 Function setting switch setting)
(5) CC-Link IE TSN IP address
setting switch
Sets the IP address (fourth octet) of CC-Link IE TSN. (Page 26 Settings for CC-Link IE TSN IP address setting
switch)
(6) CC-Link IE Field Network
station number setting switch
Sets the station number CC-Link IE Field Network. (Page 28 Settings for CC-Link IE Field Network station
number setting switch)
(7) Terminal block for module
power supply and FG
A terminal block to connect the module power supply (24VDC) and FG.
(8) Reset switch Resets the NZ2GN-GFB.
(9) CC-Link IE TSN
communication connector (P1
and P2)
Ports for CC-Link IE TSN connection. (RJ45 connector)
Connect an Ethernet cable. (Page 39 Wiring of Ethernet Cable)
There is no restrictions on the connection order of P1 and P2.
P1 LINK LED Indicates the PORT1 link status of CC-Link IE TSN.
On: Link-up
Off: Link-down
P2 LINK LED Indicates the PORT2 link status of CC-Link IE TSN.
On: Link-up
Off: Link-down
(1) (8)
(9)
(10)
(2)
(3)
(4)
(5)
(6)
(7)
(11)

14
1 PART NAMES
*1 An error status can be determined by the on/off status of RUN LED and ERR. LED. (Page 14 NZ2GN-GFB status and LED status)
NZ2GN-GFB status and LED status
The following table lists the correspondence between the NZ2GN-GFB status and the LED status.
*1 If the CC-Link IE TSN master station becomes absent during network initialization, the D LINK LED may flash continuously.
*2 This only applies when the NZ2GN-GFB is used as the CC-Link IE Field Network local station.
(10) CC-Link IE Field Network
communication connector
This port is to connect to CC-Link IE Field Network. (RJ45 connector)
Connect an Ethernet cable. (Page 39 Wiring of Ethernet Cable)
LINK LED Indicates the CC-Link IE Field Network link status.
On: Link-up
Off: Link-down
(11) DIN rail hook This hook mounts the NZ2GN-GFB on a DIN rail.
NZ2GN-GFB status LED status
RUN LED ERR. LED D LINK LED
(CC-Link IE
TSN)
D LINK LED
(CC-Link IE
Field)
L ERR. LED
CC-Link IE
TSN
Cyclic transmission in
progress
On On 
Disconnected On Off 
Reserved station setting in
progress
On Flashing 
Cyclic transmission stopped On Flashing 
Network initial setting in
progress
*1
On Flashing 
CC-Link IE
Field Network
Cyclic transmission in
progress
On On 
Disconnected On Off 
Cyclic transmission stopped On Flashing 
Searching for error in all
stations
On On Off 
Searching for data link faulty
stations
On Flashing 
Reserved station setting in
progress
*2
On Flashing 
Connecting the master
station set for ring
topology
*2
On On
Receiving abnormal data On On
Error Major error Off On or flashing 
Moderate error On Flashing 
Minor error On On 
Unit test In progress Flashing Off Off Off Off
Normal completion On Off Off Off Off
Abnormal completion On On Off Off Off
No. Name Description

2 SPECIFICATIONS
2.1 General Specifications
15
2
2 SPECIFICATIONS
2.1 General Specifications
The following table lists the general specifications.
*1 Do not use or store the programmable controller under pressure higher than the atmospheric pressure of altitude 0m.
Doing so may cause malfunction.
When using the programmable controller under pressure, please consult your local Mitsubishi representative.
*2 This indicates the section of the power supply to which the equipment is assumed to be connected between the public electrical power
distribution network and the machinery within premises.
Category applies to equipment for which electrical power is supplied from fixed facilities.
The surge voltage withstand level for the equipment with the rated voltage of 300V or less is 2500V.
*3 This index indicates the degree to which conductive material is generated in terms of the environment in which the equipment is used.
In pollution degree 2, only non-conductive pollution occurs. A temporary conductivity caused by an accidental condensation may also
occur occasionally.
*4 The equipment can also be used outside the control panel, provided that environmental conditions such as operating ambient
temperature and operating ambient humidity are met.
For compliance with the EMC Directive, refer to the following:
Page 273 EMC and Low Voltage Directives
Item Specifications
Operating ambient
temperature
0 to 55
Storage ambient
temperature
-25 to 75
Operating ambient
humidity
5 to 95%RH, non-condensing
Storage ambient
humidity
Vibration resistance Compliant with IEC
61131-2 and JIS B
3502
Frequency Constant
acceleration
Half amplitude Number of sweeps
Under intermittent
vibration
5 to 8.4Hz 3.5mm 10 times each in X,
Y, and Z directions
8.4 to 150Hz 9.8m/
Under continuous
vibration
5 to 8.4Hz 1.75mm 
8.4 to 150Hz 4.9m/
Shock resistance Compliant with IEC 61131-2 and JIS B 3502 (147m/, 3 times each in X, Y, and Z directions)
Operating
atmosphere
No corrosive gases, flammable gases, less conductive dust
Operating altitude
*1
0 to 2000m
Installation location Inside a control panel
*4
Overvoltage
category
*2
or less
Pollution degree
*3
2 or less
Equipment class Class 

16
2 SPECIFICATIONS
2.2 Performance Specifications
2.2 Performance Specifications
The following table shows the performance specifications of the NZ2GN-GFB.
*1 For details on time-managed polling, refer to the following.
User's manual for the master station used
*2 Ring topology cannot be used when the CC-Link IE TSN Class is CC-Link IE TSN Class A.
*3 256 points (512 bytes) for high-speed mode.
*4 Only one wire can be inserted into a wire insertion opening. Multiple wires cannot be connected to a terminal. Connecting two or more
wires may cause a poor contact.
*5 Power this equipment from a power supply that meets SELV (Safety Extra Low Voltage) and meets LIM (Limited Energy Circuit) or UL
1310 Class 2.
Classification Item Specifications
CC-Link IE TSN Station type Remote station
Maximum number of link
points
Remote input (RX) 16K points (16384 points, 2K bytes)
Remote output (RY) 16K points (16384 points, 2K bytes)
Remote register (RWw) 2080 points (4160 bytes)
Remote register (RWr) 2080 points (4160 bytes)
CC-Link IE TSN Class • CC-Link IE TSN Class B
• CC-Link IE TSN Class A
CC-Link IE TSN Protocol
version
CC-Link IE TSN Class B • CC-Link IE TSN Protocol version 2.0
• CC-Link IE TSN Protocol version 1.0
CC-Link IE TSN Class A CC-Link IE TSN Protocol version 2.0
Maximum response time for time-managed polling (for CC-
Link IE TSN Class A)
*1
8192s
Network topology Line topology, star topology, mix of line and star topologies, and ring
topology
*2
Multicast filter Available
CC-Link IE Field
Network
Station type Master station and local stations
Maximum number of link
points
(1 network)
Remote input (RX) 16K points (16384 points, 2K bytes)
Remote output (RY) 16K points (16384 points, 2K bytes)
Remote register (RWw) 2K points (2048 points, 4K bytes)
Remote register (RWr) 2K points (2048 points, 4K bytes)
Maximum number of link
points
(1 station)
Remote input (RX) Master station: 16K points (16384 points, 2K bytes)
Local station: 2K points (2048 points, 256 bytes)
Remote output (RY) Master station: 16K points (16384 points, 2K bytes)
Local station: 2K points (2048 points, 256 bytes)
Remote register (RWw) Master station: 2K points (2048 points, 4K bytes)
Local station: 1K points (1024 points, 2K bytes)
*3
Remote register (RWr) Master station: 2K points (2048 points, 4K bytes)
Local station: 1K points (1024 points, 2K bytes)
*3
Maximum number of connectable stations (for master station) 32 stations
Network topology Line topology, star topology, and mix of line and star topologies
Common Protection degree IP2X
External interface Communication part RJ45 connector
Module power supply part Terminal block for module power supply and FG (2-piece spring
clamp terminal block)
Applicable wire size For power supply Stranded wire: 0.3 to 1.5(22 to 16 AWG), terminal slot size:
2.4mm 1.5mm
Applicable solderless
terminal
Terminal block for module
power supply and FG
*4
Page 35 Wiring of Terminal Block for Module Power Supply and
FG
Module power supply
*5
Voltage 24VDC (ripple rate: 5% or less) (Allowable voltage range: 20.4 to
28.8VDC)
Current 310mA
Weight 0.26kg

2 SPECIFICATIONS
2.3 Ethernet Communication Specifications
17
2
2.3 Ethernet Communication Specifications
The following table shows the Ethernet communication specifications for the NZ2GN-GFB.
CC-Link IE TSN
*1 The data transmission speed can be switched by using the communication speed setting function.
*2 For the maximum segment length (length between switching hubs), check with the manufacturer of the switching hub to be used.
CC-Link IE Field Network
Item Description
Data transmission speed 1Gbps or 100Mbps
*1
Communication mode 1000BASE-T Full-duplex
100BASE-TX
Interface RJ45 connector (AUTO MDI/MDI-X)
Maximum frame size 1518 bytes
Maximum segment length 100m
*2
Number of cascade connections 1000BASE-T Check with the manufacturer of the switching hub to be used.
100BASE-TX
IP version IPv4
Item Description
Data transmission speed 1Gbps
Communication mode 1000BASE-T Full-duplex
Interface RJ45 connector (AUTO MDI/MDI-X)
Maximum segment length 100m (complies with ANSI/TIA/EIA-568-B (Category 5e))
Number of cascade connections Maximum 20 modules

18
2 SPECIFICATIONS
2.4 Function List
2.4 Function List
The following table shows the functions of the NZ2GN-GFB. For details on these functions, refer to the following.
Page 68 FUNCTIONS
Cyclic transmission
This function allows periodic data communications among stations on the network using link devices.
Transient transmission
Data communication can be performed at any time.
RAS
RAS stands for Reliability, Availability, and Serviceability. This function improves overall usability of automated equipment.
Item Description Reference
Communications using RX,
RY, RWr, and RWw
Allows I/O data to be exchanged in units of bits and in units of words between the master
station and another station.
Page 68 Communications
using RX, RY, RWr, and
RWw
I/O maintenance settings Sets whether to hold or clear the data to be transmitted from CC-Link IE TSN to CC-Link IE
Field Network or vice versa, when an error occurs in the NZ2GN-GFB or the CC-Link IE TSN
master station.
Page 73 I/O maintenance
settings
Cyclic transmission stop and
restart
Allows users to select a CC-Link IE Field Network connected station and stop the cyclic
transmission during debugging and other operations. (Data will not be received from a device
station nor transmitted from own station.) Also, the stopped cyclic transmission is restarted.
Page 77 Cyclic transmission
stop and restart
Item Description Reference
Communications using a
dedicated instruction
Data communication is performed with the NZ2GN-GFB using dedicated instructions at any
time.
Relay can also be performed across CC-Link IE TSN and CC-Link IE Field Network.
Page 78 Communications
using a dedicated instruction
Communications using the
SLMP
Data communication is performed with the NZ2GN-GFB using SLMP.
Relay can also be performed across CC-Link IE TSN and CC-Link IE Field Network.
Page 85 Communications
using the SLMP
Communications using an
engineering tool
CC-Link IE TSN and CC-Link IE Field Network stations can be accessed seamlessly with the
NZ2GN-GFB as a relay using an engineering tool.
Page 86 Communications
using the engineering tool
Item Description Reference
Module power supply
voltage drop detection
function
Detects a voltage drop of the module power supply. Page 88 Module power
supply voltage drop detection
Device station disconnection The data link of the CC-Link IE Field Network device station where an error occurred is
stopped, and the data link continues only for stations that are operating normally.
Page 89 Device station
disconnection
Automatic return The data link is automatically restarted when the CC-Link IE Field Network device station that
was disconnected due to an error becomes normal again.
Page 89 Automatic return
Master station duplication
detection
If one network has multiple CC-Link IE Field Network master stations, an overlap error is
detected.
Page 90 Master station
duplication detection
Station number duplication
detection
If one network has CC-Link IE Field Network device stations with the same station number, a
duplication error is detected.
Page 91 Station number
duplication detection
