Mitsubishi Electric RD81RC96-CA User manual

Mitsubishi Electric Programmable Controller
Camera Recorder Module RD81RC96-CA
Sample Screen Manual
Mitsubishi Electric Corporation

2/59
BCN-P5999-1333-2a
Using the Samples
The samplescreendata and filessuchas theinstruction manualcan be used upon agreement to thefollowing matters.
(1) This data is available for use by customers currently using or considering use of Mitsubishi
Electric products.
(2) The intellectual property rights of the files provided by Mitsubishi Electric (hereinafter referred to
as the "Files") belong to Mitsubishi Electric.
(3) Alteration, reproduction, transfer, or sales of the Files is prohibited.
This does not apply when the content, in part or full, is used for Mitsubishi Electric products
incorporated in a device or system created by the customer. Furthermore, this does not apply to
the transfer, reproduction, reference, or change of layout in the specifications, designs, or
instruction manuals of built-in products prepared by the customer using Mitsubishi Electric
products.
(4) Mitsubishi Electric will not be held liable for any damages resulting from the use of the Files or
the data extracted from the Files. The customer is responsible for all use.
(5) If any usage conditions are appended to the Files, those conditions must be observed.
(6) The Files may be deleted, or the contents changed without prior notice.
(7) When using the Files, please always read the corresponding manuals and related manuals
indicated therein. Please pay special attention to safety, and correctly handle the product.
■Reference document
Manual
Control No.
Revised
MELSEC iQ-R SYSTEM RECORDER USER'S MANUAL
(STARTUP)
SH-082279ENG
July 2021
MELSEC iQ-R System Recorder User's Manual
(Application)
SH-082281ENG
July 2021
MELSEC iQ-R システムレコーダユーザーズマニュアル(ス
タートアップ編)
SH-082278
July 2021
MELSEC iQ-R システムレコーダユーザーズマニュアル(応
用編)
SH-082280
July 2021
MELSEC iQ-R 系统记录用户手册(入门篇)
SH-082282CHN
July 2021
MELSEC iQ-R 系统记录用户手册(应用篇)
SH-082285CHN
July 2021

3/59
BCN-P5999-1333-2a
CONTENTS
REVISIONS..................................................................................................................................................................5
1. OUTLINE ..............................................................................................................................................................6
2. SYSTEM CONFIGURATION ................................................................................................................................6
2.1 Supported GOT .............................................................................................................................................6
2.2 Necessary Equipment ...................................................................................................................................6
2.3 Connection Configuration ..............................................................................................................................7
3. PROJECT SPECIFICATION .................................................................................................................................8
3.1 System Application ........................................................................................................................................8
3.2 Controller Setting...........................................................................................................................................8
3.3 GOT Ethernet Setting ....................................................................................................................................9
3.4 FTP Server Setting ........................................................................................................................................9
3.5 Graphics Mode (Graphics Setting) ..............................................................................................................18
3.6 Data Type of Screen Switching Device........................................................................................................18
3.7 Device List...................................................................................................................................................19
GOT Internal Devices ..........................................................................................................................19
Label (GT Desinger3) ..........................................................................................................................20
3.8 Comment.....................................................................................................................................................21
3.9 Script ...........................................................................................................................................................22
4. PLC SIDE SETTING (GX WORKS3) ..................................................................................................................23
4.1 Setting of Camera Recorder Module ...........................................................................................................23
5. SCREEN SPECIFICATIONS ..............................................................................................................................24
5.1 Screen Specifications ..................................................................................................................................24
Common Items of Each Screen...........................................................................................................24
Controller Selection (B-32001).............................................................................................................25
Live Feed Settings (B-32002)..............................................................................................................26
Live Feed (B-32003)............................................................................................................................28
Preset Position List (B-32004).............................................................................................................30
Connection Error Notification (B-32005) ..............................................................................................31
Option Settings (B-32006) ...................................................................................................................32
System Alarm (GOT) (B-32007)...........................................................................................................33
6. UTILIZE SAMPLE SCREEN...............................................................................................................................34
6.1 Checks Before Utilization.............................................................................................................................35
6.2 Utilization Procedure ...................................................................................................................................36
How to Open the Sample Screen Installed to GT Designer3...............................................................37
Preparation before Utilization...............................................................................................................38
Utilize Project.......................................................................................................................................39
6.3 Works after Utilization..................................................................................................................................41
Settings of Labels (GT Designer3).......................................................................................................41
GOT Environmental Setting.................................................................................................................42
Precautions for Screen Switching........................................................................................................44
7. CUSTOMIZE.......................................................................................................................................................45
7.1 How to Change Resolution..........................................................................................................................45
7.2 Changing the Communication Settings of PLCs from CH1 in [Controller Setting] .......................................46
7.3 How to Change Network No. and Station No. of PLCs................................................................................48
7.4 Changes of I/O Assignment of the Camera Recorder Module.....................................................................50
7.5 How to Change the Number of FTP Clients.................................................................................................51

4/59
BCN-P5999-1333-2a
7.6 IP Address Setting of the PC .......................................................................................................................52
7.7 How to Change to Ethernet Module Connection..........................................................................................53
Controller Setting of the GOT ..............................................................................................................53
PLC Side Setting (GX Works3)............................................................................................................54
7.8 Procedure for Changing the Timeout Time ..................................................................................................55
8. TROUBLESHOOTING........................................................................................................................................56
8.1 Troubleshooting Related to GOTs................................................................................................................56
8.2 Troubleshooting Related to PLCs ................................................................................................................57
9. PRECAUTIONS..................................................................................................................................................58
10. TRADEMARKS...................................................................................................................................................59

5/59
BCN-P5999-1333-2a
REVISIONS
■Sample Screen Manual
Date
Control No.*
Description
2021/1
BCN-P5999-1333
First edition
2021/4
BCN-P5999-1333-1a
The default value of the number of FTP clients has been changed to 4.
2021/7
BCN-P5999-1333-2
Simple setting mode of network cameras is supported.
The explanations are added to 2 of 3.4. FTP Server Setting.
2021/8
BCN-P5999-1333-2a
7.8 Procedure for Changing the Timeout Time has been added.
The countermeasure is added to No.8 of 8.2 Troubleshooting Related
to PLCs.
* The control No. is noted at the lower right of each page.
■Project Data
Date
Project Data
GT Designer3*
Description
2021/1
MITSUBISHI_RD81RC96-CA_X_Ver1_E.GTX
MITSUBISHI_RD81RC96-CA_V_Ver1_E.GTX
SGT_MITSUBISHI_RD81RC96-CA_X_Ver1_E.GTX
SGT_MITSUBISHI_RD81RC96-CA_F_Ver1_E.GTX
1.245F
First edition
2021/4
MITSUBISHI_RD81RC96-CA_X_Ver1a_E.GTX
MITSUBISHI_RD81RC96-CA_V_Ver1a_E.GTX
SGT_MITSUBISHI_RD81RC96-CA_X_Ver1a_E.GTX
SGT_MITSUBISHI_RD81RC96-CA_F_Ver1a_E.GTX
1.250L
The default value of the
number of FTP clients has
been changed to 4.
2021/7
MITSUBISHI_RD81RC96-CA_X_Ver2_E.GTX
MITSUBISHI_RD81RC96-CA_V_Ver2_E.GTX
SGT_MITSUBISHI_RD81RC96-CA_X_Ver2_E.GTX
SGT_MITSUBISHI_RD81RC96-CA_F_Ver2_E.GTX
1.255R
Simple setting mode is
supported.
The explanations are
added to 2 of 3.4. FTP
Server Setting.
2021/8
MITSUBISHI_RD81RC96-CA_X_Ver2a_E.GTX
MITSUBISHI_RD81RC96-CA_V_Ver2a_E.GTX
SGT_MITSUBISHI_RD81RC96-CA_X_Ver2a_E.GTX
SGT_MITSUBISHI_RD81RC96-CA_F_Ver2a_E.GTX
1.260W
The timeout time to start
live feed has been
changed.
The symbols of the script
parts have been added.
* The version number of screen design software used to create the project data is listed. Please use the screen
design software with the listed version or later versions.
* GOT Graphic Ver.2 is used as graphics setting.

6/59
BCN-P5999-1333-2a
1. OUTLINE
This manual explains the sample screens of GOT2000 connected to MELSEC iQ-R series camera recorder module
RD81RC96-CA used for live feed, PTZ control and preset function of the network camera video.
The sample screens make startup of equipment easier because they enable you to adjust shooting range of the
network camera by the GOT.
Please refer to the following table for the version of the used sample project data.
Version of the
sample screen
Description
Version of the camera
recorder module
Version of GX Works3
Ver1
First edition
Ver:01
1.072A
Ver2
Simple setting mode of
network cameras is
supported.
Ver:03
1.077F
2. SYSTEM CONFIGURATION
2.1 Supported GOT
Supported GOTs in this sample screen are as below.
・GT27 model
・GT25 model
・GT SoftGOT2000
・MELIPC MI3000
Resolution of video is different for each sample project data as below.
Please use a network camera that supports the resolution of the video.
Resolution of sample project data
Resolution of video
VGA
QVGA
XGA and GT SoftGOT (1024×631)
VGA
GT SoftGOT (1920×960)
SVGA
When using this sample screen in a GOT whose resolution is other than above, please refer to "7.1 How to Change
Resolution".
2.2 Necessary Equipment
Necessary equipment to use this sample screen is as below.
■When using GT27 model or GT25 model
Equipment
Application
Remarks
Battery (GT11-50BAT)
・Clock data
Equipped with the GOT as standard.
■When using GT SoftGOT2000
Equipment
Application
Remarks
GT SoftGOT2000
license key
・LicenseauthenticationofGT SoftGOT2000
-
■When using MELIPC MI3000
No necessary equipment.
For the network cameras can be used in this sample screen, please refer to "Applicable Products for Camera Recorder
Module" (FA-A-0326).
To check if live feed can be used in the sample screen or not, please check the "GOT linkage function" column. For
PTZ control, please check the "Camera adjustment function (PTZ)" column.

7/59
BCN-P5999-1333-2a
2.3 Connection Configuration
Connection configuration supported by this sample screen is as below.
⇒(1) CPU built-in Ethernet connection (default setting)
⇒(2) Ethernet module connection
(1) CPU built-in Ethernet connection (default setting)
In this sample screen, the settings are performed based on the system configuration below. This is an example when
using a GOT whose resolution is VGA.
*1: For details on the cable, please refer to the manual below.
⇒"GOT2000 Series Connection Manual (Mitsubishi Electric Products)"
*2: The maximum number of network cameras can be connected to one camera recorder module is 4.
For details, please refer to "MELSEC iQ-R System Recorder User's Manual (Startup)".
For the network cameras can be connected, please refer to "Applicable Products for Camera Recorder
Module" (FA-A-0326).
(2) Connection via Ethernet module
This is an example when using a GOT whose resolution is VGA.
For how to change the connection configuration, please refer to "7.7 How to Change to Ethernet Module Connection".
*1: For details on the cable, please refer to the manual below.
⇒"GOT2000 Series Connection Manual (Mitsubishi Electric Products)"
*2: The maximum number of network cameras can be connected to one camera recorder module is 4.
For details, please refer to MELSEC iQ-R System Recorder User's Manual (Startup).
For the network cameras can be connected, please refer to "Applicable Products for Camera Recorder
Module" (FA-A-0326).
R base module
Ethernet cable *1
GOT2000
・GT27**-V(640×480)
・Interface:
Standard I/F(Ethernet)
RCPU
Hub
RD81RC96-CA
Network
camera *2
R base module
Ethernet cable *1
GOT2000
・GT27**-V(640×480)
・Interface:
Standard I/F(Ethernet)
RCPU
Hub
RD81RC96-CA
Network
camera *2
Ethernet
module
RD81RC96-CA
RD81RC96-CA

8/59
BCN-P5999-1333-2a
3. PROJECT SPECIFICATION
3.1 System Application
Type
System Application Name
Standard Function
Standard System Application
Standard Font
Japanese
Communication Driver
Ethernet Connection
Ethernet (MITSUBISHI ELECTRIC), Gateway
Extended Function
Standard Font
Chinese (Simplified)
Outline Font
Gothic
Alphanumeric/Kana
Japanese Kanji
Chinese (Simplified) Kanji
Key Window Design Information
KANA KANJI(JPN)
Gateway
FTP Server
3.2 Controller Setting
■Setting for Each Channel
CH
Item
Set Value
Remarks
CH1
Manufacturer
MITSUBISHI ELECTRIC
Controller
Type
MELSECiQ-R,RnMT/NC/RT,CR800-D
I/F
Ethernet: Multi
CH2
None
CH3
None
CH4
None
■CH1 Detail Setting
Item
Set Value
Remarks
GOT NET No.
1
GOT Station
18
GOT Communication Port No.
5001
Retry (Times)
3
Startup Time (Sec)
3
Timeout Time (Sec)
3
Delay Time (ms)
0
CPU No. switching GD device first No. (3 points)
500
ModuleNo.switchingGDdevicefirstNo.(16points)
550
Servo axis switching GD device first No. (16 points)
10
■CH1 Connected Ethernet Controller Setting
Host
Net No.
Station
Unit Type
IP Address
Port No.
Communication
1
*
1
1
RCPU
192.168.3.39
5006
UDP

9/59
BCN-P5999-1333-2a
3.3 GOT Ethernet Setting
■GOT IP Address Setting
Port
Item
Set Value
Remarks
Standard Port
Update GOTEthernetStandard Portsetting
Checked
GOT IP Address
192.168.3.18
Subnet Mask
255.255.255.0
Extended Port
None
Wireless LAN
None
■GOT Ethernet Common Setting
Item
Set Value
Remarks
Default Gateway
0.0.0.0
Peripheral S/W Communication Port No.
5015
Transparent Port No.
5014
3.4 FTP Server Setting
1. When using GT27 model and GT25 model
■FTP Server Setting
Item
Set Value
Remarks
Use the function of FTP Server
Checked
Command Input Observation Cycle
15 (min)
*1
Login Name
GOT2000
*1
Password
GOT2000
*1
*1: Change the settings in accordance with the usage environment.

10/59
BCN-P5999-1333-2a
2. How to perform the setting of FTP server of GT SoftGOT2000 and MELIPC MI3000 (Windows10)
(1) Installation of IIS
Go to "Control Panel" - "Programs and Features" to select "Turn Windows features on or off", and check the
following items of "Internet Information Services".
Item
Set Value
Remarks
FTP Server
-
FTP Extensibility
Check
FTP Service
Check
Web Management Tools
-
IIS 6 Management Compatibility
Check all
IIS Management Console
Check
IIS Management Service
Check
(2) Setting after installing IIS
Go to "Control Panel" - "Windows Firewall" - "Advanced settings" to select "Inbound Rules" and enable the
items below.
Item
Set Value
Remarks
FTP Server (FTP Traffic-in)
Yes (Enabled)
FTP Server Passive (FTP Passive Traffic-in)
Yes (Enabled)
FTP Server Secure (FTP SSL Traffic-in)
Yes (Enabled)

11/59
BCN-P5999-1333-2a
(3) Restart of FTP Service
Go to "Control Panel" - "Administrative Tools" to select "Services" and restart the service from "Microsoft FTP
Service".
(4) Folder creation of FTP site
Create any folder (Example: C/inetpub/ftproot) or open "Install folder/MELSOFT/SGT2000/Multi/00001/Drive"
(*1) to create the "V" folder.
*1 For folders in "Install folder/MELSOFT", there is a possibility that access authorities given when installing
MELSOFT products are not given. Therefore, the process in (10) needs to be performed everytime the
product is installed.
When avoiding this situation, please set FTP site to a folder that is out of "Install folder/MELSOFT", and
perform the settings of (11) in GT SoftGOT2000.

12/59
BCN-P5999-1333-2a
(5) Setting of FTP site
Go to "Control Panel" - "Administrative Tools" to select "Internet Information Services (IIS) Manager".
Right-click "Sites" to select "Add FTP site".
(6) Site Information
Set "ftp (user-defined name)" in FTP site name and the folder created in (4) (Example: C/inetpub/ftproot or
Install folder/MELSOFT/SGT2000/Multi/00001/Drive/V) in Physical path. *1
*1: This is the folder for starting GT SoftGOT2000 with the module No.1. When starting it with the module No.2,
change "00001" of the folder to "00002". The folder of "00002" is created when starting the module No.2.
*When changing Physical path from the above folder, in the settings of (11), go to "Set"- "Environment Setup"
in GT SoftGOT2000 and change Path of V Drive in Virtual Drive Setting as well.
computer name
computer name

13/59
BCN-P5999-1333-2a
(7) Binding and SSL setting
Set "21 (cannot be changed)" to Port in Binding and "No SSL" to SSL.
(8) Authentication and Authorization information
Check "Basic" in Authentication and set "All users" to Allow access to in Authorization. Check "Read" and
"Write" in Permissions.

14/59
BCN-P5999-1333-2a
(9) Addition of FTP user
Right-click "Start" to open "Computer Management" in the menu.
Then, click "System Tools" - "Local Users and Groups" - "Users".
Select "Action" in the menu bar - "New User", and then input User name and Password. After that, click
"Create".
* Perform the same setting as the setting of module extended parameter in "4.1 Setting of Camera Recorder Module".
Select Groups to select and double-click "IIS_IUSRS".
Click "Add" after IIS_IUSRS Properties screen opens.

15/59
BCN-P5999-1333-2a
Click "Locations".
Select the computer name for registering the user.
Input "(User name set in (9) Addition of FTP user)" to "Enter the object names to select" and then click "Check
Names" to check the name is determined. After the check, click "OK".
Click "Apply" - "OK".
Apply
computer name
computer name
computer name

16/59
BCN-P5999-1333-2a
(10) Authority setting of file storage location
Right-click the physical path set in (6) Site Information (Example: C/inetpub/ftproot or Install
folder/MELSOFT/SGT2000/Multi/00001/Drive/V) and click "Properties" to open "Security" tab and then click "Edit".
Click "Add".
Select the location and then input "User name set in (9) Addition of FTP user". After that, click "Check Names" and
then "OK".
computer name

17/59
BCN-P5999-1333-2a
Check "Full control" in Permissions and then click "OK".
(11) Change of the virtual V drive folder of GT SoftGOT2000
[Only when setting FTP site to a folder other than "Install folder/MELSOFT/SGT2000/Multi/00001/Drive/V]
Start GT SoftGOT2000 and open "Set"- "Environment Setup" to set Path of V Drive in Virtual Drive Setting to
the physical path set in (6) Site Information (Example: C¥inetpub¥ftproot).
(12) Restart of PC
After the settings, restart the PC to complete.
After completing the FTP server settings, set the IP address of the PC in sample project.
(Refer to 7.6 IP Address Setting of the PC)
ftpUSER (MEIA8858/ftpUSER)
ftpUSER
(MEIA8858/ftpUSER)
computer name

18/59
BCN-P5999-1333-2a
3.5 Graphics Mode (Graphics Setting)
GOT Graphic Ver.2 is used as graphics setting.
3.6 Data Type of Screen Switching Device
Data type of screen switching device is BIN.

19/59
BCN-P5999-1333-2a
3.7 Device List
Some of the devices set to the on-screen switches and lamps, etc., are also used for common settings of functions
such as scripts. Using [Batch Edit] is recommended to change these devices in a batch. For the details on [Batch
Edit], please refer to "GT Designer3 (GOT2000) Screen Design Manual".
GOT Internal Devices
■GB Devices (Unchangeable)
Type
Device No.
Application
Bit
GB40
Script trigger (Always ON)
■GB Devices (Changeable)
Type
Device No.
Application
Bit
GB34100 to GB34198
Used in the camera recorder module sample screen.
■GD Devices (Changeable)
Type
Device No.
Application
Word
GD30000 to GD30098
Used in the sample screen common label (GT Designer3).
GD34100 to GD34385
Used in the camera recorder module sample screen.
GD42000 to GD43978
Used in the camera recorder module sample screen.
GD62998 to GD62999
Used in the sample screen common label (GT Designer3).
GD65297 to GD65305
Used in the camera recorder module sample screen.
■GS Devices (Unchangeable)
Type
Device No.
Application
Bit
GS512.b0
Changed time information
Word
GS513 to GS516
Changed time
GS650 to GS652
Current time
Double word
GS194 to GS195
Ethernet port 2 GOT IP address
GS198 to GS199
Ethernet port 1 GOT IP address
■Script Parts Temporary Device Area *1
Type
Device No.
Application
Word
PTMP800 toPTMP996
Used for script operation
*1 A PTMP is a local variable that is accessible by the scripts of each script parts object.

20/59
BCN-P5999-1333-2a
Label (GT Desinger3)
■Label group No.200 Com_Label
Label name
Data type
Assigned (Device)
Default value
Application
GT_b_Com_TrigScrKeepLng
Bit
GB30000
Script trigger for language
holding
GT_b_Com_TrigScrSetTim
Bit
GB30001
Script trigger for clock
setting at startup
GT_b_Com_AlmComSetConvTrig
Bit
GB30002
Alarm common setting
conversion trigger device
GT_b_Com_AlmSetConvNtcDv
Bit
GB30003
Notification device during
alarm setting conversion
GT_b_Com_String
Bit
GB30004
CTRL input Kana String
GT_b_Com_MenuTabCTRL
Bit
GB30005
CTRL disp Menu tab
GT_u16_Com_CngBsDv
Unsigned BIN16
GD30000
Screen switching device
Base Screen
GT_u16_Com_CngOvrRpDv1
Unsigned BIN16 [0..2]
GD30001
Screen switching device
Overlap 1
GT_u16_Com_CngOvrRpDv2
Unsigned BIN16 [0..2]
GD30004
Screen switching device
Overlap 2
GT_u16_Com_CngOvrRpDv3
Unsigned BIN16 [0..2]
GD30007
Screen switching device
Overlap 3
GT_u16_Com_CngOvrRpDv4
Unsigned BIN16 [0..2]
GD30010
Screen switching device
Overlap 4
GT_u16_Com_CngOvrRpDv5
Unsigned BIN16 [0..2]
GD30013
Screen switching device
Overlap 5
GT_u16_Com_CngSprInpsDv1
Unsigned BIN16
GD30016
Screen switching device
Superimpose 1
GT_u16_Com_CngSprInpsDv2
Unsigned BIN16
GD30017
Screen switching device
Superimpose 2
GT_u16_Com_CngDlgDv
Unsigned BIN16
GD30018
Screen switching device
Dialog window
GT_s16_Com_CngLngDv
Signed BIN16
GD62998
Language switching
device
GT_s16_Com_CngSytmLanDv
Signed BIN16
GD62999
System language
switching device
GT_s16_Com_StmInfRd
Signed BIN16
GD30031
System information
System signal 1-1
GT_s16_Com_StmInfWt
Signed BIN16
GD30041
System information
System signal 2-1
GT_s16_Com_StmInfWt_GOTErr
Signed BIN16
GD30042
System information
System signal GOT Error
GT_u16_Com_SetTim
Unsigned BIN16 [0..9]
GD30060
For clock setting screen
GT_u16_Com_DocIDNum
Unsigned BIN16
GD30080
Document display-ID
GT_u16_Com_DocPageNum
Unsigned BIN16
GD30081
Document display-
Page No.
GT_u16_Com_DocStNtcDspDv
Unsigned BIN16
GD30082
Document display-
Status display notification
device
GT_u16_Com_DocEndPageNum
Unsigned BIN16
GD30083
Document display-
Last page No. notification
device
Label name
Data type
Assigned (Device)
Default value
Application
