Mitsubishi Electric MELSEC-QS Series User manual

CC-Link Safety System Remote I/O Module
User's Manual

A- 1
SAFETY PRECAUTIONS
(Always read these instructions before using this equipment.)
Before using the product, please read this manual, the relevant manuals introduced in this manual,
standard programmable controller manuals, and the safety standards carefully and pay full attention to
safety to handle the product correctly.
In this manual, the safety instructions are ranked as " WARNING" and " CAUTION".
Note that the CAUTION level may lead to a serious consequence according to the circumstances.
Always follow the instructions of both levels because they are important to personal safety.
Please save this manual to make it accessible when required and always forward it to the end user.
WARNING
CAUTION
Indicates that incorrect handling may cause hazardous conditions,
resulting in death or severe injury.
Indicates that incorrect handling may cause hazardous conditions,
resulting in minor or moderate injury or property damage.

A- 2
[Design Precautions]
WARNING
When a safety programmable controller detects an error in an external power supply or a failure in
programmable controller main module, it turns off all the outputs.
Create an external circuit to securely stop the power of hazard by turning off the outputs.
Incorrect configuration may result in an accident.
Create short current protection for a safety relay, and a protection circuit such as a fuse, and
breaker, outside a safety programmable controller.
If load current more than the rating or overcurrent due to a short circuit in the load has flowed in the
CC-Link Safety remote I/O module, the module defines it as a fault and turns off all the outputs.
However, if overcurrent flows in the CC-Link Safety remote I/O module for a long time, it may cause
smoke or a fire. To prevent it, create a safety circuit such as a fuse outside the module.
When a safety remote I/O module has detected CC-Link Safety error, it turns off all the outputs.
Note that the outputs in a sequence program are not automatically turned off.
If CC-Link Safety error has been detected, create a sequence program that turns off the outputs in
the program.
If the CC-Link Safety is restored with the outputs on, it may suddenly operate and result in an
accident.
To inhibit restart without manual operation after safety functions was performed and outputs were
turned OFF, create an interlock program which uses a reset button for restart.

A- 3
[Design Precautions]
[Installation Precautions]
[Wiring Precautions]
CAUTION
Do not bunch the wires of external devices or communication cables together with the main circuit or
power lines, or install them close to each other.
They should be installed 100 mm (3.94 inch) or more from each other.
Not doing so could result in noise that would cause malfunctions.
Select the external devices to be connected to the CC-Link Safety remote I/O module, considering
the maximum inrush current with reference to the CC-Link Safety System Remote I/O Module User's
Manual.
CAUTION
Use a safety programmable controller in the environment that meets the general specifications
described in the QSCPU User's Manual (Hardware Design, Maintenance and Inspection).
Using this programmable controller in an environment outside the range of the general specifications
could result in electric shock, fire, erroneous operation, and damage to or deterioration of the
product.
Make sure to fix CC-Link Safety remote I/O module with a DIN rail or mounting screws and tighten
the screws with the specified torque.
If the screws are too loose, it may cause a drop of the screw or module.
Overtightening may cause a drop due to the damage of the screw or module.
Do not directly touch the module's conductive parts or electronic components.
Doing so may cause malfunctions or a failure.
WARNING
Be sure to shut off all phases of the external supply power used by the system before wiring.
Not completely turning off all power could result in electric shock or damage to the product.
When energizing or operating the module after installation or wiring, be sure to close the attached
terminal cover.
Not doing so may result in electric shock.

A- 4
[Wiring Precautions]
CAUTION
Individually ground the FG and LG terminals of the programmable controller with a ground
resistance of 100or less. Failure to so may result in electric shock or malfunction.
Wire the module correctly after confirming the rated voltage and terminal layout.
Connecting a power supply of a different rated voltage or incorrect wiring may cause a fire or failure.
Tighten a terminal block mounting screw, terminal screw, and module mounting screw within the
specified torque range.
If the terminal block mounting screw or terminal screw is too loose, it may cause a short circuit, fire,
or malfunctions.
If too tight, it may damage the screw and/or the module, resulting in a drop of the screw or module, a
short circuit or malfunctions.
If the module mounting screw is too loose, it may cause a drop of the screw or module.
Overtightening the screw may cause a drop due to the damage of the screw or module.
Do not install the control lines or communication cables together with the main circuit lines or power
cables. Failure to do so may result in malfunction due to noise.
Be sure there are no foreign substances such as sawdust or wiring debris inside the module.Such
debris could cause a fire, failure, or malfunctions.
Be sure to fix the communication cables or power cables by ducts or clamps when connecting them
to the module.
Failure to do so may cause damage of the module or cables due to a wobble, unintentional shifting,
or accidental pull of the cables, or malfunctions due to poor contact of the cable.
When removing the connected communication cables or power cables, do not pull the cable with
grasping the cable part.
Remove the cable connected to the terminal block after loosening the terminal block screws.
Pulling the cable connected to a module may result in malfunctions or damage of the module or
cable.

A- 5
[Startup and Maintenance precautions]
[Disposal Precautions]
WARNING
Do not touch the terminals while power is on.
Doing so could result in electric shock.
Turn off all phases of the external supply power used in the system when cleaning the module or
retightening the terminal block mounting screws, terminal screws, or module mounting screws.
Not doing so could result in electric shock.
Tighten a terminal block mounting screw, terminal screw, and module mounting screw within the
specified torque range.
If the terminal block mounting screw or terminal screw is too loose, it may cause a short circuit, fire,
or malfunctions.
If too tight, it may damage the screw and/or the module, resulting in a drop of the screw or module, a
short circuit or malfunctions.
If the module mounting screw is too loose, it may cause a drop of the screw or module.
Overtightening the screw may cause a drop due to the damage of the screw or module.
CAUTION
Do not disassemble or modify the modules.
Doing so could cause a failure, malfunctions, injury, or fire.
If the product is repaired or remodeled by other than the specified FA centers or us, the warranty is
not covered.
Restrict the mounting/removal of a module, base unit, and terminal block up to 50 times
(IEC61131-2-compliant), after the first use of the product.
Failure to do so may cause the module to malfunction due to poor contact of connector.
Since the module case is made of resin, do not drop or apply any strong impact to the module.
Doing so may damage the module.
Completely turn off the externally supplied power used in the system before mounting or removing
the module to/from the panel.
Not doing so may result in a failure or malfunctions of the module.
CAUTION
When disposing of this product, treat it as industrial waste.

A- 6
CONDITIONS OF USE FOR THE PRODUCT
(1) Although MELCO has obtained the certification for Product's compliance to the international safety
standards IEC61508, EN954-1/ISO13849-1 from TUV Rheinland, this fact does not guarantee that
Product will be free from any malfunction or failure. The user of this Product shall comply with any
and all applicable safety standard, regulation or law and take appropriate safety measures for the
system in which the Product is installed or used and shall take the second or third safety measures
other than the Product. MELCO is not liable for damages that could have been prevented by
compliance with any applicable safety standard, regulation or law.
(2) MELCO prohibits the use of Products with or in any application involving, and MELCO shall not be
liable for a default, a liability for defect warranty, a quality assurance, negligence or other tort and a
product liability in these applications.
(a) power plants,
(b) trains, railway systems, airplanes, airline operations, other transportation systems,
(c) hospitals, medical care, dialysis and life support facilities or equipment,
(d) amusement equipments,
(e) incineration and fuel devices,
(f) handling of nuclear or hazardous materials or chemicals,
(g) mining and drilling,
(h) and other applications where the level of risk to human life, health or property are elevated.

A- 7
REVISIONS
*The manual number is given on the bottom left of the back cover.
Print Date *Manual Number Revision
Sep., 2006 SH(NA)-080612ENG-A First edition
May, 2007 SH(NA)-080612ENG-B
Section 3.2, 4.5, 6.3, 6.4, 6.5.4, 6.5.5, 6.6, 9.2.7, 9.4, 9.5
Apr., 2008 SH(NA)-080612ENG-C
QS0J65BTS2-8D, QS0J65BTS2-4T
GENERIC TERMS AND ABBREVIATIONS, PACKING LIST, Section 2.1, 2.2,
Chapter3, Section 3.1, 3.2, 3.3, 4.1, 4.2, Chapter5, Section 5.1, 5.2.1, 6.3, 9.5,
Appendix 1
Section 6.5.4
Sep., 2008 SH(NA)-080612ENG-D
Compliance with the EMC Directive and Low Voltage Directive,
Section 2.2, Section 4.5, Chapter5, Section 6.4, 6.5.4, 6.6
Appendix 2
Jul., 2009 SH(NA)-080612ENG-E
Section 2.2, 3.2.3, 6.1.1, 6.2.1, 6.3, 6.5.5, 8.1, 8.2, 9.2.3, 9.5
Nov., 2009 SH(NA)-080612ENG-F Revision because of the support of module technical version C by the
QS0J65BTB2-12DT
SAFETY PRECAUTIONS, Chapter5, Section 5.1, 5.2.1, 6.2.1, Chapter8,
Appendix 2.1
Jun., 2010 SH(NA)-080612ENG-G
SAFETY PRECAUTIONS, Section 3.1, 6.5.6
CONDITIONS OF USE FOR THE PRODUCT, Section 1.1, 2.4
Apr., 2011 SH(NA)-080612ENG-H Revision because of the support of module technical version B by the
QS0J65BTS2-8D and QS0J65BTS2-4T
Revision because of the support of module technical version D by the
QS0J65BTB2-12DT
SAFETY PRECAUTIONS, Section 3.2.1, 3.2.3, 3.3, 4.2, 5.1, 5.2.1, 5.2.2, 9.5,
Appendix 2.2
Appendix 2.1, Appendix 2.3
Appendix 2.1 Appendix 2.2
Correction
Model addition
Correction
Addition
Correction
Addition
Correction
Correction
Correction
Addition
Correction
Addition
Change

A- 8
*The manual number is given on the bottom left of the back cover.
Japanese Manual Version SH-080609-K
© 2006 MITSUBISHI ELECTRIC CORPORATION
Print Date *Manual Number Revision
Aug., 2011 SH(NA)-080612ENG-I
Section 3.1, 3.2.1, 3.2.2, 9.5
May, 2012 SH(NA)-080612ENG-J
SAFETY PRECAUTIONS, COMPLIANCE WITH THE EMC, LOW VOLTAGE,
AND MACHINERY DIRECTIVES, Section 3.1, 3.2.1, 3.2.3, 3.3, 4.1, 4.2, 4.3,
Chapter 5, Section 5.1, 5.2.1, 5.2.2, 6.5.6, 9.3, 9.4, 9.5, Appendix 2.1, 2.2
October, 2018 SH(NA)-080612ENG-K
Section 2.3, 3.2.3, 5.2.1, 6.3, 9.5, Appendix 1
This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses.
Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may
occur as a result of using the contents noted in this manual.
Correction
Correction
Correction

A- 9
SAFETY PRECAUTIONS ................................................................................................................................. A - 1
CONDITIONS OF USE FOR THE PRODUCT..................................................................................................A - 6
REVISIONS.......................................................................................................................................................A - 7
INTRODUCTION...............................................................................................................................................A - 9
CONTENTS ......................................................................................................................................................A - 9
ABOUT MANUALS ......................................................................................................................................... A - 12
COMPLIANCE WITH THE EMC, LOW VOLTAGE, AND MACHINERY DIRECTIVES .................................. A - 13
GENERIC TERMS AND ABBREVIATIONS....................................................................................................A - 14
PACKING LIST ...............................................................................................................................................A - 15
CHAPTER1 OVERVIEW 1 - 1 to 1 - 2
1.1 Safety Programmable Controller Product List ................................................................................. 1 - 1
1.2 Features........................................................................................................................................... 1 - 1
CHAPTER2 SYSTEM CONFIGURATION 2 - 1 to 2 - 3
2.1 Overall Configuration ....................................................................................................................... 2 - 1
2.2 Precautions for System Configuration ............................................................................................. 2 - 2
2.3 Confirming Production Information .................................................................................................. 2 - 3
2.4 Module Replacement....................................................................................................................... 2 - 3
CHAPTER3 SPECIFICATIONS 3 - 1 to 3 - 12
3.1 General Specifications..................................................................................................................... 3 - 1
3.2 Performance Specifications ............................................................................................................. 3 - 2
3.2.1 QS0J65BTS2-8D...................................................................................................................... 3 - 2
3.2.2 QS0J65BTS2-4T ...................................................................................................................... 3 - 4
3.2.3 QS0J65BTB2-12DT.................................................................................................................. 3 - 6
3.3 I/O Signals ....................................................................................................................................... 3 - 8
3.4 Cable Specifications ...................................................................................................................... 3 - 12
CHAPTER4 FUNCTIONS 4 - 1 to 4 - 9
4.1 List of Functions............................................................................................................................... 4 - 1
4.2 Input Function .................................................................................................................................. 4 - 2
4.3 Output Function ............................................................................................................................... 4 - 5
INTRODUCTION
Thank you for purchasing the Mitsubishi Electric safety programmable controller MELSEC-QS series.
Before using the equipment, please read this manual carefully to develop full familiarity with the functions
and performance of the QS series programmable controller you have purchased, so as to ensure correct
use.
CONTENTS

A- 10
4.4 Protection Function.......................................................................................................................... 4 - 7
4.5 Error History Function ...................................................................................................................... 4 - 8
CHAPTER5 PARAMETER SETTING 5 - 1 to 5 - 20
5.1 List of Parameters............................................................................................................................ 5 - 9
5.2 Parameter Details .......................................................................................................................... 5 - 12
5.2.1 Input parameter ...................................................................................................................... 5 - 12
5.2.2 Output parameter.................................................................................................................... 5 - 18
CHAPTER6 PROCEDURES AND SETTINGS BEFORE
SYSTEM OPERATION 6 - 1 to 6 - 29
6.1 Procedures and Settings before System Operation ........................................................................ 6 - 1
6.1.1 Procedure from module installation to system operation.......................................................... 6 - 1
6.1.2 Replacement procedure of the module..................................................................................... 6 - 3
6.2 Mounting and Installation................................................................................................................. 6 - 5
6.2.1 Handling precautions ................................................................................................................ 6 - 5
6.2.2 Installation environment............................................................................................................ 6 - 7
6.3 Part Names and Settings................................................................................................................. 6 - 8
6.4 Checking Module Status (Self-Loopback Test) ............................................................................. 6 - 13
6.5 Wiring............................................................................................................................................. 6 - 15
6.5.1 Precautions for handling CC-Link dedicated cables ............................................................... 6 - 15
6.5.2 Connecting CC-Link dedicated cables.................................................................................... 6 - 15
6.5.3 Precautions for wiring module power supply .......................................................................... 6 - 15
6.5.4 Handling of spring clamp terminal block ................................................................................. 6 - 16
6.5.5 Wiring precautions with safety devices................................................................................... 6 - 19
6.5.6 Safety devices and wiring example ........................................................................................ 6 - 21
6.6 Switch Setting ................................................................................................................................ 6 - 27
CHAPTER7 PROGRAMMING 7 - 1 to 7 - 2
CHAPTER8 MAINTENANCE AND INSPECTION 8 - 1 to 8 - 4
8.1 Daily Inspection ............................................................................................................................... 8 - 2
8.2 Periodic Inspection .......................................................................................................................... 8 - 4
CHAPTER9 TROUBLESHOOTING 9 - 1 to 9 - 27
9.1 Troubleshooting Basics ................................................................................................................... 9 - 1
9.1.1 Precautions for troubleshooting ................................................................................................ 9 - 2
9.2 Troubleshooting with LEDs.............................................................................................................. 9 - 3
9.2.1 Flowchart for when the "POWER" LED does not turn on ......................................................... 9 - 4
9.2.2 Flowchart for when the "RUN" LED does not turn on ............................................................... 9 - 5
9.2.3 Flowchart for when the "ERR." LED flashes............................................................................. 9 - 6
9.2.4 Flowchart for when the "SAFETY" LED does not turn on......................................................... 9 - 7
9.2.5 Flowchart for when the "ERR." LED turns on ........................................................................... 9 - 9

A- 11
9.2.6 When the "L RUN" LED does not turn on................................................................................. 9 - 9
9.2.7 Flowchart for when the "L ERR." LED flashes........................................................................ 9 - 10
9.2.8 When the "L ERR." LED turns on ........................................................................................... 9 - 11
9.2.9 When the "SD"/"RD" LED does not turn on dimly................................................................... 9 - 11
9.3 Verifying Errors from LED Status................................................................................................... 9 - 12
9.4 Troubleshooting with GX Developer .............................................................................................. 9 - 14
9.5 Error Code List............................................................................................................................... 9 - 18
APPENDICES App - 1 to App - 6
Appendix 1 External Dimensions............................................................................................................App - 1
Appendix 2 Functions Added or Changed Due to Version Upgrade ......................................................App - 3
Appendix 2.1 QS0J65BTS2-8D upgrade..............................................................................................App - 3
Appendix 2.2 QS0J65BTB2-12DT upgrade ......................................................................................... App - 3
Appendix 2.3 When not using functions added to version upgrade module......................................... App - 5
INDEX Index - 1 to Index - 2

A- 12
ABOUT MANUALS
Before constructing or designing the safety system, be sure to read the
following manual.
The following manuals are related to this product.
If necessary, order them by quoting the details in the tables below.
REMARK
If you would like to obtain a manual individually, printed matters are available
separately. Order the manual by quoting the manual number on the table above
(model code).
Introduction manual
Manual Name Manual Number
(Model Code)
Safety Application Guide
(Sold separately)
SH-080613ENG
(13JR90)
Related manuals
Manual Name Manual Number
(Model Code)
CC-Link Safety System Master Module User's Manual QS0J61BT12
(Sold separately)
SH-080600ENG
(13JR88)
QSCPU User's Manual (Hardware Design, Maintenance and Inspection)
(Sold separately)
SH-080626ENG
(13JR92)
QSCPU User's Manual (Function Explanation, Program Fundamentals)
(Sold separately)
SH-080627ENG
(13JR93)
QSCPU Programming Manual (Common Instructions)
(Sold separately)
SH-080628ENG
(13JW01)
GX Developer Version 8 Operating Manual
(Sold separately)
SH-080373E
(13JU41)
GX Developer Version 8 Operating Manual (Safety Programmable Controller)
(Sold separately)
SH-080576ENG
(13JU53)
Explains the overview, construction method, laying and wiring examples, and application programs
of the safety-related system.
Explains the specifications, procedures and settings before system operation, parameter setting,
and troubleshooting of the QS0J61BT12 CC-Link Safety system master module.
Explains the specifications of the QSCPU, safety power supply module, safety base unit and others.
Explains the functions, programming methods, devices and others that are necessary to create
programs with the QSCPU.
Explains how to use the sequence instructions, basic instructions, application instructions, and
QSCPU dedicated instructions.
Explains the online functions of GX Developer, such as the programming, printout, monitoring, and
debugging methods.
Explains the GX Developer functions added and modified for the compatibility with the safety
programmable controller.

A- 13
COMPLIANCE WITH THE EMC, LOW VOLTAGE, AND MACHINERY DIRECTIVES
(1) Method of ensuring compliance
To ensure that Mitsubishi programmable controllers maintain EMC, Low Voltage, and
Machinery Directives when incorporated into other machinery or equipment, certain
measures may be necessary. Please refer to one of the following manuals.
• QSCPU User's Manual (Hardware Design, Maintenance and Inspection)
• Safety Guidelines
(This manual is included with the base unit.)
The CE mark on the side of the programmable controller indicates compliance with
EMC, Low Voltage, and Machinery Directives.
(2) For the product
This product complies with the EMC, Low Voltage, and Machinery Directives. Before
using this product, please read this manual, the relevant manuals, the manuals for
standard programmable controllers, and the safety standards carefully and pay full
attention to safety to handle the product correctly.
The descriptions are based on the requirements of the Directives and the harmonized
standards. However, they do not guarantee that the entire machinery constructed
according to the descriptions complies with the EMC, Low Voltage, and Machinery
Directives. The manufacture of the machinery must determine the testing method for
compliance and declare conformity to the EMC, Low Voltage, and Machinery
Directives.

A- 14
GENERIC TERMS AND ABBREVIATIONS
Unless otherwise specified, this manual uses the following generic terms
and abbreviations to explain the CC-Link Safety system remote I/O
module.
Generic Term/Abbreviation Description
QS0J65BTS2-8D Abbreviation for QS0J65BTS2-8D CC-Link Safety system remote I/O module
QS0J65BTS2-4T Abbreviation for QS0J65BTS2-4T CC-Link Safety system remote I/O module
QS0J65BTB2-12DT Abbreviation for QS0J65BTB2-12DT CC-Link Safety system remote I/O module
Safety remote I/O module Generic term for QS0J65BTS2-8D, QS0J65BTS2-4T, and QS0J65BTB2-12DT
Safety master station Station which controls the CC-Link Safety system.
One station is required per system.
Safety remote I/O station Remote station which handles only the informaion in bit unit.
Compatible with the safety-related system.
Safety remote station Another name for Safety remote I/O station.
Safety master module Another name for QS0J61BT12 CC-Link Safety system master module.
Standard remote I/O module Generic term for AJ65BTB1-16D, AJ65SBTB1-16D, AJ65BT-64AD, AJ65BT-64DAV,
AJ65BT-64DAI, and A852GOT.
SB
Link special relay (For CC-Link Safety system)
Information of the bit unit that indicates the module operation status and data link status of
the safety master station.
Represented by SB expediently.
SW
Link special register (For CC-Link Safety system)
Information of the 16-bit unit that indicates the module operation status and data link status of
the safety master station.
Represented by SW expediently.
RX
Remote input (For CC-Link Safety system)
Information which is input in bit unit from the safety remote station to the safety master
station. Represented by RX expediently.
RY
Remote output (For CC-Link Safety system)
Information which is output in bit unit from the safety master station to the safety remote
station. Represented by RY expediently.
Safety CPU module Abbreviation for QS001CPU safety CPU module.
Safety programmable
controller
Generic term for safety CPU module, safety power supply module, safety main base unit,
CC-Link safety master module and CC-Link safety remote I/O module.
Standard programmable
controller
Generic term of each module for MELSEC-Q series, MELSEC-QnA series, MELSEC-A
series and MELSEC-FX series (Used for distinction from safety programmable controller.)
GX Developer General product name for the models, SW8D5C-GPPW, SW8D5C-GPPW-A,
SW8D5C-GPPW-V and SW8D5C-GPPW-VA.
Dark test Outputs a pulse to turn OFF the input/output when it is ON, and performs the failure
diagnostics to contacts including external devices.
NC Abbreviation for normally closed contact which is normally closed, but opened when a switch
or other function is operated.
NO Abbreviation for normally open contact which is normally opened, but closed when a switch
or other function is operated.

A- 15
PACKING LIST
The following indicates the packing list of each product.
(1) QS0J65BTS2-8D
(2) QS0J65BTS2-4T
(3) QS0J65BTB2-12DT
Item Quantity
QS0J65BTS2-8D 1
CC-Link Safety System Remote I/O Module User's Manual (Hardware)QS0J65BTS2-8D 1
Item Quantity
QS0J65BTS2-4T 1
CC-Link Safety System Remote I/O Module User's Manual (Hardware)QS0J65BTS2-4T 1
Item Quantity
QS0J65BTB2-12DT 1
Holding fixtures for screw installation 2
CC-Link Safety System Remote I/O Module User's Manual (Hardware)QS0J65BTB2-12DT 1

1- 1 1.1 Safety Programmable Controller Product List
1OVERVIEW
CHAPTER1 OVERVIEW
This User's Manual describes the specifications, handling and wiring methods of the
safety remote I/O module of the CC-Link Safety system.
1.1 Safety Programmable Controller Product List
* 1: S-mark is a safety certification issued by Korea Occupational Safety and Health Agency (KOSHA).
1.2 Features
The following describes the features of the safety remote I/O module.
(1) Highest level of safety approval acquired
The safety remote I/O module has acquired certification of the highest safety level
(SIL3 of IEC 61508, Category 4 of EN 654-1, and Category 4 performance level "e" of
EN ISO 13849-1) applicable to programmable controllers.
The safety-related system with high security can be configured.
(2) Space-saving system design
Compared to the system with the safety relay, this system can be configured with a
smaller space.
(3) Improvement of wiring work efficiency
Adopting a 2-piece terminal block allows shortened wiring work hours so that incorrect
wiring can be avoided at module replacement.
In addition, multiple COM terminals avoid the necessity to add a relay terminal block.
Product Name Model Description
CC-Link Safety system
remote I/O module
QS0J65BTB2-12DT
A safety I/O module connected to external
devices. The module has eight safety input points
and four safety output points, and sends/receives
safety data to/from the safety programmable
controller over CC-Link Safety.
QS0J65BTB2-12DT-K An S-mark*1 certified CC-Link Safety system
remote I/O module
QS0J65BTS2-8D
A safety input module connected to external
devices. The module has eight safety input points
and sends/receives safety data to/from the safety
programmable controller over CC-Link Safety.
QS0J65BTS2-4T
A safety output module connected to external
devices. The module has four safety output points
and sends/receives safety data to/from the safety
programmable controller over CC-Link Safety.

1OVERVIEW
1.2 Features
1- 2
1
OVERVIEW
2
SYSTEM CONFIGURATION
3
SPECIFICATIONS
4
FUNCTIONS
5
PARAMETER SETTING
6
PROCEDURES AND SETTINGS BEFORE SYSTEM OPERATION
7
PROGRAMMING
8
MAINTENANCE AND INSPECTION
(4) Fail-safe function
When a failure occurs inside the module, the self-diagnostic function detects the
failure and turns OFF the output.
(5) Enhanced failure diagnostics
Conducting a dark test (contact fixing diagnosis) allows an error diagnostics on the
external safety devices included.
The self-diagnostic such as memory diagnostics or circuit block diagnostics is
conducted.
(6) Simple settings in parameters
Using the parameter setting screen of the programming tool allows the easier settings
for the safety remote I/O module.
(7) Improved maintenanceability at trouble occurrence
Classifying error information into major/moderate/minor allows the easier judgment of
failures/errors.
(8) Reset available for single module
When an error occurs in the module, the reset operation can be performed for the
CPU module alone without turning the power from OFF to ON.
(9) The module can be installed in six orientations
The safety remote I/O module can be installed in six different orientations.
The module can also be installed using the DIN rail.
Figure 1.1 Module installation orientation
POWER
X0 123456789ABCDEF
RUN
SAFETY
ERR.
L RUN
L ERR.
SD
RD
MITSUBISHI
MELSEC
QS0J65 BTB2-12DT
LINK
ID
STATION
NO.BAUD
RATE STATION
NAME
Y0 123
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
0
1
2
3
LINK
ID STATION
NO. BAUD
RATE STATION
NAME 0
1
2 3
6
7
4
5
2
3
0
1
E
F
C
D
A
B
8
9
POWER
X0123456789ABCDEF
RUN
SAFETY
ERR.
L RUN
L ERR.
SD
RD
MITSUBISHI
MELSEC
QS0J65BTB2-12DT
Y0 1 2 3
POWER
X0 123456789ABCDEF
RUN
SAFETY
ERR.
L RUN
L ERR.
SD
RD
MITSUBISHI
MELSEC
QS0J65 BTB2-12DT
LINK
ID
STATION
NO. BAUD
RATESTATION
NAME
Y0 123
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
0
1
2
3
0 1 2 3
4 5 6 7
8 9
A B
C D
E
F
POWER
X0123456789ABCDEF
RUN
SAFETY
ERR.
L RUN
L ERR.
SD
RD
MITSUBISHI
MELSEC
QS0J65BTB2-12DT
Y0 1 2 3
3
4
LINK
ID STATION
NO. BAUD
RATE STATION
NAME 0
1
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
3
4
1
2
0
1
2
3
4
5
6
7
8
9
A
B
C
D
E
F
3
4
1
2
Ceiling installation
Horizontal installation
Front installation

2- 1 2.1 Overall Configuration
2SYSTEM CONFIGURATION
CHAPTER2 SYSTEM CONFIGURATION
This chapter describes the system configuration, precautions for use, and applicable
devices of the safety remote I/O module.
2.1 Overall Configuration
Figure 2.1 shows the system configuration of the safety remote I/O module.
The safety remote I/O module is connected to various safety devices such as an
emergency stop or a light curtain, and the safety-related system is configured by
combining the safety remote I/O module with a safety CPU module or safety master
module.
Figure 2.1 Overall Configuration
CC-Link Safety
CC-Link Safety remote I/O station
Standard remote I/O station
Remote device station
Power supply/CPU/CC-Link Safety master module
GX Developer
(Version 8.40S or later)
Emergency stop switch Light curtain
CC-Link Safety
remote I/O station
CC-Link Safety
remote I/O station
