Mitsubishi Electric RJ72GF15-T2 User manual

MELSEC iQ-R CC-Link IE Field Network
Remote Head Module User's Manual (Startup)
-RJ72GF15-T2

1
SAFETY PRECAUTIONS
(Read these precautions before using this product.)
Before using this product, please read this manual and the relevant manuals carefully and pay full attention to safety to handle
the product correctly.
The precautions given in this manual are concerned with this product only. For the safety precautions of the programmable
controller system, refer to the MELSEC iQ-R Module Configuration Manual.
In this manual, the safety precautions are classified into two levels: " WARNING" and " CAUTION".
Under some circumstances, failure to observe the precautions given under " CAUTION" may lead to serious
consequences.
Observe the precautions of both levels because they are important for personal and system safety.
Make sure that the end users read this manual and then keep the manual in a safe place for future reference.
WARNING Indicates that incorrect handling may cause hazardous conditions, resulting in
death or severe injury.
CAUTION Indicates that incorrect handling may cause hazardous conditions, resulting in
minor or moderate injury or property damage.

2
[Design Precautions]
WARNING
●Configure safety circuits external to the programmable controller to ensure that the entire system
operates safely even when a fault occurs in the external power supply or the programmable controller.
Failure to do so may result in an accident due to an incorrect output or malfunction.
(1) Emergency stop circuits, protection circuits, and protective interlock circuits for conflicting
operations (such as forward/reverse rotations or upper/lower limit positioning) must be configured
external to the programmable controller.
(2) When the programmable controller detects an abnormal condition, it stops the operation and all
outputs are:
• Turned off if the overcurrent or overvoltage protection of the power supply module is activated.
• Held or turned off according to the parameter setting if the self-diagnostic function of the CPU
module detects an error such as a watchdog timer error.
(3) All outputs may be turned on if an error occurs in a part, such as an I/O control part, where the
CPU module cannot detect any error. To ensure safety operation in such a case, provide a safety
mechanism or a fail-safe circuit external to the programmable controller. For a fail-safe circuit
example, refer to "General Safety Requirements" in the MELSEC iQ-R Module Configuration
Manual.
(4) Outputs may remain on or off due to a failure of a component such as a relay and transistor in an
output circuit. Configure an external circuit for monitoring output signals that could cause a
serious accident.
●In an output circuit, when a load current exceeding the rated current or an overcurrent caused by a
load short-circuit flows for a long time, it may cause smoke and fire. To prevent this, configure an
external safety circuit, such as a fuse.
●Configure a circuit so that the programmable controller is turned on first and then the external power
supply. If the external power supply is turned on first, an accident may occur due to an incorrect output
or malfunction.
●For the operating status of each station after a communication failure, refer to manuals relevant to the
network. Incorrect output or malfunction due to a communication failure may result in an accident.
●When connecting an external device with a CPU module or intelligent function module to modify data
of a running programmable controller, configure an interlock circuit in the program to ensure that the
entire system will always operate safely. For other forms of control (such as program modification,
parameter change, forced output, or operating status change) of a running programmable controller,
read the relevant manuals carefully and ensure that the operation is safe before proceeding. Improper
operation may damage machines or cause accidents.
●Especially, when a remote programmable controller is controlled by an external device, immediate
action cannot be taken if a problem occurs in the programmable controller due to a communication
failure. To prevent this, configure an interlock circuit in the program, and determine corrective actions
to be taken between the external device and CPU module in case of a communication failure.
●Do not write any data to the "system area" and "write-protect area" of the buffer memory in the
module. Also, do not use any "use prohibited" signals as an output signal from the CPU module to
each module. Doing so may cause malfunction of the programmable controller system. For the
"system area", "write-protect area", and the "use prohibited" signals, refer to the user's manual for the
module used.

3
[Design Precautions]
WARNING
●If a communication cable is disconnected, the network may be unstable, resulting in a communication
failure of multiple stations. Configure an interlock circuit in the program to ensure that the entire
system will always operate safely even if communications fail. Failure to do so may result in an
accident due to an incorrect output or malfunction.
●To maintain the safety of the programmable controller system against unauthorized access from
external devices via the network, take appropriate measures. To maintain the safety against
unauthorized access via the Internet, take measures such as installing a firewall.
●Configure safety circuits external to the remote head module to ensure that the entire system
operates safely even when a fault occurs in the external power supply or the remote head module.
Failure to do so may result in an accident due to an incorrect output or malfunction.
(1) Emergency stop circuits, protection circuits, and protective interlock circuits for conflicting
operations (such as forward/reverse rotations or upper/lower limit positioning) must be configured
external to the remote head module.
(2) When the remote head module detects an abnormal condition, outputs are:
• Held or turned off according to the parameter setting of each module mounted on the main
base unit or extension base unit if the self-diagnostic function of the remote head module
detects an error such as a watchdog timer error.
(3) All outputs may be turned on if an error occurs in a part, such as an I/O control part, where the
remote head module cannot detect any error. To ensure safety operation in such a case, provide a
safety mechanism or a fail-safe circuit external to the remote head module. For a fail-safe circuit
example, refer to "General Safety Requirements" in the MELSEC iQ-R Module Configuration
Manual.
●Configure a circuit so that the remote head module is turned on first and then the external power
supply. If the external power supply is turned on first, an accident may occur due to an incorrect output
or malfunction.
●When connecting an external device with a remote head module to modify data of a running remote
head module, configure an interlock circuit in the program of the master station to ensure that the
entire system will always operate safely. For other forms of control (such as parameter change, forced
output, or operating status change) of a running remote head module, read the relevant manuals
carefully and ensure that the operation is safe before proceeding. Improper operation may damage
machines or cause accidents.
●Especially, when a remote head module is remotely controlled by an external device, immediate
action cannot be taken if a problem occurs in the remote head module due to a communication failure.
To prevent this, configure an interlock circuit in the program of the master station, and determine
corrective actions to be taken between the external device and remote head module in case of a
communication failure.
●Do not write any data to the buffer memory in the remote head module. Doing so may cause
malfunction of the programmable controller system.
●Do not write any data from the remote head module to the "system area" and "write-protect area" of
the buffer memory in each module. Also, do not use any "use prohibited" signals as an output signal
from the remote head module to each module. Doing so may cause malfunction of the programmable
controller system. For the "system area", "write-protect area", and the "use prohibited" signals, refer to
the user's manual for the module used.

4
[Design Precautions]
[Installation Precautions]
CAUTION
●Do not install the control lines or communication cables together with the main circuit lines or power
cables. Keep a distance of 100mm or more between them. Failure to do so may result in malfunction
due to noise.
●During control of an inductive load such as a lamp, heater, or solenoid valve, a large current
(approximately ten times greater than normal) may flow when the output is turned from off to on.
Therefore, use a module that has a sufficient current rating.
●After the CPU module is powered on or is reset, the time taken to enter the RUN status varies
depending on the system configuration, parameter settings, and/or program size. Design circuits so
that the entire system will always operate safely, regardless of the time.
●Do not power off the programmable controller or reset the CPU module while the settings are being
written. Doing so will make the data in the flash ROM and SD memory card undefined. The values
need to be set in the buffer memory and written to the flash ROM and SD memory card again. Doing
so also may cause malfunction or failure of the module.
●When changing the operating status of the CPU module from external devices (such as the remote
RUN/STOP functions), select "Do Not Open by Program" for "Opening Method" of "Module
Parameter". If "Open by Program" is selected, an execution of the remote STOP function causes the
communication line to close. Consequently, the CPU module cannot reopen the line, and external
devices cannot execute the remote RUN function.
●After the remote head module is powered on or is reset, the time taken to enter the RUN status varies
depending on the system configuration and/or parameter settings. Design circuits so that the entire
system will always operate safely, regardless of the time.
●Do not power off or reset the remote head module while the parameters are being written. Doing so
may cause malfunction or failure of the module.
WARNING
●Shut off the external power supply (all phases) used in the system before mounting or removing the
module. Failure to do so may result in electric shock or cause the module to fail or malfunction.

5
[Installation Precautions]
[Wiring Precautions]
CAUTION
●Use the programmable controller in an environment that meets the general specifications in the Safety
Guidelines included with the base unit. Failure to do so may result in electric shock, fire, malfunction,
or damage to or deterioration of the product.
●To mount a module, place the concave part(s) located at the bottom onto the guide(s) of the base unit,
and push in the module until the hook(s) located at the top snaps into place. Incorrect interconnection
may cause malfunction, failure, or drop of the module.
●To mount a module with no module fixing hook, place the concave part(s) located at the bottom onto
the guide(s) of the base unit, push in the module, and fix it with screw(s). Incorrect interconnection
may cause malfunction, failure, or drop of the module.
●When using the programmable controller in an environment of frequent vibrations, fix the module with
a screw.
●Tighten the screws within the specified torque range. Undertightening can cause drop of the screw,
short circuit, or malfunction. Overtightening can damage the screw and/or module, resulting in drop,
short circuit, or malfunction.
●When using an extension cable, connect it to the extension cable connector of the base unit securely.
Check the connection for looseness. Poor contact may cause malfunction.
●When using an SD memory card, fully insert it into the SD memory card slot. Check that it is inserted
completely. Poor contact may cause malfunction.
●Securely insert an extended SRAM cassette into the cassette connector of the CPU module. After
insertion, close the cassette cover and check that the cassette is inserted completely. Poor contact
may cause malfunction.
●Do not directly touch any conductive parts and electronic components of the module, SD memory
card, extended SRAM cassette, or connector. Doing so can cause malfunction or failure of the
module.
WARNING
●Shut off the external power supply (all phases) used in the system before installation and wiring.
Failure to do so may result in electric shock or cause the module to fail or malfunction.
●After installation and wiring, attach a blank cover module (RG60) to each empty slot and an included
extension connector protective cover to the unused extension cable connector before powering on the
system for operation. Failure to do so may result in electric shock.

6
[Wiring Precautions]
CAUTION
●Individually ground the FG and LG terminals of the programmable controller with a ground resistance
of 100 ohms or less. Failure to do so may result in electric shock or malfunction.
●Use applicable solderless terminals and tighten them within the specified torque range. If any spade
solderless terminal is used, it may be disconnected when the terminal screw comes loose, resulting in
failure.
●Check the rated voltage and signal layout before wiring to the module, and connect the cables
correctly. Connecting a power supply with a different voltage rating or incorrect wiring may cause fire
or failure.
●Connectors for external devices must be crimped or pressed with the tool specified by the
manufacturer, or must be correctly soldered. Incomplete connections may cause short circuit, fire, or
malfunction.
●Securely connect the connector to the module. Poor contact may cause malfunction.
●Do not install the control lines or communication cables together with the main circuit lines or power
cables. Keep a distance of 100mm or more between them. Failure to do so may result in malfunction
due to noise.
●Place the cables in a duct or clamp them. If not, dangling cable may swing or inadvertently be pulled,
resulting in damage to the module or cables or malfunction due to poor contact. Do not clamp the
extension cables with the jacket stripped. Doing so may change the characteristics of the cables,
resulting in malfunction.
●Check the interface type and correctly connect the cable. Incorrect wiring (connecting the cable to an
incorrect interface) may cause failure of the module and external device.
●Tighten the terminal screws or connector screws within the specified torque range. Undertightening
can cause drop of the screw, short circuit, fire, or malfunction. Overtightening can damage the screw
and/or module, resulting in drop, short circuit, fire, or malfunction.
●When disconnecting the cable from the module, do not pull the cable by the cable part. For the cable
with connector, hold the connector part of the cable. For the cable connected to the terminal block,
loosen the terminal screw. Pulling the cable connected to the module may result in malfunction or
damage to the module or cable.
●Prevent foreign matter such as dust or wire chips from entering the module. Such foreign matter can
cause a fire, failure, or malfunction.
●A protective film is attached to the top of the module to prevent foreign matter, such as wire chips,
from entering the module during wiring. Do not remove the film during wiring. Remove it for heat
dissipation before system operation.
●Programmable controllers must be installed in control panels. Connect the main power supply to the
power supply module in the control panel through a relay terminal block. Wiring and replacement of a
power supply module must be performed by qualified maintenance personnel with knowledge of
protection against electric shock. For wiring, refer to the MELSEC iQ-R Module Configuration Manual.
●For Ethernet cables to be used in the system, select the ones that meet the specifications in the user's
manual for the module used. If not, normal data transmission is not guaranteed.

7
[Startup and Maintenance Precautions]
[Startup and Maintenance Precautions]
WARNING
●Do not touch any terminal while power is on. Doing so will cause electric shock or malfunction.
●Correctly connect the battery connector. Do not charge, disassemble, heat, short-circuit, solder, or
throw the battery into the fire. Also, do not expose it to liquid or strong shock. Doing so will cause the
battery to produce heat, explode, ignite, or leak, resulting in injury and fire.
●Shut off the external power supply (all phases) used in the system before cleaning the module or
retightening the terminal screws, connector screws, or module fixing screws. Failure to do so may
result in electric shock.
CAUTION
●When connecting an external device with a CPU module or intelligent function module to modify data
of a running programmable controller, configure an interlock circuit in the program to ensure that the
entire system will always operate safely. For other forms of control (such as program modification,
parameter change, forced output, or operating status change) of a running programmable controller,
read the relevant manuals carefully and ensure that the operation is safe before proceeding. Improper
operation may damage machines or cause accidents.
●Especially, when a remote programmable controller is controlled by an external device, immediate
action cannot be taken if a problem occurs in the programmable controller due to a communication
failure. To prevent this, configure an interlock circuit in the program, and determine corrective actions
to be taken between the external device and CPU module in case of a communication failure.
●Do not disassemble or modify the modules. Doing so may cause failure, malfunction, injury, or a fire.
●Use any radio communication device such as a cellular phone or PHS (Personal Handy-phone
System) more than 25cm away in all directions from the programmable controller. Failure to do so
may cause malfunction.
●Shut off the external power supply (all phases) used in the system before mounting or removing the
module. Failure to do so may cause the module to fail or malfunction.
●Tighten the screws within the specified torque range. Undertightening can cause drop of the
component or wire, short circuit, or malfunction. Overtightening can damage the screw and/or module,
resulting in drop, short circuit, or malfunction.
●After the first use of the product, do not mount/remove the module to/from the base unit, and the
terminal block to/from the module, and do not insert/remove the extended SRAM cassette to/from the
CPU module more than 50 times (IEC 61131-2 compliant) respectively. Exceeding the limit may cause
malfunction.
●After the first use of the product, do not insert/remove the SD memory card to/from the CPU module
more than 500 times. Exceeding the limit may cause malfunction.
●Do not touch the metal terminals on the back side of the SD memory card. Doing so may cause
malfunction or failure of the module.
●Do not touch the integrated circuits on the circuit board of an extended SRAM cassette. Doing so may
cause malfunction or failure of the module.
●Do not drop or apply shock to the battery to be installed in the module. Doing so may damage the
battery, causing the battery fluid to leak inside the battery. If the battery is dropped or any shock is
applied to it, dispose of it without using.

8
[Startup and Maintenance Precautions]
[Operating Precautions]
[Disposal Precautions]
CAUTION
●Startup and maintenance of a control panel must be performed by qualified maintenance personnel
with knowledge of protection against electric shock. Lock the control panel so that only qualified
maintenance personnel can operate it.
●Before handling the module, touch a conducting object such as a grounded metal to discharge the
static electricity from the human body. Failure to do so may cause the module to fail or malfunction.
●When connecting an external device with a remote head module to modify data of a running
programmable controller, configure an interlock circuit in the program of the master station to ensure
that the entire system will always operate safely. For other forms of control (such as parameter
change, forced output, or operating status change) of a running remote head module, read the
relevant manuals carefully and ensure that the operation is safe before proceeding. Improper
operation may damage machines or cause accidents.
●Especially, when a remote head module is remotely controlled by an external device, immediate
action cannot be taken if a problem occurs in the remote head module due to a communication failure.
To prevent this, configure an interlock circuit in the program of the master station, and determine
corrective actions to be taken between the external device and remote head module in case of a
communication failure.
CAUTION
●When changing data and operating status, and modifying program of the running programmable
controller from an external device such as a personal computer connected to an intelligent function
module, read relevant manuals carefully and ensure the safety before operation. Incorrect change or
modification may cause system malfunction, damage to the machines, or accidents.
●Do not power off the programmable controller or reset the CPU module while the setting values in the
buffer memory are being written to the flash ROM in the module. Doing so will make the data in the
flash ROM undefined. The values need to be set in the buffer memory and written to the flash ROM
again. Doing so can cause malfunction or failure of the module.
CAUTION
●When disposing of this product, treat it as industrial waste.
●When disposing of batteries, separate them from other wastes according to the local regulations. For
details on battery regulations in EU member states, refer to the MELSEC iQ-R Module Configuration
Manual.

9
[Transportation Precautions]
CAUTION
●When transporting lithium batteries, follow the transportation regulations. For details on the regulated
models, refer to the MELSEC iQ-R Module Configuration Manual.
●The halogens (such as fluorine, chlorine, bromine, and iodine), which are contained in a fumigant
used for disinfection and pest control of wood packaging materials, may cause failure of the product.
Prevent the entry of fumigant residues into the product or consider other methods (such as heat
treatment) instead of fumigation. The disinfection and pest control measures must be applied to
unprocessed raw wood.

10
CONDITIONS OF USE FOR THE PRODUCT
(1) Mitsubishi programmable controller ("the PRODUCT") shall be used in conditions;
i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major or serious accident;
and
ii) where the backup and fail-safe function are systematically or automatically provided outside of the PRODUCT for the
case of any problem, fault or failure occurring in the PRODUCT.
(2) The PRODUCT has been designed and manufactured for the purpose of being used in general industries.
MITSUBISHI SHALL HAVE NO RESPONSIBILITY OR LIABILITY (INCLUDING, BUT NOT LIMITED TO ANY AND ALL
RESPONSIBILITY OR LIABILITY BASED ON CONTRACT, WARRANTY, TORT, PRODUCT LIABILITY) FOR ANY
INJURY OR DEATH TO PERSONS OR LOSS OR DAMAGE TO PROPERTY CAUSED BY the PRODUCT THAT ARE
OPERATED OR USED IN APPLICATION NOT INTENDED OR EXCLUDED BY INSTRUCTIONS, PRECAUTIONS, OR
WARNING CONTAINED IN MITSUBISHI'S USER, INSTRUCTION AND/OR SAFETY MANUALS, TECHNICAL
BULLETINS AND GUIDELINES FOR the PRODUCT.
("Prohibited Application")
Prohibited Applications include, but not limited to, the use of the PRODUCT in;
• Nuclear Power Plants and any other power plants operated by Power companies, and/or any other cases in which the
public could be affected if any problem or fault occurs in the PRODUCT.
• Railway companies or Public service purposes, and/or any other cases in which establishment of a special quality
assurance system is required by the Purchaser or End User.
• Aircraft or Aerospace, Medical applications, Train equipment, transport equipment such as Elevator and Escalator,
Incineration and Fuel devices, Vehicles, Manned transportation, Equipment for Recreation and Amusement, and
Safety devices, handling of Nuclear or Hazardous Materials or Chemicals, Mining and Drilling, and/or other
applications where there is a significant risk of injury to the public or property.
Notwithstanding the above, restrictions Mitsubishi may in its sole discretion, authorize use of the PRODUCT in one or
more of the Prohibited Applications, provided that the usage of the PRODUCT is limited only for the specific
applications agreed to by Mitsubishi and provided further that no special quality assurance or fail-safe, redundant or
other safety features which exceed the general specifications of the PRODUCTs are required. For details, please
contact the Mitsubishi representative in your region.

11
INTRODUCTION
Thank you for purchasing the Mitsubishi Electric MELSEC iQ-R series programmable controllers.
This manual describes the specifications, procedures before operation, system configuration, wiring, and communication
examples of the relevant product listed below.
Before using this product, please read this manual and the relevant manuals carefully and develop familiarity with the
functions and performance of the MELSEC iQ-R series programmable controller to handle the product correctly.
When applying the program examples provided in this manual to an actual system, ensure the applicability and confirm that it
will not cause system control problems.
Please make sure that the end users read this manual.
Relevant product
RJ72GF15-T2

12
COMPLIANCE WITH EMC AND LOW VOLTAGE
DIRECTIVES
Method of ensuring compliance
To ensure that Mitsubishi Electric programmable controllers maintain EMC and Low Voltage Directives when incorporated into
other machinery or equipment, certain measures may be necessary. Please refer to one of the following manuals.
• MELSEC iQ-R Module Configuration Manual
• Safety Guidelines (This manual is included with the base unit.)
The CE mark on the side of the programmable controller indicates compliance with EMC and Low Voltage Directives.
Additional measures
To ensure that this product maintains EMC and Low Voltage Directives, please refer to one of the following manuals.
• MELSEC iQ-R Module Configuration Manual
• Safety Guidelines (This manual is included with the base unit.)

13
CONTENTS
CONTENTS
SAFETY PRECAUTIONS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .1
CONDITIONS OF USE FOR THE PRODUCT . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
INTRODUCTION. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 11
COMPLIANCE WITH EMC AND LOW VOLTAGE DIRECTIVES . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .12
RELEVANT MANUALS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .14
TERMS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .15
CHAPTER 1 PART NAMES 17
CHAPTER 2 PERFORMANCE SPECIFICATIONS 20
CHAPTER 3 FUNCTION LIST 22
CHAPTER 4 PROCEDURES BEFORE OPERATION 24
4.1 Creating a Project . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.2 Connecting a Personal Computer . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25
4.3 Initializing the Remote Head Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.4 Setting Parameters . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 26
4.5 Writing to the Remote Head Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
4.6 Resetting the Remote Head Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 28
CHAPTER 5 SYSTEM CONFIGURATION 29
CHAPTER 6 WIRING 31
CHAPTER 7 COMMUNICATION EXAMPLES 33
7.1 System Configuration Example . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 33
7.2 Setting in the Master Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 36
7.3 Setting the Intelligent Device Station . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 39
7.4 Checking the Network Status. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
7.5 Program Examples . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 42
APPENDIX 46
Appendix 1 External Dimensions . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 46
INDEX 48
REVISIONS. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .50
WARRANTY . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .51
TRADEMARKS . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .52

14
RELEVANT MANUALS
This manual does not include detailed information on the following:
• General specifications
• Applicable combinations of the remote head module and the other modules, and the number of mountable modules
• Installation
For details, refer to the following.
MELSEC iQ-R Module Configuration Manual
e-Manual refers to the Mitsubishi Electric FA electronic book manuals that can be browsed using a dedicated
tool.
e-Manual has the following features:
• Required information can be cross-searched in multiple manuals.
• Other manuals can be accessed from the links in the manual.
• The hardware specifications of each part can be found from the product figures.
• Pages that users often browse can be bookmarked.
• Sample programs can be copied to an engineering tool.
Manual name [manual number] Description Available form
MELSEC iQ-R CC-Link IE Field Network Remote Head
Module User's Manual (Startup)
[SH-081614ENG] (this manual)
Specifications, procedures before operation, system configuration,
wiring, and communication examples of the CC-Link IE Field Network
remote head module
Print book
e-Manual
PDF
MELSEC iQ-R CC-Link IE Field Network Remote Head
Module User's Manual (Application)
[SH-081616ENG]
Functions, parameter settings, and troubleshooting of the CC-Link IE
Field Network remote head module
Print book
e-Manual
PDF

15
TERMS
Unless otherwise specified, this manual uses the following terms.
Term Description
Base unit A generic term for main base units, extension base units, and RQ extension base units
Buffer memory Memory in an intelligent function module for storing data such as setting values and monitored values.
Control system A system that controls a redundant system and performs network communications in a redundant
system
CPU module A generic term for the MELSEC iQ-R series, MELSEC-Q series, and MELSEC-QS series CPU modules
Cyclic transmission A function by which data are periodically exchanged among stations on the same network using link
devices
Data link A generic term for cyclic transmission and transient transmission
Dedicated instruction An instruction for using the functions of a module
Device A device (X, Y, W, or others) in a CPU module and remote head module
Disconnection A process of stopping data link if a data link error occurs
Engineering tool The product name of the software package for the MELSEC programmable controllers
Global label A label that is valid for all the program data when multiple program data are created in the project.
There are two types of global label: a module specific label (module label), which is generated
automatically by the engineering tool, and an optional label, which can be created for any specified
device.
I/O module A generic term for the input module, output module, I/O combined module, and interrupt module
Intelligent device station A station that exchanges I/O signals (bit data) and I/O data (word data) with another station by cyclic
transmission. This station responds to a transient transmission request from another station and also
issues a transient transmission request to another station.
Intelligent function module A module that has functions other than input and output, such as an A/D converter module and D/A
converter module
Label A label that represents a device in a given character string
Link device A device (RX, RY, RWr, or RWw) in a module on CC-Link IE Field Network
Link special register (SW) Word data that indicates the operating status and data link status of a module on CC-Link IE Field
Network
Link special relay (SB) Bit data that indicates the operating status and data link status of a module on CC-Link IE Field Network
Local station A station that performs cyclic transmission and transient transmission with the master station and other
local stations
Master station A station that controls the entire network. This station can perform cyclic transmission and transient
transmission with all stations. Only one master station can be used in a network.
Master/local module A generic term for the RJ71GF11-T2, QJ71GF11-T2, QS0J71GF11-T2, LJ71GF11-T2 CC-Link IE Field
Network master/local module and the following modules when the CC-Link IE Field Network function is
used:
• RJ71EN71
• RnENCPU
Module label A label that represents one of memory areas (I/O signals and buffer memory areas) specific to each
module in a given character string. For the module used, GX Works3 automatically generates this label,
which can be used as a global label.
RAS The abbreviation for Reliability, Availability, and Serviceability. This term refers to the overall usability of
automated equipment.
Redundant system A system consisting of two systems that have same configuration (CPU module, power supply module,
network module, and other modules). Even after an error occurs in one of the two system, the other
system takes over the control of the entire system. For details, refer to "Redundant System" of the
following manual.
MELSEC iQ-R Module Configuration Manual
Remote device station A station that exchanges I/O signals (bit data) and I/O data (word data) with another station by cyclic
transmission. This station responds to a transient transmission request from another station.
Remote head module The abbreviation for the RJ72GF15-T2 CC-Link IE Field Network remote head module
Remote I/O station A station that exchanges I/O signals (bit data) with the master station by cyclic transmission
Remote input (RX) Bit data input from a slave station to the master station (For some areas in a local station, data are input
in the opposite direction.)
Remote output (RY) Bit data output from the master station to a slave station (For some areas in a local station, data are
output in the opposite direction.)
Remote register (RWr) Word data input from a slave station to the master station (For some areas in a local station, data are
input in the opposite direction.)

16
Remote register (RWw) Word data output from the master station to a slave station (For some areas in a local station, data are
output in the opposite direction.)
SIL2 function module Another name for the R6PSFM.
This module is used with the SIL2 Process CPU as a pair and performs safety control. The module can
only be paired with the SIL2 Process CPU.
SIL2 Process CPU A generic term for the R08PSFCPU, R16PSFCPU, R32PSFCPU, and R120PSFCPU.
This module is used with a SIL2 function module as a pair, and performs both standard control and
safety control. This module is also used with a redundant function module as a pair and configures a
redundant system.
SIL2 mode An operation mode of the I/O module and the intelligent function module to perform safety input and
output at the SIL2 level. For details on the SIL2 mode, refer to the following.
Manuals for the I/O module or the intelligent function module used
Slave station A generic term for a local station, remote I/O station, remote device station, and intelligent device
station
Standby system A backup system in a redundant system
System switching A function which switches the systems between the control system and the standby system to continue
operation of the redundant system when a failure or an error occurs in the control system
Transient transmission A function of communication with another station, which is used when requested by a dedicated
instruction or the engineering tool
Term Description

1 PART NAMES
17
1
1PART NAMES
This chapter describes the part names of the remote head module.
No. Name Description
(1) RUN LED Indicates the operating status of the CPU module and the error level.
●RUN LEDERR LED status
Onoff: Normal operation
Onon: Minor error
Onflashing: Moderate error
Flashing (every 2s)off: Initial processing
Flashing (every 400ms)off: Module communication test in progress or changing module online
Flashing (every 400ms)on: Minor error (Module communication test in progress or changing module
online)
Offon/flashing: Major error
For troubleshooting using LED when an error occurs, refer to the following.
MELSEC iQ-R CC-Link IE Field Network Remote Head Module User's Manual (Application)
(2) ERR LED
(3) BUS RUN LED Indicates the operating status of the module.
On: RUN state
Off: STOP state
The module will be in the STOP state by the following:
• The switch of the remote head module is set to STOP.
• The master station is in the STOP state. (When the remote head module is connected to the master
station)*6
• Remote STOP
• A moderate error or major error was detected in the remote head module (except when "Continue" is
selected in "Remote head Module Operation Setting at Error Detection" under "RAS Setting" of "CPU
Parameter").
(9)
(2)
(6)
(7)
(8)
(1)
(3)
(4)
(5)
(11)
(10)
(15)
(12)
(13)
(14)

18 1 PART NAMES
(4) CTRL LED*1 Indicates the status of the control system when the remote head module is redundant. (Always off when
the module is not redundant.)
On: Operating as the control system (system switching enabled state)
Flashing: Operating as the control system (system switching disabled state)
Off: Not operating as a control system
(5) SBY LED*1 Indicates the status of the standby system and memory copy when the remote head module is redundant.
(Always off when the module is not redundant.)
On: Operating as a standby system
Flashing: Memory copy being performed
Off: Not operating as a standby system and memory copy not performed
(6) D LINK LED*1 Indicates the data link status.
On: Data link (cyclic transmission being performed)
Flashing: Data link (cyclic transmission stopped)
Off: Data link not performed (disconnection)
(7) SD/RD LED Indicates the data sending/receiving status.
On: Data being sent or received
Off: Data not sent nor received
(8) L ERR LED*1 Indicates the error status of receive data and line. When the L ERR LED is on, the port in which the error
was detected can be checked with the L ER LED of P1 or P2.
On: Abnormal data received or loopback being performed
Off: Normal data received and loopback not performed
(9) Dot matrix LED Indicates the station number set in the module and the module communication test result.
Station number not set: ""
When station number is set: 1 to 120
In offline mode: ""
For indication of the module communication test result, refer to the following.
MELSEC iQ-R CC-Link IE Field Network Remote Head Module User's Manual (Application)
(10) Switch*2 RESET/TEST Resets the remote head module or switches it to module communication test mode.
• Reset method
Hold the switch in the RESET/TEST position for a second.
• Module communication test method
Refer to the following.
MELSEC iQ-R CC-Link IE Field Network Remote Head Module User's Manual (Application)
STOP*3 Sets the remote head module to the STOP state.
When the module is in the STOP state, all output (Y) points of the remote head module turn off.
Set the module to the STOP state in the following cases:
• To stop the cyclic transmission with the master station and temporarily separate the remote head
module from the system for changeover of CC-Link IE Field system
• To perform a debug operation between modules connected to the remote head module and external
devices
• To write parameters to the remote head module
The following shows an example of a debug method with external devices using the STOP switch.
(1) Set the switch to STOP.
(2) Data transfer is stopped between the link devices of the remote head module and the devices in the
remote head module, and the devices are separated from the master station control.
(3) Perform an input/output test between the module connected to the remote head module and the
external device. Since the data transfer is stopped, the input/output status data are not sent to the
master or local station.
(4) Upon completion of the test, data are written to the remote head module and the system operation
starts.
RUN Sets the remote head module to the RUN state.*5
In the RUN state, the data transfer is started between the link devices (cyclic data from the master station)
of the remote head module and the devices in the remote head module.
Also, the output from the master station is output from the module connected to the remote head module.
The input from the module connected to the remote head module is input to the master station.
(11) USB port*4 A connector for a USB-compatible peripheral (Connector type: miniB)
(12) Ethernet port (P1) PORT1 connector for CC-Link IE Field Network. Connect an Ethernet cable.
For wiring methods and wiring precautions, refer to the following.
(Page 31 WIRING)
L ER LED Indicates the port status.
On: Abnormal data received or loopback being performed
Off: Normal data received and loopback not performed
LINK LED Indicates the link status.
On: Link-up
Off: Link-down
No. Name Description
