Mitsubishi Electric Q12DCCPU-V User manual

C Controller Module User's Manual
(Hardware Design, Function Explanation)
-Q12DCCPU-V(Basic mode)
-Q06CCPU-V
-Q06CCPU-V-B
-SW3PVC-CCPU-E

A- 1
SAFETY PRECAUTIONS
(Read these precautions before using this product.)
Before using this product, please read this manual and the relevant manuals carefully and pay full attention
to safety to handle the product correctly.
The precautions given in this manual are concerned with this product only. For the safety precautions of the
programmable controller system, refer to the user's manual for the CPU module used.
In this manual, the safety precautions are classified into two levels: " WARNING" and " CAUTION".
Under some circumstances, failure to observe the precautions under " CAUTION" may lead to serious
consequences.
Observe the precautions of both levels because they are important for personal and system safety.
Make sure that the end users read this manual and then keep the manual in a safe place for future
reference.
[Design Precautions]
WARNING
Configure safety circuits external to the C Controller module to ensure that the entire system
operates safely even when a fault occurs in the external power supply or the C Controller module.
Failure to do so may result in an accident due to an incorrect output or malfunction.
(1) Configure external safety circuits, such as an emergency stop circuit, protection circuit, and
protective interlock circuit for forward/reverse operation or upper/lower limit positioning.
(2) If the following status (a) or (b) occurs, the system will behave accordingly.
(a) When overcurrent or overvoltage protection of the power supply module is activated, the
outputs (Y) from the user program and writing to the buffer memory are disabled, and all
outputs are turned off.
(b) When the C Controller module detects an error such as a watchdog timer error by the self-
diagnostic function, the outputs (Y) from the user program and writing to the buffer memory
are disabled. Whether to hold or turn off all outputs can be set by parameters.
All outputs may turn on when an error occurs in the part, such as I/O control part, where the C
Controller module cannot detect any error.
To ensure safety operation in such a case, provide a safety mechanism or a fail-safe circuit
external to the C Controller module. For a fail-safe circuit example, refer to "CHAPTER 6
PREPARATORY PROCEDURES AND SETTING" in this manual.
WARNING
CAUTION
Indicates that incorrect handling may cause hazardous conditions,
resulting in death or severe injury.
Indicates that incorrect handling may cause hazardous conditions,
resulting in minor or moderate injury or property damage.

A- 2
[Design Precautions]
WARNING
(3) Outputs may remain on or off due to a failure of an output module relay or transistor.
Configure an external circuit for monitoring output signals that could cause a serious accident.
In an output module, when a load current exceeding the rated current or an overcurrent caused by a
load short-circuit flows for a long time, it may cause smoke and fire. To prevent this, configure an
external safety circuit, such as a fuse.
Configure a circuit so that the C Controller system is turned on first and then the external power
supply. If the external power supply is turned on first, an accident may occur due to an incorrect
output or malfunction.
For the operating status of each station after a communication failure, refer to the relevant manuals
for the network.
Incorrect output or malfunction may result in an accident.
For the following controls, configure an interlock circuit in the user program to ensure that the entire
system will always operate safely.
(1) Changing data of a running C Controller module from the development environment (personal
computer) connected
(2) Changing the operating status
(3) Operation from the development environment (personal computer)
Especially, in the case of a control from an external device to a remote C Controller module,
immediate action cannot be taken for a problem on the C Controller module due to a communication
failure.
To prevent this, configure an interlock circuit in the user program, and determine corrective actions to
be taken between the external device and C Controller module in case of a communication failure.
To maintain the safety of the C Controller system against unauthorized access from external devices
via the network, take appropriate measures. To maintain the safety against unauthorized access via
the Internet, take measures such as installing a firewall.
When configuring the system, do not leave any slot empty on the base unit.
If a slot is to be left empty, attach a blank cover (QG60).
Failure to do so may cause internal parts of the mounted modules to fly apart during a short-circuit
test or when an excess current or voltage is applied to an external I/O part by mistake.

A- 3
[Design Precautions]
[Installation Precautions]
CAUTION
Do not install the control lines or communication cables together with the main circuit lines or power
cables.
Keep a distance of 100mm (3.94 inches) or more between them.
Failure to do so may result in malfunction due to noise.
When a device such as a lamp, heater, or solenoid valve is controlled through an output module, a
large current (approximately ten times greater than normal) may flow when the output is turned from
off to on. Take measures such as replacing the module with one having a sufficient current rating.
After the C Controller module is powered on or is reset, the time taken to enter the RUN status varies
depending on the system configuration, parameter setting, and/or program size.
Design circuits so that the entire system will always operate safely, regardless of the time.
CAUTION
Use the C Controller module in an environment that meets the general specifications in this manual.
Failure to do so may result in an electric shock, fire, malfunction, or damage to or deterioration of the
product.
To mount the module, while pressing the module mounting lever located in the lower part of the
module, fully insert the module fixing projection(s) into the hole(s) in the base unit and press the
module until it snaps into place.
Incorrect mounting may cause malfunction, failure or drop of the module.
When using the module in an environment of frequent vibrations, fix the module with a screw.
Tighten the screw within the specified torque range.
Undertightening can cause drop of the screw, short circuit or malfunction.
Overtightening can damage the screw and/or module, resulting in drop, short circuit, or malfunction.

A- 4
[Installation Precautions]
[Wiring Precautions]
CAUTION
When using an extension cable, connect it to the connector of the base unit or module securely.
Check the connection for looseness.
Poor contact may cause incorrect input or output.
When using a CompactFlash card, fully insert it into the CompactFlash card slot.
Check that it is inserted completely.
Poor contact may cause malfunction.
Shut off the external power supply for the system in all phases before mounting or removing the
module.
Failure to do so may result in damage to the product.
Do not directly touch any conductive part of the module.
Doing so can cause malfunction or failure of the module.
WARNING
Shut off the external power supply for the system in all phases before wiring.
Failure to do so may result in electric shock or damage to the product.
After wiring, attach the included terminal cover to the module before turning it on for operation.
Failure to do so may result in electric shock.

A- 5
[Wiring Precautions]
CAUTION
Ground the FG and LG terminals to the protective ground conductor dedicated to the programmable
controller.
Failure to do so may result in electric shock or malfunction.
Prevent foreign matter such as dust or wire chips from entering the module.
Such foreign matter can cause a fire, failure, or malfunction.
Check the rated voltage and terminal layout before wiring to the module, and connect the cables
correctly.
Connecting a power supply with a different voltage rating or incorrect wiring may cause a fire or
failure.
Securely connect the Ethernet and RS-232 cables to respective connectors of the C Controller
module.
Do not install the control lines or the communication cables together with the main circuit lines or
power cables.
Doing so may result in malfunction due to noise.
Tighten the terminal screw within the specified torque range.
Undertightening can cause short circuit, fire, or malfunction.
Overtightening can damage the screw and/or module, resulting in drop, short circuit, or malfunction.
Place the communication and power cables in a duct or clamp them.
If not, dangling cable may swing or inadvertently be pulled, resulting in damage to the module or
cables or malfunctions due to poor contact.
When disconnecting a communication or power cable from the module, do not hold and pull the
cable part.
Doing so may cause malfunction or damage to the module or cable.
For a cable with connector, hold the connected connector by hand to disconnect the cable.
For a screw-type cable, loosen the screw to disconnect the cable.
Do not connect outputs of multiple power supply modules in parallel.
The power supply modules may produce heat, causing a fire or failure.
Connectors for external connection must be crimped or pressed with the tool specified by the
manufacturer, or must be correctly soldered.
For the tool, refer to the user's manual for the relevant I/O module.
Incomplete connections could result in short circuit, fire or malfunction.

A- 6
[Startup and Maintenance Precautions]
WARNING
Do not touch any terminal while power is on.
Doing so will cause electric shock.
Correctly connect the battery connector.
Do not charge, disassemble, heat, short-circuit, solder, or throw the battery into the fire.
Doing so will cause the battery to produce heat, explode, or ignite, resulting in injury and fire.
Shut off the external power supply for the system in all phases before cleaning the module or
retightening the terminal screws or module fixing screws.
Failure to do so may result in electric shock.
Undertightening the terminal screws can cause short circuit or malfunction.
Overtightening can damage the screw and/or module, resulting in drop, short circuit, or malfunction.
For the following controls, configure an interlock circuit in the user program to ensure that the entire
system will always operate safely.
(1) Changing data of the running C Controller module from the development environment (personal
computer) connected
(2) Changing the operating status
(3) Operation from the development environment (personal computer)
Especially, in the case of a control from an external device to a remote C Controller module,
immediate action cannot be taken for a problem on the C Controller module due to a communication
failure.
To prevent this, configure an interlock circuit in the user program, and determine corrective actions to
be taken between the external device and C Controller module in case of a communication failure.

A- 7
[Startup and Maintenance Precautions]
CAUTION
Do not disassemble or modify the modules.
Doing so may cause failure, malfunction, injury, or a fire.
Before performing online operations (especially, program modification, forced output, and operation
status change) for the running C Controller module from the peripheral connected, read relevant
manuals carefully and ensure the safety.
Improper operation may damage machines or cause accidents.
Shut off the external power supply for the system in all phases before mounting or removing the
module.
Failure to do so may cause the module to fail or malfunction.
After the first use of the product, do not mount/remove the module to/from the base unit more than
50 times. (IEC 61131-2 compliant)
Exceeding the limit of 50 times may cause malfunction.
Use any radio communication device such as a cellular phone or PHS (Personal Handy-phone
System) more than 25cm (9.85 inches) away in all directions from the C Controller system.
Failure to do so may cause malfunction.
Do not drop or apply shock to the battery to be installed in the module.
Doing so may damage the battery, causing the battery fluid to leak inside the battery.
If the battery is dropped or any shock is applied to it, dispose of it without using.
Before handling the module, touch a grounded metal object to discharge the static electricity from
the human body.
Failure to do so may cause the module to fail or malfunction.

A- 8
[Disposal Precautions]
[Transportation Precautions]
CAUTION
When disposing of this product, treat it as industrial waste.
When disposing of batteries, separate them from other wastes according to the local regulations.
(For details of the Battery Directive in EU countries, refer to Appendix 4.)
CAUTION
When transporting lithium batteries, follow the transportation regulations. (For details of the
regulated models, refer to Appendix 3.)

A- 9
CONDITIONS OF USE FOR THE PRODUCT
(1) Mitsubishi C Controller system ("the PRODUCT") shall be used in conditions;
i) where any problem, fault or failure occurring in the PRODUCT, if any, shall not lead to any major
or serious accident; and
ii) where the backup and fail-safe function are systematically or automatically provided outside of
the PRODUCT for the case of any problem, fault or failure occurring in the PRODUCT.
(2) The PRODUCT has been designed and manufactured for the purpose of being used in general
industries.
MITSUBISHI SHALL HAVE NO RESPONSIBILITY OR LIABILITY (INCLUDING, BUT NOT
LIMITED TO ANY AND ALL RESPONSIBILITY OR LIABILITY BASED ON CONTRACT,
WARRANTY, TORT, PRODUCT LIABILITY) FOR ANY INJURY OR DEATH TO PERSONS OR
LOSS OR DAMAGE TO PROPERTY CAUSED BY the PRODUCT THAT ARE OPERATED OR
USED IN APPLICATION NOT INTENDED OR EXCLUDED BY INSTRUCTIONS, PRECAUTIONS,
OR WARNING CONTAINED IN MITSUBISHI'S USER, INSTRUCTION AND/OR SAFETY
MANUALS, TECHNICAL BULLETINS AND GUIDELINES FOR the PRODUCT.
("Prohibited Application")
Prohibited Applications include, but not limited to, the use of the PRODUCT in;
• Nuclear Power Plants and any other power plants operated by Power companies, and/or any
other cases in which the public could be affected if any problem or fault occurs in the PRODUCT.
• Railway companies or Public service purposes, and/or any other cases in which establishment of
a special quality assurance system is required by the Purchaser or End User.
• Aircraft or Aerospace, Medical applications, Train equipment, transport equipment such as
Elevator and Escalator, Incineration and Fuel devices, Vehicles, Manned transportation,
Equipment for Recreation and Amusement, and Safety devices, handling of Nuclear or
Hazardous Materials or Chemicals, Mining and Drilling, and/or other applications where there is a
significant risk of injury to the public or property.
Notwithstanding the above, restrictions Mitsubishi may in its sole discretion, authorize use of the
PRODUCT in one or more of the Prohibited Applications, provided that the usage of the PRODUCT
is limited only for the specific applications agreed to by Mitsubishi and provided further that no
special quality assurance or fail-safe, redundant or other safety features which exceed the general
specifications of the PRODUCTs are required. For details, please contact the Mitsubishi
representative in your region.

A- 10
REVISIONS
*The manual number is given on the bottom left of the back cover.
Print date *Manual number Revision
Jun., 2009 SH(NA)-080766ENG-A First edition
Jan., 2010 SH(NA)-080766ENG-B
PRECAUTIONS
Aug., 2010 SH(NA)-080766ENG-C
SAFETY PRECAUTIONS, ABOUT MANUALS, HOW TO USE THIS MANUAL,
GENERIC TERMS AND ABBREVIATIONS, GLOSSARY, Section 1.1, 2.1.3,
2.1.4, 2.2.1, 2.2.2, 2.3, 2.4, 3.2, 3.4.2, 4.1, 4.4, 4.5, 4.13, 5.2 to 5.4, 6.2, 6.11.2,
8.1.1, 8.2.2, 10.1, 11.1.4, 11.3, 13.1, 13.2, 13.6, 14.1, 15.2.4, 16.3, 16.4.1,
16.5.1, Appendix 8, Appendix 9.1, Appendix 10, Appendix 11
CONDITIONS OF USE FOR THE PRODUCT, Section 2.1.5, 4.4, 4.16, 6.8.5,
Chapter 9, Section 16.4.2, Appendix 6, Appendix 7, Appendix 9
Section 2.1.5 Section 2.1.6, Section 4.4 to 4.14 Section 4.5 to 4.15,
Chapter 9 to 15 Chapter10 to 16,
Appendix 6 to 8, Appendix7 to 8 Appendix10 to 11
Mar., 2011 SH(NA)-080766ENG-D
OPERATING PRECAUTIONS, Section 1.1, 2.1.3, 2.3, 2.4, 3.3.1, 3.3.2, 4.3.3,
4.15, 4.16, 5.3.2, 5.4.2, 6.3, 8.2.2, 16.4.1, Appendix 7, Appendix 9, Appendix 12
Appendix 10
Appendix 10 to 11 Appendix 11 to 12
Jul., 2011 SH(NA)-080766ENG-E
ABOUT MANUALS, GENERIC TERMS AND ABBREVIATIONS, Section 2.1.2,
2.1.4, 2.2.1, 2.2.2, 11.1.4
Jan., 2012 SH(NA)-080766ENG-F
Section 2.2.1, 2.2.2, 2.4, 3.1
Dec., 2012
SH(NA)-080766ENG-G
GENERIC TERMS AND ABBREVIATIONS, OPERATING PRECAUTIONS,
Section 2.2.1, 2.3, 3.2, 3.3.2, 4.5, 6.3, 6.4.1, 6.6, 10.1, 11.1, 11.2.1, 11.3, 12.1,
13.3.3, 13.3.4, 13.9, 16.2.3
Partial correction
Partial correction
Addition
Modification
Partial correction
Addition
Modification
Partial correction
Partial correction
Partial correction

A- 11
Japanese manual version SH-080764-Q
© 2009 MITSUBISHI ELECTRIC CORPORATION
Oct., 2013 SH(NA)-080766ENG-H
ABOUT MANUALS, HOW TO USE THIS MANUAL,
GENERIC TERMS AND ABBREVIATIONS, GLOSSARY, PACKING LIST,
CHAPTER 1, Section 1.1, 2.1.2, 2.2.1, 2.2.2, 2.3, 2.4, 2.5, 2.5.1, 4.14, 6.3, 6.4.1,
6.7, 6.10, 6.10.1, 6.10.2, 6.12.1, 8.2.1, 10.1, 11.1, 12.1, 13.3.1, 16.2, 16.2.2,
16.2.7, 16.2.8, 16.2.11, 16.5.1, Appendix7
PRODUCT ORGANIZATION
Appendix 11
Appendix 12 Appendix 11
Dec., 2013
SH(NA)-080766ENG-I
GENERIC TERMS AND ABBREVIATIONS, Section 10.1
Mar., 2014
SH(NA)-080766ENG-J
GENERIC TERMS AND ABBREVIATIONS, Section 11.2.1, Section 12.1,
Section 12.7, Section 13.3.2, Section 13.3.3, Section 13.3.4, Section 13.9,
Appendix11
Jul., 2014 SH(NA)-080766ENG-K ABOUT MANUALS, GENERIC TERMS AND ABBREVIATIONS, CHAPTER 1,
Section 11.1, Section 11.3
Feb., 2015 SH(NA)-080766ENG-L Section 2.2.2, Section 6.7.1
Dec., 2015
SH(NA)-080766ENG-M
PACKING LIST, Section 2.1.3, Section 2.5.1, Section 3.2, Section 6.4.1,
Appendix 2.1, WARRANTY
Jun., 2016
SH(NA)-080766ENG-N
SAFETY PRECAUTIONS, GENERIC TERMS AND ABBREVIATIONS,
Section 6.6, Section 6.11
DISCONTINUED MODELS
Oct., 2017
SH(NA)-080766ENG-O
ABOUT MANUALS, GENERIC TERMS AND ABBREVIATIONS, CHAPTER 1,
Section 6.7.1, Section 11.1, Appendix 11
This manual confers no industrial property rights or any rights of any other kind, nor does it confer any patent licenses.
Mitsubishi Electric Corporation cannot be held responsible for any problems involving industrial property rights which may
occur as a result of using the contents noted in this manual.
Print date *Manual number Revision
Partial correction
Addition
Delete
Modification
Partial correction
Partial correction
Partial correction
Partial correction
Partial correction
Partial correction
Addition
Partial correction

A- 12
OPERATING PRECAUTIONS
This section provides the following precautions.
(1) Precautions for system configurations
(a) Supported modules
In a system configuration where a C Controller module is used, some main and
extension base units cannot be used ( Page 2-16, Section 2.1.6), and also
use of some modules is restricted by their function versions ( Page 2-17,
Section 2.2).
(b) Multiple CPU system
1) Applicable CPU modules
For the CPU modules that can be used with a C Controller module in a multiple
CPU system, refer to the following.
Page 11-11, Section 11.2.1
2) MT Developer connection (Version 00Y or earlier) in a multiple CPU system
When a multiple CPU system includes a C Controller module set as CPU No.1
and a Motion CPU, a communication test of MT Developer (Version 00Y or
earlier) cannot be performed. (The Motion CPU communication test error
(error code: 12288) will occur.)
To perform the communication test from MT Developer, use either of the
following methods.
• Use MT Developer Version 00Z or later.
• When using MT Developer Version 00Y or earlier, modify the multiple
CPU system configuration so that CPU No.1 is a programmable controller
CPU.
(c) Time adjustment and time notification of GOT
In a multiple CPU system configuration, when time adjustment or time notification
is performed in a GOT connected to C Controller modules for CPU No. 2 to No. 4,
it is executed to CPU No. 1.
In this case, to match the clock data between the C Controller modules assigned
to CPU No. 2 to No. 4 and the GOT, use the multiple CPU clock synchronization
function.
Page 4-33, Section 4.7.1
(d) Connection with GX Works2/GX Developer
For the connection with GX Works2/GX Developer, refer to the following.
Page 2-29, Section 2.4 (7)
Precautions for Refer to
System configurations Page A-12
Standard RAM, standard ROM, and CompactFlash card Page A-13
Battery Page A-15
Clock setting Page A-16
Starting the C Controller module Page A-16
Network configurations Page A-17
Relation between system tasks and the system watchdog timer, user
watchdog timer, and link device refresh cycles Page A-17
For the Wind River Systems product Page A-17

A- 13
(2) Precautions for standard RAM, standard ROM, and CompactFlash card
: Available, : N/A
(a) Standard RAM formatting
1) When formatting the standard RAM
Be sure to perform the method described in the following section.
Page 6-77, Section 6.10.1 (6)
Do not format it by using a command from Workbench Shell.
2) During standard RAM formatting
Do not power off or reset the C Controller module during standard RAM
formatting.
Doing so causes the standard RAM to be formatted again when the C
Controller module is started the next time.
(b) Standard ROM formatting
1) When formatting the standard ROM
Be sure to perform the method described in the following section.
Page 6-85, Section 6.10.2 (4)
Do not format it by using a command from Tornado Shell.
2) During standard ROM formatting
Do not power off or reset the C Controller module during standard ROM
formatting.
Doing so causes the standard ROM to be formatted again when the C
Controller module is started the next time.
(c) Allowable number of writes to the standard ROM (service life)
A flash ROM is used for the standard ROM and it has a limit in the number of
writes (service life). ( Page 6-71, Section 6.9)
Table A.1 Memory availability
Memory Availability
Q12DCCPU-V Q06CCPU-V Q06CCPU-V-B
Standard RAM
Standard ROM
CompactFlash card

A- 14
(d) Allowable number of writes to a CompactFlash card (service life)
• For the live of the QD81MEM and GT05-MEM, refer to the following.
Page 6-70, Section 6.8.5
• For the live of commercially available CompactFlash cards, refer to the
specifications of each product.
(e) CompactFlash card replacement
Do not power off or reset the system or remove the CompactFlash card while
writing file data to the CompactFlash card.
Doing so can cause corruption of the CompactFlash card data or a file system
error.
• To remove a CompactFlash card during file writing:
Page 6-64, Section 6.8.2
• To power off or reset the system:
Page 8-9, Section 8.2.2
(f) File name and directory name
Use alphanumeric characters and special characters (excluding \, /, *, ?, <, >, |, :,
and ") for the names of a file and a directory stored in the following memories in
the C Controller module:
• Standard RAM
• Standard ROM
• CompactFlash card
If a file or a directory with a name including characters other than alphanumeric
characters and special characters (excluding \, /, *, ?, <, >, |, :, and ") is stored in
the memories above in the C Controller module, the following phenomena may
occur:
• Character corruption on file names and directory names
• Loss of files and directories
(g) Unmounting a CompactFlash card by the RESET/SELECT switch
1) When unmounting during access
Unmounting a CompactFlash card by the RESET/SELECT switch during file
writing to the CompactFlash card can cause corruption of the CompactFlash
card data or a file system error.
Stop the access to the CompactFlash card before removing the card.
( Page 6-64, Section 6.8.2)
2) When powering off or resetting the system
Before powering off or resetting the system, refer to the following.
Page 8-9, Section 8.2.2
3) Switch operation
If the RESET/SELECT switch is held in the RESET position by mistake, the C
Controller module will be reset.
Be careful when unmounting a CompactFlash card by operating the RESET/
SELECT switch. ( Page 6-67, Section 6.8.3)

A- 15
(3) Precautions for battery
(a) For the Q12DCCPU-V
1) About file corruption
The battery must be installed before operation.
• If the C Controller system is operated without a battery and then is
powered off or reset
The data in the standard RAM and battery-backed-up RAM may be
damaged, or a file system error may occur.
• When the battery is not replaced even after a battery error
The standard RAM or battery-backed-up RAM data or clock data may be
corrupted, or a file system error may occur.
2) Battery replacement
For battery replacement, observe the procedures described in this manual.
( Page 6-53, Section 6.7.3 (4))
(b) For the Q06CCPU-V(-B)
1) About file corruption
• When the battery is not replaced even after a battery error
The standard ROM and battery-backed-up RAM data being accessed and
clock data may be corrupted, or a file system error may occur.
• If the C Controller system is operated without a battery and then shut
down improperly
The standard ROM and battery-backed-up RAM data being accessed
may be corrupted, or a file system error may occur.
• When the procedures shown in Page 6-54, Section 6.7.4 are not observed
The standard ROM and battery-backed-up RAM data being accessed
may be corrupted, or a file system error may occur.
2) Restrictions on operations without a battery
• Powering on the system without a battery
If the C Controller system is powered on with no battery installed in the C
Controller module, the system will start with unreliable clock data.
Set clock data in this case. Otherwise, event history files and programs
using clock data cannot function properly. ( Page 6-54, Section 6.7.4)
• Operating the system without a battery
If the system was operated with no battery installed in the C Controller
module, perform the shutdown operation before powering off or resetting
the C Controller system. ( Page 6-55, Section 6.7.4 (2))
3) Battery replacement
For battery replacement, observe the procedures described in this manual.
( Page 6-53, Section 6.7.3 (4))

A- 16
(4) Precautions for clock setting
(a) Clock setting
1) Setting method
Set the clock of the C Controller module as described in Page 4-30, Section
4.7 (4) (a).
If the year 2100 is exceeded after clock setting, clock data of the year 2100
and later can be used until the C Controller module is restarted.
At the time of restart, year data of the C Controller module will be reset to those
of 2000 to 2099.
2) Condition for the setting
The clock of the C Controller module must be set with the QBF_WaitEvent and
QBF_WaitUnitEvent functions not being executed.
(5) Precautions for starting the C Controller module
(a) Time required for connection from each utility to the C Controller module
After power-on or reset, the C Controller module is ready to connect to each utility
at the following timing.
• When executing the script file, "STARTUP.CMD":
Upon completion of the RUN LED flashing
• When not executing the script file, "STARTUP.CMD":
Fifteen (15) seconds after completion of the start or reset process
Do not attempt a connection before the above timing after power-on or reset.
Changing "Priority" to a larger value in the Option tab of C Controller setting utility
increases the time after which the C Controller module can be connected.
(b) Flashing "01" or "02" of the 7-segment LED (Q12DCCPU-V only)
At start-up of the C Controller module, "01" or "02" flashes on the 7-segment LED
in the following cases.
• When the C Controller module is in factory-default state
(Because the standard RAM is not initialized)
• When the C Controller module is left unused for a long period of time with no
battery installed
(Because the standard and battery-backed-up RAM data are corrupted)
If "01" or "02" flashes on the 7-segment LED, install a battery and perform the
module initialization setting procedure. ( Page 6-77, Section 6.10.1 (6))

A- 17
(6) Precautions for network configurations
(a) Precautions for using two Ethernet channels (Q12DCCPU-V only)
When using two channels as Ethernet ports, two different network addresses
must be set for CH1 and CH2 of the C Controller module.
In the above case, a response to the message received through each channel is
sent as follows:
• Messages (including response packets such as ping) to the device having the
same network address as CH1 are sent from CH1.
• Messages (including response packets such as ping) to the device having the
same network address as CH2 are sent from CH2.
(7) Relation between system tasks and the system watchdog timer, user
watchdog timer, and link device refresh cycles
When using any of the following functions, set a sufficiently long time for each of the
system watchdog timer, user watchdog timer, and link device refresh cycles.
• Shell command
• Workbench/Tornado connection
• File access
• Mount/unmount of CompactFlash card
• Ethernet communications
• NFS server communication
If any of the above is used, CPU utilization for a system task with high priority may
increase and a system watchdog timer error, a user watchdog timer error, and link
refresh timeout may occur more frequently.
For the link refresh timeout, the rate of occurrence may also increase when bus
interface driver processing (connections with peripheral devices or communication
with an intelligent function module, etc.) is used.
(8) Precautions for the Wind River Systems product
The C Controller module has an embedded real-time operating system, VxWorks,
made and sold by Wind River Systems, Inc. in the United States.
We, Mitsubishi, make no warranty for the Wind River Systems product and will not be
liable for any problems and damages caused by the Wind River Systems product
during use of the C Controller module.
For the problems or specifications of the Wind River Systems product, refer to the
corresponding manual or consult Wind River Systems, Inc.
Contact information is available on the following website.
www.windriver.com
