Mitsubishi Electric FR-A5AX User manual

TRANSISTORIZED INVERTER
-INSTRUCTION MANUAL-
IB(NA)-66808-B (0201) MEE
TRANSISTORIZED INVERTER
Printed in Japan Specifications subject to change without notice.
HEAD OFFICE:MITSUBISHI DENKI BLDG MARUNOUCHI TOKYO 100-8310 FR-A5AX
12-BIT DIGITAL INPUT
ib66808b.book 1 ページ ２００２年２月１４日 木曜日 午後７時５８分

A-1
Thank you for choosing the Mitsubishi transistorized inverter option unit.
This instruction manual gives handling information and precautions for use of this equipment. Incorrect handling
might cause an unexpected fault. Before using the equipment, please read this manual carefully to use the equipment
to its optimum.
Please forward this manual to the end user.
1. Electric Shock Prevention
This section is specifically about safety matters
Do not attempt to install, operate, maintain or inspect this product until you have read through this instruction man-
ual and appended documents carefully and can use the equipment correctly. Do not use this product until you have
a full knowledge of the equipment, safety information and instructions.
In this instruction manual, the safety instruction levels are classified into "WARNING" and "CAUTION".
Assumes that incorrect handling may cause hazardous conditions, resulting in
death or severe injury.
Assumes that incorrect handling may cause hazardous conditions, resulting in
medium or slight injury, or may cause physical damage only.
Note that the CAUTION level may lead to a serious consequence according to conditions. Please follow the instruc-
tions of both levels because they are important to personnel safety.
SAFETY INSTRUCTIONS
!While power is on or when the inverter is running, do not open the front cover. You may get an electric shock.
!Do not run the inverter with the front cover removed. Otherwise, you may access the exposed high-voltage termi-
nals and charging part and get an electric shock.
!If power is off, do not remove the front cover except for wiring or periodic inspection. You may access the
charged inverter circuits and get an electric shock.
!Before starting wiring or inspection, switch power off, wait for more than 10 minutes, and check for no residual
voltage with a tester or the like.
WARNING
CAUTION
WARNING
ib66808b.book 1 ページ ２００２年２月１４日 木曜日 午後７時５８分

A-2
2. Injury Prevention
3. Additional instructions
Also note the following points to prevent an accidental failure, injury, electric shock, etc.:
(1) Transportation and mounting
(2) Test operation and adjustment
!Any person who is involved in the wiring or inspection of this equipment should be fully competent to do the work.
!Always install the option unit before wiring. Otherwise, you may get an electric shock or be injured.
!Handle this option unit with dry hands to prevent an electric shock.
!Do not subject the cables to scratches,excessive stress, heavy loads or pinching. Otherwise, you may get an electric shock.
!Apply only the voltage specified in the instruction manual to each terminal to prevent burst, damage, etc.
!Ensure that the cables are connected to the correct terminals. Otherwise, burst, damage, etc. may occur.
!Always make sure that polarity is correct to prevent burst, damage, etc.
!While power is on or for some time after power-off, do not touch the inverter as it is hot and you may get burnt.
!Do not install or operate the option unit if it is damaged or has parts missing.
!Do not stand or rest heavy objects on the product.
!Check that the mounting orientation is correct.
!Prevent screws, metal fragments or other conductive bodies or oil or other flammable substance from entering the inverter.
!Before starting operation, confirm and adjust the parameters. A failure to do so may cause some machines to
make unexpected motions.
WARNING
C
AUTI
O
N
C
AUTI
O
N
C
AUTI
O
N
ib66808b.book 2 ページ ２００２年２月１４日 木曜日 午後７時５８分

A-3
(3) Usage
(4) Maintenance, inspection and parts replacement
(5) Disposal
(6) General instruction
!Do not modify the equipment.
!When parameter clear or all parameter clear is performed, each parameter returns to the factory setting. Re-set
the required parameters before starting operation.
!For prevention of damage due to static electricity, touch nearby metal before touching this product to eliminate
static electricity from your body.
!Do not test the equipment with a megger (measure insulation resistance).
!Treat as industrial waste.
All illustrations given in this manual may have been drawn with covers or safety guards removed to provide in-
depth description. Before starting operation of the product, always return the covers and guards into original posi-
tions as specified and operate the equipment in accordance with the manual.
WARNING
C
AUTI
O
N
C
AUTI
O
N
C
AUTI
O
N
ib66808b.book 3 ページ ２００２年２月１４日 木曜日 午後７時５８分

CONTENTS
1.PRE-OPERATION INSTRUCTIONS 1
1.1 Unpacking and Product Confirmation..................................................................................................1
1.2 Packing Confirmation...........................................................................................................................1
1.3 Structure ..............................................................................................................................................2
2.INSTALLATION 3
2.1 Pre-Installation Instructions..................................................................................................................3
2.2 Installation Procedure..........................................................................................................................3
2.3 Wiring...................................................................................................................................................5
3.12-BIT DIGITAL INPUT 6
3.1 Wiring Examples..................................................................................................................................6
3.2 Terminals.............................................................................................................................................8
4.PARAMETERS 9
4.1 Parameter List......................................................................................................................................9
4.2 Parameter Setting..............................................................................................................................11
4.3 Instructions.........................................................................................................................................16
5.SPECIFICATIONS 18
5.1 Specifications.....................................................................................................................................18
ib66808b.book 4 ページ ２００２年２月１４日 木曜日 午後７時５８分

1
1.PRE-OPERATION INSTRUCTIONS
1.1 Unpacking and Product Confirmation
Take the option unit out of the package, check the unit name, and confirm that the product is as you
ordered and intact.
Functions arailable differ between FR-A500(L)/F500(L) series and FR-V500 series, always check before
using.
"SERIAL number check
This product may be used with the FR-A520-0.4K to 22K manufactured in and after July 1997. Any of the
models may be used with this unit if its SERIAL number indicated on the rating plate and package has
"J77######" or later version.
SERIAL is made up of 1 version symbol and 8 numeric characters indicating year, month, and control
number as shown below.
SERIAL number
1.2 Packing Confirmation
Make sure that the package includes the following
" Instruction manual.........................................................................1
" Mounting screws M3 × 10 .............................................................2
J 7 7 ######
Symbol Year Month Control number
ib66808b.book 1 ページ ２００２年２月１４日 木曜日 午後７時５８分

2
PRE-OPERATION INSTRUCTIONS
1.3 Structure
FR-A5AX
Connector
Mounting
hole
Terminal
block
screw
size M3
Terminal
symbol
Front view Mounting holes
Option fixing holes
Rear view Mounting
hole
X0 X1 X5 X6 X11
X2 X10
X7 X9 X8 DY
X3 X4
ib66808b.book 2 ページ ２００２年２月１４日 木曜日 午後７時５８分

3
2.INSTALLATION
2.1 Pre-Installation Instructions
Make sure that the input power of the inverter is off.
2.2 Installation Procedure
(1) Securely insert the connector of the option unit far into the connector of the inverter. At this time, fit the
option fixing holes snugly. For the position of slot, refer to the next page.
Also be sure to fit the unit into the option fixing hook (For the FR-A500(L)/ FR-F500(L) series, it is avail-
able in Aug., 2000).
(2) Securely fix the option unit to the inverter on both sides with the accessory mounting screws. If the
screw holes do not match, the connector may not have been plugged snugly. Checkfor loose plugging.
With input power on, do not install or remove the option unit. Otherwise, the inverter and
option unit may be damaged.
CAUTION
ib66808b.book 3 ページ ２００２年２月１４日 木曜日 午後７時５８分

4
INSTALLATION
CAUTION
1. Only one type of option per inverter may be used. When two or more options are mounted, pri-
ority is in order of slots 1, 2 and 3, the options having lower priority are inoperative.
2. When the inverter cannot recognize that the option is
mounted, it displays the option error. The errors shown
differ according to the mounting slots 1, 2, 3.
Option unit
A
ccessory screw
(2 pcs.)
Option side
connector
Inverter
(without cover)
Slot 1
Inverter side connector
Slot 2
Slot 3
Option fixing hook
The slots 1, 2, and 3 are provided
with an option fixing hook.
Mounting Position Error Display
Slot 1 E.OP1
Slot 2 E.OP2
Slot 3 E.OP3
ib66808b.book 4 ページ ２００２年２月１４日 木曜日 午後７時５８分

5
INSTALLATION
2.3 Wiring
Route the wires so that they do not take up a lot of space in the control circuit terminal block of the option unit.
During wiring, do not leave wire off-cuts in the inverter. They may cause a fault, failure or malfunction.
Use the space on the left side of the control circuit terminal unit to route the wires.
REMARKS
The wires with large gaze may not be connected to the terminal block. When connected in parallel, all wires may not
fit in the wiring space due to the increased number of wires. In such cases, perform wiring by using a junction termi-
nal block.
When installing the inverter front cover, the cables to the inverter's control circuit terminals
and option terminals should be routed properly in the wiring space to prevent them from
being caught between the inverter and its cover.
Cable routing
CAUTION
ib66808b.book 5 ページ ２００２年２月１４日 木曜日 午後７時５８分

6
3.12-BIT DIGITAL INPUT
3.1 Wiring Examples
*: Use terminals SD or PC on the inverter.
(1)Relay contact signal input (2)Open collector signal input
(For sink logic)
8
4
2
1
8
4
2
1
8
4
2
1
X11
X10
X9
X8
X7
X6
X5
X4
X3
X2
X1
X0
DY
FR-A5AX
SD * Inverter
[BCD code]
Number of 100
Number of 10
Number of 1
X11
X10
X9
X8
X7
X6
X5
X4
X3
X2
X1
X0
DY
FR-A5AX
PC *
1
2
3
4
5
6
7
8
9
10
11
12
13
14
15
19
20 Inverter
Read command
AY40 type transistor output module
Number of 100
Number of 10
Number of 1
[BCD code]
REMARKS
AY40 type unit requires 24VDC power.
ib66808b.book 6 ページ ２００２年２月１４日 木曜日 午後７時５８分

7
12-BIT DIGITAL INPUT
REMARKS
1. As the input signals are at low level, use two parallel micro signal contacts or a twin contact for relay contact
inputs to prevent a contact fault.
2. A transistor of the following specifications should be selected for the open collector signal: Electrical characteris-
tics of the transistor used
•
••
•
Ic≥
≥ ≥
≥ 10mA
•
••
•Leakage current: 100µ
µµ
µA maximum
•
••
•VCE ≥
≥ ≥
≥ 30V
•
••
•
If Ic≥
≥ ≥
≥ 10mA, VCE (sat) voltage is 3V maximum
3. The control logic is the same as that of the inverter (factory-set to sink). When the logic of the inverter is
changed to source, the option logic also switches to source. For details on changing the control logic, refer to the
inverter instruction manual.
Micro signal contancts Twin contancts
ib66808b.book 7 ページ ２００２年２月１４日 木曜日 午後７時５８分

8
12-BIT DIGITAL INPUT
3.2 Terminals
Terminal Symbol Description
X0 to X11 Digital signal input terminals (frequency/speed setting signal terminals) Used to input a 3-digit BCD (999 maximum) (refer to page 6) or 12-bit binary (FFFH maxi-
mum) relay contact or open collector signal.
DY
Data read timing input signal
Used when a digital signal read timing signal is necessary.
Data is only read while the DY signal is on.
By switching the DY signal off, the X0 to X11 data before signal-off is retained. (Refer to page
12.)
SD Common terminal (sink) Common terminal for digital and data read timing signals.
This terminal is the SD terminal of the inverter.
PC
External transistor common terminal (source)
When connecting the transistor output (open collector output) of a programmable controller
(PC), etc., connect the external power common (+) to this terminal to prevent a fault occurring
due to leakage current. When you have selected the source logic, this terminal is used as a
common terminal. This terminal is the PC terminal of the inverter.
ib66808b.book 8 ページ ２００２年２月１４日 木曜日 午後７時５８分

9
4.PARAMETERS
4.1 Parameter List
This option unit does not function if the parameter values are factory setting values. Set the following
parameter values according to the application:
4.1.1 FR-A500(L)/F500(L) Series
Parameter
Number Function name Setting
Range Factory Setting Setting Increments
300 BCD code input Bias 0 to 400Hz 0Hz 0.01Hz
301 Gain 0 to 400Hz, 9999 60Hz 0.01Hz
302 Binary input Bias 0 to 400Hz 0Hz 0.01Hz
303 Gain 0 to 400Hz, 9999 60Hz 0.01Hz
304 Selection of digital input type and analog
compensation input enable/disable 0, 1, 2, 3, 9999 9999 1
305 Data read timing signal on-off selection 0, 1 0 1
ib66808b.book 9 ページ ２００２年２月１４日 木曜日 午後７時５８分

10
PARAMETERS
4.1.2 FR-V500 Series
Parameter
Number Function name Setting Range Factory Setting Setting Increments
300 BCD code input Bias 0 to 3600r/min 0r/min 0.1r/min
301 Gain 0 to 3600r/min, 9999 1500r/min 1r/min
302 Binary input Bias 0 to 3600r/min 0r/min 0.1r/min
303 Gain 0 to 3600r/min, 9999 1500r/min 1r/min
304 Selection of digital input type and analog
compensation input enable/disable 0, 1, 2, 3, 9999 9999 1
305 Data read timing signal on-off selection 0, 1 0 1
329 Digital input unit selection 0, 1, 2 1 1
447 Digital trque command bias 0 to 400% 1% 0%
448 Digital trque command gain 0 to 400% 1% 150%
REMAKS
• For Pr.329, write is disabled during operation even when "2" is set in Pr.77. When changing the parameter setting,
stop the operation.
• Binary input. . . . . . . load input data in hexadecimal
BCD code input . . . load input data in decimal
ib66808b.book 10 ページ ２００２年２月１４日 木曜日 午後７時５８分

11
PARAMETERS
4.2 Parameter Setting
(1) Input selection [Pr.304 "Selection of digital input type and analog compensation input enable / disable." ]
You can select the digital input signal type and whether compensation for digital input by analog input
is enabled or not. When the setting is "9999" (factory setting), the 12-bit digital input is invalid.
*: The analog compensation input signal is entered across inverter 1-5. For the setting of "0"
or "1", the analog compensation input is not accepted.
Digital Input
Signal Type
Analog Compensation Input*
Compensation
disable Compensation enable
BCD code input 0 2
Binary input 1 3
ib66808b.book 11 ページ ２００２年２月１４日 木曜日 午後７時５８分

12
PARAMETERS
(2) Data read timing signal on-off selection (Pr.305)
!How to use DY signal
(3) Bias adjustment [Pr.300], [Pr.302]
Bias adjustments can be made for the digital input signal.
Set the set frequency (set speed) at the digital input of 0.
•BCD code input. . . . . . . . . Set the output frequency in Pr.300.
•Binary input. . . . . . . . . . . . Set the output frequency in Pr.302.
Pr.305 setting Description
0The set frequency data (set speed data) entered from the digital signal input terminals is always imported independently of whether the DY signal is on or off. Digital signal input directly changes
output frequency.
1
The set frequency data (set speed data) entered from the digital signal input terminals is imported
only when the DY signal is on. The set frequency data (set speed data) is not imported when the DY
signal is off. Therefore, if the input status of the X0-X11 signal changes, the set frequency data (set
speed data) before off of the DY signal is valid.
OFF ON
50ms or longer necessary
Digital signal input
(terminals X0 to X11)
Data read timing signal
(across terminals DY-SD)
1ms or longer 1ms or longer
ib66808b.book 12 ページ ２００２年２月１４日 木曜日 午後７時５８分

13
PARAMETERS
(4) Gain adjustment [Pr.301], [Pr.303]
The gain may be set in either of the following two ways:
!How to set the output frequency at the input signal of 999 (BCD code) or FFFH (binary)
(The factory setting is 60Hz (1500r/min. for the FR-V500 series) for this input signal. )
!How to set the BCD code or binary value as the output frequency (output speed) setting
When "9999" isset in Pr.301(BCD code) or Pr.303 (binary), thedigital input value is set(unchanged)
as the output frequency (output speed).
(For example, to set the output frequency to 120Hz at the BCD code input of "120")
CAUTION
The maximum output frequency (maximum operation speed) for operation with the digital input is
the "gain" value set in Pr.301 and Pr.303.
To set the maximum output frequency to 60Hz or more with the FR-A500(L)/F500(L) series and the
maximum operation speed to 1500r/min or more with the FR-V500 series, change the "gain" from
the control panel or parameter unit.
Pr.301
Pr.303
Pr.300
Pr.302
0
0999 FFFH BCD Pr.304=1,3
Pr.304=0,2
Operation speed (r/min)
Output
frequency (Hz)
Bias
Digital input signal Binary (BIN)
Gain
120
0 120
Output
frequency (Hz)
Digital input signal
(BCD)
REMAKS
When this setting method is used, "bias" setting (Pr.300 or
Pr.302) cannot be made.
ib66808b.book 13 ページ ２００２年２月１４日 木曜日 午後７時５８分

14
PARAMETERS
(5) Digital input unit selection (Pr.329) (available with the FR-V500 series only)
When "9999" is set in Pr.301(BCD code input gain) or Pr.303(binary input gain), the increment when
the digital signal is set as output speed can be set.
<Example>
Pr.329=0
BCD code = 111 →11.1r/min
binary = 100H (256 in the decimal system) →25.6r/min
Pr.329=1
BCD code = 111 →111r/min
binary = 100H (256 in the decimal system) →256r/min
Pr.329=2
BCD code = 111 →1110r/min
binary = 100H (256 in the decimal system) →2560r/min
Pr.329 setting Input Value Increments
00.1r/min
1
(factory setting) 1r/min
210r/min
REMARKS
When the values other than "9999" are set in Pr.301 or Pr.303, Pr.329 is made invalid.
ib66808b.book 14 ページ ２００２年２月１４日 木曜日 午後７時５８分

15
PARAMETERS
(6) Digital torque command (Pr.447, Pr.448) (available with the FR-V500 series only)
!When "9999" is set in Pr.304 and "4" in Pr.804 "torque command selection" (The parameter setting
can be made only when the FR-A5AX is mounted on the inverter.), digital torque command of the
FR-A5AX (12bit) is made valid.
The input signal uses 11 lower bits as torque command and the most significant bit as sign. (When
the most significant bit is 1, torque command value is negative.)
!When Pr.448 = "9999" , digital input value is torque command value.
Pr.448
07FFH
Most significant bit = 0Most significant bit = 1
7FFH
-150%
150%
Pr.447
Torque command value
Factory setting
Digital input signal
400%
07FFH
7FFH 190H
(400)
190H
(400)
-400%Most significant bit = 0Most significant bit = 1
Torque command value
Digital input signal
ib66808b.book 15 ページ ２００２年２月１４日 木曜日 午後７時５８分
