Mitsubishi PKA-RP2.5FAL Operating manual

TECHNICAL & SERVICE MANUAL
CONTENTS
1. COMBINATION OF
INDOOR AND OUTDOOR UNITS ····················2
2. SAFETY PRECAUTION····································3
3. PART NAMES AND FUNCTIONS·····················6
4. SPECIFICATIONS ·············································8
5. DATA································································14
6. OUTLINES AND DIMENSIONS ······················33
7. WIRING DIAGRAM ·········································35
8. REFRIGERANT SYSTEM DIAGRAM·············36
9. TROUBLESHOOTING·····································37
10. DISASSEMBLY PROCEDURE ·······················47
11. RoHS PARTS LIST··········································50
12. OPTIONAL PARTS··························Back Cover
Indoor unit
[Model names] [Service Ref.]
PKA-RP2.5FAL PKA-RP2.5FAL
PKA-RP3FAL PKA-RP3FAL
PKA-RP4FAL PKA-RP4FAL
Indoor unit
Wall MountedSeries PKA
No.OC301
REVISED EDITION-B
R407C/R410A
Remote controller
SPLIT-TYPE, HEAT PUMP AIR CONDITIONERS
SPLIT-TYPE, AIR CONDITIONERS
Revision:
• Part No. of TOP PLATE (page
50, 51) has been modified in
REVISED EDITION-B.
Model name
indication
• Please void OC301
REVISED EDITION-A.
N
ote:
• This manual does not cover
outdoor units. When servicing
them, please refer to service
manual OC261, OC285,
OC294, OC298 and this
manual in a set.
• RoHS compliant products
have <G> mark on the spec
name plate.
August 2013
OC301B--1.qxp 13.8.22 8:08 AM Page 1

2
1COMBINATION OF INDOOR AND OUTDOOR UNITS
Outdoor unit [OC294 REVISED EDITION-A]
Heat pump type
PUHZ-RP
Outdoor unit [OC285]
Heat pump type
PUH-P
(R407C Fixed speed)
(R407C Fixed speed)
(R410A Inverter)
Outdoor unit [OC298]
Cooling only type
PU-P
4VHA
4VHA1
—
—
3VHA
—
—
2.5VHA
—
—
Indoor unit
PKA-RP2.5FAL
PKA-RP3FAL
PKA-RP4FAL
Heat pump without
electric heater
or
Cooling only
3VGAA
—
—
2.5VGAA
—
—
3YGAA
—
—
4YGAA
—
—
3VGAA
—
—
2.5VGAA
—
—
3YGAA
—
—
4YGAA
—
—
Indoor unit
PKA-RP2.5FAL
PKA-RP3FAL
PKA-RP4FAL
Heat pump type
PUH-P Cooling only type PU-P
Heat pump without
electric heater
or
Cooling only
—
—
—
—
—
—
—
—
—
—
—
—
VGAA.UK
VGAA1.UK
YGAA.UK
YGAA1.UK
VGAA.UK
VGAA1.UK
YGAA.UK
YGAA1.UK
VGAA.UK
VGAA1.UK
YGAA.UK
YGAA1.UK
VGAA.UK
VGAA1.UK
YGAA.UK
YGAA1.UK
VGAA.UK
VGAA1.UK
YGAA.UK
YGAA1.UK
VGAA.UK
VGAA1.UK
YGAA.UK
YGAA1.UK
—
—
—
—
—
—
—
—
—
—
—
—
Indoor unit
PKA-RP2.5FAL
PKA-RP3FAL
PKA-RP4FAL
Outdoor unit [OC261 REVISED EDITION-B]
32.5 4 32.5 4
OC301B--1.qxp 13.8.20 3:16 PM Page 2
OC301B

3
2SAFETY PRECAUTION
[2] Refrigerant recharging
(1) Refrigerant recharging process
1Direct charging from the cylinder.
·R407C cylinder are available on the market has a syphon pipe.
·Leave the syphon pipe cylinder standing and recharge it. (By liquid refrigerant)
(2) Recharge in refrigerant leakage case
·After recovering the all refrigerant in the unit, proceed to working.
·Do not release the refrigerant in the air.
·After completing the repair service, recharge the cycle with the specified amount of liquid refrigerant.
[1] Cautions for service
·After recovering the all refrigerant in the unit, proceed to working.
·Do not release refrigerant in the air.
·After completing the repair service, recharge the cycle with the specified amount of liquid refrigerant.
Cautions for units utilizing refrigerant R407C
CAUTIONS RELATED TO NEW REFRIGERANT
Do not use the existing refrigerant piping.
The old refrigerant and lubricant in the existing piping
contains a large amount of chlorine which may cause the
lubricant deterioration of the new unit.
Use“low residual oil piping”
If there is a large amount of residual oil (hydraulic oil, etc.)
inside the piping and joints, deterioration of the lubricant
will result.
Use ESTR , ETHER or HAB as the lubricant to
coat flares and flange connection parts.
If large amount of mineral oil enter, that can cause
deterioration of refrigerant oil etc.
Use liquid refrigerant to seal the system.
If gas refrigerant is used to seal the system, the composition
of the refrigerant in the cylinder will change and performance
may drop.
Do not use a refrigerant other than R407C.
If another refrigerant (R22, etc.) is used, the chlorine in the
refrigerant may cause the lubricant deterioration.
Use a vacuum pump with a reverse flow check valve.
The vacuum pump oil may flow back into the refrigerant
cycle and cause the lubricant deterioration.
Use the specified refrigerant only
Never use an refrigerant other than that specified.
Doing so may cause a burst, an explosion, or fire when the
unit is being used, serviced, or disposed of.
Correct refrigerant is specified in the manuals and on the
spec labels provided with our products.
We will not be held responsible for mechanical failure,
system malfunction, unit breakdown or accidents caused by
failure to follow the instructions.
Store the piping indoors, and both ends of the
piping sealed until just before brazing.
(Leave elbow joints, etc. in their packaging.)
If dirt, dust or moisture enters into refrigerant cycle, that can
cause deterioration of refrigerant oil or malfunction of com-
pressor.
Ventilate the room if refrigerant leaks during
operation. If refrigerant comes into contact with
a flame, poisonous gases will be released.
Gravimeter
Unit
OC301B--1.qxp 13.8.20 3:16 PM Page 3
OC301B

4
[3] Service tools
Use the below service tools as exclusive tools for R407C refrigerant.
No. Tool name Specifications
1Gauge manifold ·Only for R407C.
·Use the existing fitting SPECIFICATIONS. (UNF7/16)
·Use high-tension side pressure of 3.43MPa·G or over.
2Charge hose ·Only for R407C.
·Use pressure performance of 5.10MPa·G or over.
3Electronic scale
4Gas leak detector ·Use the detector for R134a or R407C.
5Adapter for reverse flow check. ·Attach on vacuum pump.
6Refrigerant charge base.
7Refrigerant cylinder. ·For R407C ·Top of cylinder (Brown)
·Cylinder with syphon
8Refrigerant recovery equipment.
OC301B--1.qxp 13.8.20 3:16 PM Page 4
OC301B

5
Cautions for units utilizing refrigerant R410A
CAUTIONS RELATED TO NEW REFRIGERANT
Use new refrigerant pipes.
Make sure that the inside and outside of refrige-
rant piping is clean and it has no contaminants
such as sulfur oxides, dirt, shaving particles, etc,
which are hazard to refrigerant cycle.
In addition, use pipes with specified thickness.
Store the piping indoors, and both ends of the
piping sealed until just before brazing.
(Leave elbow joints, etc. in their packaging.)
The refrigerant oil applied to flare and flange
connections must be ester oil, ether oil or
alkylbenzene oil in a small amount.
In case of using the existing pipes for R22, be careful with
the followings.
· For RP4 be sure to perform replacement operation before
test run.
· Change flare nut to the one provided with this product.
Use a newly flared pipe.
· Avoid using thin pipes.
Charge refrigerant from liquid phase of gas
cylinder.
If the refrigerant is charged from gas phase, composition
change may occur in refrigerant and the efficiency will be
lowered.
Do not use refrigerant other than R410A.
If other refrigerant (R22 etc.) is used, chlorine in refrige-
rant can cause deterioration of refrigerant oil etc.
Use a vacuum pump with a reverse flow check
valve.
Vacuum pump oil may flow back into refrigerant cycle and
that can cause deterioration of refrigerant oil etc.
Use the following tools specifically designed for
use with R410A refrigerant.
The following tools are necessary to use R410A refrigerant.
Keep the tools with care.
If dirt, dust or moisture enter into refrigerant cycle, that can
cause deterioration of refrigerant oil or malfunction of com-
pressor.
Do not use a charging cylinder.
If a charging cylinder is used, the composition of refrigera-
nt will change and the efficiency will be lowered.
Flare tool
Electronic refrigerant
charging scale
Vacuum pump adaptor
Size adjustment gauge
Gauge manifold
Torque wrench
Gas leak detector
Charge hose
Tools for R410A
Contamination inside refrigerant piping can cause deterio-
ration of refrigerant oil etc.
If dirt, dust or moisture enters into refrigerant cycle, that can
cause deterioration of refrigerant oil or malfunction of com-
pressor.
If large amount of mineral oil enters, that can cause deterio-
ration of refrigerant oil etc.
Use the specified refrigerant only
Never use an refrigerant other than that specified.
Doing so may cause a burst, an explosion, or fire when the
unit is being used, serviced, or disposed of.
Correct refrigerant is specified in the manuals and on the
spec labels provided with our products.
We will not be held responsible for mechanical failure,
system malfunction, unit breakdown or accidents caused by
failure to follow the instructions.
Ventilate the room if refrigerant leaks during
operation. If refrigerant comes into contact with
a flame, poisonous gases will be released.
[1] Cautions for service
(1) Perform service after collecting the refrigerant left in unit completely.
(2) Do not release refrigerant in the air.
(3) After completing service, charge the cycle with specified amount of refrigerant.
(4) When performing service, install a filter drier simultaneously.
Be sure to use a filter drier for new refrigerant.
[2] Additional refrigerant charge
When charging directly from cylinder
· Check that cylinder for R410A on the market is syphon type.
· Charging should be performed with the cylinder of syphon stood vertically. (Refrigerant is charged from liquid phase.)
OC301B--1.qxp 13.8.20 3:16 PM Page 5
OC301B

6
3PART NAMES AND FUNCTIONS
● Indoor Unit
Air intake
room air is suctioned
in here. (Removes dust and dirt from the intake air.)
Disperses airflow up and
down as well as adjusts the
angle of air flow direction.
Filter Air intake grille
Air outletAir outlet
Swing louvers
Indicator lamp section
Air flow can be changed to horizontally
by moving the Guide vane to the left or
right.
Guide vane
Gravimeter
Unit
[3] Service tools
Use the below service tools as exclusive tools for R410A refrigerant.
No. Specifications
1Gauge manifold ·Only for R410A
·Use the existing fitting specifications. (UNF1/2)
·Use high-tension side pressure of 5.3MPa·G or over.
2Charge hose ·Only for R410A
·Use pressure performance of 5.09MPa·G or over.
3Electronic scale
4Gas leak detector ·Use the detector for R134a, R407C or R410A.
5Adaptor for reverse flow check ·Attach on vacuum pump.
6Refrigerant charge base
7Refrigerant cylinder ·Only for R410A Top of cylinder (Pink)
Cylinder with syphon
8Refrigerant recovery equipment
OC301B--1.qxp 13.8.20 3:16 PM Page 6
OC301B

7
●Wireless remote controller
●When cover is open.
ON/OFF TEMP
FAN
VANE
TEST RUN
AUTO STOP
AUTO START
h
min
LOUVER
MODE
CHECK
RESETSET CLOCK
MODEL SELECT
NOT AVAILABLE
CHECK TEST RUN
˚C
AMPM
AMPM
VANE CONTROL button
Used to change the air flow direction.
CLOCK button
RESET button
SET button
ON/OFF button
The unit is turned ON and OFF alternately
each time the button is pressed.
LOUVER button
This switch the horizontal fan motion ON
and OFF.
(Not available for this model.)
MODE SELECT button
Used to switch the operation mode between
cooling, drying, blowing, heating and auto
mode.
CHECK-TEST RUN button
Only press this button to perform an inspec-
tion check or test operation.
Do not use it for normal operation.
FAN SPEED SELECT button
Used to change the fan speed.
TIMER display
Displays when in timer operation or when
setting timer.
button
SET TEMPERATURE button sets any desired
room temperature.
CLOCK display
Displays the current time.
“”“ ” display
Displays the order of timer operation.
“ ”“ ” display
Displays whether timer is on or off.
* In case the outdoor unit is cool only type,
the heating mode is not available.
Buttons used to set the “hour and minute” of
the current time and timer settings.
h and min buttons
display
SET TEMP. display indicates desired temper-
ature set.
display
FAN SPEED display indicates which fan
speed has been selected.
display
The vertical direction of air flow is indicated.
display
Blinks when model is selected.
display
Lights up while transmission to the indoor
unit is mode using switches.
display
CHECK&TEST RUN display indicates that
the unit is being checked or test-run.
display
OPERATION MODE display
Operation mode display indicates which op-
eration mode is in effect.
TIMER CONTROL buttons
AUTO STOP (OFF timer): when this switch
is set, the air conditioner will be auto-
matically stopped at the preset time.
AUTO START (ON timer): when this switch
is set, the air conditioner will be automatical-
ly started at the preset time.
MODEL SELECT
CHECK TEST RUN
OC301B--1.qxp 13.8.20 3:16 PM Page 7
OC301B

8
4SPECIFICATIONS
4-1. Heat pump type (1)
Service Ref.
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
Function
Capacity
Total input
Service Ref.
Power supply(phase, cycle, voltage)
Input
Running current
Starting current
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
W
D
H
INDOOR UNIT
PKA-RP3FAL
PKA-RP3FAL
Cooling
24,200
7,100(3,300~8,100)
1.98
0.09
0.43
0.80
Heating
27,300
8,000(3,500~10,200)
2.40
0.09
0.43
0.80
Single phase, 50Hz, 220-230-240V
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.040
15-20(530-706)
0(direct blow)
Wireless remote controller & built-in
39-45
26(1)
1,400(55-1/8)
235(9-1/4)
340(13-3/8)
24(53)
PUHZ-RP3VHA
Service Ref.
OUTDOOR
UNIT
Notes1. Rating Conditions (ISO T1)
Cooling : Indoor : D.B. 27˚C(80˚F), W.B. 19˚C (66˚F) Outdoor : D.B. 35˚C(95˚F), W.B. 24˚C (75˚F)
Heating : Indoor : D.B. 20˚C(68˚F) Outdoor : D.B. 7˚C(45˚F), W.B. 6˚C (43˚F)
Refrigerant piping length (one way) : 5m (16ft)
4. Above data based on indicated voltage
Indoor Unit Single phase 230V 50Hz
Outdoor Unit Single phase 230V 50Hz
2. Guaranteed operating range
Upper limit
Lower limit
Upper limit
Lower limit
Indoor
D.B. 35˚C, W.B. 22.5˚C
D.B. 19˚C, W.B. 15˚C
D.B. 28˚C
D.B. 17˚C
Outdoor
D.B. 46˚C
D.B. -5˚C
D.B. 21˚C, W.B. 15˚C
D.B. -11˚C, W.B. -12˚C
Cooling
Heating
5. Refer to the service manual of outdoor unit for the outdoor unit's specifications.
3. Guaranteed voltage
198~264V, 50Hz
Cooling
20,500
6,000(2,700~6,700)
1.55
0.09
0.43
0.80
Heating
23,900
7,000(2,800~8,200)
2.01
0.09
0.43
0.80
Single phase, 50Hz, 220-230-240V
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.040
15-20(530-705)
0(direct blow)
Wireless remote controller & built-in
39-45
26(1)
1,400(55-1/8)
235(9-1/4)
340(13-3/8)
24(53)
PUHZ-RP2.5VHA
PKA-RP2.5FAL
PKA-RP2.5FAL
Service Ref.
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
Function
Capacity
Total input
Service Ref.
Power supply(phase, cycle, voltage)
Input
Running current
Starting current
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
W
D
H
Service Ref.
INDOOR UNIT
OUTDOOR
UNIT
OC301B--1.qxp 13.8.20 3:16 PM Page 8
OC301B

9
Cooling
34,100
10,000(5,000~11,400)
10,000(4,900~11,400)
2.93
0.11
0.52
0.90
Heating
38,200
11,200(5,600~14,000)
11,200(4,500~14,000)
3.25
0.11
0.52
0.90
Single phase, 50Hz, 220-230-240V
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.070
22-28(780-990)
0(direct blow)
Wireless remote controller & built-in
41-46
26(1)
1,680(66-1/8)
235(9-1/4)
340(13-3/8)
28(62)
PUHZ-RP4VHA
PUHZ-RP4VHA1
PKA-RP4FAL
PKA-RP4FAL
Service Ref.
Item
Btu/h
W
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
Function
Capacity
Total input
Service Ref.
Power supply(phase, cycle, voltage)
Input
Running current
Starting current
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
W
D
H
INDOOR UNIT
Notes1. Rating Conditions (ISO T1)
Cooling : Indoor : D.B. 27˚C(80˚F), W.B. 19˚C (66˚F) Outdoor : D.B. 35˚C(95˚F), W.B. 24˚C (75˚F)
Heating : Indoor : D.B. 20˚C(68˚F) Outdoor : D.B. 7˚C(45˚F), W.B. 6˚C (43˚F)
Refrigerant piping length (one way) : 5m (16ft)
4. Above data based on indicated voltage
Indoor Unit Single phase 230V 50Hz
Outdoor Unit Single phase 230V 50Hz
2. Guaranteed operating range
Upper limit
Lower limit
Upper limit
Lower limit
Indoor
D.B. 35˚C, W.B. 22.5˚C
D.B. 19˚C, W.B. 15˚C
D.B. 28˚C
D.B. 17˚C
Outdoor
D.B. 46˚C
D.B. -5˚C
D.B. 21˚C, W.B. 15˚C
D.B. -11˚C, W.B. -12˚C
Cooling
Heating
Service Ref.
OUTDOOR
UNIT
5. Refer to the service manual of outdoor unit for the outdoor unit's specifications.
3. Guaranteed voltage
198~264V, 50Hz
PUHZ-RP4VAH
PUHZ-RP4VAH1
OC301B--1.qxp 13.8.20 3:16 PM Page 9
OC301B

10
4-2. Heat pump type (2)
Service Ref.
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
Function
Capacity
Total input
Service Ref.
Power supply(phase, cycle, voltage)
Input
Running current
Starting current
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
W
D
H
INDOOR UNIT
PKA-RP3FAL
PKA-RP3FAL
Cooling
26,800
7,850
3.43
0.09
0.43
0.80
Heating
32,100
9,400
3.61
0.09
0.43
0.80
Single phase, 50Hz, 220-230-240V
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.040
15-20(530-705)
0(direct blow)
Wireless remote controller & built-in
39-45
26(1)
1,400(55-1/8)
235(9-1/4)
340(13-3/8)
24(53)
Service Ref.
OUTDOOR
UNIT
PUH-P3VGAA / PUH-P3YGAA
PUH-P3VGAA.UK / PUH-P3YGAA.UK
PUH-P3VGAA1.UK / PUH-P3YGAA1.UK
Notes1. Rating Conditions (ISO T1)
Cooling : Indoor : D.B. 27˚C(80˚F), W.B. 19˚C (66˚F) Outdoor : D.B. 35˚C(95˚F), W.B. 24˚C (75˚F)
Heating : Indoor : D.B. 20˚C(68˚F) Outdoor : D.B. 7˚C(45˚F), W.B. 6˚C (43˚F)
Refrigerant piping length (one way) : 5m (16ft)
4. Above data based on indicated voltage
Indoor Unit Single phase 230V 50Hz
Outdoor Unit 3 phase 400V 50Hz
2. Guaranteed operating range
Upper limit
Lower limit
Upper limit
Lower limit
Indoor
D.B. 35˚C, W.B. 22.5˚C
D.B. 19˚C, W.B. 15˚C
D.B. 28˚C
D.B. 17˚C
Outdoor
D.B. 46˚C
D.B. -5˚C
D.B. 24˚C, W.B. 18˚C
D.B. -11˚C, W.B. -12˚C
Cooling
Heating
5. Refer to the service manual of outdoor unit for the outdoor unit's specifications.
3. Guaranteed voltage
198~264V, 50Hz
Cooling
22,000
6,450
2.65
0.09
0.43
0.80
Heating
25,100
7,350
2.63
0.09
0.43
0.80
Single phase, 50Hz, 220-230-240V
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.040
15-20(530-706)
0(direct blow)
Wireless remote controller & built-in
39-45
26(1)
1,400(55-1/8)
235(9-1/4)
340(13-3/8)
24(53)
PKA-RP2.5FAL
PKA-RP2.5FAL
Service Ref.
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
Function
Capacity
Total input
Service Ref.
Power supply(phase, cycle, voltage)
Input
Running current
Starting current
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
W
D
H
Service Ref.
INDOOR UNIT
OUTDOOR
UNIT
PUH-P2.5VGAA
PUH-P2.5VGAA.UK / PUH-P2.5YGAA.UK
PUH-P2.5VGAA1.UK/ PUH-P2.5YGAA1.UK
OC301B--1.qxp 13.8.20 3:16 PM Page 10
OC301B

11
Cooling
32,100
9,400
3.59
0.11
0.52
0.90
Heating
36,800
10,800
3.77
0.11
0.52
0.90
Single phase, 50Hz, 220-230-240V
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.070
22-28(775-990)
0(direct blow)
Wireless remote controller & built-in
41-46
26(1)
1,680(66-1/8)
235(9-1/4)
340(13-3/8)
28(62)
PKA-RP4FAL
PKA-RP4FAL
Service Ref.
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
Function
Capacity
Total input
Service Ref.
Power supply(phase, cycle, voltage)
Input
Running current
Starting current
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
W
D
H
INDOOR UNIT
Notes1. Rating Conditions (ISO T1)
Cooling : Indoor : D.B. 27˚C(80˚F), W.B. 19˚C (66˚F) Outdoor : D.B. 35˚C(95˚F), W.B. 24˚C (75˚F)
Heating : Indoor : D.B. 20˚C(68˚F) Outdoor : D.B. 7˚C(45˚F), W.B. 6˚C (43˚F)
Refrigerant piping length (one way) : 5m (16ft)
4. Above data based on indicated voltage
Indoor Unit Single phase 230V 50Hz
Outdoor Unit 3 phase 400V 50Hz
2. Guaranteed operating range
Upper limit
Lower limit
Upper limit
Lower limit
Indoor
D.B. 35˚C, W.B. 22.5˚C
D.B. 19˚C, W.B. 15˚C
D.B. 28˚C
D.B. 17˚C
Outdoor
D.B. 46˚C
D.B. -5˚C
D.B. 24˚C, W.B. 18˚C
D.B. -11˚C, W.B. -12˚C
Cooling
Heating
Service Ref.
OUTDOOR
UNIT
5. Refer to the service manual of outdoor unit for the outdoor unit's specifications.
3. Guaranteed voltage
198~264V, 50Hz
PUH-P4YGAA
PUH-P4VGAA.UK / PUH-P4YGAA.UK
PUH-P4VGAA1.UK / PUH-P4YGAA1.UK
OC301B--1.qxp 13.8.20 3:16 PM Page 11
OC301B

12
4-3. Cooling only type
Cooling
22,000
6,450
2.65
0.09
0.43
0.80
Single phase, 50Hz, 220-230-240V
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.040
15-20(530-706)
0(direct blow)
Wireless remote controller & built-in
39-45
26(1)
1,400(55-1/8)
235(9-1/4)
340(13-3/8)
24(53)
PKA-RP2.5FAL
PKA-RP2.5FAL
Service Ref.
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
Function
Capacity
Total input
Service Ref.
Power supply(phase, cycle, voltage)
Input
Running current
Starting current
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
W
D
H
Service Ref.
INDOOR UNIT
OUTDOOR
UNIT
PU-P2.5VGAA
PU-P2.5VGAA.UK /PU-P2.5YGAA.UK
PU-P2.5VGAA1.UK/ PU-P2.5YGAA1.UK
Service Ref.
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
Function
Capacity
Total input
Service Ref.
Power supply(phase, cycle, voltage)
Input
Running current
Starting current
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
W
D
H
Service Ref.
INDOOR UNIT
OUTDOOR
UNIT
PKA-RP3FAL
Cooling
26,800
7,850
3.43
PKA-RP3FAL
Single phase, 50Hz, 220-230-240V
0.09
0.43
0.80
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.040
15-20(530-705)
0(direct blow)
Wireless remote controller & built-in
39-45
26(1)
1,400(55-1/8)
235(9-1/4)
340(13-3/8)
24(53)
PU-P3VGAA / PU-P3YGAA
PU-P3VGAA.UK / PU-P3YGAA.UK
PU-P3VGAA1.UK / PU-P3YGAA1.UK
Notes1. Rating Conditions (ISO T1)
Cooling : Indoor : D.B. 27˚C(80˚F), W.B. 19˚C (66˚F) Outdoor : D.B. 35˚C(95˚F), W.B. 24˚C (75˚F)
Refrigerant piping length (one way) : 5m (16ft)
4. Above data based on indicated voltage
Indoor Unit Single phase 230V 50Hz
Outdoor Unit 3 phase 400V 50Hz
2. Guaranteed operating range
3. Guaranteed voltage
198~264V, 50Hz
Upper limit
Lower limit
Indoor
D.B. 35˚C, W.B. 22.5˚C
D.B. 19˚C, W.B. 15˚C
Outdoor
D.B. 46˚C
D.B. -5˚C
Cooling
5. Refer to the service manual of outdoor unit for the outdoor unit's specifications.
OC301B--1.qxp 13.8.20 3:16 PM Page 12
OC301B

13
Cooling
32,100
9,400
3.59
PKA-RP4FAL
Single phase, 50Hz, 220-230-240V
0.11
0.52
0.90
Munsell 3.4Y 7.7/0.8
Plate fin coil
Line flow (direct) x 2
0.070
22-28(775-990)
0(direct blow)
Wireless remote controller & built-in
41-46
26(1)
1,680(66-1/8)
235(9-1/4)
340(13-3/8)
28(62)
Notes1. Rating Conditions (ISOT1)
Cooling : Indoor : D.B. 27˚C(80˚F), W.B. 19˚C (66˚F) Outdoor : D.B. 35˚C(95˚F), W.B. 24˚C (75˚F)
Refrigerant piping length (one way) : 5m (16ft)
4. Above data based on indicated voltage
Indoor Unit Single phase 230V 50Hz
Outdoor Unit 3 phase 400V 50Hz
2. Guaranteed operating range
3. Guaranteed voltage
198~264V, 50Hz
Upper limit
Lower limit
Indoor
D.B. 35˚C, W.B. 22.5˚C
D.B. 19˚C, W.B. 15˚C
Outdoor
D.B. 46˚C
D.B. -5˚C
Cooling
PKA-RP4FAL
Service Ref.
Item
Btu/h
W
kW
kW
A
A
kW
K/min(CFM)
Pa(mmAq)
dB
mm(in.)
mm(in.)
mm(in.)
mm(in.)
kg(lbs)
Function
Capacity
Total input
Service Ref.
Power supply(phase, cycle, voltage)
Input
Running current
Starting current
External finish
Heat exchanger
Fan Fan(drive) x No.
Fan motor output
Airflow(Low-High)
External static pressure
Operation control & Thermostat
Noise level(Low-High)
Unit drain pipe O.D.
Dimensions
Weight
W
D
H
INDOOR UNIT
Service Ref.
OUTDOOR
UNIT
5. Refer to the service manual of outdoor unit for the outdoor unit's specifications.
PU-P4YGAA
PU-P4VGAA.UK / PU-P4YGAA.UK
PU-P4VGAA1.UK / PU-P4YGAA1.UK
OC301B--1.qxp 13.8.20 3:16 PM Page 13
OC301B

14
5DATA
5-1. PERFORMANCE DATA
COOLING CAPACITY(1)
PKA-RP2.5FAL / PUHZ-RP2.5VHA (230V)
Outdoor intake air D.B.(°C)
20 25 30
Indoor
Intake air
D.B.(°C)
Indoor
Intake air
W.B.(°C)
20
20
20
22
22
22
24
24
24
24
26
26
26
26
27
27
27
27
28
28
28
28
30
30
30
30
32
32
32
32
34
34
34
34
16
18
20
16
18
20
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
CA
5,940
6,360
6,840
5,940
6,360
6,840
5,940
6,360
6,840
7,290
5,940
6,360
6,840
7,290
5,940
6,360
6,840
7,290
5,940
6,360
6,840
7,290
5,940
6,360
6,840
7,290
5,940
6,360
6,840
7,290
5,940
6,360
6,840
7,290
SHC(W)
4,336
3,880
3,352
4,811
4,388
3,899
5,287
4,897
4,446
3,864
5,762
5,406
4,993
4,447
5,940
5,660
5,267
4,739
5,940
5,915
5,540
5,030
5,940
6,360
6,088
5,613
5,940
6,360
6,635
6,197
5,940
6,360
6,840
6,780
SHF
0.73
0.61
0.49
0.81
0.69
0.57
0.89
0.77
0.65
0.53
0.97
0.85
0.73
0.61
1.00
0.89
0.77
0.65
1.00
0.93
0.81
0.69
1.00
1.00
0.89
0.77
1.00
1.00
0.97
0.85
1.00
1.00
1.00
0.93
SHF
0.73
0.61
0.49
0.81
0.69
0.57
0.89
0.77
0.65
0.53
0.97
0.85
0.73
0.61
1.00
0.89
0.77
0.65
1.00
0.93
0.81
0.69
1.00
1.00
0.89
0.77
1.00
1.00
0.97
0.85
1.00
1.00
1.00
0.93
SHF
0.73
0.61
0.49
0.81
0.69
0.57
0.89
0.77
0.65
0.53
0.97
0.85
0.73
0.61
1.00
0.89
0.77
0.65
1.00
0.93
0.81
0.69
1.00
1.00
0.89
0.77
1.00
1.00
0.97
0.85
1.00
1.00
1.00
0.93
P.C.
1.24
1.26
1.30
1.24
1.26
1.30
1.33
1.24
1.26
1.30
1.24
1.26
1.30
1.33
1.24
1.26
1.30
1.33
1.24
1.26
1.30
1.33
1.24
1.26
1.30
1.33
1.24
1.26
1.30
1.33
1.24
1.26
1.30
1.33
CA
5,760
6,180
6,690
5,760
6,180
6,690
7,140
5,760
6,180
6,690
5,760
6,180
6,690
7,140
5,760
6,180
6,690
7,140
5,760
6,180
6,690
7,140
5,760
6,180
6,690
7,140
5,760
6,180
6,690
7,140
5,760
6,180
6,690
7,140
SHC(W)
4,205
3,770
3,278
4,666
4,264
3,813
5,126
4,759
4,349
3,784
5,587
5,253
4,884
4,355
5,760
5,500
5,151
4,641
5,760
5,747
5,419
4,927
5,760
6,180
5,954
5,498
5,760
6,180
6,489
6,069
5,760
6,180
6,690
6,640
P.C.
1.31
1.33
1.36
1.31
1.33
1.36
1.31
1.33
1.36
1.41
1.31
1.33
1.36
1.41
1.31
1.33
1.36
1.41
1.31
1.33
1.36
1.41
1.31
1.33
1.36
1.41
1.31
1.33
1.36
1.41
1.31
1.33
1.36
1.41
CA
5,580
5,970
6,510
5,580
5,970
6,510
5,580
5,970
6,510
6,960
5,580
5,970
6,510
6,960
5,580
5,970
6,510
6,960
5,580
5,970
6,510
6,960
5,580
5,970
6,510
6,960
5,580
5,970
6,510
6,960
5,580
5,970
6,510
6,960
SHC(W)
4,073
3,642
3,190
4,520
4,119
3,711
4,966
4,597
4,232
3,689
5,413
5,075
4,752
4,246
5,580
5,313
5,013
4,524
5,580
5,552
5,273
4,802
5,580
5,970
5,794
5,359
5,580
5,970
6,315
5,916
5,580
5,970
6,510
6,473
P.C.
1.39
1.43
1.46
1.39
1.43
1.46
1.50
1.39
1.43
1.46
1.39
1.43
1.46
1.50
1.39
1.43
1.46
1.50
1.39
1.43
1.46
1.50
1.39
1.43
1.46
1.50
1.39
1.43
1.46
1.50
1.39
1.43
1.46
1.50
CA : Capacity (W) SHC(W) :Sensible heat capacity
P.C. : Power consumption (kW) SHF : Sensible heat factor
OC301B--1.qxp 13.8.20 3:16 PM Page 14
OC301B

15
COOLING CAPACITY(2)
PKA-RP2.5FAL / PUHZ-RP2.5VHA
(230V)
Outdoor intake air D.B.(°C)
35 40 45
Indoor
Intake air
D.B.(°C)
Indoor
Intake air
W.B.(°C)
20
20
20
22
22
22
24
24
24
24
26
26
26
26
27
27
27
27
28
28
28
28
30
30
30
30
32
32
32
32
34
34
34
34
16
18
20
16
18
20
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
CA
5,340
5,760
6,240
5,340
5,760
6,240
5,340
5,760
6,240
6,720
5,340
5,760
6,240
6,720
5,340
5,760
6,240
6,720
5,340
5,760
6,240
6,720
5,340
5,760
6,240
6,720
5,340
5,760
6,240
6,720
5,340
5,760
6,240
6,720
SHC(W)
3,898
3,514
3,058
4,325
3,974
3,557
4,753
4,435
4,056
3,562
5,180
4,896
4,555
4,099
5,340
5,126
4,805
4,368
5,340
5,357
5,054
4,637
5,340
5,760
5,554
5,174
5,340
5,760
6,053
5,712
5,340
5,760
6,240
6,250
SHF
0.73
0.61
0.49
0.81
0.69
0.57
0.89
0.77
0.65
0.53
0.97
0.85
0.73
0.61
1.00
0.89
0.77
0.65
1.00
0.93
0.81
0.69
1.00
1.00
0.89
0.77
1.00
1.00
0.97
0.85
1.00
1.00
1.00
0.93
SHF
0.73
0.61
0.49
0.81
0.69
0.57
0.89
0.77
0.65
0.53
0.97
0.85
0.73
0.61
1.00
0.89
0.77
0.65
1.00
0.93
0.81
0.69
1.00
1.00
0.89
0.77
1.00
1.00
0.97
0.85
1.00
1.00
1.00
0.93
SHF
0.73
0.61
0.49
0.81
0.69
0.57
0.89
0.77
0.65
0.53
0.97
0.85
0.73
0.61
1.00
0.89
0.77
0.65
1.00
0.93
0.81
0.69
1.00
1.00
0.89
0.77
1.00
1.00
0.97
0.85
1.00
1.00
1.00
0.93
P.C.
1.49
1.53
1.57
1.49
1.53
1.57
1.49
1.53
1.57
1.60
1.49
1.53
1.57
1.60
1.49
1.53
1.57
1.60
1.49
1.53
1.57
1.60
1.49
1.53
1.57
1.60
1.49
1.53
1.57
1.60
1.49
1.53
1.57
1.60
CA
5,100
5,580
6,000
5,100
5,580
6,000
5,100
5,580
6,000
6,480
5,100
5,580
6,000
6,480
5,100
5,580
6,000
6,480
5,100
5,580
6,000
6,480
5,100
5,580
6,000
6,480
5,100
5,580
6,000
6,480
5,100
5,580
6,000
6,480
SHC(W)
3,723
3,404
2,940
4,131
3,850
3,420
4,539
4,297
3,900
3,434
4,947
4,743
4,380
3,953
5,100
4,966
4,620
4,212
5,100
5,189
4,860
4,471
5,100
5,580
5,340
4,990
5,100
5,580
5,820
5,508
5,100
5,580
6,000
6,026
P.C.
1.60
1.64
1.67
1.60
1.64
1.67
1.60
1.64
1.67
1.72
1.60
1.64
1.67
1.72
1.60
1.64
1.67
1.72
1.60
1.64
1.67
1.72
1.60
1.64
1.67
1.72
1.60
1.64
1.67
1.72
1.60
1.64
1.67
1.72
CA
4,860
5,220
5,640
4,860
5,220
5,640
4,860
5,220
5,640
6,120
4,860
5,220
5,640
6,120
4,860
5,220
5,640
6,120
4,860
5,220
5,640
6,120
4,860
5,220
5,640
6,120
4,860
5,220
5,640
6,120
4,860
5,220
5,640
6,120
SHC(W)
3,548
3,184
2,764
3,937
3,602
3,215
4,325
4,019
3,666
3,244
4,714
4,437
4,117
3,733
4,860
4,646
4,343
3,978
4,860
4,855
4,568
4,223
4,860
5,220
5,020
4,712
4,860
5,220
5,471
5,202
4,860
5,220
5,640
5,692
P.C.
1.73
1.77
1.80
1.73
1.77
1.80
1.73
1.77
1.80
1.83
1.73
1.77
1.80
1.83
1.73
1.77
1.80
1.83
1.73
1.77
1.80
1.83
1.73
1.77
1.80
1.83
1.73
1.77
1.80
1.83
1.73
1.77
1.80
1.83
CA : Capacity (W) SHC(W) :Sensible heat capacity
P.C. : Power consumption (kW) SHF : Sensible heat factor
OC301B--1.qxp 13.8.20 3:16 PM Page 15
OC301B

16
CA : Capacity (W) SHC(W) :Sensible heat capacity
P.C. : Power consumption (kW) SHF : Sensible heat factor
Outdoor intake air D.B.(°C)
20 25 30
Indoor
Intake air
D.B.(°C)
Indoor
Intake air
W.B.(°C)
20
20
20
22
22
22
24
24
24
24
26
26
26
26
27
27
27
27
28
28
28
28
30
30
30
30
32
32
32
32
34
34
34
34
16
18
20
16
18
20
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
CA
7,029
7,526
8,094
7,029
7,526
8,094
7,029
7,526
8,094
8,627
7,029
7,526
8,094
8,627
7,029
7,526
8,094
8,627
7,029
7,526
8,094
8,627
7,029
7,526
8,094
8,627
7,029
7,526
8,094
8,627
7,029
7,526
8,094
8,627
SHC(W)
4,709
4,139
3,480
5,272
4,741
4,128
5,834
5,343
4,775
4,054
6,396
5,946
5,423
4,745
6,678
6,247
5,747
5,090
6,959
6,548
6,071
5,435
7,029
7,150
6,718
6,125
7,029
7,526
7,366
6,815
7,029
7,526
8,013
7,505
SHF
0.67
0.55
0.43
0.75
0.63
0.51
0.83
0.71
0.59
0.47
0.91
0.79
0.67
0.55
0.95
0.83
0.71
0.59
0.99
0.87
0.75
0.63
1.00
0.95
0.83
0.71
1.00
1.00
0.91
0.79
1.00
1.00
0.99
0.87
SHF
0.67
0.55
0.43
0.75
0.63
0.51
0.83
0.71
0.59
0.47
0.91
0.79
0.67
0.55
0.95
0.83
0.71
0.59
0.99
0.87
0.75
0.63
1.00
0.95
0.83
0.71
1.00
1.00
0.91
0.79
1.00
1.00
0.99
0.87
SHF
0.67
0.55
0.43
0.75
0.63
0.51
0.83
0.71
0.59
0.47
0.91
0.79
0.67
0.55
0.95
0.83
0.71
0.59
0.99
0.87
0.75
0.63
1.00
0.95
0.83
0.71
1.00
1.00
0.91
0.79
1.00
1.00
0.99
0.87
P.C.
1.58
1.61
1.66
1.58
1.61
1.66
1.58
1.61
1.66
1.70
1.58
1.61
1.66
1.70
1.58
1.61
1.66
1.70
1.58
1.61
1.66
1.70
1.58
1.61
1.66
1.70
1.58
1.61
1.66
1.70
1.58
1.61
1.66
1.70
CA
6,816
7,313
7,917
6,816
7,313
7,917
6,816
7,313
7,917
8,449
6,816
7,313
7,917
8,449
6,816
7,313
7,917
8,449
6,816
7,313
7,917
8,449
6,816
7,313
7,917
8,449
6,816
7,313
7,917
8,449
6,816
7,313
7,917
8,449
SHC(W)
4,567
4,022
3,404
5,112
4,607
4,037
5,657
5,192
4,671
3,971
6,203
5,777
5,304
4,647
6,475
6,070
5,621
4,985
6,748
6,362
5,937
5,323
6,816
6,947
6,571
5,999
6,816
7,313
7,204
6,675
6,816
7,313
7,837
7,351
P.C.
1.67
1.70
1.74
1.67
1.70
1.74
1.67
1.70
1.74
1.80
1.67
1.70
1.74
1.80
1.67
1.70
1.74
1.80
1.67
1.70
1.74
1.80
1.67
1.70
1.74
1.80
1.67
1.70
1.74
1.80
1.67
1.70
1.74
1.80
CA
6,603
7,065
7,704
6,603
7,065
7,704
6,603
7,065
7,704
8,236
6,603
7,065
7,704
8,236
6,603
7,,065
7,704
8,236
6,603
7,065
7,704
8,236
6,603
7,065
7,704
8,236
6,603
7,065
7,704
8,236
6,603
7,065
7,704
8,236
SHC(W)
4,424
3,885
3,313
4,952
4,451
3,929
5,480
5,016
4,545
3,871
6,009
5,581
5,161
4,530
6,273
5,864
5,469
4,859
6,537
6,146
5,778
5,189
6,603
6,711
6,394
5,848
6,603
7,065
7,010
6,506
6,603
7,065
7,626
7,165
P.C.
1.77
1.82
1.86
1.77
1.82
1.86
1.77
1.82
1.86
1.92
1.77
1.82
1.86
1.92
1.77
1.82
1.86
1.92
1.77
1.82
1.86
1.92
1.77
1.82
1.86
1.92
1.77
1.82
1.86
1.92
1.77
1.82
1.86
1.92
COOLING CAPACITY(3)
PKA-RP3FAL / PUHZ-RP3VHA (230V)
OC301B--1.qxp 13.8.20 3:16 PM Page 16
OC301B

17
CA : Capacity (W) SHC(W) :Sensible heat capacity
P.C. : Power consumption (kW) SHF : Sensible heat factor
Outdoor intake air D.B.(°C)
35 40 45
Indoor
Intake air
D.B.(°C)
Indoor
Intake air
W.B.(°C)
20
20
20
22
22
22
24
24
24
24
26
26
26
26
27
27
27
27
28
28
28
28
30
30
30
30
32
32
32
32
34
34
34
34
16
18
20
16
18
20
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
CA
6,319
6,816
7,384
6,319
6,816
7,384
6,319
6,816
7,384
7,952
6,319
6,816
7,384
7,952
6,319
6,816
7,384
7,952
6,319
6,816
7,384
7,952
6,319
6,816
7,384
7,952
6,319
6,816
7,384
7,952
6,319
6,816
7,384
7,952
SHC(W)
4,234
3,749
3,175
4,739
4,294
3,766
5,245
4,839
4,357
3,737
5,750
5,385
4,947
4,374
6,003
5,657
5,243
4,692
6,256
5,930
5,538
5,010
6,319
6,475
6,129
5,646
6,319
6,816
6,719
6,282
6,319
6,816
7,310
6,918
P.C.
1.90
1.95
2.00
1.90
1.95
2.00
1.90
1.95
2.00
2.04
1.90
1.95
2.00
2.04
1.90
1.95
2.00
2.04
1.90
1.95
2.00
2.04
1.90
1.95
2.00
2.04
1.90
1.95
2.00
2.04
1.90
1.95
2.00
2.04
CA
6,035
6,603
7,100
6,035
6,603
7,100
6,035
6,603
7,100
7,668
6,035
6,603
7,100
7,668
6,035
6,603
7,100
7,668
6,035
6,603
7,100
7,668
6,035
6,603
7,100
7,668
6,035
6,603
7,100
7,668
6,035
6,603
7,100
7,668
SHC(W)
4,043
3,632
3,053
4,526
4,160
3,621
5,009
4,688
4,189
3,604
5,492
5,216
4,757
4,217
5,733
5,480
5,041
4,524
5,975
5,745
5,325
4,831
6,035
6,273
5,893
5,444
6,035
6,603
6,461
6,058
6,035
6,603
7,029
6,671
P.C.
2.04
2.10
2.14
2.04
2.10
2.14
2.04
2.10
2.14
2.20
2.04
2.10
2.14
2.20
2.04
2.10
2.14
2.20
2.04
2.10
2.14
2.20
2.04
2.10
2.14
2.20
2.04
2.10
2.14
2.20
2.04
2.10
2.14
2.20
CA
5,751
6,177
6,674
5,751
6,177
6,674
5,751
6,177
6,674
7,242
5,751
6,177
6,674
7,242
5,751
6,177
6,674
7,242
5,751
6,177
6,674
7,242
5,751
6,177
6,674
7,242
5,751
6,177
6,674
7,242
5,751
6,177
6,674
7,242
SHC(W)
3,853
3,397
2,870
4,313
3,892
3,404
4,773
4,386
3,938
3,404
5,233
4,880
4,472
3,983
5,463
5,127
4,739
4,273
5,693
5,374
5,006
4,562
5,751
5,868
5,539
5,142
5,751
6,177
6,073
5,721
5,751
6,177
6,607
6,301
P.C.
2.21
2.26
2.30
2.21
2.26
2.30
2.21
2.26
2.30
2.34
2.21
2.26
2.30
2.34
2.21
2.26
2.30
2.34
2.21
2.26
2.30
2.34
2.21
2.26
2.30
2.34
2.21
2.26
2.30
2.34
2.21
2.26
2.30
2.34
SHF
0.67
0.55
0.43
0.75
0.63
0.51
0.83
0.71
0.59
0.47
0.91
0.79
0.67
0.55
0.95
0.83
0.71
0.59
0.99
0.87
0.75
0.63
1.00
0.95
0.83
0.71
1.00
1.00
0.91
0.79
1.00
1.00
0.99
0.87
SHF
0.67
0.55
0.43
0.75
0.63
0.51
0.83
0.71
0.59
0.47
0.91
0.79
0.67
0.55
0.95
0.83
0.71
0.59
0.99
0.87
0.75
0.63
1.00
0.95
0.83
0.71
1.00
1.00
0.91
0.79
1.00
1.00
0.99
0.87
SHF
0.67
0.55
0.43
0.75
0.63
0.51
0.83
0.71
0.59
0.47
0.91
0.79
0.67
0.55
0.95
0.83
0.71
0.59
0.99
0.87
0.75
0.63
1.00
0.95
0.83
0.71
1.00
1.00
0.91
0.79
1.00
1.00
0.99
0.87
COOLING CAPACITY(4)
PKA-RP3FAL / PUHZ-RP3VHA (230V)
OC301B--1.qxp 13.8.20 3:16 PM Page 17
OC301B

18
CA : Capacity (W) SHC(W) :Sensible heat capacity
P.C. : Power consumption (kW) SHF : Sensible heat factor
Outdoor intake air D.B.(°C)
20 25 30
Indoor
Intake air
D.B.(°C)
Indoor
Intake air
W.B.(°C)
20
20
20
22
22
22
24
24
24
24
26
26
26
26
27
27
27
27
28
28
28
28
30
30
30
30
32
32
32
32
34
34
34
34
16
18
20
16
18
20
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
CA
9,900
10,600
11,400
9,900
10,600
11,400
9,900
10,600
11,400
12,150
9,900
10,600
11,400
12,150
9,900
10,600
11,400
12,150
9,900
10,600
11,400
12,150
9,900
10,600
11,400
12,150
9,900
10,600
11,400
12,150
9,900
10,600
11,400
12,150
SHC(W)
6,039
5,194
4,218
6,831
6,042
5,130
7,623
6,890
6,042
4,982
8,415
7,738
6,954
5,954
8,811
8,162
7,410
6,440
9,207
8,586
7,866
6,926
9,900
9,434
8,778
7,898
9,900
10,282
9,690
8,870
9,900
10,600
10,602
9,842
SHF
0.61
0.49
0.37
0.69
0.57
0.45
0.77
0.65
0.53
0.41
0.85
0.73
0.61
0.49
0.89
0.77
0.65
0.53
0.93
0.81
0.69
0.57
1.00
0.89
0.77
0.65
1.00
0.97
0.85
0.73
1.00
1.00
0.93
0.81
SHF
0.61
0.49
0.37
0.69
0.57
0.45
0.77
0.65
0.53
0.41
0.85
0.73
0.61
0.49
0.89
0.77
0.65
0.53
0.93
0.81
0.69
0.57
1.00
0.89
0.77
0.65
1.00
0.97
0.85
0.73
1.00
1.00
0.93
0.81
SHF
0.61
0.49
0.37
0.69
0.57
0.45
0.77
0.65
0.53
0.41
0.85
0.73
0.61
0.49
0.89
0.77
0.65
0.53
0.93
0.81
0.69
0.57
1.00
0.89
0.77
0.65
1.00
0.97
0.85
0.73
1.00
1.00
0.93
0.81
P.C.
2.34
2.39
2.46
2.34
2.39
2.46
2.34
2.39
2.46
2.52
2.34
2.39
2.46
2.52
2.34
2.39
2.46
2.52
2.34
2.39
2.46
2.52
2.34
2.39
2.46
2.52
2.34
2.39
2.46
2.52
2.34
2.39
2.46
2.52
CA
9,600
10,300
11,150
9,600
10,300
11,150
9,600
10,300
11,150
11,900
9,600
10,300
11,150
11,900
9,600
10,300
11,150
11,900
9,600
10,300
11,150
11,900
9,600
10,300
11,150
11,900
9,600
10,300
11,150
11,900
9,600
10,300
11,150
11,900
SHC(W)
5,856
5,047
4,126
6,624
5,871
5,018
7,392
6,695
5,910
4,879
8,160
7,519
6,802
5,831
8,544
7,931
7,248
6,307
8,928
8,343
7,694
6,783
9,600
9,167
8,586
7,735
9,600
9,991
9,478
8,687
9,600
10,300
10,370
9,639
P.C.
2.48
2.52
2.58
2.48
2.52
2.58
2.48
2.52
2.58
2.67
2.48
2.52
2.58
2.67
2.48
2.52
2.58
2.67
2.48
2.52
2.58
2.67
2.48
2.52
2.58
2.67
2.48
2.52
2.58
2.67
2.48
2.52
2.58
2.67
CA
9,300
9,950
10,850
9,300
9,950
10,850
9,300
9,950
10,850
11,600
9,300
9,950
10,850
11,600
9,300
9,950
10,850
11,600
9,300
9,950
10,850
11,600
9,300
9,950
10,850
11,600
9,300
9,950
10,850
11,600
9,300
9,950
10,850
11,600
SHC(W)
5,673
4,876
4,015
6,417
5,672
4,883
7,161
6,468
5,751
4,756
7,905
7,264
6,619
5,684
8,277
7,662
7,053
6,148
8,649
8,060
7,487
6,612
9,300
8,856
8,355
7,540
9,300
9,652
9,223
8,468
9,300
9,950
10,091
9,396
P.C.
2.62
2.70
2.75
2.62
2.70
2.75
2.62
2.70
2.75
2.84
2.62
2.70
2.75
2.84
2.62
2.70
2.75
2.84
2.62
2.70
2.75
2.84
2.62
2.70
2.75
2.84
2.62
2.70
2.75
2.84
2.62
2.70
2.75
2.84
COOLING CAPACITY(5)
PKA-RP4FAL / PUHZ-RP4VHA
PUHZ-RP4VHA1(230V)
OC301B--1.qxp 13.8.20 3:16 PM Page 18
OC301B

19
Outdoor intake air D.B.(°C)
35 40 45
Indoor
Intake air
D.B.(°C)
Indoor
Intake air
W.B.(°C)
20
20
20
22
22
22
24
24
24
24
26
26
26
26
27
27
27
27
28
28
28
28
30
30
30
30
32
32
32
32
34
34
34
34
16
18
20
16
18
20
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
CA
8,900
9,600
10,400
8,900
9,600
10,400
8,900
9,600
10,400
11,200
8,900
9,600
10,400
11,200
8,900
9,600
10,400
11,200
8,900
9,600
10,400
11,200
8,900
9,600
10,400
11,200
8,900
9,600
10,400
11,200
8,900
9,600
10,400
11,200
SHC(W)
5,429
4,704
3,848
6,141
5,472
4,680
6,853
6,240
5,512
4,592
7,565
7,008
6,344
5,488
7,921
7,392
6,760
5,936
8,277
7,776
7,176
6,384
8,900
8,544
8,008
7,280
8,900
9,312
8,840
8,176
8,900
9,600
9,672
9,072
P.C.
2.81
2.89
2.96
2.81
2.89
2.96
2.81
2.89
2.96
3.02
2.81
2.89
2.96
3.02
2.81
2.89
2.96
3.02
2.81
2.89
2.96
3.02
2.81
2.89
2.96
3.02
2.81
2.89
2.96
3.02
2.81
2.89
2.96
3.02
CA
8,500
9,300
10,000
8,500
9,300
10,000
8,500
9,300
10,000
10,800
8,500
9,300
10,000
10,800
8,500
9,300
10,000
10,800
8,500
9,300
10,000
10,800
8,500
9,300
10,000
10,800
8,500
9,300
10,000
10,800
8,500
9,300
10,000
10,800
SHC(W)
5,185
4,557
3,700
5,865
5,301
4,500
6,545
6,045
5,300
4,428
7,225
6,789
6,100
5,292
7,565
7,161
6,500
5,724
7,905
7,533
6,900
6,156
8,500
8,277
7,700
7,020
8,500
9,021
8,500
7,884
8,500
9,300
9,300
8,748
P.C.
3.02
3.11
3.16
3.02
3.11
3.16
3.02
3.11
3.16
3.25
3.02
3.11
3.16
3.25
3.02
3.11
3.16
3.25
3.02
3.11
3.16
3.25
3.02
3.11
3.16
3.25
3.02
3.11
3.16
3.25
3.02
3.11
3.16
3.25
CA
8,100
8,700
9,400
8,100
8,700
9,400
8,100
8,700
9,400
10,200
8,100
8,700
9,400
10,200
8,100
8,700
9,400
10,200
8,100
8,700
9,400
10,200
8,100
8,700
9,400
10,200
8,100
8,700
9,400
10,200
8,100
8,700
9,400
10,200
SHC(W)
4,941
4,263
3,478
5,589
4,959
4,230
6,237
5,655
4,982
4,182
6,885
6,351
5,734
4,998
7,209
6,699
6,110
5,406
7,533
7,047
6,486
5,814
8,100
7,743
7,238
6,630
8,100
8,439
7,990
7,446
8,100
8,700
8,742
8,262
P.C.
3.27
3.34
3.40
3.27
3.34
3.40
3.27
3.34
3.40
3.46
3.27
3.34
3.40
3.46
3.27
3.34
3.40
3.46
3.27
3.34
3.40
3.46
3.27
3.34
3.40
3.46
3.27
3.34
3.40
3.46
3.27
3.34
3.40
3.46
SHF
0.61
0.49
0.37
0.69
0.57
0.45
0.77
0.65
0.53
0.41
0.85
0.73
0.61
0.49
0.89
0.77
0.65
0.53
0.93
0.81
0.69
0.57
1.00
0.89
0.77
0.65
1.00
0.97
0.85
0.73
1.00
1.00
0.93
0.81
SHF
0.61
0.49
0.37
0.69
0.57
0.45
0.77
0.65
0.53
0.41
0.85
0.73
0.61
0.49
0.89
0.77
0.65
0.53
0.93
0.81
0.69
0.57
1.00
0.89
0.77
0.65
1.00
0.97
0.85
0.73
1.00
1.00
0.93
0.81
SHF
0.61
0.49
0.37
0.69
0.57
0.45
0.77
0.65
0.53
0.41
0.85
0.73
0.61
0.49
0.89
0.77
0.65
0.53
0.93
0.81
0.69
0.57
1.00
0.89
0.77
0.65
1.00
0.97
0.85
0.73
1.00
1.00
0.93
0.81
COOLING CAPACITY(6)
PKA-RP4FAL / PUHZ-RP4VHA
PUHZ-RP4VHA1
CA : Capacity (W) SHC(W) :Sensible heat capacity
P.C. : Power consumption (kW) SHF : Sensible heat factor
(230V)
OC301B--1.qxp 13.8.20 3:16 PM Page 19
OC301B

20
COOLING CAPACITY(7)
PKA-RP2.5FAL / PUH-P2.5VGAA
PUH-P2.5VGAA.UK PUH-P2.5YGAA.UK
PUH-P2.5VGAA1.UK PUH-P2.5YGAA1.UK
PU-P2.5VGAA
PU-P2.5VGAA.UK PU-P2.5YGAA.UK
PU-P2.5VGAA1.UK PU-P2.5YGAA1.UK (230V)
Outdoor intake air D.B.(°C)
20 25 30
Indoor
Intake air
D.B.(°C)
Indoor
Intake air
W.B.(°C)
20
20
20
22
22
22
24
24
24
24
26
26
26
26
27
27
27
27
28
28
28
28
30
30
30
30
32
32
32
32
34
34
34
34
16
18
20
16
18
20
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
16
18
20
22
CA
6,386
6,837
7,353
6,386
6,837
7,353
6,386
6,837
7,353
7,837
6,386
6,837
7,353
7,837
6,386
6,837
7,353
7,837
6,386
6,837
7,353
7,837
6,386
6,837
7,353
7,837
6,386
6,837
7,353
7,837
6,386
6,837
7,353
7,837
SHC(W)
4,470
3,965
3,382
4,981
4,512
3,971
5,492
5,059
4,559
3,918
6,002
5,606
5,147
4,545
6,258
5,880
5,441
4,859
6,386
6,153
5,735
5,172
6,386
6,700
6,324
5,799
6,386
6,837
6,912
6,426
6,386
6,837
7,353
7,053
SHF
0.70
0.58
0.46
0.78
0.66
0.54
0.86
0.74
0.62
0.50
0.94
0.82
0.70
0.58
0.98
0.86
0.74
0.62
1.00
0.90
0.78
0.66
1.00
0.98
0.86
0.74
1.00
1.00
0.94
0.82
1.00
1.00
1.00
0.90
SHF
0.70
0.58
0.46
0.78
0.66
0.54
0.86
0.74
0.62
0.50
0.94
0.82
0.70
0.58
0.98
0.86
0.74
0.62
1.00
0.90
0.78
0.66
1.00
0.98
0.86
0.74
1.00
1.00
0.94
0.82
1.00
1.00
1.00
0.90
SHF
0.70
0.58
0.46
0.78
0.66
0.54
0.86
0.74
0.62
0.50
0.94
0.82
0.70
0.58
0.98
0.86
0.74
0.62
1.00
0.90
0.78
0.66
1.00
0.98
0.86
0.74
1.00
1.00
0.94
0.82
1.00
1.00
1.00
0.90
P.C.
2.12
2.16
2.23
2.12
2.16
2.23
2.12
2.16
2.23
2.28
2.12
2.16
2.23
2.28
2.12
2.16
2.23
2.28
2.12
2.16
2.23
2.28
2.12
2.16
2.23
2.28
2.12
2.16
2.23
2.28
2.12
2.16
2.23
2.28
CA
6,192
6,644
7,192
6,192
6,644
7,192
6,192
6,644
7,192
7,676
6,192
6,644
7,192
7,676
6,192
6,644
7,192
7,676
6,192
6,644
7,192
7,676
6,192
6,644
7,192
7,676
6,192
6,644
7,192
7,676
6,192
6,644
7,192
7,676
SHC(W)
4,334
3,853
3,308
4,830
4,385
3,884
5,325
4,916
4,459
3,838
5,820
5,448
5,034
4,452
6,068
5,713
5,322
4,759
6,192
5,979
5,610
5,066
6,192
6,511
6,185
5,680
6,192
6,644
6,760
6,294
6,192
6,644
7,192
6,908
P.C.
2.24
2.28
2.33
2.24
2.28
2.33
2.24
2.28
2.33
2.41
2.24
2.28
2.33
2.41
2.24
2.28
2.33
2.41
2.24
2.28
2.33
2.41
2.24
2.28
2.33
2.41
2.24
2.28
2.33
2.41
2.24
2.28
2.33
2.41
CA
5,999
6,418
6,998
5,999
6,418
6,998
5,999
6,418
6,998
7,482
5,999
6,418
6,998
7,482
5,999
6,418
6,998
7,482
5,999
6,418
6,998
7,482
5,999
6,418
6,998
7,482
5,999
6,418
6,998
7,482
5,999
6,418
6,998
7,482
SHC(W)
4,199
3,722
3,219
4,679
4,236
3,779
5,159
4,749
4,339
3,741
5,639
5,263
4,899
4,340
5,879
5,519
5,179
4,639
5,999
5,776
5,459
4,938
5,999
6,289
6,018
5,537
5,999
6,418
6,578
6,135
5,999
6,418
6,998
6,734
P.C.
2.37
2.44
2.49
2.37
2.44
2.49
2.37
2.44
2.49
2.57
2.37
2.44
2.49
2.57
2.37
2.44
2.49
2.57
2.37
2.44
2.49
2.57
2.37
2.44
2.49
2.57
2.37
2.44
2.49
2.57
2.37
2.44
2.49
2.57
CA : Capacity (W) SHC(W) :Sensible heat capacity
P.C. : Power consumption (kW) SHF : Sensible heat factor
OC301B--1.qxp 13.8.20 3:16 PM Page 20
OC301B
