INSTALLATION & MAINTENANCE MANUAL
E27PR

These instructions should be read carefully and retained after installation by the end user for
future reference and maintenance.
These instructions should be used to aid installation of the following product:
E27PR
GENERAL INSTRUCTIONS
• This product must be installed in accordance with the latest edition of the IEE Wiring Regulations (BS7671)
and current Building Regulations. If in any doubt, consult a qualified electrician
• Please isolate mains prior to installation or maintenance
• Check the total load on the circuit (including when this luminaire is fitted) does not exceed the rating of the
circuit cable, fuse, or circuit breaker
• Please note the IP (Ingress Protection) rating of this luminaire when deciding the location for installation
• This product is Class I and must be earthed
• This product is IP65 rated
SAFETY
INSTALLATION
• Provide power to the required point of installation (refer to BS7671 for correct cabling methods). Suitable IP
rated junction boxes should be used where required
• Round cable should be used for the mains supply. The use of flat cable will cause water ingress to the fitting
• Remove the diffuser by removing the two screws on the top and bottom of the diffuser
• Drill out one of the 20mm drilling guides on the fitting, and fit a grommet (included) or compression gland
(not included)
• Using the back plate as a template, mark the location for, and drill the fixing holes ensuring not to infringe
with any gas/water pipes or electrical cables
• Feed the mains cable through the rubber grommet to retain IP rating

• Fix the base to a suitable solid surface using the screws provided. Rubber washers or sealant should be
applied around the screw heads to prevent water ingress
• Connect the luminaire to the mains supply ensuring the correct polarity is observed: L - Live (brown),
E - Earth (green/yellow), N - Neutral (blue)
• Add a suitable max. 100W E27 lamp
• Replace the diffuser
• Switch on and check for correct operation
WARNING
This product is not suitable for installation in or near a coastal or marine environment.
GENERAL
Clean the external surfaces with a damp cloth using a mild solution of detergent and warm water only, do not
use aggressive cleaning products or solvents which may damage the product.
This product is dimmable dependent on lamp type
This product should be recycled in the correct manner when it reaches the end of its life. Check local authorities
for where facilities exist.

AVJUN21_V2
ML Accessories Limited LU5 4LT
www.mlaccessories.co.uk
32
INTERNATIONAL
CONTACT DETAILS
INTERNATIONAL
CONTACT DETAILS
INTERNATIONAL
CONTACT DETAILS
WARRANTY
This product has a warranty of 1 year from date of purchase. Failure to install this product in accordance with
the current edition of the IEE Wiring Regulations (BS7671), improper use, or removal of the batch code will
invalidate the warranty. If this product should fail within its warranty period, it should be returned to the place
of purchase for a free of charge replacement. ML Accessories does not accept responsibility for any installation
costs associated with the replacement product. Your statutory rights are not affected. ML Accessories reserve
the right to alter product specification without prior notice.
