ML Accessories AX CCT Instruction Manual

INSTALLATION & MAINTENANCE MANUAL
AXxxxCCT

These instructions should be read carefully and retained after installation by the
end user for future reference and maintenance.
These instructions should be used to aid installation of the following products:
AX100CCT / AX150CCT / AX200CCT / AX100R / AX150R / AX200R / AX100L60 /
AX150L60 / AX200L60 / AXSMOD / AXDMOD / AXREMC / AXBRAC
GENERAL INSTRUCTIONS
SAFETY
• This product must be installed in accordance with the latest edition of the IEE Wiring
Regulations (BS7671) and current Building Regulations. If in any doubt, consult a
qualified electrician
• Please isolate mains prior to installation or maintenance
• Check the total load on the circuit (including when this luminaire is fitted) does not
exceed the rating of the circuit cable, fuse or circuit breaker
• Please note the IP (Ingress Protection) rating of this product when deciding the location
for installation
• Do not overload this accessory or subject it to conditions outside its rating
• This product is for indoor use only
• This product is Class I and must be earthed
• This product is IP65 rated

INSTALLATION
Note – Microwave sensors may not be suitable for all installations, for example enclosed
spaces, as they are able to detect movement through non-metallic surfaces like
plasterboard and thin doors.
SUSPENSION MOUNTING
• To suspend the fitting, screw the mounting hoop into the top of the luminaire and secure
with the screw provided
SURFACE MOUNTING
• When installing with the AXBRAC surface mount bracket (not included): using the bracket
as a template, mark the location for, and drill the fixing holes ensuring not to infringe with
any gas/water pipes or electrical cables
• Secure the bracket to the surface using suitable fixings which must be adequate to
support the weight of the luminaire
• Remove the bolts on either side of the bracket, align the bracket to the luminaire screw
holes, and refasten the bolts
WIRING
• Provide power to the required point of installation
• Connect the luminaire to the mains supply ensuring the correct polarity is observed: Live
(brown), Earth (green/yellow), Neutral (blue)
•
The luminaire can be connected to a0-10V dimmer (see Fig. 2). Please note that both Signal
DIP switches mustbe in the ON position for this function to operate. This luminaire canbe
controlled via DALI (AXDMOD is required, control gearand software not supplied) (see Fig. 1)

Provide power to the required point of installation
Connect the luminaire to the mains supply ensuring the correct polarity is observed: Live (brown),
Earth (green/yellow), Neutral (blue)
The luminaire can be connected to a 0-10V dimmer or DALI control gear (not supplied) (see Fig. 1)
Fig. 1
Select the colour temperature by means of the DIP switches located on the front of the fitting
(see Fig. 2)
Fig. 1
• Select the colour temperature by means of the DIP switches located on the front of the
fitting (see Fig. 2)
CCT DIP SWITCH SETTINGS
Fig. 2
3000K
CCT Signal
4000K
5000K
0~10V
DALI
O N
O N

Additional accessories (sold separately)
AXxxxL60 LENS
• To replace the 120° lens supplied with the optional 60° lens AXxxxL60: remove all the
screws that attach the lens to the luminaire, remove the lens, then attach the 60° lens
and replace the screws
AXxxxR REFLECTOR
• Using an Allen key (not provided) remove the outer screws around the lens, match the
reflector onto the holes, attach to the luminaire using the screws provided with the
reflector
AXDMOD / AXSMOD MODULE
• Ensuring there is no power to the fitting, remove the IP65 cover from the centre of the
luminaire by rotating anti-clockwise 30°
• Align either the Microwave sensor or DALI module into the centre of the fitting, push on
and turn clockwise 30° (see Fig. 3)
