Modern Flames OR30-SLIM-INT User manual

ORION SLIM WALL-MOUNT/RECESSED ELECTRIC FIREPLACE
Model #: OR30-SLIM-INT OR52-SLIM-INT OR60-SLIM-INT
OR76-SLIM-INT OR100-SLIM-INT
OWNER’S MANUAL
AC 220-240V, 50Hz 1,500W
（OR30-SLIM-INT, AC 220-240V, 50Hz 1,200W）

2
www.modernflames.com
Read all instructions before installing or using this heater.
Use a dedicated 13 Amp (EU) or a 10 Amp (AU/NZ) breaker.
This heater is hot when in use. To avoid burns, DO NOT let bare skin touch hot surfaces. If
provided, use handles when moving this heater. Keep combustible materials, such as furniture,
pillows, bedding, papers, clothes, and curtains at least 3 feet (0.9m) from the front of the heater
and keep them away from the sides and rear.
Extreme caution is necessary when any heater is used by or near children or invalids and
whenever the heater is left operating and unattended.
Do not operate any heater if it malfunctions. Disconnect power at service panel and have the
heater inspected by a reputable electrician before reusing.
To disconnect the heater, turn the controls to off, and turn off power to the heater circuit at the
main disconnect panel (or operate internal disconnect switch if provided).
Do not insert or allow foreign objects to enter any ventilation or exhaust opening as this may
cause an electric shock, fire, or damage the heater.
To prevent a possible fire, do not block air intakes or exhaust in any manner.
A heater has hot arcing or sparking parts inside. Do not use in areas where gasoline, paint,
flammable vapors, or liquids are used or stored.
Use this heater only as described in this manual. Any other use not recommended by the
manufacturer may cause fire, electric shock, or injury to persons.
This heater may include an audible or visual alarm to warn that parts of the heater are getting
excessively hot. If the alarm sounds (or illuminates), immediately turn the heater off and
inspect for any objects on or adjacent to the heater that may have blocked the airflow or
otherwise caused high temperatures to have occurred. DO NOT OPERATE THE HEATER
WITH THE ALARM SOUNDING (OR ILLUMINATING).
ALWAYS plug heaters directly into a wall outlet/receptacle. NEVER use with an extension cord
or relocatable power tap (outlet/power strip).
NEVER use this heater in bathrooms, laundry rooms, or any other location where the heater
could fall into a bathtub, pool, become damp, or come in contact with water.
AVOID FIRE! Regularly inspect all air vents to make sure they are free from dust, lint, or other
blockage. Unplug the unit and clean with a vacuum ONLY. DO NOT rinse or get wet.
ALWAYS mount to wall bracket before use. DO NOT set on the floor, or other surface, to use.
NEVER use a wall mount bracket from another manufacturer.
This product is not intended to be a primary heat source. It is for supplemental heat only.
INDOOR use only! NEVER use this heater outdoors! Doing so may result in electric shock!

3
www.modernflames.com
ALWAYS disconnect this unit from the power supply before performing any assembly,
cleaning, or before relocating the electric fireplace.
NEVER leave this heater unattended. ALWAYS unplug this heater when not in use.
ALWAYS store this heater in a dry location. NEVER use the fireplace if it has become wet.
NEVER plug this heater into an outlet that is old, cracked, or has loose wires or connections.
Plugging this heater into a faulty outlet could result in electric arcing within the outlet that could
cause the outlet to overheat or catch fire.
ALWAYS check your heater cord and plug connections with each use.
i) MAKE SURE the plug fits tightly in the outlet. Faulty wall outlet connections or loose
plugs can cause the outlet to overheat.
ii) Heaters draw more current than small appliances. Overheating may occur even if it has
not occurred with the use of other appliances.
iii) During use, check frequently to see if the plug outlet or face plate is HOT.
iv) If the outlet or face plate is HOT, discontinue use immediately and have a qualified
electrician inspect and/or replace the faulty outlets.
SAVE THESE INSTRUCTIONS

4
www.modernflames.com
Table of Contents
PREPARATION ......................................................................................................................................................................................5
PARTS AND HARDWARE ...................................................................................................................................................................... 5
DIMENSIONS AND SPECIFICATIONS .....................................................................................................................................................5
PRODUCT DIMENSIONS .......................................................................................................................................................................... 6
INSTALLATION AND ASSEMBLY ........................................................................................................................................................... 6
FRONT GLASS REMOVAL/INSTALLATION .............................................................................................................................................6
WALL RECESSED FRAMING .................................................................................................................................................................. 7
FINISHED OPENING DIMENSIONS ...........................................................................................................................................................8
WALL RECESSED INSTALLATION ...........................................................................................................................................................8
WALL MOUNTED INSTALLATION ....................................................................................................................................................... 10
HARDWIRING INSTALLATION ............................................................................................................................................................ 11
DRIFTWOOD LOGS AND CRUSHED GLASS INSTALLATION ..................................................................................................................12
OPERATION ........................................................................................................................................................................................13
Power ................................................................................................................................................................................................13
Master Power Switch ........................................................................................................................................................................13
OPERATION (CONTINUED) .................................................................................................................................................................14
Methods of Operation ...................................................................................................................................................................... 14
OPERATION – TOUCH CONTROL PANEL .............................................................................................................................................15
OPERATION – REMOTE CONTROL ......................................................................................................................................................16
DOWNLOAD SMART PHONE APP ...................................................................................................................................................... 18
WI-FI – INITIAL LOG-IN .......................................................................................................................................................................19
Add Manually ................................................................................................................................................................................... 20
Auto Scan ..........................................................................................................................................................................................23
OPERATION – SMART PHONE APP .....................................................................................................................................................26
HOME SCREEN .......................................................................................................................................................................................... 26
FLAME STYLE OPTIONS ............................................................................................................................................................................... 27
FLAME STYLE ONE/TWO/THREE COLOR MENU ..............................................................................................................................................28
CUSTOM MODE MENU .............................................................................................................................................................................. 29
DOWNLIGHT MENU ................................................................................................................................................................................... 30
EMBER BED MENU .................................................................................................................................................................................... 31
HEATER MENU ..........................................................................................................................................................................................32
TIMER MENU ............................................................................................................................................................................................33
WEEKLY PROGRAM SCHEDULE MENU ........................................................................................................................................................... 34
DAILY PROGRAM SCHEDULE MENU .............................................................................................................................................................. 35
OPERATION – IMPORTANT WARNINGS .............................................................................................................................................36
Remote Control Battery Information ................................................................................................................................................36
Temperature Limiting Control .......................................................................................................................................................... 36
CARE – CLEANING .............................................................................................................................................................................. 37
CARE – MAINTENANCE ...................................................................................................................................................................... 37
Electrical and Moving Parts: .............................................................................................................................................................37
Storage: ............................................................................................................................................................................................ 37
REPLACEMENT PARTS LIST .................................................................................................................................................................38
TROUBLESHOOTING / FAQ ................................................................................................................................................................ 40

5
www.modernflames.com
Preparation
This product includes a GLASS panel. Always use extreme caution when handling
glass. Failure to do so could result in personal injury or property damage.
Remove all parts and hardware from the carton and place them on a clean, soft, dry surface. Parts
and assembly steps are grouped for wall-hanging or recessing use. Check the parts list to make
sure nothing is missing. Dispose of packaging materials properly. Please recycle whenever possible.
You will need the following tools (not included): Phillips screwdriver, stud finder, level, tape measure,
electric drill, 1/4” wood drill bit, hammer.
Parts and Hardware
PART NO.
DESCRIPTION
PART NO.
DESCRIPTION
A
Screws (Long)
F
Strain Relief
B
Drywall Anchor
G
Cover Plate
C
Screws (Short)
H
Wall Mount Bracket
D
Side Skirt
I
Crushed Glass
E
Remote Control
J
Driftwood Logs
Dimensions and Specifications

6
www.modernflames.com
PRODUCT DIMENSIONS
Model
Number
A
B
C
D
E
F
G
H
I
J
K
OR30-SLIM-
INT
30-13/16"
(783mm)
19-5/8"
(499mm)
6-5/16"
(160mm)
28-3/4"
(730mm)
18-3/4”
(476mm)
5-3/4"
(146mm)
26-3/8"
(669mm)
14-3/8"
(364mm)
5"
(127mm)
1-1/4”
(32mm)
75"
(1905mm)
OR52-SLIM-
INT
52-3/8"
(1330mm)
19-5/8"
(499mm)
6-5/16"
(160mm)
50-1/4"
(1276mm)
18-3/4”
(476mm)
5-3/4"
(146mm)
47-7/8"
(1216mm)
14-3/8"
(364mm)
5"
(127mm)
1-1/4”
(32mm)
75"
(1905mm)
OR60-SLIM-
INT
60"
(1524mm)
19-5/8"
(499mm)
6-5/16"
(160mm)
58"
(1473mm)
18-3/4”
(476mm)
5-3/4"
(146mm)
55-1/2"
(1410m m)
14-3/8"
(364mm)
5"
(127mm)
1-1/4”
(32mm)
75"
(1905mm)
OR76-SLIM-
INT
76-5/8"
(1947mm)
19-5/8"
(499mm)
6-5/16"
(160mm)
74-5/8"
(1895mm)
18-3/4”
(476mm)
5-3/4"
(146mm)
72-3/16"
(1833mm)
14-3/8"
(364mm)
5"
(127mm)
1-1/4”
(32mm)
75"
(1905mm)
OR100-SLIM-
INT
101"
(2564mm)
19-5/8"
(499mm)
6-5/16"
(160mm)
98-7/8"
(2511mm)
18-3/4”
(476mm)
5-3/4"
(146mm)
96-7/16"
(2450mm)
14-3/8"
(364mm)
5"
(127mm)
1-1/4”
(32mm)
75"
(1905mm)
Installation and Assembly
Your appliance is a wall-mounted, recessed, and/or mantel installed appliance. Select a suitable
location that is not susceptible to moisture and is away from drapes, furniture, and high traffic areas.
NOTE: Follow all National and local electrical codes.
MINIMUM CLEARANCE TO COMBUSTIBLES
Measurements are taken from the glass front.
Bottom……………………...0"
Sides………………………..0"
Back………………………...0"
Top (to mantel)………………………11.8" (300mm)
Top (to TV)…………………………...11.8" (300mm)
Top (to ceiling)……………………….11.8" (300mm)
Front Glass Removal/Installation
This product includes a GLASS panel. Always use extreme caution when handling
glass. Failure to do so could result in personal injury or property damage.

7
www.modernflames.com
With one hand on the front glass to prevent it from falling, remove the two screws (one per side) from
the side of the appliance (Fig. 1-1). Set the screws aside.
Carefully lift the front glass up and away from the appliance (Fig. 1-2). Place it face down on a soft,
non-abrasive surface.
Reverse these steps to re-install the front glass.
Wall Recessed Framing

8
www.modernflames.com
Select a location that is not prone to moisture and is located at least 36” (914mm) away from
combustible materials such as curtain drapes, furniture, bedding, paper, etc.
Measure the appliance and create a rough-in frame with electrical (see below).
Remove the front glass (see “Front Glass Removal / Installation” section).
Hold the appliance up to ensure it will fit into the framing.
FINISHED OPENING DIMENSIONS
Model Number
A
B
C
OR30-SLIM-INT
29-1/4"
(743mm)
19-1/8"
(486mm)
6" min.
(152mm min.)
OR52-SLIM-INT
50-3/4"
(1289mm)
19-1/8"
(486mm)
6" min.
(152mm min.)
OR60-SLIM-INT
58-1/2"
(1486mm)
19-1/8"
(486mm)
6" min.
(152mm min.)
OR76-SLIM-INT
75-1/8"
(1908mm)
19-1/8"
(486mm)
6" min.
(152mm min.)
OR100-SLIM-INT
99-1/2"
(2527mm)
19-1/8"
(486mm)
6" min.
(152mm min.)
Wall Recessed Installation
Remove power cord and complete hardwiring (see “Hardwiring Installation” section).
Remove the two screws (one per side) from the inside of the appliance and remove the interior
walls. (Fig.2-1). Set the screws/walls aside.

9
www.modernflames.com
Insert the appliance into the opening (See “Finished Opening Dimensions”) (Fig.2-2) and then
secure it by installing 4 screws (supplied) into the slots on the insides (2 per side) (Fig.2-3).
Next reinstall the two interior walls and two screws previously removed. (Fig.2-4).
Re-install the front glass. (Fig.2-5)

10
www.modernflames.com
FAILURE TO DO SO CAN RESULT IN PERSONAL INJURY
AND/OR DAMAGE TO EQUIPMENT.
Wall Mounted Installation
NOTE: A dedicated 13 Amp (EU) or 10 Amp (AU/NZ) breaker is required.
Select a location that is not prone to moisture and is located at least 36" (914mm) away from
combustible materials such as curtain drapes, furniture, bedding, paper, etc.
Have two people hold the appliance against the wall to determine the final location.
Place the unit face down on a soft, non-abrasive surface.
Remove the wall bracket (H) from the back of the unit by removing the screws, see FIG. 3-1. Set
screws aside.
After you have selected a suitable location for wall mounting, locate the studs on the wall. You
must be able to secure to a minimum of 2 studs for proper installation of the bracket.
Using the wall bracket as a guide, mark the mounting hole locations.
This bracket MUST have the hooks facing upward and be level.
Additional support is provided by using the included wall anchors (B) between the studs.
Additional wall anchors must be installed prior to the wall bracket being mounted.
i. To install additional wall anchors, pre-drill (optional) all locations with a 1/4" drill bit.
ii. Install the wall anchors with a Philips tip screwdriver.
Install the wall bracket to the studs using #8 – 1-5/8" (A) screws and to the wall anchors with a
#8 – 1" screws (C).
With the wall mounting bracket installed, have two people lift the appliance up and insert the two
hooks of the wall bracket into the two receiver slots on the back of the appliance.
Re-insert the two screws that were removed previously.
Check the appliance for stability ensuring the bracket will not pull free from the wall.
Install the side skirt panels (D) to each side of firebox. FIG 3-2.

11
www.modernflames.com
Hardwiring Installation
If it is necessary to hardwire this appliance, a qualified electrician must remove the cord connection and
wire the appliance directly to the household wiring.
NOTE: A dedicated 13 Amp (EU) or 10 Amp (AU/NZ) breaker is required.
Note:
There are 3 wires from the appliance junction box: light blue (neutral), brown (power L1), and yellow/green
(ground) that are connected to 240V power source (circuit breaker panel).
Remove the 4 securing screws from the junction box cover plate, located on the bottom left-hand,
back-side of the appliance (Fig. 4-1).
Install the strain relief to the new junction box cover plate (located in hardware bag) (Fig. 4-2).
Separate the black, white, and green wires that have the wire nuts on them.
Remove all the wire nuts. Connect the green wire (G) to the supply ground wire, the white wire (N) to
the supply Neutral wire, and the black wire (L) to the supply line/hot wire. (Fig. 4-3).
Secure the new junction box cover plate by using the 4 screws previously removed.
Junction Box
Cover Plate

12
www.modernflames.com
Driftwood Logs and Crushed Glass Installation
Front glass must be removed and the appliance must be mounted in its final location before the
driftwood logs and crushed glass is installed.
Install driftwood logs first, then add the crushed glass around logs.
If crushed glass falls into the channel used by the front glass, preventing the front glass from being
installed, the channel can be cleared by sliding the crushed glass along the channel until it falls into
one of the cleanout slots.
Photos below shows recommended log placement, but logs may be arranged to customer’s liking.

13
www.modernflames.com
Read and understand this entire owner’s manual, including all safety
information, before plugging in or using this product. Failure to do so
could result in electric shock, fire, serious injury, or death.
Operation
Power
Plug the power cord into a dedicated 240 Volt 13 Amp (EU) or 10 Amp (AU/NZ) grounded outlet (see
IMPORTANT SAFETY INFORMATION). A dedicated circuit is preferred but not essential in all cases. A
dedicated circuit will be required if after installation, the circuit breaker trips on a regular basis when
heater is operating. Make sure the outlet is in good condition and the plug is not loose. NEVER exceed
the maximum amperage for the circuit.
Master Power Switch
Located above the Touch Control Panel is the Master Power Switch. Ensure the rocker switch is pressed
in the “On” position prior to operating the fireplace.
Note: After resetting the Master Power Switch or from a loss of power, the fireplace takes 20-30 seconds
before the fireplace is fully booted and operational.
Pairing the Remote
With the fireplace ON, press and hold the Power button on the fireplace for 5 seconds until you
hear a beep from the fireplace. “P1” will be shown on the display.
Within 5 seconds of the fireplace beeping, repeatedly press the power button on the remote until
the fireplace beeps again.
Pairing must be completed within 5 seconds or the fireplace pairing will time out of pairing mode.

14
www.modernflames.com
Operation (Continued)
Methods of Operation
This electric fireplace can be operated by the TOUCH CONTROL PANEL located on the UPPER right
corner of the fireplace, by the battery-powered REMOTE CONTROL, or by the MODERN FLAMES APP
using a smart phone.
Touch Control Panel
Remote Control
Modern Flames App

15
www.modernflames.com
Operation – Touch Control Panel
Touch Panel Operation
Button
Function
Action
ON: Enables control panel functions. Turns
on flame.
OFF: Disables control panel functions.
Turns off flame.
1. Press once: Indicator light turns on. Power turns
on. All functions enabled.
2. Press again: Flame turns off. Unit goes to standby.
All functions turn off.
3. NOTE: Press and Hold for 5 seconds: Places
fireplace in remote paring mode. Displays P1 during
pairing
FLAME BUTTON: Changes between
flame presets.
NOTE: Color effect stays on until power
button is turned off.
This fireplace has memory function for
flame presets.
1. Press once: Flame color illuminates.
2. Press again until preset color is reached. In total,
three styles of flame with six colors for each flame.
NOTE: Press and hold for 5 seconds to start
connecting with App.
DOWNLIGHT BUTTON: Cycles down light
colors.
NOTE: Downlight color effect stays on until
power button is turned off.
This fireplace has memory function for
down light settings.
1. Press once: Cycle Down light.
2. Press again until desired color is reached. In total
ten colors and one fade mode.01-02-03-04-05-06-07-
08-09-10-11-00 (off)
NOTE: Press and hold for 5 seconds to turn on/off
night light mode.
MEDIA BED BUTTON: Cycles media bed
colors.
NOTE: Media bed color effect stays on
until power button is turned off.
This fireplace has memory function for
media bed settings.
1. Press once: Turns on ember bed.
2. Press again until desired color is reached. In total
ten colors and one fade mode.01-02-03-04-05-06-07-
08-09-10-11-00 (off).
HEATER BUTTON: Turns heater on and
off.
NOTE: The heater only works when the
flame is on. If the flame is off, the heater
will not turn on.
NOTE: To prevent overheating, the heater
fan will blow cool air for 8-10 seconds after
the heater turns off.
1. Press once: Turns the heater and blower on.
2. Press again until it cycles thru the heater settings.
Settings:
H0 - Heater and blower off
F– Fan only
H1 - Low Heater
H2 - High Heater
NOTE: Press and hold the heater button for 5
seconds to lock/unlock the heater and thermostat. H0
will be displayed when locked.
THERMOSTAT BUTTON: Turns heater on
/ off to maintain room at selected
temperature.
NOTE: Press the button for 5 seconds to
switch between °C and °F.
1. Press once: Touch-on control panel indicator
becomes active.
2. Press again until desired temperature is reached.
Digital display shows settings 0-10. Table shows
corresponding temperatures.
NO
0
1
2
3
4
5
6
7
8
9
10
NO
°C
20
21
22
23
24
25
26
27
28
29
30
°C
°F
68
70
72
74
76
78
80
82
84
86
88
°F

16
www.modernflames.com
Operation – Remote Control
Remote Control Operation
Button
Function
Action
ON: Enables control panel functions.
Turns on flame.
OFF: Disables control panel functions.
Turns off flame.
1. Press once: Indicator light turns on. Power turns on. All
functions enabled.
2. Press again: Flame turns off. Unit goes to standby. All
functions turn off.
HOME BUTTON: Returns the fireplace
to the default color settings.
1. Press once: Flame video changes to flame style 1, color
yellow. Ember bed and down light changes to orange.
Flame speed changes to default and sound level changes
to low.
FLAME BUTTON: Cycles between
flame styles.
ʌ: Cycles up between preset of current
flame styles.
v: Cycles down between preset of
current flame styles.
+: Increases flame speed of current
flame style and color.
--: Decrease flame speed of current
flame style and color.
NOTE: This fireplace has memory
function for flame.
1. Press flame button once: Flame switches to next flame
style in the sequence.
2. Press flame button again until desired style is reached.
In total, three flame styles.
Note: Press and hold for 5 seconds enables Wi-Fi pairing
mode
3. Press ʌ once: Changes up to the next preset of current
flame style.
4. Press ʌ again until desired preset is selected from
1C-2C-3C-4C-5C-6C.
5. Press v once: Changes down to the next preset of
current flame style.
6. Press v again until desired preset is selected from
6C-5C-4C-3C-2C-1C.
7. Press + button to increase the flame speed.
Displayed: 01-02-03.
8. Press button to decrease the flame speed.
Displayed: 03-02-01.
AUDIO BUTTON: Raises and lowers
the audio from the fireplace.
1. Press once: Changes the volume level.
2. Press again cycles between volume settings.
Volume settings:
S0 - Off
S1 - Low
S2 - Medium
S3 - High
DOWNLIGHT BUTTON: Cycles down
light colors.
NOTE: Downlight color effect stays on
until power button is turned off.
This fireplace has memory function for
down light settings.
1. Press once: Cycle downlight.
2. Press again until desired color is reached. In total ten
colors and one fade mode.01-02-03-04-05-06-07-08-09-10-
11
NOTE: Press and hold for 5 seconds to turn on/off night
light mode.
DOWNLIGHT BRIGHTNESS BUTTON:
Makes downlight dimmer and brighter.
NOTE: LED down light brightness stays
on until power button is turned off.
1. Press once: Brightness becomes active.
2. Press again until desired setting is reached. In total 5
levels.
From L4 - L3 - L2 - L1 - L0 (off)

17
www.modernflames.com
Operation – Remote Control (Continued)
Button
Function
Action
MEDIA BED BUTTON: Cycles media bed
colors.
NOTE: Media bed color effect stays on
until power button is turned off.
This fireplace has memory function for
media bed settings.
1. Press once: Turns on ember bed.
2. Press again until desired color is reached. In total
ten colors and one fade mode.01-02-03-04-05-06-07-
08-09-10-11
MEDIA BRIGHTNESS BUTTON: Makes
media bed dimmer and brighter.
NOTE: LED media light brightness stays
on until power button is turned off.
1. Press once: Brightness becomes active.
2. Press again until desired setting is reached. In total
5 levels.
From E4 - E3 - E2 - E1 - E0 (off)
TIMER BUTTON: Controls timer settings
to turn off fireplace at selected time.
Settings range from 30 min to 8 hours.
1. Press once: Indicator light turns on. Timer defaults
to 0.5 hours.
2. Press again until desired setting is reached.
00(off)-30-1H-2H-3H-4H-5H-6H-7H-8H
HEATER BUTTON: Turns heater on and
off.
NOTE: The heater only works when the
flame is on. If the flame is off, the heater
will not turn on.
NOTE: To prevent overheating, the heater
fan will blow cool air for 8-10 seconds after
the heater turns off.
1. Press once: Turns the heater and blower on.
2. Pressing Additionally: Cycles thru heater settings.
Settings:
H0 - Heater and blower off
F– Fan only
H1 - Low Heater
H2 - High Heater
NOTE: Press and hold the heater button for 5
seconds to lock/unlock the heater and thermostat. H0
will be displayed when locked.

18
www.modernflames.com
Download Smart Phone App
Smart Phone App Connection
Note: Download the Modern Flames App from your App store before connecting
Download Mobile App

19
www.modernflames.com
Wi-Fi – Initial Log-in
Search for and install the “Modern Flames” app from the Google Play or Apple App store or scan the
QR code on the previous page.
After the App is installed, log in to the Modern Flames App. Must have Wi-Fi and Bluetooth enabled
on your smart phone.
Once opened from the home page, select the add “+” symbol.

20
www.modernflames.com
Wi-Fi – Pairing
Add Manually
Select the series of fireplace that will be paired with and follow the instructions.
When pairing via Wi-Fi, the 2.4 GHz Wi-Fi signal must be used. Ensure the appropriate login
information is entered before continuing to the next step.
