modway Rendezvous EEI-2548 User manual

BENCH
bench
EEI-2548 BENCH
4
4
4
4
Side Arms ×2 Seat Cushion ×1 4
Seat Frame
×1 Legs ×4
E
Flat Washer M8 ×10
Bolt M8×50mm ×10
Spring Washer M8 ×10
Plastic Washer ×4
(Remarks: If damaged or the chair is not even
after assembly can be used as backup.)
3
and then follow the simple step-by-step
f reach of children.

EEI-2548 BENCH
A×5 B×5 C×5
A×5 B×5 C×5
STEP1:
STEP2:
Legs Package
+
Hardware Package
Please open the Velcro on the bottom of Seat Frame (3) to find legs package and hardware package.
Attach one of Side Arm (1) and Seat Frame (3) by 5 pieces of Bolt (A), 5 pieces of Spring Washer (B),
and 5 pieces of Flat Washer (C) as shown. Do not fully tighten Bolts (A).
Repeat the same step for another Side Arm (1).
E
C
B
A
A
B
C
E
E×1
E×1

inside
4
EEI-2548 BENCH
D×4
Carefully turn over the bench.
STEP3:
STEP4:
Assembly is complete. The bench
is ready to use now!
Recover the Velcro on the bottom of Seat Frame (3). Insert Legs (4) with 4 pieces of Plastic Washer
(D) into the bottom of Seat Frame (3) until secured tightly and right position as shown. Put the Seat
Cushion (2) to the Seat Frame (3).
Attention: Please pay attention to the direction of the legs.
The toped edge of legs is positioned inside. Please assemble it in the right position as shown.
