Molpir DD-MOL-005 User manual

Installation manual
Date: 28. 9. 2020 NM_DD-MOL-005_000_28092020_EN.doc ©MOLPIR 2020. All rig ts reserved .
Disinfectant dispenser; non-contact; spray; for
the pole with diameter 30 mm
Ordering code: DD-MOL-005
T ank You for purc asing our product. Read t is Installation manual carefully before t e installation of t e product.

Date: 28. 9. 2020 NM_DD-MOL-005_000_28092020_EN.doc Page 2/12
Components list
Note: T e dispenser ① as already mounted t e bracket ③ on its back.
Poz.
Poz.Poz.
Poz. Názov
NázovNázov
Názov Kód
KódKód
Kód K
KK
Ks
ss
s
① Disinfectant dispenser; non-contact; 600 ml; spray; w ite DD-MOL-000 1
② Disinfectant dispenser key DD-MOL-302 1
③ Bracket plate of disinfectant dispenser for t e pole wit 30 - 35 mm diameter 0811377-M 1
④ Reduction for clamping on t e rod d = 30mm; for non-contact dispenser 0811378-M 1
⑤ Bracket for t e pole wit 30 mm diameter 0811379-M 2
⑥ Rear cover of t e dispenser for t e pole diameter 30/34/ 35mm 068754-M 1
⑦ Gasket for t e rear cover of t e dispenser for t e pole diameter 30 mm 0690030-30 2
⑧ Screw M5x20 mm wit round ead Torx 25 105BN6404M5x20 4
⑨ Screw M4x10 mm wit round ead Torx 20 104BN6404M4x10 4
⑩ Was er D4,3 mm x D12 mm x H1,6 mm 104BN733D4 4
⑪ Screw M4x10mm wit round ead Torx 20 104BN6404M4x10 6
⑫ Self-tapping screw 4,8x19mm wit round ead; P ilips 104BN18784,8x19 1
⑬ Disinfectant tank ND-DD-MOL-000.1 1
⑭ Control unit of t e dispenser ND-DD-MOL-000.2 1

Date: 28. 9. 2020 NM_DD-MOL-005_000_28092020_EN.doc Page 3/12
Tools necessary for t e installation
•screwdriver Torx 20
•screwdriver Torx 25
•scissors
•Driver-Drill + P ilips bit (for mounting self-tapping screw ⑫)
Installation procedure
Mount t e brackets ⑤ wit t e screws ⑧. Before Place t e dispenser on propper place.
Palcing t e dispenser to t e pole insert t e reduction
For clamping for t e pole diameter 30 mm ④.

Date: 28. 9. 2020 NM_DD-MOL-005_000_28092020_EN.doc Page 4/12
Mount t e second screws ⑧ and tig t t em evenly to assure t e same gaps between t e main bracket plate ③ and
t e brackets ⑤.
To avoid „rotating“ dispenser on t e
pole we suggest to secure it by self-
tapping screw ⑫ (follow internal rules
for possibility to drill t e pole).
For installation of self-tapping screw use
Driver-drill tool.

Date: 28. 9. 2020 NM_DD-MOL-005_000_28092020_EN.doc Page 5/12
Cut t e gaskets ⑦ at t e indicated place on t e gasket so t at t ey can be fitted to t e pole.

Date: 28. 9. 2020 NM_DD-MOL-005_000_28092020_EN.doc Page 6/12
Placet e gaskets ⑦ on t e pole (2 pcs) on t e upper and bottom side of t e dispenser so t at t e gaskets fit exactly
into t e slots in t e metal older of t e dispenser③.

Date: 28. 9. 2020 NM_DD-MOL-005_000_28092020_EN.doc Page 7/12
Place t e rear cover of t e dispenser ⑥ - first t e lower side and t en t e upper side and c eck t at t e rear cover fits
exactly into t e grooves of t e gaskets.

Date: 28. 9. 2020 NM_DD-MOL-005_000_28092020_EN.doc Page 8/12
Use 6 screws ⑪ to firmly attac t e back cover to t e dispenser body.

Date: 28. 9. 2020 NM_DD-MOL-005_000_28092020_EN.doc Page 9/12
Preparation for operation
Use t e key ②and open t e front cover of t e dispenser.

Date: 28. 9. 2020 NM_DD-MOL-005_000_28092020_EN.doc Page 10/12
Inserting batteries
Open t e battery cover by pus ing t e latc in t e direction of t e arrow and t en remove t e battery cover.
Insert 4 pcs new AA alkaline batteries so t at t e polarity of t e inserted batteries matc es t e polarity markings on t e
dispenser control unit body.
Replace t e battery cover and secure t e cover latc .

Date: 28. 9. 2020 NM_DD-MOL-005_000_28092020_EN.doc Page 11/12
Pouring disinfectant
Remove t e cap of disinfectant tank and fill t e reservoir wit a suitable disinfectant. T en close t e tank wit t e cap.
Use a funnel for filling to prevent t e disinfectant from spilling!
Do not overfill t e tank! T e volume of t e tank is 600 ml.
Recommended disinfectant may contain max. 75 % of alco ol.

Date: 28. 9. 2020 NM_DD-MOL-005_000_28092020_EN.doc Page 12/12
Dose volume setting
Switc t e main switc to position I or II to select t e volume of eac dose (position I is 0.5 ml; position II is 1.0 ml) and
t en close t e front cover of t e dispenser. T is sets t e dispenser to energy saving mode and it "waits" for t e ands to
approac t e detection space under t e dispenser nozzle.
Make several “sprays” by repeatedly placing your ands under t e dispenser to expel air from t e disinfectant transport
tubes in t e dispenser control unit.
After closing t e front cover and removing t e key, t e dispenser is ready for normal use.
