Monicon CHR-1445 User manual

Monicon Instruments Co., Ltd. CHR-1445/2685
BATTERY CHARGER
CHR-1445 / 2685
TEL：[phone]
FAX：[phone]
Web Site：http://www.monicon.com.tw
E-mail：[email protected]
Copyright © 2007 Monicon Instruments Co., Ltd. All right reserved. Contents in this
publication may not be reproduced in any form without the expressed written permission of
Monicon Instruments Co., Ltd

Monicon Instruments Co., Ltd. CHR-1445/2685
Important Safety Instruction
Warning:
1. SAVE THESE INSTRUCTIONS –This manual contains important safety and operating
instructions for battery charger Model CHR-1445 / 2685.
2. Do not expose charger to rain or snow.
3. Use of an attachment not recommended or sold by the battery charger manufacturer may
result in a risk of fire, electric shock, or injury to persons.
4. To reduce risk of damage to electric plug and cord, pull by plug rather than cord when
disconnecting charger.
5. An extension cord should not be used unless absolutely necessary, Use of improper
extension cord could result in a risk of fire and electric shock. If an extension cord must
be used, make sure:
a) That pins on plug of extension cord are the same number, size, and shape as
those of plug on charger;
b) That extension cord is properly wired and in good electrical condition; and
c) That wire size is large enough for ac ampere rating of charger as specified in
Table 1.1

Monicon Instruments Co., Ltd. CHR-1445/2685
6. Do not operate charger with damaged cord or plug –replace the cord or plug
immediately.
7. Do not operate charger if it has received a sharp blow, been dropped, or otherwise
damaged in any way; take it to a qualified serviceman.
8. Do not disassemble charger; take it to a qualified serviceman when service or repair is
required. Incorrect reassembly may result in a risk of electric shock or fire.
9. To reduce risk of electric shock, unplug charger from outlet before attempting any
maintenance or cleaning. Turning off controls will not reduce this risk.
10. WARNING –RISK OF EXPLOSIVE GASES.
a) WORKING IN VICINITY OF A LEAD-ACID BATTERY IS DANGEROUS.
BATTERIES GENERATE EXPLOSIVE GASES DURING NORMAL
BATTERY OPERATION. FOR THIS REASON, IT IS OF UTMOST
IMPORTANCE THAT YOU FOLLOW THE INSTRUCTINOS EACH
TIME YOU USE THE CHARGER.
b) To reduce risk of battery explosion, follow these instructions and those
published by battery manufacturer and manufacturer of any equipment you
intend to use in vicinity of battery. Review cautionary marking on these
products and on engine.
11. PERSONAL PRECAUTIONS
a) Consider having someone close enough by to come to your aid when you
work near a lead-acid battery.
b) Have plenty of fresh water and soap nearby in case battery acid contacts skin,
clothing, or eyes.
c) Wear complete eye protection and clothing protection. Avoid touching eyes
while working near battery.
d) If battery acid contacts skin or clothing, wash immediately with soap and
water. If acid enters eye, immediately flood eye with running cold water for at
least 10 minutes and get medical attention immediately.
e) NEVER smoke or allow a spark or flame in vicinity of battery or engine.
f) Be extra cautious to reduce risk of dropping a metal tool onto battery. It might
spark or short-circuit battery or other electrical part that may cause explosion.
g) Remove personal metal items such as rings, bracelets, necklaces, and watches
when working with a lead-acid battery. A lead-acid battery can produce a
short-circuit current high enough to weld a ring or the like to metal, causing a
severe burn.
h) Use charger for charging a LEAD-ACID battery only. It is not intended to
supply power to a low voltage electrical system other than in a starter-motor
application. Do not use battery charger to charging dry-cell batteries that are

Monicon Instruments Co., Ltd. CHR-1445/2685
commonly used with home appliances. These batteries may burst and cause
injury to persons and damage to property.
i) NEVER charge a frozen battery.
12. PREPARING TO CHARGE
a) If necessary to remove battery from vehicle to charge, always remove
grounded terminal from battery first. Make sure all necessaries in the vehicle
are off, so as not to cause an arc.
b) Be sure area around battery is well ventilated while battery is being charged.
c) Clean battery terminals. Be careful to keep corrosion from coming in contact
with eyes.
d) Add distilled water in each cell until battery acid reaches level specified by
battery manufacturer. Do not overfill. For a battery without removable cell
caps, such as valve regulated lead acid batteries, carefully follow
manufacturer’s recharging instructions.
e) Study all battery manufacturer’s specific precautions while charging and
recommended rates of charge.
f) Determine voltage of battery by referring to car owner’s manual and make
sure that output voltage selector switch is set at correct voltage. If charger has
adjustable charge rate, charge battery initially at lowest rate.
13. CHARGER LOCATION
a) Locate charger as far away from battery as dc cables permit.
b) Never place charger directly above battery being charged; gases from battery
will corrode and damage charger.
c) Never allow battery acid to drip on charger when reading electrolyte specific
gravity or filling battery.
d) Do not operate charger in a closed-in area or restrict ventilation in any way.
e) Do not set a battery on top of charger.
14. DC CONNECTION PRECAUTIONS
a) Connect and disconnect dc output clips only after setting any charger switches
to “off”position and removing ac cord from electric outlet. Never allow clips
to touch each other.
b) Attach clips to battery and chassis as indicated in 15(e), 15(f), and 16(b)
through 16(d).
15. FOLLOW THESE STEPS WHEN BATTERY IS INSTALLED IN VEHICLE. A
SPARK NEAR BATTERY MAY CAUSE BATTERY EXPLOSION. TO REDUCE
RISK OF A SPARK NEAR BATTERY:
a) Position ac and dc cords to reduce risk of damage by hood, door, or moving
engine part.

Monicon Instruments Co., Ltd. CHR-1445/2685
b) Stay clear of fan blades, belts, pulleys, and other parts that can cause injury to
persons.
c) Check polarity of battery posts. POSITIVE (POS, P, +) battery post usually
has larger diameter than NEGATIVE (NEG, N,-) post.
d) Determine which post of battery is grounded (connected) to the chassis. If
negative post is grounded to chassis (as in most vehicles), see (e). If positive
post is grounded to the chassis, see (f).
e) For negative-grounded vehicle, connect POSTIIVE (RED) clip from battery
charger to POSITIVE (POS, P, +) ungrounded post of battery. Connect
NEGATIVE (black) CLIP to vehicle chassis or engine block away from
battery. Do not connect clip to carburetor, fuel lines, or sheet-metal body parts.
Connect to a heavy gage metal part of the frame or engine block.
f) For positive-grounded vehicle, connect NEGATIVE (BLACK) clip from
battery charger to NEGATIVE (NEG, N, -) ungrounded post of battery.
Connect POSITIVE (RED) clip to vehicle chassis or engine block away from
battery. Do not connect clip to carburetor, fuel lines, or sheet-metal body parts.
Connect to a heavy gage metal part or the frame or engine block.
g) When disconnecting charger, turn switches to off, disconnect AC cord,
remove clip from vehicle chassis, and then remove clip from battery terminal.
h) See operating instructions for length of charge information.
16. FOLLOW THESE STEPS WHEN BATTERY IS OUTSIDE VEHICLE. A SPARK
NEAR THE BATTERY MAY CAUSE BATTERY EXPLOSION. TO REDUCE RISK
OF A SPARK NEAR BATTERY:
a) Check polarity of battery posts. POSTIIVE (POS, P, +) battery post usually
has a larger diameter than NEGATIVE (NEG, N, -) post.
b) Attach at least a 24-inch-long 6-gauge (AWG) insulated battery cable to
NEGATIVE (NEG, N, -) battery post.
c) Connect POSITIVE (RED) charger clip to POSITIVE (POS, P, +) post of
battery.
d) Position yourself and free end of cable as far away from battery as possible –
then connect NEGATIVE (BLACK) charger clip to free end of cable.
e) Do not face battery when making final connection.
f) When disconnecting charger, always do so in reverse sequence of connecting
procedure and break first connection while as far away from battery as
practical.
g) A marine (boat) battery must be removed and charged on shore. To charge it
on board requires equipment specially designed for marine use.

Monicon Instruments Co., Ltd. CHR-1445/2685
Table of Content
1. Descriptions............................................................7
2. Features..................................................................7
3. Specifications .........................................................7
4. Installation and Operation....................................8
5. Notes:......................................................................8
6. Label Specification ................................................8
7. Dimensions.............................................................9

Monicon Instruments Co., Ltd. CHR-1445/2685
1. Descriptions
Intelligence module keeps lead acid battery at full charging all the time.
Short-circuit, over load, and over voltage protection prevent any damage to the
battery. Wide AC input voltage and DC output voltage gives the high flexibility of
usage. Charger also in accordance with the principle of high Efficiency, at Full
Load >85% of efficiency is achieved. Easy operation reduces the time and cost for
client training.
2. Features
-Short circuit protection, overload protection, force charge input
-Float charging system, constant voltage output, current limited
-Rugged design for industrial environments, wide range of input voltage
3. Specifications
AC Input Voltage: DC output voltage:
Voltage 90~250VAC 13.6 ~ VDC
Frequency 50/60Hz 24.4 ~ 27VDC
Changing algorithm: Protection:
Constant voltage Over voltage, Over current, DC short circuit
Efficiency: Working Temperature:
at Full Loaded >85% -40 ~ 40℃
Storage Temperature: Relative humidity:
-40 ~ 70℃Max. 90 %
Dimension: Weight:
147mmL*82mmW*43mmmH 482.2g

Monicon Instruments Co., Ltd. CHR-1445/2685
4. Installation and Operation
1.1 Turn off the AC power before connecting to L and N terminals.
1.2 Connect + and –terminals on the charger to + and –terminals of the battery then turn
ON the AC power.
1.3 The design of automatic charging circuit limits the output, when the battery is fully
charged.
1.4 Built-in short circuit protection.
5. Notes:
5.1. All the adjustments are preset at factory.
5.2. When charging, lead-acid battery produces gas, please install it in a well ventilated
area.
5.3. Avoiding contact with rain, sun, or corrosive gas.
5.4. Battery voltage must be over 6V.
5.5. Charger only for lead acid battery.
6. Label Specification
1. AC Power indicator: When ac power is connected, this light turns on.
2. Low output current: When the battery is close to fully charged, only this LED
remains.
3. Moderate flow of current: When current output is near 50%, the LED turns on.
4. Charging at full load: When LED light is on, the charger is operating above 50%
capacity.
5. When the red light is on: Please check the following status,
I. Has the battery voltage dropped below standard safety value (happens in old
battery, dead battery, battery hasn’t been serviced etc.)
II. Input & output has been improperly connected.
III. Ensure charger’s output voltage meets the battery voltage.
○
1
○
2
○
3
○
4
⑤

Monicon Instruments Co., Ltd. CHR-1445/2685
7. Dimension
