Monitronics Vista-15pmt Operating instructions

VISTA

VISTAVISTA

VISTA-

-15PMT

15PMT15PMT

15PMT

VISTA

VISTAVISTA

VISTA-

-20PMT

20PMT20PMT

20PMT

Programming Guide

ON OFF

OFF

MAX

INSTANT

READY

AWAY

TEST

CODE

STAY

BYPASS

CHIME

ARMED

READY

OFF

MAX

INSTANT

READY

AWAY

TEST

CODE

STAY

BYPASS

CHIME

ARMED

READY

This control is a certified SIA-compliant control that

meets SIA specifications for False Alarm Reduction.

K5305-1MTPRV9 3/11 Rev. A - SIA Reference: MTV15P, MTV20P

– 2–

TABLE OF CONTENTS

PROGRAMMING MODE COMMANDS.................................................................................................3

DATA FIELD PROGRAMMING FORM..................................................................................................4

CONFIGURABLE ZONE TYPES WORKSHEETS...............................................................................13

∗

∗∗

∗56 ZONE PROGRAMMING MENU MODE........................................................................................14

∗

∗∗

∗58 EXPERT ZONE PROGRAMMING MODE.....................................................................................15

WIRELESS KEY PROGRAMMING TEMPLATES...............................................................................16

∗

∗∗

∗57 FUNCTION KEY PROGRAMMING...............................................................................................16

OUTPUT DEVICE PROGRAMMING GENERAL INFORMATION (*79/*80 Menu Mode)....................17

∗

∗∗

∗79 RELAY/POWERLINE CARRIER DEVICE PROGRAMMING MENU MODE.................................17

∗

∗∗

∗80 OUTPUT FUNCTION MENU MODE.............................................................................................18

∗

∗∗

∗81 ZONE LIST MENU MODE ............................................................................................................19

∗

∗∗

∗82 ALPHA DESCRIPTOR MENUMODE............................................................................................20

ALPHA VOCABULARY LIST (For Entering Zone Descriptors).......................................................21

SETTING SCHEDULES ......................................................................................................................22

AVS SYSTEM ENABLE and QUICK PROGRAMMING COMMANDS................................................23

SETTING THE REAL-TIME CLOCK......................................................................................................2

∗

∗∗

∗29 COMMUNICATION DEVICE MENU MODE (Pass-Through Programming)...............................24

ZONE TYPE DEFINITIONS.................................................................................................................25

UL NOTICES.......................................................................................................................................26

SIA QUICK REFERENCE GUIDE .......................................................................................................26

UPLOADING/DOWNLOADING VIA THE INTERNET..........................................................................23

WORKSHEET for SCHEDULES.........................................................................................................27

WORKSHEET for ∗

∗∗

∗56 ZONE PROGRAMMING..................................................................................28

WORKSHEET for ∗

∗∗

∗57 FUNCTION KEY PROGRAMMING.................................................................29

WORKSHEET for ∗

∗∗

∗79 RELAY/POWERLINE CARRIER DEVICE PROGRAMMING..........................29

WORKSHEET for ∗

∗∗

∗81 ZONE LIST PROGRAMMING.........................................................................29

WORKSHEET for ∗

∗∗

∗80 OUTPUT FUNCTION PROGRAMMING..........................................................30

TABLE OF DEVICE ADDRESSES......................................................................................................31

5800 SERIES TRANSMITTER INPUT LOOP IDENTIFICATION.........................................................31

SETTING THE REAL-TIME CLOCK

IMPORTANT: The Real-Time Clock must be set before the end of the installation.

NOTE: All partitions must be disarmed before the date/time can be set.

1. Master Code + [#] + [6] [3]

2. Press [∗] when the time/date is displayed.

A cursor appears under the first digit of the hour.

To move cursor ahead, press [

∗

]. To go back, press [#].

•Enter the 2-digit hour setting.

•Enter the 2-digit minute setting.

•Press [1] for PM or [2] for AM.

•Enter the last two digits of the current year.

•Enter the 2-digit month setting.

•Enter the 2-digit day setting.

3. To exit, press [∗] when cursor is at the last digit, or wait 30 seconds.

– 3–

PROGRAMMING MODE COMMANDS

TO ENTER PROGRAMMING MODE (using an alpha keypad connected to the control):

A. POWER UP, then press [✱] and [#] at the same time, within 50 seconds of powering up (this method must be used if ✱98

was used to exit program mode). OR

B. Initially, key: Installer Code (4 + 1 + 1 + 2) plus 8 + 0 + 0.

PROGRAMMING MODE COMMANDS

Task Command/Explanation

Go to a Data Field Press [∗

∗∗

∗] + [Field Number], followed by the required entry.

Entering Data When the desired field number appears, simply make the required entry. When the last entry for a field is

entered, the keypad beeps three times and automatically displays the next data field in sequence. If the

number of digits that you need to enter in a data field is less than the maximum digits available (for

example, the phone number fields *41, *42), enter the desired data, then press [∗] to end the entry. The

next data field number is displayed.

Review a Data Field Press [#] + [Field Number].

Data will be displayed for that field number. No changes will be accepted in this mode.

Deleting an Entry Press [∗

∗∗

∗] + [Field Number] + [∗

∗∗

∗]. (Applies only to fields ∗40 thru *46, *94, and pager fields)

Initialize Download ID Press ✱

✱✱

✱96. Initializes download ID and subscriber account number.

Reset Factory Defaults Press ✱

✱✱

✱97. Sets all data fields to original factory default values.

Zone Programming Press ✱

✱✱

✱56. Zone characteristics, report codes, alpha descriptors, and serial numbers for 5800 RF trans.

Function Key Programming Press ✱

✱✱

✱57. Unlabeled keypad keys (known as ABCD keys) for special functions

Zone Programming

(Expert Mode) Press ✱

✱✱

✱58. Same options as *56 mode, but with fewer prompts. Intended for those familiar with this type

of programming, otherwise *56 mode is recommended.

Output Device Mapping Press ✱

✱✱

✱79. Assign module addresses and map individual relays/powerline carrier devices

Output Programming Press ✱

✱✱

✱80. 4229 or 4204 Relay modules, Powerline Carrier devices, or on-board triggers

Zone List Programming Press ✱

✱✱

✱81. Zone Lists for relay/powerline carrier activation, chime zones, pager zones, etc.

Alpha Programming Press ✱

✱✱

✱82. Zone alpha descriptors

IP/GSM Programming Press ∗

∗∗

∗29. For programming the IP/GSM options.

Exit Program Mode with

installer code lockout Press ✱

✱✱

✱98. Exits programming mode and

prevents

re-entry by: Installer Code + 8 + 0 + 0.

To reenter programming mode, the system must be powered down, then powered up. Then use method

A above. See field *88 for other *98 Program mode lockout options.

Exit Program Mode Press ✱

✱✱

✱99. Exits programming mode and

allows

re-entry by: Installer Code + 8 + 0 + 0 or method A

above.

Scheduling Mode Enter code + [#] + 64. Create schedules to automate various system functions.

Site-Initiated Download Installer code + [#] + 1 (perform while system is disarmed and in normal mode)

AVS QUICK PROGRAMMING COMMANDS (for AAV sessions using the AVS system)

For controls with the following firmware revision levels, these commands automatically configure the control for AVS

operation. VISTA-15PMT = version 6.0 or higher; VISTA-20PMT = version 7.0 or higher

•installer code + [#] + 03: enable AVS operation

•installer code + [#] + 04: enable AVS operation and enable panel sounds on the AVST speaker

•installer code + [#] + 05: remove all programming options set by [#] + 03 quick command

•installer code + [#] + 06: remove all programming options set by [#] + 04 quick command

Refer to the AVS SYSTEM ENABLE and QUICK PROGRAMMING COMMANDS section for details on the specific options

that are set with each command, depending on the control used.

To select the AAV session communication path (phone line/communication device), see field ∗55 Dynamic Signaling Priority.

To enable AAV operation, use ∗91 Options field (option 4).

SPECIAL MESSAGES

OC = OPEN CIRCUIT (no communication between Keypad and Control).

EE or ENTRY ERROR = ERROR (invalid field number entered; re-enter valid field number).

After powering up, AC, dI (disabled) or “Busy Standby vx.x (firmware revision) Dl will be displayed after approximately 4

seconds. This will revert to a “Ready” message in approximately 1 minute, which allows PIRS, etc. to stabilize. You can

bypass this delay by pressing [#] + [0].

NOTE for CANADIAN PANELS: Power up time is 2 minutes, and Contact ID report code 305 System Reset is sent if the [#]

+ [0] command is not performed before the 2 minutes expires.

If E4 or E8 appears, more zones than the expansion units can handle have been programmed. The display will clear after

you correct the programming.

IMPORTANT: The Real-Time Clock must be set before the end of the installation. See procedure in the Setting the Real-

Time Clock section on the previous page.

– 4–

DATA FIELD PROGRAMMING FORM

Entries apply to both the VISTA-15PMT and VISTA-20PMT controls, except entries shown in dashed boxes apply only to the

VISTA-20PMT (partition entries) and are not applicable to the VISTA-15PMT.

Entry of a number other than one specified will give unpredictable results. Values shown in brackets are factory defaults.

SIA Features: The VISTA-15PMT and VISTA-20PMT are certified SIA-compliant controls that meet SIA specifications for

False Alarm Reduction. Fields marked with heavy borders are related to SIA requirements and have entries or operation

different than non SIA-compliant controls.

∗

∗∗

∗20 Dealer Installer Code [4112] | | |

4 digits, 0000–9999 This code can perform all system

functions except cannot edit the central station reporting

phone numbers (fields *41, *42). For security purposes, the

factory default installer code should be changed.

∗

∗∗

∗21 Quick Arm Enable [1,1]

0 = no; 1 = yes Part. 1 Part.2

If enabled, users can press the [#] followed by an arming

key to arm the system instead of using a security code. The

security code is always needed to disarm the system.

∗

∗∗

∗22 RF Jam Option [0]

0 = no RF Jam detection

1 = send RF Jam report

If enabled, a report is sent if the system detects an RF

jamming signal.

UL: must be 1 if wireless devices are used

∗

∗∗

∗23 Quick (Forced) Bypass [0,0]

0 = no quick bypass UL: must be “0” Part. 1 Part. 2

1 = allow quick bypass (code + [6] + [#] )

Zones bypassed by this function will be displayed after the

bypass is initiated.

∗

∗∗

∗24 RF House ID Code [00,00,00] | | |

00 = disable wireless keypads Part. 1 Part. 2 Common

01–31 = using 5827, 5827BD or 5804BD keypad

The House ID identifies receivers and wireless keypads. If a

5827 or 5827BD Wireless Keypad or 5804BD Transmitter is

being used, a House ID code must be entered and the

keypad set to the same House ID. You can assign RF house

ID for each partition

∗

∗∗

∗26 Chime By Zone [6, 7]

KP (Keypad) Sound Enables 1 2

Entry 1

0 = no “entry 1” keypad trouble sounds, AND no chime by

zone (keypad chimes on fault of any entry/exit or

perimeter zone when chime mode is on)

1 = Chime by Zone enabled (list chime zones on zone

list 3 using *81 Menu mode)

2 = Communication device (LRR) Trouble sounding

enabled (for communication devices such as

7845GSM, 7845i-GSM, GSMV)

4 = System Low Battery sounding enabled

7 = select all entry 1 options

Entry 2

0 = no “entry 2” keypad trouble sounds

1 = RF Supervision sounding enabled

2 = RF Low Battery sounding enabled

4 = RF Jam sounding enabled

7 = select all entry 2 options

For each entry, enter the sum of the desired options.

Example Entry 1: for Chime by Zone and System Low

Battery sounding, enter 5. To enable all options, enter 7.

Keypad (KP) Trouble Sounding can be enabled/disabled for

the conditions listed in each entry.

∗

∗∗

∗27 Powerline Carrier Device (X–10) [0]

House Code

0 = A; 1 = B; 2 = C; 3 = D; 4 = E; 5 = F; 6 = G; 7 = H; 8 = I;

9 = J; #10 = K; #11 = L; #12 = M; #13 = N; #14 = O; #15 = P

Powerline Carrier devices require a House ID, identified in

this field. Program Powerline Carrier devices in interactive

modes ∗79, *80 and *81.

UL: not for fire or UL installations

∗

∗∗

∗28 Access Code for Phone Module [00] |

00 = disable; (Partition 1 only)

1st digit: enter 1–9; 2nd digit: enter # + 11 for "✱", or # + 12

for "#".

You must assign a 2-digit access code for the 4286 Phone

Module, if used. Example: If desired access code is 7∗, then

7 is the first entry, and [#] + 11 (for ∗) is the second entry.

NOTE: A 0 in either digit disables the phone module.

UL: must be “00” for UL Commercial Burg. installations

∗

∗∗

∗29 Enable IP/GSM – Communication Device Menu

Mode (pass-through programming)

This is a Menu Mode command, not a data field, for programming

IP/GSM communication device options. See ∗29 Menu Mode

section later in this document.

∗

∗∗

∗31 Single Alarm Sounding Per Zone [0]

0 = “alarm sounding per zone” will be the same as the

“number of reports in armed period” set in field *93 (1 if

one report, 2 if 2 reports, unlimited for zones in zone list

UL: must be “0”

SIA: Must be “0” if *93 Reports in Armed Period is set

to “2” report pairs.

1 = one alarm sounding per zone

If enabled, limits alarm sounding on the bell output to once

per zone per armed period.

∗

∗∗

∗32 Fire Alarm Sounder Timeout [0]

0 = sounder stops at timeout;

1 = no sounder timeout UL: must be “1” for fire install.

This control complies with NFPA requirements for temporal

pulse sounding of fire notification appliances. Temporal

pulse sounding for a fire alarm consists of the following: 3

pulses – pause – 3 pulses – pause – 3 pulses.

∗

∗∗

∗33 Alarm Sounder (Bell) Timeout [1]

0 = none; 1 = 4 min; 2 = 8 min; 3 =12 min; 4 = 16 min;

UL: For residential fire alarm installation, must be set for

a minimum of 4 min (option 1); for UL Commercial

Burglary installations, must be minimum 16 min (option 4)

This field determines whether the external sounder will shut

off after time allotted, or continue until manually turned off.

∗

∗∗

∗34 Exit Delay [60,60] | |

45 - 96 = 45 - 96 secs; 97 = 120 secs Part. 1 Part. 2

NOTE: Entries less than 45 will result in a 45-second delay.

UL installations: For UL Commercial Burglar Alarm and UL

Residential Burglar Alarm installations with line security,

total exit time must not exceed 60 seconds.

Common zones use part. 1 delay.

The system waits the time entered before arming entry/exit

zones. If the entry/exit door is left open after this time

expires, an alarm will occur. Common zones use same

delay as partition 1.

– 5–

∗

∗∗

∗35 Entry Delay #1 [30,30] | |

30 - 96 = 30 - 96 seconds Part. 1 Part. 2

97 = 120 secs

98 = 180 secs

99 = 240 secs

Upon entering, the system must be disarmed before the time

entered expires, otherwise it sounds an alarm.

NOTE: Entries less than 30 will result in a 30-second delay.

Common zones use same delay as partition 1.

For UL Residential Burglary Alarm installations, must be set

for a maximum of 30 seconds; entry delay plus dial delay

should not exceed 1 min. For UL Commercial Burglar Alarm,

total entry delay may not exceed 45 seconds.

∗

∗∗

∗36 Entry Delay #2 [30,30] | |

See *35 Entry Delay 1 for entries. Part. 1 Part. 2

∗

∗∗

∗37 Audible Exit Warning N/A

Feature always enabled; field removed in this control.

Warning sound consists of slow continuous beeps until the

last 10 seconds, and then it changes to fast beeps. Sound

ends when exit time expires.

∗

∗∗

∗38 Confirmation Of Arming Ding [0,0]

0 = no Part. 1 Part. 2

1 = yes (wired keypads and RF)

2 = yes, RF only (except 5827, 5827BD)

Confirmation of arming is 1/2-sec external sounder “ding.”

If 1 selected, ding occurs when closing report is sent if

open/close reporting is enabled, or at the end of Exit Delay.

If 2 selected, ding occurs upon reception of the wireless

arming command.

UL: must be “1” for UL Commercial Burglar Alarm inst.

∗

∗∗

∗39 Power Up In Previous State N/A

Feature always enabled; field removed in this control.

When the system powers up armed, an alarm will occur 1

minute after arming if a zone is faulted. Note that if the

previous state was armed Away or Stay, the system ignores

sensor changes for 1 minute, which allows sensors such as

PIRs to stabilize.

DIALER PROGRAMMING (✱40 – ✱42)

Do not fill unused spaces. Enter 0–9; #+11 for '✱'; #+12 for '#'; #+13

for a 2-second pause. If fewer than the maximum digits entered, exit

the field by pressing [✶]. The next data field number is displayed.

∗

∗∗

Call Waiting Disable

Enter up to 6 digits. To clear entries, press ✱40✱. If call

waiting is used, enter call waiting disable digits “∗(#+11) 70”

plus “# + 13” (pause) and also set Call Waiting Disable

option in field *91.

NOTES: 1. The call waiting disable feature cannot be used on a

PABX line.

2. Using Call Waiting Disable on a non-call waiting line

will prevent successful communication to the central

station.

∗

∗∗

∗41 Primary Phone No.

| | | | | | | | | | | | | | | | | | |

Can be changed by corporate installer code only. Enter up to

20 digits. To clear entries, press ∗41∗.

∗

∗∗

∗42 Secondary Phone No.

| | | | | | | | | | | | | | | | | | |

Can be changed by corporate installer code only. Enter up to

20 digits. To clear entries, press ∗42∗.

NOTE: Entry of a number other than one specified will give

unpredictable results.

For fields *43 thru *46: Enter 0–9; #+11 for B; #+12 for C; #+13 for

D; #+14 for E; #+15 for F. Enter [✱]as the fourth digit if a 3-digit

account number (for 3+1 dialer reporting format) is used. Enter 0 as

the first digit of a 4-digit account number for Nos. 0000-0999. Exit

field by pressing ✱if only 3 digits are used. E.g., For Acct. B234,

enter: #+11 2 3 4 .

∗

∗∗

∗43 Partition 1 Primary Acct. No.

| | | / | | | | | [FFFFFFFFFF]

Enter 4 or 10 digits, depending on selection in *48 Report

Format. See box above. To clear entries, press *43*.

∗

∗∗

∗44 Partition 1 Secondary Acct. No.

| | | / | | | | | [FFFFFFFFFF]

Enter 4 or 10 digits, depending on selection in *48 Report

Format. See box above. To clear entries, press *44*.

∗

∗∗

∗45 Partition 2 Primary Acct. No.

| | | / | | | | | [FFFFFFFFFF]

Enter 4 or 10 digits, depending on selection in *48 Report

Format. See box above. To clear entries, press *45*.

∗

∗∗

∗46 Partition 2 Secondary Acct. No.

| | | / | | | | | [FFFFFFFFFF]

Enter 4 or 10 digits, depending on selection in *48 Report

Format. See box above. To clear entries, press *46*.

∗

∗∗

∗47 Phone System Select [3]

If Cent. Sta.

IS NOT

on a WATS line:

0=Pulse Dial; 1=Tone Dial;

if Cent. Sta.

a WATS line:

2 = Pulse Dial ; 3 = Tone Dial

Select the type of phone service for the installation.

∗

∗∗

∗48 Report Format [7,7]

Primary Secondary

0 = 3+1, 4+1 ADEMCO L/S STANDARD

1 = 3+1, 4+1 RADIONICS STANDARD

2 = 4+2 ADEMCO L/S STANDARD

3 = 4+2 RADIONICS STANDARD

5 = 10-digit ADEMCO CONTACT ID® REPORTING

6 = 4+2 ADEMCO EXPRESS

7 = 4-digit ADEMCO CONTACT ID® REPORTING

8 = 3+1, 4+1 ADEMCO L/S EXPANDED

9 = 3+1, 4+1 RADIONICS EXPANDED

Select the format for primary/secondary phone numbers

∗

∗∗

∗49 Split/Dual Reporting [0]

0 = Standard/backup reporting only (all to primary)

Primary Phone No. 2nd Phone No.

1 = Alarms, Restore, Cancel Others

2 = All except Open/Close, Test Open/Close, Test

3 = Alarms, Restore, Cancel All

4 = All except Open/Close, Test All

5 = All All

– 6–

∗

∗∗

∗50 Burglary Dialer Delay [2,0]

Delay Time Delay Disable

Delay Time:

1 = 15 seconds; 2 = 30 seconds; 3 = 45 seconds

Provides delay of “BURGLARY ALARM” report to the central

station, which allows time for the subscriber to avoid a false

alarm transmission. This delay does not apply to zone type

24 alarms (silent burglary) or to 24-hour zone types 6, 7, and

8 (silent panic, audible alarm, auxiliary alarm), which are

always sent as soon as they occur.

Delay Disable:

0 = use delay set in entry 1

1 = dial delay disabled for zones listed in zone list 6 (use

zone list 6 to enter those zones that need dial delay to

be disabled; these zones ignore the setting in entry 1)

UL: Dial delay plus entry delay must not exceed one minute;

use zone list 6 to disable dial delay from appropriate zones,

if necessary.

∗

∗∗

∗53 SESCOA/Radionics Select [0]

0 = Radionics (0-9, B-F); enter “0” for all non-SESCOA formats

1 = SESCOA (0-9 only reporting)

∗

∗∗

∗54 Dynamic Signaling Delay [4]

Select delay from 0 to 225 secs, in 15-sec increments.

0 = no delay (both signals sent);

1 = 15 secs; 2 = 30 secs, etc.

Intended for reporting via a communication device on the ECP

bus (LRR). This field lets you select the time the panel should

wait for acknowledgment from the first reporting destination

(see ∗55) before it attempts to send a message to the second

destination. Delays can be selected from 0 to 225 seconds, in

15-second increments. This delay is per message. If 0 is

entered in this field, the control panel will send redundant

reports to both Primary Dialer and LRR.

UL: If using line security, must be “0; Reports will be sent to

both the dialer and the communication device.

∗

∗∗

∗55 Dynamic Signaling Priority / [0]

AAV Path Select

0 = Primary Dialer first / AAV via phone line

1 = Communication Device (LRR) first / AAV via

communication device path (see AAV paragraph below)

This field selects the primary communication path for

reporting (dialer or communication device) of primary phone

number events†(see ∗49 Split/Dual Reporting) and selects

the communication path used for AAV sessions (phone line

or communication device path). Use ∗29 IP/GSM menu

mode to enable the communication device being used.

† Reports intended for the secondary phone number are not

sent via the communication device.

For Dynamic Signaling Priority:

Select the initial reporting destination for messages:

Primary Dialer First selected (

•If acknowledged before delay expires (see ∗54), then

message will not be sent via LRR.

•If not acknowledged before delay expires, message is

sent to both the Primary Phone No. and via LRR.

Communication Device (LRR) First selected (

•If acknowledged before delay expires, then message will

not be sent to the primary dialer.

•If not acknowledged before delay expires, message is

sent to both the Primary Phone No. and via LRR.

For AAV Path Select:

•If using the UVS system or AVS system with non-ECP

connection, option 0 must always be used.

•If using the AVS system with ECP connection, either

option (0 or 1) may be used, but note the following:

IMPORTANT: If option “1” is selected, a 2-way voice (AAV)

device compatible with the communication device path must

be used (ex. GSMV communicator). When selected, AAV

sessions always occur via the GSMV communicator, even if

reporting reverts to phone line backup due to GSMV

communicator path reporting failure.

For UL Commercial Burglary installations that use a DACT

and LRR, this field must be “0”.

∗

∗∗

∗56, ∗

∗∗

∗57, ∗

∗∗

∗58 Menu Modes

These are Menu Mode commands, not data fields, for Zone

Programming, Function Key Programming, and Expert Mode Zone

Programming respectively. See respective sections later in this

document.

TO PROGRAM SYSTEM STATUS, & RESTORE REPORT CODES

(∗

∗∗

∗59 thru ∗

∗∗

∗68, *70 thru ∗

∗∗

∗76, and ∗

∗∗

∗89):

For 3+1 or 4+1 Standard Format: Enter a code in the

first

box: 1–

9, #+10 for 0, #+11 for B, #+12 for C, #+13 for D, #+14 for E, #+15

for F.

A 0 (

not

#+10) in the

first

box will disable a report. A 0 (

not

#+10)

in the

second

box will result in automatic advance to the next field.

For Expanded or 4+2 Format: Enter codes in

both

boxes (1st and

2nd digits) for 1–9, 0, or B–F, as described above.

A 0 (

not

#+10) in the

second

box will eliminate the expanded

message for that report. A 0 (

not

#+10) in

both

boxes will disable

the report.

For Ademco Contact ID® Reporting: Enter any digit (other than 0)

in the

first

box, to enable zone to report (entries in the

second

boxes

are ignored).

A 0 (

not

#+10) in the

first

box disables the report.

UL: Report codes are required in fields *61, *65, *71, *72, for UL

Commercial Burglar Alarm installations.

Report codes are required in fields *60, *62, *63, *64, *70, *73, *74,

*75, *76, for UL Commercial Burglar Alarm installations and

required for Residential Fire Alarm installations

SYSTEM STATUS REPORT CODES (✱59–✱68)

∗

∗∗

∗59 Exit Error Alarm Report Code [1]

SIA NOTE: Always enabled. Sends both exit error and zone

alarm reports in the event of an exit error condition. Also see

field *69.

After arming the system, entry/exit and interior zones

remaining open after exit delay expires cause an alarm

sound at the keypad and external sounder (keypad also

displays “EXIT ALARM”), and entry delay begins. Disarming

before the end of the entry delay stops the alarm sounding

and no message is sent to the central station. The keypad

will display “CA” (fixed-word) or “ALARM CANCELED”

(alpha display).

If the system is not disarmed before entry delay expires, an

“EXIT ALARM” message and zone alarm message will be

sent to the central station. The keypad will display “EA”

(fixed-word ) or “EXIT ALARM” (alpha display), and alarm

sounding continues until the system is disarmed (or timeout

occurs).

An Exit Alarm condition will also result if a fault occurs in an

exit or interior zone within 2 minutes following the end of the

exit delay, and an “EXIT ALARM” message will be sent to

the central station (also see field *69 Recent Closing report).

With Contact ID format, the message will contain the zone

number and error code 374 (“ALARM–EXIT ERROR”).

∗

∗∗

∗60 Trouble Report Code [10] |

Sent if a zone has a trouble condition.

See UL System Reporting Note above *59.

∗

∗∗

∗61 Bypass Report Code [00] |

Sent when a zone is manually bypassed.

See UL System Reporting Note above *59.

∗

∗∗

∗62 AC Loss Report Code [10] |

Timing of this report is random with up to a 4-hour delay. If

AC restores before the report goes out, there is no “AC

LOSS” report.

See UL System Reporting Note above *59.

∗

∗∗

∗63 Low Bat Report Code [10] |

Sent when the system’s backup battery has a low-battery

condition. See UL System Reporting Note above *59

– 7–

∗

∗∗

∗64 Test Report Code [10] |

Use Scheduling mode to set periodic test reports, or use the

following key commands:

installer code +[#] + [0] + 0 = test report sent every 24 hours

installer code +[#] + [0] + 1 = test report sent once per week

installer code +[#] + [0] + 2 = test report sent every 28 day

Each mode sets schedule 32 (VISTA-20PMT) or schedule 08

(VISTA-15PMT) to the stated repeat option; first test report

sent 12 hours after command†.

See System Reporting UL Note above *59.

† NOTE: Make sure the Real-Time Clock is set to the proper

time before entering the test report schedule command to

ensure that test reports are sent when expected. (see Setting

the Real-Time Clock section)

∗

∗∗

∗65 Open Report Code [0,0,0]

Part. 1 Part. 2 Common

Sent upon disarming the system in the selected partitions.

See UL System Reporting Note above *59.

∗

∗∗

∗66 Arm Away/Stay Rpt Code

[0,0,0,0,0,0]

Away Stay Away Stay Away Stay

Part. 1 Part. 2 Common

This option allows for independent programming of Away

and Stay reports for each partition, including the common

lobby.

NOTE: “OPEN” reports are not sent if the associated closing

report is not enabled.

∗

∗∗

∗67 RF Trans. Low Bat Report Code [10] |

Sent when a transmitter low-battery condition exists.

UL: must be enabled if wireless devices are used

∗

∗∗

∗68 Cancel Report Code [10] |

SIA NOTE: Report enabled.

Sent upon disarming the system after an alarm condition

was reported.

∗

∗∗

∗69 Recent Closing Report Code [11] |

SIA NOTE: Always enabled. Sends both recent closing and

zone alarm reports if fault occurs within 2 min. after exit time

expires. Also see field *59.

Similar to the Exit Error condition described in field *59, but

occurs if any burglary zone is faulted within two minutes

after the initial exit delay expires. Disarming the system

within the two minutes stops the alarm sound and displays

"ALARM CANCELED " or "CA" and faulted zone number. No

message is sent to the Central Monitoring Station.

If the system is not disarmed within two minutes, the alarm

sound continues and a “recent closing” and a “zone alarm”

message are sent to the Central Monitoring Station (after

dial delay expires).

RESTORE REPORT CODES (✱70 – ✱76)

∗

∗∗

∗70 Alarm Restore Rpt Code [0]

NOTE: Alarm restore signals indicate that respective alarm

zone(s) are no longer faulted. Alarm restore reports are sent

to the central station at bell timeout (field *33), if the zone(s)

in alarm are actually restored to a non-faulted state at that

time. Otherwise, alarm restore report(s) for respective alarm

zones are sent when the system is disarmed.

If Reports Per Armed Period Per Zone (*93) is also

programmed, the system will report alarm and restore codes

as described above until the “Reports Per Armed Period”

count is reached. Disarming and rearming will reset the

“Reports Per Armed Period” count.

∗

∗∗

∗71 Trouble Restore Rpt Code [10] |

Sent when a trouble in a zone is restored and code + OFF

performed. See UL System Reporting Note above *59.

∗

∗∗

∗72 Bypass Restore Rpt Code [00] |

Sent when a zone that has been bypassed is unbypassed.

See UL System Reporting Note above *59.

∗

∗∗

∗73 AC Restore Rpt Code [10] |

Sent after AC power has been restored after an AC power

outage.

See UL System Reporting Note above *59.

∗

∗∗

∗74 Low Bat Restore Rpt Code [10] |

Sent after a system low-battery condition is restored to

normal.

See UL System Reporting Note above *59.

∗

∗∗

∗75 RF Trans. Lo Bat Rst Rpt Code [10] |

Sent when a transmitter’s low battery condition is restored

(i.e., new battery installed).

UL: must be enabled if wireless devices are used. See UL

System Reporting Note above *59.

∗

∗∗

∗76 Test Restore Rpt Code [10] |

Sent when the Test mode is exited or upon timeout (4hrs).

See UL System Reporting Note above *59.

OUTPUT AND SYSTEM SETUP (✱

✱✱

✱77 – ✱

✱✱

✱93)

∗

∗∗

∗77 Daylight Saving Time [3][11] |

Start\End Month

0 = Disabled

1-12 = January-September (1 = Jan, 2 = Feb, etc)

#+10 = October; #+11 = November; #+12 = December

Enter the start and end month for daylight saving time, if

applicable to the region.

∗

∗∗

∗78 Daylight Saving Time [2][1] |

Start\End Weekend

0 = disabled; 1 = first; 2 = second; 3 = third; 4 = fourth;

5 = last; 6 = next to last; 7 = third to last

Enter the start and end weekend for daylight saving time, if

applicable to the region.

∗

∗∗

∗79, *80, *81, *82 Menu Modes

These are Menu Mode commands, not data fields, for Output

Device Mapping, Output Programming, Zone List Programming, and

Alpha Programming respectively. See page 2 and their respective

sections in the Installation and Setup Guide for procedures.

∗

∗∗

∗84 Auto Stay Arm [MTV15P = 1; MTV20P = 1]

0 = no

1 = partition 1 only; 2 = partition 2 only; 3 = both partitions

If enabled, the system will automatically change AWAY

mode to STAY mode if the entry/exit door is not opened and

closed within the exit delay time after a user arms in AWAY

mode from a wired keypad (non-RF device). An Opening

report followed by an Armed Stay report is sent to the

Central Station.

If the door is opened and closed within the exit delay period,

the system remains in AWAY mode.

Any RF device that arms the system AWAY overrides this

feature and the system remains armed AWAY.

∗

∗∗

∗85 Cross Zone Timer [0]

This option not for use in UL installations.

(assign cross zones on zone list 4, using *81 Menu mode)

0 = 15 seconds 6 = 2-1/2 min #+12 = 8 min

1 = 30 seconds 7 = 3 min #+13 = 10 min

2 = 45 seconds 8 = 4 min #+14 = 12 min

3 = 60 seconds 9 = 5 min #+15 = 15 min

4 = 90 seconds #+10 = 6 min

5 = 2 minutes #+11 = 7 min

NOTE: Cross zoning takes effect only after Exit Delay expires.

Sets the maximum amount of time in which two cross zones

must be tripped in an armed system to send an alarm

message to the Central Station. If only one cross zone is

tripped during this time, a trouble message (CID code 380)

for that zone is sent to the Central Station.

– 8–

∗

∗∗

∗86 Cancel Verify Keypad Display [1]

0 = no; 1 = yes

This feature causes a “ALARM CANCELED” display on the

LCD keypad under the following conditions:

•After the kissoff of the cancel message to the Central

Station, indicating a successful transmission.

•When an alarm is successfully canceled before the

Central Station received the Alarm message. E.g., if an

alarm is incorrectly triggered and the user presses code +

OFF before the dial delay time has expired, the message

will never go out to the CS.

•When the Cancel report is not enabled and the system is

disarmed:

a. before dialer delay expires (alarm report not sent)

message “Alarm Canceled” is displayed.

b. after dialer delay expires message “Alarm Canceled”

is not displayed.

∗

∗∗

∗87 Misc. Fault Delay Time [0]

(used with Configurable Zone Types “digit 6”)

0 = 15 seconds 6 = 2-1/2 min #+12 = 8 min

1 = 30 seconds 7 = 3 min #+13 = 10 min

2 = 45 seconds 8 = 4 min #+14 = 12 min

3 = 60 seconds 9 = 5 min #+15 = 15 min

4 = 90 seconds #+10 = 6 min

5 = 2 minutes #+11 = 7 min

UL: may only be used on non-burglar alarm/ non-fire alarm

zones when used in fire and/or UL burglar alarm installation

Used with zones assigned to a configurable zone type with fault

delay on (configurable zone type digit “6”), and sets a zone

response time of 15 seconds to 15 min. It can be assigned to

zones with sensors that provide a trouble indication when an oil

tank is low, or similar applications for critical condition

monitoring where non-alarm response is desired.

∗

∗∗

∗88 Program Mode Lockout Options [0]

0 = standard *98 installer code lockout (reentry only by [∗] +

[#] within 50 seconds after power up)

1 = lockout [∗] + [#] reentry after *98 exit (reenter via

installer code or downloader only)

2 = lockout all local programming after *98 exit (reentry via

downloader only)

This table summarizes the Program Mode Lockout options:

Exit *88 Reentry By:

Command Entry Installer Power-up† Downloader

*99 n/a yes yes yes

*98 0 no yes yes

*98 1 yes no yes

*98 2 no no yes

†pressing [∗] + [#] within 50 seconds of power up

∗

∗∗

∗89 Event Log Full Report Code [00] |

See box above field *59 for report code entries.

If an Event Logging selection is made in field ∗90, a

message can be sent to the central station receiver when

the log is 80% full. If the log becomes full, new messages

overwrite the oldest messages in the log.

∗

∗∗

∗90 Event Log Enables [15]

NOTE

System messages are logged when any non-zero

entry is made. To select all options, enter #15.

0 = None

1 = Alarm/Alarm Restore

2 = Trouble/Trouble Restore

4 = Bypass/Bypass Restore

8 = Open/Close.

Example:

To select “Alarm/Alarm

Restore”, and “Open/Close”, enter 9 (1 + 8);

This system can record various events in a history log

(VISTA-20PMT = 100 events; VISTA15PMT = 50 events). At

any time, the downloader operator can then upload the log

and view or print out all or selected categories of the log, or

can clear the log. Event log can also be viewed at an alpha

keypad. The display/printout at the central station will show

the date, time, event, and description of the occurrences.

Data Entry Example: To select Alarm/Alarm Restore” and

“Open/Close”, enter 9 (1+ 8); to select all events, enter #15.

NOTE

System messages are logged when any non-zero

entry is made.

∗

∗∗

∗91 Option Selection / Remote [8, 0]

Interactive Services (RIS) Enable 1 2

Entry 1: Options

0 = None

1 = Bell Supervision Processing

4 = AAV UL: must use ADEMCO UVCM module

8 = Exit Delay Restart/Reset †† UL: must be disabled

#+12 = AAV and Exit Delay Restart/Reset

SIA Guidelines: Exit Delay should be enabled.

Entry 2: Call Waiting Disable / RIS Enable

0 = call waiting not used

1 = call waiting disable digits (*70) entered in field *40;

(when selected, the system dials the entry in field *40

only on alternate dial attempts; this allows proper

dialing in the event call waiting service is later

canceled by the user).

2 = RIS (Remote Interactive Services) enabled

3 = Call Waiting disable and RIS enabled

IMPORTANT: AAV should not be used when Paging or

Alarm Reports are sent to a secondary number unless the

monitoring zone option is used (which pauses calls).

Otherwise, the call to the secondary number by the

communicator after the alarm report will prevent the AAV

from taking control of the telephone line, and the AAV

“Listen in” session cannot take place.

††“Exit Delay Restart/reset” option allows use of the [∗] key

to restart the exit delay at any time when the system is

armed STAY or INSTANT. This feature also enables

automatic exit delay reset, which resets exit delay if the

entry/exit door is re-opened and closed before exit delay

time expires after arming AWAY. Automatic Exit Delay

Reset occurs only once during an armed AWAY period.

Remote Interactive Services (RIS) Enable: This option

enables enhanced Remote Interactive Services (RIS), if

supported by the communication service in use.

∗

∗∗

∗92 Phone Line Monitor Enable [0,0]

Entry 1: 1 2

0 = disabled, 1-15 = 1 min - 15 min

(#+10 = 10 min; #+11 = 11 min; #+12 = 12 min; #+13 = 13

min; #+14 = 14 min; #+15 = 15 min)

Entry 2:

0 = Keypad display when line is faulted

1 = Keypad display plus keypad trouble sound

2 = Same as “1”, plus programmed output device STARTS.

If either partition is armed, external sounder activates

also.

NOTE: Output Device must either be programmed to be

STOPPED in field ✱80 or STOPPED by Code + # + 8 +

output number.

Entry 1: Sets the length of time a phone line fault must

remain after detected before the second digit option is

activated.

Entry 2: Selects the desired phone line fault response.

Option 2 may be used even if a relay unit or Powerline

carrier device is not connected to the control.

Programmed Output Device must either be programmed to

be STOPPED in field ∗80 or STOPPED by entry of [security

code] + [#] + 8 + device number. Partition in ∗80 should be

set to “0,” for STOP.

UL: Field *92 must be enabled for fire alarm installations,

UL commercial burglar alarm installations and UL

residential burglar alarm installations.

If the control unit is used on a UL commercial burglar alarm

system which requires 2 methods of remote

communication, then the control unit’s DACT and the other

method of signal transmission must monitor each other

against communication failure and line fault. The fault must

be received and annunciated within 200 seconds of its

occurrence.

–9–

∗

∗∗

∗93 Reports In Armed Period [1,0]

Per Zone (Swinger Suppression) Restrict Unlimited

Restrict Report Pairs: Report Pairs Reports

1 = 1 report pair; 2 = 2 report pairs

NOTE: If restricting report pairs, *70 Alarm Restore Report

Code must be enabled.

Unlimited Reports Enable:

0 = restrict reports to the setting in entry 1

1 = unlimited reports for zones listed in zone list 7; (use

zone list 7 to enter those zones that require unlimited

reporting; these zones ignore the setting in entry 1)

Selection limits the number of alarm/alarm restore message

pairs per zone sent to the CS in an armed period. Swinger

suppression applies to burglary zones only.

DOWNLOAD INFORMATION (✱94, ✱95)

∗

∗∗

∗94 Download Phone No. [18006821690]

| | | | | | | | | | | | | | | | | | |

Enter up to 20 digits, 0–9; #+11 for '✱'; #+12 for '#'; #+13 for

a 2-second pause. Do not fill unused spaces. If fewer than

20 digits, exit field by pressing ✱. To clear entries from field,

press ✱94✱.

UL: Up/downloading via phone line may be performed only if

a technician is at the site.

Up/downloading via the Internet has not been evaluated

by UL.

∗

∗∗

∗95 Ring Count For Downloading [15]

NOTE: Do not enter “0” if using 4286 Phone Module.

0 = Disable Station Initiated Download;

1–14 = number of rings (1–9, # +10 =10, # +11 =11,

# +12 =12, # +13 =13, # +14 =14);

15 = answering machine defeat (# +15 =15).

Refer to the chart below and program accordingly.

phone answer down-

module machine loading Set field ∗

∗∗

∗95 to…

yes no no 1-14 (not 0)

yes yes no greater than rings set on

answer machine (e.g., if ans.

machine is 4 rings, set this

field to 5). This allows access

to the phone module if the

answer machine is off.

yes no yes 1-14 (not 0)

yes yes yes 15 (bypasses answer

machine†)

no no no 0

no yes no 0

no no yes 1-14

no yes yes 15

†NOTE: If “15” is entered to bypass an answering machine, and a

4286 Phone Module is included in the system, you should note

the following:

When calling in from an off-premises phone, the user should make

the initial call, allow 1 or 2 rings only, then hang up, then call again.

The phone module will now seize the line, and 2 long tones sound,

followed by the usual voice prompt for the access code. If this

procedure is not followed, phone module operation will not be

possible.

∗

∗∗

∗96, ∗

∗∗

∗97 Initialize/Reset Defaults

This is a command, not a data field.

∗

∗∗

∗98, *99 Exit Commands

This is a command, not a data field.

PAGER OPTIONS (✱160- ✱172)

The system can send various reports to several pagers (MTV20P =

up to 4; MTV15P = up to 2).

To program pager reporting, do the following:

1. Enter the pager phone number(s), preface characters, and pager

report options in data fields *160 - *171.

2. Enable Pager Delay, if desired, in field *172 (delays alarm

reporting for ALL pagers).

3. Make sure appropriate user open/close pager reports are enabled

(see Security Codes section in User Guide). Users that perform

actions in partition 1 will, if enabled, attempt to report to all

pagers enabled for open/close reporting in partition 1. Users that

perform actions in partition 2 will, if enabled, attempt to report to

all pagers enabled for open/close reporting in partition 2.

4. If using latchkey pager report, define the latchkey report

schedule using Scheduling mode (master code + [#] [6] [4]

then select event type

). System must be armed for the

Latchkey report to be sent.

5. If using a function key to manually send a message to a pager,

use *57 Function Key Menu mode to define the key (function

6. If reporting zone alarms and troubles to a pager, use *81 Zone

List menu mode to assign the zones associated with each pager

(zone lists 9-12†).

† MTV15P supports zone lists 9 and 10 only.

∗

∗∗

∗160 Pager 1 Phone No.

| | | | | | | | | | | | | | | | | | |

Enter up to 20 digits. 0–9; #+11 = '✱'; #+12 = '#'; #+13 = 2-

sec pause.

If entering fewer than 20 digits, exit by pressing [∗] + next

field number. To clear entries, press ∗160∗

∗

∗∗

∗161 Pager 1 Characters

| | | | | | | | | | | | | | |

Enter the optional prefix characters, up to 16 digits.

0–9; #+11 = '✱'; #+12 = '#'; #+13 = 2-second pause.

Up to 16 optional characters may be sent as a prefix to the 7-digit

system status code sent to Pager #1 (if used). Phone number in field

*160 must have been entered. If fewer than 16 characters, exit by

pressing [∗] and next field number. To clear entries: press ∗161∗.

The 16 characters may be composed of the following:

PIN number, Subscriber account number,

∗character, # character, 2-second pause,†

special character(s) the user may decide to transmit

† Some paging systems require pause(s) before the prefix.

The Pager format for the 7-digit status code is defined as follows:

XXX-YYYY where:

XXX = 3-digit event code: 911 = Alarm, 811 = Trouble, 101 =

Opening (disarm), 102 = Closing (arm AWAY)

YYYY = 4-digit user or zone number (depending on type of event).

The first digit indicates partition (0 = system, 1 = part 1, 2 =

part 2, 3 = common), followed by the 3-digit user or zone

number.

DisplayExample1.911–1004 Indicatesanalarm(911) caused

by a fault in zone 4 (0004) in part. 1.

DisplayExample2.102–2005 Indicatesthesystemisreporting

a closing–system arming (102) by User 5 (0005) in partition 2.

∗

∗∗

∗162 Pager 1 Report Options [0,0,0]

P1 P2 common

For each partition, select from the following options:

0 = no reports sent

1 = Opens/closes all users enabled for paging†

4 = All alarms and troubles

5 = All alarms / troubles, and opens/closes for all users

12 = Alarms / troubles for zones entered in zone list 9

13 = Alarms / troubles for zones entered in zone list 9, and

opens/closes for all users

For each partition, select from the listed options.

† For users enabled for paging. Reports to pager only when

arming (close)/disarming (open) from a keypad using a

security code; auto-arming/disarming, arming with assigned

button, and keyswitch arming do not send pager messages.

–10 –

∗

∗∗

∗163 Pager 2 Phone No.

| | | | | | | | | | | | | | | | | | |

Enter up to 20 digits. 0–9; #+11 = 'Q'; #+12 = '#'; #+13 = 2-

sec pause.

If entering fewer than 20 digits, exit by pressing [∗] + next

field number. To clear entries, press ∗163∗.

∗

∗∗

∗164 Pager 2 Characters

| | | | | | | | | | | | | | |

Enter the optional prefix characters, up to 16 digits.

0–9; #+11 = '✱'; #+12 = '#'; #+13 = 2-second pause.

See field ∗161 for explanation. If fewer than 16 characters,

exit by pressing [∗] and next field number. To clear entries,

press ∗164∗.

∗

∗∗

∗165 Pager 2 Report Options [0,0,0]

P1 P2 common

See field *162 for reporting options. Select for each partition

(use zone list 10 if using options 12 or 13).

∗

∗∗

∗166 Pager 3 Phone No.

| | | | | | | | | | | | | | | | | | |

Enter up to 20 digits. 0–9; #+11 = '✱'; #+12 = '#'; #+13 = 2-

sec pause.

If entering fewer than 20 digits, exit by pressing [∗] + next

field number. To clear entries, press ∗166∗.

∗

∗∗

∗167 Pager 3 Characters

| | | | | | | | | | | | | | |

Enter the optional prefix characters, up to 16 digits.

0–9; #+11 = '✱'; #+12 = '#'; #+13 = 2-second pause.

See field ∗161 for explanation. If fewer than 16 characters,

exit by pressing [∗] and next field number. To clear entries,

press ∗167∗.

∗

∗∗

∗168 Pager 3 Report Options [0,0,0]

P1 P2 common

See field *162 for reporting options. Select for each partition

(use zone list 11 if using options 12 or 13).

∗

∗∗

∗169 Pager 4 Phone No.

| | | | | | | | | | | | | | | | | | |

Enter up to 20 digits. 0–9; #+11 = '✱'; #+12 = '#'; #+13 = 2-

sec pause.

If entering fewer than 20 digits, exit by pressing [∗] + next

field number. To clear entries, press ∗169∗.

∗

∗∗

∗170 Pager 4 Characters

| | | | | | | | | | | | | | |

Enter the optional prefix characters, up to 16 digits.

0–9; #+11 = '✱'; #+12 = '#'; #+13 = 2-second pause.

See field ∗161 for explanation. If fewer than 16 characters,

exit by pressing [∗] and next field number. To clear entries,

press ∗170∗.

∗

∗∗

∗171 Pager 4 Report Options [0,0,0]

P1 P2 common

See field *162 for reporting options. Select for each partition

(use zone list 12 if using options 12 or 13).

∗

∗∗

∗172 Pager Delay Option For Alarms [3]

0 = none; 1 = 1 minute; 2 = 2 minutes; 3 = 3 minutes

This delay is for ALL pagers in the system.

This field determines the delay of alarm reports to the pager.

This gives the Central Station enough time to verify the

alarm report it received before the dialer attempts to dial the

pager.

MISCELLANEOUS SYSTEM FIELDS (*174-*181)

∗

∗∗

∗174 Clean Me Reporting Options [0]

(for ESL smoke detectors)

0 = disable; 1 = Clean Me signal reports;

NOTE:

If Clean Me is enabled, you must enter “3” in field

✱56 programming for zone 1 response time.

This is a maintenance feature for ESL 2-wire smoke

detectors on Zone 1. If used, this option limits the number of

smoke detectors to a maximum of 10, rather than 16. To

enable the “clean me” feature, a time response setting of “3”

(1.2 seconds) must be entered in ∗56 Zone Programming for

zone 1.

∗

∗∗

∗177 Device Duration 1, 2 [0] [0]

(used in *80 Menu mode-Device Actions 5/6) 1 2

0 = 15 seconds 6 = 2-1/2 min #+11 = 7 min

1 = 30 seconds 7 = 3 min #+12 = 8 min

2 = 45 seconds 8 = 4 min #+13 = 10 min

3 = 60 seconds 9 = 5 min #+14 = 12 min

4 = 90 seconds #+10 = 6 min #+15 = 15 min

5 = 2 minutes

These entries set the duration for output action options 5

(duration 1) and 6 (duration 2) programmed in ∗80 Output

Function Programming.

∗

∗∗

∗181 50/60 Hertz AC Operation [0]

0 = 60 Hz; 1 = 50 Hz

Select the type of AC power applied to the control (option is

used for Real-Time Clock synchronization)

CONFIGURABLE ZONE TYPE OPTIONS (*182-*185)

(see Configurable Zone Type Worksheet on page 13)

•The system allows you to define custom zone types (MTV20P

supports 4 [types 90-93]; MTV15P supports 2 [types 90, 91]),

based on the options described below.

•All configurable zone types can be programmed via the downloader.

Zone types 90-91 can also be programmed from a keypad using

data fields *182-*185.

•IMPORTANT: Be careful when selecting combinations of options

for configurable zone types. Contradictory options can cause

unpredictable results.

Configurable Zone Type Options

Auto Restore (entry 2): Faults on zones set for this option are

cleared; restore messages sent upon restoral of faults.

Vent Zone (entry 2): Zones set for this option are ignored if faulted

when arming the system, but are protected if the zone is later

restored (e.g., an open window can be ignored when arming, but if

the window is later closed, it will be protected; opening the window

again causes an alarm.)

Bypass Disarmed (entry 4): Zones set for this option can be

bypassed only while the system is disarmed.

Bypass Armed (entry 4): Zones set for this option can be bypassed

when the system is armed.

Dial Delay (entry 6): Alarms on zones set for this option participate

in dial delay central station reporting, if system dial delay enabled in

field *50.

Fault Delay (entry 6): Faults on zones set for this option are

delayed by the time set in field *87. Do not use this option if using

entry/exit delay for this zone type.

Faults Display (entry 7): Selects how faults on zones set for this

zone type are displayed.

Power Reset/Verification (entry 7): Selects whether the system

resets power (when user enters code + OFF), and whether the

system performs alarm verification (see description for zone type 16

in Zone Type Definitions section) when a fault occurs on these

zones.

Use Entry Delay (entry 8): Selects whether to use the system’s

entry delay times.

Use Exit Delay (entry 8): Selects whether to use the system’s exit

delay time.

Interior Type (entry 8): Zones set for this option are treated same

as standard zone type 4 (bypasses when armed STAY, faults

displayed).

Alarm Sounds (entry 9): Selects the type of alarms sound for

zones set for this zone type.

–11 –

Configurable Zone Type Options (continued)

Bell Timeout (entry 9): Alarm sounding on zones set for this option

remain for the duration set in fields *32 / *33.

Fire Zone (entry 9): Zones set for this option respond in the same

manner as if programmed for zone type 9. Do not set fire zones to

respond as a “fault” in entries 1-6.

Trouble Sounds (entry 10): Selects the type of trouble sounds for

zones set for this zone type (periodic beeps = once every 30

seconds; trouble beeps = rapid beeping).

Chime Enable (entry 10): Zones set for this option cause a chime

when Chime mode is on.

∗

∗∗

∗182 Configurable Zone Type 90

1 2 3 4 5 6 7 8 9 10

Enter the appropriate value for each entry, 1-10, based on the charts

provided on the next page. Each entry is the sum of the values of its

selected options

(0-9, #+10=10, #+11=11, #+12=12, #+13=13, #+14=14, #+15=15).

To calculate the value for each entry, add the values of the

selected options in each of the entry’s columns shown in the

respective chart (one option per column). For example, to

program entry 2 for “alarm response to short,” “auto restore

on,” but not a “vent zone,” enter 5 (“1” for alarm short + “4”

for auto restore-yes + “0” for vent zone-no).

UL: Do not configure zones as a fire alarm or UL burglar

alarm zone.

∗

∗∗

∗183 Zone Type 90 Report Codes

90 ALARM ID: XXX

TROUBLE ID: XXX

Enter the desired 3-digit Contact ID® report codes for

alarms and troubles occurring on zones assigned to this

zone type. Enter the codes sequentially (all 6 digits). When

entering digits, [#] moves cursor back, [∗] moves forward.

Press [∗] when done to continue.

NOTE: Zone alarm report codes and trouble report code

(∗60) and relevant restore codes must be enabled in order to

report configurable zone type codes.

Important Notice on Report Codes: To avoid confusion at

the central station, it is recommended that existing Contact

ID® codes be used with configurable zone types whenever

possible. Check with the central station for a complete list of

Contact ID® report codes. If none of the codes are suitable,

choose a code in the reserved range of 750-789 and make

sure to define the code with your central station.

∗

∗∗

∗184 Configurable Zone Type 91

1 2 3 4 5 6 7 8 9 10

Enter the appropriate value for each entry, 1-10, based on

the charts provided on the next page. Each entry is the sum

of the values of its selected options

(0-9, #+10=10, #+11=11, #+12=12, #+13=13, #+14=14,

#+15=15).

See ∗182 for entries.

UL: Do not configure zones as a fire alarm or UL burglar

alarm zone.

∗

∗∗

∗185 Zone Type 91 Report Codes

91 ALARM ID: XXX

TROUBLE ID: XXX

See ∗183 for entries.

Press [∗] when done to continue.

∗

∗∗

∗189 AUI Device Enable [0,0,0,0]

(for Touchscreen Keypads) AUI 1 AUI 2 AUI 3 AUI 4

System supports touchscreen style keypads (e.g., Symphony

Advanced User Interface, and 6270 Touchscreen Keypad).

AUI Compatibility Note: To ensure proper AUI device

operation, use AUI devices with the following rev levels:

6270 series use version 1.0.9 or higher; 8132/8142

(Symphony) series use version 1.1.175 or higher.

Touchscreen device 1: Set device address to 1

Touchscreen device 2: Set device address to 2

Touchscreen device 3: Set device address to 5 (V20PMT)

Touchscreen device 4: Set device address to 6 (V20PMT)

Note for Remote Services Device Address: Using an AUI

device address for Remote Services provides enhanced

remote services features, but an actual AUI device is not

used. If no AUI addresses are available (all four AUIs are

being used), choose an available standard keypad address

and use the appropriate keypad address field ∗190 - ∗196 to

select the Remote Services operating partition (some

remote access features will be unavailable).

NOTE: Use of touchscreen style keypads does not affect

the number of standard keypads supported.

VISTA-20PMT: Up to four AUI devices.

To enable a touchscreen keypad, enter the option

corresponding to each touchscreen’s home partition.

For Touchscreen device usage

0 = disable

1 = partition 1

2 = partition 2

3 = partition 3 (common)

For Remote Services device usage

5 = part. 1 (auto-stay arm disabled)

6 = part. 2 (auto-stay arm disabled)

7 = part. 3 (common; auto-stay arm disabled)

VISTA-15PMT: Up to two AUI devices. Select the desired

option.

For Touchscreen device usage

0 = disable

1 = enable

For Remote Services device usage

5 = auto-stay arm disabled

Note for Remote Services Devices: If using the Remote

Services feature of the communication device, select an

option 5-7, depending on the partition the Remote Services

device is associated with (these options automatically

disable auto-stay arming when the system is armed from the

respective Remote Services device). Refer to the

communication device’s installation instructions for details

on enabling the Remote Services feature.

KEYPAD OPTIONS *190-*196

To enable keypads:

1. Set desired address at keypad (refer to keypad’s instructions for

setting the address).

2. Use data fields *190-*196 to enable keypad addresses, assign a

partition, enable sound options in field.

3. Use fields *197, *198, and *199 to turn on partition number

display, exit time interval display, and select fail display mode.

4. Set keypad-related data fields as appropriate: *21 Quick Arm

Enable, *23 Forced Bypass, *84 Auto STAY Arm

NOTES: 1.Options for keypad address 16 are set by the factory

and cannot be changed.)

2. Each keypad must be assigned a unique address.

Keypads programmed with the same address will give

unpredictable results.

–12 –

KEYPAD OPTIONS

∗

∗∗

∗190 Keypad 2 Device Address 17 [0] [0]

VISTA-20PMT V20P Partition/ Sound

Partition: V15P Enable

Enter the desired option for the keypad’s home partition.

For Touchscreen device usage

0 = disable

1 = partition 1

2 = part. 2

3 = part. 3 (common)

For Remote Services device usage

5 = part. 1 (auto-stay arm disabled)

6 = part. 2 (auto-stay arm disabled)

7 = part. 3 (common; auto-stay arm disabled)

Sound: Enter the desired sound option for this keypad.

0 = no suppression

1 = suppress arm/disarm and E/E beeps

2 = Suppress chime beeps only

3 = suppress arm/disarm, E/E, and chime beeps

VISTA-15PMT

Enable:

For Touchscreen device usage

0 = disable

1 = enable

For Remote Services device usage

5 = auto-stay arm disabled

Sound: Enter the desired sound option for this keypad.

0 = no suppression

1 = suppress arm/disarm and E/E beeps

2 = Suppress chime beeps only

3 = suppress arm/disarm, E/E, and chime beeps

Note for Remote Services Devices: If using the Remote

Services feature of the communication device, select an

option 5-7 (option 5 for VISTA-15PMT), depending on the

partition the Remote Services device is associated with

(these options automatically disable auto-stay arming

when the system is armed from the respective Remote

Services device). Refer to the communication device’s

installation instructions for details on enabling the Remote

Services feature.

Partition Sound

Enable

∗

∗∗

∗191 Keypad 3 Device Address 18 [0] [0]

See field ∗190 for entries.

∗

∗∗

∗192 Keypad 4 Device Address 19 [0] [0]

See field ∗190 for entries.

∗

∗∗

∗193 Keypad 5 Device Address 20 [0] [0]

See field ∗190 for entries.

∗

∗∗

∗194 Keypad 6 Device Address 21 [0] [0]

See field ∗190 for entries.

∗

∗∗

∗195 Keypad 7 Device Address 22 [0] [0]

See field ∗190 for entries.

∗

∗∗

∗196 Keypad 8 Device Address 23 [0] [0]

See field ∗190 for entries.

∗

∗∗

∗197 Exit Time Display Interval [2]

0 = no display; 1-5 = seconds between display refresh

If enabled, keypads display the exit time remaining after

arming the system, updated at the interval selected (i.e. if

the exit delay is 30 seconds and “2” is selected in this field,

the keypad display refreshes every 2 seconds, displaying

30, 28, 26, 24, etc.).

An interval greater than “1” may be necessary for some

older keypads to allow users time to enter key presses

between display updates.

NOTE: If enabled and using only 2-digit fixed-word keypads

(e.g., 6150RF), do not set exit delay time greater than 96

seconds. Using a longer delay time may cause end-user

confusion because 2-digit display keypads cannot display

times greater than “99.” If longer exit time is required by the

installation, it is recommended that the Exit Time Display

option be disabled (“0”).

TOUCH SCREEN DEVICE NOTE: If using more than one

touch screen device (e.g., 6270, Symphony) with the

system, leave field *197 Exit Time Display Interval set to the

default value “0.” The 6270 automatically displays remaining

exit time in one-second increments.

∗

∗∗

∗198 Display Partition Number [1]

(VISTA-20PMT; for Alpha Display Keypads)

0 = no; 1 = yes (partition no. appears on Alpha Display)

If selected, the partition number is displayed in the upper-left

corner of the display. This is useful when using the GOTO

partition function.

∗

∗∗

∗199 ECP Fail Display [0]

0 = 3-digit display (“1” + device address)

1 = 2-digit fixed-display as “91”

Select “0” if using Alpha keypads and/or 3-digit Fixed-Word

Display keypads. ECP faults will display “1” plus the device

address (00-15) of device causing the fault (e.g., faults on

device 07 display as “107”).

Select “1” if using 2-digit Fixed-Word Display keypads (e.g.,

certain 6128 series keypads). If selected, ECP faults for all

devices will display as “91” on 2-digit displays, and “191” on

3-digit or Alpha keypads.

–13 –

CONFIGURABLE ZONE TYPES WORKSHEETS

Configurable zone types 90 and 91 can be programmed via downloader software or from a keypad using data fields*182-

*185. Configurable zone types 92 and 93 (VISTA-20PMT only) can only be programmed using the downloader software.

Programming Configurable Zone Type options involves making 10 entries in data field *182 for zone type 90 and field *184 for

zone type 91, where each entry represents the sum of the values of the various options shown in the tables below. Use fields

*183 and *185 to program Contact ID report codes for these zone types.

ENTRY 1 (See note 5 for RF zones) ENTRY 2 (See note 5 for RF zones)

Response when system disarmed and zone is:

Intact EOL

RF zone normal

Open

RF zone N/A

Shorted

RF zn off-normal

Auto

Restore

Vent Zone

0 = normal

1 = alarm

2 = trouble

3 = fault

0 = normal

4 = alarm

8 = trouble

12 = fault

0 = normal

1 = alarm

2 = trouble

3 = fault

see note 6

0 = no

4 = yes 0 = no

8 = yes

Entry 1 = EOL + Open Entry 2 = Short + auto restore + vent zone

ENTRY 3 (See note 5 for RF zones) ENTRY 4 (See note 5 for RF zones)

Response when armed STAY and zone is:

Intact EOL

RF zone normal

Open

RF zone N/A

Shorted

RF zn off-normal

Byp. when

disarmed Byp. when

armed

0 = normal

1 = alarm

2 = trouble

3 = fault

0 = normal

4 = alarm

8 = trouble

12 = fault

0 = normal

1 = alarm

2 = trouble

3 = fault

see note 6

0 = no

4 = yes

0 = no

8 = yes

Entry 3 = EOL + Open Entry 4 = Short + byp. disarmed + byp. armed

ENTRY 5 (See note 5 for RF zones) ENTRY 6 (See note 5 for RF zones)

Response when armed AWAY and zone is:

Intact EOL

RF zone normal

Open

RF zone N/A

Shorted

RF zn off-normal

Dial Delay

(see field *50) Fault Delay

(see field *87)

0 = normal

1 = alarm

2 = trouble

3 = fault

0 = normal

4 = alarm

8 = trouble

12 = fault

0 = normal

1 = alarm

2 = trouble

3 = fault

see note 6

0 = no

4 = use delay

0 = no

8 = use delay

see note 1

Entry 5 = EOL + Open Entry 6 = Short + dial delay + fault delay

ENTRY 7 ENTRY 8

Display Faults Power Reset/

Verification Use Entry

Delay 1/2 Use Exit

Delay Respond as

Interior Type

0 = show alarms

when armed

& disarmed

1 = don’t show

alarms when

armed (show

alarms, trbles,

faults when

disarmed)

3 = never show

any alarms,

trbles, faults

0 = no

4 = power reset

after fault

(by code + OFF)

12 = verification

(see zone

type 16)

0 = no

1 = delay 1

2 = delay 2

0 = no

4 = use exit

delay

0 = no

8 = yes

see note 2

Entry 7 = fault display + power

reset/verification Entry 8 = entry delay 1/entry delay 2 + exit delay +

interior zone type

ENTRY 9 ENTRY 10

Alarm Sounds Use Bell

Timeout Respond as

Fire Zone Trouble

Sounds Chime when

Chime Mode On

0 = none

1 = steady

keypad

2 = steady bell

and keypad

3 = pulsing bell

and keypad

0 = no

4 = yes

see fields *32,

*33

0 = no

8 = yes

see zone type

09; see note 4

0 = none

1 = periodic

beep

2 = trouble

beeps

0 = no

4 = yes

Entry 9 = alarm sounds + bell timeout + fire zone Entry 10 = trouble sounds + chime

Entries for Fields *182 and *184

Entry Zone Type 90 Zone Type 91

(field *182) (field *184)

To calculate the value for each entry:

Simply add the values of the selected options

in each of the entry’s columns (one option per

column). For example, to program Entry 2 for

“alarm response to short,” “auto restore on,”

but not a “vent zone,” enter 5 (“1” for alarm

short + “4” for auto restore yes + “0” for vent

zone no).

OPEN SHORTEDINTACT

EOL

ZONE-003-V0

Zone Conditions Represented

in Entries 1-6

NOTES:

1. Do not use the “fault delay” option with a

configurable zone type if it is set for an

entry or exit delay, otherwise

unpredictable results may occur.

2. To create an interior type zone, select

“respond as interior zone type” (entry 8,

interior type = yes), and set zone

response to “fault” in entries 3-4 to ensure

fault displays; do not set as “normal,”

“alarm,” or “trouble.”

3. Do not set fire zones to respond as a

“fault” (entries 1-6), otherwise faults will

not display unless the [∗] key is pressed.

4. 4219/4229 modules must use EOLRs or

unpredictable results may occur.

5. RF Zones: The “open” option in entries 1,

3, and 5 is not applicable for RF zones.

Use the “intact EOL” option for normal RF

zone conditions and “shorted” for off-

normal RF zone conditions.

6. a. Zone-Doubling/Double-Balanced: A

short on either zone of a zone-doubled

pair or on a double-balanced zone

causes a tamper condition.

b. For double-balanced zones, this entry

must be “0.”

c. For zone-doubled zones, both zones

of the doubled pair must be assigned

the same response to a short.

–14 –

∗

∗∗

∗56 ZONE PROGRAMMING MENU MODE

(press *56 while in Program mode) The Zone Programming Worksheet is on page 28.

Zones and Partitions

Each protection zone needs to be programmed with various attributes using *56 Zone Programming mode or ✱58 Expert

Programming Mode. Using this mode, enter the zone number to be programmed and make appropriate entries at the

prompts. Finally, Confirm the serial number of wireless transmitter zones.

The VISTA-20PMT system can control two independent areas of protection (known as partitions) for use by independent

users, if desired, by simply assigning zones to one or the other partition during zone programming. The VISTA-20PMT, by

default, automatically distributes users between the two partitions. The master user can change the user number distributions.

Zones can also be assigned to a common partition, which is an area shared by users of both partitions (such as a lobby in a

building). This allows either partition to arm, while leaving the common partition disarmed for access into the other partition.

The following describes the functioning of the VISTA-20PMT common partition:

• The common zone sounds and reports alarms only when both partitions are armed. If only one partition is armed, the

system ignores faults on the common zone.

• Either partition may arm its system if the common zone is faulted, but once armed, the other partition will not be able to arm

unless the common zone is first bypassed or the fault is corrected.

• Faults on the common zone are displayed on common zone keypads, and will also appear on another partition’s keypad

when that partition is armed.

• Either partition can clear and restore the common zone after an alarm.

For each of the following prompts, make the desired entry, followed by the [∗] key to accept the entry.

SET TO CONFIRM?

0 = no (default)

1 = yes (See XMIT TO CONFIRM prompt later in this section.)

We recommend that you confirm the programming of every

transmitter.

This display appears upon entry into this mode.

If 1 (Yes) is entered, you will be prompted to confirm each

transmitter after entering the serial and loop numbers (at the

“XMIT TO CONFIRM” prompt later).

ENTER ZN NUM.

VISTA-20PMT:

wired 01-08 (and 09-48†)

wireless 09-48; RF button zones 49-64

VISTA-15PMT:

wired 01-06 (and 07-22†)

wireless 09-34; RF button zones 49-56

Both Controls:

91 = addr. device report enable

92 = duress report enable

95, 96, 99 =emerg. zones

To quit, enter 00 to quit (returns to data field mode).

Enter the zone number that you wish to program.

Enter a report code for zone 91 to enable addressable device

reporting.

Enter a report code for zone 92 to enable duress reporting.

95, 96, 99 are emergency (panic) key zones.

† if zone expanders are used.

SUMMARY SCREEN:

System displays a summary of the entered zone’s current

programming. Press [∗] to continue.

“IN: L” appears for wireless zones and indicates input type and

loop.

“IN: AD” appears for hardwire expansion zones (AW) and

indicates the module’s address (AD), which is based on the zone

number.

“HW: RT” appears for hardwire zones and indicates configuration

(EOL, NO, NC, zone doubling, double-balanced) and response

time selection.

ZONE TYPE

Each zone must be assigned to a zone type, which defines the way

in which the system responds to faults in that zone. Enter the Zone

Type code from the list below:

Note: If 00 is entered, Delete Zone ? will be displayed.

00 = Not used 07 = 24-Hr Audible 20 = Arm–STAY*

01 = Entry/exit #1 08 = 24-Hr Aux 21 = Arm–AWAY*

02 = Entry/exit #2 09 = Fire 22 = Disarm*

03 = Perimeter 10 = Interior w/Delay 23 = No Alarm Resp

04 = Interior Follower 12 = Monitor Zone 24 = Silent Burglary

05 = Trouble Day/Alarm Night 14 = Carbon Monoxide 77 = Keyswitch

06 = 24-Hr Silent 15 = Medical** 81 = AAV Monitor

16 = Fire w/Verify Zone

*5800 button-type transmitters only 90-91 = Configurable

**Zone type 15 is similar to zone type 08 (keypad alarm sounding, no bell

output), except that Contact ID code 100 is sent to the central station.

UL: Zone type 15 may not be used in UL installations.

PARTITION

1, 2, or 3-common (VISTA-20PMT)

Enter the Partition number for this zone.

REPORT CODE

1-9, 10 for 0, 11 for B, 12 for C, 13 for D, 14 for E, 15 for F

For Contact ID®, enter any non-zero entry as the first digit to enable

reporting for this zone.

To disable the report code for this zone, enter 00.

Enter the report code for this zone, which consists of 2 hexadecimal

digits, each in turn consisting of 2 numerical digits. For example, for a

report code of “10,” enter

and

HARDWIRE TYPE

Appears only for zones 02-08. Zone 1 is automatically set for EOL

operation. Enter the desired hardwire type:

0 = EOL 3 = zone doubling (ZD)†

1 = NC 4 = double-balanced (DB)†

2 = NO († VISTA-20PMT)

RESPONSE TIME

For hardwired zones 01-08. Enter the desired response time for this

zone:

0 = 10mSec 2 = 700mSec

1 = 350mSec 3 = 1.2 secs (see field ∗174)

NOTE: If zone doubling is being used, the response time selected for

zones 02-08 automatically applies to each zone’s associated doubled

zone.

INPUT TYPE

Skipped for zones 2-8, and for zones 10-16 if zone-doubling enabled.

Enter the input type:

2 = AW (Aux wired zone) 4 = UR (unsupervised RF)

3 = RF (supervised RF) 5 = BR (unsupervised button type)

NOTE: To change the input type of a previously programmed wireless

device to a wired zone, you must first delete the transmitter’s serial

number.

All of the RF transmitters have one or more unique factory-assigned

input (loop) ID codes. Each of the inputs requires its own programming

zone

(e.g., a 5804's four inputs require four programming zones).

RF Transmitters can be enrolled as one of the following types:

Type Description

(Supervised RF) Sends periodic check-in signals, as well as fault,

restore, and low-battery signals. The trans. must

stay within receiver's range.

(Unsupervised RF) Sends all the signals that the “RF” type does, but

the control does not supervise the check-in

signals. The transmitter may therefore be carried

off-premises.

(Unsupervised

Button RF)

Sends only fault signals. It will not send a low-

battery signal until it is activated. The transmitter

may be carried off-premises.

NOTE: For the built-in hardwired zones, the Input Device type is

automatically displayed as HW and cannot be edited.

–15 –

INPUT S/N

Enroll the transmitter’s serial number and loop number as follows:

1. a. Transmit two open/close sequences (for button-type

transmitters, press and release the button twice, waiting

about 4 seconds before pressing the button the second

time).

b. Manually enter the 7-digit serial number printed on the label

of the transmitter. Press the [∗] key to move to the “L”

position, then enter the loop number.

Use the [A] (Advance) and [B] (Back) keys to move the

cursor forward and back within the screen. Pressing the [C]

(Copy) key will insert the previously enrolled serial number, if

desired (used when programming a transmitter with several

input loops).

To delete an existing serial number, enter 0 in the loop

number field. The serial number will change to 0's. If 0

was entered in error, simply re-enter the loop number or

press [#], and the serial number will return to the display.

2. Press [∗] to continue. The system now checks for a duplicate

serial/loop number.

If no duplicate is found, the display shows the serial number

and loop number.

3. Press [∗] to continue to confirmation screen.

Loop Number Change

NOTE: If the [C] key is used to copy the previously enrolled serial

number, the cursor will move to the Loop column (L) with the

previous serial number displayed, and display a highlighted

question mark for the loop number.

Enter the loop number and press [✱]. The system will now check

for a duplicate serial/loop number combination.

XMIT TO confirm

Appears if you answered “Yes” at the “Set to Confirm” prompt.

Activate the loop input or button that corresponds to this zone.

Press [∗] to continue.

If the serial/loop number transmitted does not match the serial

number entered, a display showing the entered and the received

serial/loop numbers appears.

If so, activate the loop input or button on the transmitter once

again. If a match is not obtained, press the [#] key twice and

then enter (or transmit) the correct serial number.

Press [∗] to continue

If the serial number transmitted matches the serial number

entered, the keypad will beep 3 times and a summary display will

appear, showing that zone's programming. An “s” indicates that

a transmitter’s serial number has been enrolled.

Press [∗] to accept the zone information and continue.

PROGRAM ALPHA?

Press 1 if you want to program descriptors for the zone now, and

refer to the *82 Descriptor Programming section for procedure.

To program descriptors later, enter 0 (no).

Press [∗] to return to the ENTER ZN NUM prompt.

Completing Zone Programming

•When you have finished programming all zones, test each zone

using the system’s TEST mode.

•Do not use the Transmitter ID Sniffer Mode for checking

wireless transmitting devices, as it will only check for

transmission of one zone on a particular transmitter, NOT the

zones assigned to each additional loop.

∗

∗∗

∗58 EXPERT ZONE PROGRAMMING MODE

(press ∗

∗∗

∗58 while in Data Programming mode)

This method is designed for use by installers with previous experience

in programming HONEYWELL control panels. This mode is also used

to program wireless keys using pre-defined templates.

SET TO CONFIRM?

Select whether you want confirmation of wireless device enrollment.

(See “XMIT TO CONFIRM” prompt later in this section.) We

recommend that you confirm the programming of every

transmitter.

SUMMARY SCREEN

Zn ZT P RC HW: RT

01 09 1 10 EL 1

(Typical for Zone 1, initial summary screen)

Zn ZT P RC IN: L

10 00 1 10 RF: –

(Typical for entered zone number; zone 10 in this example)

System displays summary of zone 1’s current programming.

Enter the zone number being programmed, then press [∗]. A summary

screen for that zone is displayed, along with any current programming

values, and the cursor moves to the Zone Type location. The cursor

then automatically moves to the next locations after each entry is

made.

Special Function Keys:

•[A] (Advance) and [B] (Back) keys on the keypad move the

cursor within the screen.

•[C] (Copy) key will insert the previous zone’s attributes, if

desired.

•[D] key starts the Wireless Key Programming Templates

menu (see Wireless Key Programming Templates section that

follows this section).

Sequentially enter Zone Type (ZT), Partition (P)†, and Report Code

(RC; 0-9 only; use *56 mode to enter hex codes), then Hardwire Type

(HW) and Response Time (RT) for basic wired zones 1-8 or Input

Device Type (IN) for zones 9 and higher (Loop Number [L] is

programmed at the INPUT S/N prompt).

See *56 Zone Programming Menu Mode section described earlier for

entry values.

† applies to VISTA-20PMT

Press [∗] to save the programming and continue. If needed, press the

[#] key to back up without saving.

•For wireless devices (input types RF, UR, BR), continue to the

INPUT S/N (serial number/loop number) and XMIT TO CONFIRM

prompts described earlier in the *56 Zone Programming Menu

Mode section. When done, the display returns to the initial summary

screen prompt to let you program the next zone.

•For wired devices, the display returns to the initial summary screen

prompt to let you program the next zone.

To Quit, enter 00 at the zone number location and press [∗].

–16 –

WIRELESS KEY PROGRAMMING TEMPLATES

(press the [D] key from *58 Menu mode Summary Screen)

This procedure programs the wireless keys, but a key is not active for arming/disarming until it is assigned to a user

number (see

System Operation

section, Assigning Attributes Command in the Installation Instructions).

TEMPLATE ?

Enter desired template number 1–6 (see chart below), then press

[∗] to continue.

To exit the Template screen, press [#]. The system returns to the

*58 Menu mode Summary Screen.

TEMPLATE SUMMARY

L 01 02 03 04

T 23 22 21 23

The selected template is displayed.

The top line represents loop numbers, the bottom line represents

each loop’s zone type.

Press [∗] to accept template and continue.

PARTITION (VISTA-20PMT)

Enter the partition (1, 2) in which the key is to be active. Press [∗]

to continue.

ENTER START ZONE

The system displays the lowest zone number of the highest available

consecutive 4-zone group.

To start at a different zone number, enter the zone desired, and press

[∗]. If the system has four consecutive zones beginning with that zone,

the zone number is displayed. If not, the system will again display a

suggested zone that can be used.

If the required number of consecutive zones is not available at all, the

system will display “00”.

Press [∗] to accept.

Continue to the INPUT S/N (serial number/loop number) and XMIT TO

CONFIRM prompts described earlier in the *56 Menu Mode section.

IMPORTANT: When confirmed, the key is not active for

arming/disarming until it is assigned to a user number (using the

assigning attributes command, attribute “4”). See System Operation

section in Installation Instructions.

When done, the keypad beeps three times and the display returns to

the ENTER START ZONE prompt to let you enter the starting zone for

the next wireless key.

To quit this mode and return to *58 Menu mode, enter 00 at this

prompt and press [∗].

Wireless Key Predefined Default Templates

For 5804 Loop Function Zone Type For 5804BD Loop Function Zone Type

TEMPLATE 1 1 No Response 23 TEMPLATE 4 1 No Response 23

2 Disarm 22 2 No Response 23

3 Arm Away 21 3 Arm Away 21

4 No Response 23 4 Disarm 22

TEMPLATE 2 1 No Response 23 TEMPLATE 5 1 No Response 23

2 Disarm 22 2 Arm Stay 20

3 Arm Away 21 3 Arm Away 21

4 Arm Stay 20 4 Disarm 22

TEMPLATE 3 1 24-hour audible 7 TEMPLATE 6 1 24-hour audible 7

2 Disarm 22 2 Arm Stay 20

3 Arm Away 21 3 Arm Away 21

4 Arm Stay 20 4 Disarm 22

∗

∗∗

∗57 FUNCTION KEY PROGRAMMING

(press ∗

∗∗

∗57 while in Data Programming mode) The Function Key Worksheet is on page 29.

The system provides the ability to program each of the four keypad function keys to perform one of 12 system operations. The

end user can then activate the function by simply pressing and holding the programmed key for 2 seconds. Typical functions

(listed below) include single-button arming, turning lights on/off, or single-button paging.

To assign emergency key functions (function key option “00”), first program the respective emergency zone number (95 for

“A” key, 96 for “C” key, 99 for “B” key) with the desired zone type using ∗56 (or ∗58) Zone Programming mode, then use ∗57

Function Key menu mode to assign the desired key.

To use a function key to activate a relay action (∗57 Menu mode key function 07), use ∗79 Menu mode to map the output, and

use ∗80 Menu mode to define the output’s action; select system operation type “66.”

To use a function key for a user macro, use ∗57 menu mode to activate the desired key, then define the actual macro

functions using the user code + [#] + [6] [6] command.

PRESS KEY TO PGM

Press the desired function key to be programmed, A-D, then

press [∗] to continue.

When done, press 0 to exit this mode and return to data field

mode.

NOTE: A key programmed as a function key is no longer

available to be used as an end-user macro key or panic key.

321

654

987

READY

INSTANT

MAX

OFF

CODE

AWAY

TEST

CHECK

STAY

BYPASS

keypad_keys-00-001-V0

PARTITION (VISTA-20PMT)

Enter the partition (1-3) in which this function key will be active.

KEY "A" FUNC

Enter the desired function for this key:

00 = For the Function key selected, the function will be as follows

(default):

If A selected = Zone 95 (emergency key, same as [1] [∗] pair)

If B selected = Zone 99 (emergency key, same as [∗] [#] pair)

If C selected = Zone 96 (emergency key, same as [3] [#] pair)

If D selected = Single-button paging

01 = Single-button paging (sends a 999-9999 message to pager)

02 = Display time

03 = Arm AWAY (reports as User 00 if closing reports are enabled)

04 = Arm STAY (reports as User 00 if closing reports are enabled)

05 = Arm NIGHT-STAY (reports as User 00 if closing reports enabled)

06 = Step Arming (arms STAY, then NIGHT-STAY if enabled, then AWAY)

07 = Output Device Command (for device programmed as system

operation type 66 in *80 Menu Mode)

08 = Communication Test (sends Contact ID code 601)

09 -12= Macro Keys 1-4 respectively (defined by [#] [6] [6] command)

NOTE: Macros 11-12 apply to VISTA-20PMT only

Press [∗] to continue; returns to key number prompt with the next

function key letter displayed.

–17 –

OUTPUT DEVICE PROGRAMMING GENERAL INFORMATION (*79/*80 Menu Mode)

Output Devices: The VISTA-20PMT system supports up to 16 relays and/or Powerline Carrier devices (X-10 devices)

plus 2 built-in trigger outputs in any combination. These 18 “outputs” are assigned to system-wide output

numbers (01-18). Use *79 Menu Mode to assign output numbers and map them to device addresses.

The VISTA-15PMT supports 8 relays and 2 built-in trigger outputs (total 10 outputs).

Output Functions: The system also provides installer-defined output functions, which can be assigned to any of the physical

outputs. Therefore, the action of any one of the outputs can be based on as many of these defined

functions as desired. This lets a single relay or X-10 device perform many functions.

The control supports: V20PMT = up to 48 defined functions; V15PMT = up to 24 functions

Use *80 Menu Mode to define output functions.

WARNING: Relays and output devices are not recommended for life safety applications.

NOTE: When navigating the *79 and *80 menus: The [✱] key is used to accept an entry and advance to the next prompt.

The [#] key is used to revert back to the last question to check or change an entry. Press [✱] to go forward again.

Programming Output Devices

1. Use *79 Menu Mode to assign module and output numbers and map them to device addresses.

NOTE: You must map output devices using *79 Menu Mode before you can use *80 menu Mode.

2. Use *80 Menu Mode to create output definitions, which control the output devices, if desired.

3. Use *81 Zone List Menu mode to define zone lists for use with output devices if the device action is based on more than

one zone.

•To program a device for manual activation (user code + [#] [7] / [#] [8] + 2-digit device number) or for scheduled automatic

activation, simply map the device using *79 Menu mode.

•To program a device to automatically activate upon a system event (or function key), use *79 Menu mode to map the device,

then use *80 Menu mode to define the automated device action.

∗

∗∗

∗79 RELAY/POWERLINE CARRIER DEVICE PROGRAMMING MENU MODE

(press ∗

∗∗

∗79 while in Programming mode) The *79 Device Mapping Worksheet is on page 29.

Use this menu to assign Relay Module device addresses and specific relay numbers, and Powerline Carrier unit numbers. The

system is based on predefined module addresses for 4204 and 4229 modules. Refer to the table shown at the “Module

Address” prompt and set the modules’ addresses (via module DIP switches) accordingly.

The following table shows how these outputs are identified.

Output Identification

This output…is identified by…

Relays the Relay Module’s device address and the relay position on that module (i.e. the physical relay

number, 1-4, on that module).

X-10 Device a house ID (entered in data field *27) and the unit number of the device.

Built-in Outputs the output number assigned, 17 for Trigger 1 and/or 18 for Trigger 2.

ENTER OUTPUT NO.

01-18 = VISTA-20PMT relays/X-10;

01-08, 17, 18 = VISTA-15PMT relays/X-10

[∗] to continue

This is the logical (or reference) relay number as used in the

system. Relays and X-10 devices are numbered 01-16; the on-

board triggers are numbered 17 and 18 and can be programmed

for inverted output, if required.

OUT NORM LOW (appears only for triggers 17/18)

0 = no (standard default); sets the output level normally high

1 = yes; sets the output normally low (can be used for resetting 4-

wire smoke detectors)

[∗] to return to Output Number prompt

Output Trigger 17 can be used for resetting 4-wire smoke

detectors by connecting it to the negative power terminal of the

smoke detector, selecting 1 at this prompt, and setting as zone

type 54, fire zone reset, in *80 Menu mode.

After entry, display returns to Output Number prompt. Use *80

Menu mode to program the function of the trigger.

OUTPUT TYPE

0 = delete; 1 = 4204/4229 relay (skip to “B” prompt); 2 =

Powerline Carrier device (skip to “A” prompt)

[∗] to continue.

“A”(if X-10 was selected)

UNIT No.

Enter the unit code (01-16, set at the device).

[∗] to return to the Output Number prompt continue

“B”(if relay was selected)

MODULE ADDR

Enter the predefined address for this module (07-15; see Table of

Device Addresses).

Make sure the module’s DIP switches are set to the selected address.

[∗] to continue

Module Addresses

Address Module

07 1st 4229 (with zones 09-16)

08 2nd 4229 (with zones 17-24)

09†3rd 4229 (with zones 25-32)

10†4th 4229 (with zones 33-40)

11†5th 4229 (with zones 41-48)

12 1st 4204

13 2nd 4204

14†3rd 4204

15†4th 4204

† These addresses apply to VISTA-20PMT only.

REL POSITION (actual relay number on module)

For 4204 modules, relay numbers are 1-4. For 4229 modules, relay

numbers are 1-2.

[∗] to return to the Output Number prompt for programming the next

device

This is the actual (or physical) relay number with respect to the Relay

Module upon which it is located. For 4204 modules, relay numbers are

1-4. For 4229 modules, relay numbers are 1-2.

The system returns to the Output Number prompt for programming the

next device.

–18 –

∗

∗∗

∗80 OUTPUT FUNCTION MENU MODE

(press ∗

∗∗

∗80 while in Programming mode)

The Output Definition Worksheet is on page 30.

Use this mode to program output function definitions (up to 48 functions) that provide automated control of any of the output

devices, based on events occurring on individual zones or zones with certain zone types. Each output definition is identified

by an output function number, and includes the following components:

Output Definition Components

Component Description

Output Function No. A reference number that defines an output’s characteristics.

Activated By Determines whether the initiating event occurs on a zone, a zone list, or a zone type.

Event Event that triggers the output action. Can be an event occurring on a specific zone number or a

zone list, or a specific zone type.

Partition If the output is activated by zone type, this defines the partition in which the programmed event is

to cause the device action.

Output Action Defines the action of the relay/X-10 device when the defined event occurs. Can close for 2

seconds, stay closed until reset, continuously pulse (1-second close-open-close-open, etc.),

toggle the device state, or activate for a defined duration (set in data field *177).

Output No. Assigns this function to a specific output number (defined in *79 Menu Mode). This is the output

number that will perform this function upon the triggering event. Note that each defined function is

associated with only one output number. This means that if more than one output device needs to

perform this particular function, you need to define another output function number with the same

attributes, but assign the appropriate output number. (i.e. output devices can be assigned more

than one function number, but each function number can only be assigned a single output

number.

For example, if you want to pulse a strobe light upon fire alarms on zone 4 using a relay mapped to output number 2 (as

programmed in *79 Menu Mode), program the following in *80 Menu Mode:

Prompt Entry

Output Funct. # = 01 (assuming this is the first output function)

Activated By: = 3 (zone number)

Enter Zn No. = 04 (requires 2-digit zone numbers)

Output Action = 3 (continuous pulse)

Output Number = 02 (device mapped in *79 Menu Mode)

OUTPUT FUNCT. #

Enter the output function number to be defined

(VISTA-20PMT: 01-48; VISTA-15PMT: 01-24).

[∗] to continue; 00 = exit

SUMMARY SCREEN

01 A E P Trig

?00 0 0 – ZL=00

This screen displays a summary of the current output

programming

A = Output Action; E = Triggering event; P = Partition;

Trig = Trigger type

Question mark indicates the device shown has not been mapped.

Use *79 Menu mode to map the device.

[∗] to continue

ACTIVATED BY

0 = delete (deletes the output function and any previous

programming); a confirmation prompt appears.

To delete this output definition, press 1. If you do not want to

delete this output, press 0.

1 = zone list (go to “A” prompt); 2 = zone type (go to “B” prompt);

3 = zone number (go to “C” prompt)

Press [∗] to continue

Select where the initiating event for this output definition is to

occur

“A”(if zone list was selected)

ZN LIST

Enter the desired zone list number (01-08). At the ENTER

EVENT prompt, enter the zone list event that will activate this

output (0 = restore; 1 = alarm; 2 = fault; 3= trouble)

Press [∗] to continue and skip to the “Output Action” prompt.

NOTE: For alarm, fault, and trouble, an event on ANY zone in the

list activates the output, but ALL zones in the list must be

restored before the output is restored.

“B”(if zone type was selected)

ENTER ZN TYPE

Enter the desired zone type. See list below *80 Worksheet for zone

types.

At the PARTITION prompt, enter the partition in which this zone type

will occur (0 = any partition; 1 = part 1; 2 = part 2; 3 = part 3).

Press [∗] to continue and skip to the “Output Action” prompt.

CHOICES FOR ZONE TYPES:

00 = Not Used 05 = Day/Night 14 = Carbon Monoxide††

01 = Ent/Exit #1 06 = 24 Hr Silent 15 = Medical

02 = Ent/Exit #2 07 = 24 Hr Audible 16 = Fire w/verification

03 = Perimeter 08 = 24 Hr Aux 23 = No Alarm Response

04 = Interior Follower 09 = Fire 24 = Silent Burglary

10 = Interior w/Delay 77 = Keyswitch Zone

12 = Monitor Zone 81 = AAV Monitor Zone

90-91 = Configurable

CHOICES FOR SYSTEM OPERATION:

20 = Arming–Stay 36 = **At Bell Timeout*** 58 = Duress

21 = Arming–Away 38 = Chime 60 = AAV

22 = Disarming 39 = Any Fire Alarm 61 = AVS/GSMV session begin §

31 = End of Exit Time 40 = Bypassing 62 = AVS/GSMV session end §

32 = Start of Entry Time 41 = **AC Power Failure 66 = Function Key†

33 = Any Burglary Alarm 42 = **System Battery Low 67 = Bell Fail

43 = Comm. Failure 68 = Telco Line Cut

52 = Kissoff 78 = Keyswitch Red LED

54 = Fire Zone Reset 79 = Keyswitch Green LED

** Use 0 (Any) for Partition No. (P) entry.

*** Or at Disarming, whichever occurs earlier.

† Use *57 Menu Mode to assign the function key (function “07”).

†† when used with an output function, the carbon monoxide zone type

activates upon CO alarms only. Does not activate for trouble

conditions.

§ automatically set when appropriate AVS Quick Command

performed.

Note: In normal operation mode:

Code + # + 7 + NN Key Entry starts Device NN.

Code + # + 8 + NN Key Entry stops Device NN.

–19 –

“C”(if zone number was selected)

ENTER ZN NO.

Enter the desired zone number, then press [∗] to continue. At the

ENTER EVENT prompt, enter the zone event that will activate

this output (0 = restore; 1 = alarm/fault/trouble).

Press [∗] to continue to the OUTPUT ACTION prompt

OUTPUT ACTION

0 = off

1 = Close for 2 seconds

2 = Close and Stay Closed

3 = Continuous Pulse 1 sec on and 1 sec off

4 = Change Device State; 5 = Duration 1 (see data field *177); 6 =

Duration 2 (see data field *177)

Press [∗] to continue.

Enter the desired device action.

ENTER OUTPUT NO.

Enter the device output number (programmed in *79 Menu Mode)

you want associated with this output.

01-16 = VISTA-20PMT output no.

01-08 = VISTA-15PMT output no.

17-18 = on-board triggers

Press [∗] to continue.

SUMMARY SCREEN

A summary screen appears showing the programmed settings.

Press [∗] to return to OUTPUT FUNCTION NUMBER prompt.

∗

∗∗

∗81 ZONE LIST MENU MODE

(press *81 while in Programming mode)

The Zone List Worksheet is on page 29.

Zone lists let you group individual zones for use with certain system actions. Using this mode, simply select an appropriate

zone list number, then add the desired zone numbers to be included in that list.

The following table shows the available zone lists and their purposes:

List No. Used for…Notes

1, 2 general purpose (GP)

3 chime-by-zone (see field *26 to enable option)

4 cross zones (see note at right)

5 night stay zones

6 dial delay disable

7 unlimited reports

8 general purpose

9 zones that activate Pager 1

10 zones that activate Pager 2

11 zones that activate Pager 3 (VISTA-20P)

12 zones that activate Pager 4 (VISTA-20P)

•Any list may include any or all of the system's zone numbers.

•A zone list can be assigned to more than one output relay.

•Zone List 4: When creating zone list 4 for cross zoning,

include only zones assigned to zone types 3, 4, or 5. Do not

include zones that have delays (entry/exit zones, interior

w/delay) or 24-hour zones, as these zone types may produce

unpredictable operation and may not function as intended.

See field *85 for Cross Zone Timer option.

•Zone List 6: See field *50 for Dial Delay Disable option.

•Zone List 7: See field *93 for Unlimited Reports option.

ZONE LIST NO.

Enter the zone list number (01-12) to program (or 00 to exit this

mode). Press [∗] to continue.

ENTER ZN NUM.

Enter each zone number (01-64†) to add to the zone list, followed

by pressing [∗] (example, 01∗, 02∗, 03∗).

Press 00 to continue.

† VISTA-20PMT = 01-64; VISTA-15PMT = 01-06, 09-34, 49-56.

IMPORTANT: Do not include fire zones in zone lists that are

used to STOP device actions.

DEL ZN LIST?

0 = don’t delete list; current zone list remains saved

1 = delete this zone list; All zones in the zone list will be deleted.

[∗] to continue

DELETE ZONE?

0 = don’t delete zones; save the entire zone list and return to the

Zone List No. prompt

1 = go to next prompt to delete zones

[∗] to continue

ZN TO DELETE?

Enter each zone (01-64†) to be deleted from the list, following

each with [∗].

00 when done to return to the Zone List No. prompt.

† VISTA-20PMT = 01-64; VISTA-15PMT = 01-06, 09-34, 49-56.

–20 –

∗

∗∗

∗82 ALPHA DESCRIPTOR MENU MODE

The system lets you assign zone descriptors for protection zones, keypad panics, and RF receiver supervision faults. Each

description can be composed of a combination of up to 3 words selected from a vocabulary of words stored in memory (see

Alpha Vocabulary List page). In addition, up to 10 installer-defined words can be added to those already in memory, plus 3

additional words can be assigned as partition descriptors. Thus, when an alarm or trouble occurs in a zone, an appropriate

description for that zone's location can be displayed at the keypad. Zone descriptors are recommended for systems using Alpha

display keypads, and are necessary if a 4286VIP Phone Module is used.

NOTE: You can also enter zone descriptors when the zone is being defined in ✱56 Menu mode.

4286 NOTE: If using a 4286VIP Phone Module, select from those words in the Alpha Vocabulary List shown in boldface

type. The phone module will not provide annunciation of the other words.

If a Phone Module is added to an existing system, the Alpha descriptors presently in the system should be reprogrammed,

selecting from those words shown in boldface type in the Alpha Vocabulary List. The phone module will not provide

annunciation of any other words.

PRE-DEFINED DESCRIPTORS

PROGRAM ALPHA

0 = no (quit Alpha mode)

1 = yes

Press [∗] or [#] to continue.

CUSTOM WORDS

0 = no (continue to descriptor programming)

1 = yes (go to custom word programming)

Press 0 to program standard alpha descriptors. The system will

then display the descriptor for zone 1.

To program custom words, press 1 (custom words are described

later).

Press [∗] to continue.

∗

∗∗

∗ZN 01

Descriptor screen for zone 1 appears. To program a descriptor

(up to 3 words) for a zone, do the following:

1. Press [∗] plus the desired zone number (existing descriptor, if

any, is displayed), then press [∗] plus the zone number again

(flashing cursor appears).

2. a. Press [#] plus the 3-digit number from the Alpha Vocabulary

List on page 21 for the first word.

b. Press [6] to accept the word and move the cursor for the

next word.

3. Repeat steps 2a and 2b for the second and third words (if

used).

4. When all words have been entered, press [8] to save the

descriptor for that zone. The flashing cursor disappears.

5. Repeat steps 1-4 to assign a descriptor for the next zone.

6. When all descriptors have been entered, press [∗] + 0 + 0 (or

simply press [#]) after the last descriptor has been saved to

return to the PROGRAM ALPHA? prompt.

Enter 0 (no) at the prompt to exit this mode and return to Data

Field mode.

ADDING CUSTOM WORDS (up to 10 words)

You can add up to 10 installer-defined words to the built-in

vocabulary, which can then be used when programming zone

descriptors. Each of the 10 words can actually consist of a word

string of one or more words, but no more than

ten

characters can be

used for each word or word string.

For custom words, the keys have the following functions:

[4] moves cursor one space to the left.

[6] moves cursor one space to the right.

[8] saves the new word in the system's memory.

1. Select Custom Word mode (enter 1) when the prompt “CUSTOM

WORD ?” is displayed.

2. Enter the number (01–10, or 11, 12, 13 for partition descriptors– see

below) of the custom word or word string to be created,

corresponding to index numbers 245 - 254 respectively. A cursor

appears at the beginning of the second line.

NOTE: Custom words 8, 9, and 10 are “reminder words” that can be

programmed to display using Scheduling Mode.

3. Refer to the Character (ASCII) Chart on the next page.

Press [#], followed by the two-digit entry for the first letter you would

like to display (e.g., # 6 5 for “A”). The cursor moves to the right, in

position for the next character.

To delete a character, simply enter the SPACE character (#32) at

the unwanted character’s location.

4. Repeat Step 3 to create the desired word(s). Each word can be a

maximum of 10 characters (except custom message/partition

descriptor word numbers 11, 12, and 13, which can be a maximum of

16 characters).

5. When the word is complete, press the [8] key to save the custom

word(s) in the vocabulary list and return to the “CUSTOM WORD ?”

display.

6. Repeat Steps 1–5 for other custom words to be entered. To change

a custom word, just overwrite it. When all words have been

programmed, enter 0 at the “CUSTOM WORD ?” prompt to return to

the Program Alpha prompt. Enter 0 again to exit Descriptor mode.

To Assign Partition/Custom Message Descriptors, use Adding

Custom Words procedure, but:

VISTA-15PMT: Use word number 11 in step 2. The custom message

replaces the standard “DISARMED Ready to Arm”

message.

VISTA-20PMT: Use the following word numbers in step 2:

11 = partition 1; 12 = partition 2; 13 = common lobby

This manual suits for next models

Table of contents

Popular Control Unit manuals by other brands

Elpro Technologies

Elpro Technologies 505U-K user manual

Johnson Controls

Johnson Controls Penn System 450 Series installation instructions

XUNZEL

XUNZEL SOLARPOWER-HD Series General installation manual

EMS

EMS FireCell FCZ-170-111 installation guide

Belanger

Belanger Bias-T owner's manual

Tyco

Tyco DV-3HP manual

Pego

Pego VISION TOUCH PAN User and maintenance manual

Genebre

Genebre 2114 10 Installation, operation and maintenance manual

HYTROL

HYTROL E24 3.0 CARD quick start guide

FAAC

FAAC MASTER-T manual

Eaton

Eaton EU1E-SWD Series Instruction leaflet

Ahlborn

Ahlborn ALMEMO 8590-9 operating instructions

D-Link

D-Link T568A Hardware Quick Installation Guide

Ross

Ross DM2E manual

Dover

Dover PSG Quattroflow Q-Control operating manual

Orbinox

Orbinox TK Installation, operation & maintenance manual

AMP EFI

AMP EFI MS3Pro user manual

GEM

GEM eSyLite R629 operating instructions

Monitronics VISTA-15PMT Operating instructions

Popular Control Unit manuals by other brands
