Motorline professional MC61PL Operation and installation manual

v5.1
REV. 08/2019
MC61PL
MC61PL
EN
INSTALLER AND USER’S MANUAL

1A 1B1A 1B
1B
4A
5A
5A
7A
5B
7B
6A
8A
6B
8B
9A
9B
10A
ENEN
00. CONTENT
INDEX
COMPONENTS CONNECTION TO THE CONTROL BOARD
. SAFETY INSTRUCTIONS
TECHNICAL SPECIFICATIONS
. CONTROL BOARD
. CONNECTIONS SCHEME
FUNCTION’S BOARD
PROGRAMMING AUTOMATIC CLOSING
OPENING AND CLOSING COURSE PROGRAMMING
ENABLE/DISABLE STOP
AUTOMATION SENSIBILITY PROGRAMMING
ENABLE/DISABLE CONDOMINIUM FUNCTION
ENABLE/DISABLE SAFETY PHOTOCELLS
INCREASE OR DECREASE DECELERATION
ENABLE/DISABLE FOLLOW ME
. FUNCTIONS
INSTRUCTIONS FOR FINAL CONSUMERS/TECHNICIANS
. TROUBLESHOOTING
PROGRAMMING/ERASE REMOTE CONTROLS
. REMOTE CONTROLS
ATTENTION:
01. SAFETY INSTRUCTIONS
This product is certified in accordance with European
Community (EC) safety standards.
This product complies with Directive 2011/65/EU of the
European Parliament and of the Council, of 8 June 2011, on
the restriction of the use of certain hazardous substances in
electrical and electronic equipment.
(Applicable in countries with recycling systems).
This marking on the product or literature indicates that the
product and electronic accessories (eg. Charger, USB cable,
electronic material, controls, etc.) should not be disposed
of as other household waste at the end of its useful life. To
avoid possible harm to the environment or human health
resulting from the uncontrolled disposal of waste, separate
these items from other types of waste and recycle them
responsibly to promote the sustainable reuse of material
resources. Home users should contact the dealer where they
purchased this product or the National Environment Agency
for details on where and how they can take these items
for environmentally safe recycling. Business users should
contact their vendor and check the terms and conditions
of the purchase agreement. This product and its electronic
accessories should not be mixed with other commercial
waste.
This marking indicates that the product and electronic
accessories (eg. charger, USB cable, electronic material,
controls, etc.) are susceptible to electric shock by direct or
indirect contact with electricity. Be cautious when handling
theproductandobserveallsafetyproceduresinthismanual.

2A2A EN
GENERAL WARNINGS
•This manual contains very important safety and usage information.
very important. Read all instructions carefully before beginning the
installation/usage procedures and keep this manual in a safe place
that it can be consulted whenever necessary.
•This product is intended for use only as described in this manual. Any
other enforcement or operation that is not mentioned is expressly
prohibited, as it may damage the product and put people at risk causing
serious injuries.
•This manual is intended firstly for specialized technicians, and does not
invalidate the user’s responsibility to read the “User Norms” section in
order to ensure the correct functioning of the product.
•The installation and repair of this product may be done by qualified
and specialized technicians, to assure every procedure are carried
out in accordance with applicable rules and norms. Nonprofessional
and inexperienced users are expressly prohibited of taking any action,
unless explicitly requested by specialized technicians to do so.
•Installations must be frequently inspected for unbalance and the
wear signals of the cables, springs, hinges, wheels, supports and other
mechanical assembly parts.
•Donotuse the productifitisnecessary repair oradjustmentisrequired.
•When performing maintenance, cleaning and replacement of parts, the
product must be disconnected from power supply. Also including any
operation that requires opening the product cover.
•The use,cleaning and maintenance ofthisproduct maybe carriedout by
any persons aged eight years old and over and persons whose physical,
sensorial or mental capacities are lower, or by persons without any
knowledge of the product, provided that these are supervision and
instructions given by persons with experienced in terms of usage
of the product in a safe manner and who understands the risks and
dangers involved.
•Children shouldn’t play with the product or opening devices to avoid
the motorized door or gate from being triggered involuntarily.
WARNINGS FOR TECHNICIANS
•Before beginning the installation procedures, make sure that you have
all the devices and materials necessary to complete the installation of
the product.
•You should note your Protection Index (IP) and operating temperature
to ensure that is suitable for the installation site.
•Provide the manual of the product to the user and let them know how
to handle it in an emergency.
•If the automatism is installed on a gate with a pedestrian door, a door
locking mechanism must be installed while the gate is in motion.
•Do not install the product “upside down” or supported by elements do
not support its weight. If necessary, add brackets at strategic points to
ensure the safety of the automatism.
•Do not install the product in explosive site.
•Safety devices must protect the possible crushing, cutting, transport
and danger areas of the motorized door or gate.
•Verify that the elements to be automated (gates, door, windows,
blinds, etc.) are in perfect function, aligned and level. Also verify if the
necessary mechanical stops are in the appropriate places.
•The central must be installed on a safe place of any fluid (rain, moisture,
etc.), dust and pests.
•You must route the various electrical cables through protective tubes,
to protect them against mechanical exertions, essentially on the power
supply cable. Please note that all the cables must enter the central
from the bottom.
•If the automatism is to be installed at a height of more than 2,5m from
the ground or other level of access, the minimum safety and health
requirements for the use of work equipment workers at the work of
Directive 2009/104/CE of European Parliament and of the Council of 16
September 2009.
01. SAFETY INSTRUCTIONS

3A3A EN
•Attach the permanent label for the manual release as close as possible
to the release mechanism.
•Disconnect means, such as a switch or circuit breaker on the electrical
panel, must be provided on the product’s fixed power supply leads in
accordance with the installation rules.
•If the product to be installed requires power supply of 230Vac or
110Vac, ensure that connection is to an electrical panel with ground
connection.
•The product is only powered by low voltage satefy with central (only
at 24V motors)
WARNINGS FOR USERS
•Keep this manual in a safe place to be consulted whenever necessary.
•If the product has contact with fluids without being prepared, it must
immediately disconnect from the power supply to avoid short circuits,
and consult a specialized technician.
•Ensure that technician has provided you the product manual and
informed you how to handle the product in an emergency.
•Ifthesystemrequiresanyrepairormodification,unlocktheautomatism,
turn off the power and do not use it until all safety conditions have
been met.
•In the event of tripping of circuits breakers of fuse failure, locate
the malfunction and solve it before resetting the circuit breaker or
replacing the fuse. If the malfunction is not repairable by consult this
manual, contact a technician.
•Keep the operation area of the motorized gate free while the gate in in
motion, and do not create strength to the gate movement.
•Do not perform any operation on mechanical elements or hinges if the
product is in motion.
RESPONSABILITY
•Supplier disclaims any liability if:
•Product failure or deformation result from improper installation
use or maintenance!
•Safety norms are not followed in the installation, use and
maintenance of the product.
•Instructions in this manual are not followed.
•Damaged is caused by unauthorized modifications
•In these cases, the warranty is voided.
01. SAFETY INSTRUCTIONS
SYMBOLS LEGEND:
• Important safety
notices
• Useful information
• Programming
information
• Potentiometer
information
• Connectors
information
• Buttons
information

4A4A
M1 M2 FLH FC 24v
24v
RGB
R
G
B
GND
GND
DV COM NC12/24V
~ ~
DV 12/24V
~ ~
24AC
+ BAT - MOT + LED - V+ SEN PUL BL DS
ANT
GND GND GND
230VAC
LIGHT
VR1
+-
SEL SET
MONO TEMP. I.CMD
12V24V 0V
24AC
+ BAT - MOT + LED -
V+ SEN PUL
BL DS
GND GND
GND
EN
. CONNECTIONS SCHEME
COMPONENTS CONNECTION TO THE CONTROL BOARD
Automatic bollard
LED tape
The use of photocells or magnetic coil is
essential to ensure the safety in the use of
automation.
Photocells
MSC
Battery V
Module
Red
Yellow
Green
Black
Red
Yellow
Green
Black
The MSC is a
crespuscular sensor, the
input when it is active, the
leds of the Pylon will work.
When it is flush with the
sensor, the LEDs do not
work during the day and
work at night.
If you wish, that the LEDs
are always working, simply
make a shunt between the
connector  and  of the
Control Panel as shown in
the image on the left.

5A 5B
CMD
SET
SEL
8s
CMD
SET
SEL
CMD
SET
SEL
1s
5A 5B
ENEN
The control board MC has the capacity to memorize  remote controls (Rolling Code).
• Programming
 • Press the CMD button 
second and the display point
turns on.
 • Press a button of your choice from the remote control
to program and the display point will flash twice. Remote
control will be memorized after  seconds.
. CONTROL BOARD
TECHNICAL SPECIFICATIONS
. REMOTE CONTROLS
. REMOTE CONTROLS
PROGRAMMING/ERASE REMOTE CONTROLS
PROGRAMMING/ERASE REMOTE CONTROLS
• Power supply 24Vdc AC/DC
• Battery output 24Vdc - 7AH máx.
• Lamp output 24Vac - 3W máx.
• Motor output 24Vdc -100W máx.
• Lock output 12Vdc - 10W máx.
• Auxiliary accessories output 24Vdc - 3W máx.
• Working temperature -10°C a +55°C
• Incorporated Radio Receiver 433,92 Mhz
• Accepted codestype Rolling Code
• Central dimensions 99x104,5 mm
• Fuse 8A
• Erase remote controls
Press CMD for  seconds (during this
time the LED display point will stay
ON). After this time, LED display point
will flash twice and all codes have
been deleted from memory.
FUNCTION’S BOARD
. FUNCTIONS
The control board MCPL has a menu that allows access to all automatic configurations.
MENU FUNCTION MÁX. MIN.
PROGRAMABLE STATE FACTORY VALUE PAGE
Automation sensibility
programming 56A
Opening and closing course
programming
Opening indicator
Closing indicator
6B
Enable/disable photocells Disable
Enable
0 7A
Programming automatic closing Disable 0 7B
Enable/disable condominium
function
Disable
Enable
0 8A
Enable/disable STOP Disable
Enable
1 8B
Increase or decrease
deceleration Disable 29A
Enable/disable Follow Me Disable
Enable
09B
min. max.
91
min. max.
min. max.
10s
1s
90s
4s

6A 6B
CMD
SET
SEL
5s
CMD
SET
SEL
CMD
SET
SEL
CMD
SET
SEL
CMD
SET
SEL
CMD
SET
SEL
CMD
SET
SEL
5s
6A 6B
ENEN
 • Press the SEL and SET
buttons simultaneously
for  sec. to access the
programming menu.
When you start the opening display shows U.
When you start the closing display shows d.
Opening indicator Closing indicator
 • The display will show F.
Press the SEL button as
many times as necessary
until the display shows P.
 • Press the SET button to
start the course recognition.
During the course recognition, display shows P.
To make the opening and closing course programmation, the mechanical limit switches
must always be in tune.
º Unlock the motor;
º Manually, put the gate in closing position and adjust the closing limit switch;
º Manually, put the gate at the opening position you want and adjust the opening limit
switch.
. FUNCTIONS
OPENING AND CLOSING COURSE PROGRAMMING
 • Press the SEL and SET
buttons simultaneously
for  sec. to access the
programming menu.
 • Press the SET button
once to save this option.
 • The display will show F.
Press SET button to access
the submenu.
 • The display will show
Fand the configuration is
successfully done.
 • The display will show
a value between  and ,
indicating the currently
configured level. Use SEL
button to choose desired
option.
 • To exit the programming
mode wait  sec. until (–)
appears.
This menu allows to set the level of sensibility that you want in the motor operation.
Maximum sensibility - 1 | Minimum sensibility - 9
AUTOMATION SENSIBILITY PROGRAMMING
. FUNCTIONS
 • If the door is open, it will close until it reaches the closing limit switch.
 • It will open slowly for  seconds to detect the force during deceleration.
 • It will close slowly to detect the force during deceleration.
 • It will open at normal speed until it reaches the opening limit switch.
 • It will close immediately, stopping only when it reaches the closing limit switch.
 • Programming completed.

7A 7B7A 7B
CMD
SET
SEL
5s
CMD
SET
SEL
CMD
SET
SEL
CMD
SET
SEL
CMD
SET
SEL
5s
CMD
SET
SEL
CMD
SET
SEL
CMD
SET
SEL
ENEN
Option  disables the automatic closing, and the gate will close only if it receives an order
from a configured device.
Any option between  and , multiplied by , sets the automatic closing time, the minimum
is  seconds (number ) and the maximum is  seconds (number ).
 • Press the SEL and SET
buttons simultaneously
for  sec. to access the
programming menu.
 • Use the SEL button to put
on the desired option. Press
the SET button once to save
this option.
 • The display will show F.
Press the SEL button as
many times as necessary
until the display shows A.
 • Press the SET button to
access the submenu.
 • The display will show A
and the configuration was
successful.
 • To exit the programming
mode wait  sec. until (–)
appears.
. FUNCTIONS
PROGRAMMING AUTOMATIC CLOSING
When photocells enabled, if any obstacle interrupt them (if the door is closing), the door will
reverse the direction.
0 - Disable | 1 - Enable
 • Press the SEL and SET
buttons simultaneously
for  sec. to access the
programming menu.
 • The display will show 
(disabled),  (enable). Use
the SEL key to select the
desired option and press
SET to confirm.
 • The display will show F.
Press the SEL button as
many times as necessary
until the display shows C.
 • The display shows C
and the configuration is
successful.
 • Press the SET button to
access the submenu.
 • To exit the programming
mode wait  sec. until (–)
appears.
ENABLE/DISABLE SAFETY PHOTOCELLS
. FUNCTIONS

8A 8B8A 8B
CMD
SET
SEL
5s
CMD
SET
SEL
CMD
SET
SEL
CMD
SET
SEL
CMD
SET
SEL
5s
CMD
SET
SEL
CMD
SET
SEL
CMD
SET
SEL
ENEN
• When this function is activated, the control board will only work if STOP contact is closed. If
the barrier is open, the control board reject any opening or closing order.
0 - Disable | 1 - Enable
 • Press the SEL and SET
buttons simultaneously
for  sec. to access the
programming menu.
 • The display will show the
value  or , which identifies
the option in which the
control board is currently
configured. Use the SEL
button to put on the desired
option. Press the SET button
once to save this option.
 • The display will show F.
Press the SEL button as
many times as necessary
until the display shows E.
 • The display will show E
and the configuration was
successful.
 • Press the SET button to
access the submenu.
 • To exit the programming
mode wait  sec. until (–)
appears.
For this function, you must have installed a safety device N.C at the barrier.
. FUNCTIONS
ENABLE/DISABLE STOP
0-Disabled
• If you send an order to the gate completely open, it will close.
• If pressing during the closure, the gate reverses direction (it will open).
When disabled, you can control the opening or closing of the gate whenever you want, and their
behavior is: open-stop-close-stop-open-stop - (...) for each time you press a remote control key.
1 - Enabled
• This function makes the control board ignore all the orders sent by configured devices during the
course of opening and during the pause time.
• Pressing the remote control during the opening, the order is declined and the gate continues to open.
• When activated the condominium function is activated the closing time in  seconds.
 • Press the SEL and SET
buttons simultaneously
for  sec. to access the
programming menu.
 • The display will show the
value  or , which identifies
the option in which the
control board is currently
configured. Use the SEL
button to put on the desired
option. Press the SET button
once to save this option.
 • The display will show F.
Press the SEL button as
many times as necessary
until the display shows L.
 • The display will show L
and the configuration was
successful.
 • Press the SET button to
access the submenu.
 • To exit the programming
mode wait  sec. until (–)
appears.
ENABLE/DISABLE CONDOMINIUM FUNCTION
. FUNCTIONS

9A 9B9A 9B
CMD
SET
SEL
5s
CMD
SET
SEL
CMD
SET
SEL
CMD
SET
SEL
CMD
SET
SEL
5s
CMD
SET
SEL
CMD
SET
SEL
CMD
SET
SEL
ENEN
With the “Follow Me” function activated, whenever the photocells detect the passage of a
user/obstacle, the control board triggers the closing maneuver  seconds later.
0 - Disable | 1 - Enable
 • Press the SEL and SET
buttons simultaneously
for  sec. to access the
programming menu.
 • The display will show the
value  or , which identifies
the option in which the
control board is currently
configured. Use the SEL
button to put on the desired
option. Press SET to save the
option.
 • The display will show F.
Press the SEL button as
many times as necessary
until the display shows b.
 • The display will show b
and the configuration was
successful.
 • Press the SET button to
access the submenu.
 • To exit the programming
mode wait  sec. until (–)
appears.
ENABLE/DISABLE FOLLOW ME
. FUNCTIONS
The deceleration reduce the motor speed in the final part of the course (opening or closing).
Without deceleration - select the value 0
Minimum deceleration – 1 second
Maximum deceleration – 9 seconds
 • Press the SEL and SET
buttons simultaneously
for  sec. to access the
programming menu.
 • The display will show the
value  or . Use the SEL
button to put on the desired
option. Press the SET button
once to save this option.
 • The display will show F.
Press the SEL button as
many times as necessary
until the display shows H.
 • The display will show H
and the configuration was
successful.
 • Press the SET button to
access the submenu.
 • To exit the programming
mode wait  sec. until (–)
appears.
INCREASE OR DECREASE DECELERATION
. FUNCTIONS

10A10A EN
. TROUBLESHOOTING
INSTRUCTIONS FOR FINAL CONSUMERS/TECHNICIANS
Anomaly Procedure Behavior Procedure II Discovering the origin of the problem
• Automatic
bollard
doesn't work
• Make sure you
have 230V power
supply connected to
automation and if
the fusible working
properly.
• Still not working • Consult a qualified
technician.
1• Open the control board box;
2• Measure the V output of the transformer to detect the fault location;
A) Has 24V:
1• Verify the control board supplies of the motor to detect if the fault is in the motor or in the control board. Replace the damaged component or send it
to the services for diagnosis and repair.
B) Has not 24V:
1• Verify the 230V input of the transformer. If have 230V the problem is in the transformer. If haven't 230V, the problem should be in the fusible, electric
cables or in the power supply. Verify all the systems.
• Check that the
safety features are
activated. • Still not working • Consult a qualified
technician. • In the E menu, make sure the stop function is enabled (page A). If enabled and the circuit is not closed, the automatic bollard will not work.
• Automatic
bollard
doesn’t move
but makes
noise
• Unlock the
automatic bollard
and move by hand to
check for mechanical
problems.
• Automatic bollard
is stuck? • Consult a qualified technician. • Unlock the automatic bollard and move by hand to check if the movement is normal.
• Automatic bollard
moves easily? • Consult a qualified technician.
• Turn off the motor from control board and test it on directly to a V battery to find out if it is damaged;
• If the motor runs, the problem is in the control board. Remove it and send it to the technical services for diagnosis;
• If the motor does not work, remove it and send to the technical services for diagnosis.
• Automatic
bollard
opens but
doesn’t
close
1 • Check if there is any
obstacle in front of the
photocells;
2 • Make sure if the
photocells are
working. Put your hand
in front and check that
the relay makes the
same noise.
3 • Check if any of the
control devices (key
selector, push button,
video intercom, etc.) of
the automatic bollard
are jammed and
sending permanent
signal to control unit;
• Automatic bollard
opened but didn’t
close again.
• Consult a qualified
technician.
• Verify if the display is connected to confirm the existence of power supply;
• Verify if the photocells are powered in control board output;
• Access the menu on the display and disable the photocells and the stop function;
• Try to close;
A) Closed:
• Problem is in one of these two systems. Activate the photocells and check that the automatic bollard closes. If close, problem will be in stop
function. Ative tin the menu and try to close the automatic bollard to be sure.
B) Doesn't closed:
• Problem is in the motor or in the control board. Give an order to the automatic bollard close while measuring the control board power output to
the motor. If you have V, the control board is working and the problem is in the motor.
• If it has not current, the problem is in the control board.
• Automatic
bollard
doesn’t make
complete
route
• Unlock the
automatic bollard
and move by hand to
check for mechanical
problems.
• Encountered
problems? • Consult a qualified technician. • Unlock the automatic bollard and move by hand to check if the movement is normal.
• Automatic bollard
moves easily? • Consult a qualified technician.
• Verify if the tests to the automatic bollard were well made;
• Change the strength of F menu until the motor move the automatic bollard without changing the direction;
• This adjustment should be made to in case the automatic bollard find an obstacle do an inversion;
• If even at maximum power level (F) is still the problem, test the motor directly connected to a V battery to see if it has the power to open/close
the automatic bollard completely;
• Change the strength in the F menu until the motor move the automatic bollard without changing the direction;
