Monster SmartView 300S User manual

SmartView
™
300S
Swivel Mount
Support pivotant
SmartView
™
300S
Base pivotante
SmartView
™
300S

USER GUIDE & WARRANTY
GUIDE ET GARANTIE D’UTILISATEUR
GUÍA DEL USUARIO Y GARANTÍA

A NOTE FROM THE HEAD MONSTER
Dear Enthusiast,
THANK YOU
for purchasing the
Monster SmartView 300S FlatScreen
Mount. The SmartView 300S refl ects
our passion for creating the most
innovative and practical AV solutions
on the market, so enthusiasts like
yourself always experience the
absolute best from their
high-performance AV components. Monster FlatScreen
Mounts deliver the clean, sophisticated style you want,
plus exclusive adjustment features for the perfect view
in virtually any room. Start enjoying TV on your
terms—when, where and how you want to watch.
Noel Lee,
The Head Monster

More Great Products
from Monster FlatScreen
™
The Look You Want. The Performance You Need.
Monster FlatScreen Cables
™
Ultra slim and fl exible, Monster FlatScreen
Cables ensure a clean, no-clutter hookup to
your thin display. Plus, they feature advanced
Monster Cable technologies, so you always get
the best possible picture and sound.
Monster FlatScreen PowerProtect
™
and PowerCenters
™
Safeguard your fl atscreen investment
from harmful electrical surges and
“dirty” AC power with exclusive Monster
Power
®
technologies, including Monster
® technologies, including Monster ®
SurgeGuard
™
and Monster
Clean Power
.
™
Monster FlatScreen Clean
™
Our safe LCD and plasma cleaning solution
instantly removes dust, dirt and fi ngerprints
from your fl atscreen without drips, stains
or scratches.
For more details on all our Monster FlatScreen products,
visit us at
MonsterCable.com/FlatScreen
Monster Cable technologies, so you always get
the best possible picture and sound.
Monster FlatScreen Clean
Our safe LCD and plasma cleaning solution

1
SmartView 300S FlatScreen Mount
SmartView 300S is designed to mount
10"
to
24"
fl atscreen televisions to vertical walls. Maximum weight
capacity is
40 lbs.
SAFETY WARNING:
If you don’t understand these
directions, or have doubts about this product’s installation,
please call a qualifi ed contractor or contact Monster Cable
Products, Inc. at
1-877-800-8989.
Before installing, carefully review the instructions to
ensure that no parts are missing or defective. Improper
installation can cause damage or serious injury. Do not
use this product for any purpose not explicitly specifi ed
by Monster or the manufacturer. Neither Monster nor the
manufacturer can be liable for damage or injury caused by
incorrect assembly, incorrect mounting or incorrect use.
All hardware is supplied for the following wall conditions:
Wood stud, brick, solid concrete and concrete block.
Note:
The supplied hardware
is not for steel stud walls.
If you are uncertain about the nature of your wall
construction, consult an installation contractor.



2
Specifi cations and Notes:



 




Monster is constantly striving to improve its products.
Specifi cations are subject to change without notice.

3
Required Tools
Wall Stud Mounting:
Electronic stud sensor
Level
Electric hand drill
3/16" drill bit
Phillips screwdriver
Combination wrenches or socket set
Masonry Mounting
(brick, solid concrete, concrete blocks):
Above tools
Replace 3/16" drill bit with 1/2" masonry drill bit
•
•
•
•
•
•
•
•

4
Package Contents
1 LCD Mounting Plate
(VESA
™
(VESA™ (VESA
75/100-Compliant)
Screws
4 ea. M4x15
4 ea. M5x15
Bubble Level
2 Round
Washers
2 Lag Bolts
2 Masonry
Anchors
1 Wall Mounting Plate
Allen Wrench
If any parts are missing, please call 800-877-8989.

5
Warnings
Forbidden Actions:
Do not install on a sloping surface. Install
exclusively on a vertical surface.
Do not mount to cabinetry made of particleboard.
Do not install in a room with excessively high
temperatures or high humidity. Install at least
3 ft. from all water sources.
Do not install near an air conditioner.
Do not install in a location where there is excessive
dust, smoke or moisture. These sources can create
a fi re.
Never apply unnecessary stress or load on the
installed unit. Never hang on unit.
Do not install unit alone. Safe installation requires
at least two people.
Do not route your fl atscreen TV’s power cord
in wall. Check local building/electrical codes for
more information.

6
Cautions
To prevent eye fatigue, do not install where
there is direct sunlight or excessive light.
When carrying out maintenance, disconnect
the TV’s power supply to avoid electrical shock.
If planning to route AV cable in wall, only use
cable UL-certifi ed for this use.
