MOOKA CTO5OP116W User manual

www.mooka.co/warranty
facebook.com/mookaofficial
Beyond Elegance
SOUS-VIDE CIRCULATOR-CTO5OP116W

NOTE
1.Use as per instruction manual.
2.Do not touch hot surfaces.
3.Keep out of reach of children.
Register within 2 weeks after receiving your new product.
www.mooka.co/warranty
PLEASE VISIT NOW
CUSTOMER SERVICE
[email protected] @mookaofficial
ACTIVATE YOUR 12 MONTH WARRANTY
& GET EXCLUSIVE GIFT

A Big Thank You
We’re thrilled that you have chosen to purchase the Sous Vide
Circulator. At Mooka, we’re committed to providing you with
products that enhance your daily life. We also aim to give our
customers excellent support. Should you have any questions or
feedback about your new product, simply get in touch with our
customer support team at 1-855-558-8999, or by email at
[email protected].
Enjoy your new product!

CONTENTS
Product Overview
Operation Warning
How to Use Your Sous-vide Circulator
Sous-vide Time and Temperature Guide
Prepare Your Food
Setup (clamp & pot)
Setup (temp/timer)
Maintenance
Cleaning
Technical Specifications
Recycling
Troubleshooting FAQ
01
02
05
05
06
07
08
09
10
11
12
13

PRODUCT OVERVIEW:
- 01 -
@mookaofficial [email protected]
Control Interface
Clamp
Temperature
time selection
Working illuminator
ON/OFF buttons
“+”and”-”
adjustment buttons

OPERATION WARNING
This section explains the potential dangers that may arise when
operating the sous-vide circulator and notes many important safety
precautions.
1. Before plugging into a socket, check whether your voltage
corresponds to the rating label of the appliance.
2. Counter tops such as marble and corian cannot withstand the heat
generated by the circulator. Do not place the cooking container on
marble or corian surfaces to prevent damage.
3. Do not use extension cords. Never operate with a damaged cord or
plug and use properly grounded electrical outlets only.
4. Do not immerse the device past the top etch mark on the stainless
steel skirt. Only the stainless steel skirt and the pump housing are
dishwasher safe. Unplug from the outlet when not in use and before
the cleaning process.
5. Burn Hazard. The cooking container, stainless steel portion of the
circulator, and food pouches all get hot when used. Use oven mitts
or tongs when handling. Allow the device to cool before emptying
the water bath.
6. Do not disassemble. Observe all warning labels. Do not remove
warning labels.
7. Do not use this appliance for anything other than its intended use
(Like laboratory work or heating a hot tub).
8. Firmly lock the product by clamping it on the side of your container.
Place the container on an even surface to prevent spills and tipping
over. Do not place unit on a stove, or in an oven.
- 02 -
@mookaofficial [email protected]

@mookaofficial [email protected]
9. Do not use de-ionized water (DI water).
10. Do not let children use and play with this appliance. Keep the
appliance and its cord out of reach of children.
11. Never use a damaged appliance. If it has been damaged, please
contact the seller for advice.
12. If the supply cord is damaged, it must be replaced by the
manufacturer, its service agent or a similarly qualified person in
order to avoid a hazard.
13. Don’t let excess power cord hang over the edge of the table or
worktop, or allow it to touch hot surfaces.
14. Switch off the appliance and disconnect from the power supply
before changing accessories or touching moving parts.
15. When the appliance operates under abnormal power distribution, it
may lose performance and the appliance may need to be
unplugged to operate normally again.
16. This appliance can be used by children aged 8 years and above if
they have been given supervision or instruction concerning use of
the appliance in a safe way and if they understand the hazards
involved. Cleaning and user maintenance shall not be made by
children unless they are older than 8 and supervised by an adult.
Keep the appliance and its cord out of reach of children aged
younger than 8.
Appliance can be used by persons with reduced physical, sensory,
or mental capacities, or lack of experience and knowledge if they
have been given supervision or instruction concerning use of the
appliance in a safe way and if they understand the hazards involved.
- 03 -

@mookaofficial [email protected]
17. This appliance is intended to be used in household and similar
applications such as:
- Staff kitchen areas in shops, offices, farm houses and other
working environments.
- By clients in hotels, motels and other residential type
environments.
18. If the appliance falls down into water tank, firstly unplug it, then
remove it from the tank. Wipe the water on the appliance’s surface
and place it in a ventilated place to dry completely.
Sous-vide circulators are designed to be used with water only.
- 04 -

@mookaofficial [email protected]
Before first use, remove any stickers or similar items from the
appliance, except for the warning label.
- 05 -
HOW TO USE YOUR SOUS-VIDE CIRCULATOR
Sous-vide Time and Temperature Guide
FOOD TEMPERATURE (℉) TIMING RANGE (min)
Beefsteak Medium-rare 58°C/136°F 1.5 to 3 hours
Roast beef Medium-rare 60°C/140°F 6 to 14 hours
Lamb shank 75°C/167°F 24 hours
Chicken breast 65°C/149°F 1 to 2 hours
Chicken (Bone in) 75°C/167°F 1.5 to 3 hours
Pork chop Medium-rare 62°C/144°F 1 to 1.45 hours
Fish 50°C/122°F 40 minutes to 1 hour
Salmon 46°C/115°F 45 minutes
Potato Whole (Tender) 85°C/185°F 1.5 to 3 hours
Vegetables( Green) 85°C/185°F 5 to 20 minutes
Egg (Poached in shell) 65°C/149°F 1to 2 hours

@mookaofficial [email protected]
Prepare your food and seasoning and place in a vacuum-sealed bag.
Alternatively zip-lock freezer bags can be used. It is important to use
freezer bags made of food-grade plastic, as the seal on thinner bags
(e.g. sandwich bags) can and will degrade and break down during long
cooking times.
To expel air from your plastic bag use the immersion method:
1. Simply add the food to the bag with your seasoning.
2. Leave the mouth of the bag open then carefully immerse the bag into
the water, leaving about 2-3 cm above the water.
3. Seal it while it is in the water. The pressure from the water
surrounding the bag is heavier than the air inside the bag, which
causes the air to be pushed up and out of the bag.
PREPARE YOUR FOOD
- 06 -

@mookaofficial [email protected]
The sous-vide circulator requires a 4-15L
container or pot. Make sure
the container or pot capacity meets this
requirement.
Firmly lock the appliance by clamping it
on the side of your container.
SETUP (CLAMP & POT)
- 07 -

1.Plug the appliance into a power outlet. The “ ” icon and operating
lamp will be on and it will enter the standby mode. Press the “ ”
icon to enter the settings mode. You will hear a beep sound each
time it is pressed.
2. Setting the temperature: Press the “+” or “–“adjust button to set the
temperature.
4. Press the “ ” icon to confirm the setting and the unit will operate.
If you want to change the settings, press and hold the “ ” icon for
3 seconds, then repeat the steps as instructed above.
The unit will stop automatically when the timer has run down, and an
“END” icon will be displayed on the screen.
5. During heating up, the control interface will display the current
temperature.
After the timer has been set and the desired temperature reached,
the control interface will display a countdown timer. You can press
the “+” or “–” button to check the current temperature; it will revert
back to show the countdown timer after 10 minutes.
6. Press and hold the “ ” icon for 3 seconds to stop the device
3. Setting the timer. Press the “ ” icon
to set the time. You will see that the
timer blinks.
First, press the + or – adjust button to
set hour, then press “ ” again to set
the minute.
The timer will start its countdown when
the set temperature is reached.
- 08 -
@mookaofficial [email protected]
SETUP (TEMP/TIMER)

• Always turn off and unplug the unit after using it.
• Maintenance of the appliance must be performed by certified
personnel only.
• Use the appliance at room temperature.
Check for signs of damage including pulled cord or physical damage to
appliance or its heater. If any signs of physical damage are found,
please contact the seller for further advice.
@mookaofficial [email protected]
MAINTENANCE
- 09 -

It is recommended to clean the appliance after each use. However,
never use rough scouring pads or abrasive cleansers on any plastic or
metal parts as the surface may be damaged.
• Use a damp cloth to clean the heating coil, pump shaft and sensors.
• Do not rinse the top part of the circulatory, including the main body, in
water.
After long-time use, some limescale may be present on the
heating element and housing. To remove the limescale, it is
suggested to clean with mixture of vinegar and water.
Caution: rinse quickly and thoroughly with water if vinegar
comes into contact with eyes. If the eye is red, painful or
sensitive to light, seek medical advice.
@mookaofficial [email protected]
-10 -
CLEANING
Cleaning the circulatory
To clean the stainless-steel skirt and pump cover,place in the
dishwasher or wash in the sink with detergent.
Cleaning the skirt

When not in use, store the appliance, its accessories and the
instruction manual in a safe, dry place.
@mookaofficial [email protected]
- 11 -
STORE IN A SAFE PLACE
TECHNICAL SPECIFICATIONS
Operating voltage 120V, 60HZ
Model/model number CTO5OP116W8
Power consumption 1000W
Temperature range 0°F-195 °F
Temperature stability ± 1°F
Circulation pump >8 LMP
Timer Up to 99 hours
Required tank capacity 4-15L
Water ingress rating IPX7
MADE IN CHINA

Do not dispose of the device with normal domestic waste
Dispose of the device via a registered waste disposal firm or through
your communal waste disposal facility. Observe the current regulations
of disposing of electrical appliances. In case of doubt, consult your
local waste disposal facility.
@mookaofficial [email protected]
RECYCLING
- 12 -

@mookaofficial [email protected]
TROUBLE SHOOTING FAQ
- 13 -
PROBLEM POSSIBLE CAUSES SOLUTIONS
System will not turn on The power plug is not
available
Check power plug and
circuit breakers.
Try another power plug.
Return unit to
manufacturer for repair
if this does not solve it.
Low water level alarm/
Low water level alarm
turns on after a few seconds
of operation
The water level can
drop during operation
over along period due
to water turbulence
and heat.
Add more water. The
pump generates “waves”
– sometimes these
waves will cause the
water level at the sensors
to fluctuate up and down.
The waves sometimes
drop the water level right
under the sensor and will
cause a low water alarm.
This is normal and you
just need to add more
water.
Food damage ：The pump’s water jet
is cracking eggs or
damaging fish fillets
Turn the pump outlet to
face the container wall;
this will greatly temper
the flow of the pump
output. It is also good
practice to bag eggs to
prevent them from being
“blown” around in certain
containers.
Temperature read does not
match thermometer：
Sous Vide circulators
are calibrated to a
scientific platinum
primary standard which
is far more accurate
than store
thermometers.
This the normal.

- 14 -
@mookaofficial [email protected]
PROBLEM POSSIBLE CAUSES SOLUTIONS
Slurping noise Your pump has formed
a water vortex.
Add more water or
gently disturb the water
with a spoon. There is
no sure way to eliminate
a vortex from forming
due to the pump
rotation, but it will usually
go away on its own.
Gurgling + Woosh noise ：The pump is sucking air Add more water. You
should also see small
bubbles in your tank.
Lights in house are slightly
flickering when system is on
This is normal as the
circulator is modulating
power.
Needn’t do anything
Error code EE1 will be
appeared in below situation
with alarm sound
No water in tank / Water
below minimum level
Appliance in situation
of short circuit
Add enough water.
If short circuit is occurred,
please contact seller
for help.
