Motion CM-16 User manual

MANUAL CM-16
Wall remote 4 channel
English

CM-16 is a wall remote with 4 channels for operating blinds
with the press of a button. Blinds can be moved to any desired
position or to a preset favorite position.The remote control can
be used separately from the wall plate as a hand or table remote.
Its clean shape and matte black color perfectly fit the interior of
contemporary homes and buildings.
Safety
WARNING: Important safety
instructions. Follow all instructions,
since incorrect installation can lead
to severe injury.
Do not let children play with the
blind and/or remote control.
Take care that the blind can move
freely and is not blocked by any
objects.
Do not paint the device.
Keep the device dry.
Do not drop, knock, or shake the
device. Rough handling can break
internal circuit boards.
Do not ingest battery, Chemical
Burn Hazard" or equivalent
wording
This product contains a coin /
button cell battery. If the coin /
button cell battery is swallowed, it
can cause severe internal burns in
just 2 hours and can lead to death.
Keep new and used batteries
away from children.If the battery
compartment does not close
securely, stop using the product
and keep it away from children.
If you think batteries might
have been swallowed or placed
inside any part of the body, seek
immediate medical attention.
Replacement of a battery with an
incorrect type that can defeat a
safeguard.
Disposal of a battery into fire or a
hot oven, or mechanically crushing
or cutting of a battery, that can
result in an explosion.
Leaving a battery in an extremely
high temperature surrounding
environment that can result in
an explosion or the leakage of
flammable liquid or gas.
A battery subjected to extremely
low air pressure that may result
in an explosion or the leakage of
flammable liquid or gas.
For the latest information and updated manuals, visit rtube.nl/cm-16
Channels Max.
blinds
Frequency Range Frequency
emission
power
Power
supply
4Unlimited 433.925 MHz
30 m with
1 concrete
wall
≤2.32dBm 3 x CR2430
3.0V
Length Width Height Working
temperature
Certificates
86 mm 17 mm 17 mm -10°C~50°C

FCC Manual I FCC ID: ZY4CM16
Regulatory Information
1 FCC Information for User
This product does not contain any user-
serviceable components and is to be used with
approved antennas only. Any product changes
or modifications will invalidate all applicable
regulatory certifications and approvals.
2 FCC Electronic Emission Notices
This device complies with part 15 of the FCC
Rules.
Operation is subject to the following two condi-
tions:
1. This device may not cause harmful interfer-
ence
2. This device must accept any interference
received, including interference that may
cause undesired operation.
3 FCC Radio Frequency Interference
Statement
This equipment has been tested and found
to comply with the limits for a class B digital
device, pursuant to Part 15 of the FCC Rules.
These limits are designed to provide reasonable
protection against harmful interference when
the equipment is operated in a commercial
environment. This equipment generates, uses
and can radiate radio-frequency energy and, if
not installed and used in accordance with the
instructions, may cause harmful interference to
radio communications.
Operation of this equipment in a residential
area may cause harmful interference, in which
case the user will be required to correct the
interference at their own expense.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is encouraged to
try to correct the interference by one or more of
the following measures:
Reorient or relocate the receiving antenna
Increase the distance separating the
equipment and receiver
Connect the equipment to an outlet on a circuit
different from that to which the receiver is
connected
Consult the dealer or an experienced radio/TV
technician for help
Cleaning
Follow these general rules when
cleaning the outside of the device
and its components:
Use a damp, soft, lint-free
cloth. Avoid getting moisture in
openings.
Do not use aerosol sprays,
solvents, alcohol, or abrasives.
Service & Support
Do not perform repairs yourself.
Do not attempt to open the device
or disassemble it. You run the
risk of electric shock and voiding
the limited warranty. No user-
serviceable parts are inside.
Warranty Service
First follow the advice in this
manual. If the product appears to
be damaged or does not function
properly, go to your local dealer
for instructions on how to obtain
warranty service.
Recycle
This marking indicates
that this product should
not be disposed with
other household wastes throughout
the EU. To prevent possible harm to
the environment or human health
from uncontrolled waste disposal,
recycle it responsibly to promote
the sustainable reuse of material
resources. To return your used device,
please use the return and collec-tion
systems or contact the retailer where
the product was purchased. They can
take this product for environmental
safe recycling.
EU Declaration
Hereby, Coulisse declares that
the radio equipment type CM-16
is in compliance whith directive
2014/53/EU. The full text of the
EU declaration of conformity is
available at the following internet
address: www.my.coulisse.com

1Buttons The center button has two functions: press to stop the blind, hold to
move the blind to its favorite position.
1. BUTTONS 1. BUTTONS
Down
Up
Center
(stop/favorite)
Pair
Button

1
2
3
+
-
CR2450 3,0V
2
1
Changing the battery
2. CHANGING THE BATTERY 2. CHANGING THE BATTERY

3
3.3
3.1
3.2
3. PAIR A REMOTE 3. PAIR A REMOTE
Pair a remote Repeat steps 3.1 - 3.3 to remove a
blind from a channel.
Shortly press the program button on the motor. The blind will start
stepping, indicating that program mode has been activated.
(The blind remains stepping until the program mode is de-activated.)
Press the pair button on the back of the remote control to pair the
blind to the remote control. The blind will shortly stop stepping
indicating that the remote has been paired to the blind.
Select a desired channel for the blind by pressing 1 of the 4 channel
buttons on the remote control.
Channel 1
Channel 2
Channel 3
Channel 4

4Remote holder
4. REMOTE HOLDER 4. REMOTE HOLDER
Different materials require different types of fittings. Always choose
screws and plugs that are specially suited to the material.

motion-blinds.com
CM16U-R3
All rights reserved. No part of this publication may be reproduced, stored in a retrieval
system, or transmitted, in any form, by any means, electronic, mechanical, photocopying,
recording, digital or otherwise without the written permission of the publisher.
Although this manual has been composed with the utmost care, Coulisse b.v. does not
accept any responsibility for damage due to mistakes and/or faults in this manual.
Coulisse b.v. reserves the right to revise the manual and to revise and/or change its
content at any time, without obligation to notify any person or entity of such revisions
or changes.
