MotionComposites APEX A User manual

ULTRALIGHT RIGID WHEELCHAIRS
motioncomposites.com
USER MANUAL

GENERAL – RIGID WHEELCHAIRS |USER MANUAL
3
T1 866 650-6555 F1 888 966-6555 Email [email protected]
MAINTENANCE MANUAL
& WARRANTY
INFORMATION
Dealer: This manual must be given to the user of the APEX wheel-
chair before its first use.
User: Prior to using the APEX wheelchair, carefully read this manu-
al and keep it for future reference.
For more information about this product, its parts/accessories and
the services provided, please visit: motioncomposites.com
APEX
Thank you for selecting the APEX composites wheelchair. Please do
not hesitate to send us your feedback or questions regarding this
product’s reliability, safety, usability, as well as any repair/mainte-
nance services offered by an authorized Motion Composites dealer.
WARNING  READ THIS MANUAL
Do not operate this wheelchair without reading and understanding
this user manual. If you are unable to understand the warnings,
cautions and instructions, contact your Motion Composites dealer
or customer support at: 1 866 650-6555 before attempting to use
this wheelchair.
If you ignore this warning, you may fall,
tip over or lose control of the wheelchair and seriously injure your-
self or others and damage your wheelchair.
Made in Canada with Canadian and imported parts.
CONTACT INFORMATION
Motion Composites Inc.
160, Armand Majeau Sud
Saint-Roch-de-l’Achigan, Québec
J0K 3H0 Canada
Telephone: 1866650-6555
Fax: 1888966-6555
[email protected]
motioncomposites.com
EuropEan authorizEd rEprEsEntativE
Advena Ltd
Tower Business Centre
2nd Floor, Tower Street
Swatar, BKR 4013, Malta
IMPORTANT INFORMATION!
If you have any questions about safety, adjustments,
accessories, use, or maintenance, please contact your authorized
Motion Composites distributor or dealer.
Please record the following information for future reference:
Date of purchase:
Serial Number:
Supplier:
Address:
Telephone:
REDEFINING THE WORLD'S EXPECTATIONS
ABOUT RIGID WHEELCHAIRS
APEX is Motion Composites' latest adjustable ultralight rigid wheel-
chair. Its design is nothing short of revolutionary. Why? Because it
offers the best of both worlds. The best in lightness, strength and
performance combined with aluminum and carbon materials.
And, for the first time, the best possible settings and adjustments
for a rigid wheelchair.
THE LIGHTEST WHEELCHAIR
OF ITS CATEGORY
With a transit weight of only 9.2 lbs (4.2 kg), APEX erases any
preconceived notions about rigid wheelchairs. It is completely
adjustable to meet the needs of almost any client and operates like
a thoroughbred.
HEADTURNING DESIGN
Check out the design and construction details on the APEX. Or
examine its innovative components and accessories such as the
integrated impact guard and rigidify system. In one word... revolu-
tionary.
Welcome to a new era in rigid chair design and performance.
SHED THE WEIGHT,
UP THE PERFORMANCE
Available in aluminum frame, the APEX cantilever design is con-
structed using the industry’s most advanced materials. Plus, the
APEX represents not just low frame weight. It is also the lightest
configured adjustable wheelchair in the industry.
NIMBLE AND RESPONSIVE
The unique rear rigidizing bar on the APEX optimizes ride perfor-
mance. By increasing rear-frame rigidity, we’ve achieved an open
design concept that increases lateral stability.
Result — flex where and when you want it, and no sacrifice in stabili-
ty for gains in comfort and ease of transit.

USER MANUAL |RIGID WHEELCHAIRS – GENERAL
NOTE: If you ignore these warnings or fail to inspect or maintain your wheelchair as directed in the manual, you may fall, tip over or lose control of the wheelchair and seriously injure yourself or others and damage the
wheelchair.
4
SLEEK STYLING
Inspired by modern design and aesthetics, the head-turning lines
on the APEX prove once again that form should follow function. We
invite you to linger on the APEX’s gentle curves and bold styling.
Every design detail delights the eye and excites the senses.
ADJUSTS TO YOUR LIFE
As people change and evolve, so should their wheelchairs. From
simple adjustments in back angle, seat and floor height to tunable
rear wheel positions and seat width, the APEX is fully modular and
adjustable. Plus, its laser-etched markings allow you to more easily
adjust key components and specify exact positioning.
BUBBLE LEVEL (DOUBLE)
For quick and easy angle adjustments.
TECHNOLOGIES
HIGHMODULUS CARBON T700
The lightest and most rigid material available, also
renowned for its vibration dampening properties.
UNIQUE ALUMINUM ALLOY
Stronger and lighter than the competition's.
TRIPLEREINFORCED ALUMINUM
Reduces weight while maintaining high strength.
CLAMPED RIGIDIZING SYSTEM
Reduces weight while maintaining high strength.
INTEGRATED IMPACT GUARD WITH TOP GRIP
Prevents daily-use scratches to the front of frame. Adds
high friction grip for transfers. Protects vulnerable areas
of lower extremities.
BUBBLE LEVELS
An alloy stronger and lighter than aluminum 7005.
STANDARD CARBON FIBER CAMBER TUBE
Reduces weight while maintaining high strength.
LASER ETCHED MARKINGS
An alloy stronger and lighter than aluminum 7005.
NEWTON ACCESSORIES
Reduces weight while maintaining high strength.
APEX C
The pinnacle of design and performance, the APEX Carbon is the
choice of discriminating users. The lightest, smoothest ride in the
world!
APEX A
Since choice is important, we also build the APEX Aluminum with a
unique alloy that’s 20% stronger than 7005 aluminum. This elevates
the APEX A into a new category of adjustable performance.
