Motor Scrubber MS2000S Instruction Manual

MotorScrubber MS2000S/M/L Instruction Manual

2
PLEASE READ ALL INSTRUCTIONS
When using electric products, basic safety precautions should always be followed to
reduce the risk of electric shock and personal injury, including the following:
Consider your work area environment. When using the MotorScrubber be aware of
overhead electrical wires. MOTOR SCRUBBER IS POWERED BY DC CURRENT ONLY.
DO NOT ATTEMPT TO OPERATE MOTORSCRUBBER WITH AC CURRENT.
• Never pull the MotorScrubber by its cord or yank it to disconnect it from the battery.
• Keep the cord away from heat, oil and sharp edges.
• Keep your MotorScrubber clean. For safer operation follow instructions for attaching
accessories. Keep the upper handle switch area dry, clean and free from oil, grease
and water.
• Disconnect the MotorScrubber when not in use AND WHEN ATTACHING
ACCESSORIES.
• Inspect for damage before using MotorScrubber.
• When servicing, use only genuine parts and accessories.
• MOTORSCRUBBER IS A POWER TOOL. AS WITH ANY POWER TOOL, ALWAYS USE
BOTH HANDS TO ENSURE SAFE OPERATION.
Save these instructions for future reference.

3
ASSEMBLING YOUR MOTORSCRUBBER
1. Remove the motor housing and yoke from carton. Connect the electrical plug from
the yoke to the electrical plug from the end of handle. Push together FIRMLY (See Fig.
1), be certain the electrical plugs are fully locked together. Then insert the yoke into
the handle aligning the screw holes in the yoke with the two holes in the handle (See
Fig. 2). Insert the thumb screws and finger tighten.
2. Attach the hub to the motor assembly using the flat washer, lock washer, and bolt
provided. Assemble in the order shown in Fig.3 below.
3. To operate the MotorScrubber using the rechargeable battery, connect the electrical
plug from the battery to the electrical plug attached to the handle (See Fig. 4).
4. To operate the MotorScrubber using the 25’ cord (MS-1025), connect the electrical
plug from the MS-1025 to the electrical plug attached to the handle, then connect the
other end of the MS-1025 to either the MS-1020 12VDC vehicle battery post adapter,
the MS-1022 cigarette lighter adapter, or the battery pack.
If you have purchased a MotorScrubber MS2000S or MS2000M
model please skip to point 3 below. Points 1 and 2 only apply to the
MS2000L model which comes non assembled.
Electrical Connector from Yoke
Electrical Connector
from Handle
FIG. 1
Screws
FIG. 2
FIG. 4FIG. 3

4
THE HARNESS
• The harness should be put over your shoulders like a backpack. There are
two adjustable straps which can be pulled to tighten the shoulder supports to a
comfortable user level.
• The sternum clip oers extra support and is tightened by pulling the adjustment strap.
• The velcro belt strap can be fastened across your abdomen or if you prefer not to
use this make sure this is fixed behind you, then the shoulder straps only can be used
without the belt.
CHANGING A MOTORSCRUBBER BRUSH
• Line-up the tabs on the disc with the hub on the MotorScrubber.
• Hold the hub to prevent rotation. Press down while turning the disc clockwise until
it locks in place.
• To remove, press down on the disc and turn it counter-clockwise holding hub until
tabs are free. Then lift o the disc.
For an instructional video please visit the support section of www.motorscrubberclean.com
Carry Handle
Charger Pouch
Battery Pack
Electrical Cable
Electrical Connector

5
CLEANING WITH THE MOTORSCRUBBER
• Apply soap/cleaning solution to the surface with a sprayer or directly to the scrub
disc. You may also mix soap concentrate in a bucket and dip the scrub head into the
bucket.
• Scrub with straight, light strokes. You do not have to exert pressure. MotorScrubber
will do the work.
• DO NOT USE MOTORSCRUBBER WITH FLAMMABLE CLEANING FLUIDS.
• AUTOMATIC SHUT-OFF: MotorScrubber is equipped with a self-resetting circuit
breaker to prevent damage to the motor. If the unit is stalled, the circuit breaker will
interrupt the electrical power from your 12-volt battery. Remove MotorScrubber from
the work surface. The circuit breaker will re-set in 6 to 10 seconds. Resume using
MotorScrubber.
UNDERWATER USE
• Because its motor head can be fully-immersed in water,
the MotorScrubber is ideal for many underwater cleaning
tasks. One of the more popular uses of the MotorScrubber
is cleaning the “scum line” above the water level in
swimming pools, spas, boats, etc.
• mmersing the head for long periods of time could aect
its water-proofing seals due to the eects of prolonged
heating and cooling. The seals could contract and allow
water to make direct contact with the motor, which would
cause a motor failure. Guidelines need to be followed to
avoid this.
• The seals should be inspected before each use to check
for signs of corrosion that would compromise its water
tightness. If the unit is used underwater on a regular
basis an internal inspection of the head is required each
month by a competent technician, this is to check for water
ingress.
 WE RECOMMEND NOT USING THE MOTORSCRUBBER
FULLY SUBMERGED IN WATER FOR MORE THAN
2 MINUTES CONTINUOUSLY. MOTORSCRUBBER
SHOULD THEN BE REMOVED AND ALLOWED TO COOL
FOR 5 MINUTES.
• Waterline cleaning where MotorScrubber is half in and half
out of the water has no limitations.
• Regular underwater usage will reduce the lifetime of
the head unit. MS4000 complete motor head can be
purchased and replaced when required. 1 year is the
suggested life of regular underwater use.
Submerge
upto 25cm
away from
the switches

6
BATTERY INFORMATION
The battery should be charged before using your MotorScrubber, after each use, and if
unused for 4 months. A full charge takes 8 hours. First, connect the coil cord into the
charger and then plug the charger directly into a 120 VAC/60HZ or 240 VAC electrical
outlet or use an adapter or a charger made for the AC source being used. (Do not
use an extension cord). After charging, disconnect the charger from the AC outlet and
(IMPORTANT) disconnect the charger from the battery.
There are two sources of battery power for the MotorScrubber: (A) the rechargeable
battery pack with harness; and (B) a 25-foot cord (MS-1025) which connects to the boat/
vehicle 12-volt DC battery supply via MS-1022 or MS-1020.
• MotorScrubber uses a rechargeable sealed lead-acid battery
• Capacity: 12-volt, 7.0 amp-hour
• Non-spillable
The battery pack contains a fuse for protection against a short circuit. If your MotorScrubber
will not run, open the fuse holder in the battery pack and check the fuse. Replace if
necessary with: 30 AMP-32 VOLT, ABC GLASS FUSE (MSS038).
• Do not charge in a gas-tight container
• Do not short the battery terminals
• Do not incinerate
• Flush with water at once if contact is made with electrolyte (acid)
IMPORTANT SAFETY INSTRUCTIONS FOR BATTERY & CHARGER
• To protect against risk of electrical shock do not put battery charger in water or any
other liquid.
• Do not operate in the presence of explosives and/or flammable fumes or liquids.
• Do not store or carry battery so that metal objects can contact battery terminals - the
battery could short circuit causing fire, personal injury or damage to the battery.
• Never attempt to open battery for any reason. If the housing of the battery breaks
or cracks, immediately discontinue use and do not recharge. The battery should be
replaced.
• Do not charge a battery if it is wet or shows any evidence of corrosion.
• Do not incinerate the battery; it can explode in a fire.
• Plug the battery charger directly into a 120VAC/60HZ or 240VAC, with the correct
plug adaptor, electrical outlet (Do not use an extension cord).
• Charge the battery only with the MotorScrubber battery charger.
• Do not use the charger in wet or damp conditions. It is intended for indoor use only.
Do not use the charger near sinks or tubs. Do not immerse in water.

7
• Do not allow the cord to hang over the edge of a table or counter, or touch hot
surfaces.
• Do not use charger for any other uses other than MotorScrubber batteries; other
batteries may explode.
• Do not operate charger with damaged cord or plug, have them replaced immediately.
• Do not operate charger if it has received a sharp blow, been dropped or otherwise
damaged in any way. Return the appliance to your local distributor for examination,
repair or electrical or mechanical adjustment. Do not disassemble charger.
• For best results do not charge a battery when it or air temperature is below 40°F (5°C)
or above 105°F (40°C).
• Unplug the charger when not in use and before cleaning or maintenance.
• Do not abuse the cord. To reduce the risk of damage to the electric plug or cord,
never carry the charger by its cord or yank the cord to disconnect. Instead, grasp
the charger plug and pull to disconnect. Keep charger cord away from heat, oil and
sharp edges.
 NEVER ATTEMPT TO OPERATE THE MOTORSCRUBBER FROM AN ELECTRICAL
OUTLET. OPERATE THE MOTORSCRUBBER ONLY FROM THE 12VOLT BATTERY.
TROUBLESHOOTING
If your MotorScrubber is not turning on or is turning slowly:
1. First, check battery terminals are connected properly and motor to handle plugs
are connected securely. Next, using a voltmeter, simply open the battery pack,
disconnect the two leads at the battery, and touch the voltmeter probes to the
terminals accordingly. A satisfactory reading would be approximately 11.5 to 13 volts.
2. If the battery tests as satisfactory, the motor should be tested next. Disconnect the
plug between the handle and the motor (wrap cord from handle with rubber band to
prevent cord from retracting into handle), connect the battery pack coil cord directly
to the motor. If the motor now turns properly then the o/on switch or wiring harness
within the handle is not functioning properly. If the motor still does not turn, the
MS4000 is defective. Consult your selling distributor.
For additional help on using the MotorScrubber please visit the
support section of our website www.motorscrubberclean.com

Every MotorScrubber is thoroughly inspected and tested before leaving the factory. It is warranted to
be free from defects in workmanship and materials for the period of one year from the date of original
purchase. Should any problem covered by this warranty develop during the one-year period, follow the
instructions in this booklet and return the unit carefully packaged with freight prepaid to your original
supplier.
Your supplier will inspect the item and liaise with us directly. If inspection shows the problem was
caused by a defect in workmanship or materials, your supplier will repair (or at our joint option, replace)
the unit without charge, return freight prepaid.
THIS WARRANTY IS VOID IF:
1. Alterations have been made to the product.
2. Repairs are required because of normal use.
3. Repairs have been made or attempted by anyone other than an authorised MotorScrubber agent.
4. The product has been mistreated, misused or improperly maintained or operated.
5. The warranty certificate is not completed and returned to MotorScrubber.
In no event shall MotorScrubber be liable for any damages beyond repair or replacement as described
above, including without limitation, warranties of merchantability and fitness for a specific purpose. This
warranty gives you specific legal rights and you may also have other rights which vary from state to
state. Some states do not allow the exclusion or limitation of incidental or consequential damages, so
the above limitation or exclusion may not apply to you. Some states do not allow limitation on how long
an implied warranty lasts, so the above limitations may not apply to you.
To register your warranty visit www.motorscrubberclean.com/#!warranty/nja4l
YOUR
WARRANTY
LIMITED ONEYEAR WARRANTY
MOTORSCRUBBER 12VOLT DC TOOL
