Motorline professional CHAINLIFT Instruction Manual

v1.0
REV. 02/2021
CHAINLIFT
CHAINLIFT EN
USER/INSTALLER MANUAL

1B
4A
4A
4B
5A
6A
6A
6B
7A
8
1A 1B
ENEN
1B
4A
4A
4B
5A
6A
6A
6B
7A
8
STANDARDS TO FOLLOW
TECHNICAL SPECIFICATIONS
INSIDE THE PACKAGE
DIMENSIONS
. SAFETY INSTRUCTIONS
. OPERATOR
SCHEMES FOR TESTS
FINAL CONSUMERS AND SPECIALIZED TECHNICIANS INSTRUCTIONS
. INSTALLATION
. COMPONENTS TEST
. TROUBLESHOOTING
OPERATOR INSTALLATION
INSTALLATION OF THE CHAIN
ADJUST STOPS
INSTALLATIONS OF THE GUTTER
00. CONTENT 01. SAFETY INSTRUCTIONS
INDEX STANDARDS TO FOLLOW
This product is certified in accordance with European
Community (EC) safety standards.
This product complies with Directive 2011/65/EU of the
European Parliament and of the Council, of 8 June 2011, on
the restriction of the use of certain hazardous substances in
electrical and electronic equipment.
(Applicable in countries with recycling systems).
This marking on the product or literature indicates that the
product and electronic accessories (eg. Charger, USB cable,
electronic material, controls, etc.) should not be disposed of
as other household waste at the end of its useful life. To avoid
possible harm to the environment or human health resulting
from the uncontrolled disposal of waste, separate these items
from other types of waste and recycle them responsibly to
promote the sustainable reuse of material resources. Home
users should contact the dealer where they purchased this
product or the National Environment Agency for details on
where and how they can take these items for environmentally
safe recycling. Business users should contact their vendor and
check the terms and conditions of the purchase agreement.
This product and its electronic accessories should not be
mixed with other commercial waste.
This marking indicates that the product and electronic
accessories (eg. charger, USB cable, electronic material,
controls, etc.) are susceptible to electric shock by direct or
indirect contact with electricity. Be cautious when handling
theproductandobserveallsafetyproceduresinthismanual.

2A EN
01. SAFETY INSTRUCTIONS
GENERAL WARNINGS
•This manual contains very important safety and usage information.
very important. Read all instructions carefully before beginning the
installation/usage procedures and keep this manual in a safe place
that it can be consulted whenever necessary.
•This product is intended for use only as described in this manual. Any
other enforcement or operation that is not mentioned is expressly
prohibited, as it may damage the product and put people at risk
causing serious injuries.
•This manual is intended firstly for specialized technicians, and does
not invalidate the user’s responsibility to read the “User Norms”
section in order to ensure the correct functioning of the product.
•The installation and repair of this product may be done by qualified
and specialized technicians, to assure every procedure are carried
out in accordance with applicable rules and norms. Nonprofessional
and inexperienced users are expressly prohibited of taking any
action, unless explicitly requested by specialized technicians to do
so.
•Installations must be frequently inspected for unbalance and the
wear signals of the cables, springs, hinges, wheels, supports and
other mechanical assembly parts.
•Do not use the product if it is necessary repair or adjustment is
required.
•When performing maintenance, cleaning and replacement of parts,
theproduct mustbedisconnectedfrompowersupply. Alsoincluding
any operation that requires opening the product cover.
•The use, cleaning and maintenance of this product may be carried
out by any persons aged eight years old and over and persons whose
physical, sensorial or mental capacities are lower, or by persons
without any knowledge of the product, provided that these are
supervision and instructions given by persons with experienced in
terms of usage of the product in asafe manner and who understands
the risks and dangers involved.
•Children shouldn’t play with the product or opening devices to avoid
the motorized door or gate from being triggered involuntarily.
WARNINGS FOR TECHNICIANS
•Before beginning the installation procedures, make sure that you
have all the devices and materials necessary to complete the
installation of the product.
•YoushouldnoteyourProtectionIndex(IP)andoperatingtemperature
to ensure that is suitable for the installation site.
•Provide the manual of the product to the user and let them know
how to handle it in an emergency.
•If the automatism is installed on a gate with a pedestrian door,
a door locking mechanism must be installed while the gate is in
motion.
•Do not install the product “upside down” or supported by elements
do not support its weight. If necessary, add brackets at strategic
points to ensure the safety of the automatism.
•Do not install the product in explosive site.
•Safety devices must protect the possible crushing, cutting, transport
and danger areas of the motorized door or gate.
•Verify that the elements to be automated (gates, door, windows,
blinds, etc.) are in perfect function, aligned and level. Also verify if
the necessary mechanical stops are in the appropriate places.
•The central must be installed on a safe place of any fluid (rain,
moisture, etc.), dust and pests.
•You must route the various electrical cables through protective
tubes, to protect them against mechanical exertions, essentially on
the power supply cable. Please note that all the cables must enter
the central from the bottom.
•If the automatism is to be installed at a height of more than 2,5m
from the ground or other level of access, the minimum safety and

3A EN
01. SAFETY INSTRUCTIONS
•health requirements for the use of work equipment workers at the
work of Directive 2009/104/CE of European Parliament and of the
Council of 16 September 2009.
•Attach the permanent label for the manual release as close as
possible to the release mechanism.
•Disconnect means, such as a switch or circuit breaker on the
electrical panel, must be provided on the product’s fixed power
supply leads in accordance with the installation rules.
•If the product to be installed requires power supply of 230Vac or
110Vac, ensure that connection is to an electrical panel with ground
connection.
•The product is only powered by low voltage satefy with central (only
at 24V motors)
WARNINGS FOR USERS
•Keep thismanualinasafeplaceto be consultedwhenevernecessary.
•If the product has contact with fluids without being prepared, it
must immediately disconnect from the power supply to avoid short
circuits, and consult a specialized technician.
•Ensure that technician has provided you the product manual and
informed you how to handle the product in an emergency.
•If the system requires any repair or modification, unlock the
automatism, turn off the power and do not use it until all safety
conditions have been met.
•In the event of tripping of circuits breakers of fuse failure, locate
the malfunction and solve it before resetting the circuit breaker or
replacing the fuse. If the malfunction is not repairable by consult
this manual, contact a technician.
•Keep the operation area of the motorized gate free while the gate in
in motion, and do not create strength to the gate movement.
•Do not perform any operation on mechanical elements or hinges if
the product is in motion.
RESPONSABILITY
•Supplier disclaims any liability if:
•Product failure or deformation result from improper installation
use or maintenance!
•Safety norms are not followed in the installation, use and
maintenance of the product.
•Instructions in this manual are not followed.
•Damaged is caused by unauthorized modifications
•In these cases, the warranty is voided.
SYMBOLS LEGEND:
• Important safety
notices
• Useful information
• Programming
information
• Potentiometer
information
• Connectors
information
• Buttons
information

1240mm
1000mm
24mm
44mm
25kg max.
200mm
01•
03•
04•
08•
09•
05•
06•
07•
02•
4A 4B
ENEN
02. OPERATOR 02. OPERATOR
TECHNICAL SPECIFICATIONS INSIDE THE PACKAGE
DIMENSIONS
CHAINLIFT
• Product power supply 230 V 50/60Hz
• Motor voltage 24Vdc
• Power 100W
• Absorbed current 4 A
•RPM 60 RPM
• Noise LpA <= 50dB (A)
• Operating temperature -25°C ~ 55°C
• IP IP65
• Working Frequency 80%
• Weight max. Chain 25kg (+/- 20 mt iron chain)
On the package you will find the following kit components:
01 • 01 Chainlift
02 • 02 FALK controller
03 • 01 flashing lamp
04 • 02 batteries and 01 transformer
05 • 01 user manual
06 • 01 Photocell MF30
07 • 02 key unlock
08 • 01 control planel
09 • 01 8m plastic chain

5A
500mm
350mm
300mm
1
5
2
3
4
200mm 180mm 180mm 200mm
EN
 • Drill a hole in the ground to create a concrete shoe. The dimensions presented
are recommended in shoe creation. You should leave tubes in the middle for the passage
cables for power and accessories.
 • Apply the column with the screws to the concrete base. You must ensure that the
column is level (use a level).
GROUND
HEMBRAS
TORNILLOS
HEMBRAS
CHAINLIFT
CHAINLIFT CHAINLIFT
VÃO
03. INSTALLATION
OPERATOR INSTALLATION
For the correct functioning of the automatism, it is necessary to take into
the dimensions mentioned in the image. Leave a mm free space on the
door side of each automatism, so you can open the automatism door
whenever necessary.
 • Proceed in the same way to install the second column of the automatism.
 • Measure the desired distance from one tower to another automatism tower (length
before installation.
CEMENT SHOULD
BE DRY
INSTALLATION OF
THE CHAIN
EXISTING FOUNDATION
*If you are installing the automatism
in an existing foundation, screw the
fixing plate to the floor, using
suitable screws and bushings
(not supplied in the kit).
INSTALLATION OF
THE GUTTER
 • Fill the hole with concrete and smooth the top where you will fix the column.

6
7
7
8
8
7
8
6A 6B
ENEN
03. INSTALLATION 03. INSTALLATION
INSTALLATION OF THE GUTTER TO THE GROUND
11 • Cut the gutter from the floor as far
as the span, and install it under the
ground with cement.
Center it according to the column, so
that the chain enter the gutter when
making the descent movement.
Fine-tune the stops according to the height you want the chain to rise and fall.
09 • Unscrew the stop screw, remove it and place it in the desired hole.
10 • Retighten the stop screw at the chosen place.
ADJUST STOPS
Gutter B must be
filled with cement in the
interior, to give resistance.
Ifyouchoose anothertypeofgutter (gutterA), youwillneedto makeafoundation
to fix it on the ground.
Gutter BGutter A
INSTALLATION OF THE CHAIN
 • Secure the chain in one of the
columns with a padlock.
 • Stretch the chain to the
second column, and if the chain
is too long for the span, cut the
overflow.
After installing the two columns, proceed as follows to install
the chain:
 • Attach the other end to the
second column with padlock.
If you use an iron chain,
you must place a plastic
"fuse link" so that the chain can
burst in the event that a vehicle crosses the span with the chain
raised.
If you do not want to use a padlock on both columns, you can
cut the chain link to mount it on one of the plates by closing it
again with welding.

7A EN
SCHEMES FOR TESTS
04. COMPONENTS TEST
To detect if the failure is in the control board or in the motor, it is necessary to perform tests
with a direct connection to a V power supply. In the diagrams below, it is shown how this
connection should be made and how to interleave the different components wires.
Make the connections as shown in the
picture.
If the engine runs, the problem is in
the control board. Changing the wires
in the battery, changes the direction of
movement of the motor.
The test must be carried out by specialized technicians due to the serious danger
related to the misuse of electrical systems !!
To perform the tests, you do not need to remove the automation from where it is installed.
This way you can see if the automation directly connected to the current can work properly.

8A EN
05. TROUBLESHOOTING
FINAL CONSUMERS AND SPECIALIZED TECHNICIANS INSTRUCTIONS
Problem Procedure Behavior Behavior II Discovering the origin of the problem
• Motor
doesn't work
• Make sure you have
230V power supply
connected to control
board and if it is
working properly.
• Still not working • Consult a qualified
technician.
• Motor
doesn’t move
but makes
noise
• Unlock motor and
move the gate by hand
to check for mechanical
problems on the gate.
• Found problems? • Consult a qualified gates
technician. 1 • Check motion axis and associated motion systems related with the motor (wheels, gear racks, etc.) to find out what is the problem.
• The gate moves
easily?
• Consult a qualified
MOTORLINE technician.
• Motor
opens but
doesn’t close
• Unlock motor and
move the gate by hand
to closed position.
Lock motor again and
turn of power supply for
5 seconds. Reconnect it
and send order to open
gate using transmitter.
• Gate opened but
didn’t close again.
1 • Check if there is any
obstacle in front of the
photocells;
2 • Check if any of the control
devices (key selector, push
button, video intercom, etc.)
of the gate are jammed and
sending permanent signal to
control unit;
3 • Consult a qualified
MOTORLINE technician.
• Motor
doesn’t make
full course
• Unlock motor and
move the gate by hand
to check for mechanical
problems on the gate.
• Found problems? • Consult a qualified gates
technician 1 • Check motion axis and associated motion systems related with the motor (wheels, gear racks, etc.) to find out what is the problem.
• The gate moves
easily?
• Consult a qualified
MOTORLINE technician
1 • Open control board and check
if it has power supply;
2 • Check input fuses of the
control board;
3 • Disconnect the motor from
control board and test them by
connecting directly to power
supply in order to find out if they
have problems (see page 11A).
4 • If the motor works, problem is
on the control board.
Pull it out and send it to our
MOTORLINE technical services for
diagnosis;
5 • If the motor doesn’t work,
remove them from installation
site and send to our MOTORLINE
technical services for diagnosis.
1 • Check capacitor, testing
operator with a new one;
2 • If capacitors are not the
problem, disconnect motor from
control board and it them by
connecting directly to power
supply in order to find out if it has
problems (see page 7B);
3 • If the motor works, the problem
is from control board. Pull it out
and send it to our MOTORLINE
technical services for diagnosis;
4 • If the motor doesn’t work,
remove them from installation
site and send to our MOTORLINE
technical services for diagnosis.
1 • Check capacitor, testing
operator with a new one;
2 • If capacitors are not the
problem, disconnect motor
from control board and test it
by connecting directly to power
supply in order to find out if it is
broken;
3 • If the motor doesn’t work,
remove them from installation
site and send to our MOTORLINE
technical services for diagnosis.
4 • If motor work well and move
gate at full force during the
entire course, the problem is
from controller. Set force using
trimmer on the board. Make a new
working time programming, giving
sufficient time for opening and
closing with appropriate force .
5 • If this doesn’t work, remove
control unit and send it to
MOTORLINE technical services.
NOTE: Setting force of the
controller should be sufficient
to make the gate open and close
without stopping, but should stop
and invert with a little effort from
a person. In case of safety systems
failure, the gate shall never cause
physical damaged to obstacles
(vehicles, people, etc).
All MOTORLINE control boards have LEDs that
easily allow to conclude which devices are with
anomalies.
All safety devices LEDs (DS) in normal
situations remain On.
All "START" circuits LEDs in normal situations
remain Off.
If LEDs devices are not all On, there is some
security systems malfunction (photocells,
safety edges), etc.
If "START" circuits LEDs are turn On, there is a
control device sending permanent signal
A) SECURITY SYSTEMS:
1 • Close with a shunt all safety systems on
the control board (check manual of the control
board in question).
If the automated system starts working
normally check for the problematic device.
2 • Remove one shunt at a time until you find
the malfunction device
3 • Replace it for a functional device and check
if the motor works correctly with all the other
devices. If you find another one defective,
follow the same steps until you find all the
problems.
B) START SYSTEMS:
1 • Disconnect all wires from START terminal
input.
2 • If the LED turned Off, try reconnecting one
device at a time until you find the defective
device.
NOTE:
In case procedures described in sections A)
and B) don’t result, remove control board and
send to the MOTORLINE technical services for
diagnosis;
