Motorola Bluetooth Wireless Hands Free User manual

™
Bluetooth Wireless
Hands Free
Car Kit
User's Guide >
art#020829-O.eps

1
Welcome
Welcome to Motorola’s “connected” world of Bluetooth™ personal area wireless
networking. The Motorola Bluetooth Wireless Hands Free Car Kit makes wireless
connection simple and quick.
The advanced, sophisticated Motorola Bluetooth Wireless Hands Free Car Kit offers these
features:
• seamless, wireless hands-free audio through Bluetooth link
• digital audio interface with high quality, full-duplex, hands free speech
• Voice Recognition
• voice user interface
• entertainment mute—automatically mutes radio during calls
• noise reduction and acoustic echo cancellation
• automatic volume control
• Ignition sense—continue an active call after car is turned off
• compliance with Bluetooth Headset v1.1 and Bluetooth Hands Free 0.96 profile
Note: There may be differences between the performances of the Bluetooth headset
profile and the Bluetooth Hands Free profile. See the “Using Your Car Kit” chapter for
details.

2
Personal Communications Sector
600 North U.S. Highway 45
Libertyville, Illinois 60048
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States)
1-800-461-4575 (Canada)
www.motorola.com (United States)
www.motorola.ca (Canada)
MOTOROLA, the Stylized M Logo and all other trademarks indicated as such herein are trademarks of
Motorola, Inc. ® Reg. U.S. Pat. & Tm. Off. The Bluetooth trademarks are owned by their proprietor and used by
Motorola, Inc. under license. All other product or service names are the property of their respective owners.
© 2002 Motorola, Inc. All rights reserved. Printed in the U.S.A.
Manual number: 6889176G01-O

3
Contents
Welcome . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 1
Safety and General Information . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4
Installing the Hands Free Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Guidelines for Installation and Connection . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Installation Procedure . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5
Using Your Car Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
The Control Module . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Linking Your Car Kit and Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 8
Disconnecting the Car Kit from Your Phone . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Training Your Car Kit’s Internal Voice Recognition . . . . . . . . . . . . . . . . . . . . . . . . . . . .10
Placing a Call with the Car Kit . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 13
Using Features While on a Call . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 14
Troubleshooting . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 16
Training Quick Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 17
Calling Features Quick Reference . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .19
Motorola Limited Warranty for Accessories . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 20
Total Customer Satisfaction . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 22
Motorola’s Warranty . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 23

4
Safety and General Information
IMPORTANT INFORMATION ON SAFE AND EFFICIENT OPERATION. READ THIS
INFORMATION BEFORE USING YOUR PHONE.
Users are not permitted to make changes or modify the device in any way. Changes or
modifications not expressly approved by the party responsible for compliance could void
the user’s authority to operate the equipment. See 47 CFR Sec. 15.21
.
This device complies with part 15 of the FCC rules and with RSS-210 / RSS-139 of the
Industry Canada. Operation is subject to the following two conditions: (1) This device may
not cause harmful interference, and (2) this device must accept any interference received,
including interference that may cause undesired operation. See 47 CFR Sec. 15.19(3).
Canada Compliance (Industry Canada)
To prevent radio interference to the licensed service, this device is intended to be operated indoors
and away from windows to provide maximum shielding. Equipment that is installed outdoors is
subject to licensing.
European Union (EU) and EFTA
This equipment complies with the R&TTE directive 1999/5/EC and has
been provided with the CE mark accordingly.
Electromagnetic Interference/Compatibility
Nearly every electronic device is susceptible to electromagnetic interference (EMI) if inadequately
shielded, designed, or otherwise configured for electromagnetic compatibility.

5
Installing the Hands Free Kit
Installing the Hands Free Kit
Guidelines for Installation and Connection
• Only qualified personnel should install this car kit. If necessary, contact with vehicle
manufacturer for air bag information specific to the vehicle.
Caution: An air bag inflates with great force. DO NOT place objects, including
communication equipment, in the area over the air bag or in the air bag deployment area. If
the communication equipment is improperly installed and the air bag inflates, serious injury
could occur.
• Mount components securely on strong surfaces to prevent shifting that could cause
injury or interfere with safe vehicle operation. Always use the supplied mounting
hardware
• Mounted components and attached wires or cables must not interfere with seating or
leg space.
• Route cables so they are protected from pinching, sharp edges, and crushing. Keep
all in-line connectors easily accessible.
• This car kit is intended for use in 12 volt negative ground systems only. The car kit
draws less than 3 amps. Confirm that the vehicle’s electrical system can supply this
current.
Installation Procedure
Caution: This car kit must be connected to a maximum 10A fuse in the car fuse panel to
prevent fire or other damages if a short circuit should occur somewhere in the Junction
Box.
Before installation, unpack, assemble, and test all components on a service bench.
Installing the Bluetooth Junction Box
Mount the box using the screws provided.
The best location for the Bluetooth junction box is under the dash. The box must be
protected from dirt and moisture and have adequate space for cooling and to allow for
cable connection.
For optimal Bluetooth performance, mount the junction box so that the side with the
barcode faces away from the mounting surface.

6
Installing the Hands Free Kit
The location MUST NOT interfere with the vehicle’s air bag deployment.
Installing the Power Cable and Fuse Kit
Caution: Failure to follow these steps may cause the accessory not to work properly and
may cause damage to the car kit.
1 Remove all fuses and tape them to their respective holders. DO NOT re-insert fuses until
you complete and inspect all connections.
2 Connect the fuse kit’s GREEN Ignition Sense wire (3 amp fuse) to an ignition-switched
location on the fuse block. When the ignition is off, the ignition sense line is low.
3 Connect the power cable’s ORANGE Entertainment Mute Wire to the vehicle’s
entertainment system.
Note: This feature is only operational if the car radio and/or phone support this capability.
Installation may require an optional relay (not included).
4 Connect the fuse kit’s RED positive primary lead (4 amp fuse) to a point in the vehicle’s
fuse box that is fused at 4 to 10 amp.
5 Connect the fuse kit’s BLACK ground wire to the vehicle chassis.
6 Inspect all connections.
Note: The Yellow and Blue wires are not used.
7 Re-insert all fuses. Do not replace any fuse with a higher amperage fuse.
Installing the Microphone
Note: Always use the supplied mounting hardware.
Orange
Blue
Yellow
Wire crimps:
green to green,
red to red,
black to black
Vehicle
Chassis
Green: to a point in
the fuse box
Red: to a point in fuse box
that is always active
4 - 10 AMP fuse
Black
C
B
Speaker
(SSN4020)
Junction Box
(SYN8883A, SYN0415A,
SYN0416A, SYN0417A
Microphone
(SMN4103)
Power Cable
(SKN4834A)
Vehicle
Radio
Control Module
(SYN9698A)
Fuse Kit
(SKN4937A)

7
Installing the Hands Free Kit
1 Attach one of the three supplied mounting clips to the
microphone.
2 Select a suitable location, and mount the microphone.
• Locate the microphone no more than 16 inches (40 cm)
from the driver.
• Aim the microphone directly toward the driver.
• Do not allow anything (such as a rear-view mirror or sun
visor) to block the path between the microphone and the
driver.
• Mount the microphone firmly so that vibrations do not affect
audio quality.
3 Connect the microphone to the Bluetooth Junction Box.
Installing the External Speaker
Note: Always use the supplied mounting hardware.
1 Mount the speaker to the transmission hump or beneath the dash. Position the speaker
so that it does not directly face the microphone.
Caution: The location of the external speaker MUST NOT interfere with the vehicle’s air
bag deployment.
2 Connect the speaker to the Bluetooth Junction Box.

Using Your Car Kit
8
Using Your Car Kit
The Control Module
The control module enables you to set up and use the Bluetooth Hands Free Car Kit.
Linking Your Car Kit and Phone
Before you can use this car kit, you must link it with your phone.
You establish a Bluetooth link between your car kit and phone with a paired link.
When you set up a paired link, the car kit remembers the phone’s ID. Once the car kit and
phone are paired, your car kit automatically connects to your phone every time you start your
vehicle or power up the car kit.
Initial Pairing
With the car kit and phone in close proximity:
Step Result
1 Set the car kit to pairing mode:
Start your vehicle.
or
Power up the car kit by pressing the
Bluetooth Button
E .
B
C
Bluetooth Button Voice Recognition Button Volume-Up Button
Volume-Down Button
Microphone Mute Button

9
Using Your Car Kit
Validating Pairing
To verify whether your phone has the Bluetooth headset or Bluetooth Hands Free profile,
attempt to pair your phone with the car kit as if the phone has Bluetooth Hands Free profile.
2 If your phone has a Bluetooth Hands
Free
Profile, press and hold the Bluetooth
Button E . *
or
If your phone has only a Bluetooth
Headset Profile,
press and hold both the
Bluetooth Button
E and the Voice
Recognition Button.*
The Bluetooth Button
E and the Voice
Recognition Button begin to flash
(often 3 seconds).
The Bluetooth Button
E and the Mute
Button begin to flash.
You now have two minutes to create a
wireless connection between the car kit
and your phone.
To leave pairing mode before timeout,
press the Bluetooth Button
E until the
buttons stop flashing (often 3 seconds).
* If you don’t know which profile to use, see “Validating Pairing” on page 10.
3 Set phone to scan and connect to this
car kit.
For Motorola phones:
a Press MENU .
b Select SETTINGS .
c Select CONNECTION .
d Select BLUETOOTH LINK .
e Select HANDSFREE .
f Select SCAN ALL .
Note: If your phone is not a Motorola
phone, refer to its manual for instructions
on how to scan/discover the car kit.
Your phone scans all Bluetooth Hands
Free devices around it. When your
phone “finds” the car kit, it displays
Motorola BT Car-kit .
4 Select LINK. Your phone displays Pass Key .
5 Enter Pass Key
or
Press 0000
or
Press OK/Send/Yes key
(depends on
your phone)
The Bluetooth Button
E remains lit
(indicating that the link between your
phone and the car kit has been
established), while all other buttons
stop flashing.
Step Result

Using Your Car Kit
10
If the Bluetooth link cannot be established, or if you are not able to make a call, then pair
your phone and the car kit according to the procedure for Bluetooth headset profile.
This car kit can be paired with up to three phones at a time.
Automatic Connection
After initial pairing, every time you start your vehicle, your phone and car kit will automatically
be connected (if your phone’s relevant settings are not changed and it is in power-on mode).
When the wireless connection is established, the Bluetooth Button
E remains lit.
If your phone is powered off when you start your vehicle, the Bluetooth connection may
not be automatically established when you turn on your phone.
To manually establish the connection:
Disconnecting the Car Kit from Your Phone
To disconnect the car kit from your phone, press and hold the Bluetooth Button E for more
than 3 seconds.
The car kit and phone are automatically disconnected when you turn off the vehicle, unless
you are in an active call.
Training Your Car Kit’s Internal Voice
Recognition
The Bluetooth Hands Free Car Kit supports two types of Voice Recognition:
• your phone’s voice dial feature
• the car kit’s internal Voice Recognition
What Is Training?
Voice Recognition is a feature that allows you to use speech to control your Bluetooth Hand
Free Car Kit. First you must train the car kit to recognize and then perform various
commands that you speak.
Training the car kit’s Voice Recognition “teaches” it to:
• recognize your voice—familiarize the car kit with your voice qualities and pronunciation
• attach your voice commands to key words or phone numbers
Step Result
Press the Bluetooth Button
E after you
turn on the phone.
If the connection cannot be established
10 seconds after you press the Bluetooth
Button
E , press the button again to
restart the paging.
The Bluetooth Button
E begins to flash,
and the car kit attempts to connect to your
phone. If the wireless connection is
established, the Bluetooth Button
E will
stop flashing and remain lit.

11
Using Your Car Kit
Training the Car Kit
To train the car kit’s Voice Recognition, follow these steps:
1 Make sure your phone’s keypad tones are set to normal tones. (Refer to the user’s guide
for your phone for information about using your phone’s Settings menu to define keypad
tones.)
If the Bluetooth Button
E is not lit, press it to establish a Bluetooth link.
2 Press and hold the Voice Recognition Button until it begins to flash.
3 Train the car kit by using the commands described in “Training Commands” below.
4 To exit Training Mode, press and release the Voice Recognition Button.
Training Commands
The following sections describe the commands used in Training Mode to train your car kit’s
Voice Recognition.
Note: To use the functions described below, a Bluetooth link must be established between
the car kit and your phone.
Each section shows you how to enter each command as follows:
H # 2 #
The H symbol means that you should press the keys indicated. In this example, you would
press your phones # key, followed by the 2 key, then the # key again.
H # 5 # Language Selection
Allows you to choose a language used by Voice Recognition when it prompts you with
instructions. After you enter this command, you can step through a list of languages.
• Press * to advance through the list, # to go back.
• Press any other number key to select a language.
H # 6 # Key Word On/Off
Used to activate and deactivate the key word. The key word can be set to On or Off .
When the key word is set to
On , you can answer an incoming phone call by pronouncing the
keyword (not compatible with music tone ringer).
H # 2 # Record Key Word
Used to record the key word described above.
The key word is attached to a single user and cannot be used by anyone else. Other users
must activate Voice Recognition by pressing the Voice Recognition Button and then saying
names that they have recorded.
During normal recording, you are required to say the name twice.
To exit this mode, press any key.
To distinguish the key word from other words spoken during a normal conversation, and to
prevent the key word from being activated accidentally, follow these guidelines:
• Select a key word made of 2- 3 words.

Using Your Car Kit
12
• When recording, say the key word in a louder tone of voice.
H # 8 # Record Name
Used to record and store names and their associated phone numbers in the Voice
Recognition Phone Book.
During normal recording, you are required to say the name twice. If the Voice Recognition
has difficulty matching the first to the second pronunciation, it may require you to say the
name yet again.
When entering a phone number, press
C to delete the last digit or press and hold C to
cancel the recording. Note that the
+ and # characters can be stored as part of a phone
number, but the
* character cannot.
When recording names, follow these guidelines:
• For your safety, do not record while driving. Park the vehicle in a quiet environment
(windows rolled up, radio off).
• Do not try to record a number while a passenger is talking to you.
• Direct your voice directly toward the microphone.
• Speak in your normal tone and inflection. The Voice Recognition will match the word
exactly as you have spoken it in record mode.
• Use words with multiple syllables to help the Voice Recognition differentiate names.
• Avoid names that sound alike.
H # 3 # Delete / Browse
Used to delete one or more recorded names or the Voice Recognition key word.
When you select this mode, you enter the Voice Recognition phone book. If you speak a
name when you enter the phone book, the list of entries is sorted from that name onward.
You can browse through the phone book to verify or delete entries.
• To scroll through the phone book, press # or * .
• To delete a selected name, press 9 .
• To exit this mode, press C .
H # 9 # Delete List
Used to delete all phone book entries as well as the key word.
• To delete the full list of phone book entries, press 9 .
• To exit this mode, press any key except 9 , # , and * .
H # 4 # AGC Mode
AGC (Automatic Gain Control) Mode enables the car kit to automatically adjust for changes
in surrounding background noise. The default setting for this mode is Off .
Press
# 4 # to toggle this mode On and Off .
Placing a Call with the Car Kit
You can place a call with the car kit in these ways:

13
Using Your Car Kit
• dial a number from the phone
• use voice activation
See “Making a Call with the Car Kit’s Internal Voice Recognition” on page 13.
In both cases, you must first link your car kit and phone as described in “Linking Your Car
Kit and Phone” on page 8.
When connected, the call is hands free.
Making a Call with the Car Kit’s Internal Voice Recognition
Before you can use your car kit’s Voice Recognition, you must:
• Record voice names for phone book entries on your car kit—See “ H # 8 # Record
Name” on page 12.
• Activate Voice Recognition Mode—See “Turning on Voice Recognition Mode” below.
Turning on Voice Recognition Mode
By default, the car kit’s Voice Recognition is disabled. It is turned on the first time you enter
Training Mode and record a name. You can then selectively disable it and enable it again,
depending on whether you want to use Voice Recognition on the car kit or on your phone.
• To turn on the car kit’s Voice Recognition Mode, enter # 0 # (using your phone’s
keypad).
• To exit the car kit’s Voice Recognition Mode, enter # 0 # again.
Placing a Call
1 Activate Voice Recognition Mode on the car kit. (See “Turning on Voice Recognition
Mode” on page 13 above.)
2 Press and release (within three seconds) the Voice Recognition Button.
From the car kit’s speaker, you will hear “say a name.”
3 Say the name of the entry you want to call.
When the car kit recognizes the name, it automatically dials the number. You will hear
“calling,” followed by the name you said.
To use the functions described below, a Bluetooth link must be established between the car
kit and your phone. Most phones automatically activate a Bluetooth connection when you
place a call.
During an active call with no Bluetooth link established, you can still transfer the call to the
car kit:
• Press and release (in less than three seconds) the Bluetooth Button E . A Bluetooth
link is established, and the call is hands free. (Your phone must support this feature.)
When Car Kit Voice Recognition
Is .. . .
Pressing Voice Recognition Button
Activates . . .
disabled PHONE’s voice dial feature
enabled CAR KIT’s Voice Recognition

Using Your Car Kit
14
Note: Some phones require you to press the Bluetooth Button E twice. See the user’s guide
for your phone for more information.
Receiving a Call
To answer an incoming call, do one of the following:
• Press and release (in less than three seconds) the Bluetooth Button E .
or
Press your phone’s press the OK/Send/Yes key (depending on your phone), just as you
would to answer a call in privacy mode.
or
•
Use voice activation. See “Making a Call with the Car Kit’s Internal Voice
Recognition” on page 13.
Ending a Call
To end a call:
• Press and release (in less than three seconds) the Bluetooth Button E . You can also
end a call by pressing the END key on the phone.
Using Features While on a Call
Note: To use the functions described below, a Bluetooth link must be established between
the car kit and your phone. Most phones automatically activate a Bluetooth connection when
you place a call.
Rejecting an Incoming Call
While the phone is ringing, reject the call by pressing and holding the Bluetooth Button E for
more than 3 seconds.
Note: Performance may vary on different phones. For example, for some phones (such as
Ericsson’s T68), rejecting an incoming call can break the Bluetooth link.
Transferring a Call
From the car kit to your phone:
•
During a call, press and hold the Bluetooth Button E for more than 3 seconds. (Most
phones prompt you to accept the transfer before completing the transfer.)
From your phone to the car kit:
•
During a call, press and release the Bluetooth Button E . (Some phones require you to
press the Bluetooth Button E twice. See the user’s guide for your phone for more
information.)
Muting and Unmuting a Call
To mute the microphone during a call, press the car kit’s mute button. The Mute Button will
flash, and the other party will not be able to hear you.
To un-mute the call, press the mute button again.

15
Using Your Car Kit
Volume Buttons
Press the volume buttons ( C and B ) on the car kit to increase and decrease the volume.
If you press and hold a volume button, the volume is automatically increased or decreased
to the highest or lowest step.
You can also adjust the volume remotely by pressing the phone’s volume buttons, if your
phone supports this feature.

16
Troubleshooting
Troubleshooting
You cannot pair your
phone with the car kit.
Turn the phone off and then back on. (You may
need to remove the phone’s battery.) Try pairing the
phone and car kit again.
You make a call and the
other party hears too
much background noise.
Check the location and placement of your car kit’s
microphone. (See “Installing the Hands Free Kit” on
page 5 for details.)
Nothing happens when
you enter a training
command.
You must have a Bluetooth link and be in Voice
Recognition Training Mode.

17
Training Quick Reference
1 Set phone keypad tones to normal tones. (Refer to phone user’s guide for information
about defining keypad tones.)
If Bluetooth Button
E does not flash, press it to establish a Bluetooth link.
2 Press, hold Voice Recognition Button until it flashes.
3 Train car kit by using commands described below.
4 Exit Training Mode: Press, release Voice Recognition Button.
Record Key Word
Related Information
H # 2 #
FSay a name (speak clearly)
GMotorola (for example)
FRepeat
GMotorola
FMotorola stored
FRepeat (confirm first entry or when car
kit cannot distinguish key word)
FAborting (if nothing said for 10 seconds)
Note: Turn off vehicle to reduce noise while
recording.
Record Name
Related Information
H # 8 #
FSay a name (speak clearly)
GJohn Smith
FRepeat
GJohn Smith
FPress the number, star to end
H number to store, then *
FJohn Smith Stored
FRepeat (when car kit cannot distinguish
key word)
FAborting (if nothing said for 10 seconds)
FMemory full (if more than 30 names
stored or 30 s. recorded)
H C (clear last digit—not on all phones)
H C (press and hold to erase phone
number and cancel)
Note: Turn off vehicle to reduce noise while
recording.
Delete/Browse
Related Information
H # 3 #
FSay a name, press 9 to delete
GJohn Smith (name you want to delete)
FJohn Smith, press 9 to delete
G 9 (John Smith name and phone number
deleted)
H # (hear next name)
* (hear previous name)
FAborting (if nothing said for 10 seconds)
Note: Turn off vehicle to reduce noise while
recording.
Key Word On/Off
Related Information
H # 6 #
FOn
H # 6 #
FOff
Key to Symbols
H Press the following
key(s) or enter the
following information
F Car kit says ...
G You say ...

18
AGC Mode On/Off
Related Information
H # 4 #
FOn
H # 4 #
FOff
Delete List
Related Information
H # 9 #
FPress 9 to delete all
H 9 (all names and key word deleted)
FAborting (if nothing said for 10 seconds)
Car Kit Voice Recognition Mode On/Off
Related Information
H # 0 #
FOn
H # 0 #
FOff
