Motorola MBP88CONNECT User manual

USER’S GUIDE
Wi-Fi®Video Baby Monitor Camera
Model: MBP88CONNECT
The features described in this user’s guide are subject to modifications without prior notice.

This User’s Guide has all the information you need to make the most out of your
product.
Please read the Safety Instructions on pages 5 - 6 before you install the unit.
Inside the Box
• 1 x Wi-Fi®Camera Unit
• 1 x Power Adapter
• 1 x Quick Start Guide
• 1 x Star Grip
In multi-camera packs, you will find one or more additional Camera Units with
power adapter units.
Welcome...
to your new Motorola Wi-Fi
®
Video Baby Monitor
Camera!
Thank you for purchasing your new Motorola Wi-Fi®Video Baby Monitor
Camera. Now you can view and hear your baby sleep in the room or you can
monitor your older children in their playroom. You can install the Camera only
from your iPhone®/iPad®or Android™ devices and view the Camera video
from your PC or Notebook, as well as from your iPhone®/iPad®or Android™
devices.
Please keep your original dated sales receipt for your records. For warranty
service of your Motorola product, you will need to provide a copy of your dated
sales receipt to confirm warranty status. Registration is not required for warranty
coverage.
For product related questions, please call:
US and Canada 1-888-331-3383
Email: [email protected]
On the Web: www.motorolastore.com

1. Photo Sensor (Night Vision Mode)
2. Camera Lens
3. Infrared LEDs (x 8, for night vision)
4. Power LED
On when linked to Parent Unit
Flashes when searching for Parent
Unit
5. Microphone
6. Camera Battery LED
On when AC power is connected
to camera.
Flashes when the battery level of
the camera is low.
7. POWER ON/OFF switch
8. Temperature Sensor
9. Power Adapter Outlet
10. PAIR Button
11. Speaker
12. Star Grip or Tripod Mount
13. Antenna
Overview of your Camera
1
2
3
4
5
6
78
9
10
11
12
13
Important guidelines for installing your Wi-Fi®Camera Unit
• Use of other 2.4 GHz products, such as other wireless networks, Bluetooth®
systems or microwave ovens may cause interference with this product. Keep
the Wi-Fi®Camera Unit away from these types of products, or turn them off if
they appear to be causing interference.
• Always ensure that you have a good Wi-Fi®connection available.

4Table of contents
Table of contents
1. Safety Instructions..................................................................................... 5
2. System Requirements ............................................................................... 8
3. Getting started - Connecting Devices......................................................9
3.1 Power up the Camera Unit ......................................................................... 9
3.2 User Account and Camera Setup on Android™ Devices....................... 11
3.2.1 Power ON and Connect the Camera ...................................... 11
3.2.2 Download Hubble for Motorola Monitors App ........................ 11
3.2.3 Run Hubble for Motorola Monitors App on Android™
Devices ...................................................................................... 11
3.2.4 Add the Camera to your account ............................................. 12
3.3 User Account and Camera Setup on iPhone®/iPad®............................ 15
3.3.1 Power ON and Connect the Camera ...................................... 15
3.3.2 Download Hubble for Motorola Monitors App ........................ 15
3.3.3 Run Hubble for Motorola Monitors App on iPhone®/iPad®... 15
3.3.4 Add the Camera to your account ............................................. 16
4. Camera Functions:.................................................................................. 21
4.1 Connecting the Camera Unit to power ................................................... 21
4.2 Overview of the Features on Hubble App ............................................... 21
5. Working with PC/Notebook................................................................... 24
6. Procedure for Resetting the Camera......................................................25
7. Help.......................................................................................................... 26
8. General Information ................................................................................ 32
9. Technical Specifications ......................................................................... 38

Safety Instructions 5
ENGLISH
1. Safety Instructions
WARNING :
Strangulation Hazard: Children have
STRANGLED in cords. Keep this cord
out of the reach of children (more than
3ft (1m) away). Never use extension
cords with AC Adapters. Only use the
AC Adapters provided
.

6Safety Instructions
Wi-Fi®CAMERA UNIT SET UP & USE:
• Choose a location for the Wi-Fi®Camera Unit that will provide the best
view of your baby in the crib.
• Place
the Wi-Fi®Camera Unit on a flat surface, such as a chest of
drawers, desk, shelf or mount the Unit securely using the Star Grip or
Tripod mount screw hole on the underside of the stand.
• NEVER place the Wi-Fi®Camera Unit or cords within the crib.

Safety Instructions 7
ENGLISH
WARNING
This Wi-Fi®Camera Unit is compliant with all relevant electromagnetic field
standards and is, when handled as described in the User's Guide, safe to use.
Therefore, always read the instructions in this User's Guide carefully before
using the device.
• Adult assembly is required due to small parts. Keep all small parts away from
children.
• This product is not a toy. Do not allow children to play with it.
• This Wi-Fi®Camera Unit is not a substitute for responsible adult supervision.
• Keep this User’s Guide for future reference.
• Do not cover the Wi-Fi®Camera Unit with a towel or blanket.
• Test the Wi-Fi®Camera Unit and all its functions so that you are familiar with
it prior to use.
• Do not use the Wi-Fi®Camera Unit near water.
• Do not place the Wi-Fi®Camera Unit near a heat source.
• Do not touch the plug contacts with sharp or metal objects.

8System Requirements
2. System Requirements
Web Portal
• Windows®7
• Mac OS®10.7
• Chrome™ 24
• Internet Explorer®9
• Safari®6
• Java™ 7
• Firefox®18.0
• Adobe®Flash®Player 15.0
Android™System
• Version 4.2 or above
iPhone®/iPad®iOS
• Version 7.0 or above
High Speed (Wi-Fi®) Internet
• At least 0.6 Mbps upload bandwidth per camera (you can test your internet
speed on this site: http://www.speedtest.net)

Getting started - Connecting Devices 9
ENGLISH
3. Getting started - Connecting Devices
How does it work?
When a user tries to access the Camera, our secure server authenticates the
user’s identity and permits access to the Camera.
3.1 Power up the Camera Unit
•Connect the micro USB plug of the power adapter to the Camera Unit and
the other end to an electrical outlet.
• Slide the POWER ON/OFF switch to the ON position to turn the Camera
Unit on.
• The Camera must be within range of the Wi-Fi®router with which you want
to connect. Make sure the password of the router is available for entering
during the in-app setup process.
MBP88CONNECT Wi-Fi Router
Hubble
Service
Access your
Camera locally. View your Camera from any
compatible device remotely.

10 Getting started - Connecting Devices
IMPORTANT
The Baby Unit is able to operate without mains power for up to 3 hours with the
support of the built-in rechargeable battery (Ni-MH battery 2.4V, 900mAh).
Please charge the unit for at least 16 hours before first time use. The battery is
not a user-accessible item. Please contact the helpline if you think it needs
replacing.
Behavior of the status Indicator LED:
Pairing and setting up Flashes slowly in red and blue
Connected Flashes slowly in blue
Paired but not connected Lights up in blue
Ready for connection Flashes slowly in blue
NOTE
Only use the enclosed Power Adapter (5V DC / 1500mA).
You can only setup via a compatible smartphone or tablet, and not via a PC.

Getting started - Connecting Devices 11
ENGLISH
Android™
3.2 User Account and Camera Setup on Android™ Devices
What you need
• MBP88CONNECT Camera
• Power adapter for the Camera
• Device with AndroidTM system version 4.2 and above
3.2.1 Power ON and Connect the Camera
• Connect the power adapter to an electrical outlet and insert the plug into the
micro USB socket on the back of the Camera Unit.
• Make sure that the ON/OFF switch is in the ON position.
• The Camera’s Red LED flashes after the Camera has finished booting. When
you hear one beep, this means that the Camera is ready for setup.
3.2.2 Download Hubble for Motorola Monitors App
• Go to Google Play™ Store to search for "Hubble for Motorola Monitors".
• Download "Hubble for Motorola Monitors" App from Google Play™ Store
and install it on your Android™ device
3.2.3 Run Hubble for Motorola Monitors App on Android™ Devices
• Ensure that your Android™ device is connected to your Wi-Fi®router.
• Run "Hubble for Motorola Monitors" App, enter your account information,
read through the Terms of Service, then select "I agree to the Terms of Use"
before you tap
Create . (Picture A1)
Note
If you already have a Hubble App account, please select Already have an
Account? to go to the next step.
A1

12 Getting started - Connecting Devices
3.2.4 Add the Camera to your account
• Tap on the top right corner of the screen to add camera. (Picture A2)
• The following setup instructions will appear on the screen. (Picture A3)
• Plug in and switch on the camera, and wait for a couple of minutes for it to
warm up.
• Tap
Continue when the Camera LED starts to blink.
A2
A3

Getting started - Connecting Devices 13
ENGLISH
Android™
• The following setup instructions will appear on the screen. (Picture A4)
• Press and hold the
PAIR button on the bottom of the Camera Unit for 3
seconds. You will then hear a beep tone, followed by a voice prompt
indicating that the Camera is ready for pairing.
• Tap
Continue .
• The App will automatically search for and connect to your Camera as shown
in the pictures below. (Pictures A5, A6)
• The blue/red colour LED on the Camera Unit will flash.
A4
A5 A6

14 Getting started - Connecting Devices
• Select your Wi-Fi®Network, enter your password and then tap Connect .
(Pictures A7, A8)
• It will take a few minutes for the Camera to connect to the Wi-Fi®network
before showing the connection status. (Pictures A9, A10)
• If connection fails, please tap
Retry and repeat the steps starting from 3.2.4.
• Tap
View Camera to view the video captured by the Camera Unit. The status
indicator LED on the Camera Unit will flash in red/blue.
A7 A8
A9 A10

Getting started - Connecting Devices 15
ENGLISH
iOS®
3.3 User Account and Camera Setup on iPhone
®
/iPad
®
What you need
• MBP88CONNECT Camera
• Power adapter for the Camera
• iPhone®/ iPad®with iOS version 7.0 and above
3.3.1 Power ON and Connect the Camera
• Connect the power adapter to an electrical outlet and insert the plug into the
micro USB socket at the back of the Camera.
• Make sure that the ON/OFF switch is in the ON position.
• The Camera's red LED flashes after the Camera has finished booting. When
you hear one beep, this means that the Camera is ready for setup.
3.3.2 Download Hubble for Motorola Monitors App
• Go to App Store to search for "Hubble for Motorola Monitors".
• Download "Hubble for Motorola Monitors" App and install it on your iPhone
®
/iPad
®
.
3.3.3 Run Hubble for Motorola Monitors App on iPhone®/iPad®
• Ensure that your iPhone®/iPad®is connected to your Wi-Fi®Router.
• Run the "Hubble for Motorola Monitors" App, enter your account
information, read through the Terms of Service, and then select "I agree to
the Terms of Service" before you tap
Create . (Picture i1)
Note:
If you already have a Hubble App account, please select Already have an
Account? to go to the next step (Picture i1).
i1

16 Getting started - Connecting Devices
3.3.4 Add the Camera to your account
• Tap on the top right corner of the screen to add camera. (Picture i2)
• The following Bluetooth setup instructions will appear on the screen. (Picture
i3)
i2
i3

Getting started - Connecting Devices 17
ENGLISH
iOS®
• Tap Settings and activate Bluetooth on your iPhone®/iPad®(Pictures i4,i5).
• Press the HOME key to return to the home screen, then tap on "Hubble for
Motorola Monitors" App to resume setup.
• The following setup instructions will appear on the screen. (Picture i6)
Note that if Bluetooth is on, you will be brought to this step directly.
• Wait for a couple of minutes for the Camera Unit to warm up and tap
Continue when the Camera LED indicator starts to blink.
i4 i5
i6

18 Getting started - Connecting Devices
• The following will appear on the screen. (Pictures i7, i8)
• Name the location of your Camera Unit and tap
Continue . (Pictures i9, i10)
i7 i8
i9 i10

Getting started - Connecting Devices 19
ENGLISH
iOS®
• The Camera Unit will search for the Wi-Fi®network (Picture i11) and display
a list of available networks. (Picture i12)
• Select your Wi-Fi®network and tap
Continue . (Picture i13)
• Enter your Wi-Fi®password and tap
Next . (Picture i14)
• It will take a few minutes for the Camera Unit to connect to the Wi-Fi®
network before showing the connection status. (Pictures i15, i16)
i11 i12
i13 i14

20 Getting started - Connecting Devices
• If connection fails, tap Retry and repeat the steps starting from 3.3.4.
• Tap
View Live Camera to view the video captured by the Camera Unit. The
LED indicator on the Camera Unit will light up in blue.
i15 i16
