GENERAL
GENERAL
The following provides advisory and caution-
ary instructions to users of GSM mobile
stations regarding their own and third party
safety.
ELECTRICAL SAFETY
ELECTRICAL SAFETY
This apparatus is intended for use when
supplied with power from:
Battery Chargers:
SLN9347 + SPN4161A or SPN4069A
SLN5039 + SPN4181A or SPN4030A
Battery Savers:
SKN4292, SKN4519
Car Kits/Vehicular Chargers:
S3060, S3284, S3285, S2461, S1759, S1758,
S3512A
Other usage will invalidate any approval given
to this apparatus and may be dangerous.
AIRCRAFT SAFETY
AIRCRAFT SAFETY
Switch off your cellular telephone when in an
aircraft. The use of cellular telephones in an
aircraft may be dangerous to the operation of
the aircraft, disrupt the cellular network and is
illegal. Failure to observe this instruction may
lead to suspension or denial of cellular
telephone services to the offender, or legal
action or both.

SAFETY FIRST
EXPLOSIVE ATMOSPHERES
EXPLOSIVE ATMOSPHERES
• Users are advised not to use the
equipment when at a refuelling point.
• Users are reminded of the need to observe
restrictions on the use of radio equipment
in fuel depots, chemical plants or where
blasting operations are in progress.
ROAD SAFETY
ROAD SAFETY
• The use of the Alert device to operate a
vehicle's lights or horn on public roads is
not permitted.
• It is advised that a hand-held microphone
or telephone handset should not be used
by the driver while the vehicle is moving,
except in an emergency. Speak only into
a fixed, neck slung or clipped-on micro-
phone when it would not distract your
attention from the road.
USAGE INSIDE A VEHICLE
USAGE INSIDE A VEHICLE
If operating a cellular telephone inside the
vehicle without utilizing an external antenna,
the functionality of inadequately shielded
equipment (such as antilock braking and fuel
injection systems, etc.) in your vehicle may be
impaired.
Consult your vehicle owner's manual or ask
your automobile dealer if you have questions
about your vehicle.

MEDICAL ELECTRONICS
MEDICAL ELECTRONICS
Operation of any radio transmitting equip-
ment, including cellular telephones, may
interfere with the functionality of inadequately
shielded medical devices (such as pacemak-
ers, hearing aids, etc.) Consult your physi-
cian or ask the manufacturer of the medical
device if you have questions.

SAFETY FIRST
MANUAL UPDATES
MANUAL UPDATES
No user manual updates at this time.

1
Page 5
INTRODUCTION
INTRODUCTION
This cellular telephone is designed for the
GSM System. Using this phone makes it
possible to contact any phone in the world,
provided you are in an area covered by the
GSM system.
The cellular telephone does not contain your
GSM-subscriber number, this information is
contained on your SIM card supplied by your
local service provider. All billing will be
registered, when the conversation takes
place, to the subscriber number on the SIM
card which is inserted in the phone.
Instruction sequences shown in this manual
are presented in the following format:
This format indicates that you should press
the key and then the key (one, then
the other, not simultaneously).
For your protection, some features require a
6-digit security code.
• Your security code is initially set to
'000000'. To program a unique security
code, please see section, 'Changing the
Security Code.'

1ESSENTIAL INFORMATION
Page 6
Telephone Overview
Telephone Overview
See flap at the front page.
Display
Display
Thedisplayand keypad are backlit wheneverthe
telephoneisswitchedon. Afterseveral seconds,
theback lighting will turnoff.
Pressing anykeywillreturnthebacklighting.
1. Displays the entered telephone number or
alphamessage. Thefollowing indicators may
alsoappearinthedisplay:
Power on
Stayslitwhilethephoneison.
In Use
Symbollightswhenacallisinprogress.
No Service
Fixed symbol: Youareoutofcellularsystem
coverage andcannotmakecalls.
Flashing: Youareinanareawithcoverage
butnotregisteredon the system. You can
makeemergencycallsusingthespecialGSM
emergencynumber, 112, butcannot make/
receiveordinarycalls.
Roam
FixedSymbol: Youareregisteredona
preferredsystemdifferentfromyourhome
system.
Flashing: Youareregisteredonanon-
preferredsystem.

1
Page 7
Signal Strength
Themore segments displayedin the bar
graph,thebetterthesignalstrengthandcall
quality.
BatteryLevel
Fixedsymbol: Batterychargelevelis
sufficientfornormaloperation.
Slowflash: Warning! Battery charge level
becoming low.
Rapidflash: Batterychargelevelisnearly
depleted. Replaceorrechargebattery.
ShortMessageService
Theshortmessagefeatureisnotavailableonthis
model. Thisphonecannotbeupgradedtosupport
thisfeature.
ColdTemperatureNote
Thisphoneisequippedwiththelatestindisplay
technology. This"supertwist" liquidcrystaldisplay
(LCD)providessuperiorperformance,viewing
angleandviewingcontrast over previous LCD
technologies. Atextremelycoldtemperatures,it is
normal forthedisplay to respond moreslowlyto
keypresses. When entering numbers under
these circumstances, the audible tones will
still indicate that a key has been depressed
and the visual indication will follow shortly.

1ESSENTIAL INFORMATION
Page 8
Volume Keys
Volume Keys
2. The push buttons on the right side of
the phone adjust the earpiece and
ringer volume levels. Press the top
button to increase, or the bottom button
to decrease the volume level.
To adjust earpiece volume:
Operate the volume buttons with the phone
held to your ear.
To adjust ring alert volume:
Operate the volume buttons to the
desired volume level for the ring tone of
incoming calls.
SIM Card Release
SIM Card Slide
3. To remove SIM card, slide button down,
then pull SIM card out.
Keypad
Keypad
4. Press to turn phone on or off.
5. Press to make and receive calls.
6. Press to end calls.
7. Use to store numbers and names
into memory.
8. Use to recall numbers and names
from memory.

1
Page 9
9.
Microphone mute
Switches microphone off/on during
conversation.
Select by pressing
Secondary features
Use in sequence with other keys to
initiate features.
10. Letter entry (a):
Use to store and recall phone numbers
with names.
Clear (c):
Clears the display. Press and release
to clear last digit. Press and hold to
clear entire display.
11. Menu:
Use to initiate menu features
Short Message Service ( ):
The short message feature is not
available on this model. This phone
cannot be upgraded to support this
feature.
12. Press to move forward and
backward through memory locations
and feature menus.
13. Flip The flip can be used to answer
and end calls.

1ESSENTIAL INFORMATION
Page 10
BASIC OPERATION
BASIC OPERATION
Yournetworkserviceprovidersuppliedyouwitha
subscription card knownas aSubscriberIdentitiy
ModulecardorSIM card. TheSIMcardisyour
keytoaccessingGSMservicesandcontainsthe
followingpersonaldata:
•subscriber number
•home system
•services subscribed to
•PIN and unblocking codes
Your valid SIM card must be correctly inserted
into the phone's card reader to access
services.

1
Page 11
Inserting the SIM Card
Inserting the SIM Card
Insert the SIM card into the phone's card
reader either before or after turning the phone
on.
If the SIM card is missing, 'Insert Card'
will appear in the phone's display.
If the SIM card is damaged or not cor-
rectly inserted, (e.g. inserted upside down
or backwards) 'Check Card' will appear in the
display. Check for proper orientation and re-
insert the SIM card.
To remove SIM card, slide SIM card release
button down, then pull SIM card out.

1ESSENTIAL INFORMATION
Page 12
Switch Phone On/Off
Switch Phone On/Off
Switch on:
If the SIM card is not inserted the display will
prompt you to do so. The telephone then
checks the validity of the SIM card.
If 'Enter PIN' appears in the display, the SIM
card is protected by a PIN code.
PIN code
FormoreinformationonPINcodes,seesection,
"EnteringthePINCode".
If'EnterUnlockCode'appearsinthedisplay,the
phoneis protectedbyanelectroniclock.
unlock code
For more information on lock features, see
section, "Electronic Lock".
If 'Blocked' appears in the display, your SIM
card is blocked from use. Please see section,
"Unblocking the SIM card".
If'BadCard'or'Blocked'then'See Supplier'
appearsinthedisplay,aproblem exists withyour
SIMcard. Pleaseseek helpfromyourservice
provider.
Switch off:

1
Page 13
Entering the PIN Code
Entering the PIN Code
YourPersonalIdentificationNumber(PIN)isa4-8
digitcodethat protects your SIMcard from
unauthoriseduse.
ThefirstPINcodeisselectedbytheSIMprovider.
TochangeordisablethePIN code, see sections,
"ChangingthePINCode" or"PINCodeEnable/
Disable".
Whenthe SIMcard is protectedby aPIN code,
'EnterPIN'appearsinthedisplay wheneverthe
phoneis switched on or the SIM card is inserted.
PIN code
ThePINcodewillappearas
*
*
*
*
*
*
If you make a mistake while entering the PIN
code,
If the PIN code is accepted, 'OK' will appear
in the display.
If the PIN code is not accepted, 'Wrong PIN'
then 'Enter PIN' will appear in the display.
Re-enter PIN code.
If you do not succeed after three attempts,
'Blocked' will appear in the display. The SIM
card is blocked from further use. To unblock
the SIM card, see section, "Unblocking the
SIM card".

1ESSENTIAL INFORMATION
Page 14
Making Calls
Making Calls
The indicator must be off.
Telephone number
Phone numbers up to 20 digits long may be
dialled.
If a call is temporarily interrupted, 'Retrying'
may appear in the display. The system will
automatically reconnect the call if possible.
Dialling Errors
Dialling Errors
To erase last digit:
To erase entire display: and hold
Ending Calls
Ending Calls
Either or close the "flip".
To retry if number is busy:
Receiving Calls
Receiving Calls
Your phone must be on, unlocked, and in
service.
To answer calls:
or open the "flip".
To stop alert signal without answering:

1
Page 15
Automatic Redial
Automatic Redial
Before ending an unsuccessful call attempt:
'Redial' will appear in the display.
Your phone will continuously attempt to
complete the call until the redial procedure
times out. When the call is successful, your
phone will ring once to alert you.
To cancel: or turn the phone off.
International Calls
International Calls
Justliketheordinary telephonesystem, youmust
addan international prefix before diallingthe
country prefix andthe telephone number. This
featureautomaticallyaddstheinternationalprefix.
To select:
(display shows '+')
country prefix, telephone number
It is possible to store the sequence
into memory and still have the maximum of 20
digits.

1ESSENTIAL INFORMATION
Page 16
GSM Emergency Calls
GSM Emergency Calls
To dial the GSM emergency number, 112:
This call may be initiated with or without a
SIM card inserted and despite electronic lock
activation or PIN protection. The call is
directed to a central emergency operator as
long as the indicator is either flashing or
off.

1
Page 17
Storing Telephone Nos. into Memory
Storing Telephone Nos. into Memory
Yourphonecanstoreupto100telephone
numbersandnames. Each memorylocation can
holdanumber up to 20 digits long and a name up
to16characterslong. Thephone's memory
locationsarelabelledfrom1to100.
Additionally,yourSIMcardmayalsostore
telephonenumbers. Pleasecontactyourcard
provider fordetails. SIMcardmemory locations
arelabelled101andup.
To store phone number with name:
Enter person's name.
To enter names, the characters on the
number keys are used.
For example,
to enter character 'N'.
and hold down.
Display shows: M-N-0-5-M-N
Release key when desired character
appears.
To advance to the next position, either
press a new key or press
Repeatprocedurefor the next character.
Youcouldhavealsoselectedthecharacter
'N'bypressing repeatedly.
To correct mistakes:
When name is complete:

1ESSENTIAL INFORMATION
Page 18
Next,
phone number
memory location number
(1-100 or 101 and up for SIM card
locations)
To store phone number without name:
phone number memory location
number (1-100 or 101 and up for SIM
card locations)
The name (if entered) and phone number will
be stored in the selected memory location. If
the selected memory location is already
occupied, 'In Use' will appear in the display;
new memory location number.
If all memory locations are filled, 'Full' will
appear in the display.
If you have no preference for a memory
location number:
as the memory location number.
The phone number and name will be stored in
the next available memory location.
If you desire a memory location in a particular
decade like 50-59:
as memory location
number.
