ROKR E2
GSM
C over.Print.Front.UG.landscape-ROKRE2.UG.fm Page 1 W ednesday,October26,2005 4:33 PM

1
HELLOMOTO
Introducing your new Motorola ROKR E2 GSM wireless phone. Here’s a quick anatomy lesson.
Scroll up,
down, left,
or right.
Press in to
select.
Right Soft
Key
Voice Key
Clear/Back
Key
Turn on &
off, hang up,
exit menus.
Left Soft Key
Volume Keys
Charge up or
connect.
Play music.
Lock keypad.
Go
handsfree.
Make &
answer calls.

2
Main Menu
Options Back
Options Main Menu
Service Provider 10:15
Contacts
Settings
Web Access
IM
Office Tools
Multimedia
Messages
Recent Calls
Browser
Home Screen Main Menu
Press and hold the
Power Key u for a few
seconds to turn on your
phone.
1
Press the Navigation Key up, down, left, or right ( S ) to
highlight a menu feature.
Press the Navigation Key
in ( s ) to select it.
3
Press the Main Menu
soft key to open the
Main Menu .
2

3
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
Certain mobile phone features are dependent on the
capabilities and settings of your service provider’s
network. Additionally, certain features may not be
activated by your service provider, and/or the
provider's network settings may limit the feature’s
functionality. Always contact your service provider
about feature availability and functionality. All
features, functionality, and other product
specifications, as well as the information contained
in this user's guide are based upon the latest
available information and are believed to be accurate
at the time of printing. Motorola reserves the right to
change or modify any information or specifications
without notice or obligation.
MOTOROLA and the Stylized M Logo are registered
in the US Patent & Trademark Office. All other
product or service names are the property of their
respective owners. The Bluetooth trademarks are
owned by their proprietor and used by Motorola, Inc.
under license. Java and all other Java-based marks
are trademarks or registered trademarks of Sun
Microsystems, Inc. in the U.S. and other countries.
Microsoft, Windows and Windows Me are registered
trademarks of Microsoft Corporation; and Windows
XP is a trademark of Microsoft Corporation.
© Motorola, Inc., 2005.
Caution: Changes or modifications made in the radio
phone, not expressly approved by Motorola, will void
the user’s authority to operate the equipment.
Software Copyright Notice
The Motorola products described in this manual may
include copyrighted Motorola and third-party
software stored in semiconductor memories or other
media. Laws in the United States and other countries
preserve for Motorola and third-party software
providers certain exclusive rights for copyrighted
software, such as the exclusive rights to distribute or

4
reproduce the copyrighted software. Accordingly, any
copyrighted software contained in the Motorola
products may not be modified, reverse-engineered,
distributed, or reproduced in any manner to the
extent allowed by law. Furthermore, the purchase of
the Motorola products shall not be deemed to grant
either directly or by implication, estoppel, or
otherwise, any license under the copyrights, patents,
or patent applications of Motorola or any third-party
software provider, except for the normal,
non-exclusive, royalty-free license to use that arises
by operation of law in the sale of a product.
Manual Number: 68XXXXX119-O

5
contents
contents
menu map. . . . . . . . . . . . 7
Safety Information . . . . . 9
Use and Care . . . . . . . . 15
EU Conformance . . . . . 16
Recycling Information . 17
essentials . . . . . . . . . . . 18
about this guide . . . . . 18
SIM card. . . . . . . . . . . 18
battery . . . . . . . . . . . . 20
turn it on & off . . . . . . 22
make a call . . . . . . . . . 22
answer a call. . . . . . . . 22
store a phone number in
the contact list . . . . . . 22
call a stored phone
number. . . . . . . . . . . . 23
your phone number . . 23
main attractions . . . . . . 25
audio player . . . . . . . . 25
FM radio . . . . . . . . . . . 29
airplane mode. . . . . . . 30
memory card . . . . . . . 31
voice commands . . . . 34
photos . . . . . . . . . . . . 36
video clips. . . . . . . . . . 38
Bluetooth® wireless. . 40
synchronize phone
information . . . . . . . . . 44
basics. . . . . . . . . . . . . . . 48
display . . . . . . . . . . . . 48
text entry . . . . . . . . . . 51
volume . . . . . . . . . . . . 54
handsfree speaker . . . 54
codes & passwords . . 55
lock & unlock phone . . 55
lock & unlock keypad . 56
customize . . . . . . . . . . . 57
profiles . . . . . . . . . . . . 57
time & date. . . . . . . . . 58
themes . . . . . . . . . . . . 58
display appearance . . . 59
answer options. . . . . . 60
calls . . . . . . . . . . . . . . . . 61
turn off a call alert . . . . 61
recent calls . . . . . . . . . 61
redial. . . . . . . . . . . . . . 62
return a call . . . . . . . . . 62
hold or mute a call . . . 63
call waiting . . . . . . . . . 63
caller ID . . . . . . . . . . . 63
emergency calls . . . . . 64
international calls . . . . 64
speed dial . . . . . . . . . . 64

6
contents
voicemail . . . . . . . . . . . 65
other features . . . . . . . . 66
advanced calling . . . . . 66
contacts. . . . . . . . . . . . 68
messages . . . . . . . . . . 73
instant messaging . . . . 75
personalize . . . . . . . . . 76
call times & costs . . . . 79
handsfree . . . . . . . . . . 80
data & fax calls . . . . . . 81
network . . . . . . . . . . . . 82
personal organizer . . . . 82
security . . . . . . . . . . . . 86
fun & games . . . . . . . . 86
service and repairs . . . . 89
SAR Data . . . . . . . . . . . . 90
Warranty. . . . . . . . . . . . . 92
WHO Information . . . . . 98
index. . . . . . . . . . . . . . . . 99

7
menu map
menu map
main menu
n Contacts
e Messages
• Create Message
•Inbox
• My Folder
• Templates
•Drafts
• Outbox
• Create Postcard
• Send Online Storage *
•IM*
•Email
• Call Voicemail
ã IM
á Web Access
•Browser
• Web Shortcuts
• Stored Pages
•History
• Go To Page
• Browser Setup
• Web Sessions *
h Multimedia
• Voice Recorder
•Camera
•VideoCamera
•Games
•FMRadio
• Media Player
w Settings
• (see next page)
s Recent Calls
Tip: Press # to change the
main menu to a list view and
back. For feature help, press
the
Main Menu key
>
ÉOffice Tools > Help .
É Office Tools
•Help
•MOTOSYNC
•Calculator
• Modem
• Calendar
• World Clock
• Customer Services *
•AlarmClock
• Bluetooth
• Task List
• File Manager
• Download Manager
•Email
• Notepad
• Dialing Services
•FixedDial
• Service Dial *
This is the standard main
menu layout.
Your phone’s
menu may be different.
* optional features

8
menu map
settings menu
•Profiles
•Normal
•Vibrate
• Silent
• Meeting
• Airplane Mode
• Sleeping
•Active
•Car
• Phone Settings
• Display Settings
• Backlight Timeout
• Display Timeout
• Screensaver Timeout
• Brightness
•BatteryMeter
•BatterySave
•Time&Date
• Language
• Talking Phone
•TextEntry
•Reset
• Reset All Settings
• Delete All Data
• Delete Memory Cards
• Properties
• Java System
• Software Update
• Headset Settings
• Auto-Answer
•VoiceDial
• TTY Settings
•Network
• Current Network
• Scan Available Networks
• Search For New Network
•MyNetworkList
• Search Setup
• Service Tone
• Call Settings
• Speed Dial
•CallForward
•In-CallSetup
•MyCallerID
• Call Waiting
• In-Call Message Alert
• In-Call Timer
• Answer Options
• Auto Redial
•RoamAlert
•DTMF
• Fixed Dialing
• Call Drop Tone
• My SIM Number
• Themes
• Data Connections
• Add New Connection
• Edit Existing Connection
• Remove Connection
• Connections
• Bluetooth
• Modem
• USB Settings
• Data Connections
•Security
• Phone Lock
• Application Lock
•SIMPINLock
• Change Passwords
Tip: You can press number
keys to select options that
have numbers next to them.
This is the standard main
menu layout.
Your phone’s
menu may be different.
* optional features

9
Safety Information
Safety and General Information
Safet y Info rma tion
This section contains important information on
the safe and efficient operation of your mobile
device. Read this information before using your
mobile device.
*
Exposure To Radio Frequency
(RF) Energy
Your mobile device contains a transmitter and
receiver. When it is ON, it receives and transmits RF
energy. When you communicate with your mobile
device, the system handling your call controls the
power level at which your mobile device transmits.
Your Motorola mobile device is designed to comply
with local regulatory requirements in your country
concerning exposure of human beings to RF energy.
Operational Precautions
For optimal mobile device performance and to be
sure that human exposure to RF energy does not
exceed the guidelines set forth in the relevant
standards, always follow these instructions and
precautions.
External Antenna Care
If your mobile device has an external antenna, use
only a Motorola-supplied or approved replacement
antenna. Use of unauthorized antennas,
modifications, or attachments could damage the
mobile device and/or may result in your device not
* The information provided in this document supersedes
the general safety information in user’s guides
published prior to September 1, 2005.

10
Safety Information
complying with local regulatory requirements in your
country.
DO NOT hold the external antenna when the mobile
device is IN USE. Holding the external antenna
affects call quality and may cause the mobile device
to operate at a higher power level than needed.
Product Operation
When placing or receiving a phone call, hold your
mobile device just like you would a landline phone.
If you wear the mobile device on your body, always
place the mobile device in a Motorola-supplied or
approved clip, holder, holster, case, or body harness.
If you do not use a body-worn accessory supplied or
approved by Motorola, keep the mobile device and its
antenna at least 2.5 centimeters (1 inch) from your
body when transmitting.
When using any data feature of the mobile device,
with or without an accessory cable, position the
mobile device and its antenna at least
2.5 centimeters (1 inch) from your body.
Using accessories not supplied or approved by
Motorola may cause your mobile device to exceed RF
energy exposure guidelines. For a list of
Motorola-supplied or approved accessories, visit our
website at
www.motorola.com .
RF Energy
Interference/Compatibility
Nearly every electronic device is subject to RF energy
interference from external sources if inadequately
shielded, designed, or otherwise configured for RF
energy compatibility. In some circumstances your
mobile device may cause interference with other
devices.
This device complies with Part 15 of the FCC Rules.
Operation is subject to the following two conditions:
(1) this device may not cause harmful interference,
and (2) this device must accept any interference
received, including interference that may cause
undesired operation.

11
Safety Information
Follow Instructions to Avoid
Interference Problems
Turn off your mobile device in any location where
posted notices instruct you to do so. These locations
include hospitals or health care facilities that may be
using equipment that is sensitive to external RF
energy.
In an aircraft, turn off your mobile device whenever
instructed to do so by airline staff. If your mobile
device offers an airplane mode or similar feature,
consult airline staff about using it in flight.
Pacemakers
If you have a pacemaker, consult your physician
before using this device.
Persons with pacemakers should observe the
following precautions:
• ALWAYS keep the mobile device more than
20 centimeters (8 inches) from your
pacemaker when the mobile device is turned
ON.
• DO NOT carry the mobile device in the breast
pocket.
• Use the ear opposite the pacemaker to
minimize the potential for interference.
• Turn OFF the mobile device immediately if
you have any reason to suspect that
interference is taking place.
Hearing Aids
Some digital mobile devices may interfere with some
hearing aids. In the event of such interference, you
may want to consult your hearing aid manufacturer or
physician to discuss alternatives.
Other Medical Devices
If you use any other personal medical device, consult
your physician or the manufacturer of your device to
determine if it is adequately shielded from RF energy.

12
Safety Information
Driving Precautions
Check the laws and regulations on the use of mobile
devices in the area where you drive. Always obey
them.
When using your mobile device while driving, please:
• Give full attention to driving and to the road.
Using a mobile device may be distracting.
Discontinue a call if you can’t concentrate on
driving.
• Use handsfree operation, if available.
• Pull off the road and park before making or
answering a call if driving conditions so
require.
Responsible driving practices can be found in the
“Smart Practices While Driving” section at the end of
this guide and/or at the Motorola website:
www.motorola.com/callsmart .
Operational Warnings
Obey all posted signs when using mobile devices in
public areas, such as health care facilities or blasting
areas.
Automobile Air Bags
Do not place a mobile device in the air bag
deployment area.
Potentially Explosive Atmospheres
Areas with potentially explosive atmospheres are
often but not always posted, and can include fueling
areas such as below decks on boats, fuel or chemical
transfer or storage facilities, or areas where the air
contains chemicals or particles, such as grain, dust,
or metal powders.
When you are in such an area, turn off your mobile
device, and do not remove, install, or charge
batteries. In such areas, sparks can occur and cause
an explosion or fire.

13
Safety Information
Damaged Products
If your mobile device or battery has been submerged
in water, punctured, or subjected to a severe fall, do
not use it until you take it to a Motorola Authorized
Service Center. Do not attempt to dry it with an
external heat source, such as a microwave oven.
Batteries and Chargers
If jewelry, keys, beaded chains, or other conductive
materials touch exposed battery terminals, this could
complete an electrical circuit (short circuit), become
very hot, and could cause damage or injury. Be
careful when handling a charged battery, particularly
when placing it inside a pocket, purse, or other
container with metal objects.
Use only
Motorola Original ™ batteries and chargers.
Caution:
To avoid risk of personal injury, do not
dispose of your battery in a fire.
Your battery, charger, or mobile device may contain
symbols, defined as follows:
Choking Hazards
Your mobile device or its accessories may include
detachable parts, which may present a choking
hazard to small children. Keep your mobile device
and its accessories away from small children.
Symbol Definition
Important safety information
follows.
Do not dispose of your battery or
mobile device in a fire.
Your battery or mobile device may
require recycling in accordance
with local laws. Contact your local
regulatory authorities for more
information.
Do not throw your battery or
mobile device in the trash.
Your mobile device contains an
internal lithium ion battery.
032374o
032376o
032375o
032377o
032378o
Li Ion BATT

14
Safety Information
Glass Parts
Some parts of your mobile device may be made of
glass. This glass could break if the product is dropped
on a hard surface or receives a substantial impact. If
glass breaks, do not touch or attempt to remove. Stop
using your mobile device until the glass is replaced
by a qualified service center.
Seizures/Blackouts
Some people may be susceptible to epileptic seizures
or blackouts when exposed to flashing lights, such as
when playing video games. These may occur even if
a person has never had a previous seizure or
blackout.
If you have experienced seizures or blackouts, or if
you have a family history of such occurrences, please
consult with your physician before playing video
games or enabling a flashing-lights feature (if
available) on your mobile device.
Discontinue use and consult a physician if any of the
following symptoms occur: convulsion, eye or muscle
twitching, loss of awareness, involuntary
movements, or disorientation. It is always a good
idea to hold the screen away from your eyes, leave
the lights on in the room, take a 15-minute break
every hour, and stop use if you are very tired.
Repetitive Motion
When you repetitively perform actions such as
pressing keys or entering finger-written characters,
you may experience occasional discomfort in your
hands, arms, shoulders, neck, or other parts of your
body. If you continue to have discomfort during or
after such use, stop use and see a physician.

15
Use and Care
Use and Care
Use and Care
To care for your Motorola phone, please keep it away from:
liquids of any kind dust and dirt
Don’t expose your phone to water,
rain, extreme humidity, sweat, or
other moisture.
Don’t expose your phone to dust, dirt,
sand, food, or other inappropriate
materials.
extreme heat or cold cleaning solutions
Avoid temperatures below
-10°C/14°F or above 45°C/113°F.
To clean your phone, use only a dry
soft cloth. Don’t use alcohol or other
cleaning solutions.
microwaves the ground
Don’t try to dry your phone in a
microwave oven.
Don’t drop your phone.

16
EU Conformance
European Union Directives Conformance
Statement
EU Conformance
Hereby, Motorola declares that this
product is in compliance with
• The essential requirements and other
relevant provisions of Directive 1999/5/EC
• All other relevant EU Directives
The above gives an example of a typical Product
Approval Number.
You can view your product’s Declaration of
Conformity (DoC) to Directive 1999/5/EC (to R&TTE
Directive) at www.motorola.com/rtte. To find your
DoC, enter the product Approval Number from your
product’s label in the “Search” bar on the web site.

17
Recycling Information
Recycling Information
Caring for the Environment by Recycling
When you see this symbol on a Motorola
product, do not dispose the product with
household waste.
Recycling Mobile Phones and Accessories
Do not dispose of mobile phones or electrical
accessories, such as chargers or headsets, with your
household waste. In some countries or regions,
collection systems are set up to handle electrical and
electronic waste items. Contact your regional
authorities for more details. If collection systems
aren’t available, return unwanted mobile phones or
electrical accessories to any Motorola Approved
Service Centre in your region.

18
essentials
essentials
about this guide
This guide shows how to locate a menu
feature as follows:
Find it: Press Main Menu > ÉOffice Tools
>
Calculator
This example shows that, from the home
screen, you press the
Main Menu soft key to
open the menu, scroll to and select
ÉOffice Tools , then scroll to and select Calculator .
Press the navigation key up, down, left, or
right
S to scroll to a menu feature. Press the
navigation key in
s to select the highlighted
menu feature.
SIM card
Caution: Don’t bend or scratch your SIM card.
Keep it away from static electricity, water, and
dirt.
Your Subscriber Identity Module (SIM) card
contains personal information like your phone
symbols
This means a feature is
network/subscription dependent
and may not be available in all areas.
Contact your service provider for
more information.
This means a feature requires an
optional accessory.
