Motorola MOTORIZR Z3 User manual

1
v95.1.0 English
HELLOMOTO
Introducing your new Motorola MOTO RIZR Z3 GSM wireless phone.
Charge Indicator Light
Bumper Bar
Push down to close slider.
Left Soft Key
Browser Key
Send Key
Make & answer calls.
Navigation Key
Scroll up, down, left, or right.
Bluetooth Indicator Light
Right Soft Key
Clear/Back Key
Power/End Key
Turn on/off, hang up, exit menus.
Centre Key
Open main menu & select menu items.
Z3.UG_O2.book Page 1 Monday, October 30, 2006 9:43 AM

2
v95.1.0 English
Camera Lens & High-Intensity LED
Camera Light
(on back of phone)
Voice Command Key
Use voice commands to make calls
& perform basic phone functions.
Camera Key
Activate camera & take photos.
Mini-USB Port
Insert battery charger & phone
accessories.
* This key functions as the PTT key when the push to talk
service is available on your phone.
Bumper Bar
Push up to open slider.
Volume Keys
set ring volume when slider is
closed.
Smart Key *
Select menu items.
Handsfree Speaker
(on back of phone)
Z3.UG_O2.book Page 2 Monday, October 30, 2006 9:43 AM

3
v95.1.0 English
14
32
Press the Centre Key s
to open the
Main Menu .
Press and hold the
Power
Key
O until the display
lights up, to turn on your
phone.
Press the
Navigation Key S
up/down/left/right to
highlight a menu
feature.
Press the
Centre Key
s to select it.
Home Screen Main Menu
Service Provider
15/10/07
Ring Styles Camera Select Exit
Messages
Note: This is the standard home screen and main menu layout.
Your phone’s home screen and main menu may be different.
10:10
Z3.UG_O2.book Page 3 Monday, October 30, 2006 9:43 AM

4
v95.1.0 English
www.hellomoto.com
Certain mobile phone features are dependent
on the capabilities and settings of your
service provider’s network. Additionally,
certain features may not be activated by your
service provider, and/or the provider’s
network settings may limit the feature’s
functionality. Always contact your service
provider about feature availability and
functionality. All features, functionality, and
other product specifications, as well as the
information contained in this user’s guide are
based upon the latest available information
and are believed to be accurate at the time of
printing. Motorola reserves the right to
change or modify any information or
specifications without notice or obligation.
MOTOROLA and the Stylised M Logo are
registered in the US Patent & Trademark
Office. All other product or service names are
the property of their respective owners. The
Bluetooth trademarks are owned by their
proprietor and used by Motorola, Inc. under
licence. Java and all other Java-based marks
are trademarks or registered trademarks of
Sun Microsystems, Inc. in the U.S. and other
countries. Microsoft and Windows are
registered trademarks of Microsoft
Corporation; and Windows XP is a trademark
of Microsoft Corporation.
© Motorola, Inc., 2006.
Caution: Changes or modifications made in
the radio phone, not expressly approved by
Motorola, will void the user’s authority to
operate the equipment.
Software Copyright Notice
The Motorola products described in this
manual may include copyrighted Motorola
and third-party software stored in
semiconductor memories or other media.
Laws in the United States and other countries
preserve for Motorola and third-party
software providers certain exclusive rights for
Z3.UG_O2.book Page 4 Monday, October 30, 2006 9:43 AM

5
v95.1.0 English
copyrighted software, such as the exclusive
rights to distribute or reproduce the
copyrighted software. Accordingly, any
copyrighted software contained in the
Motorola products may not be modified,
reverse-engineered, distributed, or
reproduced in any manner to the extent
allowed by law. Furthermore, the purchase of
the Motorola products shall not be deemed to
grant either directly or by implication,
estoppel, or otherwise, any licence under the
copyrights, patents, or patent applications of
Motorola or any third-party software provider,
except for the normal, non-exclusive,
royalty-free licence to use that arises by
operation of law in the sale of a product.
While Products specifications and features
may be subject to change without notice, we
are making every possible effort to ensure
that user manuals are updated on a regular
basis to reflect product functionality
revisions. However, in the unlikely event that
your manual version does not fully reflect the
core functionality of your product, please let
us know. You may also be able to access
up-to-date versions of our manuals in the
consumer section of our Motorola web site, at
http://www.motorola.com.
