phone diagram
Speaker Key
Micro USB Connector
Charge or connect to PC.
4-Way Navigation Key OK/Play Key
Music Key
Right Soft Key
Left Soft Key
PTT Button
Menu Key
Talk Key/Recent Call Power/End Key
3.5 mm Audio Jack
The important keys and connectors. MOTOROLA and the Stylized
M Logo are registered in the
US Patent & Trademark Office.
The Bluetooth trademarks are
owned by their proprietor and
used by Motorola, Inc. under
license. Microsoft Windows,
Windows Media Player, and
Exchange Server are either
a registered trademark or
a trademark of Microsoft
Corporation in the United
States and/or other countries.
All other product or service
names are the property of their
respective owners.
© 2009 Motorola, Inc. All rights
reserved.
Certain mobile phone
features are dependent on
the capabilities and settings
of your service provider’s
network. Additionally,
certain features may not be
activated by your service
provider, and/or the provider’s
network settings may limit
the feature’s functionality.
Always contact your service
provider about feature
availability and functionality.
All features, functionality, and
other product specifications,
as well as the information
contained in this tutorial, are
based on the latest available
information and are believed
to be accurate at the time
of publication. Motorola
reserves the right to change
or modify any information or
specifications without notice
or obligation.
NEXTBACK
Volume Keys

HOME »
LESSON:
PRINT »
VIEW »
EXIT »
EXTERNAL LINKS:
Additional Support
motorola debut™i856
PHONE DIAGRAM »
KNOW YOUR PHONE »
TRANSFERRING MUSIC »
LOADING MUSIC »
PLAYING MUSIC »
PLAYLIST BASICS »
MUSIC PLAYER OPTIONS »
continue getting to know your phone
NEXTBACK
turn it on and off
To turn on your phone,
press and hold for a few
seconds or until the display
turns on. If prompted, enter
your four-digit unlock code.
To turn off your phone,
press and hold for two
seconds.
make and answer calls
To make a call, enter a phone
number and press or use
a voice command.
To answer a call when your
phone rings and/or vibrates,
press .
To answer a call on
speakerphone, press the
speaker key .
To hang up, press .
opening and navigating menus
Press the navigation key up,
down, left, or right to scroll to
items in the display.
When you highlight the desired
item, press to select it.
1
2
3

HOME »
LESSON:
PRINT »
VIEW »
EXIT »
EXTERNAL LINKS:
Additional Support
motorola debut™i856
PHONE DIAGRAM »
KNOW YOUR PHONE »
TRANSFERRING MUSIC »
LOADING MUSIC »
PLAYING MUSIC »
PLAYLIST BASICS »
MUSIC PLAYER OPTIONS »
transferring music to your phone
NEXTBACK
From a CD – Windows Media Player
Insert the music CD in your computer’s CD
drive and Launch Windows Media Player 11.
Copy the music CD to the media player library
(also called ripping the CD).
Insert a microSD card into your phone and set your
phone to memory card access mode by pressing
Menu > Settings > Connections > USB >
Memory Card Access. Plug your phone into your
computer using an original Motorola USB data cable.
Go to “My Computer.”
Double click on the memory card (removable disk)
and folders will be displayed (MUSIC, VIDEO,
My_Music, etc).
Grab the My_Music folder within “My Documents”
and drop it into the MUSIC folder.
Disconnect the device from the computer.
Launch the Music Player and rock out!
* HINT: Device generated folders are in all caps. (MUSIC, VIDEO, PODCAST, etc). Your content must be stored
in the device generated folders to be recognized and displayed.
** HINT: If you have launched the music player prior to plugging in the phone to your computer you may need
to reload the music within the music player.
1
2
3
4
5
6
7
8
You can listen to music from your favorite CDs on your new Motorola Debut i856. Just load the
music onto your computer, and then transfer the music from the computer to your phone.
Note: You’ll need an optional
microSD memory card
installed in your phone to use
the music player.
Note: Before you copy files
to your phone, make sure
the files are in a format that
the phone recognizes. Your
phone’s music player can play
the following types of audio
files: AAC, AAC+, MP3, WAV,
WMA, Real Audio G2/8/10.

HOME »
LESSON:
PRINT »
VIEW »
EXIT »
EXTERNAL LINKS:
Additional Support
motorola debut™i856
PHONE DIAGRAM »
KNOW YOUR PHONE »
TRANSFERRING MUSIC »
LOADING MUSIC »
PLAYING MUSIC »
PLAYLIST BASICS »
MUSIC PLAYER OPTIONS »
transfer music from a microSD card or your computer
NEXTBACK
Insert the memory card (removable disk)
into your Motorola Debut i856 phone, then
turn it on.
Now change your connection settings
to memory card access. Press Menu >
Settings > Connections > USB >
Memory Card Access.
Attach a Motorola original USB cable to
the micro USB port on your phone and to
an available USB port on your computer.
On your computer, double click the
My Computer icon, and then the
Removable Disk icon.
You will see a variety of folders, double
click the My_Music icon.
Copy all of the music files from this
folder and paste them into the MUSIC
folder icon.
Remember, you must tell your computer
you are going to disconnect the phone
from the USB port.
You can now select and play the music
files with your phone’s music player.
1
2
3
4
5
6
7
Have music already loaded on a memory card or your computer?
You can load it onto your phone in a few simple steps.
Note: The unauthorized
copying of copyrighted
materials is contrary to the
provisions of the Copyright
Laws of the United States
and other countries. This
device is intended solely for
copying non-copyrighted
materials, materials in which
you own the copyright,
or materials which you
are authorized or legally
permitted to copy. If you are
uncertain about your right
to copy any material, please
contact your legal advisor.
Folders that are generated by
the phone are in ALL CAPS.

HOME »
LESSON:
PRINT »
VIEW »
EXIT »
EXTERNAL LINKS:
Additional Support
motorola debut™i856
PHONE DIAGRAM »
KNOW YOUR PHONE »
TRANSFERRING MUSIC »
LOADING MUSIC »
PLAYING MUSIC »
PLAYLIST BASICS »
MUSIC PLAYER OPTIONS »
loading music from a pre-loaded microSD card
NEXTBACK
Place pre-loaded microSD card into
your phone, the required folders
will be added automatically (MUSIC,
VIDEO, PODCAST, etc).*
Connect your phone to a PC with a
USB cable.
Automated dialog displayed on PC.
Options presented: Play Music,
Open folder to view as files,
Take no action
Select Open folder to view files, and
memory Card folders will be displayed.
Grab My_Music folder with the pre-loaded
music and drop it into the MUSIC folder
(phone generated folder).
Disconnect device from computer.
Launch Music player and rock out!**
* HINT: Device generated folders
are in all CAPS. (Ex. MUSIC, VIDEO,
PODCAST, etc). Your content must be
stored in the device generated folders
to be recognized and displayed.
** HINT: If you have launched the
Music Player prior to plugging in the
phone to your computer you may need
to reload the music within the Music
Player.
1
2
3
4
5
6
7

HOME »
LESSON:
PRINT »
VIEW »
EXIT »
EXTERNAL LINKS:
Additional Support
motorola debut™i856
PHONE DIAGRAM »
KNOW YOUR PHONE »
TRANSFERRING MUSIC »
LOADING MUSIC »
PLAYING MUSIC »
PLAYLIST BASICS »
MUSIC PLAYER OPTIONS »
playing music
NEXTBACK
To activate your phone’s music player,
press the music player key.
To play the first music file in the folder,
press under Play. (If the selected
folder contains subfolders, this plays
the first music file in the first of the
subfolders.)
Scroll to choose how you want
your music played (Songs, Playlists,
Albums, etc.).
Press to view the folder’s
contents. Scroll to a music file and
press under Play or to play
the first music file in it.
1 3
2
4
Launch music player
When you insert a microSD card for the first time, your phone will give you four options. Select option
2, “Go to My Music” to start the music player. In the music player press the Menu key and select
“Reload Music” to add the songs to your music library.
Music controls
Your music player has all the same controls you’d expect. Here’s how to use them.
Tip: The Songs folder contains
all the music files on the
memory card in a single list.
option
Pause and Resume: Press under Pause or to
pause, and press under Play or to resume
playing paused music files.
Skip to Next or Previous: Press and release right
or left to skip to the next or previous music file.
Fast Forward and Rewind: Press and hold right
or left for 2 seconds to fast forward or to rewind.

HOME »
LESSON:
PRINT »
VIEW »
EXIT »
EXTERNAL LINKS:
Additional Support
motorola debut™i856
PHONE DIAGRAM »
KNOW YOUR PHONE »
TRANSFERRING MUSIC »
LOADING MUSIC »
PLAYING MUSIC »
PLAYLIST BASICS »
MUSIC PLAYER OPTIONS »
making a playlist
NEXTBACK
Press the music player key.
Select Add Songs. A list of all
music files appears.
Tip: For options to help you sort
through this list, press .
Enter a playlist name.
Note: If you do not assign a name,
the playlist is named Playlist
followed by a number. For example,
the first playlist you create without
a name is automatically named
Playlist-1.
Select each file you want on the
playlist. A checkmark appears by
each selected file.
Tip: To deselect a selected item,
scroll to the file and press .
1
3
2
4
You can create your own sets of music—or playlists—to use when riding the train or working out.
Note: The unauthorized
copying of copyrighted
materials is contrary to the
provisions of the Copyright
Laws of the United States
and other countries. This
device is intended solely for
copying non-copyrighted
materials, materials in which
you own the copyright,
or materials which you
are authorized or legally
permitted to copy. If you are
uncertain about your right
to copy any material, please
contact your legal advisor.
When you are finished selecting files,
press under Done and
under Save.
5

HOME »
LESSON:
PRINT »
VIEW »
EXIT »
EXTERNAL LINKS:
Additional Support
motorola debut™i856
PHONE DIAGRAM »
KNOW YOUR PHONE »
TRANSFERRING MUSIC »
LOADING MUSIC »
PLAYING MUSIC »
PLAYLIST BASICS »
MUSIC PLAYER OPTIONS »
removing a song
NEXTBACK
remove song from playlist
Before you have saved a new playlist or
while editing a playlist, scroll to the song
you want to remove.
Press > Remove Song
and press OK.
Confirm that you want the song
removed from the playlist.
Don’t worry, you are not
deleting the song from your
library, you’re just removing
it from your playlist.
1
2
3
Changing a playlist is as easy as changing your mind. You can remove some or all songs while
creating or editing a playlist.
Note: The unauthorized
copying of copyrighted
materials is contrary to the
provisions of the Copyright
Laws of the United States
and other countries. This
device is intended solely for
copying non-copyrighted
materials, materials in which
you own the copyright,
or materials which you
are authorized or legally
permitted to copy. If you are
uncertain about your right
to copy any material, please
contact your legal advisor.

HOME »
LESSON:
PRINT »
VIEW »
EXIT »
EXTERNAL LINKS:
Additional Support
motorola debut™i856
PHONE DIAGRAM »
KNOW YOUR PHONE »
TRANSFERRING MUSIC »
LOADING MUSIC »
PLAYING MUSIC »
PLAYLIST BASICS »
MUSIC PLAYER OPTIONS »
delete a playlist
NEXTBACK
While you’re in the music player,
select Playlists.
Scroll to the playlist you want to
delete and press the > Delete
Playlist. Press the button under Yes
to confirm.
1
2
Decide you want to remove a playlist from your phone completely?
No problem, it’s easy to do as well.
Note: The unauthorized
copying of copyrighted
materials is contrary to the
provisions of the Copyright
Laws of the United States
and other countries. This
device is intended solely for
copying non-copyrighted
materials, materials in which
you own the copyright,
or materials which you
are authorized or legally
permitted to copy. If you are
uncertain about your right
to copy any material, please
contact your legal advisor.

HOME »
LESSON:
PRINT »
VIEW »
EXIT »
EXTERNAL LINKS:
Additional Support
motorola debut™i856
PHONE DIAGRAM »
KNOW YOUR PHONE »
TRANSFERRING MUSIC »
LOADING MUSIC »
PLAYING MUSIC »
PLAYLIST BASICS »
MUSIC PLAYER OPTIONS »
music player options
BACK
To customize music playback,
select Equalizer.
You can also select custom visual
effects for the music playback
screen. Press > Setup then
scroll to Visuals and press left or
right to change your selection.
You can select sounds like
Pop, R&B, and Rock.
1 3
2
While you’re listening to the music player, you have a number of settings you can adjust.
Set-up the following options in the music player by pressing ( > Setup.
Note: The unauthorized
copying of copyrighted
materials is contrary to the
provisions of the Copyright
Laws of the United States
and other countries. This
device is intended solely for
copying non-copyrighted
materials, materials in which
you own the copyright,
or materials which you
are authorized or legally
permitted to copy. If you are
uncertain about your right
to copy any material, please
contact your legal advisor.
