Motorola iDEN i580 User manual

SouthernLINC Wireless
iDEN
Digital Multi-service Data-capable Phone
i580 Phone User’s Guide
@NNTN6776B@
NNTN6776B

IMPORTANT NOTICE: PLEASE READ
PRIOR TO USING YOUR PHONE
The SIM card provided with this kit is intended for use
with the phone provided in this package.
Loss of certain features will result when using a SIM
card from one of the following models: i30sx, i35s,
i50sx, i55sr, i58s, i60c, i80s, i85s, i88s, i90c, i95cl
series, and the i2000 series.
For more information on SIM card compatibility, go to
www.motorola.com/iden/support.
Defects or damage to your Motorola phone that result
from the use of non-Motorola branded or certified
Accessories, including but not limited to replacement
housings and or other peripheral accessories, are
excluded from warranty coverage. Please refer to the
text of Motorola's Limited One Year warranty located in
this user’s guide for complete details.

i
Contents
Getting Started........................................... 1
Locating Your SIM Card....................................3
Battery...............................................................3
Activating Service..............................................6
Powering On and Off.........................................6
Enabling Over-the-Air Security..........................7
Finding Your Phone Number and LINC ID........8
Phone Basics ....................................................8
SIM Card Security ...........................................12
Antenna ...........................................................17
Accessories.....................................................18
For More Information.......................................18
Making Calls............................................. 19
Phone Calls.....................................................19
InstantLINC Mobile to Mobile Calls .................19
Receiving Calls................................................20
Choosing a Number to Call .............................21
Missed Phone Calls.........................................22
Using Speakerphone.......................................22
Using Mute ......................................................23
Making Emergency Phone Calls .....................23
LINCaroundSM...........................................24
Channels and Codes.......................................25
Private LINCaround Calls................................27
Making Emergency Calls While in
LINCaroundSM Mode ..................................28
Setup Options .................................................28
Call Alerts..................................................30
Sending Call Alerts..........................................30
Receiving Call Alerts .......................................30
Using the Call Alert Queue..............................30
Recent Calls..............................................32
Viewing the Recent Calls List..........................32
Calls and Call Alerts........................................32
LINC Feature Items in InstantLINC Mobile to
Mobile Calls ................................................33
Storing Items to Contacts................................36
Deleting Items .................................................37
Making Calls From the Recent Calls List ........37

ii
Contacts ................................................... 39
Accessing Contacts.........................................40
Creating Entries...............................................40
Storing Numbers Faster ..................................42
Editing Entries .................................................43
Viewing Entries................................................43
Deleting Entries...............................................45
Checking Capacity ..........................................45
Creating Pauses and Waits.............................46
International Numbers .....................................46
Making Calls From Contacts ...........................46
Accessing Contacts with GSM Phones ...........47
Call Forwarding........................................ 48
Forwarding All Calls ........................................48
Turning Off Call Forwarding ............................49
Forwarding Missed Calls.................................49
Viewing Call Forwarding Settings....................50
Advanced Calling Features..................... 51
Call Waiting .....................................................51
Switching Between Calls.................................51
Putting a Call on Hold......................................52
Calling 2 People ..............................................52
Creating Pauses and Waits While Dialing.......53
Making International Calls...............................53
Setting Flip Actions .........................................53
Group Calls .....................................................54
Call Timers ......................................................55
Using Your Phone as a Modem ......................56
Features for the Hearing Impaired ..................57
Memo .........................................................60
Ring Tones................................................61
Setting Your Phone to Vibrate.........................61
Ring and Vibrate .............................................62
Assigning Ring Tones to Contacts ..................62
Viewing Ring Tone Assignments ....................62
Downloading More Ring Tones .......................63
About DRM Ring Tones ..................................63
Managing Memory ..........................................63
Deleting Custom Ring Tones ..........................63
Entering Text ............................................65
Using Word Mode ...........................................65

iii
Special Function Keys.....................................66
Messages ................................................. 67
Message Notifications .....................................67
Message Center..............................................68
Voice Mail Messages ............................... 69
Receiving a Message......................................69
Accessing Voice Mail From
the Message Center ...................................69
Sending Unanswered Calls to Voice Mail .......69
Text Messaging........................................ 70
Setting Up........................................................70
Receiving a Message......................................70
Reading from the Message Center .................71
Creating and Sending Messages ....................71
Sorting Messages............................................74
Managing Memory...........................................74
Using a Memory Card.............................. 75
Ensuring Files on the Memory Card Are
Compatible With Your Phone .....................75
Using the Memory Card With
Your Phone.................................................77
Using the Memory Card With
Your Computer ...........................................79
Other Memory Cards
Compatible With Your Phone .....................81
Camera ......................................................82
Accessing the Camera ....................................82
Taking Pictures ...............................................82
More Actions for Captured Pictures ................84
Recording Videos............................................85
Changing Storage Preference.........................86
Accessing the Media Center ...........................87
Customizing the Camera.................................87
Managing Memory ..........................................88
Media Center.............................................89
Viewing the Media Center ...............................89
Forward Locked Items.....................................91
DRM Items ......................................................92
Pictures ...........................................................92
Videos .............................................................93
Audio Recordings............................................94
Renaming Items ..............................................95
Locking Items ..................................................95

iv
Deleting Items .................................................95
Copying and Moving Items..............................96
Changing Storage Preference.........................97
Accessing the Camera ....................................97
Accessing the Audio Player.............................97
Managing Memory...........................................97
Audio Player............................................. 99
Accessing the Audio Player.............................99
Exiting the Audio Player ..................................99
Playing Audio Files..........................................99
Adjusting the Volume ....................................100
How Your Audio Files Are Organized............100
Searching By First Letter...............................101
Playing a List and Using Repeat
and Shuffle................................................101
Working With Playlists...................................102
Deleting Audio Files ......................................105
DRM Items ....................................................106
Setting Audio and Visual Options..................106
Digital Rights Management................... 108
Installing Items ..............................................108
Understanding DRM Status Icons.................108
Sharing Items ................................................108
Managing DRM Items ...................................109
Using LINC Features ..............................112
LINC Feature Icons .......................................112
LINC Messages.............................................113
LINC Pictures ................................................115
LINC Events ..................................................119
LINC My Info .................................................122
LINC Contact.................................................123
LINC Manager .........................................125
Accessing LINC Features
From LINC Manager .................................125
Turning LINC Features On and Off ...............125
Changing the Quick Notes List......................125
Setting One Touch PTT ................................126
Setting My Info Sending Option ....................127
My Info.....................................................129
Viewing My Info.............................................129
Editing My Info ..............................................129

v
Datebook ................................................ 131
Viewing Datebook .........................................131
Creating Events.............................................132
Editing Events ...............................................134
Deleting Events .............................................134
Receiving Reminders ....................................135
Making Calls From Datebook and Datebook
Reminders ................................................135
Customizing Datebook Setup........................136
Java Applications .................................. 138
Installing Applications....................................138
Running Applications.....................................138
Suspending Applications ...............................138
Resuming Applications..................................139
Ending Applications.......................................139
Downloading Applications .............................139
Deleting Applications.....................................140
Managing Memory.........................................140
Shortcuts on the Main Menu .........................140
Java Applications and GPS Enabled.............141
Bluetooth®..............................................144
Understanding Bluetooth®Access Settings..144
Setting Your Phone for Bluetooth® .................... 145
Accessing Bluetooth®...................................146
Making a Bluetooth®Connection ..................146
Setting Device Details ...................................149
Sending Contacts, Datebook Events and
Pictures.....................................................150
Receiving Items.............................................151
GPS Enabled...........................................152
IMPORTANT: Things to Keep in Mind ..........152
Making an Emergency Call ...........................154
Viewing Your Approximate Location .............155
Enhancing GPS Performance .......................156
Setting Privacy Options.................................157
Using GPS with Map Software......................158
Voice Records ........................................161
Viewing Voice Records .................................161
Creating Voice Records ................................161
Playing Voice Records ..................................162
Labeling Voice Records ................................162

vi
Locking Voice Records..................................162
Deleting Voice Records.................................163
Managing Memory.........................................163
Customizing Your Phone...................... 164
Setting the Volume........................................164
Setting Your Phone to Vibrate.......................164
Changing the Look of Your Phone ................164
Temporarily Turning Off Transmissions ........166
Using Settings ...............................................166
Profiles ................................................... 172
Viewing Profiles.............................................172
Switching Profiles ..........................................172
Surveillance Profile........................................173
Car Profile .....................................................173
How Changing Settings Affects Profiles........173
Temporary Profiles ........................................174
Creating Profiles............................................175
Editing Profiles ..............................................175
Deleting Profiles ............................................175
Setting Call Filtering ......................................175
Shortcuts.................................................177
Creating a Shortcut .......................................177
Using a Shortcut............................................177
Editing a Shortcut..........................................178
Deleting Shortcuts.........................................178
Using a Headset .....................................179
Using a Bluetooth Headset ...........................179
Attaching a Headset......................................179
Using a Remote PTT Button .........................179
Understanding Status Messages..........181
Safety and General Information ............184
RF Operational Characteristics .....................184
Portable Radio Product Operation and EME
Exposure...................................................184
Electromagnetic Interference/Compatibility...187
Medical Devices ............................................187
Operational Warnings ...................................188
Operational Cautions ....................................189
Accessory Safety Information .......................190

vii
Hearing Aid Compatibility..................... 192
Caring for the Environment by
Recycling ............................................ 194
Disposal of your Mobile Telephone and
Accessories ..............................................194
MOTOROLA LIMITED WARRANTY ...... 195
Patent and Trademark Information ...... 199
Index ....................................................... 200
Driving Safety Tips ................................ 207

viii

ix
DECLARATION OF CONFORMITY
Per FCC CFR 47 Part 2 Section 2.1077(a)
Responsible Party Name: Motorola, Inc.
Address: 8000 West Sunrise Boulevard
Plantation, FL 33322 USA
Phone Number: 1 [phone]
Hereby declares that the product:
Product Name: i580
Model Number: H85XAH6RR5AN
Conforms to the following regulations:
FCC Part 15, subpart B, section 15.107(a),
15.107(d) and section 15.109(a)
Class B Digital Device
As a personal computer peripheral, this device
complies with Part 15 of the FCC Rules. Operation
is subject to the following two conditions: (1) this
device may not cause harmful interference, and (2)
this device must accept any interference received,
including interference that may cause undesired
operation.
Note: This equipment has been tested and
found to comply with the limits for a Class
B digital device, pursuant to part 15 of the
FCC Rules. These limits are designed to
provide reasonable protection against
harmful interference in a residential
installation. This equipment generates,
uses and can radiate radio frequency
energy and, if not installed and used in
accordance with the instructions, may
cause harmful interference to radio
communications. However, there is no
guarantee that interference will not occur
in a particular installation.
If this equipment does cause harmful
interference to radio or television reception,
which can be determined by turning the
equipment off and on, the user is
encouraged to try to correct the interference
by one or more of the following measures:
• Reorient or relocate the receiving
antenna.
• Increase the separation between the
equipment and receiver.
• Connect the equipment into an outlet on
a circuit different from that to which the
receiver is connected.
• Consult the dealer or an experienced
radio/TV technician for help.

x

1
Getting Started
volume
controls
stereo
headset jack
retractable
antenna
mirror
memory
card slot
external
display
PTT button
camera
lens
spotlight
accessory
connector
light sensor
power button
camera key
microphone

2
Getting Started
To start using your i580 phone:
•Make sure your SIM card is in place.
•Charge the battery.
•Activate your service.
•Enable over-the-air security if you are prompted
to.
Navigation key — press the arrows to
scroll through menus and lists.
OOK key — selects highlighted item;
answers calls.
mMenu key — accesses context-sensitive
menus.
AOption key — selects the option
appearing above it on the display.
sSend key — places phone calls.
eEnd key — ends phone calls; returns to
idle screen.
t??Acts like swhen the flip is closed; turns
speaker on; used with voice names and
voice records.
.??Acts like ewhen the flip is closed;
accesses recent calls; sends incoming
calls to voice mail.

3
Locating Your SIM Card
Locating Your SIM Card
Your SIM (Subscriber Identity Module) card is a
small piece of plastic located in the SIM card
holder in the back of your phone, underneath the
battery.
If your SIM card is not in the SIM card holder, it
may be in the box your phone came in, attached to
a piece of plastic about the size of a credit card. If
this is the case, carefully detach your SIM card
from the surrounding plastic and insert it as
described in “Inserting Your SIM Card” on page 15.
If there is no SIM card in your phone or the box,
contact SouthernLINC Wireless at
1-800-406-0151.
Battery
Removing the Battery Door
1Make sure the phone is powered off. See
“Powering On and Off” on page 6.
2Slide the release button back until it releases the
battery door.
SIM card
release
button

4
Getting Started
3Allow the battery door to pop up, slide it forward,
and remove it from the back of your phone.
Inserting the Battery
Your phone comes with a High Performance
Lithium Ion Battery.
1Remove the battery door.
2Insert the battery into the battery area. Press the
battery down to secure it.
3Replace the battery door and press it gently until
you hear a click.
Charging the Battery
Your phone comes with a standard charger.
1Plug the charger into an electrical outlet.
2Open the connector cover.
connector
cover

5
Battery
3Plug the other end of the charger into the
accessory connector.
4 Charger Attached or Device Attached appears
on the internal display.
Tip: To remove the charger from the accessory
connector: Press the buttons on the sides
of the plug. Pull the plug straight out.
5If you have purchased optional batteries or
chargers, see “Charging Times”.
Charging Times
See your battery and charger to determine the
appropriate charging time.
For best results, charge the batteries within the
temperature range of 50°F to 104°F (10°C to
40°C).
Prolonged charging is not recommended.
Battery Charger
Rapid Standard
High
Performance
2 hours 5 hours
Maximum
Capacity
3 hours 6 hours

6
Getting Started
Removing the Battery
1With the phone powered off, remove the battery
door.
2Remove the battery by pushing it toward the
antenna and lifting it out.
Battery Use and Maintenance
•The Motorola iDEN Approved Lithium Ion
chargers provide optimum performance. Other
chargers may not fully charge the iDEN Lithium
Ion battery or may yield a reduced number of
lifetime charge cycles.
•Extreme temperatures degrade battery
performance. Do not store the battery where
temperatures exceed 140°F (60°C) or fall below
-4°F (-20°C).
•Lithium Ion batteries have a self discharge rate
and without use, lose about 1% of their charge
per day.
•The battery capacity is degraded if the battery is
stored for long periods while fully charged. If
long term storage is required, store at half
capacity.
Activating Service
The first time you power on your phone, you must
be in your local calling area. This activates your
service.
Powering On and Off
The first time you power your phone on, a screen
may appear asking you to update your browser
information. This means you must enable security.
To power your phone on:
1Open the flip.
2Press p.
Note: When powering on, if you press pfor
more than 5 seconds, you will turn off
calls and other transmissions. See
“Temporarily Turning Off Transmissions”
on page 166.
