Motorola RAZR User manual

1
HELLOMOTO
We are pleased that you have chosen the Motorola RAZR V3m wireless phone.
040128o
Left Soft Key
Perform function
in lower left
display.
Voice Key
Create voice
records, activate
speech dialing &
voice
commands.
Smart/
Speakerphone
Key
Volume Keys
Camera Key
4-Way Navigation Key
with Center Select
From home screen, press
center key to open main menu.
Clear Key
Right Soft Key
Perform function
in lower right
display.
Power & End Key
Turn phone
on/off, end calls,
exit menu
system.
Accessory
Connector Port
Insert charger &
phone
accessories.
Send Key
Make & answer
calls.
Camera Lens
Smart/
Speakerphone
Key
Take self-portrait
photo with
camera when flip
is closed.
External Display
View incoming
call information,
use as camera
viewfinder when
flip is closed.

2
Motorola, Inc.
Consumer Advocacy Office
1307 East Algonquin Road
Schaumburg, IL 60196
www.hellomoto.com
1-800-331-6456 (United States)
1-888-390-6456 (TTY/TDD United States for
hearing impaired)
1-800-461-4575 (Canada)
Certain mobile phone features are dependent on the
capabilities and settings of your service provider’s
network. Additionally, certain features may not be
activated by your service provider, and/or the
provider's network settings may limit the feature’s
functionality. Always contact your service provider
about feature availability and functionality. All
features, functionality, and other product
specifications, as well as the information contained
in this user's guide are based upon the latest
available information and are believed to be
accurate at the time of printing. Motorola reserves
the right to change or modify any information or
specifications without notice or obligation.
MOTOROLA and the Stylized M Logo are registered
in the US Patent & Trademark Office. The Bluetooth
trademarks are owned by their proprietor and used
by Motorola, Inc. under license. All other product or
service names are the property of their respective
owners.
© Motorola, Inc., 2006
Caution: Changes or modifications made in the
radio phone, not expressly approved by Motorola,
will void the user's authority to operate the
equipment.
Manual number: 6809501A90-O

3
contents
contents
menu map . . . . . . . . . . . . 5
Use and Care . . . . . . . . . 7
essentials . . . . . . . . . . . . 8
about this guide . . . . . . 8
battery . . . . . . . . . . . . . 9
turn it on. . . . . . . . . . . . 11
make a call . . . . . . . . . . 11
answer a call. . . . . . . . 12
adjust volume. . . . . . . 12
change the call alert . . . 13
view your phone
number. . . . . . . . . . . . 13
main attractions . . . . . . 14
get & play music. . . . . 14
record & play
voice records . . . . . . . 19
record & play
video clips. . . . . . . . . . 20
take & send a photo. . . 22
send a multimedia
(Pix/Flix) message. . . . 24
receive a multimedia
(Pix/Flix) message. . . . 26
download pictures . . . 27
download V CAST
videos. . . . . . . . . . . . . 27
removable memory
capability. . . . . . . . . . . 28
Bluetooth®
connections . . . . . . . . 32
cable connections. . . . 34
TTY operation . . . . . . . 34
basics . . . . . . . . . . . . . . 36
home screen . . . . . . . 36
navigation key. . . . . . . 39
menus . . . . . . . . . . . . 39
enter text . . . . . . . . . . 41
handsfree speaker . . . 46
external display. . . . . . 47
airplane mode. . . . . . . 47
change a code, PIN,
or password . . . . . . . . 48
lock/unlock keypad . . . 49
lock/unlock phone. . . . 49
if you forget a code,
PIN, or password . . . . 50
customize . . . . . . . . . . . 51
ringer/alert styles &
detailed settings . . . . . 51
get ringtones . . . . . . . 52
activate ringer IDs. . . . 52
talking phone
settings. . . . . . . . . . . . 53
answer options. . . . . . 53

4
contents
wallpaper . . . . . . . . . . . 53
screen saver . . . . . . . . 54
backlight . . . . . . . . . . . 55
hide/show location
information . . . . . . . . . 55
AGPS limitations
& tips. . . . . . . . . . . . . . 56
conserve battery . . . . . 57
calls . . . . . . . . . . . . . . . 58
change the active
line. . . . . . . . . . . . . . . . 58
redial a number . . . . . . 58
automatic redial. . . . . . 58
emergency calls . . . . . 59
use AGPS during
an emergency call . . . . 59
recent calls . . . . . . . . . 60
return unanswered
calls . . . . . . . . . . . . . . . 61
attach number . . . . . . . 61
speed dial . . . . . . . . . . 62
voicemail . . . . . . . . . . . 62
in-call options. . . . . . . . 63
other features . . . . . . . . 64
messages . . . . . . . . . . 64
contacts. . . . . . . . . . . . 66
personalizing
features . . . . . . . . . . . . 70
menu features . . . . . . . 73
dialing . . . . . . . . . . . . . 75
monitor calls . . . . . . . . 75
handsfree . . . . . . . . . . 76
Bluetooth® wireless
connections . . . . . . . . . 77
data & fax calls . . . . . . 78
network . . . . . . . . . . . . 79
personal organizer . . . . 80
security . . . . . . . . . . . . 81
news &
entertainment . . . . . . . 81
service & repairs . . . . . 83
Specific Absorption
Rate Data
. . . . . . . . . . . 84
index . . . . . . . . . . . . . . 86

5
menu map
menu map
main menu
B GET IT NOW*
• Get Tunes & Tones
• Get Pix & Flix
• Get Fun & Games
• Get News & Info
•GetGoing
C MESSAGING
•NewTxtMsg
•NewPixMsg
•Inbox
•Sent
•Drafts
•Voicemail
E CONTACTS
• New Contact
• Contact List
• Groups
• Speed Dials
A RECENT CALLS
•Missed
• Received
•Dialed
•All
•ViewTimers
D SETTINGS & TOOLS
(see next page)
* optional features
This is the standard main
menu layout. Your phone’s
menu may be a little different.

6
menu map
SETTINGS & TOOLS menu
Tools
• Calendar
•AlarmClock
• World Clock
• Notepad
•Calculator
Sounds Setting
• Ring Styles
• Talking Phone Settings
Airplane Mode
• Airplane Mode
• Prompt at Startup
Display
• Wallpaper
• Screen Saver
• Display Themes
• Greeting
•HomeScreen
System
•SystemSelect
•DeviceInfo
•Location
• Security
• Icon Glossary
Call Settings
• In-Call Setup
• Headset
Initial Setup
• SpeakerPhone
• Auto Redial
• Backlight
• TTY Setup
• Language
• Battery Save
•DTMF
• Hyphenation
• Master Reset
• Master Clear
Connections
• Incoming Call
• Bluetooth

7
Use and Care
Use and Care
Use and Care
To care for your Motorola phone, please keep it
away from:
liquids of any kind dust and dirt
Don’t expose your phone to
water, rain, extreme humidity,
sweat, or other moisture.
Don’t expose your phone to
dust, dirt, sand, food, or other
inappropriate materials.
extreme heat or cold cleaning solutions
Avoid temperatures below
-10°C/14°F or above 45°C/113°F.
To clean your phone, use only a
dry soft cloth. Don’t use alcohol
or other cleaning solutions.
microwaves the ground
Don’t try to dry your phone in a
microwave oven.
Don’t drop your phone.

8
essentials
essentials
about this guide
This guide shows how to locate a menu
feature as follows:
Find it: Press MENU ( s )  ARECENT CALLS
 Dialed
This example shows that from the home
screen, you must press
MENU ( s ), scroll
across to
RECENT CALLS on the main menu, then
scroll down to and select
Dialed . Press S to
scroll across and down, and the center
key
s to select a menu option.
CAUTION: Before using the
phone for the first time, read the
Important Safety and Legal
Information
included in the gray-
edged pages at the back of this
guide.
symbols
This means a feature is network/
subscription dependent and may not
be available in all areas. Contact your
service provider for more
information.
This means a feature requires an
optional accessory.

9
essentials
battery
battery tips
Battery life depends on the network, signal
strength, temperature, features, and
accessories you use.
• Always use Motorola
Original batteries and
chargers. The warranty
does not cover damage
caused by non-Motorola batteries and/
or chargers.
• New batteries or batteries stored for a
long time may take more time to
charge.
• When charging your battery, keep it
near room temperature.
• When storing your battery, keep it
uncharged in a cool, dark, dry place.
• Never expose batteries to
temperatures below -10°C (14°F) or
above 45°C (113°F). Always take your
phone with you when you leave your
vehicle.
• It is normal for batteries to gradually
wear down and require longer charging
times. If you notice a change in your
battery life, it is probably time to
purchase a new battery.
Contact your local recycling center for
proper battery disposal.
Warning: Never dispose of batteries in a fire
because they may explode.
Before using your phone, read the battery
safety information in the “Safety and General
Information” section included in this guide.

10
essentials
install the battery
charge the battery
New batteries are shipped partially charged.
Before you can use your phone, you need to
install and charge the battery as described
below. Some batteries perform best after
several full charge/discharge cycles.
Note: When the battery is charging, the
phone automatically changes to the audible
Master Volume setting, regardless of which
ringstyle you have set. The phone changes
back to your selected ringstyle when you
disconnect the charger.
To charge using the charger:
1
Insert the
charger into the
USB connector
on your phone
as shown.
2 Plug the other
end of the
charger into the appropriate electrical
outlet.
The battery indicator
N flashes while
your phone is charging.
3 When your phone indicates Charge Complete
and the battery indicator stops flashing,
remove the charger.
1. 2.
3. 4.

11
essentials
Tip: You can safely leave the charger
connected to the phone after charging is
complete. This will
not damage the battery.
When you charge the battery, the battery level
indicator in the upper right corner of the
display shows how much of the charging
process is complete. At least one segment of
the battery level indicator must be visible to
ensure full phone functionality while charging.
To charge from your PC, connect a cable
from your phone’s mini-USB port to a high-
power USB port on a computer (not a low-
power one such as the USB port on your
keyboard or bus-powered USB hub). Typically,
USB high-power ports are located directly on
your computer.
Both your phone and the computer must be
turned on, and your computer must have the
correct software drivers installed. Cables and
software drivers are available in Motorola
Original data kits, sold separately.
turn it on
1 Open your phone.
2 Press and hold the
power key for three
seconds.
The phone may
require several
seconds to power on.
3 If necessary, enter your four-digit unlock
code (the last four digits of your phone
number) and press
OK to unlock the
phone.
make a call
1 Dial the number.
Tip: If you make a mistake, press the
clear key
B to delete the last digit. Press
and hold
B to clear all digits.

12
essentials
2 Press N to make the call.
3 Press P to end the call.
Tip: Closing the flip also ends the call unless
you are using the speakerphone feature (see
page 46).
Note: You must dial the phone number from
the home screen. See page 36.
answer a call
When you receive a call, your phone rings or
vibrates and displays an incoming call
message.
1 Press N to answer.
2 Press P to end the call.
Tip: You can set the phone to answer calls
when you open the flip. (To activate, press
MENU ( s )  DSETTINGS & TOOLS  Call Settings
 In-Call Setup  Answer Options  Open To Answer .)
Note: If the phone is locked, you must first
enter your four-digit unlock code to answer
the call.
adjust
volume
Press the up or down
volume keys to:
• increase or decrease earpiece volume
during a call
• increase or decrease ringer volume
setting when the home screen is
visible (phone must not be in a call and
flip must be open)
• silence an incoming call alert
040135o

13
essentials
change the call alert
phone flip open
In the home screen,
press the down volume
key to switch to lower
call alert volume, then
switch to
Vibrate , then
Alarm , and, finally, All Off . Press the up volume
key to cycle back from silent alert to vibrate
and then to the lowest alert volume setting.
phone flip closed
Press and hold
the up or down
volume key,
then, within five
seconds, press
the smart/speakerphone key to scroll through
the alert styles:
Master Volume , Alarm Only , Vibrate Only ,
and
All Off . The alert styles are shown on the
external display.
After scrolling to the desired alert style, press
the up or down volume key to save the setting
and return to the home screen.
view your phone
number
To view your phone number from the home
screen, press
B# .
While you are on a call, press
Options , then
select
My Number .
040135o
Volume Keys
Smart/
Speakerphone
Key

14
main attractions
main attractions
You can do much more with your phone than
make and receive calls! This section
describes some of your phone’s highlights.
get & play music
Use the Get Tunes & Tones menu to:
• get new tunes and tones
• record new sounds
• set tunes and tones as your ringtone
• access music files
download V CAST music
You can download music from the
V CAST Music catalog and store it in
your phone’s memory or on your memory
card.
Find it: Press MENU ( s )  BGET IT NOW
 Get Tunes & Tones
1 Scroll to Get V CAST Music and press OK ( s )
to open the V CAST music catalog.
2 Browse or search the catalog to find the
songs you want.
3 When the desired song is highlighted,
select
Preview to preview the song or Buy to
purchase the song.
4 When your phone displays song details
and price, press
BUY ( s ) to confirm your
selections.
5 When you see a confirmation that your
purchase was successful and your music

15
main attractions
is available for download, press OK ( s ) to
continue, or choose to download at a later
time.
6 When prompted to select a storage
location, scroll to
Phone Memory or Memory Card
and press the center key
s to begin
downloading.
Your phone displays a status indicator.
After downloading, you will have to wait
for the phone to acquire the content
license.
7 Press OK ( s ) when the download is
complete.
8 Press Play to play the downloaded song
immediately.
or
Press Library to go to the Music Library (see
page 15).
or
Press OK ( s ) to return to the previously
viewed music catalog.
manage music
Go to the Music Library to sort your music or
create playlists.
Find it: Press MENU ( s )  BGET IT NOW
 Get Tunes & Tones
Scroll to Manage Music and press OK ( s ).
The
Music Library includes these options:
option
Genres
Organize your songs into folders by music
type such as Folk, Rock, or Country.
Artists
Organize your songs into folders by names
of artists.

16
main attractions
create a playlist
Find it: Press MENU ( s )  BGET IT NOW
 Get Tunes & Tones
1 Scroll to Manage Music and press OK ( s ).
2 Scroll to Playlists and press OK ( s ).
3 If playlist(s) already exist, press Options .
Then select
Create playlist and press OK ( s ).
or
If no playlists exist, press Create . Then
enter a title for the playlist in the text box
and press
OK ( s ).
4 Press B to return to the Music Library
menu.
5 Select Genres , Artists , Albums , or Songs .
Albums
Organize your songs into folders by album
title.
Note: Even if you have only one song from
an album, you will see a folder for that
album.
Songs
Organize your songs into folders by song
title.
Playlists
View playlists that you have created.
Inbox
View alert notifications received when new
music from a selected artist is available for
download.
Play All
Play all songs in list order.
option
Shuffle
Resort a playlist order.
option

17
main attractions
6 Scroll to a desired song and press Options .
7 Scroll to and select Add to Playlist .
8 Scroll to the desired playlist and press
ADD ( s ).
9 Repeat steps 3 through 6 to add more
songs.
10 Press P to return to the home screen.
edit a playlist
1 Press S right to open BGETITNOW .
2 Scroll to Get Tunes & Tones and press OK ( s ).
3 Scroll to Manage Music and press OK ( s ).
4 Scroll to Playlists and press OK ( s ).
5 Scroll to the playlist you want to edit and
press the
Options key.
6 Scroll to Edit Playlist and press OK ( s ).
7 Edit the playlist as desired.
To change the order of songs in your
playlist, scroll to a song and press
Move .
Then scroll up or down to move the song
up or down in the playlist. When finished,
press
Save .
To delete a song, scroll to the song and
press
Remove .
8 Press P to return to the home screen.
play music
Use the MusicPlayer to play music files that
you download from the V CAST Music catalog
(see page 14).
Find it: Press MENU ( s )  BGET IT NOW
 Get Tunes & Tones
1 Scroll to My Music and press OK ( s ).
The MusicPlayer opens and displays a list
of music files on phone memory and the
microSD™ (TransFlash) memory card.

18
main attractions
2 Scroll to a desired song and press
PLAY ( s ) to play the song. (The song
plays only once.)
or
Select Playlist to see a list of your playlists.
or
Press the Options key to open the Options
menu (see the table following these
steps).
3 If you select a playlist or Play All Songs , press
the navigation key
S right during a song
to advance to the next song in the current
playlist. Press the navigation key
S left
to skip to the previous song.
Press the
Options key while a song is
playing to access these functions:
Note: Any music currently playing is
stopped when you press the
Options key.
Play All —Play all songs in the playlist.
Shuffle —Play songs from the playlist in
random order.
Get V CAST Music —Connects you to the
V CAST Music catalog to download more
songs.
When you select a song and press the
Options
key, your phone displays the following
options:
option
Move
Move the song from the memory card to
the phone, or from the phone to the card.
Lock
Note: This option may not be available for
all songs.
Lock the song to prevent it from being
deleted.

19
main attractions
record & play voice
records
You can create a voice record and play it back
later. This feature allows you to create
reminders for yourself.
create voice record
Tip: Press and go! Create a voice record
quickly by pressing and holding the voice
button (on the right side of the phone). When
you finish recording, press
Save to save the
voice record,
SEND ( S ) to send it in a
message, or
Erase to delete it.
Find it: Press MENU ( s )  BGET IT NOW
 Get Tunes & Tones
1 Scroll to Record New and press OK ( s ).
2 Press OK ( s ) to begin recording, then
press
STOP ( s ) when finished.
The voice record is automatically saved, and
your phone displays the
Get Tunes & Tones list.
You can now select
Erase , Play , or Options .
Tip: After you create a voice record, you can
give it a new name. In your
Get Tunes & Tones
listing, your phone displays an indicator next
to the names of voice records that you
Erase
Delete the selected song.
Erase All
Erase all songs.
Song Info
Displays the following information for the
selected song: title, artist, album title,
genre, copyright year, duration, and track
number (if available).
option
